SB365
User manual
Contents
1 Important 2
Safety 2
2 Your Bluetooth speaker 3
Introduction 3
What's in the box 3
Overview of the speaker 4
3 Get started 5
Power supply 5
Turn on 5
4 Play from Bluetooth-enabled devices 6
Connect a device 6
Play from Bluetooth device 7
Clear the pairing information 7
5 Other features 7
Charge your mobile devices 7
Listen to an external device 7
Adjust volume 8
6 Product information 8
Specications 8
7 Troubleshooting 9
General 9
About Bluetooth device 10
8 Notice 10
Disposal of your old product and
batteries 11
1EN
1 Important
Safety
Warning
• Never remove the casing of this speaker.
• Never lubricate any part of this speaker.
• Never place this speaker on other electrical equipment.
• Keep this speaker away from direct sunlight, naked
amesorheat.
Important safety instructions
a Read these instructions.
b Keep these instructions.
c Heed all warnings.
d Follow all instructions.
e Do not use this apparatus near water.
f Clean only with dry cloth.
g Do not block any ventilation openings.
Install in accordance with the
manufacturer's instructions.
h Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (including ampliers) that
produce heat.
i Protect the power cord from being
walked on or pinched, particularly at
plugs, convenience receptacles, and the
point where they exit from the apparatus.
j Only use attachments/accessories
specied by the manufacturer.
k Unplug this apparatus during lightning
storms or when unused for long periods
of time.
l Refer all servicing to qualied service
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.
m Battery usage CAUTION – To prevent
battery leakage which may result in bodily
injury, property damage, or damage to
the unit:
• Install all batteries correctly, + and - as
marked on the unit.
• Do not mix batteries (old and new or
carbon and alkaline, etc.).
• Remove batteries when the unit is not
used for a long time.
n Battery shall not be exposed to excessive
heat such as sunshine, re or the like.
o Apparatus shall not be exposed to
dripping or splashing.
p Do not place any sources of danger on
the apparatus (e.g. liquid lled objects,
lighted candles).
q Where the plug of the Direct Plug-in
Adapter is used as the disconnect device,
the disconnect device shall remain readily
operable.
Note
• The type plate is located on the bottom of the
apparatus.
2 EN
2 Your Bluetooth
speaker
Congratulations on your purchase, and
welcometoPhilips!Tofullybenetfromthe
support that Philips offers, register your product
at www.philips.com/welcome.
Introduction
With this product, you can
• play audio from Bluetooth-enabled devices,
or other external devices;
• charge your mobile devices.
What's in the box
Check and identify the contents of your
package:
• Main unit
• Power adaptor
• Audio-in cable
• Short user manual
•
3EN
Overview of the speaker
b
c
d
e
a
d
f
a NFC
• Connect a device with NFC feature
through Bluetooth.
b
• Bluetooth indicator.
c
• Turn on the speaker or switch to
standby mode.
• Disconnect the paired device.
• Enter Bluetooth pairing mode.
• Clear Bluetooth pairing information.
4 EN
g
d - VOL/VOL +
• Adjust volume.
e CHARGING
• Charge mobile devices.
f AUDIO IN
• Connect an external audio device.
g DC IN
• Connect power.
3 Get started
Always follow the instructions in this chapter in
sequence.
Power supply
Option 2: AC power
Caution
• Risk of product damage! Make sure that the power
voltage corresponds to the voltage printed on the back
or underside of the speaker.
• Risk of electric shock! When you unplug the AC
adapter, always pull the plug from the socket. Never
pull the cord.
Either AC power or battery can be used as
power supply of this product.
Option 1: Battery power
Caution
• Risk of explosion! Keep batteries away from heat,
sunshine,orre.Neverdiscardbatteriesinre.
• Batteries contain chemical substances, so they should
be disposed of properly.
Note
• Batteries are not supplied with the accessories.
• If battery is low, the buttonasheswhenthespeaker
is turned on.
To install the batteries:
1 Open the battery compartment.
2 Insert 4 AA batteries with correct polarity
(+/-) as indicated.
3 Close the battery compartment.
Connect the power adaptor to:
• the DC IN socket at the back of the
speaker.
• the wall outlet.
Turn on
Press .
» The speaker switches to Bluetooth
mode.
» TheBluetoothindicatorbeginstoash.
Switch to standby mode
The speaker switches to standby mode in the
following situation:
• Press again;
• The connection with Bluetooth device or
other device is invalid for 15 minutes; or
• Music playback is stopped for 15 minutes.
5EN
4 Play from
Bluetoothenabled devices
With this product, you can listen to audio from
Bluetooth-enabled devices.
Connect a device
Note
• Make sure that your Bluetooth device is compatible
with this speaker.
• Before pairing a device with this speaker, read its user
manual for Bluetooth compatibility.
• The speaker can memorize a maximum of 4 paired
devices.
• Make sure that Bluetooth function is enabled on your
device, and your device is set as visible to all other
Bluetooth devices.
• Any obstacle between this speaker and a Bluetooth
device can reduce the operational range.
• Keep away from any other electronic device that may
cause interference.
Connect a device manually
Note
• The operational range between this speaker and a
Bluetooth device is approximately 10 meters (30 feet).
1 Press on the speaker.
» The Bluetooth indicator begins to
ash.
2 On your Bluetooth device, enable
Bluetooth and search for Bluetooth devices
(refer to the user manual of the device).
3 When [Philips SB365] is displayed on
your device, select it to start pairing and
connection. If necessary, enter default
password “0000”.
» After successful pairing and connection,
the speaker beeps twice, and the
Bluetooth indicator turns solid blue.
To disconnect the Bluetooth-enabled device:
• Press and hold for 3 seconds;
• Disable Bluetooth on your device; or
• Move the device beyond the
communication range.
To reconnect the Bluetooth-enabled device:
• Next time you turn on the speaker, the
speaker will reconnect the last connected
device automatically; or
• On your Bluetooth device, select “PHILIPS
SB365“ on your Bluetooth menu to start
connection.
To connect another Bluetooth-enabled device:
1 Press and hold for 3 seconds to
disconnect the currently connected device;
» The speaker enters Bluetooth pairing
mode.
2 Connect another Bluetooth device.
Connect a device through NFC
Near Field Communication (NFC) is a
technology that enables short-range wireless
communication between various NFC
compatible devices, such as mobile phones and
IC tags.
If your Bluetooth device supports NFC, you can
connect it with this speaker easily.
1 Press on the speaker.
» The Bluetooth indicator begins to
ash.
2 Enable the NFC feature on your Bluetooth
device (see the user manual of the device
for details).
3 Touch the NFC tag on the speaker with
the back of your Bluetooth device.
6 EN
5 Other features
Charge your mobile devices
4 On your Bluetooth device, accept the
pairing request with "SB365". If necessary,
input "0000" as the pairing password.
5 Follow the on-screen instructions to
complete the pairing and connection.
» After successful pairing and connection,
the speaker beeps twice, and the
Bluetooth indicator turns solid blue.
LED indicator Description
Flashing blue Connecting or waiting for
connection
Solid blue Connected
Play from Bluetooth device
After successful Bluetooth connection, play
audio on the Bluetooth device.
» Audio streams from your Bluetooth
device to the speaker.
With this speaker, you can charge your mobile
devices through the CHARGING socket.
Note
• The USB socket is used for charging only.
• In AC power supply mode, connect to
your mobile device with a USB cable (not
supplied).
» Once the device is recognized, the
charging starts.
CHARGING
Clear the pairing information
In Bluetooth mode, press and hold for 8
seconds.
» All the Bluetooth pairing information
is erased.
Listen to an external device
With this speaker, you can also listen to an
external audio device such as an MP3 player.
7EN
Note
• Make sure that there is no Bluetooth connection, or
music playback through Bluetooth is paused.
6 Product
information
1 Connect the supplied audio input cable to
• the AUDIO IN socket on this speaker,
and
• the headphone socket on the external
device.
2 Play audio on the external device (refer to
its user manual).
Adjust volume
During play, press VOL + or - VOL to increase
or decrease volume.
Note
• When the volume reaches the minimum or maximum,
the buttonashesforonesecond.
8 EN
Note
• Product information is subject to change without prior
notice.
Specications
Amplier
Rated Output Power 2 X 4 W RMS
Signal to Noise Ratio > 65 dBA
AUX Input 600 mV
Bluetooth
Bluetooth version V4.0
Supportedproles A2DP, AVRCP
Range 10 m (Free space)
General information
Power Supply
- AC Power
(power adapter)
- Battery 4 x 1.5 V LR6 AA
Brand name: PHILIPS;
Power adapter A:
Model: OH1015A0901660U1-UL;
Input: 100-240 V~,
50/60 Hz, 350 mA;
Output: 9 V 1.66 A;
Power adapter B:
Model: TPA103B15090-US;
Input: AC100-240 V~,
50/60 Hz, 1.1A MAX;
Output: 9 V 1.66 A;
Charging Voltage
and Current
Operation Power
Consumption
Dimensions - Main
Unit (W x H x D) 201 x 101 x 35 mm
Weight - Main Unit 0.5 kg
5 V 1 A
12 W
7 Troubleshooting
Warning
• Never remove the casing of this device.
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
device, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips Web page (www.
philips.com/support). When you contact Philips,
make sure that the device is nearby and the
model number and serial number are available.
General
No power
• Make sure that the AC power plug of the
unit is connected properly.
• Make sure that there is power at the AC
outlet.
• Insert the batteries with their polarities
(+/– signs) aligned as indicated.
• Replace the battery.
No sound
• Adjust volume on the speaker or the
Bluetooth-connected device.
• Make sure that your Bluetooth device is
within the effective operational range.
No response from the unit
• Take out the batteries and turn on the unit
again.
• Disconnect and reconnect the AC power
plug, then turn on the unit again.
• Make sure that AC power is connected
properly.
• Make sure that there is power at the AC
outlet.
9EN
About Bluetooth device
8 Notice
The audio quality is poor after connection
with a Bluetooth-enabled device.
• The Bluetooth reception is poor. Move the
device closer to this product or remove
any obstacle between them.
Cannot connect with the device.
• The Bluetooth function of the device is not
enabled. Refer to the user manual of the
device for how to enable the function.
• This product is already connected with
another Bluetooth-enabled device.
Disconnect that device and then try again.
The paired device connects and disconnects
constantly.
• The Bluetooth reception is poor. Move the
device closer to this product or remove
any obstacle between them.
• For some devices, Bluetooth connection
may be deactivated automatically as a
power-saving feature. This does not indicate
any malfunction of this product.
Anychangesormodicationsmadetothis
device that are not expressly approved by
WOOX Innovations may void the user’s
authority to operate the equipment.
Notice for the USA and Canada
This device complies with Part 15 of the FCC
Rules and license-exempt RSS standard of
Industry Canada. Operation is subject to the
following two conditions:
1 this device may not cause harmful
interference, and
2 this device must accept any interference
received, including interference that may
cause undesired operation.
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses, and can radiate radio frequency energy
and, if not installed and used in accordance
with the instruction manual, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is encouraged
to try to correct the interference by one or
more of the following measures:
• Relocate the receiving antenna.
• Increase the separation between
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
RF Radiation Exposure Statement: This
equipment complies with FCC’s and IC’s RF
10 EN
radiation exposure limits set forth for an
uncontrolled environment. The antenna(s)
used for this transmitter must be installed and
operated to provide a separation distance of
at least 20 cm from all persons and must not
be collocated or operating in conjunction with
any other antenna or transmitter. Installers must
ensure that 20cm separation distance will be
maintained between the device (excluding its
handset) and users.
CAN ICES-3(B)/NMB-3(B)
Disposal of your old product and batteries
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
Never dispose of your product with other
household waste. Please inform yourself about
the local rules on the separate collection of
electrical and electronic products and batteries.
The correct disposal of these products helps
prevent potentially negative consequences on
the environment and human health.
Your product contains batteries, which cannot
be disposed of with normal household waste.
Please inform yourself about the local rules on
separate collection of batteries. The correct
disposal of batteries helps prevent potentially
negative consequences on the environment and
human health.
Please visit www.recycle.philips.com for
additional information on a recycling center in
your area.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old
equipment.
The Bluetooth® word mark and logos are
registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by WOOX
Innovations is under license.
The N Mark is a trademark or registered
trademark of NFC Forum, Inc. in the United
States and in other countries.
11EN
Specifications are subject to change without notice.
2014 © WOOX Innovations Limited. All rights reserved.
Philips and the Philips’ Shield Emblem are registered
trademarks of Koninklijke Philips N.V. and are used by WOOX
Innovations Limited under license from Koninklijke Philips N.V.
SB365_37_UM_V3.0
Loading...
