Philips QP2520-20 operation manual

QP2531, QP2530, QP2522, QP2521, QP2520

empty page before TOC

English 6 Dansk 23 Deutsch 41 Español 60 Français 78 Italiano 97 Nederlands 116 Norsk 135 Português 152 Suomi 171 Svenska 189 Türkçe 207

Ελληνικα

224

English

Introduction

Congratulations on your purchase and welcome to Philips! To fully benefit from the support that Philips offers, register your product at

www.philips.com/welcome.

General description (Fig. 1)

1 Protection cap 2 Blade 3 Blade release slide 4 On/off button 5 Battery status indicator (QP2531, QP2530 only) 6 Small plug 7 Battery charge indicator (QP2522, QP2521,

QP2520 only)

8 Supply unit (QP2531, QP2530: adapter type

HQ850. QP2522, QP2521, QP2520: adapter type

A00390.) 9 Replacement blade (QP2531, QP2522 only) 10 Click-on stubble comb 5mm 11 Click-on stubble comb 3mm (QP2531, QP2530,

QP2520 only) 12 Click-on stubble comb 2mm (QP2531, QP2530

only) 13 Click- on stubble comb 1mm

Important safety information

Read this important information carefully before you use the appliance and its accessories and save it for future reference. The accessories supplied may vary for different products.

English

Danger

Warning

English

- Keep the supply unit dry.

- The supply unit contains a

transformer. Do not cut off the

supply unit to replace it with

another plug, as this causes a

hazardous situation.

- Only charge the appliance with

the supply unit provided.

English

- This appliance can be used by

children aged from 8 years and

above and persons with

reduced physical, sensory or

mental capabilities or lack of

experience and knowledge if

they have been given

supervision or instruction

concerning use of the

appliance in a safe way and

understand the hazards

involved. Children shall not play

with the appliance. Cleaning

and user maintenance shall not

be made by children without

supervision.

- Always unplug the appliance

before you clean it under the

tap.

- Always check the appliance

before you use it. Do not use

the appliance if it is damaged,

as this may cause injury. Always

replace a damaged part with

one of the original type.

Caution

English

- Do not open the appliance to

replace the rechargeable

battery.

- Never immerse the charging

stand in water and do not rinse

it under the tap.

- Never use water hotter than

80°C to rinse the appliance.

- Only use this appliance for its

intended purpose as shown in

the user manual.

- For hygienic reasons, the

appliance should only be used

by one person.

- Never use compressed air,

scouring pads, abrasive

cleaning agents or aggressive

liquids such as petrol or

acetone to clean the appliance.

- Do not use the supply unit in or

near wall sockets that contain

or have contained an electric air

freshener to prevent irreparable

damage to the supply unit.

English

Electromagnetic fields (EMF)

- This Philips appliance complies with all

applicable standards and regulations regarding

exposure to electromagnetic fields.

General

- This appliance is waterproof. It is suitable for

use in the bath or shower and for cleaning

under the tap. For safety reasons, the appliance

can therefore only be used without cord.

- The appliance is suitable for mains voltages

ranging from 100 to 240 volts.

- The supply unit transforms 100-240 volts to a

safe low voltage of less than 24 volts.

Charging

Note: This appliance can only be used without cord.

QP2531, QP2530: Charging normally takes approx. 4 hours.

QP2522, QP2521, QP2520: Charging normally takes approx. 8 hours.

A fully charged appliance has an operating time of up to 60 minutes (QP2531, QP2530) or 45 minutes (QP2522, QP2521, QP2520).

Charge the appliance before you use it for the first time and when the battery charge indicator indicates that the battery is almost empty.

Battery status indicator QP2531, QP2530:

When the battery status indicator light flashes orange, the battery is almost empty.

English

To indicate that the appliance is charging, the battery status indicator light flashes green.

When the battery is fully charged, the battery status light lights up green continuously.

Approx. 30 minutes after the battery is fully charged or when you disconnect the appliance from the mains, the light of the battery status indicator switches off automatically.

Battery charge indicator QP2522, QP2521, QP2520:

The battery status is indicated by the performance of the appliance. When the appliance starts working more slowly, the battery is almost empty and needs to be charged for optimal performance.

Charging with the adapter

1 Insert the small plug into the appliance and put

the adapter in the wall socket. 2 QP2522, QP2521, QP2520 only: The battery

charge indicator on the adapter lights up

continuously, when the appliance is connected

to the mains. 3 After charging, remove the adapter from the

wall socket and pull the small plug out of the

appliance.

Using the appliance

You can use the appliance to trim, edge or shave facial hair (beard, moustache and sideburns). Shave for a smooth result, trim to obtain a certain length and edge to create perfect edges and sharp lines. This appliance is not intended for shaving,

English

edging or trimming hairs on lower body parts or scalp hair. Take your time when you first start to use the appliance. You have to acquire practice with the appliance. Note: This appliance can only be used without

cord.

Switching the appliance on and off

1 To switch on the appliance, press the on/off

button once. 2 To switch off the appliance, press the on/off

button once.

Shaving

Warning: Before you use the appliance, always check the blade for damage or wear. If the blade is damaged or worn, do not use the appliance, as injury may occur. Replace a damaged blade before you use the appliance (see chapter ‘Replacement’).

Shaving tips and tricks

- Make sure that the blade is in full contact with

the skin by placing it flat on the skin.

- For the best result, move the appliance against

the grain.

- Make long strokes while you press lightly.

- You can use the appliance dry or wet with gel

or foam, even in the shower.

- Shaving a clean beard and face gives the best

results.

Edging

English

1 Switch on the appliance. 2 Place the blade on the skin and move the

appliance up or against the grain in long strokes

while you press it lightly.

Note: Make sure you hold the surface of the

blade flat against your skin. 3 Switch off and clean the appliance after every

use (see ‘Cleaning and maintenance’).

You can also use both edges of the blade to create sharp lines and perfect edges. Hold the appliance in such a way that the blade is perpendicular to the skin and one of its edges touches the skin. This allows more precise detailing of sideburns and the area around the mouth and nose.

1 To use the blade for creating sharp edges and

lines, use either edge of the blade. 2 Switch on the appliance.

3 Place the edge of the blade perpendicular onto

the skin.

English

4 Switch off and clean the appliance after every

use (see ‘Cleaning and maintenance’).

Trimming with comb

The click-on stubble combs allow you to trim hair to different lengths.

QP2531, QP2530 come with 4 click-on stubble combs: 5mm, 3mm, 2mm, 1mm.

QP2520 comes with 3 click-on stubble combs: 5mm, 3mm, 1mm.

QP2522, QP2521 come with 2 click-on stubble combs: 5mm, 1mm.

Start with the 5mm comb to acquire practice with this appliance.

The indication on each comb corresponds to the hair length in millimeters.

Tips

Make straight strokes while applying gentle pressure.

Always make sure that the tips of the clickon stubble comb point in the direction in which you move the appliance.

Make sure that the flat part of the comb is always in full contact with the skin to obtain an even trimming result.

Since hair grows in different directions, you need to move the appliance in different directions as well (upward, downward or across).

Trimming is easier when the skin and hair are dry.

1 Place the comb onto the blade, with the teeth

of the comb pointing upwards.

Note: Always trim in the direction of the teeth of

the comb. This will give you the best results.

2 Switch on the appliance.

3 Place the comb onto the skin and move the

appliance in the direction of the teeth of the

comb.

Note: For the best result, move it against the

grain. 4 Switch off and clean the appliance after every

use (see ‘Cleaning and maintenance’). 5 To remove the comb, hold it on both sides and

pull it off the blade.

Cleaning and maintenance

Clean the appliance after every use.

Caution: Never use compressed air, scouring pads, abrasive cleaning agents or aggressive liquids such as petrol or acetone to clean the appliance.

Caution: Do not tap the appliance against a surface to remove water from it, as this may cause damage. Replace the blade if it is damaged.

English

Cleaning the appliance

1 Remove the comb from the blade. Always turn

the appliance off before putting on or taking off

combs.

2 If a lot of hairs have accumulated on the comb,

first blow them off.

3 If a lot of hairs have accumulated on the

appliance, first blow them off.

4 Then switch on the appliance and rinse the

blade with lukewarm water.

Caution: Do not dry the blade with a towel or

a tissue as this may cause damage.

5 Then rinse the comb with lukewarm water. 6 Let the appliance and comb dry.

Note: The blade is fragile. Handle it carefully. Replace the blade if it is damaged.

Storage

Always attach the protection cap on the blade to protect the blade from damage during travelling or storage.

We advise you to let the appliance and its attachments dry before you store them for the next use.

1 Place the protection cap onto the edge of the

blade.

2 Close the protection cap.

Replacement

Replacing the blade

For optimal cutting and gliding performance of the blade, we advise you to replace the blade every 4 months or when it no longer provides the shaving or trimming results you expect. The advice of replacing every 4 months is based on two full shaves a week. Depending on your usage behavior the exact lifetime of the blade could be longer or shorter. Similar to what you would experience with a manual blade, the blade becomes blunt over time, which results in increased hair pulling and reduced cutting performance.

English

1 Push the blade release slide upwards carefully,

and hold the blade on its sides to remove the

blade and prevent it from flying away.

2 Hold the new blade on its sides and press it

onto the handle (‘click’). Note: When you hear a click the new blade is

placed correctly and ready for use.

Ordering accessories

To buy accessories or spare parts, visit www.shop.philips.com/service or go to your Philips dealer. You can also contact the Philips Consumer Care Center in your country (see the international warranty leaflet for contact details).

The following parts are available:

- QP210 Blade 1-pack

- QP220 Blade 2-pack

Recycling

- This symbol means that this product shall not

be disposed of with normal household waste

(2012/19/EU).

- This symbol means that this product contains a

built-in rechargeable battery which shall not be

disposed of with normal household waste

(2006/66/EC). We strongly advise you to take

your product to an official collection point or a

Philips service centre to have a professional

remove the rechargeable battery.

- Follow your country’s rules for the separate

collection of electrical and electronic products

and rechargeable batteries. Correct disposal

helps prevent negative consequences for the

environment and human health.

Removing the rechargeable battery

Caution: Only remove the rechargeable battery when you discard the appliance. Make sure the battery is completely empty when you remove it.

Note: We strongly advise you to have a professional remove the rechargeable battery.

1 Disconnect the appliance from the mains and

let the appliance run until the motor stops.

2 Remove the blade from the appliance. 3 Remove the bottom of the appliance by

bending it downwards and pull it off.

English

4 Take out the battery compartment by

separating the bottom part from the top part.

English

5 Separate the battery section from the bottom

part.

6 Lift the battery out of the inner body with the

screwdriver. The battery is connected with

double-sided tape.

Warning: Be careful, the battery strips are very sharp.

Warranty and support

If you need information or support, please visit www.philips.com/support or read the international warranty leaflet.

Guarantee restrictions

The blade is not covered by the terms of the international guarantee because it is subject to wear.

Troubleshooting

This chapter summarizes the most common problems you could encounter with the appliance. If you are unable to solve the problem with the information below, visit www.philips.com/support for a list of frequently asked questions or contact the Consumer Care Center in your country.

Problem Possible cause Solution

English

The appliance does not charge when it is connected to the mains.

I cannot switch on the appliance when it is connected to the mains.

The appliance does not work anymore.

The appliance has to be switched off when you charge it.

You cannot use the appliance when it is charging. You can only use the appliance without cord.

The rechargeable battery is empty.

The blade is blocked by dirt.

Switch off the appliance.

Disconnect the appliance from the mains before use.

Charge the appliance (see chapter ‘Charging’). QP2530: During charging, the battery charge indicator flashes. QP2520: During charging, the charge indicator on the adapter lights up. If the battery charge indicator does not flash or light up, check whether there is a power failure or if the wall socket is live. If there is no power failure and the wall socket is live but the battery charge indicator still does not flash or light up, take the appliance to your dealer or a Philips service center.

Switch on the appliance and rinse the blade under the tap with warm water.

Hold the blade in a cup with warm water (60°C and no hotter) for approx.30 seconds.

English

Problem Possible cause Solution

The appliance doesn’t cut hairs anymore.

The appliance makes a strange noise.

The appliance doesn’t function optimally anymore.

The blade is placed on the handle incorrectly.

The blade is damaged or worn.

The blade is placed onto the handle incorrectly.

The blade is blocked by dirt.

The blade is subject to wear and therefore its performance decreases over time.

The blade is a delicate part of the appliance and can easily be damaged. If the blade is damaged, it may not function optimally anymore.

Push the blade onto the appliance until you hear a click.

Replace the blade with a new one. See chapter ‘Replacement’.

Remove and reattach the blade. Push it onto the appliance until you hear a click.

Remove the blade and clean it thoroughly.

Replace the blade with a new one. See chapter ‘Replacement’.

Introduktion

Tillykke med dit køb, og velkommen til Philips! For at få fuldt udbytte af den support, Philips tilbyder, skal du registrere dit produkt på

www.philips.com/welcome.

Generel beskrivelse (fig. 1)

1 Beskyttelseshætte 2 Knivenhed 3 Udløser til knivenhed 4 On/off-knap 5 Batteristatusindikator (kun QP2531, QP2530) 6 Lille stik 7 Batteriopladningsindikator (kun QP2522,

QP2521, QP2520) 8 Forsyningsenhed (QP2531, QP2530:

adaptertype HQ850. QP2522, QP2521, QP2520:

adaptertype A00390). 9 Udskiftningsknivenhed (kun QP2531, QP2522) 10 Stubbekam til at klikke på 5 mm 11 Stubbekam til at klikke på 3 mm (kun QP2531,

QP2530, QP2520) 12 Stubbekam til at klikke på 2 mm (kun QP2531,

QP2530) 13 Stubbekam til at klikke på 1 mm

Vigtige sikkerhedsoplysninger

Læs disse vigtige oplysninger omhyggeligt igennem, inden apparatet og tilbehøret tages i brug, og gem dem til eventuel senere brug. Det medfølgende tilbehør kan variere for forskellige produkter.

Dansk

Fare

Advarsel

- Hold forsyningsenheden tør.

- Strømforsyningsenheden

indeholder en transformator.

Klip ikke

strømforsyningsenheden af og

udskift den med et andet stik,

da dette vil føre til farlige

situationer.

- Brug kun den medfølgende

strømforsyningsenhed ved

opladning af apparatet.

Dansk

- Dette apparat må bruges af

børn fra 8 år og opefter og

personer med reducerede

fysiske, sensoriske eller mentale

evner eller manglende erfaring

og viden, hvis de er blevet

instrueret i sikker brug af

apparatet og forstår de

medfølgende risici. Lad ikke

børn lege med apparatet.

Rengøring og vedligeholdelse

må ikke foretages af børn uden

opsyn.

- Tag altid stikket ud af apparatet,

inden det skylles under

vandhanen.

- Kontroller altid apparatet,

inden du anvender det. Anvend

ikke apparatet, hvis det er

beskadiget, da dette kan

forårsage personskade. Udskift

altid en beskadiget del med en

tilsvarende original type.

Dansk

Forsigtig

- Apparatet må ikke åbnes i

forbindelse med udskiftning af

det genopladelige batteri.

- Opladeren må aldrig kommes

ned i vand eller skylles under

vandhanen.

- Rens aldrig apparatet med

vand, der er varmere end 80°C.

- Brug kun apparatet til det

tilsigtede formål som vist i

brugervejledningen.

- Af hygiejniske grunde bør

apparatet kun anvendes af en

og samme person.

- Brug aldrig trykluft,

skuresvampe eller skrappe

rengøringsmidler, som f.eks.

benzin, acetone eller lignende,

til rengøring af apparatet.

- Brug ikke

strømforsyningsenheden i eller i

nærheden af stikkontakter, som

indeholder eller har indeholdt

en elektrisk luftfrisker, for at

forhindre uoprettelig

beskadigelse af

strømforsyningsenheden.

Elektromagnetiske felter (EMF)

- Dette Philips-apparat overholder alle

branchens gældende standarder og regler

angående eksponering for elektromagnetiske

felter.

Generelt

- Dette apparat er vandtæt. Apparatet er

velegnet til brug i badet eller under bruseren og

kan rengøres under vandhanen. Af

sikkerhedsmæssige årsager kan apparatet kun

betjenes trådløst.

- Apparatet kan tilsluttes netspændinger mellem

100 og 240 V.

- Strømforsyningsenheden omformer 100-240

Volt til en lav sikkerhedsspænding under 24

Volt.

Dansk

Opladning

Bemærk: Dette apparat kan kun bruges uden ledning.

QP2531, QP2530: Opladning tager normalt ca. 4 timer.

QP2522, QP2521, QP2520: Opladning tager normalt ca. 8 timer.

Dansk

Et fuldt opladet apparat har en brugstid på op til 60 minutter (QP2531, QP2530) eller 45 minutter (QP2522, QP2521, QP2520).

Oplad apparatet, før du bruger det første gang, og når batteriopladningsindikatoren viser, at batteriet næsten er tomt.

Batteristatusindikator QP2531, QP2530:

Når batteristatusindikatoren blinker orange, er batteriet næsten tomt.

For at indikere, at apparatet oplades, blinker batteristatusindikatoren grønt.

Når batteriet er fuldt opladet, lyser batteristatusindikatoren konstant grønt.

Ca. 30 minutter efter at batteriet er fuldt opladet, eller når du kobler apparatet fra stikkontakten, slukkes batteristatusindikatorens lys automatisk.

Batteriopladningsindikator QP2522, QP2521, QP2520:

Batteristatus angives af apparatets ydeevne. Når apparatet begynder at køre langsommere, er batteriet næsten tomt og skal oplades for at opnå optimal ydeevne.

Opladning med adapter

1 Sæt det lille stik i apparatet, og sæt adapteren i

stikkontakten. 2 Kun QP2522, QP2521, QP2520:

Batteriopladningsindikatoren på adapterens

lyser konstant, når apparatet er koblet til

stikkontakten. 3 Efter opladning skal du tage adapteren ud af

stikkontakten og tage det lille stik ud af

apparatet.

Sådan bruges apparatet

Du kan bruge apparatet til at trimme, rette kanter på eller barbere ansigtshår (skæg, overskæg og bakkenbarter). Barber for at opnå et glat resultat, trim for at opnå en bestemt længde, og ret kanter for at skabe perfekte kanter og skarpe linjer. Dette apparat er ikke beregnet til barbering, kantretning eller trimning af hår på de nedre kropsdele eller hovedhår. Tag dig god tid, når du begynder at bruge apparatet første gang. Du skal vænne dig lidt til at bruge apparatet. Bemærk: Dette apparat kan kun bruges uden

ledning.

Dansk

Sådan tændes og slukkes apparatet

1 Apparatet tændes ved at trykke én gang på

tænd/sluk-knappen. 2 Apparatet slukkes ved at trykke én gang på

on/off-knappen.

Dansk

Barbering

Advarsel: Inden du bruger apparatet, skal du altid kontrollere, om knivenheden er beskadiget eller slidt. Hvis knivenheden er beskadiget eller slidt, må du ikke bruge apparatet, da du kan risikere at komme til skade. Udskift en beskadiget knivenhed, inden du bruger apparatet (se afsnittet "Udskiftning").

Barberingstips og tricks

- Sørg for, at knivenheden er i fuld kontakt med

huden ved at anbringe den fladt på huden.

- Bevæg apparatet mod hårene for at opnå det

bedste resultat.

- Brug lange strøg, mens du trykker let.

- Du kan bruge apparatet på et tørt eller vådt

ansigt med sæbe eller skum, også under

bruseren.

- Resultatet bliver bedst, hvis skægget og ansigtet

er rent.

1 Tænd for apparatet. 2 Anbring knivenheden på huden, og før

apparatet op eller mod hårene med lange strøg,

mens du trykker let.

Bemærk: Sørg for at holde knivenhedens

overflade fladt mod huden. 3 Sluk for apparatet, og rengør apparatet før hver

brug (se "Rengøring og vedligeholdelse").

+ 214 hidden pages
