Por table DVD Player

User manual

PET714 PET718

8 7

AV OUT/DVD

6 5 4

3 2

! @ # %$

5 7

% @

6 7

8 9

^ $ #

English

FUNCTIONAL OVERVIEW

Congratulations on your purchase and welcome to Philips! To fully benefit from the support that Philips offers, register your product at www.philips.com/welcome.

Main unit controls ( see figure 1)

1 OPEN .....................Open the disc door to insert or remove disc.

2 OK ..........................Confirm a selection.

3 3, 4, 1, 2 ...........Navigate in a menu.

...........(1 / 2) search backward/forward in a disc at different

speeds.

4 DISPLAY MODE....Switch to AV Out mode.

5 MENU.....................Enter or exit the disc contents menu.

6 J( / § ..................Skip to the previous/next chapter, track or title.

7 2

;

.........................Start or interrupt playback.

8 9.............................Stop playback or erase a program.

9 IR.............................Remote sensor.

0 POWER and CHG..Power and charge indicator.

Left of player ( see figure 1)

! ....................Power supply socket.

@ AV OUT... ...............Audio/Video output jack.

FUNCTIONAL OVERVIEW

# ...................Volume control.

$ ...............Headphone jacks.

% ON/OFF...................Switch the power on/off.

Remote controls ( see figure 2)

1 SETUP....................Enter or exit the system menu.

2 DVD MENU...........Enter or exit the disc contents menu.

3 3, 4, 1, 2 ...........Navigate in a menu.

...........(1 / 2) search backward/forward in a disc at different

speeds.

4 OK ...........................Confirm a selection.

5 PROGRAM .............Enter the program menu.

6 DISPLAY ................Display information on TFT during playback.

7 PREV/NEXT J( / § Skip to the previous/next chapter, track or title. 8 PLAY/PAUSE 2;...Start or interrupt playback.

REMOTE CONTROL

9 STOP 9 ..................Stop playback or erase a program.

0 TITLE ......................Display the disc title

! Numeric Keypad (0-9)...Input numbers.

@ REPEAT ..................Repeat a chapter/track/title.

# A-B... ......................Repeat playback of a specific section on a disc.

$ ZOOM .....................Enlarge or reduce a picture or active image on the TFT.

% SUBTITLE ..............Select a subtitle language.

^ AUDIO ....................Select an audio language when playing a DVD disc or

select an audio mode (Stereo, Mono-Left or Mono-Right) when playing a VCD/CD disc.

CAUTION

Use of controls or adjustments or performance of procedures other than herein may result in hazardous radiation exposure or other unsafe operation.

INTRODUCTION

Your portable DVD player

Your portable DVD player plays digital video discs conforming to the universal DVD Video standard. With it, you will be able to enjoy full-length movies with true cinema picture quality, and stereo or multichannel sound (depending on the disc and on your playback set-up).

The unique features of DVD-Video, such as selection of soundtrack and subtitle languages, and of different camera angles (again depending on the disc), are all included.

What’s more, parental lock lets you decide which discs your children will be able to see. You will find your player remarkably easy to use with the On-Screen Display and player display in combination with the remote control.

Unpacking

• Portable DVD player • Remote Control

• Car adaptor (12V) • Audio / Video cable

• User Manual • Warranty

• Quick Start Guide

• AC power adaptor, DSA-9W-09 F (DVE) or AY4132 (PHILIPS) for PET714 only DSA-20R-12F (DVE) for PET718 only

Placement

• Place the player on a firm, flat surface.

• Keep away from domestic heating equipment and direct sunlight.

• If the player cannot read CDs/DVDs correctly, try using a commonly

available cleaning CD/DVD to clean the lens before taking the player to be repaired. Other cleaning methods may destroy the lens.

• Always keep the disc door closed to avoid dust on the lens.

• The lens may cloud over when the player is suddenly moved from cold to warm

surroundings. It is then not possible to play a CD/DVD. Leave the player in a warm environment until the moisture evaporates.

INTRODUCTION

About Built-in Rechargeable Battery

Precautions related to battery recharge 1 Once the battery is fully discharged, immediately recharge it (regardless of

whether you plan to use the battery or not) in order to maximize the battery life. When the power is low, the battery icon will be shown on the upper-left corner of the TFT for warning.

2 To charge the battery, please directly connect this DVD player to AC mains

and the charge indicator will turn on.

Using and maintaining your rechargeable batteries 1 Please make sure you always use only the AC adapter included with the play-

er to recharge your batteries.

2 Recharge efficiency will degrade when the environmental temperature drops

below 50

F (10oC) or exceed 95oF (35oC).

3 The lasting time of the fully charged battery when a headphone is connected

to the DVD player is approximately 2 hours.

Playable disc formats

In addition to DVD-Video disc, you will also be able to play all Video CDs and audio CDs (including CDR, CDRW,DVD

±R and DVD±RW).

DVD-Video

Depending on the material on the disc (a movie, video clips, a drama series, etc.) these discs may have one or more Titles, and each Title may have one or more Chapters. To make access easy and convenient, your player lets you move between Titles, and also between Chapters.

CD with JPEG files

You can also view JPEG still photos on this player.

INTRODUCTION

Video CD

Depending on the material on the disc (a movie, video clips, a drama series, etc.) these discs may have one or more Tracks, and tracks may have one or more indexes, as indicated on the disc case.To make access easy and convenient, your player lets you move between tracks and between indexes.

Audio CD / MP3 CD

Audio CDs / MP3-CD contain music tracks only. You can play them in the conventional way through a stereo system using the keys on the remote control and/or main unit, or via the TV using the On Screen Display (OSD).

GENERAL INFORMATION

Power Sources

This unit operates on a supplied AC adapter, car adapter, or the built-in Ni-MH battery.

• Make sure that the input voltage of the AC adaptor is in line with the local volt-

age. Otherwise, the AC adaptor and unit may be damaged.

• Do not touch the AC adaptor with wet hands to prevent electric shock.

• When connecting with car power (cigarette lighter) adaptor, be sure the

input voltage of the adaptor is identical with car voltage.

• Unplug the AC adaptor from the outlet when the unit is not used for long peri-

ods of time.

• Hold the plug to disconnect the AC adaptor. Do not pull the power cord.

Safety and maintenance

• Do not disassemble the unit for laser rays are dangerous to eyes.

Any service should be done by qualified service personnel.

• Unplug the AC adaptor to cut the power if liquid or objects get inside the unit.

• Take care not to drop the unit or subject it to strong shocks, which may

cause malfunction.

• Important (for models with by-packed headphones): Philips guarantees compli-

ance with the maximum sound power of its audio players as determined by relevant regulatory bodies only with the original model of provided headphones. In case this one needs replacement, we recommend that you contact your retailer to order a model identical to that of the original provided by Philips.

• Traffic safety: do not use while driving or cycling as you may cause an accident

• Do not expose to excessive heat caused by heating equipment or

direct sunlight.

• This product is not waterproof: do not allow your player to be submersed

in water. Water entering the player may cause major damage.

• Do not use any cleaning agents containing alcohol, ammonia, benzene,

or abrasives as these may harm the player.

• The apparatus shall not be exposed to dripping or splashing. Do not place any

sources of danger on the apparatus (e.g. liquid filled objects,lighted candles)

• Do not touch the lens!

• Excessive sound pressure from earphones and headphones can cause hearing loss.

• Battery shall not be exposed to excessive heat such as sunshine, fire or the like.

Note: When the player is in use for a long period of time, the surface will be

heated. This is normal.
