Philips SA5295C User Manual

Philips GoGear Opus Flash audio video player

16GB

SA5295C

Entertainment in superb sound

with FullSound and premium earphones

The Philips GoGear Opus digital audio/ video player featuring Philips patented FullSound technology brings you superb audio quality. Enjoy MP3, WMA and AAC music and view videos on the 2.8" color screen whenever you go.

Experience music and video - anytime, anyplace

• Enjoy MP3, WMA and AAC music plus FM radio

• High-definition headphones for precise sound

Enjoy straight away

• Control playpack while browsing your library

• SuperScroll™ to find what you want in a fast, simple way

• 2.8" QVGA LCD color display for superb video enjoyment

• Easy and intuitive user interface with album art display

All your entertainment on the go

• FullSound™ to bring CD listening experience to MP3

• Charge directly from your PC via USB

• Playlist on the go and delete functions

• Up to 30-hour music or 6-hour video playback*

Flash audio video player

16GB

SA5295C/02

Specifications

Picture/Display

• Diagonal screen size (inch): 2.8 inch

•Lines of text: 7

• Resolution: QVGA, 320 x 240 pixels, 262K colours

•Backlight

•Type: LCD

Sound

• Equalizer customizable

• Frequency response: 20 - 18k Hz

• Output Power: 2 x 2.4mW

• Signal to noise ratio: > 84 dB

• THD: 0.05% at 1kHz

• Channel separation: 45 dB

• Equalizer settings: Classic, D Hop, Jazz, Lounge, Pop, RnB, Rock, Spoken word

• Sound Enhancement: FullSound

Audio Playback

• MP3 bit rates: 8-320 kbps and VBR

• Compression format: MP3, WMA, AAC

• WMA bit rates: 5-320 kbps

• WMA sample rates: 8, 11.025, 16, 22.050, 32, 44.1,

kHz

• Digital Rights Management for Portable Devices, Supports download & subscription music services

• ID3 Tag support: Album title and artist name

• MP3 sample rates: 16, 32, 44.1, 48, 11.025, 22.050,

, 8 kHz

Still Picture Playback

• Picture compression format: JPEG

•Slide show

Storage Media

• Built-in memory type: NAND Flash

• Built-in memory capacity: 16 GB

Connectivity

• Headphone: 3.5 mm

•USB: High speed USB 2.0

Convenience

• Battery charging indication: On User Interface

• Battery low indication

• Function: Keypad lock

•Superscroll

•Volume control

• Firmware upgradeable

Accessories

• CD-ROM: Yes , with IFU, Device Manager, Media converter & Windows Media Player

• Headphones: AY3817

• USB cable: AY3930

ance, Electronica, Hip

: Windows Media DRM

•Quick start guide

• Pouch: AY4255

Software

• Device manager: to restore and upgrade

• Media Converter for Philips formats to player : AVI,MOV,RM,WMV etc. Needs Quicktime (for MOV), Realplayer (for RM) and WMP10 or above (for WMV) installations.

• Windows Media Player 11

: Converts following

Green Specifications

• Lead-free soldered product

System Requirements

• PC OS: Windows XP (SP2) or Windows Vista

• Internet connection: Yes (for access to updated

upport documents, manuals, future firmware and

s PC software upgrades)

•CD-ROM drive

• USB: Free USB port

Power

• Battery capacity: 880mAh

• Playtime on internal battery: Up or 6 hours video

•Battery Type: LI-Polymer

• Rechargeable: Yes, via USB

to 30 hours audio

Dimensions

• Product weight: 0.095 kg

• Product dimensions (WxDxH): 106 x 9.9 x 58 mm

• Packaging type: D-box

Tuner/Reception/Transmission

• Station presets: 20

•Tuner Bands: FM

• RDS: Program Type, Radio Text, Station

formation, Station Name

Video Playback

• MPEG4 SP: Upto 640kbps in avi format, 320x240 , 30fps (Other formats supported by using provided converter software)

• WMV9: Upto 512kbps, 320x240 , 30fps (Other

ormats supported by using provided converter

f software)

• Digital Rights Management: Windows XP (SP2) or

ws Vista

Windo

Audio Capturing

• Audio file format: WAV

• Built-in microphone: mono

• Voice recording: ADPCM

• FM radio recording

•

Highlights

FullSound™

Philips' innovative FullSound technology faithfully restores sonic details to compressed MP3 music, dramatically enriching and enhancing it, so you can experience CD music without any distortion. Based on an audio post-processing algorithm, FullSound combines Philips' renowned expertise in music reproduction with the power of the latest generation Digital Signal Processor (DSP). The result is fuller bass with more depth and impact, boosted voice and instrument clarity, and rich detail. Rediscover your compressed MP3 music in true-tolife sound that will touch your soul and move your feet.

High-definition headphones

Designed according to the curvature of the human canals, these ergonomically designed headphones with exceptional noise isolation feature precisely direct soundwaves from the speaker to your ear drums with highest definition.

SuperScroll™

Issue date 2009-04-05

Version: 2.0.4

12 NC: 8670 000 51662 UPC: 6 09585 16879 4

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective owners.

www.philips.com

Double action search keys allow easy speed control when scrolling through large libraries. You can choose to move through your playlist one song or video at a time or just press and hold down a little harder to SuperScroll™ swiftly to your desired file.

* Actual transfer speed may vary based on your operating system and

software configuration.

* Supports download and subscription services compatible with WMA

DRM10

* Windows Media and the Windows logo are trademarks, or

registered trademarks of Microsoft Corporation in the United States and/or other countries.

* Rechargeable batteries have a limited number of charge cycles and

may eventually need to be replaced. Battery life and number of charge cycles vary by use and settings.
