Using This Guide
This guide contains information to help you prepare your site for
installing Avid Unity™ MediaNet hardware. By following these site
preparation guidelines, you can help ensure the smooth and successful
installation of your Avid Unity MediaNet environment. You can also
avoid delays in getting your Avid Unity MediaNet Server, sto rage subsystem, and connected Avid Unity MediaNet clients up and running.
This guide includes:
• A site planning overview
• System layout
• Environmental requirements
• Electrical requirements
• Networking requirements
n
• A site planning check list
Your MediaNet environment might not contain certain features that are
described in your documentation. Avid’s documentation describes all features
regardless of which model you purchased.
8
Who Should Use This Guide
This guide is intended for system administrators and facilities personnel who are preparing the site for the Avid Unity MediaNet installation.
About This Guide
The information in this guide is organized as follows:
• Chapter 1, “Site Planning Overview” provides general information about setting up your site, customer responsibilities, and
selecting a location for your MediaNet hardware.
• Chapter 2, “System Layout” discusses the various available system configurations and provides dimensions and weight of the
MediaNet components for planning system floor space and
loading.
• Chapter 3, “Environmental Requirements” describes the environment for the MediaNet hardware, including necessary temperature and humidity limits.
• Chapter 4, “Electrical Requirements” describes the power requirements for the MediaNet hardware, including special plugs and
outlets.
• Chapter 5, “Networking Requirements” discusses how the
MediaNet environment can be connected to an in-house or standalone 10BASE-T/100BASE-T network.
• Chapter 6, “Site Planning Check List” provides a list of all the necessary items to complete before the MediaNet hardware installation can begin.
9
Symbols and Conventions
The Avid Unity MediaNet documentation uses the following special
symbols and conventions:
1. Numbered lists, when order is important.
a. Alphabetical lists, when the order of secondary items is
important.
• Bulleted lists, when the order of the items is unimportant.
- Indented dashed lists, when the order of subtopics is unimportant.
Look here in the margin
for tips.
n
c
w
In the margin you will find tips that help you perform tasks more easily and efficiently.
A note provides important related information, reminders, recommendations,
and strong suggestions.
A caution means that a specific action you take could cause harm to
your computer or cause you to lose data.
A warning describes an action that could cause you physical harm.
Follow the guidelines in this guide or on the unit itself when handling electrical equipment.
10
If You Need Help
If you are having trouble using Avid Unity MediaNet, you should:
1. Retry the action, carefully following the instr uctions given for that
2. Check the documentation that came with your hardware for main-
3. Check the Customer Service and News + Publications sections of
4. Check the Avid Bulletin Board, “Avid Online,” for information on
5. Contact your local Avid Reseller; in North America, you may con-
task in this guide.
tenance or hardware-related issues.
the Avid Web site at http://www.avid.com for the latest FAQs,
Tips & Techniques, Film + Television Update, and other Avid
online offerings.
product and user conferences. If you do not find the solution to
your problem, you can exchange information with other Avid customers and Avid Customer Support representatives.
tact Avid Customer Support at 800-800-AVID (2843).
n
For general information, call your local Avid Reseller; in North America, call
the Avid Customer Relations Desk at 800-894-5654.
Related Information
The following documents provide more information about MediaNet:
• Avid Unity MediaNet Setup Guide
• Avid Unity MediaNet Administration Guide
• Avid Unity MediaNet Quick Start Card for Macintosh Clients
• Avid Media Composer Products Site Preparation Guide for Macintosh
systems
• Avid Media Composer Products Setup Guide for Macintosh systems
11
If You Have Documentation Comments
Avid Technology continuously seeks to improve its documentation.
We value your comments about this guide or other A v id-supplied documentation.
Simply e-mail your documentation comments to Avid Technology at
TechPubs@avid.com
Please include the title of the document, its part number, revision, and
the specific section you are commenting on in all correspondence.
How to Order Documentation
To order additional copies of this documentation from within the
United States, call Avid Telesales at 800-949-AVID (2843). If you are
placing an order from outside the United States, contact your local
Avid representative.
12
CHAPTER 1
Site Planning Overview
You need to carefully plan for space, environmental, and power
requirements for your Avid Unity MediaNet hardware so the installation proceeds smoothly. During your planning you need to consider:
• Which MediaNet hardware components are standard and which
are optional. This can effect your installation date if you need to
obtain some optional components from sources other than Avid.
• The environment into which you are installing the MediaNet
hardware. You might need to make adjustments to keep the components within their normal operating limits.
• The electrical capacity of the area where you are installing the
MediaNet hardware. You will need to upgrade the power and
electrical outlets to support the UPSs supplied with your
MediaNet hardware.
• Connections for a telephone line. You will need the telephone line
to obtain Avid dial-up support.
You should refer to this guide anytime you plan to move the hardware, or when you install additional components to expand the capacity of your Avid Unity MediaNet storage subsystem.
13
Standard MediaNet Hardware Components
The following hardware components are supplied with all MediaNet
environments:
• One or two UPSs
• One to six MEDIArray™ enclosures
• One MEDIAhub, or one or two MEDIAswitches
• One MediaNet Server with keyboard and modem
• Copper cables
Optional MediaNet Hardware Components
The following hardware components are optional with all MediaNet
environments. You can purchase these components separately or from
Avid:
• The rack
• The display for the MediaNet Server
• Optical cables
Choosing the System Location
The MediaNet hardware is modular and consists of the MediaNet
Server, the MEDIAswitch or MEDIAhub, and the MEDIArray storage
subsystem. Avid recommends that you plan to mount all the components in a rack and provide proper computer-room space for the hardware.
14
You need to be aware of the following requirements whether you are
providing computer-room space or other properly prepared space for
your hardware:
• Locate the hardware away from high-traff ic areas and potential
impacts. High-traffic areas include patch panels, experimental
equipment, or equipment that needs frequent physical reconfiguration.
• Choose a location where the hardware will be free from significan t
temperature or humidity changes, or possible damage from moisture. See Chapter 3
for information on environmental limitations.
• Locate the hardware in a clean environment, free from smoke and
dust. Do not place any hardware over or near ventilation holes in a
raised-floor computer room. Do not place any hardware under
ceiling or wall ventilation ducts or cold air returns. Dust from the
ventilation can cause problems with the hardware.
• Verify that the location you select has a sturdy, level floor, and is
not subject to vibration. The rack holding the hardware must be
stable during normal operation and service. See Chapter 2
for the
weights of all the hardware components.
• Make sure the hardware has adequate space in front of and behind
the rack for times when service or reconfiguration is necessary. If
the rack has a door, it must be able to open completely to allow
access to the front panels of the hardware. See Chapter 2
for infor-
mation on rack clearances.
• Make sure there is adequate power and the corr ect r eceptacle type
for each hardware component, the rack power strips, or the
optional uninterruptible power supply (UPS). Do not use extension cords to plug in any of the hardware components. See Chap-
ter 4 for information on power requirements.
• Make sure you have Ethernet connections near the MediaNet
Server and MEDIAswitch. This allows for connections to the network for troubleshooting, when necessary. This connection can
also be used by A vid for performing diagnostics. See Chapter 5
for
information on network requirements.
15
• Make sure you have a telephone connection for a modem near the
MediaNet Server. This will be used by Avid Customer Support to
dial into the MediaNet Server to check configuration issues, reconfigure the MEDIAswitch, or perform diagnostics. You might also
want to have a second telephone line for a telephone handset to
allow you to talk with A v id Customer Support fr om the MediaNet
Server location.
• For some configurations, make sure you have a table next to the
MediaNet rack to hold the MediaNet Server.
Customer Responsibility
Before installing your MediaNet hardware, you are responsible for:
• Developing a floor plan for your hardware configuration. This
includes the MediaNet hardware and any attached MediaNet
clients.
• Preparing your site to meet all the proper power, environmental,
and space requirements for the MediaNet hardware and any
attached MediaNet clients. To obtain site requirements for your
MediaNet clients, see the Avid Media Composer Products Site Prepa-
ration Guide for Macintosh systems.
n
• Obtaining a rack for mounting the UPSs, the MEDIArray enclosures, the MEDIAswitch or MEDIAhub, and the MediaNet Server.
You can purchase the rack separately or through Avid.
If you choose to purchase a rack rather than use the Avid MediaNet rack, the
rack must have 230-volt power strips with C-19 plugs on the ends of the
power cords to connect properly with the UPSs.
• Obtaining a display for the MediaNet Server. You can purchase
the display separately or through Avid.
16
• Obtaining and running all long copper cables (over 99 feet [30
meters]) between the MediaNet hardware and any attached
MediaNet clients throughout your facility. You must also provide
the proper hardware connections at both ends of the cables. You
can purchase these cables separately or through Avid.
• Obtaining and running all optical cables between the MediaNet
hardware and any attached MediaNet clients throughout your
facility. You must also pr ovide the pr oper hardwar e connections at
both ends of the cables. You must purchase these cables separately.
• Installing and configuring any Ethernet routers or bridges before
the Avid representative begins your system installation.
• Running all cables related to Ethernet, and providing the proper
network setup and connections.
• Installing appropriate Ethernet connections within the areas
where MediaNet hardware and MediaNet clients are being
installed.
• Installing an analog telephone line for Avid dial-up support.
c
Avid is not responsible for installing or troubleshooting cables that
you do not purchase from Avid. Avid also does not provide network
services and strongly suggests you use a local service provider to
install and set up network connections.
17
CHAPTER 2
System Layout
Avid Unity MediaNet is available in four standard configurations.
These configurations are fully rack-mountable. They are compatible
with the Avid Unity MediaNet rack or any standard 19-inch video
racks using either NEMA or EIA mounting-hole layouts. The configurations are:
• Three MediaNet clients, 180-GB storage, and a MEDIAhub
• Three MediaNet clients, 180-GB storage, and a MEDIAswitch
• Five MediaNet clients, 540-GB storage, and a MEDIAswitch
• Nine MediaNet clients, 1080-GB storage, and two MEDIAswitches
Figure 2-1
client MediaNet hardware. Use these rack layouts as a guide in determining how to plan the layout for your site. In its final form, your rack
might look a bit different from the standard configurations due to
additional hardware or site-specific layout re quirements.
shows possible rack layouts for the five-client and nine-
18
Avid Unity
Five-client hardware layout Nine-client hardware layout
Figure 2-1 MediaNet Rack Hardware Layout
Clearance and Access
Avid Unity
For normal operation, you’ll need to maintain approximately 2 feet
(0.6 meters) of open space in front of and behind the rack. This allows
free access to the components in the rack for operating changes or
adjustments.
For service, you’ll need approximately 3 feet (1 meter) of open space in
front of the rack and 2 feet (0.6 meters) of open space behind the rack.
This allows for the removal of any component that needs to be
replaced.
19
Airflow
Cables
Make sure that you do not obstruct the airflow around the rack with
large containers, boxes, desks, chairs, or other objects. This can cause
the MediaNet hardware in the rack to run at an elevated temperature
and possibly shorten individual component life.
Some optional racks are available with a fan located in the top of the
rack. If you select one of these racks, make sure the fan does not
become obstructed by dirt, dust, or paper so it can provide proper
cooling for the components in the rack.
You can use copper or optical cables to connect between the
MEDIAswitch or MEDIAhub and the MediaNet clients. You can mix
copper and optical cables in the same environment. You cannot mix
copper and optical cables within the same run.
For example, Figure 2-2
shows that any particular cable run must consist of only one cable material, either copper or optical. You cannot use
connectors within a run. Run A and Run B, however, can be of copper
cable and Run C of optical cable.
Avid Avid Avid
Run B
Run A Run C
(copper) (optical)
(copper)
MEDIAswitch
or MEDIAhub
Figure 2-2 Mixing Copper and Optical Cables
20
n
If you find your cable is not long enough for the distance you need it to run,
you must obtain a longer cable. Avid does not support more than one cable
within a particular run.
All cable runs between the MEDIAswitch or MEDIAhub and the
MEDIArray enclosures are made using copper cables that are 10 feet
(3 meters) or less.
Copper cables are fully shielded, 75-Ω (ohm), twin-axial Fibre Channel
cables with the shield fully bonded to a DB-9 connector at each end.
They can be used when the distance from the MediaNet client to the
MEDIAswitch or MEDIAhub does not exceed 99 feet (30 meters). Copper cables must meet the 1-GBd FC-AL standard, Revision 4.4 or
higher. Cable lengths longer than 33 feet (10 meters) must be equalized.
Optical cables are optional within the MediaNet environment and cus-
tomer supplied. They can be either 50-µm (micrometer), multimode,
dual SC cables or 62.5-µm (micrometer), multimode, dual SC cables.
The 50-µm cables can be used for distances from 3 feet (1 meter) to
1650 feet (500 meters). The 62.5-µm cables can be used for distances
from 3 feet (1 meter) to 575 feet (175 meters).
When you are using optical cables, you also need to use two media
interface adapters (MIAs), one MIA at each end of the cable, to attach
to the MEDIAswitch or MEDIAhub and the MEDIArray controller
board. The MEDIAswitch, MEDIAhub, and the controller board are
set up to accept a copper cable connection.
Table 2-1
length.
presents information on copper and optical cables and their
21
Table 2-1 Cable Information
Name Media Type Speed Distance
Coaxial Twinax Copper ECL 1.0625 Gb Up to 99 feet
(30 meters)
50 Micrometer
Multimode Fibre
62.5 Micrometer
Multimode Fibre
Optical Shortwave Laser 1.0625 Gb Up to 1650 feet
Optical Shortwave Laser 1.0625 Gb Up to 575 feet
Dimensions and Weight
Table 2-2 provides the dimensions and weight of the MediaNet hard-
ware and the optional rack components. Make sure the surfaces where
you place the equipment can accommodate the equipment’s size and
weight.
(500 meters)
(175 meters)
22
Table 2-2 Component Dimensions and Weight
Component Height Width Depth Weight
MediaNet Server Components
MediaNet Server 7.87 in (200 mm) 19.37 in (492 mm) 17.52 in (445 mm) 38 lb (17.3 kg)
Display
a
16.30 in (416 mm) 16.10 in (410 mm) 17.30 in (441 mm) 44 lb (20.0 kg)
Keyboard 1.25 in (32 mm) 19.00 in (482 mm) 6.50 in (165 mm) 4 lb (1.8 kg)
Storage Subsystem
MEDIArray
17.50 in (445 mm) 6.07 in (154 mm) 24.91 in (633 mm) 80 lb (36.0 kg)
enclosure
Connectivity
MEDIAhub 1.70 in (43 mm) 8.70 in (221 mm) 5.70 in (145 mm) 3 lb (1.4 kg)
MEDIAswitch 3.40 in (86 mm) 19.00 in (482 mm) 21.20 in (538 mm) 26 lb (11.9 kg)
Power Management
UPS 7.00 in (178 mm) 17.60 in (448 mm) 18.70 in (475 mm) 86 lb (39.1 kg)
Mounting Hardware
MediaNet rack
b
68.35 in (1736 mm) 25.55 in (649 mm) 34.21 in (869 mm) 250 lb (113.6 kg)
a. Values are for Avid-supplied display.
b. Dimensions and weight will vary if you use a standard video rack.
23
CHAPTER 3
Environmental Requirements
The Avid Unity MediaNet hardware is designed to operate in a stan-
dard “open office” or computer-r oom environment. When you select a
location, you should:
• Make sure the location has a sturdy, level floor, and is not subject
to vibration.
• Make sure the location is away from high-traffic areas.
• Make sure the location is clean and free fr om dust, smoke, or other
airborne contaminants.
• Make sure the location does not have significant temperature
changes. Choose a location where the temperature does not vary
more than 18°F (7.78°C) per hour.
• Make sure the location does not have significant humidity
changes. A location with approximately 40 percent humidity can
prevent problems stemming from electrostatic discharge.
• Make sure the location has adequate space in front of and behind
the rack. You must be able to connect cables and service the parts
of your hardware. It also needs adequate airflow for cooling.
24
If security for the MediaNet hardware is important, you should
address this issue during site planning. Planning and implementing
security for the hardware, before its installation, will save disrupting
the hardware and its users at a later time.
n
The MediaNet Server needs to be located near the storage subsystem (within
10 feet [3 meters]). If there are several people that need access to the MediaNet
Server, you will need to arrange security clearance for all the people who use
the MediaNet Server.
Table 3-1
and humidity specifications for the MediaNet hardware components.
Make sure your environment meets the narrowest range of specifications in the table.
For example, the MEDIAswitch can operate in an environment of
to 104°F (0°C to 40°C)
an environment of
ture at your site should not drop below
(32°C)
provides information on operating and storage temperature
32°F
, but the MediaNet Server should only operate in
50°F to 90°F (10°C to 32°C). Therefore, the tempera-
50°F (10°C) or rise above 90°F
while the MediaNet Server is running.
25
Table 3-1 Environmental Specifications
Component Operating
Temperature
MediaNet Server Components
MediaNet Server 50°F to 90°F
(10°C to 32°C)
Display
a
50°F to 104°F
(10°C to 40°C)
Keyboard 50°F to 104°F
(10°C to 40°C)
Storage Subsystem
MEDIArray
enclosure
50°F to 104°F
(10°C to 40°C)
b
Connectivity
MEDIAhub 50°F to 104°F
(10°C to 40°C)
MEDIAswitch 32°F to 104°F
(0°C to 40°C)
Operating
Humidity
8% to 80%
noncondensing
20% to 95%
noncondensing
8% to 80%
noncondensing
20% to 80%
noncondensing
20% to 80%
noncondensing
8% to 80%
noncondensing
Storage
Temperature
50°F to 110°F
(10°C to 43°C)
32°F to 140°F
(0°C to 60°C)
50°F to 110°F
(10°C to 43°C)
–40°F to 149°F (–
40°C to 65°C)
–22°F to 140°F (–
30°C to 60°C)
–40°F to 167°F (–
40°C to 75°C)
Storage
Humidity
8% to 80%
noncondensing
10% to 95%
noncondensing
8% to 80%
noncondensing
10% to 90%
noncondensing
10% to 90%
noncondensing
8% to 80%
noncondensing
Power Management
UPS 32°F to 104°F
(0°C to 40°C)
5% to 95%
noncondensing
5°F to 122°F (–
c
15°C to 50°C)
5% to 95%
noncondensing
a. Values are for Avid-supplied display.
b. Maximum operating temperature is the temperature inside the MEDIArray
enclosure.
c. Battery life is reduced at temperatures above 77°F (25°C).
26
CHAPTER 4
Electrical Requirements
You should consider installing a separately derived power system for
your Avid Unity MediaNet hardware. This ensures that you can control the hardware gr ounding, with all grounds brought to a single
point, and that uncontrolled equipment, such as coffee makers or floor
polishers, cannot be plugged into the same power source as the
MediaNet hardware.
If you do not create a separately derived power system, you need to
make sure the power outlets you use are from the same distribution
panel. This helps to prevent the occurrence of ground loops that can be
caused by plugging equipment into power sources with different
ground potentials.
When you have your hardware controlled by UPSs, you’ll need to run
separate 230-volt, 30-amp power lines, with an IEC C-20 receptacle, to
the location where you are installing the hardware. If you run more
than one line because you have two UPSs, you must make sure the
lines come from the same distribution panel.
w
You should have all the electrical work at your site done by a
licensed electrician. All the electrical changes must meet country,
state, and local electrical codes.
27
As you choose the location for your MediaNet hardware, keep these
electrical requirements in mind:
• Make sure there is adequate, dedicated power for the individual
hardware components or for the UPSs that are part of your Avid
Unity MediaNet environment.
n
Avid recommends the use of UPSs appropriately sized for your Avid Unity
MediaNet configuration. The UPSs provide protection against sudden power
surges or losses that could cause you to lose files or experience corrupt data.
• Make sure your location is away from major electrical equipment
such as motors, air conditioners, or elevators.
• Make sure the location is not subject to electrostatic buildup.
• Plug only your MediaNet hardware into the power strips. Do not
plug in coffee makers, radios, lights, or other non-Avid devices.
Table 4-1
ware. Make sure your site meets these specifications.
shows the electrical specifications for all the MediaNet hard-
28
Table 4-1 Electrical Specifications
Component Voltage Frequency Watts
(Max. U.S.)
MediaNet Server Components
MediaNet Server 110 or 220 Vac 50 to 60 Hz 145 W
Display
a
100 to 240 Vac 50 to 60 Hz 95 W
Storage Subsystem
MEDIArray enclosure 100 to 240 Vac 47 to 63 Hz 400 W
Connectivity
MEDIAhub 100 to 240 Vac 50 to 60 Hz 50 W
MEDIAswitch 100 to 240 Vac 50 to 60 Hz 300 W
Power Management
UPS 230 Vac
c
50 to 60 Hz 1500 W
a. Values are for Avid-supplied display.
b. Fully configured with two power supplies, two link cards, and ten MEDIArray drives.
c. Requires an IEC C-20 receptacle.
b
29
Hardware Component Power Cords
Choose the power cords for the MediaNet hardware according to the
country destination; it must comply with local safety requirements.
Use the following guidelines to replace the original cord set:
• CEE-22 requirements: The female receptacle of the cord set,
shown in Figure 4-1
Figure 4-1 Receptacle (CEE-22)
• United States and Canada requirements: In the United States and
Canada, the male plug is a NEMA 5-15P style and is UL listed and
CSA certified. Figure 4-2
with desktop, countertop, or rack-mounted units; all other equipment requires SJT cordage. Only SJT -type cor d sets can be used for
units that sit on the floor.
, must comply with CEE-22 requirements.
shows the plug. SVT cordage can be used
Select the cord set according to the current rating of your unit. See
Table 4-2
States and Canada.
Figure 4-2 NEMA 5-15P Style Plug
for the selection criteria for power cords in the United
30
• European countries requirements: In Europe, use only an H05VV-
2
F, <HAR>, VDE, PVC, 3 x 1.00 mm
power cord. Für den
Gebrauch in Deutschland muß ein Netzkabel des Typs H05VV-F,
2
<HAR>, PVC, Größe, 3 x 1.00 mm
verwendet werden.
Table 4-2 Power Cord Requirements
Size of Conductors in Cord
Cord Type U.S./Canada Europe U.S./Canada Europe
SJT 16 A WG 3 x 1.00 mm
SVT 18 AWG N A
SVT 17 AWG NA 12 A N A
a. NA – Not applicable.
UPS Power Cord
Use the following guidelines to replace the original cord set on the
UPS:
• Worldwide requirements: The UPS ships with a replaceable
Maximum Current Rating of Unit
2
12 A 10 A
a
10 A NA
power cord and the male plug is an IEC C-20 style. The power
cord and plug are UL listed and CSA certified. Figure 4-3
shows
the plug.
Receptacle Plug
Figure 4-3 IEC C-20 Style Plug and Receptacle
31
CHAPTER 5
Networking Requirements
Y ou need to consider connecting all of the MediaNet clients you attach
to the Avid Unity MediaNet hardware to an Ethernet network. The
network allows you to pass sequences, using AvidNet™ T ransfer Tool,
to other workstations on your network for changes or additions such
as effects editing, 3D and animation editing, graphics compositing, or
audio editing.
The Ethernet network can be either a standalone network or an existing in-house network. The network can be either 10BASE-T or
100BASE-T. Each system must be properly configured with a valid IP
address and subnet mask. See the AvidNet Transfer Tool User’s Guide for
more information on configuring the MediaNet client network.
32
You can connect your MediaNet client to the network by:
• Attaching one or more systems directly to the network.
Ethernet
Avid Avid Avid
• Attaching one or more systems to the network through a router.
The router allows you to segregate the MediaNet clients from the
rest of the network.
Ethernet
Router
Avid Avid Avid
c
You can also connect the Avid Unity MediaNet Server to the network.
This allows you to test network connections to the attached MediaNet
clients, troubleshoot Avid Unity MediaNet environment problems, or
obtain software updates from Avid through the Internet. Avid recommends that you do not plan to have the MediaNet Server connected to
the network all the time — only when the need arises.
The MediaNet Server is a dedicated system, designed to manage the
files stored on the Avid Unity MediaNet storage subsystem. It
should not be used to do any other work, such as word processing,
graphics, or spreadsheets. Using the MediaNet Server to do other
work will seriously impact your MediaNet environment performance.
33
CHAPTER 6
Site Planning Check List
As you prepare your site for the Avid Unity MediaNet hardware,
check the following items to make sure your site is ready for the hardware installation.
System Layout
There is room for a table to hold the MediaNet Server (required for a
nine-client configuration only).
All optical cables and MIAs are obtained and installed.
Optical cables cannot be damaged by traffic or moving objects.
Environment
Two telephone lines are available at the system location.
System location has a sturdy, level floor with no vibration.
System location provides adequate airflow to cool the hardware.
34
Electrical
System location is not a high-traffic area.
System location is clean and free from dust, smoke, and other airborne
contaminants.
System location does not experience large changes in temperature or
humidity.
System location has appropriate clearance in front of and behind the
rack for normal operation, cable changes, and service.
System location has necessary security.
System location has adequate, dedicated power for the individual
hardware components or for the UPSs that are part of the Avid Unity
MediaNet environment.
System location has one or two 230-volt, 30-amp IEC C-20 receptacles
installed for UPSs.
System location is not near major electrical equipment, such as motors,
air conditioners, or elevators.
System location is not subject to electrostatic buildup.
System hardware is plugged into power strips with no other non-Avid
devices plugged into them.
35
Network
All Ethernet network cables are installed.
An Ethernet hub is installed, if needed.
An Ethernet router is installed, if needed.
Ethernet network connections are available for each MediaNet client.
Table 6-1 MediaNet Networking Information
IP Address Subnet Mask
MediaNet Server
MEDIAswitch #1
MEDIAswitch #2
MediaNet Client #1
MediaNet Client #2
MediaNet Client #3
MediaNet Client #4
MediaNet Client #5
MediaNet Client #6
MediaNet Client #7
MediaNet Client #8
MediaNet Client #9
36
FCC Notice
APPENDIX A
Regulatory and Safety Notices
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference
2. This device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be required to
correct the interference at his own expense.
37
Canadian ICES-003
This Class A digital apparatus meets all requirements of the Canadian
Interference Causing Equipment Regulations.
Cet appareil numérique de la classe A respecte toutes les ex ige nces du
Règlement sur le matériel brouilleur du Canada.
European Union Notice
Declaration of Conformity
(According to ISO/IEC Guide 22 and EN 45014)
Application of Council
Directives:
Standards to which
Conformity is Declared:
Manufacturer’s Name: Avid Technology, Inc.
European Contact: Nearest A vid Sales and Service Office or
Type of Equipment: Information Technology Equipment
73/23/EEC, 89/336/EEC.
EN 60950: 1992 + A1 + A2 + A3 + A4
IEC950: 1992 + A1 + A2 + A3 + A4: 1993 Mod.
CISPR 22:1985 / EN 55022:1988 Class A
EN 50082-1:1992 / IEC801 -2, -3, -4
1925 Andover Street,
Tewksbury, MA 01876, USA
Avid Technology International B.V .
Sandyford Business Center
Unit 3,
Dublin 18, Ireland
38
Product Name: Media Composer for the Windows NT and
N1709
Macintosh Operating Systems, Film Composer,
Symphony, Avid Xpress for the Macintosh
Operating System, Avid Xpress with Plus Bundle
for the Macintosh Operatin g System, Avid Xpress
with Deluxe Bundle for the Windows NT and
Macintosh Operating Systems, Avid Xpress with
Elite Bundle for the Windows NT and Macintosh
Operating Systems
Base Model Numbers: All for the Windows NT Operating System;
Avid Xpress, 1000, 1000 XL, 9000, MC Offline,
MC Offline XL, and Media Station for the Macintosh
Operating System
Product Options: All
Year of Manufacture: 1999
(1) The product was tested in a typical Symphony, Avid Xpress with
Deluxe Bundle for the Wi ndows NT Operating System, Avid Xpress
with Elite Bundle for the Windows NT Operating System, or Avid
Media Composer configuration.
I, the undersigned, hereby declare that the equipment specified above
conforms to the above Directives and Standards.
George R. Smith, Director of Quality Engineering
Australia and New Zealand EMC Regulations
39
