Philips SCM4480-27 User Manual

Register your product and get support at

www.philips.com/welcome

EN universal USB charger 4

FR chargeur USB universel 7

ES cargador USB universal 10

SCM4480/27

SCM4480_27 05-03-2008 15:44 Pagina 1

SCM4480_27 05-03-2008 15:44 Pagina 2

2

1

3

A

B

SCM4480_27 05-03-2008 15:44 Pagina 3

4

ENGLISH

1 Your universal USB charger

Congratulations on your purchase and welcome to Philips!

This universal USB charger provides instant power to most
devices with a service voltage of 5V DC (mobile
telephones, MP3 players, etc.).

Carefully read and save this user manual for it contains
important safety and operating instructions for this
USB charger. Before using the USB charger read all
instructions and cautionary markings on the USB charger
itself and the device to be charged.

To fully benefit from the support that Philips offers,
register your product at:www.philips.com/welcome

NNoottee::
For several portable devices (5V), a USB cable is
supplied with the original device (e.g. most MP3
players). In this case, you can also use this cable to
charge your device.

2 What’s in the box?

– universal USB charger
– connector tips for 5V DC devices (mobile telephones,

MP3 players, etc.)
– retractable USB cable
– connector tip holder
– travel bag
– user manual
– compatibility sheet

3 Important safety instructions

• Read and observe all warnings on the USB charger and
in this user manual.

• Power consumption of the connected device must not
exceed 5.4V, 350 mA.

• Never use the USB charger in moist places or close to
water.

• Do not expose the USB charger to rain or excessive
moisture.

• Do not place inflammable, explosive or hazardous
objects near the USB charger.

• Only use the supplied USB cable and connector tips.
Use of other types of cords and tips may damage the
USB charger and/or your device.

• Only use the USB charger in an environment with the
proper temperature (-10ºC - 40ºC).

• Keep the USB charger away from children.

• Do not disassemble or try to repair the USB charger
yourself.You might get injured or the USB charger may
be damaged.

• Store the USB charger in a dry place with the proper
ambient temperature (-10ºC - 45ºC).

• Do not operate the USB charger if it has been subjected
to shock or damage.

• To avoid risk of electric shock, unplug the USB charger
from the AC power supply and disconnect devices
before cleaning or when not in use.

• Allow a sufficient amount of free space all around the
USB charger for adequate ventilation.

• This power unit is intended to be correctly orientated in
a vertical or floor mount position.

• Do not throw or shake the USB charger.

• This appliance is not intended for use by persons
(including children) with reduced physical,sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.

• Children should be supervised to ensure that they do
not play with the appliance.

• Do not recharge non-rechargeable batteries.

SCM4480_27 05-03-2008 15:44 Pagina 4

5

ENGLISH

4 Functional overview (fig. A)

PPHH IILL II PP SS

• Lights up when a 5V device is charging (when no
device is connected, the PHILIPS logo will flash).

• Flashes when the device is fully charged.

FFoollddaabbllee ppoowweerr pplluugg
Connects to the wall outlet.

UU SSBB ppoorrtt
Connects to 5V DC devices (mobile telephones,
MP3 players, etc.).

5 Operation

CC hhaa rrggiinngg ddeevviicceess -- pprreeppaarraattiioonn

Check the maximum input voltage (V DC) of the
device you wish to connect. For this see the user
manual that came with the device.
Make sure the device does not consume more current
(mA) than 350 mA.
Check what connector tip is required for your device.
See the compatibility sheet for the proper tip for your
device.

CC hhaa rrggiinngg 55VV ddeevviicceess

(fig. B)
Insert the plug of the USB cable into the USB port (3).
Connect the connector tip to the USB cable.
Insert the connector tip into the power supply jack of
the device.
>

PPHH IILL II PP SS

lights up when a device is charging.

>

PPHH IILL II PP SS

will flash when the device is fully charged.
Disconnect the device from the USB charger.
Disconnect all cables from the device and from the
USB charger.

6 Technical specifications

• Rated input: 100V - 240V AC (50/60Hz), 0.2A

• Rated output: 5.4V, 350 mA

• Operating temperature: -10ºC - 40ºC

• Size: 70.3 x 55.5 x 35.5 mm (h x w x d)

• Weight: 70 g

• Maximum battery capacity for charging is 1,200mAh,
battery type is Li-Ion or Lithium Polymer

• Power consumption:

- in Off mode: 0 W;

- in Standby mode: 0.25 W.

7 Troubleshooting

PPrroobblleemm

– Possible cause

• Solution

UUSSBB cchhaarrggeerr ddooeess nnoott cchhaarrggee ccoonnnneecctteedd ddeevviiccee

– Voltage of device does not correspond with that of USB

charger.

• Refer to the user manual that came with the device.

– Improper connection between device and USB charger.

• Make sure that the USB cable is properly inserted into
the device and the USB charger.

– Damaged USB cable or connector tip.

• Replace USB cable and/or connector tip.

– Wrong connector tip used.

• Check connector tip and replace if necessary.

– Non supplied USB cable / connector tip used.

• Replace with supplied USB cable/connector tip.

– Problems with electrical circuit of USB charger.

• Take the USB charger to your local distributor.

55

44

33

22

11

33

22

11

3

2

1
