Phonic XP R220 Service Manual

XP-R220

AU

SERVICE MANUAL

COMPACT DISC PLAYER BASIC CD MECHANISM : DA23LH

• Replace this Service manual with “Revision Publishing” when it is issued.

S/M Code No. 09-012-442-6T1

SIMPLE

DATA

PARTS LIST

! = ! SAFTY PA RTS
C = Components marked

K NO. = Only use japanese.

! O ACCESSORY 87-B30-282-010 2A AC ADAPTOR,AC-D603UNC AUB3NF XP-R220
! O ACCESSORY 87-B30-282-010 2A AC ADAPTOR,AC-D603UNC AUBNF XP-R220
O ACCESSORY 87-B30-477-010 — HEADPHONE,HP-M046 N AUB3NF XP-R220
O ACCESSORY 87-B30-477-010 — HEADPHONE,HP-M046 N AUBNF XP-R220
O APPEARANCE 8B-HC1-001-010 — LID,CD AUB3NF XP-R220
O APPEARANCE 8B-HC1-001-010 — LID,CD AUBNF XP-R220
X APPEARANCE 8B-HC1-004-010 — LID,BAT AUB3NF XP-R220
X APPEARANCE 8B-HC1-004-010 — LID,BAT AUBNF XP-R220
O APPEARANCE 8B-HC1-007-010 — CABI ASSY,BOTTOM AUB3NF XP-R220
O APPEARANCE 8B-HC1-007-010 — CABI ASSY,BOTTOM AUBNF XP-R220

O APPEARANCE 8Z-HC4-027-010 0E FOOT,DIA10 AUB3NF XP-R220
O APPEARANCE 8Z-HC4-027-010 0E FOOT,DIA10 AUBNF XP-R220
O APPEARANCE * 8B-HC1-002-010 — CABI,CENTER AUB3NF XP-R220
O APPEARANCE * 8B-HC1-002-010 — CABI,CENTER AUBNF XP-R220
X APPEARANCE * 8B-HC1-003-010 — CABI,BOTTOM AUB3NF XP-R220
X APPEARANCE * 8B-HC1-003-010 — CABI,BOTTOM AUBNF XP-R220
O APPEARANCE * 8B-HC4-016-010 — HLDR,OPEN AUB3NF XP-R220
O APPEARANCE * 8B-HC4-016-010 — HLDR,OPEN AUBNF XP-R220
O AUDIO C 0701 87-016-430-080 0E C-CAP,E 100-6.3 M 5.5L WX AUB3NF XP-R220
O AUDIO C 0701 87-016-430-080 0E C-CAP,E 100-6.3 M 5.5L WX AUBNF XP-R220

O AUDIO C 0702 87-012-274-080 0E C-CAP,U 1000P-50 K B AUB3NF XP-R220
O AUDIO C 0702 87-012-274-080 0E C-CAP,U 1000P-50 K B AUBNF XP-R220
O AUDIO C 0703 87-012-274-080 0E C-CAP,U 1000P-50 K B AUB3NF XP-R220
O AUDIO C 0703 87-012-274-080 0E C-CAP,U 1000P-50 K B AUBNF XP-R220
O AUDIO C 0706 87-010-831-080 0E C-CAP,U 0.1-16 Z F AUB3NF XP-R220
O AUDIO C 0706 87-010-831-080 0E C-CAP,U 0.1-16 Z F AUBNF XP-R220
O AUDIO C 0707 87-A10-047-080 0E C-CAP,U 1-10 Z F AUB3NF XP-R220
O AUDIO C 0707 87-A10-047-080 0E C-CAP,U 1-10 Z F AUBNF XP-R220
O AUDIO C 0708 87-A10-047-080 0E C-CAP,U 1-10 Z F AUB3NF XP-R220
O AUDIO C 0708 87-A10-047-080 0E C-CAP,U 1-10 Z F AUBNF XP-R220

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O AUDIO C 0709 87-A10-047-080 0E C-CAP,U 1-10 Z F AUB3NF XP-R220
O AUDIO C 0709 87-A10-047-080 0E C-CAP,U 1-10 Z F AUBNF XP-R220
O AUDIO C 0710 87-016-421-080 0E C-CAP,E 10-16 M WX AUB3NF XP-R220
O AUDIO C 0710 87-016-421-080 0E C-CAP,E 10-16 M WX AUBNF XP-R220
O AUDIO C 0711 87-016-429-080 0E C-CAP,E 100-4 M WX AUB3NF XP-R220
O AUDIO C 0711 87-016-429-080 0E C-CAP,E 100-4 M WX AUBNF XP-R220
O AUDIO C 0712 87-A10-353-080 0E C-CAP,U 0.22-10 K B AUB3NF XP-R220
O AUDIO C 0712 87-A10-353-080 0E C-CAP,U 0.22-10 K B AUBNF XP-R220
O AUDIO C 0713 87-010-831-080 0E C-CAP,U 0.1-16 Z F AUB3NF XP-R220
O AUDIO C 0713 87-010-831-080 0E C-CAP,U 0.1-16 Z F AUBNF XP-R220

O AUDIO C 0714 87-A11-062-080 0E C-CAP,S 2.2-16 Z F AUB3NF XP-R220
O AUDIO C 0714 87-A11-062-080 0E C-CAP,S 2.2-16 Z F AUBNF XP-R220
O AUDIO C 0715 87-016-421-080 0E C-CAP,E 10-16 M WX AUB3NF XP-R220
O AUDIO C 0715 87-016-421-080 0E C-CAP,E 10-16 M WX AUBNF XP-R220
O AUDIO C 0716 87-010-831-080 0E C-CAP,U 0.1-16 Z F AUB3NF XP-R220
O AUDIO C 0716 87-010-831-080 0E C-CAP,U 0.1-16 Z F AUBNF XP-R220
O AUDIO C 0717 87-010-831-080 0E C-CAP,U 0.1-16 Z F AUB3NF XP-R220
O AUDIO C 0717 87-010-831-080 0E C-CAP,U 0.1-16 Z F AUBNF XP-R220
O AUDIO C 0718 87-016-431-080 0E C-CAP,E 220-4 M WX AUB3NF XP-R220
O AUDIO C 0718 87-016-431-080 0E C-CAP,E 220-4 M WX AUBNF XP-R220

O AUDIO C 0719 87-016-431-080 0E C-CAP,E 220-4 M WX AUB3NF XP-R220
O AUDIO C 0719 87-016-431-080 0E C-CAP,E 220-4 M WX AUBNF XP-R220
O AUDIO C 0720 87-012-274-080 0E C-CAP,U 1000P-50 K B AUB3NF XP-R220
O AUDIO C 0720 87-012-274-080 0E C-CAP,U 1000P-50 K B AUBNF XP-R220
O AUDIO C 0721 87-012-274-080 0E C-CAP,U 1000P-50 K B AUB3NF XP-R220
O AUDIO C 0721 87-012-274-080 0E C-CAP,U 1000P-50 K B AUBNF XP-R220
O AUDIO C 0722 87-010-831-080 0E C-CAP,U 0.1-16 Z F AUB3NF XP-R220
O AUDIO C 0722 87-010-831-080 0E C-CAP,U 0.1-16 Z F AUBNF XP-R220
O AUDIO FB 0701 83-XM1-617-080 0E C-COIL,BK2125HM601 AUB3NF XP-R220
O AUDIO FB 0701 83-XM1-617-080 0E C-COIL,BK2125HM601 AUBNF XP-R220

O AUDIO FB 0702 83-XM1-617-080 0E C-COIL,BK2125HM601 AUB3NF XP-R220
O AUDIO FB 0702 83-XM1-617-080 0E C-COIL,BK2125HM601 AUBNF XP-R220
O AUDIO FB 0703 83-XM1-617-080 0E C-COIL,BK2125HM601 AUB3NF XP-R220
O AUDIO FB 0703 83-XM1-617-080 0E C-COIL,BK2125HM601 AUBNF XP-R220
O AUDIO FB 0704 83-XM1-617-080 0E C-COIL,BK2125HM601 AUB3NF XP-R220
O AUDIO FB 0704 83-XM1-617-080 0E C-COIL,BK2125HM601 AUBNF XP-R220
S AUDIO IC 0701 87-A21-085-040 1C C-IC,TA2120FN AUB3NF XP-R220
S AUDIO IC 0701 87-A21-085-040 1C C-IC,TA2120FN AUBNF XP-R220
O AUDIO J 0701 87-A61-446-010 0E JACK,3.5 GRN ST W/REM AUB3NF XP-R220
O AUDIO J 0701 87-A61-446-010 0E JACK,3.5 GRN ST W/REM AUBNF XP-R220

– 2 –

PARTS LIST

! = ! SAFTY PA RTS
C = Components marked

K NO. = Only use japanese.

S AUDIO Q 0701 87-026-264-080 0E C-TR,RN1411 AUB3NF XP-R220
S AUDIO Q 0701 87-026-264-080 0E C-TR,RN1411 AUBNF XP-R220
S AUDIO Q 0702 87-A30-328-040 1D C-TR,IMX9 AUB3NF XP-R220
S AUDIO Q 0702 87-A30-328-040 1D C-TR,IMX9 AUBNF XP-R220
X AUDIO R 0701 88-108-339-080 0E C-RES,U 3.3-1/16W J AUB3NF XP-R220
X AUDIO R 0701 88-108-339-080 0E C-RES,U 3.3-1/16W J AUBNF XP-R220
X AUDIO R 0702 88-108-223-080 0E C-RES,U 22K-1/16W J AUB3NF XP-R220
X AUDIO R 0702 88-108-223-080 0E C-RES,U 22K-1/16W J AUBNF XP-R220
X AUDIO R 0703 88-108-223-080 0E C-RES,U 22K-1/16W J AUB3NF XP-R220
X AUDIO R 0703 88-108-223-080 0E C-RES,U 22K-1/16W J AUBNF XP-R220

X AUDIO R 0704 88-108-183-080 0E C-RES,U 18K-1/16W J AUB3NF XP-R220
X AUDIO R 0704 88-108-183-080 0E C-RES,U 18K-1/16W J AUBNF XP-R220
X AUDIO R 0705 88-108-183-080 0E C-RES,U 18K-1/16W J AUB3NF XP-R220
X AUDIO R 0705 88-108-183-080 0E C-RES,U 18K-1/16W J AUBNF XP-R220
X AUDIO R 0706 88-108-102-080 0E C-RES,U 1K-1/16W J AUB3NF XP-R220
X AUDIO R 0706 88-108-102-080 0E C-RES,U 1K-1/16W J AUBNF XP-R220
X AUDIO R 0707 88-108-472-080 0E C-RES,U 4.7K-1/16W J AUB3NF XP-R220
X AUDIO R 0707 88-108-472-080 0E C-RES,U 4.7K-1/16W J AUBNF XP-R220
X AUDIO R 0708 88-108-102-080 0E C-RES,U 1K-1/16W J AUB3NF XP-R220
X AUDIO R 0708 88-108-102-080 0E C-RES,U 1K-1/16W J AUBNF XP-R220

X AUDIO R 0709 88-108-479-080 0E C-RES,U 4.7-1/16W J AUB3NF XP-R220
X AUDIO R 0709 88-108-479-080 0E C-RES,U 4.7-1/16W J AUBNF XP-R220
X AUDIO R 0710 88-108-479-080 0E C-RES,U 4.7-1/16W J AUB3NF XP-R220
X AUDIO R 0710 88-108-479-080 0E C-RES,U 4.7-1/16W J AUBNF XP-R220
X AUDIO R 0711 88-108-103-080 0E C-RES,U 10K-1/16W J AUB3NF XP-R220
X AUDIO R 0711 88-108-103-080 0E C-RES,U 10K-1/16W J AUBNF XP-R220
X AUDIO R 0712 88-108-103-080 0E C-RES,U 10K-1/16W J AUB3NF XP-R220
X AUDIO R 0712 88-108-103-080 0E C-RES,U 10K-1/16W J AUBNF XP-R220
X AUDIO R 0713 88-108-109-080 0E C-RES,U 1-1/16W J AUB3NF XP-R220
X AUDIO R 0713 88-108-109-080 0E C-RES,U 1-1/16W J AUBNF XP-R220

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X AUDIO R 0714 88-108-109-080 0E C-RES,U 1-1/16W J AUB3NF XP-R220
X AUDIO R 0714 88-108-109-080 0E C-RES,U 1-1/16W J AUBNF XP-R220
X AUDIO R 0715 88-108-472-080 0E C-RES,U 4.7K-1/16W J AUB3NF XP-R220
X AUDIO R 0715 88-108-472-080 0E C-RES,U 4.7K-1/16W J AUBNF XP-R220
X AUDIO R 0716 88-108-472-080 0E C-RES,U 4.7K-1/16W J AUB3NF XP-R220
X AUDIO R 0716 88-108-472-080 0E C-RES,U 4.7K-1/16W J AUBNF XP-R220
X AUDIO R 0717 88-108-472-080 0E C-RES,U 4.7K-1/16W J AUB3NF XP-R220
X AUDIO R 0717 88-108-472-080 0E C-RES,U 4.7K-1/16W J AUBNF XP-R220
X AUDIO R 0718 88-108-472-080 0E C-RES,U 4.7K-1/16W J AUB3NF XP-R220
X AUDIO R 0718 88-108-472-080 0E C-RES,U 4.7K-1/16W J AUBNF XP-R220

X AUDIO R 0719 88-108-224-080 0E C-RES,U 220K-1/16W J AUB3NF XP-R220
X AUDIO R 0719 88-108-224-080 0E C-RES,U 220K-1/16W J AUBNF XP-R220
X AUDIO R 0720 88-108-224-080 0E C-RES,U 220K-1/16W J AUB3NF XP-R220
X AUDIO R 0720 88-108-224-080 0E C-RES,U 220K-1/16W J AUBNF XP-R220
X AUDIO R 0722 88-108-103-080 0E C-RES,U 10K-1/16W J AUB3NF XP-R220
X AUDIO R 0722 88-108-103-080 0E C-RES,U 10K-1/16W J AUBNF XP-R220
X AUDIO R 0724 88-108-103-080 0E C-RES,U 10K-1/16W J AUB3NF XP-R220
X AUDIO R 0724 88-108-103-080 0E C-RES,U 10K-1/16W J AUBNF XP-R220
X AUDIO R 0725 88-108-102-080 0E C-RES,U 1K-1/16W J AUB3NF XP-R220
X AUDIO R 0725 88-108-102-080 0E C-RES,U 1K-1/16W J AUBNF XP-R220

X AUDIO R 0726 88-108-102-080 0E C-RES,U 1K-1/16W J AUB3NF XP-R220
X AUDIO R 0726 88-108-102-080 0E C-RES,U 1K-1/16W J AUBNF XP-R220
X AUDIO R 0727 88-108-102-080 0E C-RES,U 1K-1/16W J AUB3NF XP-R220
X AUDIO R 0727 88-108-102-080 0E C-RES,U 1K-1/16W J AUBNF XP-R220
X AUDIO R 0728 88-108-102-080 0E C-RES,U 1K-1/16W J AUB3NF XP-R220
X AUDIO R 0728 88-108-102-080 0E C-RES,U 1K-1/16W J AUBNF XP-R220
X AUDIO R 0733 88-108-103-080 0E C-RES,U 10K-1/16W J AUB3NF XP-R220
X AUDIO R 0733 88-108-103-080 0E C-RES,U 10K-1/16W J AUBNF XP-R220
O AUDIO VR 0701 87-A92-144-010 0E VR,RTRY 30KX2 H AUB3NF XP-R220
O AUDIO VR 0701 87-A92-144-010 0E VR,RTRY 30KX2 H AUBNF XP-R220

O CHARGE C 0101 87-012-286-080 0E C-CAP,U 0.01-25 K B AUB3NF XP-R220
O CHARGE C 0101 87-012-286-080 0E C-CAP,U 0.01-25 K B AUBNF XP-R220
O CHARGE C 0102 87-A11-031-080 0E C-CAP,E 100-16 M WX AUB3NF XP-R220
O CHARGE C 0102 87-A11-031-080 0E C-CAP,E 100-16 M WX AUBNF XP-R220
O CHARGE C 0103 87-012-286-080 0E C-CAP,U 0.01-25 K B AUB3NF XP-R220
O CHARGE C 0103 87-012-286-080 0E C-CAP,U 0.01-25 K B AUBNF XP-R220
O CHARGE C 0104 87-016-367-080 0E C-CAP,E 47-6.3 M WX AUB3NF XP-R220
O CHARGE C 0104 87-016-367-080 0E C-CAP,E 47-6.3 M WX AUBNF XP-R220
S CHARGE D 0101 87-017-520-080 0E C-DIODE,SFPB52 AUB3NF XP-R220
S CHARGE D 0101 87-017-520-080 0E C-DIODE,SFPB52 AUBNF XP-R220

– 3 –

PARTS LIST

! = ! SAFTY PA RTS
C = Components marked

K NO. = Only use japanese.

S CHARGE D 0102 87-A40-270-080 0E C-DIODE,MC2838 AUB3NF XP-R220
S CHARGE D 0102 87-A40-270-080 0E C-DIODE,MC2838 AUBNF XP-R220
O CHARGE J 0101 87-A61-447-010 0E JACK,DC DJ26B BLK 6 AUB3NF XP-R220
O CHARGE J 0101 87-A61-447-010 0E JACK,DC DJ26B BLK 6 AUBNF XP-R220
S CHARGE Q 0101 87-A30-376-040 0E C-TR,RN1405 AUB3NF XP-R220
S CHARGE Q 0101 87-A30-376-040 0E C-TR,RN1405 AUBNF XP-R220
S CHARGE Q 0102 87-A30-075-080 0E C-TR,2SA1235F AUB3NF XP-R220
S CHARGE Q 0102 87-A30-075-080 0E C-TR,2SA1235F AUBNF XP-R220
S CHARGE Q 0103 89-211-323-080 1A C-TR,2SB1132R AUB3NF XP-R220
S CHARGE Q 0103 89-211-323-080 1A C-TR,2SB1132R AUBNF XP-R220

S CHARGE Q 0104 89-416-643-080 0E C-TR,2SD1664R AUB3NF XP-R220
S CHARGE Q 0104 89-416-643-080 0E C-TR,2SD1664R AUBNF XP-R220
S CHARGE Q 0105 87-A30-076-080 0E C-TR,2SC3052F AUB3NF XP-R220
S CHARGE Q 0105 87-A30-076-080 0E C-TR,2SC3052F AUBNF XP-R220
X CHARGE R 0101 88-108-102-080 0E C-RES,U 1K-1/16W J AUB3NF XP-R220
X CHARGE R 0101 88-108-102-080 0E C-RES,U 1K-1/16W J AUBNF XP-R220
X CHARGE R 0102 88-108-224-080 0E C-RES,U 220K-1/16W J AUB3NF XP-R220
X CHARGE R 0102 88-108-224-080 0E C-RES,U 220K-1/16W J AUBNF XP-R220
X CHARGE R 0103 88-118-689-080 0E C-RES,S 6.8-1/10W J AUB3NF XP-R220
X CHARGE R 0103 88-118-689-080 0E C-RES,S 6.8-1/10W J AUBNF XP-R220

X CHARGE R 0104 88-118-100-080 0E C-RES,S 10-1/10W J AUB3NF XP-R220
X CHARGE R 0104 88-118-100-080 0E C-RES,S 10-1/10W J AUBNF XP-R220
X CHARGE R 0105 88-138-399-080 0E C-RES, 3.9-1/4W J AUB3NF XP-R220
X CHARGE R 0105 88-138-399-080 0E C-RES, 3.9-1/4W J AUBNF XP-R220
X CHARGE R 0106 88-108-561-080 0E C-RES,U 560-1/16W J AUB3NF XP-R220
X CHARGE R 0106 88-108-561-080 0E C-RES,U 560-1/16W J AUBNF XP-R220
O CHARGE S 0101 87-A92-085-010 — SW,MICRO ESE11SV1 AUB3NF XP-R220
O CHARGE S 0101 87-A92-085-010 — SW,MICRO ESE11SV1 AUBNF XP-R220
X DISC TRANSPORT M8-ZZK-F95-070 — DA23LH AUB3NF XP-R220
X DISC TRANSPORT M8-ZZK-F95-070 — DA23LH AUBNF XP-R220

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

O DRIVER C 0601 87-016-430-080 0E C-CAP,E 100-6.3 M 5.5L WX AUB3NF XP-R220
O DRIVER C 0601 87-016-430-080 0E C-CAP,E 100-6.3 M 5.5L WX AUBNF XP-R220
O DRIVER C 0602 87-012-286-080 0E C-CAP,U 0.01-25 K B AUB3NF XP-R220
O DRIVER C 0602 87-012-286-080 0E C-CAP,U 0.01-25 K B AUBNF XP-R220
O DRIVER C 0603 87-012-286-080 0E C-CAP,U 0.01-25 K B AUB3NF XP-R220
O DRIVER C 0603 87-012-286-080 0E C-CAP,U 0.01-25 K B AUBNF XP-R220
O DRIVER C 0613 87-010-759-080 0E C-CAP,U 0.1-25 Z F AUB3NF XP-R220
O DRIVER C 0613 87-010-759-080 0E C-CAP,U 0.1-25 Z F AUBNF XP-R220
O DRIVER CN 0601 87-099-522-080 1A C-CONN,6P V ZH-SM3 AUB3NF XP-R220
O DRIVER CN 0601 87-099-522-080 1A C-CONN,6P V ZH-SM3 AUBNF XP-R220

S DRIVER IC 0601 87-A21-449-040 1E C-IC,AN8746SA AUB3NF XP-R220
S DRIVER IC 0601 87-A21-449-040 1E C-IC,AN8746SA AUBNF XP-R220
X DRIVER R 0601 88-108-000-080 0E C-JUMPER,U AUB3NF XP-R220
X DRIVER R 0601 88-108-000-080 0E C-JUMPER,U AUBNF XP-R220
X DRIVER R 0602 88-108-100-080 0E C-RES,U 10-1/16W J AUB3NF XP-R220
X DRIVER R 0602 88-108-100-080 0E C-RES,U 10-1/16W J AUBNF XP-R220
X DRIVER R 0603 88-108-000-080 0E C-JUMPER,U AUB3NF XP-R220
X DRIVER R 0603 88-108-000-080 0E C-JUMPER,U AUBNF XP-R220
O EASS C 0451 87-010-831-080 0E C-CAP,U 0.1-16 Z F AUB3NF XP-R220
O EASS C 0451 87-010-831-080 0E C-CAP,U 0.1-16 Z F AUBNF XP-R220

S EASS IC 0451 87-A21-140-010 2P C-IC,MSM51V17400D AUB3NF XP-R220
S EASS IC 0451 87-A21-140-010 2P C-IC,MSM51V17400D AUBNF XP-R220
X EASS R 0451 88-108-100-080 0E C-RES,U 10-1/16W J AUB3NF XP-R220
X EASS R 0451 88-108-100-080 0E C-RES,U 10-1/16W J AUBNF XP-R220
O KNOB 8B-HC1-008-010 — KEY,PLAY AUB3NF XP-R220
O KNOB 8B-HC1-008-010 — KEY,PLAY AUBNF XP-R220
O KNOB 8B-HC1-009-010 — KEY,DSL AUB3NF XP-R220
O KNOB 8B-HC1-009-010 — KEY,DSL AUBNF XP-R220
O KNOB 8B-HC1-010-010 — KNOB,SL OPEN AUB3NF XP-R220
O KNOB 8B-HC1-010-010 — KNOB,SL OPEN AUBNF XP-R220

O KNOB 8B-HC1-011-010 — KEY,BAND AUB3NF XP-R220
O KNOB 8B-HC1-011-010 — KEY,BAND AUBNF XP-R220
O KNOB 8B-HC1-012-010 — KNOB,SL HOLD AUB3NF XP-R220
O KNOB 8B-HC1-012-010 — KNOB,SL HOLD AUBNF XP-R220
O KNOB 8B-HC1-014-010 — KNOB,SL EASS AUB3NF XP-R220
O KNOB 8B-HC1-014-010 — KNOB,SL EASS AUBNF XP-R220
X LBL,POP 8B-HC1-970-010 — LBL,POP AU AUB3NF XP-R220
X LBL,POP 8B-HC1-970-010 — LBL,POP AU AUBNF XP-R220
O MICON C 0301 87-016-350-040 0E CAP,E 470-4 M 5L MA AUB3NF XP-R220
O MICON C 0301 87-016-350-040 0E CAP,E 470-4 M 5L MA AUBNF XP-R220

– 4 –

PARTS LIST

! = ! SAFTY PA RTS
C = Components marked

K NO. = Only use japanese.

O MICON C 0302 87-012-286-080 0E C-CAP,U 0.01-25 K B AUB3NF XP-R220
O MICON C 0302 87-012-286-080 0E C-CAP,U 0.01-25 K B AUBNF XP-R220
O MICON C 0303 87-012-286-080 0E C-CAP,U 0.01-25 K B AUB3NF XP-R220
O MICON C 0303 87-012-286-080 0E C-CAP,U 0.01-25 K B AUBNF XP-R220
O MICON C 0304 87-010-831-080 0E C-CAP,U 0.1-16 Z F AUB3NF XP-R220
O MICON C 0304 87-010-831-080 0E C-CAP,U 0.1-16 Z F AUBNF XP-R220
O MICON C 0305 87-012-286-080 0E C-CAP,U 0.01-25 K B AUB3NF XP-R220
O MICON C 0305 87-012-286-080 0E C-CAP,U 0.01-25 K B AUBNF XP-R220
O MICON C 0306 87-012-286-080 0E C-CAP,U 0.01-25 K B AUB3NF XP-R220
O MICON C 0306 87-012-286-080 0E C-CAP,U 0.01-25 K B AUBNF XP-R220

O MICON C 0307 87-012-286-080 0E C-CAP,U 0.01-25 K B AUB3NF XP-R220
O MICON C 0307 87-012-286-080 0E C-CAP,U 0.01-25 K B AUBNF XP-R220
O MICON C 0308 87-012-286-080 0E C-CAP,U 0.01-25 K B AUB3NF XP-R220
O MICON C 0308 87-012-286-080 0E C-CAP,U 0.01-25 K B AUBNF XP-R220
O MICON C 0309 87-016-430-080 0E C-CAP,E 100-6.3 M 5.5L WX AUB3NF XP-R220
O MICON C 0309 87-016-430-080 0E C-CAP,E 100-6.3 M 5.5L WX AUBNF XP-R220
O MICON C 0310 87-012-286-080 0E C-CAP,U 0.01-25 K B AUB3NF XP-R220
O MICON C 0310 87-012-286-080 0E C-CAP,U 0.01-25 K B AUBNF XP-R220
O MICON CN 0301 87-A60-756-080 1B C-CONN,24P V 24FLT-SM1TB AUB3NF XP-R220
O MICON CN 0301 87-A60-756-080 1B C-CONN,24P V 24FLT-SM1TB AUBNF XP-R220

S MICON D 0301 87-A40-270-080 0E C-DIODE,MC2838 AUB3NF XP-R220
S MICON D 0301 87-A40-270-080 0E C-DIODE,MC2838 AUBNF XP-R220
S MICON IC 0301 8B-HC1-652-030 1H C-IC,MN101C439-AK AUB3NF XP-R220
S MICON IC 0301 8B-HC1-652-030 1H C-IC,MN101C439-AK AUBNF XP-R220
X MICON L 0301 88-118-000-080 0E C-JUMPER,S AUB3NF XP-R220
X MICON L 0301 88-118-000-080 0E C-JUMPER,S AUBNF XP-R220
O MICON L 0302 87-A50-367-080 0E C-COIL, 10UH LQG21F AUB3NF XP-R220
O MICON L 0302 87-A50-367-080 0E C-COIL, 10UH LQG21F AUBNF XP-R220
X MICON R 0301 88-108-274-080 0E C-RES,U 270K-1/16W J AUB3NF XP-R220
X MICON R 0301 88-108-274-080 0E C-RES,U 270K-1/16W J AUBNF XP-R220

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

X MICON R 0302 88-108-473-080 0E C-RES,U 47K-1/16W J AUB3NF XP-R220
X MICON R 0302 88-108-473-080 0E C-RES,U 47K-1/16W J AUBNF XP-R220
X MICON R 0303 88-108-000-080 0E C-JUMPER,U AUB3NF XP-R220
X MICON R 0303 88-108-000-080 0E C-JUMPER,U AUBNF XP-R220
X MICON R 0304 88-108-104-080 0E C-RES,U 100K-1/16W J AUB3NF XP-R220
X MICON R 0304 88-108-104-080 0E C-RES,U 100K-1/16W J AUBNF XP-R220
X MICON R 0305 88-108-223-080 0E C-RES,U 22K-1/16W J AUB3NF XP-R220
X MICON R 0305 88-108-223-080 0E C-RES,U 22K-1/16W J AUBNF XP-R220
X MICON R 0306 88-108-124-080 0E C-RES,U 120K-1/16W J AUB3NF XP-R220
X MICON R 0306 88-108-124-080 0E C-RES,U 120K-1/16W J AUBNF XP-R220

X MICON R 0307 88-108-000-080 0E C-JUMPER,U AUB3NF XP-R220
X MICON R 0307 88-108-000-080 0E C-JUMPER,U AUBNF XP-R220
X MICON R 0309 88-108-473-080 0E C-RES,U 47K-1/16W J AUB3NF XP-R220
X MICON R 0309 88-108-473-080 0E C-RES,U 47K-1/16W J AUBNF XP-R220
X MICON R 0317 88-108-103-080 0E C-RES,U 10K-1/16W J AUB3NF XP-R220
X MICON R 0317 88-108-103-080 0E C-RES,U 10K-1/16W J AUBNF XP-R220
X MICON R 0318 88-108-224-080 0E C-RES,U 220K-1/16W J AUB3NF XP-R220
X MICON R 0318 88-108-224-080 0E C-RES,U 220K-1/16W J AUBNF XP-R220
X MICON R 0321 88-108-104-080 0E C-RES,U 100K-1/16W J AUB3NF XP-R220
X MICON R 0321 88-108-104-080 0E C-RES,U 100K-1/16W J AUBNF XP-R220

X MICON R 0327 88-108-274-080 0E C-RES,U 270K-1/16W J AUB3NF XP-R220
X MICON R 0327 88-108-274-080 0E C-RES,U 270K-1/16W J AUBNF XP-R220
X MICON R 0328 88-108-563-080 0E C-RES,U 56K-1/16W J AUB3NF XP-R220
X MICON R 0328 88-108-563-080 0E C-RES,U 56K-1/16W J AUBNF XP-R220
X MICON R 0335 88-108-000-080 0E C-JUMPER,U AUB3NF XP-R220
X MICON R 0335 88-108-000-080 0E C-JUMPER,U AUBNF XP-R220
O MICON S 0302 87-A91-457-080 1C C-SW,SL 1-1-3 SS-350-A13B-C-T AUB3NF XP-R220
O MICON S 0302 87-A91-457-080 1C C-SW,SL 1-1-3 SS-350-A13B-C-T AUBNF XP-R220
O MICON S 0303 87-A91-457-080 1C C-SW,SL 1-1-3 SS-350-A13B-C-T AUB3NF XP-R220
O MICON S 0303 87-A91-457-080 1C C-SW,SL 1-1-3 SS-350-A13B-C-T AUBNF XP-R220

O MICON(LID) C 0901 87-A10-047-080 0E C-CAP,U 1-10 Z F AUB3NF XP-R220
O MICON(LID) C 0901 87-A10-047-080 0E C-CAP,U 1-10 Z F AUBNF XP-R220
O MICON(LID) C 0902 87-012-286-080 0E C-CAP,U 0.01-25 K B AUB3NF XP-R220
O MICON(LID) C 0902 87-012-286-080 0E C-CAP,U 0.01-25 K B AUBNF XP-R220
O MICON(LID) C 0903 87-A10-025-080 0E C-CAP,U 0.22-16 Z F AUB3NF XP-R220
O MICON(LID) C 0903 87-A10-025-080 0E C-CAP,U 0.22-16 Z F AUBNF XP-R220
O MICON(LID) C 0904 87-A10-025-080 0E C-CAP,U 0.22-16 Z F AUB3NF XP-R220
O MICON(LID) C 0904 87-A10-025-080 0E C-CAP,U 0.22-16 Z F AUBNF XP-R220
O MICON(LID) C 0905 87-A10-025-080 0E C-CAP,U 0.22-16 Z F AUB3NF XP-R220
O MICON(LID) C 0905 87-A10-025-080 0E C-CAP,U 0.22-16 Z F AUBNF XP-R220

– 5 –

PARTS LIST

! = ! SAFTY PA RTS
C = Components marked

K NO. = Only use japanese.

O MICON(LID) C 0906 87-A10-025-080 0E C-CAP,U 0.22-16 Z F AUB3NF XP-R220
O MICON(LID) C 0906 87-A10-025-080 0E C-CAP,U 0.22-16 Z F AUBNF XP-R220
O MICON(LID) C 0907 87-A10-047-080 0E C-CAP,U 1-10 Z F AUB3NF XP-R220
O MICON(LID) C 0907 87-A10-047-080 0E C-CAP,U 1-10 Z F AUBNF XP-R220
O MICON(LID) C 0908 87-012-198-080 0E C-CAP,U 180P-50 J CH AUB3NF XP-R220
O MICON(LID) C 0908 87-012-198-080 0E C-CAP,U 180P-50 J CH AUBNF XP-R220
O MICON(LID) C 0909 87-012-198-080 0E C-CAP,U 180P-50 J CH AUB3NF XP-R220
O MICON(LID) C 0909 87-012-198-080 0E C-CAP,U 180P-50 J CH AUBNF XP-R220
O MICON(LID) C 0910 87-012-274-080 0E C-CAP,U 1000P-50 K B AUB3NF XP-R220
O MICON(LID) C 0910 87-012-274-080 0E C-CAP,U 1000P-50 K B AUBNF XP-R220

O MICON(LID) C 0911 87-010-831-080 0E C-CAP,U 0.1-16 Z F AUB3NF XP-R220
O MICON(LID) C 0911 87-010-831-080 0E C-CAP,U 0.1-16 Z F AUBNF XP-R220
O MICON(LID) C 0912 87-010-831-080 0E C-CAP,U 0.1-16 Z F AUB3NF XP-R220
O MICON(LID) C 0912 87-010-831-080 0E C-CAP,U 0.1-16 Z F AUBNF XP-R220
S MICON(LID) D 0901 87-A40-270-080 0E C-DIODE,MC2838 AUB3NF XP-R220
S MICON(LID) D 0901 87-A40-270-080 0E C-DIODE,MC2838 AUBNF XP-R220
S MICON(LID) IC 0901 8B-HC1-602-010 — C-IC,HD6433863A71W AUB3NF XP-R220
S MICON(LID) IC 0901 8B-HC1-602-010 — C-IC,HD6433863A71W AUBNF XP-R220
O MICON(LID) L 0901 8B-HC1-607-080 — C-COIL,OSC 1.00MHZ AUB3NF XP-R220
O MICON(LID) L 0901 8B-HC1-607-080 — C-COIL,OSC 1.00MHZ AUBNF XP-R220

O MICON(LID) LCD0901 8B-HC1-610-010 — LCD, BHC-1 AUB3NF XP-R220
O MICON(LID) LCD0901 8B-HC1-610-010 — LCD, BHC-1 AUBNF XP-R220
S MICON(LID) Q 0901 87-A30-385-040 0E C-TR,DTA114YUA AUB3NF XP-R220
S MICON(LID) Q 0901 87-A30-385-040 0E C-TR,DTA114YUA AUBNF XP-R220
S MICON(LID) Q 0902 87-A30-404-040 0E C-TR,DTC114YUA AUB3NF XP-R220
S MICON(LID) Q 0902 87-A30-404-040 0E C-TR,DTC114YUA AUBNF XP-R220
S MICON(LID) Q 0903 87-A30-385-040 0E C-TR,DTA114YUA AUB3NF XP-R220
S MICON(LID) Q 0903 87-A30-385-040 0E C-TR,DTA114YUA AUBNF XP-R220
S MICON(LID) Q 0904 87-A30-385-040 0E C-TR,DTA114YUA AUB3NF XP-R220
S MICON(LID) Q 0904 87-A30-385-040 0E C-TR,DTA114YUA AUBNF XP-R220

All components used on this model at the production line are shown in this service manual.
However, please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service, and will not be stocked at the spare parts centers.

C UNIT NAME REF NO. MODEL NAME! DESCRIPTIONK NO.PARTS CODE SUFFIX

S MICON(LID) Q 0905 87-A30-143-040 0E C-TR,2SA1576A AUB3NF XP-R220
S MICON(LID) Q 0905 87-A30-143-040 0E C-TR,2SA1576A AUBNF XP-R220
X MICON(LID) R 0901 88-108-473-080 0E C-RES,U 47K-1/16W J AUB3NF XP-R220
X MICON(LID) R 0901 88-108-473-080 0E C-RES,U 47K-1/16W J AUBNF XP-R220
X MICON(LID) R 0902 88-108-822-080 0E C-RES,U 8.2K-1/16W J AUB3NF XP-R220
X MICON(LID) R 0902 88-108-822-080 0E C-RES,U 8.2K-1/16W J AUBNF XP-R220
X MICON(LID) R 0903 88-108-332-080 0E C-RES,U 3.3K-1/16W J AUB3NF XP-R220
X MICON(LID) R 0903 88-108-332-080 0E C-RES,U 3.3K-1/16W J AUBNF XP-R220
X MICON(LID) R 0904 88-108-683-080 0E C-RES,U 68K-1/16W J AUB3NF XP-R220
X MICON(LID) R 0904 88-108-683-080 0E C-RES,U 68K-1/16W J AUBNF XP-R220

X MICON(LID) R 0905 88-108-223-080 0E C-RES,U 22K-1/16W J AUB3NF XP-R220
X MICON(LID) R 0905 88-108-223-080 0E C-RES,U 22K-1/16W J AUBNF XP-R220
X MICON(LID) R 0906 88-108-682-080 0E C-RES,U 6.8K-1/16W J AUB3NF XP-R220
X MICON(LID) R 0906 88-108-682-080 0E C-RES,U 6.8K-1/16W J AUBNF XP-R220
X MICON(LID) R 0907 88-108-392-080 0E C-RES,U 3.9K-1/16W J AUB3NF XP-R220
X MICON(LID) R 0907 88-108-392-080 0E C-RES,U 3.9K-1/16W J AUBNF XP-R220
X MICON(LID) R 0908 88-108-472-080 0E C-RES,U 4.7K-1/16W J AUB3NF XP-R220
X MICON(LID) R 0908 88-108-472-080 0E C-RES,U 4.7K-1/16W J AUBNF XP-R220
X MICON(LID) R 0909 88-108-333-080 0E C-RES,U 33K-1/16W J AUB3NF XP-R220
X MICON(LID) R 0909 88-108-333-080 0E C-RES,U 33K-1/16W J AUBNF XP-R220

X MICON(LID) R 0910 88-108-333-080 0E C-RES,U 33K-1/16W J AUB3NF XP-R220
X MICON(LID) R 0910 88-108-333-080 0E C-RES,U 33K-1/16W J AUBNF XP-R220
X MICON(LID) R 0911 88-108-393-080 0E C-RES,U 39K-1/16W J AUB3NF XP-R220
X MICON(LID) R 0911 88-108-393-080 0E C-RES,U 39K-1/16W J AUBNF XP-R220
X MICON(LID) R 0912 88-108-104-080 0E C-RES,U 100K-1/16W J AUB3NF XP-R220
X MICON(LID) R 0912 88-108-104-080 0E C-RES,U 100K-1/16W J AUBNF XP-R220
X MICON(LID) R 0913 88-108-474-080 0E C-RES,U 470K-1/16W J AUB3NF XP-R220
X MICON(LID) R 0913 88-108-474-080 0E C-RES,U 470K-1/16W J AUBNF XP-R220
X MICON(LID) R 0914 88-108-474-080 0E C-RES,U 470K-1/16W J AUB3NF XP-R220
X MICON(LID) R 0914 88-108-474-080 0E C-RES,U 470K-1/16W J AUBNF XP-R220

X MICON(LID) R 0915 88-108-473-080 0E C-RES,U 47K-1/16W J AUB3NF XP-R220
X MICON(LID) R 0915 88-108-473-080 0E C-RES,U 47K-1/16W J AUBNF XP-R220
X MICON(LID) R 0916 88-108-104-080 0E C-RES,U 100K-1/16W J AUB3NF XP-R220
X MICON(LID) R 0916 88-108-104-080 0E C-RES,U 100K-1/16W J AUBNF XP-R220
X MICON(LID) R 0917 88-108-102-080 0E C-RES,U 1K-1/16W J AUB3NF XP-R220
X MICON(LID) R 0917 88-108-102-080 0E C-RES,U 1K-1/16W J AUBNF XP-R220
X MICON(LID) R 0918 88-108-102-080 0E C-RES,U 1K-1/16W J AUB3NF XP-R220
X MICON(LID) R 0918 88-108-102-080 0E C-RES,U 1K-1/16W J AUBNF XP-R220
X MICON(LID) R 0919 88-108-102-080 0E C-RES,U 1K-1/16W J AUB3NF XP-R220
X MICON(LID) R 0919 88-108-102-080 0E C-RES,U 1K-1/16W J AUBNF XP-R220

– 6 –
