Physio Control Lifepak CR2 Getting Started Manual

Page 1
®
LIFEPAK
with LIFELINKcentral™ AED Program Manager
CR2 Defibrillator
Getting Started Guide
Page 2
®
LIFEPAK
with LIFELINKcentral™ AED Program Manager
CR2 Defibrillator
Thank you for making defibrillation readily available to your workplace or community so that, when a heart stops beating, lifesaving treatment is just min u tes aw ay.
Please ensure the LIFEPAK CR2 Defibrillator is ‘Connected and Ready’ for use in an emergency by following these simple instructions.
Page 3
Defibrillator Management
The Connected AED
Physio-Control oers web-based services that can monitor your LIFEPAK CR2 defibrillator (AED) and ensure it is ready for use. These services are LIFELINKcentral AED Program Manager and LIFENET® System.
LIFELINKcentral AED Program Manager is used by customers to manage AEDs.
LIFENET System is used by health care organizations that have additional emergency equipment.
Note: LIFELINKcentral AED Program Manager and
LIFENET System are not available in all countries.
If your LIFEPAK CR2 defibrillator has wireless capability, it can connect to the internet and report its status to LIFELINKcentral AED Program Manager or LIFENET System. If the AED is not ready or fails to check in, an email notification is sent to your organization’s account administrator. Email notifications are also sent if a battery or electrode expiration date is approaching.
Note: The AED does not have to be connected to function. You can verify the AED is ready for use by checking the Readiness indicator as described in step 6 of this guide.
Page 4
How the AED Connects
The AED can connect to LIFELINKcentral AED Program Manager or LIFENET System using a Wi-Fi®, cellular, or USB connection to the internet.
LIFEPAK CR2 Defibrillator Connectivity
Note: The micro-USB port is to be used
by authorized users only. The micro-USB port does not provide power and should not be connected to other devices, such as mobile phones or other USB connected products.
Page 5
Unpack the LIFEPAK CR2 defibrillator (AED)
Confirm the Date of Manufacture on the battery
Take contents out of the box and check
1 2
them against the sales order.
If something is missing from the shipping box, please call Physio-Control Customer Support or your local authorized distributor as soon as possible. See the contact list included in the box for region-specific phone numbers.
The date of manufacture is printed on the battery label in YYYY-MM-DD format. The battery must be installed within 1 year of this date. For detailed information about battery service life, see the LIFEPAK CR2 Defibrillator Operating Instructions.
Page 6
3
Determine if the AED has
®
Wi-Fi
All LIFEPAK CR2 defibrillators have USB capability. To determine if the AED also has wireless (Wi-Fi or Cellular) capability, check the serial number label located in the battery compartment on the back of the AED.
or cellular capability.
1 If this additional pair of ID and IC numbers is present,
the AED has cellular capability.
2 If this number is present, the AED has Wi-Fi capability.
Check the option that corresponds to your AED.
USB only (no Wi-Fi or cellular capability)
Wi-Fi and USB
Wi-Fi, cellular, and USB
Page 7
Record the serial number.
Install battery and wait for
Find the AED’s serial number as shown below and record it here.
SERIAL NUMBER:
self-test to complete.
Insert the battery into the battery
54
compartment located on the back of the AED. The device will automatically begin a self-test. This may take up to 2 minutes. Wait until 3 audible tones sound before proceeding to step 6.
Note: If the same battery has been previously inserted, the 3 tones will not sound.
Page 8
Verify that the Readiness
Check the speaker.
6
indicator is flashing.
The green Readiness indicator will flash every 6 seconds through a small hole located on top of the lid. A flashing Readiness indicator means the AED is ready for use.
Readiness indicator
7
Open the lid and confirm that the voice prompts are audible. Do not respond to the voice prompts at this time. Close the lid to turn o the device.
IMPORTANT!
DO NOT pull the red
handle at this time; only pull in an emergency.
Page 9
8
Refer to Wireless Setup Guide, if applicable.*
If your AED has wireless capability, please refer to the Wireless Setup Guide included in the box to connect
the AED to your LIFELINKcentral AED Program Manager or LIFENET System account. Refer to step 3 in this guide to determine if your AED has wireless capability.
Note: LIFELINKcentral AED Program
Manager and LIFENET System are not available in all countries.
*If your AED does not have wireless
capability, skip to step 9 in this guide.
Page 10
9
Store the AED and accessories.
Confirm the Readiness indicator is flashing,
and place your AED in the location where it
will be stored.
If your AED is equipped with a carrying
case, place spare electrode trays in the back
compartment. Attach the rescue kit to the
handle or carrying case strap, if applicable.
Store in a central and accessible location.
Notify potential users of the location.
Avoid exposure to moisture or dust.
Do not store the AED in the presence of
flammable gases or in direct contact with flammable material.
Store at recommended storage
temperature: 15° to 35°C (59° to 95°F).
You r LIFEPAK CR2 Defibrillator is now ready for use
Page 11
Training Maintenance
Read the Operating Instructions.
The Operating Instructions provide complete directions for use, indications, and potential adverse events. Store the instructions in a convenient location for reference.
Watch the training videos.
You can find the training videos by visiting the Physio-Control website: www.physio-control.com
Attend formal CPR and AED training.
Physio-Control recommends that all identified users attend formal CPR and AED training provided by a recognized training center.
The LIFEPAK CR2 defibrillator conducts daily, weekly, and monthly self-tests to ensure it is ready for use. If your device needs attention and has a wireless connection to your LIFELINKcentral or LIFENET System account, your account administrator will receive an email notification.
If your device does not have a wireless connection, you should check the status at least once a month by confirming that the Readiness indicator still flashes every 6 seconds. If the Readiness indicator does not flash, please refer to the Operating Instructions for troubleshooting information. If you need assistance, call Physio-Control Customer Support or your local authorized distributor. See the contact list included in the box for region-specific phone numbers for Physio-Control.
Page 12
How to get help.
If you need assistance, contact Physio-Control Customer Support. See the contact list included with this guide for region-specific phone numbers. When you call, be prepared to provide your device serial number (recorded in step 4 of this guide).
Physio- Control is now par t of Stryker.
Physio-Control Headquarters 11811 Willows Road NE Redmond, WA 98052 www.physio-control.com
©2018 Physio-Control, Inc. Redmo nd, WA 98052, USA
Customer Support P.O. Box 97006 Redmond, WA 98073 Toll Fre e 80 0.442 .114 2 Fax 800.426.8049
