Philips SA5125-97 User Manual

Philips GoGear Flash audio video player

2GB*

SA5125

Your music and video on the move

Get ready for total entertainment with the Philips SA5125 Digital Audio Video Player. Its bright, large display and intuitive UI let you easily engage with all your music, videos and photos.

Experience music and video - anytime, anyplace

• Enjoy MP3 and WMA music plus FM tuner

• 1.8” backlit color display for comfortable viewing

• Stores up to 1000 songs or 500 photos or 8 hours of videos*

• Enjoy WMV videos purchased online or from your PC

Enjoy straight away

• Control playback while browsing your media library

• SuperScroll™ finds what you want in a fast, simple way

• Unique album art navigation for a new experience every time

All your entertainment on the go

• Enjoy up to 20 hours of music or 4 hours of video playtime*

• Auto sync with Windows Media Player

• Charge directly from your PC via USB

• Playlist on the go and Delete function for easy organization

Flash audio video player

2GB*

SA5125/97

Specifications Product highlights

Picture/Display

• Type: LCD

• Diagonal screen size (inch): 1.8 inch

• Resolution: 220x176 pixels , 65K Colours

• Backlight

• Lines of text: 7

Sound

• Bass enhancement: Concert sound EX

• Equalizer: 5-bands

• Equalizer customizable

• Equalizer settings: Classic, Funk, Hip Hop, Jazz, Rock, Spoken word, Techno

• Frequency response: 20 - 16 000 Hz

• Output Power: 2x2.5mW (16 Ohm)

• Signal to noise ratio: > 82dB

• THD: 0.1%

Audio Playback

• Compression format: MP3, WMA

• MP3 bit rates: 8-320 kbps and VBR

• WMA bit rates: 32 - 192 kbps

• WMA sample rates: 16,22.050,32,44.1,48

• Digital Rights Management: Windows Media DRM for Portable Devices, Supports download & subscription music services

Video Playback

• WMV9: Upto 384kbps, 220x176 , 24fps (Other formats supported by using provided converter software)

• Digital Rights Management: Windows Media DRM for Portable Devices, Supports download,subscription & rental video services

Still Picture Playback

• Picture compression format: JPEG

•Slide show

FM Radio

• FM Radio functions: Autostore/Manual store, Preset List, Sorting

Convenience

• Battery charging indication: On User Interface

• Battery full indication

• Battery low indication

• Function: Keypad lock

• Superscroll

•Volume control

• SuperPlay

Connectivity

• Headphone: 3.5 mm

• USB: High speed USB 2.0

Storage Media

• Built-in memory type: NAND Flash

• Built-in memory capacity: 2GB

• Music memory capacity, WMA: Upto 1000 songs

Power

• Battery capacity: 630mAh

• Battery Type: LI-Polymer

• Playtim e on inte rn al batte ry: Upto 20 hours audio or 2 hours video

• Rechargeable: Yes, via USB

Software

• Device manager

• Windows Media Player 11

• Media Converter for Philips: Converts following formats to player : AVI(Microsoft video1 format), MPEG-1,2,4, DVD(*.vob),MOV,WMV,RM etc. Needs Quicktime (for MOV) and WMP10 or above (for WMV) installations.

Accessories

• CD-ROM: Yes , with IFU, Device Manager & Windows Media Player

• Headphones: AY3809

• USB cable: AY3911

• Quick start guide

System Requirements

• PC OS: Windows XP (SP2) or Windows Vista

•CD-ROM drive

•Sound card

•Video card

Green Specifications

• Lead-free soldered product

Dimensions

• Product weight: 0.060 kg

• Product dimensions (WxDxH): 46 x 9.9 x 92.5 mm

• Packaging type: Clamshell

• Blister dimensions (WxDxH): 135 x 40 x 195 mm

• Weight incl. Packaging: 0.250 kg

• Master carton dimensions: 196 x 205 x 146 mm

• Master carton quantity: 5

•

Playlist on the go and Delete

Unique album art navigation

Issue date 2008-11-15

Version: 3.0.12

12 NC: 8670 000 31995 EAN: 87 12581 34901 1

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective owners.
