SRP3014

User manual

2 EN

Contents

1 Your universal remote 2

Introduction 2
Overview of the universal remote 2
Supported devices 3

2 Get started 4

Insert batteries (not included) 4
Set up the universal remote 5

3 Notice 9

Notice of compliance 9
Disposal of your old product and batteries 10

4 Service and support 11

Frequently asked questions 11
Need help? 11

English

EN 1

1 Your universal remote

Congratulations on your purchase, and welcome to Philips! To fully

benet from the support that Philips offers, register your product at

www.philips.com/welcome

Introduction

With the universal remote, you can operate up to 4 different devices.

Overview of the universal remote

a

b

c

d

e

f

g

a INPUT: select available source inputs (antenna, cable, etc.).

: power on or off.

: LED indicator

b Device selection buttons

2 EN

c LIVE: displays live TV programs.

LIST: displays a list of recorded programs.
INFO: displays on-screen channel information.
STREAM: shor tcut to the Netix.
GUIDE: displays the program guide.

: play

: fast forward

: rewind
: pause
: stop

: record

d

/ / / : scroll the menu up/down/left/right.

OK: conrm your selection.
MENU: menu on or off.
BACK: go back one menu level or exit.

e

: mute

LAST: return to the previous tuned channel.
CH+/CH-: go to the next/previous channel.
VOL: adjust the volume.

f A/B/C/D: context sensitivity buttons (A - yellow, B - blue, C- red,

D - Green).

g Digit buttons

ENTER: conrm the digit button selection.
(-): selects between one and two-gure channel numbers.

English

Note

The button “STREAM” is pre-programmed as a shortcut to Netix. All other

•

streaming services such as Vudu, Amazon, YouTube and Hulu Plus etc may be

accessed through navigation.

Supported devices

Device name Description

TV TV, DTV
BD DVD player/recorder, Blu-ray player
STB Cable box, satellite receiver, IPTV, DVR, HDTV

decoder and TiVo

STR Streaming devices, Apple TV, Roku, Sony, WD TV,

Netgear

EN 3

2 Get started

Insert batteries (not included)

Warning

Check the battery polarity when inser ting in the batter y compartment. Incorrect

•

polarity may damage the product.

Caution

Risk of explosion! Keep batteries away from heat, sunshine or re. Never discard

•

batteries in re.

• Risk of decreased battery life! Never mix different brands or types of batteries.

Note

When you replace the batteries, all user settings will be retained in the memory of

•

the universal remote for 5 minutes.

4 EN

Set up the universal remote

You must rst set up the universal remote before operating your

devices.

Manual registration

Switch on your device.

1

Press and hold the device selection button (e.g. TV) for 5 seconds

2

until the blu

e LED is on.

English

Look up the 5-digit code for your brand in the code list. Codes

3

are listed by the device type and brand name. The most popular

code is listed rst.

EN 5

Enter the rst 5-digit code using the digit buttons.

4

If the light is off, a valid code is saved. Otherwise, the light will ash

5

once, and then remains on for code re-entry.

Operate the device with the universal remote. If your device

6

responds correctly, it means you have entered the right code.
Otherwise, repeat from step 2, and enter the second code on the
list.

Note

It is possible sometimes that your device only responds to some of the buttons. In

•

such case, set up with the next code in the code list, and try operating your device

again.

6 EN

Auto registration

Switch on your device.

1

Press and hold the device selection button (e.g. TV) for 5 seconds

2

until the blu

e LED is on.

English

Point at your device with the universal remote. Then press and

3

release
infrared signal is sent every 2 seconds as the universal remote

searches, indicated by a blue flash.

to start searching the code for your brand. A different

EN 7

When the device is off, immediately press and release OK to save

4

the code. The blu

max. 20
minutes

Operate the device with the universal remote. If your device

5

e LED indicator will turn off.

responds correctly, it means you have saved the right code.

Note

•

Auto registration can be reversed, by pressing and releasing once more during
the auto registration process. This is helpful if you missed out the chance to press OK

within 2 seconds. Make sure that the device is rst powered on again.

• Repeat the same procedures to set up other devices.

8 EN

3 Notice

Notice of compliance

Notice for US

This set complies with the FCC rules, Part 15 and with 21 CFR

1040.10. Operation is subject to the following two conditions:

a This device may not cause harmful interference, and
b This device must accept any interference received, including

interference that may cause undesired operation.

FCC rules

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may
cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to tr y to correct the
interference by one or more of the following measures:

• Relocate the receiving antenna.

• Increase the separation between equipment and receiver.

• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for
help.

FCC Radiation Exposure Statement:

This equipment complies with FCC radiation exposure limits set forth

for an uncontrolled environment. This equipment should be installed
and operated with a minimum distance of 20cm between the radiator
and your body. This transmitter must not be co-located or operated in
conjunction with any other antenna or transmitter.

Warning: Changes or modications made to this equipment not
expressly approved by Gibson Innovations may void the FCC
authorization to operate this equipment.

Model number: SRP3014
Trade Name: Philips

Responsible party: Gibson Innovations USA Inc.3070 Windward Plaza
Suite F, Box 735 Alpharetta, GA 30005

Notice for Canada:

This device complies with Industry Canada licence-exempt RSS

standard(s). Operation is subject to the following two conditions: (1)
this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation.

English

EN 9

This Class B digital apparatus complies with Canadian ICES-003.

IC Radiation Exposure Statement:

This equipment complies with Canada radiation exposure limits set

forth for uncontrolled environments.
This transmitter must not be co-located or operating in conjunction
with any other antenna or transmitter.

Disposal of your old product and batteries

Your product is designed and manufactured with high quality materials

and components, which can be recycled and reused.
Never dispose of your product with other household waste. Please
inform yourself about the local rules on the separate collection of
electrical and electronic products and batteries. The correct disposal of
these products helps prevent potentially negative consequences on the
environment and human health.

Your product contains batteries, which cannot be disposed of with

normal household waste.
Please inform yourself about the local rules on separate collection of
batteries. The correct disposal of batteries helps prevent potentially
negative consequences on the environment and human health.
Please visit www.recycle.philips.com for additional information on a
recycling center in your area.

Environmental information

All unnecessary packaging has been omitted. We have tried to make
the packaging easy to separate into three materials: cardboard (box),

polystyrene foam (buffer) and polyethylene (bags, protective foam
sheet.)

Your system consists of materials which can be recycled and reused
if disassembled by a specialized company. Please observe the local
regulations regarding the disposal of packaging materials, exhausted

batteries and old equipment.

10 EN

4 Service and support

Frequently asked questions

My universal remote does not work at all.

• Check if you have correctly setup the device with the right code.

• Check if you have pressed the corresponding device key for your
device.

• Check if the batteries are inserted properly. If the battery level is
low, replace the batteries.

• Check if your device is powered on.

If several device codes are listed under the brand of my device, how
can I select the correct device code?

To seek the correct device code, test the codes one by one. The codes

are sorted by popularity, and the most popular code is listed rst.

My device responds only to some of the commands.

You have set a code for which only some commands work properly

but some do not. Try other codes until most keys work properly.

Need help?

We advise you to rst read this user manual carefully. It helps you set

up and use the universal remote.

If, however, you require extra information or have additional questions

about setup, usage, warranty, etc of the SRP3014, you can always
contact us.
When calling our helpline, make sure to have the SRP3014 at hand
when you call, so that our operators can help you determine whether
SRP3014 is working properly.

You will nd our contact details at the end of this user manual.

For online support, visit www.philips.com/support

English

EN 11
