HTP-2900
High Power 5.1 Surround Sound System
Complete your home theater system with rich, powerful surround sound.
It's the perfect complement to your flat panel television.
A/V RECEIVER:
SX-217-K
PIONEER-EXCLUSIVE INNOVATIONS
Sound Retriever for Improved Sound Quality of Compressed Audio
›
Pioneer Hybrid Amplier Design
›
FEATURES FOR SUPERIOR
SOUND QUALITY
860 Watts Total System Power (RMS)
›
Built-in 6-Channel Amplier: 144 Watts x 6 (RMS 10 % THD, 1 kHz)
›
Continuous Power Output (FTC)
›
Front/Center/Surround: 100 Watts per Channel (200 Hz-20 kHz,
–
0.7 % THD, 8 Ω)
Subwoofer: 100 Watts (45 Hz-200 Hz, 0.7 % THD, 8 Ω)
–
New Freescale 180MIPS Processing DSP
›
Midnight Listening Mode
›
192 kHz/24-bit DAC
›
SURROUND SOUND TECHNOLOGIES
Built-in DTS® 96/24 / Dolby® Digital / Dolby® Pro Logic II Decoders
›
WMA9 Pro Decoder
›
Advanced Surround (9 Modes)
›
Dialogue Enhancement
›
Auto Surround
›
Virtual Surround Back Mode
›
ENHANCED CONVENIENCE
SR Remote
›
FL Dimmer (4 Steps)
›
Quick Setup Operation
›
Tuner Edit Operation
›
FM/AM Presets (30 Stations)
›
TERMINALS
A 3.5 mm Audio Jack Input on the Front Panel
›
3 Digital Inputs (2 Coaxial, 1 Optical) / 3 Audio Inputs
›
(Tuner Included) / 1 Audio Output
SPECIFICATIONS
Power Requirements: AC 120 V/60 Hz
›
Power Consumption: 320 Watts
›
Standby Power Consumption: 0.5 Watts
›
SPEAKER SYSTEM:
S-FCRW2900-K
Front/Surround: 3-1/16 inch (7.7 cm), Magnetically Shielded
›
Center: 3-1/16 inch (7.7 cm) Cone, Magnetically Shielded
›
Subwoofer: 6-5/16 inch (16 cm) Cone
›
Page 2
HTP-2900
High Power 5.1 Surround Sound System
RECEIVER DIMENSIONS
›
(W x H x D): 16-9/16 x 6-1/4 x 13-11/16 inches (420 x 158 x 348 mm)
›
Weight: 18 lbs. 15 oz. (8.6 kg)
SPEAKER SYSTEM DIMENSIONS
›
(W x H x D) Front/Surround: 3-15/16 x 5-3/8 x 3-1/8 inches
(100 x 136 x 80 mm)
›
Center: 10-5/8 x 3-3/4 x 3-9/16 inches (270 x 96 x 90 mm)
›
Subwoofer: 7-1/2 x 14-3/16 x 12-5/8 inches (190 x 360 x 320 mm)
Weight
›
Front/Surround: 1 lbs. 3 oz. (0.55 kg)
›
Center: 1 lbs. 11 oz. (0.78 kg)
›
Subwoofer: 8 lbs. 13 oz. (4.0 kg)
CONNECTIONS
Rear Panel
INTEGRATED TECHNOLOGIES
Specifications and design subject to modification without notice.
PIONEER and the Pioneer Logo are registered trademarks of Pioneer Corporation.
“DTS” is a registered trademark of DTS, Inc. and “DTS 96/24” is a trademark of DTS, Inc.
Pro Logic II, Dolby Digital and the double-D symbol are registered trademarks of Dolby Laboratories.
Windows Media® Audio 9 Professional, Microsoft, Windows Media and the Windows logo are trade-
marks, or registered trademarks of Microsoft Corporation in the United States and/or other countries.
Proprietary driver is required for WMA9 Pro playback on computer.
ENERGY STAR® and the ENERGY STAR certification mark are registered U.S. marks.
