Chapter 1: Introduction
The Avid® S6 Display Module is a hardware display module for the S6 control surface.
Avid S6 Display Module and mounting bracket
Module Components
The Display Module consists of a TFT display and SBC controller. A mounting bracket is also included.
Module Capabilities and Features
• 1280 x 800 TFT screen
• 2 (two) USB ports
• 2-pin 12v Power connector
• 1 (one) 1000-BaseT (Gigabit) Ethernet RJ45 connector
Chapter 1: Introduction 1
System Requirements and Compatibility
Avid can only assure compatibility and provide support for hardware and software it has tested and approved.
For complete system requirements and a list of qualified computers, operating systems, hard drives, and third-party devices, visit:
www.avid.com/compatibility
Registration
Review the enclosed Registration Information Card and follow the instructions on it to register your purchase online.
By registering, you become eligible to receive the following:
• Technical support information
• Software update and upgrade notices
• Hardware warranty information
About www.avid.com
The Avid website (www.avid.com) is your best online source for information about Avid. The following are just a few of the services and features available.
Product Registration
Support and Downloads
manuals; browse the Compatibility documents for system requirements; search the online Knowledge Base or join the worldwide
Pro Tools community on the User Conference.
Training and Education
a certified Pro Tools training center.
Products and Developers
plug-ins, applications, and hardware.
News and Events
Register your purchase online.
Contact Avid Customer Success (technical support); download software updates and the latest online
Study on your own using courses available online or find out how you can learn in a classroom setting at
Learn about Avid products; download demo software or learn about our Development Partners and their
Get the latest news from Avid or sign up for a Pro Tools demo.
Chapter 1: Introduction 2
Chapter 2: S6 Display Module Connections
USB Power
Ethernet
Gigabit Ethernet RJ45
+12V
0V
Connecting a Single Module
Connectors for power, Ethernet, and USB are located along the bottom of the display.
Ports and connectors along the bottom of the Display Module
Do not use the USB ports unless instructed to do so by an Avid Authorized Service Representative.
The Display Module is powered by 12 V DC. The power input connector is a 2-conductor Molex.
Power and Ethernet
Chapter 2: S6 Display Module Connections 3
Chapter 3: S6 Display Module Overview
This chapter identifies the hardware features on the Display Module.
Display Module
The Display Module is an eight-channel display module that consists of a TFT display and mounting bracket. The Display Module
shows channel information such as channel name, metering, routing, function graphs, and track waveforms.
Chapter 3: S6 Display Module Overview 4
Appendix A: Specifications
Mechanical
Avid S6 Display Module Mechanical Specifications
Parameter Specification
Dimensions (L x W x D)
Weight 3.52 lbs (1.60 kg)
Power Requirements 12 VDC, 1.8 A
Ethernet Ports (2) 1000-BaseT (Gigabit) Ethernet RJ-45
USB Ports (2) USB 2.0
7.3 x 11.1 x 2.4 inches
185.5 x 282.3 x 60 mm
Environmental
Avid S6 Display Module Environmental Specifications
Parameter Specification Limit Units Condition/Comment
Storage Temperature –18 to +60 deg C deg C 0 to +140 deg F
Operating Temperature +4 to +40 deg C deg C +40 to +104 deg F
Storage humidity range 5 to 95 % Non-condensing
Operating Humidity Range 20 to 80 % Non-condensing
Continuous Vibration (Storage
only: non-powered transportation)
1 g RMS Random spectrum
Appendix A: Specifications 5
Dimensions
Appendix A: Specifications 6
