Page 1
Screeneo UL5 Smart
Ultra Short Throw Projector
User Manual
Register your product and get support at
www.philips.com/support
Page 2
Table of contents
Introduction ............................................... 3
Dear customer ............................................................ 3
About this user manual ............................................ 3
What’s in the box ....................................................... 3
Customer service centre ........................................... 3
1 General safety information ..............4
Setting up the product ............................................. 4
Repairs .......................................................................... 4
Power supply ............................................................... 5
2 Overview .............................................. 5
Front view .................................................................... 5
Side view....................................................................... 5
Top view........................................................................6
Bottom view ................................................................ 6
Remote control ........................................................... 6
3 Initial setup .......................................... 7
Place the projector ....................................................7
Connect to power supply ........................................ 8
Prepare the remote control ....................................8
Power on and set up the projector ....................... 8
4 Connect to playback devices ..........10
Connect to devices through HDMI™ ..................10
Connect to devices through USB-C .....................10
Connect to devices through HDMI™ ARC ........11
Connect to a dongle ...............................................11
5 Connect to external speakers or
headphones ........................................ 12
Bluetooth connection .............................................12
6 Media playback .................................13
Play videos from USB storage devices ................13
7 Change settings ................................14
8 Maintenance ......................................16
Cleaning .....................................................................16
Update firmware ......................................................16
9 Troubleshooting ...............................18
10 Appendixes ........................................20
Technical data ...........................................................20
CE statement .............................................................21
FCC statement ...........................................................21
Canada regulatory compliance ............................21
Other notice ..............................................................22
Page 3
Introduction
Dear customer
Thank you for purchasing this projector.
We hope you enjoy this product and the many
functions it oers!
About this user manual
The quick start guide supplied with this product
allows you to start using this product quickly and
easily. Detailed descriptions can be found in the
following sections of this user manual.
Read the entire user manual carefully. Follow
all safety instructions in order to ensure proper
operation of this product (see General safety
information, page 4). The manufacturer accepts
no liability if these instructions are not followed.
Symbols used
Notice
This symbol indicates tips that will help
you use this product more eectively
and easily.
DANGER!
Danger of personal injury!
This symbol gives warning of danger
of personal injury. Physical injury or
damage can result from improper
handling.
CAUTION!
Damage to the product or loss of
data!
This symbol gives warning of damage
to the product and possible loss of
data. Damage can result from improper
handling.
What’s in the box
a Screeneo UL5 Smart projector (SCN355/INT)
b Remote control with 2 AAA batteries
c Quick Start Guide with Warranty Card
d AC adapter
e AC power cables with plugs x 3
a
b c d
Quick Start
Guide
e
Customer service centre
The Support page, warranty card, and user
manuals can be found here:
Web: www.philips.com/support
Support Contacts:
International Phone: +41 215 391 665
Please ask your provider for international call
costs!
Mail: [email protected]
Access our FAQ websites:
https://support.philipsprojection.com
https://community.philipsprojection.com
3
Philips · Screeneo UL5 Smart
Page 4
1 General safety
information
Take note of all warning and safety notes
indicated. Do not make any changes or settings
that are not described in this user manual.
Incorrect operation, and improper handling can
lead to physical injury, damage to the product or
loss of data.
Setting up the product
This product is for indoor use only. Place the
product securely on a stable, at surface. To help
avoid possible injuries to persons or damage to
the product itself, position all cables in such a
way that no one will trip over them.
Do not operate the product in damp rooms.
Never touch the mains cable or the mains
connection with wet hands.
Never operate the product immediately after
moving it from a cold location to a hot location.
When the product is exposed to such a change
in temperature, moisture may condense on the
crucial internal parts.
The product must have sucient ventilation and
must not be covered. Do not put the product in
closed cabinets, boxes, or other enclosures when
in use.
Protect the product from direct sunlight, heat,
intense temperature uctuations and moisture.
Do not place the product in the vicinity of heaters
or air conditioners. Observe the information on
temperature listed in the technical data (see
Technical data, page 20).
Prolonged operation of the product causes the
surface to become hot. In case of overheating,
the product automatically switches to standby
mode.
Do not allow liquids to leak into the product.
Turn o the product and disconnect it from the
mains supply if liquids or foreign substances
leaked into the product. Have the product
inspected by an authorised service centre.
Always handle the product with care. Avoid
touching the lens. Never place heavy or sharp
objects on the product or on the power cable.
If the product gets too hot or emits smoke, shut it
down immediately and unplug the power cable.
Have your product checked by an authorised
service centre. Keep the product away from open
ames (e.g. candles).
The remote control is with batteries (type AAA).
DANGER!
Risk of explosion with incorrect type
of batteries!
There is a risk of explosion if the wrong
battery type is used.
Do not expose the batteries to excessive heat
such as sunshine, or open re. Do not expose the
batteries to low air pressure at high altitude.
Under the following conditions, a layer of
moisture can appear inside the product which
can lead to malfunctions:
• if the product is moved from a cold to a
warm area;
• after a cold room is heated;
• when the product is placed in a damp
room.
Proceed as follows to avoid any moisture buildup:
1 Seal the product in a plastic bag before
moving it to another room, in order for it to
adapt to room conditions.
2 Wait one to two hours before you take the
product out of the plastic bag.
The product should not be used in a very dusty
environment. Dust particles and other foreign
objects may damage the product.
Do not expose the product to extreme vibrations.
This may damage the internal components.
Do not allow children to handle the product
without supervision. The packing materials
should be kept out of the hands of children.
For your own safety, do not use the product
during thunderstorms with lightning.
Repairs
Do not repair the product yourself. Improper
maintenance can result in injuries or damage to
the product. The product must be repaired by an
authorised service centre.
Please nd the details of authorised service
centres on the warranty card supplied with this
product.
Do not remove the type label from this product,
as this will void the warranty.
4
Philips · Screeneo UL5 Smart
Page 5
Power supply
b
a
e f
Use only a power adapter which is certied
for this product (see Technical data, page 20).
Check whether the mains voltage of the power
supply matches the mains voltage available at the
setup location. This product complies with the
voltage type specied on the product.
The power outlet shall be installed near the
product and shall be easily accessible.
CAUTION!
Always use the button to turn the
projector o.
Turn o the product and unplug from the power
outlet before cleaning the surface (see Cleaning,
page 16). Use a soft, lint-free cloth. Never use
liquid, gaseous or easily ammable cleaners
(sprays, abrasives, polishes, alcohol). Do not allow
any moisture to reach the interior of the product.
DANGER!
Risk of eye irritation!
This product is equipped with a high
power RGB laser, which emits very
bright light. Do not look directly into
the projector lens during operation.
This could cause eye irritation or
damage.
2 Overview
Front view
a
• Switch the projector on or to standby
mode.
• When the projector is on, the LED lights
up in white.
• When the projector is in standby mode,
the LED lights up in red.
b IR sensor
Side view
c
d
c USB-C
Connect to the AC adapter.
d USB-C
Connect to a USB-C port on a playback
device.
e HDMI
Connect to an HDMI™ output port on a
playback device.
5
f USB-A
Connect to a USB storage device/dongle.
Philips · Screeneo UL5 Smart
Page 6
Top view
a
a
116.75 89.25
Remote control
a Projection lens
b Autofocus sensor
Bottom view
a Tripod socket
Screw size: M6 (max. length = 20 mm; min.
length = 15 mm)
b
47.00 47.00
j
a
b
c
d
e
k
f
g
l
m
a
Switch to a dierent input source.
b
Adjust the focus automatically or manually.
c OK
Conrm a selection on the screen.
d Navigation buttons (Up, Down, Left, Right)
h
i
• Navigate items on the screen.
• Press / to change the value for the
current setting.
e
Access the home screen.
f
Access the projector's settings menu.
/
g
Increase or decrease the volume.
h
Launch the mouse function. Press OK to
click. Press any navigation button will stop
the Mouse or press again the mouse key
will make it disappear. --> Press the mouse
6
Philips · Screeneo UL5 Smart
Page 7
key will freeze the cursor. Press it again to
unfreeze the cursor.
i
Toggle between dierent picture presets.
j
Switch the projector on or to standby.
k
• Return to the previous screen or exit the
current screen.
• Open the sidebar when home screen
displays.
l
Mute the speakers.
m
Toggle between dierent brightness modes.
3 Initial setup
Notice
Make sure all devices are disconnected
from their power supplies before
establishing or changing any
connections.
Place the projector
1 Place the projector on a at surface such as
a table in front of the projection surface.
This is the most common way to position the
projector for quick setup and portability.
2 If the projection direction is incorrect, press
on the remote control to access the
projector's settings menu and select Projector
> Installation > Front Table.
Source
Sound
Projector
System
Support
Location
lnstallation
4-Corner Keystone
Vertical Keystone
Digital Zoom
Autofocus on startup
Front Table
Rear
Front Ceiling
Rear Ceiling
7
Philips · Screeneo UL5 Smart
Page 8
Connect to power supply
CAUTION!
Always use the button to turn the
projector on and o.
1 Select a supplied power cable with the
correct plug (EU/UK/US).
2 Connect the power cable to the AC adapter.
3 Connect the AC adapter to the USB-C port on
the projector.
4 Connect the power cable to an electrical
socket.
• The power LED on the projector lights up
in red.
c
d
ab
Prepare the remote control
CAUTION!
The improper use of batteries can
lead to overheating, explosion, risk of
re and injury. Leaking batteries can
possibly damage the remote control.
Never expose the remote control to
direct sunlight.
Avoid deforming, dismantling or
charging the batteries.
Avoid exposure to open re and water.
Replace empty batteries immediately.
Remove the batteries from the remote
control if not in use for long periods of
time.
Dispose of the used batteries according
to the manufacturer's instructions and
local environment regulations for your
region.
1 Open the battery compartment.
2 Insert the supplied batteries (type AAA) with
correct polarity (+/-) indicated.
3 Close the battery compartment.
• When using a remote control with infrared
signals, point the remote control at the IR
sensor on the projector, and make sure there
is no obstacle between the remote control
and the IR sensor.
Power on and set up the
projector
Power on/off the projector
• To turn on the projector, press and hold
on the projector for 2 seconds or press on
the remote control. The power LED on the
projector turns from red to white.
• To turn o the projector, press and hold on
the projector/remote control for 2 seconds or
press this button twice. The projector enters
standby mode and its power LED turns from
white to red.
• To fully shut down the projector, disconnect
the power cable from the electrical socket.
Set up the projector system
When you turn on the projector for the rst time
or after it was reset to its factory default settings,
the projector system will start and prompt you to
set it up by making some basic settings.
After the setup, you can start using the projector
or continue to make other adjustments.
Step 1: Select the display language
Press the down or up navigation button on the
remote control to select your preferred display
language and press the OK button to conrm.
Note: The default display language is English
and not all languages are available.
8
Philips · Screeneo UL5 Smart
Page 9
Step 2: Set the date and time
Press the down or up navigation button on the
remote control to set the values for the date and
time. Press the right or left navigation button to
move to the next or previous value.
Step 3: Pair the remote control
Follow the on-screen instructions to pair the
remote control with the projector.
Step 4: Set up Wi-Fi
Connect the projector to your Wi-Fi network to
enjoy online content, or to use screen mirroring.
Press the button on the remote control from
the home screen.
When you see the main menu, select "WiFi" and
select the available network you want to connect.
You will see the home screen shown below after
completing the setup.
Screen size adjustment
The projection screen size (or size of images) is
determined by the distance between the lens of
the projector and the projection surface.
This projector has a projection distance of 17.1
mm to 216.1 mm, and thus creates a screen size
of 40" to 80".
Digital zooming
You can use the digital zooming function to
reduce the screen size by up to 50%.
1 Press on the remote control to access the
settings menu, go to Projector > Digital Zoom
and press the OK button.
2 Press / to adjust the screen size. The
changes take eect immediately.
Source
Sound
Projector
System
Support
Location
lnstallation
4-Corner Keystone
Vertical Keystone
Digital Zoom
Autofocus on startup
Digital Zoom
Image focus adjustment
You can let the projector automatically adjust the
image focus for you or adjust it manually.
• To automatically adjust the image focus,
press on the remote control. The projector
automatically adjusts the image focus for rst
time usage.
• To manually adjust the image focus, press
or on the remote control.
Image shape adjustment
You can adjust the image shape manually.
To manually adjust the image shape:
1 Press on the remote control to access the
settings menu, go to 4-Corner Keystone and
press the OK button.
2 Follow the on-screen instructions to adjust
the image shape.
Or, you can also do the following:
1 Press on the remote control to access the
settings menu, go to Vertical Keystone and
press the OK button.
2 Select Manual from the list of options.
3 Follow the on-screen instructions to adjust
the image shape.
9
Philips · Screeneo UL5 Smart
Page 10
4 Connect to
Side
Side
playback devices
Notice
Make sure all devices are disconnected
from their power supplies before
establishing or changing any
connections.
Connect to devices through
HDMI™
You can connect a playback device (e.g. a Bluray player, gaming console, camcorder, digital
camera or PC) to the projector through HDMI™
connection. With this connection, images are
shown on the projection screen, and audio is
played on the projector.
1 Using an HDMI™ cable, connect the HDMI
port on the projector to an HDMI™ output
port on a playback device.
Side
Connect to devices through
USB-C
You can connect a playback device (e.g. a smart
device or PC) to the projector through USB-C
connection. With this connection, images are
shown on the projection screen, and audio is
played on the projector.
1 Using an USB-C cable, connect the USB-C port
on the projector to an USB-C output port on
a playback device.
Side
Phones
Phones
Tablets
Tablets
Computers
Computers
Phones
Phones
Tablets
Tablets
Computers
Computers
Smart Sticks
Smart Sticks
Game consoles
Game consoles
DVD/VCR
DVD/VCR
2 If the projector does not automatically switch
to the correct input source, press on the
remote control to switch the input source to
HDMI.
10
2 If the projector does not automatically switch
to the correct input source, press on the
remote control to switch the input source to
USB C.
Philips · Screeneo UL5 Smart
Page 11
Connect to devices through
HDMI™ ARC
The HDMI port on the projector supports
Audio Return Channel (ARC). You can connect
a compatible audio system (e.g. a home cinema
system, AV receiver or sound bar) to the projector
through HDMI™ ARC connection. With this
connection, audio is streamed to the connected
audio system.
Tip: To get 5.1 surround sound, you typically need
to connect the projector to a 5.1 home cinema
system.
1 Using an HDMI™ cable, connect the HDMI
port on the projector to the HDMI™ ARC port
on a compatible audio system.
• The HDMI™ ARC port on your audio
system might be labeled dierently. See
the documentation supplied with the
device for more information.
2 If the projector does not automatically switch
to the correct input source, press on the
remote control to switch the input source to
HDMI.
3 To activate the HDMI™ ARC function on the
projector, press on the remote control
to access the settings menu, go to Audio
Output, press the OK button and select ARC
from the list of options.
Source
Sound
Projector
System
Support
Sound Mode
Output
Volume
Reset Settings
lnternal Speaker
ARC
Bluetooth Output
Connect to a dongle
You can connect a dongle (e.g. Amazon Fire Stick,
Roku Stick or Chromecast) to the projector to
easily watch videos over the internet. With this
connection, images are shown on the projection
screen, and audio is played on the projector.
1 Connect a dongle to the projector's HDMI
port using an HDMI™ cable.
2 Connect the dongle to the projector's USB-A
port using a USB cable.
External Dongle (5V/2A)
(not included)
3 If the projector does not automatically switch
to the correct input source, press on the
remote control to switch the input source to
HDMI.
11
Philips · Screeneo UL5 Smart
Page 12
5 Connect to
external speakers
or headphones
You can connect external speakers or
headphones to the projector. With this
connection, audio from the projector is played
through the external speakers or headphones.
• The internal speakers of the projector are
deactivated automatically when external
speakers or headphones are connected
to the projector.
DANGER!
Danger of hearing damage!
Before connecting the headphones,
turn down the volume on the projector.
Do not use the projector over a longer
time at high volume – especially when
using headphones. This could lead to
hearing damage.
Bluetooth connection
The projector is equipped with Bluetooth
technology, allowing you to connect to
headphones or external speakers.
Before you can use the projector with Bluetooth
speakers or headphones for the rst time, you
must pair the projector with them. The projector
will automatically connect to a device as soon as
they are paired.
Notice
Be sure that the Bluetooth device is
no farther than 10 m (33 ft) from the
projector when connecting the two.
Even when connecting within the
specied communication distance,
connections can be lost due to the
signal status.
1 Make sure the projector is on.
2 Turn on your Bluetooth speaker or
headphones and make sure it is in pairing
mode. Press the pairing button on the device,
if needed. See the documentation supplied
with the device for more information.
3 Press the button on the remote control to
pair the projector with the device.
• Once you press this button, the projector
enters pairing mode and displays
"Searching" on the screen. Also, its power
LED blinks in light blue.
• When the pairing is complete, the
projector briey displays "Paired
successfully" on the screen, as well as the
name of the paired device. Also, its power
LED turns solid light blue.
• If no pairing is created, the projector
will automatically exit pairing mode in
10 seconds.
Tips:
• The projector will automatically switch its
audio output to Bluetooth output after
connecting to a Bluetooth device.
• After connecting a Bluetooth device, press
/ on the remote control to adjust the
volume to the desired level.
Disconnect a Bluetooth device
Use one of the following methods to disconnect
a Bluetooth device from the projector but leave
it paired.
The projector automatically switches its audio
output to internal speaker when no Bluetooth
device is connected.
• Terminate the Bluetooth connection from the
Bluetooth device, or turn o the Bluetooth
device. The projector will briey display
"Disconnected" on the screen.
• Turn o the projector.
Reconnect a Bluetooth device
Once you pair and connect a Bluetooth device to
the projector using the steps above, the projector
will automatically reconnect unless the Bluetooth
device gets unpaired or turned o. The projector
briey displays "Paired successfully" on the screen
after a reconnection.
Unpair a Bluetooth device
This will remove the Bluetooth device from the
projector's memory. You'll need to pair and
connect this device to use it again.
To unpair a Bluetooth device connected to the
projector, select it from the list of paired devices
and then press the OK button.
To unpair a Bluetooth device not connected to
the projector, select it from the list of paired
devices and then press the OK button twice.
12
Philips · Screeneo UL5 Smart
Page 13
6 Media playback
The projector has an integrated VLC. Using this
media player, you can access and play video
and audio les stored in the projector's internal
memory or a USB storage device.
Notice
The projector supports a USB storage
device that is formatted for FAT16 or
FAT32 le system.
Supported media le formats
Most video and audio formats are supported,
including MKV, MP4, AVI, MOV, Ogg, FLAC, TS,
M2TS, WAV, AAC and MP3.
How to navigate the user interface of the
media player
• Use only the remote control.
• Press the navigation buttons (Up, Down, Left,
Right) to move between items on the screen.
• Press the OK button to conrm or open the
selected item.
• Press to return to the previous screen or
exit the current screen.
4 Select a media le. Note: Only supported
media les are displayed on the screen. All
folders and les are ordered alphabetically
by name.
5 Press the OK button to start playing the
selected media le.
6 During the playback, press the OK button to
pause the playback and bring up the control
bar at the bottom of the screen. Press the
OK button again to resume the playback
and hide the control bar. Press / to go
10 seconds backward or forward. To adjust
the volume, press / .
During the playback, you can press to
temporarily bring up the control bar at the
bottom of the screen. You can also press to
bring up the more options menu on the right
of the screen. To instantly hide the control
bar or the more option menu, press .
Play videos from USB
storage devices
1 Connect a USB storage device to the USB-A
port on the projector.
2 Go to the projector's home screen by pressing
on the remote control and then select File
manager.
3 Select Browsing from the left navigation
pane, and then select and open the folder for
the USB storage device, which is to the right
of the Internal memory folder.
13
While the control bar is visible, press the
navigation buttons to select an option and
then press the OK button to conrm the
option or change the value. To close the
dialog box of an option, press .
7 To stop the playback and return to the list of
les in the current folder, press .
Philips · Screeneo UL5 Smart
Page 14
7 Change settings
1 Press on the remote control to access the
projector's settings menu.
2 Use the navigation buttons and the OK
button to select a menu item.
3 Press / or / to select a value for the
menu item.
4 Press the OK button to make the change.
Note: For some menu items such as Digital
Zoom, the change takes eect once you
select a dierent value.
5 Press one or more times to exit the
projector's settings menu.
• EasyLink (CEC): Turn HDMI™ CEC (Consumer
Electronics Control) on or o. The default
value is Enable.
Picture settings
You can view and change the following picture
settings.
Source
Sound
Projector
System
Brightness Mode
Picture Mode
Color Temperacue
HDR Brightness
Brightness
Source settings
You can view and change the following source
settings.
Source
Sound
Projector
System
Support
lnput Source
3D Mode
EasyLink (CEC)
• Input Source: Select the projector's input
source.
• Philips OS: Select this to use the Philips
OS. This is the default value.
• HDMI: Select this when your device is
connected to the projector's HDMI port.
• USB C: Select this when your device is
connected to the projector's USB C port.
• 3D Mode: Select the input signal's 3D format
when the input source is HDMI or USB C.
• O: Select this when the input signal is of
2D format. This is the default value.
• Side-by-Side: Select this when the 3D
input signal is of the side by side format.
• Top/Bottom: Select this when the 3D
input signal is of the top/bottom format.
• L/R Inverted: If you have problems with
the left and right eye reversed when
using 3D glasses, please adjust L/R
Inverted from default OFF to ON.
Support
Contrast
• Brightness Mode: Set the brightness mode to
Normal or Bright. Tip: You can more quickly
change the brightness mode by pressing
on the remote control.
• Picture Mode: Select a predened color
brightness setting for picture and video
display, or select User to customize color
values on brightness, contrast, saturation,
hue and sharpness. Tip: You can more
quickly change the picture preset by pressing
on the remote control.
• Color Temperature: Select Warm to enhance
warm colors such as red; select Cool to make
picture bluish; select Standard for a moderate
color temperature; select User to customize
values on red, green and blue.
• HDR Brightness: Set the brightness for high
dynamic range (HDR).
• Brightness: Adjust the display brightness.
• Contrast: Adjust the display contrast.
• Saturation: Adjust the video saturation of
selected primary color.
• Hue: Adjust the video hue of selected primary
color.
• Sharpness: Select dierent sharpness level.
• Color Calibration: Adjust the gain of selected
primary color.
• Reset Settings: Reset the Picture settings to
default.
14
Philips · Screeneo UL5 Smart
Page 15
Sound settings
You can view and change the following sound
settings.
Source
Sound
Projector
System
Support
Sound Mode
Audio Output
Volume
Reset Settings
• Sound Mode: Select a predened sound
eect, or select User to customize values on
Bass and Treble.
• Audio Output: Select the projector's audio
output type.
• Internal Speaker: Use the projector's
internal speaker to output audio.
• ARC: Use an HDMI™ ARC compatible
device to output audio.
• Bluetooth Output: Use the Bluetooth
devices paired with the projector to
output audio.
• Reset Settings: Reset the Sound settings to
default.
• 4-Corner Keystone: Adjust projector corner
keystone.
• Vertical Keystone: Manually correct the
vertically keystone by adjusting the corners of
the screen.
• Digital Zoom: Scale down the projection
image by up to 50%. The default value is
100% (no scale-down).
• Autofocus on startup: Turn this on to let the
projector automatically adjust the focus on
startup. The default values is Yes.
• Reset Settings: Reset the Projector settings to
default.
System settings
You can view and change the following system
settings.
Source
Sound
Projector
System
Support
Language
Sleep Timer
LED Indicator
About
Menu Position
Factory Reset
Projector settings
You can view and change the following projector
settings.
Source
Sound
Projector
System
Support
Location
lnstallation
4-Corner Keystone
Vertical Keystone
Digital Zoom
Autofocus on startup
• Location: Select dierent projector installed
location. Each option reserves the individual
setting for the following items: Installation,
4-Corner Keystone, Vertical Keystone, Digital
Zoom, Autofocus on startup.
• Installation: Adjust the projection to the
correct direction based on how the projector
is installed.
15
• Language: Select the display language for the
projector.
• Sleep Timer: Select a period of time after
which the projector turns o automatically.
The default value is Disable.
• About:
• Hardware Version: Check hardware
version of this product.
• Software Version: Check rmware version
of this product.
• Serial Number: Check serial number of
this product.
• MAC Address: Check MAC address of this
product.
• Laser hours: Check Laser hours of this
product.
• Menu Position: Set the settings menu's
position to Center, Top Left, Top, Top Right,
Right, Bottom Right, Bottom, Bottom Left or
Left.
• Factory Reset: Restore the product to its
factory default settings. After the factory
reset, the projector will restart and allow you
to set it up as new.
Philips · Screeneo UL5 Smart
Page 16
Support
Source
Sound
Projector
System
Support
Get In Touch
m.me/philipsprojection
youtube.com/philipsprojection
8 Maintenance
Cleaning
DANGER!
Follow the following instructions
when cleaning the projector:
Use a soft, lint-free cloth. Never use
liquid or easily ammable cleansers
(sprays, abrasives, polishes, alcohol,
etc.). Do not allow any moisture to
reach the interior of the projector.
Do not spray the projector with any
cleaning uids.
Wipe over the surfaces gently. Be
careful that you do not scratch the
surfaces.
Cleaning the lens
Use a dry cloth for cleaning the lens of the
projector.
DANGER!
Do not use any liquid cleaning agents!
Do not use any liquid cleaning
agents for cleaning the lens, to avoid
damaging the coating lm on the lens.
16
Update firmware
The latest rmware for the projector can be
found on www.philips.com/support for you
to get the best features and support from the
projector.
Before you update the rmware of the projector,
check the current software version:
• Press on the remote control and go to
About.
Source
Sound
Projector
System
Support
Language
Sleep Timer
LED Indicator
About
Menu Position
Factory Reset
Philips · Screeneo UL5 Smart
Philips and the Philips Shield
Emblem are registered trademarks
of Koninklijke Philips N.V. and are
used under license.
Hardware Version: 1.0.0
Firmware Version: 1.0.6
Serial Number: RY2208N320A00001
MAC Address: A8:77:E5:D2:4D:35
Laser hours: 50
Page 17
CAUTION!
Do not turn o the projector or remove
the USB ash drive during a software
update.
OTA firmware update
1 Visit www.philips.com/support, nd your
product (model number: SCN355/INT), open
its support page and locate "Software &
drivers".
2 Download the update package and unzip it
if necessary. You should get an update le
named "SCN355INT_rmware.zip". Copy
this le to the root directory of a USB ash
drive. Note: Do not unzip this le.
3 Turn on the projector if it is o.
4 Connect the USB ash drive to the projector.
5 Press on the remote control to access the
settings menu, go to Firmware Upgrade and
press the OK button. The projector will search
for the update le. If it nds the le, you will
see the Start Update dialog box.
6 Press any of the navigation buttons on the
remote control to select the UPDATE button
and press the OK button.
7 Wait for the update to complete. The
projector will restart after the update.
17
Philips · Screeneo UL5 Smart
Page 18
9 Troubleshooting
Power cycling
If a problem occurs and you cannot resolve it using the instructions in this user manual, try the
following steps to resolve the problem.
1 Turn the projector o by pressing twice.
2 Wait at least 10 seconds.
3 Turn the projector on by pressing and holding for 2 seconds.
4 If the problem persists, contact one of our customer service centres or your dealer.
Problem Solution
The projector cannot be turned on. • Disconnect and reconnect the power cable, and try
The projector cannot be turned o.
No image from the external HDMI™ device. 1. Check if the correct HDMI™ input is selected
No sound from the external connected
device.
No sound from external HDMI™ output
device.
No sound when you connect your computer
using an HDMI™ cable.
Only the home menu appears and not the
image from the external device.
Only the home menu appears and not the
image from the connected computer.
The projector turns itself o. • When the projector is running for a long period of
The projector cannot read the USB storage
device.
to turn the projector on again.
• Press and hold longer than ten seconds. If this
does not work, disconnect the power cable.
(HDMI).
2. Disconnect the HDMI™ cable or switch o the
HDMI™ device.
3. Wait three seconds.
4. Reconnect the HDMI™ cable or switch on the
HDMI™ device again.
• Check the cables to the external device.
• Check that the sound is activated on the external
device.
• Only the original cables from the device
manufacturer may function.
• On the HDMI™ output device, set the audio setting
to Multichannel (Raw data) & Stereo (PCM).
• Check that the sound is activated on the computer.
• Check if the cables are connected to the correct
sockets.
• Check that the external device is turned on.
• Check if the video output of the external device is
turned on.
• Check that the HDMI™ output of the computer is
turned on.
• Check if the resolution of the computer is set to
1920*1080.
time, the surface becomes hot.
• Check that the power cable is connected correctly.
• The projector does not support the exFAT le
system.
• Format the USB storage device in FAT32 or NTFS
format, then use it.
18
Philips · Screeneo UL5 Smart
Page 19
Problem Solution
The projector does not react to remote
control commands.
The temperature of the projector’s surface
is warm.
The projector does not work after I connect
it to a laptop.
• Check the batteries of the remote control.
• For this projector it is normal to generate moderate
heat during operation.
• Check that the HDMI™ cable is plugged in
correctly.
• Make sure that the laptop has been switched to
projector display.
I cannot pair the projector with a Bluetooth
device.
• Turn on the Bluetooth device and make sure it is in
pairing mode.
• Position the Bluetooth device so that it is less than
10 m (33 ft) from the projector.
• To connect Bluetooth speakers/headphones to the
projector, make sure the projector is on.
• To connect a Bluetooth playback device to the
projector, make sure the projector is o (in standby
mode).
• If another Bluetooth device is already connected to
the projector, disconnect it.
• Move the projector farther away from other
devices (microwave oven, wireless router, etc.) that
are emitting radio frequency signals.
After a Bluetooth device is connected,
there is no sound from the projector or the
Bluetooth device.
• Check if the Bluetooth device’s volume is at the
minimum.
• Check if projector's volume is at the minimum.
• Check if the playback has started.
• Try playing another video/audio le.
• Try reconnecting the two devices.
Black dots (dead pixels) appear on the
screen.
Auto focus does not work Wipe the projection lens clean with a dry cloth before
DMD displays from Texas Instruments typically contain
a small number of pixels that do not function normally.
Your display has been inspected and is in compliance
with the manufacturer's specications, meaning that
any pixel defects will not aect the operation or use
of your display. Without prejudice to generality of the
foregoing, a display with no more than 7 dead pixels
meets the factory specications and is not considered a
defect under this warranty.
turning on the projector.
19
Philips · Screeneo UL5 Smart
Page 20
10 Appendixes
Integrated Media Player
Thousands of codecs supported via VLC built-in
players
Technical data
Technology/optical
Display technology ..............................................TI DLP
Light source .....................................................RGB laser
Colorimetry & metadata ................................REC.709
Resolution ......................................1920 × 1080 pixels
RGB laser lifetime .......................... over 30,000 hours
Contrast ratio ...................................................... 1800:1
Aspect ratio .............................................................. 16:9
Throw ratio ............................................................0.23:1
Screen size (diagonal) ..................................40" - 120"
Screen distance .. 17.1 mm - 216.1 mm/0.67" - 8.5"
Lens protection ............................................................no
Projection modes .......................................................... 4
Focus adjustment ...............................auto or manual
Keystone correction .........................................manual
TOF ................. yes for manual 4 corners adjustment
4 corner correction ....................................................yes
Digital zoom .......................................... yes (50-100%)
Integrated media player ..........................................yes
Sound
Built-in speakers ................................................ 2 x 3 W
Surround mode ...........................................................no
Equalization ................................................................yes
Dimensions and weight
Unpacked (W x D x H) ............... 94 x 86.6 x 206 mm
(excluding footpad)
Packed (W x D x H) ....................152 x 323 x 171 mm
Weight ...................................................1.05 kg/2.31 lb
Temperature requirements
Operating temperature ............................0 °C - 40 °C
Storage temperature .............................-20 °C - 60 °C
Package contents
1. Screeneo UL5 Smart projector
2. Remote control
3. AC adapter
4. Power cables (EU, UK, US)
5. AAA batteries for remote control
6. Quick Start Guide with Warranty Card
Model
SCN355/INT
EAN INT: 7640186960311
EAN APAC: 7640186960328
UPC: 667619992883
Connection
HDMI™ in ..................................................................... x 1
USB-A (5V/2A out + external drive) ...................... x 1
USB-C ............................... x2 (1 for power; 1 for data)
Bluetooth ...................................... Dual Bluetooth 5.0
Power source
Power consumption .........................operating: 35 W
................................................................standby: 0.25 W
AC adapter .........................................................................
............... Input: AC 100 -240V, 50/60Hz, 1.5A (Max)
........................................ Output: DC 20.0V, 5A, 100W
20
Philips · Screeneo UL5 Smart
Page 21
CE statement
• The product shall only be connected to a USB
interface of version USB 2.0 or higher.
• Adapter shall be installed near the
equipment and shall be easily accessible.
• The operating temperature of the EUT can’t
exceed 35°C and shouldn’t be lower than 5°C.
• The plug is considered as disconnect device
of adapter.
• The UNII Band 5150-5250 MHz is for indoor
use only.
• The device complies with RF specifications
when the device is used at 20 cm from your
body.
Hereby, Screeneo Innovation SA declares that
this product is in compliance with essential
requirements and other relevant provisions of
Directive 2014/53/EU.
The Declaration of Compliance can be consulted
on the site www.philips.com.
Frequency bands Maximum output
power
BT EDR (EIRP) 9.09 dBm
BT BLE (EIRP) 4.85 dBm
Wi-Fi 2.4GHz (EIRP) 17.88 dBm
Wi-Fi 5GHZ (EIRP) 17.89 dBm
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses
and can radiate radio frequency energy and, if
not installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment o and on, the user is encouraged
to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/
TV technician for help.
During operation, the separation distance
between the user and the antenna shall be at
least 20 cm. This separation distance will ensure
that there is sucient distance from a properly
installed externally-mounted antenna to satisfy
the RF exposure requirements.
FCC ID: 2ASRT-SCN355
FCC statement
15.19 Labeling requirements.
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
15.21 Information to the user.
Any changes or modifications not expressly
approved by the party responsible for compliance
could void the user’s authority to operate the
equipment.
15.105 Information to user.
This equipment has been tested and found to
comply with the limits for a Class B digital device,
21
Canada regulatory
compliance
This device complies with Industry Canada CAN
ICES-3 (B)/NMB-3(B)
RSS-Gen & RSS-247 statement: This device
complies with Industry Canada RSS standard(s).
Operation is subject to the following two
conditions:
1 This device may not cause interference, and
2 This device must accept any interference,
including interference that may cause
undesired operation of the device.
RF Radiation Exposure statement: The device
meets the exemption from the routine evaluation
limits in section 2.5 of RSS102 and users can
obtain Canadian information on RF exposure and
compliance.
Philips · Screeneo UL5 Smart
Page 22
This device should be installed and operated
with a minimum distance of 7.8 inches
(20 centimetres) between the device and your
body.
Other notice
Preservation of the environment as part of a
sustainable development plan is an essential
concern of Screeneo Innovation SA. The desire
of Screeneo Innovation SA is to operate systems
respecting the environment and consequently
it has decided to integrate environmental
performances in the life cycle of these products,
from manufacturing to commissioning use and
elimination.
Batteries: If your product contains batteries, they
must be disposed of at an appropriate collection
point.
Product: The crossed-out waste bin symbol on
the product means that the product belongs to
the family of electrical and electronic equipment.
In this respect, the European regulations ask you
to dispose of it selectively:
• At sales points in the event of the
purchase of similar equipment.
• At the collection points made available
to you locally (drop-o centre, selective
collection, etc.).
In this way you can participate in the reuse and
upgrading of Electrical and Electronic Equipment
Waste, which can have an eect on the
environment and human health.
The paper and cardboard packaging used can be
disposed of as recyclable paper. Have the plastic
wrapping recycled or dispose of it in the nonrecyclable waste, depending on the requirements
in your country.
Trademarks: The mentioned references in
this manual are trademarks of the respective
companies. The lack of the trademarks ® and
™ does not justify the assumption that these
dedicated terminologies are free trademarks.
Other product names used herein are for
identication purposes only and may be
trademarks of their respective owners. Screeneo
Innovation SA disclaims any and all rights in
those marks.
Neither Screeneo Innovation SA nor its aliates
shall be liable to the purchaser of this product
or third parties for damages, losses, costs, or
expenses incurred by the purchaser or third
parties as a result of accident, misuse, or abuse
of this product or unauthorised modications,
repairs, or alterations to this product, or failure
to strictly comply with Screeneo Innovation SA
operating and maintenance instructions.
Screeneo Innovation SA shall not be liable for any
damages or problems arising from the use of any
options or any consumable materials other than
those designated as original Screeneo Innovation
SA/PHILIPS products or Screeneo Innovation SA/
PHILIPS approved products.
Screeneo Innovation SA shall not be held liable
for any damage resulting from electromagnetic
interference that occurs from the use of any
interface cables other than those designated as
Screeneo Innovation SA/PHILIPS products.
All rights reserved. No part of this publication
may be reproduced, stored in a retrieval
system or transmitted in any form or by any
means, electronic, mechanical, photocopying,
recording, or otherwise, without the prior written
permission of Screeneo Innovation SA. The
information contained herein is designed only for
use with this product. Screeneo Innovation SA is
not responsible for any use of this information as
applied to other devices.
This user manual is a document that does not
represent a contract.
Errors, printing errors and changes are reserved.
The terms HDMI, HDMI High-Denition
Multimedia Interface, HDMI Trade Dress and
the HDMI Logos are trademarks or registered
trademarks of HDMI Licensing Administrator, Inc.
This product complies with IEC 60825-1:2014
Class 1 Laser Product.
22
Philips · Screeneo UL5 Smart
Page 23
As with any bright light
source, do not stare
into the beam, RG2 IEC
62471-5:2015.
• This product complies with EN60825-
1:2014+A11:2021.
• This product complies with EN50689:2021.
• This product is designed to project images on
a wall or screen.
CAUTION
• Do not look into the lens while in use.
• Use of controls or adjustments or
performance of procedures other than those
specied herein may result in hazardous
radiation exposure.
• The use of optical instruments with this
product will increase eye hazard.
• Never allow children to stare into the
projector beam at any distance from the
projector.
• Do not turn on the projector with the remote
commander while in front of the projection
lens.
• Avoid the use of optical aids such as
binoculars or telescopes inside the beam.
FCC ID: 2ASRT-SCN355
Manufactured: January 2024
QAYYMMS355AXXXXX
QAYYMMS355AXXXXX
Rev.: XX-XXX
Rating label
Laser label
23
Philips · Screeneo UL5 Smart
Page 24
Screeneo Innovation SA
Route de Lully 5c - 1131 Tolochenaz - Switzerland
Philips and the Philips Shield Emblem are registered trademarks of Koninklijke Philips N.V. and are
used under license. Screeneo Innovation SA is the warrantor in relation to the product with which this
booklet was packaged.
Screeneo UL5 Smart
2024 © Screeneo Innovation SA. All rights reserved.
EN
Loading...
