Page 1
True wireless
JT60
User manual
Register your product and get support at
www.philips.com/support
Page 2
Contents
1 Important safety instructions 2
Hearing Safety 2
General information 2
2 Your True wireless
earphones 3
What's in the box 3
Other devices 3
Overview of your Bluetooth
wireless earpieces 4
3 Get started 5
Charge the battery 5
Pair the earpieces with your
Bluetooth device at the rst
time 6
Pair the earpieces with another
Bluetooth device 7
4 Use your headphones 7
Connect the earpieces to your
Bluetooth device 7
Power on/o 8
Manage your calls and music 8
LED indicator status 8
How to wear 9
5 Reset the earpieces 10
6 Technical data 10
7 Notice 11
Declaration of conformity 11
Disposal of your old product
and battery 11
Compliance with EMF 11
Environmental information 12
Notice of compliance 12
8 Trademarks 13
9 Frequently asked questions 14
Page 3
1 Important
General information
safety
instructions
Hearing Safety
Danger
To avoid hearing damage, limit the time you
use headphones at high volume and set the
volume to a safe level. The louder the
volume, the shorter the safe listening time is.
Be sure to observe the following guidelines when using your earpieces.
• Listen at reasonable volumes for
reasonable periods of time.
• Be careful not to adjust the volume
continuously upwards as your
hearing adapts.
• Do not turn up the volume so high
that you can't hear what's around
you.
• You should use caution or temporarily discontinue use in potentially
hazardous situations.
• Excessive sound pressure from
earphones and headphones can
cause hearing loss.
• Using headphones with both ears
covered while driving is not recommended and may be illegal in some
areas while driving.
• For your safety, avoid distractions
from music or phone calls while in
trac or other potentially dangerous
environments.
To avoid damage or malfunction:
Caution
Do not expose headphones to excessive heat
Do not drop your headphones.
Headphones shall not be exposed to dripping
or splashing.
Do not allow your headphones to be
submerged in water.
Do not use any cleaning agents containing
alcohol, ammonia, benzene, or abrasives.
If cleaning is required use a soft doth, if
necessary dampened with a minimum amount
of water or diluted mild soap, to clean the
product.
The integrated battery shall not be exposed to
excessive heat such as sunshine, re or the
like.
Danger of explosion if battery is incorrectly
replaced. Replace only with the same or
equivalent type.
About operating and storage temperatures
and humidity
• Store in a place where temperature is
between -20°C (-4°F) and 50°C (122 °F)
(up to 90% relative humidity.
• Operate in a place where temperature
is between 0°C (32°F) and 45°C (113 °F)
(up to 90% relative humidity.
• Battery life may be shorter in high or
low temperature conditions.
• Replacement of a battery with an
incorrect type that can defeat a
safeguard (for example, in the case of
some lithium battery types);
• Disposal of a battery into re or a hot
oven, or mechanically crushing or
cutting of a battery, can result in an
explosion;
• Leaving a battery in an extremely high
temperature surrounding environment
can result in an explosion or the
leakage of ammable liquid or gas;
• A battery subjected to extremely low
air pressure that may result in an
explosion or the leakage of ammable
liquid or gas.
Page 4
2 Your True
wireless
earphones
Congratulations on your purchase, and
welcome to Philips! To fully benet
from the support that Philips oers,
register your product at
www.philips.com/support
With this Philips wireless earpieces, you
can:
• enjoy convenient wireless
handsfree calls;
• enjoy and control wireless music;
• switch between calls and music.
What's in the box
USB charging cable (for charging only)
Quick start guide
Global Warranty
Safety leaet
True wireless in-ear headphones
Philips JT60
Replaceable rubber ear caps x 3 pairs
Charging case
Other devices
A mobile phone or device (e.g. notebook, PDA, Bluetooth adapters, MP3
players etc) which supports Bluetooth
and is compatible to the earpieces
(see 'Technical data' on page 10).
Page 5
Overview of your
Bluetooth wireless
earpieces
Microphone
LED indicator (earphone)
Multi-function touch
LED indicator (charging case)
USB-C charging slot
5
Page 6
3 Get started
Charge the battery
Note
Before you use your earpieces for the rst
time, place the earpieces in the charging case
and charge the battery for 2 hours for
optimum battery capacity and lifetime.
Use only the original USB charging cable to
avoid any damage.
Finish your call before charging the earpieces,
as connecting the earpieces for charging will
power the earpieces o.
Charging case
Connect one end of the USB cable into
the charging case, and another end into
the power source.
The charging case starts charging.
• Charging process is veried by the
blue LED light on the front panel,
• When the charging case is fully
charged, the blue light goes on.
Earpieces
Place the earpieces in the charging case.
The earpieces start charging.
• Charging process is veried by white
LED light on the earpieces.
• When the earpieces is fully charged,
the white light goes o.
Tip
Normally, a full charge takes 2 hours (for the
earpieces or charging case).
Tip
The charging case serves as a portable backup
battery for charging the earpieces. When the
charging case is fully charged, it supports 3 full
recharge cycle for the earpieces.
Page 7
Pair the earpieces with
your Bluetooth device at
the st time
Make sure that the earpieces is fully
charged.
Open the top cover and take out
both earpieces from charging box.
The following example shows you
how to pair the earpieces with
your Bluetooth device.
Turn on the Bluetooth function
of your Bluetooth device, select
Philips JT60.
Enter the earpieces password
“0000” (4 zeros) if prompted.
For those Bluetooth devices
featuring Bluetooth 3.0 or higher,
no need to enter a password.
Philips JT60
The LED on both earpieces
ash in whtie & blue alternately.
The earpieces is now in pairing
mode and is ready to pair with a
Bluetooth device (e.g. a mobile
phone).
Turn on the Bluetooth function of
your Bluetooth device.
Pair the earpieces with your
Bluetooth device. Refer to the user
manual of your Bluetooth device.
Note
After powering on, if the earpieces cannot nd
any previously connected Bluetooth device, it
will automatically switch to pairing mode.
Single earpiece pairing
(Mono mode)
Take either right or Left earpiece out
from charging box for Mono use. The
earpiece will power on automatically.
There will be a voice “Power on” from
earpiece.
Note
Take the second Earpiece from the charging
box and they will pair each other automatically.
Page 8
Pair the earpieces with
another Bluetooth device
If you have another Bluetooth device
that you want to pair with the earpieces,
make sure the Bluetooth function in any
other previously paired or connected
devices are turned o.
Long touch over 5 seconds both left &
right side simultaneously with earpiece
on ear, release when Pairing voice
prompt is heard.
Note
The earpieces stores 4 device in the memory. If
you try to pair more than 4 devices, the earliest
paired device is replaced by the new one.
4 Use your
earpieces
Connect the earpieces to
your Bluetooth device
Turn on the Bluetooth function of
your Bluetooth device.
Open the top cover from charging
box.
The blue LED ashes.
The earpieces will search the
last connected Bluetooth device
and reconnect to it automatically. If the last connected device is
not available, the earpieces will
enter pairing mode.
Tip
The earpieces cannot connect to more than 1
device at the same time. If you have two paired
Bluetooth devices, only turn on the Bluetooth
function of the device that you want to connect.
If you turn on the Bluetooth function of your
Bluetooth device after turning on the earpieces,
you have to go to the Bluetooth menu of the
device and connect the earpieces to the device
manully.
Note
If the earpieces fails to connect to any
Bluetooth device within 5 minutes, it will turn o
automatically to save the battery life.
In some Bluetooth devices, connection may not
be automatic. In this case, you have to go to the
Bluetooth menu of your device and connect the
earpieces to the Bluetooth device manually.
Page 9
Power on/o
Task
Turn the
earpieces
on.
Turn the
earpieces
o.
Multifunction
button
Operation
Earpiece
take out
from
charging
box to
power on
Earpiece
put back to
charging
box to
power o
Call control
Task
Pick up/
hang up call/
Reject call
Switch caller
during a call
Tip
By removing the earpiece, it will automatically
change to sleep mode. When put earpiece back, it
will return to active mode.
Multifunction
button
Right/Left
earpiece
Right/Left
earpiece
Operation
Single tap
Tap and
hold
Manage your calls and
music
Music control
Task
Play or
pause music
Skip forward Right /Left
Skip
backward
Multifunction
button
Right/Left
earpiece
earpiece
Right
earpieces
Operation
Single tap
Double
taps
Triple taps
LED indicator status
Headphones
status
The earpieces are
connected to a
Bluetooth device.
The earpieces are
ready for pairing
The earpieces are
on but not
connected to a
Bluetooth device
Low battery level
(earpieces)
Battery is fully
Battery LED indicator on
charged
earpieces status
(charging box).
Indicator
White LED blink
every 5s
The blue & white
LED ash
alternately
White LED blink
every 1s
(auto turn o after
3min)
Blue LED blink 2x
every 5s
Refer to Case
LED
Page 10
Charging Box (4 blue
LED)
Battery LED indicator on
Bluetooth device
Charging Box
LED (USB on)
Charging Box
LED (USB o)
Indicator
Continue to lit as
long as USB is on
Indicator
It will show a battery indicator on
Bluetooth device after connected to
earpieces.
Voice Assistant
Task
Trigger voice
(Siri/Google)
assistant
Button
Left
earpiece
Operation
Tap and
hold 2
seconds
How to wear
Tip
When USB is o, the LED is lit for 30s after case open
or closed
Page 11
5 Reset the
earpieces
6 Technical data
If you encounter any pairing or connection
issue, you can follow the following
procedure to factory reset your earpieces.
On your Bluetooth device, go to the
Bluetooth menu and remove
Philips JT60 from the device list.
Turn o the Bluetooth function of your
Bluetooth device.
Tap & hold multi-function touch for
>25s on each earpiece individually.
Return earpieces to charging box &
close the lid.
Follow steps in “Use your earpiec-
5
es-Connect the earpieces to your
Bluetooth device.”
Pair the earpieces with your
6
Bluetooth device, select Philips
JT60
Music time — 6 hours
Talk time — 6 hours
Standby time — 200 hours
Charging time: 2 hours
Lithium-ion battery 55 mAh on each
earpiece, Lithium-ion battery 380
mAh on charging box
Bluetooth version: 5.0
Compatible Bluetooth proles:
• HSP (Hands-Free Prole-HFP)
• A2DP (Advanced Audio Distri-
bution Prole)
• AVRCP (Audio Video Remote
Control Prole)
Supported audio codec: SBC, AAC
Frequency range: 2.402-2.480 GHz
Transmitter power: < 10 dBm
Operating range: Up to 10 meters (33
feet)
Auto power o
USB-C port for charging
Low battery warning: available
Note
Specications are subject to change without
notice.
Page 12
7 Notice
Declaration of conformity
Hereby, MMD Hong Kong Holding Limited
declares that this product is in compliance with the essential requirements and
other relevant provisions of Directive
2014/53/EU. You can nd the Declaration
of Conformity on www.p4c.philips.com.
Disposal of your old
product and battery
Your product is designed and manufactured with high quality materials and
components, which can be recycled and
reused.
This symbol on a product means that
the product is covered by European
Directive 2012/19/EU.
Remove the integrated battery
If there is no collection/recycling system
for electronic products in your country,
you can protect the environment by
removing and recycling the battery
before disposing the headphones.
• Make sure the earpieces is disconnected from the charging case
before removing the battery.
• Make sure the charging case is
disconnected from the USB
charging cable before removing the
battery.
This symbol means that the product
contains a built-in rechargeable battery
covered by European Directive
2013/56/EU which cannot be disposed
of with normal household waste. We
strongly advise you to take your product
to an ocial collection point or a Philips
service centre to have a professional
remove the rechargeable battery.
Inform yourself about the local separate
collection system for electrical and
electronic products and rechargeable
batteries. Follow local rules and never
dispose of the product and rechargeable
batteries with normal household waste.
Correct disposal of old products and
rechargeable batteries helps prevent
negative consequences for the environment and human health.
Compliance with EMF
This product complies with all applicable standards and regulations regarding
exposure to electromagnetic elds.
Page 13
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard
(box), polystyrene foam (buer) and
polyethylene (bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by a
specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and
old equipment.
Notice of compliance
The device complies with the FCC rules, Part
15. Operation is subject to the following two
conditions:
1. This device may not cause harmful
interference, and
2. This device must accept any interference
received, including interference that may
cause undesired operation.
FCC rules
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate
radio frequency energy and, if not installed
and used in accordance with the instruction
manual, may cause harmful interference to
radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment o and on, the user is
encouraged to try to correct the interference
by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between equipment
and receiver
Connect the equipment into an outlet on a
circuit dierent from that to which the
receiver is connected.
Consult the dealer or an experienced
radio/TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment.
This transmitter must not be co-located or
operating in conjunction with any other
antenna or transmitter.
Caution: The user is cautioned that changes
or modications not expressly approved by
the party responsible for compliance could
void the user's authority to operate the
equipment.
Canada:
This device contains licence-exempt
transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development Canada’s licence-exempt RSS(s).
Operation is subject to the following two
conditions: (1)This device may not cause
interference. (2)This device must accept any
interference, including interference that may
cause undesired operation of the device.
L’émetteur/récepteur exempt de licence
contenu dans le présent appareil est
conforme aux CNR d’Innovation, Sciences et
Développement économique Canada
applicables aux appareils radio exempts de
licence.
L’exploitation est autorisée aux deux
conditions suivantes : (1) L’appareil ne doit
pas produire de brouillage; (2) L’appareil doit
accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en
compromettre le fonctionnement.
CAN ICES-3(B)/NMB-3(B)
IC Radiation Exposure Statement:
This equipment complies with Canada
radiation exposure limits set forth for
uncontrolled environments.
This transmitter must not be co-located or
operating in conjunction with any other
antenna or transmitter.
Page 14
8 Trademarks
Bluetooth
The Bluetooth® word mark and logos
are registered trademarks owned by
Bluetooth SIG, Inc. and any use of such
marks by MMD Hong Kong Holding
Limited is under license. Other trademarks and trade names are those of
their respective owners.
Siri
Siri is a trademark of Apple Inc., registered in the U.S. and other countries.
Google
Google and Google Play are trademarks
of Google LLC.
Page 15
9 Frequently
asked
questions
My Bluetooth headset is connected to a
Bluetooth stereo enabled mobile phone,
but music only plays on the mobile phone
speaker.
Refer to the user manual of your mobile
phone. Select to listen to music through
the headset.
My Bluetooth headset does not turn on.
The battery level is low. Charge the
headset.
I cannot pair my Bluetooth headset with
my Bluetooth device.
The Bluetooth is disabled. Enable the
Bluetooth feature on your Bluetooth
device and turn on the Bluetooth device
before you turn on the headset.
Pairing does not work.
• Put both earpieces into charging box.
• Make sure you have disabled the
Bluetooth function of any previously
connected Bluetooth devices.
• On your Bluetooth device, delete
“Philips JT60” from the Bluetooth
list.
• Pair your headset (see ‘Pair the
headset with your Bluetooth device
at the rst time’ on page 6).
The Bluetooth device cannot nd the
headset.
• The headset may be connected to a
previously paired device. Turn o the
connected device or move it out of
range.
• Pairing may have been reset or the
headset has been previously paired
with another device. Pair the headset
with the Bluetoot device again as
described in the user manual. (see
‘Pair the headset with your Bluetooth
device at the st time’ on page 6).
The audio quality is poor and crackling
noise can be heard.
• The Bluetooth device is out of range.
Reduce the distance between your
headset and Bluetooth device, or
remove obstacles between them.
• Charge your headset.
The audio quality is poor when streaming
from the mobile phone is very slow, or
audio streaming does not work at all.
Make sure your mobile phone not only
supports (mono) HSP/HFP but alos
supports A2DP and is BT4.0x (or higher)
compatible (see ‘Technical data’ on page
10).
APP DOWNLOAD
Scan the QR code/press 'Download'
button or search 'Philips Headphones' in
Apple App Store or Google Play to
download App.
Page 16
Philips and the Philips Shield Emblem are registered trademarks of
Koninklijke Philips N.V. and are used under license. This product has been
manufactured by and is sold under the responsibility of MMD Hong Kong
Holding Limited or one of its aliates, and MMD Hong Kong Holding
Limited is the warrantor in relation to this product.
UM_JT60_00_EN_V2.0
Loading...
