Pioneer DEH-8018ZT User Manual
Audio System
TOYOTA PART NO.
PT546-00120
Owner’s Manual
for AM/FM/HD Radio Broadcast/CD Player with iPod/
USB control/Bluetooth-Audio
Alteration or modifications
carried out without appropriate
authorization may invalidate
the user’s right to operate the
equipment.
FCC ID : AJDK036
MODEL NO. : DEH-8018ZT
IC : 775E-K036
This device complies with Part
15 of the FCC Rules and RSSGen of the IC Rules. Operation
is subject to the following two
conditions: (1) this device may
not cause harmful interference,
and (2) this device must accept
any interference received,
including interference that may
cause undesired operation of
the device.
Information to User
Alteration or modifications
carried out without appropriate
authorization may invalidate
the user's right to operate the
equipment.
This transmitter must not
be co-located or operated in
conjunction with any other
antenna or transmitter.
This equipment complies with
FCC/IC radiation exposure limits
set forth for an uncontrolled
environment and meets the FCC
radio frequency (RF) Exposure
Guidelines in Supplement C to
OET65 and RSS-102 of the IC
radio frequency (RF) Exposure
rules. This equipment has
very low levels of RF energy
that it deemed to comply
without maximum permissive
exposure evaluation (MPE). But
it is desirable that it should be
installed and operated keeping
the radiator at least 20cm or
more away from person's body
(excluding extremities: hands,
wrists, feet and ankles).
WARNING
Handling the cord on this
product or cords associated
with accessories sold with
the product may expose
you to chemicals listed on
proposition 65 known to the
State of California and other
governmental entities to cause
cancer and birth defect or other
reproductive harm.
Wash hands after handling.
USE OF CONTROL OR ADJUSTMENT OR PERFORMANCE OF
PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION EXPOSURE.
THE USE OF OPTICAL INSTRUMENTS WITH THIS PRODUCT
WILL INCREASE EYE HAZARD.
[For Canadian model]
This Class B digital apparatus
complies with Canadian ICES-
003.
2
<CRB3644-B/U>2
Features
CD playback
Music CD/CD-R/CD-RW playback is
possible.
MP3 file playback
You can play back MP3 files
recorded on CD-ROM/CD-R/CD-RW
(ISO9660 Level 1/Level 2 standard
recordings) or USB portable audio
player/USB memory.
Supply of this product only con-
•
veys a license for private, noncommercial use and does not
convey a license nor imply any
right to use this product in any
commercial (i.e. revenue-generating) real-time broadcasting
(terrestrial, satellite, cable and/or
any other media), broadcasting/
streaming via internet, intranets
and/or other networks or in other
electronic content distribution
systems, such as pay-audio or
audio-on-demand applications.
An independent license for such
use is required. For details,
please visit
http://www.mp3licensing.com.
WMA file playback
You can play back WMA files
recorded on CD-ROM/CD-R/CD-RW
(ISO9660 Level 1/Level 2 standard
recordings) or USB portable audio
player/USB memory.
AAC file playback
You can play back AAC files
recorded on CD-ROM/CD-R/CD-RW
(ISO9660 Level 1/Level 2 standard
recordings) or USB portable audio
player/USB memory.
iPod compatibility
When you use this unit, you can
control an iPod, iPod classic, iPod
nano, iPod touch, iPhone. (Refer to
page 21.)
About WMA
Windows Media is either a registered trademark or trademark of
Microsoft Corporation in the United
States and/or other countries.
This product includes technology
owned by Microsoft Corporation
and cannot be used or distributed
without a license from Microsoft
Licensing, Inc.
NOTICE
This unit may not operate
correctly depending on the
application used to encode
WMA files.
3
<CRB3644-B/U>3
About iPod
Reproducing and playing back
•
non-copyrighted material and
material that can legally be
reproduced and played back for
private use is permitted with the
iPod. Infringement of copyright is
legally prohibited.
iPod and iPhone are trademarks
•
of Apple Inc., registered in the
U.S. and other countries.
“Made for iPod” and “Made for
•
iPhone” mean that an electronic
accessory has been designed
to connect specifically to iPod
or iPhone, respectively, and has
been certified by the developer
to meet Apple performance
standards. Apple is not
responsible for the operation of
this device or its compliance with
safety and regulatory standards.
Please note that the use of this
accessory with iPod or iPhone
may affect wireless performance.
4
•
Apple is not responsible for
the operation of this device or
its compliance with safety and
regulatory standards.
In this manual, iPod and iPhone
•
will be referred to as iPod.
About XM radio
XM Satellite Radio and all related
marks and logos are trademarks of
Sirius XM Radio Inc. and its subsidiaries. All rights reserved. Service
not available in Alaska and Hawaii.
About HD Radio™
Technology
HD RadioTM Technology manufactured under license from iBiquity Digital Corporation. U.S. and
Foreign Patents. HD RadioTM and
the HD, HD Radio, and “Arc” logos
are proprietary trademarks of iBiquity Digital Corp.
About Bluetooth
The Bluetooth® word mark and
logos are registered trademarks
owned by Bluetooth SIG, Inc. and
any use of such marks by Pioneer
Corporation is under license. Other
trademarks and trade names are
those of their respective owners.
<CRB3644-B/U>4
Important information
about this manual
For safety reasons, this manual
indicates items requiring particular
attention with the following marks.
NOTICE
This is a warning against
anything which may cause
damage to the vehicle or its
equipment if the warning is
ignored. You are informed about
what you must or must not do
in order to avoid or reduce the
risk of damage to your vehicle
and its equipment.
CAUTION
This is a warning against anything which may cause injury to
people if the warning is ignored.
You are informed about what
you must or must not do in
order to reduce the risk of injury
to yourself and others.
To ensure the correct
audio system operation
Do not allow this unit to come
•
into contact with liquids.
Electrical shock could result.
Also, this unit damage, smoke,
and overheat could result from
contact with liquids.
Do not put anything other than a
•
Compact Disc into the slot.
The use of cellular phones inside
•
or near the vehicle may cause
noise from the audio system
speakers you are listening to.
However, this does not indicate a
malfunction.
The Safety of Your
Ears is in Your Hands
Get the most out of your equipment by playing it at a safe level—a
level that lets the sound come
through clearly without annoying
blaring or distortion and, most
importantly, without affecting your
sensitive hearing. Sound can be
deceiving. Over time, your hearing
“comfort level” adapts to higher
volumes of sound, so what sounds
“normal” can actually be loud and
harmful to your hearing. Guard
against this by setting your equipment at a safe level BEFORE your
hearing adapts.
ESTABLISH A SAFE LEVEL:
Set your volume control at a low
•
setting.
Slowly increase the sound until
•
you can hear it comfortably and
clearly, without distortion.
Once you have established a
•
comfortable sound level, set the
dial and leave it there.
BE SURE TO OBSERVE THE
FOLLOWING GUIDELINES:
Do not turn up the volume so
•
high that you can’t hear what’s
around you.
Use caution or temporarily
•
discontinue use in potentially
hazardous situations.
Do not use headphones while
•
operating a motorized vehicle;
the use of headphones may
create a traffic hazard and is
illegal in many areas.
5
<CRB3644-B/U>5
Contents
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
About WMA . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
About iPod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
About XM radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
About HD Radio Technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
About Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Impor tant information about this manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
To ensure the correct audio system operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
The Safet y of Your Ears is in Your Hands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Main Displays and Possible Operation s . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Basic Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 -11
Listening to the RADIO. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12-13
Listening to the HD Radio broadcast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14-15
Listening to a CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-17
Listening to MP3/W MA /AAC DISC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18-20
About handling the iPod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20-21
Conne cting the iPod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21-22
Disconnecting the iPod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Listening to songs on the iPod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24-25
ABC SE ARCH on an iPod . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
About handling the USB por table audio player/USB memor y. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Conne cting the USB por table audio player/USB memor y . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Listening to USB por table audio player/USB memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
How to subscribe to X M Satellite Radio <Option> . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Display the R ADIO ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Listening to a XM Satellite Radio broadcast. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34-35
Using the AUX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36-37
Bluetooth Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38- 40
Listening to Bluetooth -Audio player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42-43
Phone Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44 -47
Using Hands-Fre e Phoning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 8
Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Changing the Opening Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 -51
Initial Set ting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Conne cting an ex ternal amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Using the Steering C ontroller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53-54
MP3, WMA and A AC files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
MP3 additional information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
WMA additional information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
AAC additional information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
About folders and MP3/W MA /AAC files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
USB por table audio player/ USB memory compatibility . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
CD player and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
CD- R and CD-RW discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
DualDiscs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Error indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 0- 63
Changing or dis connecting your battery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
6
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 4
<CRB3644-B/U>6
Main Displays and Possible Operations
Possible operations are indicated.
Turn the MULTI KNOB to the right or left to
adjust the volume level, select a menu or select
an item from a list. Press the MULTI KNOB in the
center to set a selecting an item.
The following are the main displays that appear during
UP/DOWN/RIGHT/LEFT and MULTI KNOB operation. Each
display indicates the operations that are currently available.
You can select the next or the previous track
on a CD or iPod by pressing the RIGHT/LEFT.
You can select the next or the previous track or select a
folder on a CD , in a USB memory or Bluetooth-Audio
player by pressing the UP/DOWN/RIGHT/LEFT.
You can tune or seek a radio frequency by
pressing the UP/DOWN/RIGHT/LEFT.
You can tune the Satellite Radio broadcasting
frequency or display and switch the category
by pressing the UP/DOWN/RIGHT/LEFT.
MULTI
KNOB
LEFT
You can select a setting option, etc. by
pressing the UP/DOWN/RIGHT/LEFT or
UP/DOWN.
or
You can select a setting option, etc. by
pressing the center of the MULTI KNOB.
You can navigate a list or edit the OPENING
TITLE by pressing the MULTI KNOB in the
center or the UP/DOWN/RIGHT/LEFT.
UP
RIGHT
DOWN
7
<CRB3644-B/U>7
Basic Operation
Your audio system works when the
ignition switch is in the “ACC” or
“ON” position.
NOTICE
To avoid draining the battery,
do not leave the car audio on
longer than necessary when the
engine is not running.
1 POWER
Press to turn the unit on or off.
2 MULTI KNOB/VOLUME
Turn the MULTI KNOB to raise/lower
the volume levels (total volume step
is 64). MULTI KNOB operation varies
depending on the audio source or
Menu. (Refer to page 7.)
To select the following setting
options, press the MULTI KNOB to
switch to the AUDIO MENU. Turn
the MULTI KNOB clockwise or counterclockwise to select an item and
press the MULTI KNOB. You can
select SET TINGS in TUNER mode or
iPod mode.
SSP AUDIO CTRL SETTINGS
BLUETOOTH PHONE
8
<CRB3644-B/U>8
SSP (Scion Sound Processing)
•
SSP is a modified DSP (Digital Signal
Processing) system that provides a
customized sound for your vehicle.
Press the MULTI KNOB to display
the current SSP mode setting.
While the setting is displayed, press
repeatedly to switch to the following
modes.
NATURAL:
Natural and smooth sound
that gives no listening
fatigue but comfort.
HEAR:
A powerful, energetic, live
sound.
FEEL:
Player’s sound –> reproduces the sound on the stage
that musicians hear.
For more details, please visit the SCION
Web site at
http://www.scion.com/.
Each time you press it, the SSP changes
in the following order:
NATURAL HEAR FEEL
AUDIO CTRL
•
When the MULTI KNOB is turned,
the setting item of the AUDIO CTRL
menu will switch in the following
order:
FADER BALANCE BASS TREBLE
ASL (Automatic Sound Levelizer) SUB-W
(Subwoofer) ASR (Sound Retriever)
FADER: Turn the MULTI KNOB to adjust the
sound balance between the rear and
front speakers.
The display ranges from R7 to F7.
BALANCE:
Turn the MULTI KNOB to adjust the
sound balance between the left and
right speakers. The display ranges
from L7 to R7.
BASS: Turn the MULTI KNOB to adjust low-
pitched tones. The display ranges from
–5 to 5.
TREBLE:
Turn the MULTI KNOB to adjust highpitched tones. The display ranges from
–5 to 5.
ASL: During driving, noise in the car changes
according to the driving speed. The
Automatic Sound Levelizer (ASL)
automatically adjusts the volume based
on driving speed. If this noise becomes
greater, the sensitivity (variation of
volume level to noise level) of ASL can
be set to one of three levels. Press the
MULTI KNOB changes the ASL setting
as follows:
LOW MID HIGH OFF
SUB-W:
Subwoofer output phase can be
switched between normal and reverse
by pressing the MULTI KNOB, Turn
the MULTI KNOB up or down to adjust
the output level of the subwoofer.
Each time MULTI KNOB is turned up
or down, subwoofer level increases or
decreases. (+6 to –24 is displayed as
the level is increased or decreased.)
• The output level and output phase
of the subwoofer can be adjusted
only when "SUB-W CTRL" on the
SETUP MENU is set to ON. While
"SUB -W CTRL" is set to OFF, the
output level and output phase cannot
be adjusted. (Refer to page 52.)
ASR: The ASR (Sound Retriever) function
provides a wide, deep and rich quality
to MP3/WMA/AAC sound, which gives
the user a lively impression. Pressing the
MULTI KNOB repeatedly switches the
setting in the followin g ord er :
LOW RATE
LOW RATE:
Effective for low-compres-
HIGH RATE:
Effective for high -compres-
HIGH RATE OFF
sion audio media.
sion audio media.
<CRB3644-B/U>9
9
NOTICE
The ASR function can only be
•
selected when playing MP3/
WMA/AAC from CD and iPod,
USB portable audio player/
USB memory/BluetoothAudio.
The ASR function does not
•
support external compressed
audio media.
Switching of ASR settings is
•
disabled in Bluetooth-Audio
mode when no Bluetooth
device is connected or when
settings cannot be switched.
BASS function and TREBLE
•
function values can be set for
each of the modes (AM, FM,
CD/MP3/WMA/AAC, iPod/USB
portable audio player/USB
memory, XM Satellite Radio,
Bluetooth audio player, AUX).
When you switch modes, the
settings change to the BASS
and TREBLE values set for the
selected mode.
The ASL function is only
•
effective when the vehicle is
moving.
•
SETTINGS
You can select this item in TUNER
mode or iPod mode.
If you select SETTINGS, you can set
the following items.
• HD ON/OFF (in TUNER mode)
• IPOD DIRECT (in iPod mode)
• AUDIO BOOK (in iPod mode)
To select a setting option in iPod
mode, turn the MULTI KNOB clockwise or counterclockwise and press
the MULTI KNOB.
IPOD DIRECT AUDIO BOOK
HD ON/OFF:
If you set HD ON /OFF to ON, digital
broadcasting is preferentially selected.
During SCAN or SEEK operations, the
tuner searches for all digital and analog
broadcasting stations.
If you set HD ON /OFF to OFF, only
analog broadcasting is selected. During
SCAN or SEEK operations, the tuner
searches only for analog broadcasting
stations.
When the MULTI KNOB is pressed,
switches in the following order:
ON OFF
• The setting can only be changed in
RADIO mode.
IPOD DIRECT:
A menu for turning on or off iPod direct
control (in iPod mode). If you select ON,
you can control iPod operations on the
iPod, and you can control only the volume of iPod from this unit. If you select
OFF, you can control iPod operations
from this unit.
When the MULTI KNOB is pressed,
switches in the following order:
OFF ON
• The setting can only be changed in
iPod mode.
AUDIO BOOK:
You can change the iPod Audiobook
playback speed.
Pressing the MULTI KNOB repeatedly
switches the setting in the following
order:
NORMAL FASTER SLOWER
• The speed can only be changed in
iPod mode.
• While IPOD DIRECT is set to ON, the
speed cannot be changed.
NOTICE
iPod (5th generation) and iPod
nano (1st generation) do not
support iPod direct control.
10
<CRB3644-B/U>10
BLUETOOTH
•
If you select BLUETOOTH, you can
make the settings for connecting and
controlling Bluetooth devices.
To select the following setting
options, turn the MULTI KNOB
clockwise or counterclockwise and
press the MULTI KNOB. Refer to
page 38 “Bluetooth Settings.”
BT PAIRING LIST PHONE LIST
AUDIO SET PASSKEY BT POWER
ON/BT POWER OFF BT INFO
DISPLAY ON/DISPLAY OFF INITIALIZE
BT PAIRING:
You can connect your Bluetooth
devices.
LIST PHONE:
You can connect or disconnect a reg istered Bluetooth-compatible mobile
phone, or delete it from the list.
LIST AUDIO:
You can connect or disconnect a reg istered Bluetooth device, delete the
device from the list, and select the
connection method.
SET PASSKEY:
You can set the passkey.
BT POWER ON/BT POWER OFF:
You can select whether or not to automatically connect a Bluetooth device
when the ignition switch is set to ON.
BT INFO:
You can check the name and address
of this unit.
DISPL AY ON/DISPLAY OFF:
You can select whether or not to display the connection confirmation when
a Bluetooth device is connected by
setting the ignition switch to ON.
INITIALIZE:
You can initialize certain setting information or all settings.
PHONE
•
If you select PHONE, you can edit
the phonebook, set the ring tone or
transfer the call histories.
To select the following items, turn
the MULTI KNOB clockwise or counterclockwise and press the MULTI
KNOB.
PHONE BOOK SET HF SOUND SEND
HISTORY
PHONE BOOK:
You can edit the phonebook in this
unit.
SET HF SOUND:
When a mobile phone is connected,
you can select the ring tone and adjust
the volume of the call tone and ring
tone.
SEND HISTORY:
You can transfer the call histories on
the connected mobile phone to this
unit.
When the MULTI KNOB is pressed,
switches in the following order:
YES NO
3 BACK
Press the BACK button to exit from
the menu.
Press and hold the BACK button to
exit from a list that was displayed by
pressing the LIST/MENU button.
<CRB3644-B/U>11
11
Listening to the RADIO
1 FM1/2
Switches between FM1 and FM2
modes.
2 AM•SAT
Switches between the AM mode and
SAT1/2/3 modes. (must have Satellite
Radio receiver and antenna installed at
an additional charge to listen to Satellite
Radio.)
3 LIST/MENU
Press to display the registered broadcasting station list in PRESET1-6.
Use the MULTI KNOB to select a station from the list.
12
<CRB3644-B/U>12
4 MULTI KNOB (SELECT LIST)
Turn the MULTI KNOB clockwise
or counterclockwise to select a station. Press the MULTI KNOB to set
the station. If you press and hold the
MULTI KNOB in the center until you
hear a beep, the currently tuned station is stored as a preset channel in
the preset channel list.
5 RIGHT (TUNE <UP>)
Press to manually select (one step
at a time) the station with the next
higher frequency.
fast-forward to a higher frequency.
Press and hold to
6 UP (TUNE <UP>)
Press to select the next higher station.
Press and hold to continue searching
for a higher frequency station.
7 LEFT (TUNE <DOWN>)
Press to manually select (one step
at a time) the station with the next
lower frequency. Press and hold to
fast-forward to a lower frequency.
8 DOWN (TUNE <DOWN>)
Press to select the next lower
station.
Press and hold to continue searching
for a lower frequency station.
9 PRESET 1-6
Press to recall previously stored stations (Preset Channels).
Press and hold until you hear a
beep, and the station you are currently tuned to is stored as a Preset
Channel.
NOTICE
You can store up to 6 stations
per band.
a SCAN
If you press, is indicated in the
display. The tuner begins searching
for stations with good reception and
you can listen to each channel for 5
seconds.
<CRB3644-B/U>13
13
Listening to the HD
Radio broadcast
HD RadioTM Technology is a terrestrial
digital radio broadcast that utilizes
AM/FM analogue broadcasting frequencies to transmit digital signals.
For information regarding viewing
methods, refer to Listening to the
RADIO (page 12). This section contains explanations solely regarding
HD Radio broadcast functions.
14
<CRB3644-B/U>14
1 RIGHT (TUNE <UP>)
When receiving the HD Radio
Broadcast signal and tuning in
a Multicast Channel-supported
broadcast in something other than
analogue, the following actions will
occur each time you press.
When
The first SPS is tuned in.
receiving
MPS
signal
When
The next SPS is tuned in.
receiving
SPS
signal
When
receiving
The next MPS is tuned
in.
last SPS
2 LEFT (TUNE <DOWN>)
When receiving the HD Radio
Broadcast signal and tuning in
a Multicast Channel-supported
broadcast in something other than
analogue, the following actions will
occur each time you press.
When
receiving
MPS
signal
The previous MPS is
tuned in.
When
receiving
SPS
The previous SPS is
tuned in. Or, the next
MPS is tuned in.
signal
When
The first SPS is tuned in.
receiving
next SPS
signal
3 TEXT
If you press while the HD Radio
broadcasting signal is being recieved,
the display switches in the following
order.
Upper: Station Name
Lower: Frequency
Album Title
Song Title
When is displayed, if you press
and hold until you hear a beep, the
display will changes. A maximum of
2 pages (24 characters) can be displayed.
Artist Name
Song Title
<CRB3644-B/U>15
15
Listening to a CD
NOTICE
Never try to disassemble or
•
oil any part of the compact
disc player. Do not insert
anything except a compact
disc into the slot.
Use 12-cm disc. Do not use
•
8-cm disc or an adapter for
8-cm disc.
Load a CD in the CD slot.
No title name is displayed when playing back a CD containing no te xt information.
16
<CRB3644-B/U>16
1 DISC
Switches to the CD mode. (Only
effective if a disc is loaded.)
2 (EJECT)
Press to eject the disc.
3 LIST/MENU
Press to display a CD List.
Use the MULTI KNOB to select a CD
from the list.
4 MULTI KNOB (SELECT LIST)
Turn the MULTI KNOB clockwise
or counterclockwise to select the
desired title. Press the MULTI KNOB
in the center to start playback.
• No CD List is displayed when playing back a CD containing no text
information.
5 UP/DOWN (SELECT LIST)
Press to select the desired title.
6 RIGHT (TRACK <UP>)
Press to proceed to the next track.
Press and hold until you hear a beep.
Playing of the track is fast forwarded.
(There is sound.)
7 LEFT (TRACK <DOWN>)
Press to takes you back to the start
of the track currently playing. Press
to return to the previous track once
more.
Press and hold until you hear a beep.
Playing of the track is reversed.
(There is sound.)
8 PRESET1 (PLAY/PAUSE)
To pause the CD, press PRESET 1
while the CD is playing. Press again
to resume playing.
9 PRESET5 (Random)
If you press this, and is
indicated in the display. This unit
starts to play tracks on the disc being
played in random order. Press again
to cancel.
a PRESET6 (Repeat)
If you press this, and is indicated in the display. This unit starts
to repeat the track being played.
Press again to cancel.
b SCAN
If you press this, and is indicated in the display. This unit starts
to play the first 10 seconds of each
track on the CD being played. Press
again to cancel.
c TEXT
Press, and display indications change
as follows (TEXT CD only):
Upper: Artist Name
Lower: Track Title
Disc Title
Tra c k Tit l e
When is displayed, if you press
and hold until you hear a beep, the
display will changes. A maximum of
2 pages (24 characters) can be displayed.
Tra c k Tit l e
ELAPSED TIME
CAUTION
Compact disc players use an
invisible laser beam which
could cause hazardous radiation
exposure if directed outside
the unit. Be sure to operate the
player correctly.
<CRB3644-B/U>17
17
Listening to MP3/
WMA/AAC DISC
1 DISC
Switches to the DISC mode. (Only
effective if a disc is loaded.)
2 (EJECT)
Press to eject the disc.
3 LIST/MENU
Press to display an MP3/ WMA/AAC List.
Use the MULTI KNOB to select an item
from the list.
4 MULTI KNOB (SELECT LIST)
Turn the MULTI KNOB clockwise or
counterclockwise to select a file or
folder.
Press the MULTI KNOB in the center
to play the selected file or folder. Use
the MULTI KNOB to select an item
from the list.
(When a folder is selected, the first
track in the folder is played.)
The MP3/ WMA/AAC List is displayed when the top folder in the
root directory or the file or folder
name is selected.
18
<CRB3644-B/U>18
5 RIGHT (TRACK <UP>)
Press to proceed to the next file.
Press and hold until you hear a beep.
Playing of the file is fast forwarded.
(There is no sound.)
6 LEFT (TRACK <DOWN>)
Press to takes you back to the start
of the file currently playing. Press to
return to the previous file once more.
Press and hold until you hear a beep.
Playing of the file is reversed. (There
is no sound.)
7 UP (FOLDER <UP>)
Press to proceed to the next folder.
8 DOWN (FOLDER <DOWN>)
Press to return to the previous folder.
Press and hold until you hear a beep
to jump to HOME.
HOME means returning back to play
the first file in the first folder on the
CD being played.
9 PRESET1 (PLAY/PAUSE)
To pause the track, press PRESET
1 while the track is playing. Press
again to resume playing.
a PRESET5 (Random)
If you press this, and is indicated in the display. This unit starts
to play files in the folder being played
in random order. Press again to cancel.
If you press and hold until you hear a
beep,
display. This unit starts to play files in
all folders on the disc being played in
random order. Press again to cancel.
and is indicated in the
b PRESET 6 (Repeat)
If you press this, and is indicated in the display. This unit starts
to repeat the file being played. Press
again to cancel.
If you press and hold until you hear a
beep,
display. This unit starts to repeat the
folder being played. Press again to
cancel.
and is indicated in the
c SCAN
If you press this, and is indicated in the display. This unit starts
to play the first 10 seconds of each
file in the folder being played. Press
again to cancel.
If you press and hold until you hear a
beep,
display. This unit starts to play the
first 10 seconds of the first file of
each folder. Press again to cancel.
and is indicated in the
d TEXT
Press and display indications change
as follows:
Upper: Artist Name
Lower: Track Title
Folder Name
File Name
When is displayed, if you press
and hold until you hear a beep, the
display will changes. A maximum of
2 pages (24 characters) can be displayed.
Tra c k Tit l e
ELAPSED TIME
<CRB3644-B/U>19
19
NOTICE
When playing back a disc
recorded with the Multi
Session system, the first
session only is played back.
If the first session combines
MP3, WMA and AAC files
and music data (CD-DA), this
product only plays the music
data. (Refer to page 54.)
About handling the
iPod
About iPod settings
This unit supports only an iPod
•
featuring the Dock connector
port.
Operations may vary depending
•
on the software version of iPod.
The iPod Equalizer setting set by
•
the iPod is not used.
The Shuffle function of the iPod
•
is operated as Random on this
unit.
CAUTION
Store the data into another
•
media, to avoid losing the
data during iPod operation
with this unit.
Do not allow direct
•
sunlight to fall on the
iPod when it is not being
used. Extended exposure
to direct sunlight can
result in iPod malfunction
due to the resulting high
temperatures.
Do not leave the iPod in
•
high temperatures or direct
sunlight.
Fix the iPod securely when
•
using with this unit. Do not
let the iPod fall onto the floor,
where it may become jammed
under the brake or accelerator
pedal.
For details, refer to the User Guide
of your iPod.
20
<CRB3644-B/U>20
Loading...
