Philips PR1906C User Manual

Instructions for use

Color Television

PR1906C1

3135 015 18291

Once your PHILIPS MAGNAVOX purchase is registered, you’re eligible to receive all the privileges of

owning a PHILIPS MAGNAVOX product. So complete and return the Warranty Registration Card

enclosed with your purchase at once. And take advantage of these important benefits.

Return your Warranty Registration card today to ensure you

receive all the benefits you’re entitled to.

Congratulations

on your

purchase,

and welcome to the

“family!”

Dear PHILIPS MAGNAVOX product owner:

Thank you for your confidence in PHILIPS MAGNAVOX. You’ve selected one of the best-built, bestbacked products available today. And we’ll do everything in our power to keep you happy with your purchase for many years to come.

As a member of the PHILIPS MAGNAVOX “family,” you’re entitled to protection by one of the most comprehensive warranties and outstanding service networks in the industry.

What’s more, your purchase guarantees you’ll receive all the information and special offers for which you qualify, plus easy access to accessories from our convenient home shopping network.

And most importantly you can count on our uncompromising commitment to your total satisfaction. All of this is our way of saying welcome–and thanks for investing in a PHILIPS MAGNAVOX product.

Sincerely,

Robert Minkhorst President and Chief Executive Officer

Know these

safety

symbols

t This “bolt of lightning” indicates uninsulated material within your unit which may cause an elec-

trical shock. For the safety of everyone in your household, please do not remove product covering.

s The “exclamation point” calls attention to features for which you should read the enclosed lit-

erature closely to prevent operating and maintenance problems. WARNING: TO PREVENTFIRE OR SHOCK HAZARD, DO NOTEXPOSE THIS EQUIPMENTTO

RAIN OR MOISTURE. CAUTION: To prevent electric shock, match wide blade of plug to wide slot, and fully insert. ATTENTION: Pour éviter les chocs électriques, introduire la lame la plus large de la fiche dans la

borne correspondante de la prise et pousser jusqu’au fond.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Warranty

Verification

Registering your product within 10 days confirms your right to maximum protection under the terms and conditions of your PHILIPS MAGNAVOX warranty.

Owner

Confirmation

Your completed Warranty Registration Card serves as verification of ownership in the event of product theft or loss.

Model

Registration

Returning your Warranty Registration Card right away guarantees you’ll receive all the information and special offers which you qualify for as the owner of your model.

P.S. Remember, to get the most from your PHILIPS

MAGNAVOX product, you must return your Warranty Registration Card within 10 days. So please mail it to us right now!

Hurry!

Visit our World Wide Web Site at http://www.philipsmagnavox.com

SAFETY INSTRUCTIONS - Read before operating equipment

This product was designed and manufactured to meet strict quality and safety standards. There are, however, some installation and operation precautions which you should be particularly aware of.

1. Read Instructions - All the safety and operating instructions should

be read before the appliance is operated.

2. Retain Instructions - The safety and operating instructions should

be retained for future reference.

3. Heed Warnings - All warnings on the appliance and in the operating

instructions should be adhered to.

4. Follow Instructions - All operating and use instructions should be

followed.

5. Water and Moisture - The appliance should not be used near water

- for example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement or near a swimming pool, etc.

6. Carts and Stands - The appliance should be used only with a cart or

stand that is recommended by the manufacturer.

6A. An appliance and cart combination should be moved

with care. Quick stops, excessive force, and uneven surfaces may cause the appliance and cart combination to overturn.

6B. Tilt/Stability- All televisions must comply with recommended inter-

national global safety standards for tilt and stability properties of its cabinet design.

• Do not compromise these design standards by applying excessive pull force to the front, or top, of the cabinet which could ultimately overturn the product.

• Also, do not endanger yourself, or children, by placing electronic equipment/toys on the top of the cabinet. Such items could unsuspectingly fall from the top of the set and cause product damage and/or personal injury.

7. Wall or Ceiling Mounting - The appliance should be mounted to a

wall or ceiling only as recommended by the manufacturer.

8. Ventilation - The appliance should be situated so that its location or

position does not interfere with its proper ventilation. For example, the appliance should not be situated on a bed, sofa, rug, or similar surface that may block the ventilation openings; or, placed in a builtin installation, such as a bookcase or cabinet that may impede the flow of air through the ventilation openings.

9. Heat - The appliance should be situated away from heat sources such

as radiators, heat registers, stoves, or other appliances (including amplifiers) that produce heat.

10. Power Sources - The appliance should be connected to a power sup-

ply only of the type described in the operating instructions or as marked on the appliance.

11. Power-Cord Protection - Power supply cords should be routed so

that they are not likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords and plugs, convenience receptacles, and the point where they exit from the appliance.

12. Cleaning - The appliance should be cleaned only as recommended

by the manufacturer.

13. Power Lines - An outdoor antenna should be located away from

power lines.

14. Outdoor Antenna Grounding - If an outside antenna is connected

to the receiver, be sure the antenna system is grounded so as to provide some protection against voltage surges and built up static charges.

Section 810 of the National Electric Code, ANSI/NFPA No. 70-1984, provides information with respect to proper grounding of the mats and supporting structure grounding of the lead-in wire to an antenna discharge unit, size of grounding connectors, location of antenna-discharge unit, connection to grounding electrodes and requirements for the grounding electrode. See Fig. below.

15. Non-use Periods - The power cord of the appliance should be

unplugged from the outlet when left unused for a long period of time.

16. Object and Liquid Entry - Care should be taken so that objects do

not fall and liquids are not spilled into the enclosure through openings.

17. Damage Requiring Service - The appliance should be serviced by

qualified service personnel when:

A. The power supply cord or the plug has been damaged; or B. Objects have fallen, or liquid has been spilled into the appliance;

C. The appliance has been exposed to rain; or D. The appliance does not appear to operate normally or exhibits a

marked change in performance; or

E. The appliance has been dropped, or the enclosure damaged.

18. Servicing - The user should not attempt to service the appliance

beyond that described in the operating instructions. All other servicing should be referred to qualified service personnel.

Note to the CA TVsystem installer: This reminder is provided to call the CATV system installer's attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.

Example of Antenna Grounding as per NEC - National Electric Code

GROUND CLAMP

ELECTRIC SERVICE EQUIPMENT

ANTENNA LEAD IN WIRE

ANTENNA DISCHARGE UNIT

(NEC SECTION 810-20)

GROUNDING CONDUCTORS

(NEC SECTION 810-21)

GROUND CLAMPS

POWER SERVICE GROUNDING ELECTRODE SYSTEM

(NEC ART 250, PART H)

Introduction

Welcome/Registration of Your TV . . . . . . . . . . . . . . .2

Safety/Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Basic Cable TV Signal Connection . . . . . . . . . . . . . .5

Basic Antenna Signal Connection . . . . . . . . . . . . . . .6

Basic TV to VCR Connection . . . . . . . . . . . . . . . . . .7

Basic TV and Remote Operations . . . . . . . . . . . . . . .8

TV Remote Buttons . . . . . . . . . . . . . . . . . . . . . . . . . .9

Setup MENU

✧ Selecting the Menu Language . . . . . . .10

✧ Setting the Cable Control . . . . . . . . . . . . . . . .11

✧ Using the Auto Program Control . . . . . . . . . . .12

✧ How to Use the Channel Edit Control . . . . . . .13

Onscreen MENU

✧ Adjusting the TV Picture . . . . . . . . . . . .14

✧ Setting the TV for Closed Caption . . . . . . . . .15

✧ Using the Sleep Timer Control . . . . . . . . . . . .16

✧ Using the Volume Bar Control . . . . . . . . . . . .17

✧ Using the Alternate Channel Control . . . . . . .17

SmartLock™

✧ Understanding the SmartLock Feature . . . .18

✧ Setting the SmartLock Access Code . . . . . . . . .19

✧ Setting the Blocking Options . . . . . . . . . . . . . .20

✧ Block Programming Using Movie Ratings . . . .21

✧ Block Programming Using TV Ratings . . . . . .22

✧ Using the SmartLock Review Screen . . . . . . . .23

General Information

Troubleshooting . . . . . . . . . . . . . . . . . . . . .24

Glossary of TV Terms . . . . . . . . . . . . . . . . . . . . . . .25

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Factory Service Locations . . . . . . . . . . . . . . . . .26-27

Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

TABLE OF CONTENTS

NOTE: This owner's manual is used with several different television models. Not all features (and drawings) discussed in this manual will necessarily match those found with your television system. This is normal and does not require contacting your dealer or requesting service.

Here are a few of the special features built into this new Color Television:

SmartLock™ feature allows you to block the viewing of certain channel or external audio/video connections where you might not want your children viewing inappropriate material.

Infrared Remote Control works your TV set. Standard broadcast (VHF/UHF) or Cable TV

(CATV) channel capability. Closed Captioning allows the viewer to read TV

program dialogue or voice conversations as onscreen text.

Automatic Programming of Channels for quick and easy selection of favorite stations available in your area.

Onscreen Features (in either English or Spanish) show helpful messages for setting of TV controls.

Sleep Timer automatically turns the TV OFF at preset times.

SmartPicture™, SmartSound™, SmartSurf™, and SmartLock™ are all

registered trademarks of Philips Consumer Electronics Company.

our Cable TV input into your

home may be a single (75 ohm) cable, or a Converter Box installation. In either case the connection to the TV is very easy. Just put the threaded end of the cable signal to the TV's antenna plug and screw it down tight.

If your Cable TV signal is a sin-

gle round cable (75 ohm) then

you're ready to connect to the TV.

If you have a Cable Converter Box:

Connect the Cable TV signal to the Cable Signal IN(put) plug on the Converter.

Connect the Cable TV cable to

the 75Ω plug on the TV.

If you have a Cable Converter Box:

Connect the OUT(put) plug from the Converter to the 75Ω plug on the TV.

BASIC CABLE TV SIGNAL CONNECTION

BEGIN

CABLE TV

Cable TV Company

Cable TV Signal Input

Cable TV Converter

Box Connection

Round Cable

75Ω

Jack Panel

Remember: Set the TV for the type signal you've just connected. Refer to the Cable Control on page 11 to set the TV for cable tuning.

To select only the channel numbers on your Cable system refer to the Auto Program Control on page 12. If you use a Cable Converter box, set the TV to the same channel as the converter's CH 3/4 switch (on the rear of the converter.)

SMART

HELP

Back of TV

75 V

OUT

75 V

combination antenna receives

normal broadcast channels (VHF 2-13 and UHF 14-69). Your connection is easy since there is only one 75Ω (ohm) antenna plug on the back of your TV - and that’s where the antenna goes.

If your antenna has a round

cable (75 ohm) on the end, then

you're ready to connect it to the TV.

If your antenna has flat twin-lead wire (300 ohm), you first need to

attach the antenna wires to the screws on a 300 to 75 ohm adapter.

Push the round end of the

adapter (or antenna) onto the 75Ω plug on the rear of the TV. If the round end of the antenna wire is threaded, screw it down tight.

BASIC ANTENNA SIGNAL CONNECTIONS

BEGIN

ANTENNA

Remember: Be sure to set the TV for the type signal you've connected (see the “Cable” section on page 11 of this manual.)

To set the TV to select only the channel numbers in your area see how to “Program" or "Add" channels in the TV’s memory on page 12 (Auto Program section).

To order any optional accessory contact your dealer or the Philips Parts Center at 1-800-851-8885.

SMART

HELP

300 to 75Ω

Adapter

Combination VHF/UHF

Antenna

(Outdoor or Indoor)

Twin Lead

Wire

Round Cable

75Ω

Back of TV

Note: For homes with separate UHF and VHF antennas you will need an optional combiner to connect to the TV.

75 V

U/V

Combiner

75-300 Ohm Adapter

Back of TV

75 V

he basic Antenna, or Cable

TV, to VCR to TV connection

is shown below. For more information on other hookups (possible when Cable Converter/Descrambler boxes are included) refer to your accessory Device and Cable Converter Owner's Manual for details.

Connect your Antenna or Cable TV signal to the IN FROM ANT(enna) plug on the Accessory.

Connect the OUT TO TV plug

on the VCR to the 75Ω plug on the

TV (connecting cable supplied with the Accessory Device.)

BASIC TV TO VCR CONNECTION

BEGIN

TV TO VCR

Round Cable

75Ω Supplied with VCR

Outdoor

VHF/UHF

Antenna

300 to 75Ω

Ohm Adapter

Cable TV signal

Back of TV

VCR, Camcorder, DVD,

or an Accessory Device

IN FROM ANT.

OUT TO TV

75 V

Press the POWER button to

turn the TV ON.

Press the VOLUME + button to increase the sound level, or the VOLUME – button to lower the sound level.

Pressing both buttons at the same time will display the onscreen menu.

Once in the menu, use these button to make adjustments or selections.

Press the CHANNEL UP ▲ or DOWN ▼ button to select TV chan-

nels.

When operating the TV using the remote control, point the remote

toward the remote sensor window on the TV.

BASIC TV/REMOTE OPERATIONS

BEGIN

TELEVISION

o load the supplied batteries

into the remote:

1. Remove the battery compartment lid on the back of the remote.

2. Place the batteries (2-AA) in the remote. Be sure the (+) and (-)

ends of the batteries line up correctly (inside of case is marked.)

3. Reattach the battery lid.

BATTERY INSTALLATION

REMOTE

Point the remote control toward

the remote sensor window on the TV when operating the TV with the remote.

Remember, The tuned channel number will always briefly appear when the TV is first turned ON (and with channel changes.)

You can also press the STATUS/EXIT button (on the remote) to see what channel the TV is ON.

SMART HELP

– VOLUME +

POWER

CHANNEL

Remote Sensor Window

– VOLUME +

CHANNEL

POWER

CH+

CH–

A/CH

STATUS

VOL+

VOL–

EXIT

SLEEP

MUTE

TV REMOTE BUTTONS

Power Button

Press to turn the TV ON and OFF.

Number Buttons

Press the number buttons to select TV channels. For single digit entries, press the number of the channel you desire. The TV will pause for a few seconds, then change to the selected channel.

Channel (+), (–) Buttons

Press to change the tuned channel.

Volume (+), (–) Buttons

Press to adjust the TV sound level.

CC Button

Press to select Closed Caption options within the menu.

A/CH Button

Press to toggle between the currently viewed channel and the previously viewed channel.

Status/Exit Button

Press to see the current channel number and the Clock (if set) on the TV screen. Also press to clear the TV screen after control adjustments.

Cursor Buttons

Use these button to select and adjust the TV's onscreen menu.

Menu Button

Press for the onscreen menu to appear. Pressing the menu button after menu selections are made will eliminate the menu from the display.

Sleep Button

Press to set the TV to automatically turn itself OFF.

Mute Button

Press to turn the sound OFF on the TV. Press again to return the sound to its previous level.

A/CH

STATUS

EXIT

SLEEP

POWER

CH+

CH–

VOL+

VOL–

MUTE

+ 19 hidden pages
