Pioneer SE-S3BT-B User Manual

Wireless Stereo Headphones

S3wireless

Scene style series

BLUEGR AY

BLACKBLACK PINK

Travel deeper into music and leave time behind

With support for 25 hours’ continuous playback, you’re free to dive into music and forget the passage of time with no battery worries. The S3wireless also features Fast Charge providing four hours’ playback in just 10 minutes, enough to get you where you’re going. Extra-large φ 40 mm (1 musical experience. Operability is simple with a single button handling music control, call management, and press-activation of smartphone voice assistants. Like the Pioneer name—respected by DJs all over the world thanks to our long association with hip-hop, electronic, and club music culture—the S3wireless has authenticity other brands can’t match. Minimalist Japanese styling and a portfolio of four distinctive, carefully matched color-schemes complement functional yet elegant proportions.

/16˝) drivers reproduce deep, powerful bass, while support for the AAC codec, ideal for the iPhone, delivers a higher-quality

Black Gray Blue Pink

SOUND QUALITY FEATURES

› Extra-large Φ 40 mm (1 9/16˝) drivers for deep bass › Clear, balanced, natural sound with powerful low-frequency response › Supports AAC codec for enhanced audio quality › Deep housing and earpad proﬁle optimize acoustics and immersion

WIRELESS HANDS-FREE FUNCTIONS

› Features the latest Bluetooth® 5.0 wireless technology › Button activates Voice Assistant/Call Reject (press and hold center); Play/

Pause and Call Accept/End (press center); Redial (double-press center); Volume Up/Down (press up/press down); and Track Skip Forward/Back

(press and hold up/press and hold down) › Easy press-and-hold activation of smartphone voice assistants › Pair two devices with Multi-point Function, enabling call monitoring on

smartphone and music playback from tablet simultaneously › Supports free Pioneer Notiﬁcation App for Android

notiﬁcations of text messages, emails, SNS, and more via headphones

™

which reads out

BATTERY & PLAYTIME

› Stamina Battery supports up to 25 hours continuous playback › Fast Charge replenishes battery for 4 hours playback in just 10 minutes › Battery fully recharges in approximately 2 hours

DESIGN ERGONOMICS

› Headphones fold ﬂat and inward for compact storage in bags › Convenient reversible USB Type-C charging terminal › Wide, lightweight headband distributes weight evenly for comfort

› Comfortable cushioned earpads suit most ear sizes › Color-matched parts including earpads, headband, and housings › Available in a choice of four color-schemes

SPECIFICATIONS & ACCESSORIES

› Model number: SE-S3BT › Transmission method: Bluetooth › Output: Bluetooth Standard Protocol Power Class 2 › Transmission distance: Up to 10 m (32 ft.) › Frequency used: 2.4 GHz (2.4000 GHz–2.4835 GHz) › Modulation: FHSS › Supported Bluetooth proﬁles: A2DP/AVRCP/HFP/HSP › Supported codecs: SBC/AAC › Multi-pairing: Max. 8 devices › Multi-point: Max. 2 devices › Battery: DC 3.7 V rechargeable lithium-ion › Battery time: Max. 25 hours of continuous

transmission (including audio playback) › Charging time: Approx. 2 hours › Type: Wireless on-ear stereo headphones › Driver: Φ 40 mm (1 › Frequency response: 10 Hz–22,000 Hz › Weight: 205 g (7.23 oz.) › Supplied with USB Type-C charging cable,

instruction booklet

/16˝) dynamic driver

Version 5.0

Package dimensions (W x H x D)

133 mm x 203 mm x 60 mm

(5 1/4˝ x 8 x 2 3/8˝)

Stamina Battery for 25 hours playback

You don’t need to recharge every day thanks to Stamina Battery, which delivers 25 hours continuous playback. Recharge in just two hours via the rotationally symmetrical USB Type-C terminal, which accepts the cable plug from either side for quick and easy connection.

Folding design for easy portability

Swiveling and folding mechanisms tuck the housings inside the headband for easy storage in your bag, no cable mess. Slim proﬁle lets it slip into narrow briefcases or handbags, so you really can have music wherever you go.

Access your voice assistant

Press and hold the center button to activate the voice assistant on your Google Assistant or Siri enabled smartphone. Once connected, your assistant will respond to a variety of commands without you needing to reach for your device.

Fast Charge in minutes

If you realize the battery’s low and you’re heading out, Fast Charge will push four hours’ worth of wireless playback into your headphones in just 10 minutes. Enough to get you to work or school with that playlist you’ve been looking forward to.

The biggest drivers in its class

The S3wireless packs some serious hardware with extra-large Φ 40 mm (1 drivers producing exhilaratingly deep bass and a clear mid-range for vocals. Support for the high-quality AAC wireless audio codec enhances a sense of resolution, and is ideal for use with the iPhone.

/16˝) dynamic

Connect two devices at once

Multi-point Function lets you wirelessly connect two devices at once. You can listen to music from your tablet while being connected and ready to take incoming calls from your smartphone.

Note: Only one device can make/receive calls or play audio at the same time.

Hands-free wireless music and calls

Everything you need for hands-free control, such as intuitive volume adjustment and track selection, is via a single multi-function button on the housing. Voice Assistant or Call Reject activates when the center button is pressed and held; Play/Pause and Call Accept/End with a single press (center); and Redial with a double press (center). Volume Up/Down is performed with a press up/press down gesture on either end of the button, while pressing and holding up or down skips tracks forward or back.

Bluetooth® 5.0 wireless

connectivity

The S3wireless incorporates the latest

Bluetooth

you have registered the headphones to your smartphone, it will connect automatically when selected from a list of available devices shown on your touchscreen.

5.0 wireless technology. Once

Raise Volume (Press Once) Skip Forward (Hold)

Play/Pause; Accept/End Call (Press Once)

Redial (Press Twice) Voice-Assistant Activation;

Call Reject (Hold)

Lower Volume (Press Once) Skip Back (Hold)

Power On/Off (Hold)

INTEGRATED TECHNOLOGIES

Pioneer Notification App for Android™ available from the Google Play store. Please check device and OS requirements before installation.

• “PIONEER” and the Pioneer logos are registered trademarks of Pioneer Corporation, and are used under license. • The Bluetooth® word mark and logos are registered trademarks owned by the Bluetooth SIG, Inc.

• Apple, iPhone, iPad, and Siri are trademarks of Apple Inc., registered in the U.S. and other countries. App Store is a service mark of Apple Inc.

• Google, Android, Google Assistant, Google Play and other related marks and logos are trademarks of Google LLC. • All other trademarks and registered trademarks are the property of their respective holders.

Note: Speciﬁcations and design are subject to change without notice.
