Page 1
PI4010G
www.philips.com/welcome
User manual
Always there to help you
Register your product and get support at
Question?
Contact
Philips
Question?
Contact
Philips
Page 2
Page 3
1EN
Contents
1 Important safety instructions 3
Safety 3
Compliance 3
Care of the environment 4
Notice 4
Written Offer 4
2 Overview 6
Controls 6
Home screen 6
Use the drag-down menu of setup options 7
3 Get started 8
Charge power 8
Conserve battery power 8
Switch the device on or off 8
4 Basics 9
Find apps 9
Use the screen 10
Switch screen rotation on or off 10
Lock/ unlock the screen 10
Customize the Home screen 11
Add application icons and widget 11
Delete items 11
Relocate items 11
Add wallpapers 11
Text entry 11
Select input methods 11
Enter text 12
Use the Google Keyboard 12
Edit text 12
5 Connections 14
Connect to the Internet 14
Connect through Wi-Fi 14
Connect through the mobile
network 14
Connect to your computer 14
Use a Micro SD card 15
Connect to Bluetooth 15
Connect with Bluetooth devices 15
Send or receive les through
Bluetooth 16
Listen to music through stereo
Bluetooth headphones and
speakers 16
Connect to GPS 17
Portable hotspot 17
6 Apps 18
Install apps 18
Play Store 18
Other sources 18
Manage apps 18
7 Browser 20
Add a bookmark 20
8 Email 21
Set up your email account 21
Select account settings 21
Check your email messages 21
Compose email messages 22
Organize email messages 22
9 Tools 23
Camera 23
Take photos or record videos 23
Calendar 24
10 Use the device in corporate
networks 25
Install secure credentials 25
Set up your Microsoft Exchange account 25
Add VPN 25
11 Settings 27
SIM management 27
WIRELESS & NETWORKS 27
Wi-Fi 27
Airplane mode 27
VPN settings 27
DEVICE 27
Page 4
2 EN
Sound 27
Display 27
Storage 28
Battery 28
Apps 28
Location access 28
Security 28
Screen lock 28
Find Me Back 28
Visible passwords 29
Device administrators 29
Unknown sources 29
Language & input 29
Language 29
Personal dictionary 29
Voice Search 29
Text-to-speech output 29
Reset 30
ACCOUNTS 30
Date & time 30
Automatic setting 30
Manual setting 30
Accessibility 30
Auto-rotate screen 30
About tablet 30
System updates 30
Status and information about the
device 30
12 Checkforrmwareupdate 32
Update the rmware online 32
13 Technical data 33
14 Warranty 35
Need help?
Please visit
www.philips.com/welcome
where you can access a full set of supporting
materials such as the user manual, the latest
software updates, and answers to frequently
asked questions.
Page 5
3EN
1 Important safety
instructions
Safety
Only use attachments/accessories specied by
the manufacturer.
Use only power supplies listed in the user
manual.
The product shall not be exposed to dripping
or splashing.
Do not place any sources of danger on the
product (e.g. liquid lled objects, lighted
candles).
Batteries (battery pack or batteries installed)
shall not be exposed to excessive heat such as
sunshine, re or the like.
Where the plug of the Direct Plug-in Adapter
is used as the disconnect device, the disconnect
device shall remain readily operable.
Warning
• Never remove the casing of this apparatus.
• Never lubricate any part of this apparatus.
• Never place this apparatus on other electrical
equipment.
• Keep this apparatus away from direct sunlight, naked
ames or heat.
• Ensure that you always have easy access to the power
cord, plug or adaptor to disconnect the apparatus from
the power.
Hearing Safety
Warning
• To prevent possible hearing damage, do not listen at
high volume levels for long periods.
• Excessive sound pressure from earphones and
headphones can cause hearing loss.
The maximum output voltage of the player is
not greater than 150 mV.
Compliance
This product complies with the requirement of
the 1999/5/EC directive.
A copy of the EC Declaration of Conformity
is available in the Portable Document Format
(PDF) version at www.philips.com/support.
SAR statement
Your device is a radio transmitter and receiver.
It is designed not to exceed the limits for
exposure to radio waves (radio frequency
electromagnetic elds) recommended by
international guidelines. The guidelines were
developed by an independent scientic
organization (ICNIRP) and include a substantial
safety margin designed to assure the safety of
all persons, regardless of age and health. The
radio wave exposure guidelines use a unit of
measurement known as the Specic Absorption
Rate, or SAR. The SAR limit for mobile devices
is 2 W/kg.
Tests for SAR are conducted using standard
operating positions with the device transmitting
at its highest certied power level in all tested
frequency bands. The highest SAR values under
the ICNIRP guidelines for this device model are:
Maximum SAR for this model and conditions
under which it was recorded
Philips PI4010G (Body-worn) 0.571
W/kg
During use, the actual SAR values for this
device are usually well below the values stated
above. This is because, for purposes of system
efciency and to minimize interference on the
network, the operating power of your device
Page 6
4 EN
is automatically decreased when full power is
not needed. The lower the power output of the
device, the lower its SAR value.
Body-worn SAR testing has been carried out
at a separation distance of 1.5 cm. To meet
RF exposure guidelines during body-worn
operation, the device should be positioned at
least this distance away from the body.
If you are not using an approved accessory
ensure that whatever product is used is free of
any metal and that it positions the device the
indicated distance away from the body.
Note
• The type plate is located on the back of the product.
Care of the environment
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by a
specialized company. Please observe the local
regulations regarding the disposal of packaging
materials, and old equipment.
Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
When this crossed-out wheeled bin symbol is
attached to a product it means that the product
is covered by the European Directive 2002/96/
EC.
Please inform yourself about the local separate
collection system for electrical and electronic
products.
Please act according to your local rules and
do not dispose of your old products with your
normal household waste. Correct disposal of
your old product helps to prevent potential
negative consequences for the environment and
human health.
Your product contains batteries covered by
the European Directive 2006/66/EC, which
cannot be disposed with normal household
waste.Please inform yourself about the local
rules on separate collection of batteries
because correct disposal helps to prevent
negative consequences for the environmental
and human health.
Always bring your product to a professional to
remove the built-in battery.
Notice
Written Offer
WOOX Innovations hereby offers to deliver,
upon request, a copy of the complete
corresponding source code for the copyrighted
open source software packages used in this
product for which such offer is requested by
the respective licenses.
This offer is valid up to three years after
product purchase. To obtain source code,
please contact [email protected]. If you
prefer not to use email or if you do not receive
conrmation receipt within a week after mailing
to this email address, please write to Open
Source Team, 6/F, Philips Electronics Building, 5
Science Park East Avenue, Hong Kong Science
Page 7
5EN
Park, Shatin, New Territories, Hong Kong. If you
do not receive timely conrmation of your
letter, please email to the email address above.
This product is partly based on Open
Source software. The license text and
acknowledgment can be retrieved from
the device under > About tablet > Legal
information.
Specications are subject to change without
notice. Philips and the Philips’ Shield Emblem
are registered trademarks of Koninklijke Philips
N.V. and are used by WOOX Innovations
Limited under license from Koninklijke Philips
N.V.. WOOX Innovations reserves the right
to change products at any time without being
obliged to adjust earlier supplies accordingly.
Page 8
6 EN
2 Overview
Controls
a Power/ lock button
• Press and hold: switch on or off the
device.
• Press: lock/unlock the screen; To unlock
the screen, drag the lock to an icon.
• Reset: press and hold the button for 10
seconds.
b ,
• Press: increase/decrease the volume.
• Press and hold: increase/decrease fast.
c Speaker
d
• Slot for Micro SD card
• Slot for SIM card
e Rear camera lens (2.0 MP)
f
• 3.5-mm headphone connector
g Front camera lens (0.3 MP)
h
• USB connector for data transfer and
power charging
c
b
a
i
h
d
e
f
g
i
• Microphone
Home screen
a APPS/WIDGETS: List all apps or
widgets.
Settings: Customize the settings of
PI4010G.
Chrome:Web browser of Google
b : Tap to return to the Home screen.
: Go back one level.
: Display recent applications that you
have accessed.
(for some apps): View the options menu.
c Google Search
• : Use the quick search box to search
on PI4010G or the Web.
• : Google voice search
d Notications
• Drag down the bar to check the event.
e Time, battery level, setup options
• Drag down the bar to check battery
level or select setup options.
a
b
cd e
Page 9
7EN
Use the drag-down menu of
setup options
1 Drag down the top bar as shown.
2 Tap the icon to select your options.
• Battery charging underway
• Switch to the settings menu
• Switch on or off Wi-Fi
• Switch on or off Bluetooth
• Switch on or off GPS
• Switch on or off the data connection
through the mobile network
Make sure that you have mount your
SIM card onto PI4010G to access the
mobile network.
• Switch on or off the airplane mode.
When the airplane mode is on, the
access to Wireless connection is
disabled.
• Change the screen brightness
• Change your option for the screen-off
timer
/
• Switch screen rotation on or off
• Enable or disable the device to
work as the hotspot for the Internet
connection through the mobile
network.
Page 10
8 EN
3 Get started
Charge power
PI4010G has a built-in battery that can be
charged through the USB connector of the
supplied USB power adapter.
• By using the USB cable, connect PI4010G
to the supplied USB power adapter.
Note
• Rechargeable batteries have a limited number of charge
cycles. Battery life and number of charge cycles var y by
use and settings.
Conserve battery power
• To conserve battery power and increase
the play time, do the following:
Use the sleep mode
After the selected time duration, PI4010G goes
to the sleep mode, and the screen switches
off automatically. To save battery power, do the
following:
• Go to > Display > Sleep to set the
screen-off timer to a low value.
• To switch off Wi-Fi during the sleep mode,
a Go to > Wi-Fi.
b At the top bar, select > Advanced
> Keep Wi-Fi on during sleep. Select
Nev e r.
Switch the device on or off
Press and hold the power/ lock button to
switch the device on or off.
POWER
Page 11
9EN
4 Basics
Find apps
Navigate on the Home screen to nd an app:
• Swipe left/ right to select a page;
• Alternatively, tap to open the list of
apps. Swipe left/ right to scroll through
the list;
• Use the navigation buttons /
to switch between screens. Tap to
go to the apps that you have accessed
recently.
Tip
• On PI4010G, you can install apps from the Play Store
or other sources.
Play Store:
• Download different apps, games, and
others.
Settings:
• Customize the settings of PI4010G.
Play Music:
• Play music that you store on PI4010G.
• Online music service of Google
Gallery:
• View pictures and videos that you
store or make on PI4010G.
Camera:
• Take photos or record videos.
Play Movies & TV:
• Online movie & TV service of Google
(available in some countries)
YouTube:
• Online video service of Google
Deezer:
• Online music service (available in some
countries)
Play Books:
• Online book service of Google
(available in some countries)
/
Google+/ Orkut:
• Social networking service of Google
Hangouts:
• Chat service of Google
Blogger:
• Blogger service of Google
Browser:
• Browse Web pages.
Chrome:
• Web browser of Google
Google Search:
• Search on PI4010G or the Web.
Voice Search
• Voice search and voice action services
of Google
Maps:
• Maps service of Google
Earth:
• Satellite view of maps (available in
some countries)
• Email:Set up your email account on
PI4010G.
Gmail:
• Mail service of Google
Downloads:
• View the list of your downloads from
the Web.
Page 12
10 EN
ES File Explorer:
• Browse the les/ folders on PI4010G,
install apps, and manage les.
KingsoftOfce:
• Create and manage your document,
text, Powerpoint and Excel les.
Drive:
• Cloud storage service of Google
Translate:
• Online language translation service of
Google
Calendar:
• Add events, and set reminders for your
events.
Keep:
• Keep quick notes.
Clock:
• Use the timer, alarm clock, and
stopwatch.
Calculator
Sound Recorder:
• Record and listen to voice messages.
AccuWeather:
• Online weather forecast service
Use the screen
Switch screen rotation on or off
1 Drag down the top bar.
2 In the pull-down menu, tap / to
switch screen screen rotation on or off.
Lock/ unlock the screen
By locking the screen, you can lock all the
touch controls on the screen. Thus, undesired
operations are prevented.
Auto lock
After a time duration, the screen dims and is
locked automatically. To set the time duration,
go to > Display > Sleep.
To lock the screen manually
• Press the power/ lock button.
To unlock the screen
1 If necessary, press the power/ lock button
to display the lock.
2 Drag the lock to unlock.
Page 13
11EN
Customize the Home screen
To access functions quickly from the Home
screen, you can add and rearrange items.
Add application icons and widget
1 Swipe left/ right to select a page.
• If necessary, tap to return to the
Home screen.
• Make sure that the page isn't lled.
• Tap . Tap APPS or WIDGET to open
the list of apps or widgets.
2 Tap and hold an icon or widget until the
page is displayed.
» The icon or widget is added to the
selected page.
Delete items
1 Tap and hold an item to unlock.
2 Drag the item to .
Relocate items
1 Tap and hold an item to unlock.
2 Drag the item to a space on the page.
3 Release the item.
» The item moves to the space.
Add wallpapers
1 From the Home screen, go to > Display
> Wallpaper.
2 Select your options.
Text entry
With the onscreen keyboard, you can enter
text in multiple languages.
Select input methods
1 From the Home screen, select Settings
> Language & input.
2 Select your input methods:
Google Keyboard: for multiple languages
Google voice typing: for text input through
voice
3 To select your input options, tap next to
the input method.
Page 14
12 EN
Enter text
1 Tap the text box to show the onscreen
keyboard.
2 Tap on the keys to enter text.
To delete the entry before the cursor,
• Select .
To move to the next line,
• Select .
Use the Google Keyboard
Select keyboard settings or input
languages
• On the onscreen keyboard, tap .
Switch between selected input
languages
1 Add to the option list the languages that
you often use.
a On the onscreen keyboard, tap
>Input languages.
b Tap the checkbox to select languages.
2 On the onscreen keyboard, tap and hold
to select a language.
Switch between letters and numbers/
symbols
• Tap or .
Tip
• On the numeric/symbol keyboard, tap ~\{ to switch
between numbers/symbols and more symbol choices.
Switch between upper and lower cases
• Tap repeatedly to switch between
and .
: The next letter you enter is in upper
case.
: All letters you enter are in lower case.
To switch to the input mode of all upper
cases,
1 Tap and hold or .
» The button changes to blue.
2 When a click sounds, release the button.
» is displayed.
» All letters you enter are in upper case.
Switch to other options on a button
• Tap and hold the button that is marked
with a symbol at the lower/upper right
corner.
» A pop-up screen is displayed.
Edit text
You can cut, copy, and paste the text that you
have entered.
Copy or cut the selected text
1 Tap and hold the text until the pop-screen
is displayed.
Page 15
13EN
» Current word is selected, with marks
for start and end positions.
2 Drag the marks to select or change the
start/ end positions.
• Tap Select all to select all the text.
3 Tap Copy or Cut.
» The selected text is copied or cut.
Paste the selected text
1 Put the cursor in a position.
2 Tap and hold the position until the pop-
screen is displayed.
» In the pop-up screen, the option Paste
is displayed.
» Tap Paste.The text is pasted in the
selected position.
Page 16
14 EN
5 Connections
Connect to the Internet
You can connect PI4010G to the Internet
through Wi-Fi or mobile network.
Connect through Wi-Fi
Connect PI4010G to a wireless router (Access
Point). You can connect PI4010G to the
network that is built around the router.
To connect to the Internet, make sure that the
router connects to the Internet directly and no
dial-up is required on the computer.
1 From the Home screen, tap Settings >
Wi-Fi.
2 Select the option to switch on the Wi-Fi
function.
» You see a list of Wi-Fi networks in
range.
3 Connect PI4010G to a network:
a Tap to select a network.
b On the pop-up screen, enter the
password to the network.
» is displayed in the status bar
when the Wi-Fi connection is
completed successfully.
» Next time you switch on
PI4010G, PI4010G connects to
the previously connected network
automatically.
Note
• If MAC address ltering is enabled on your router, add
the MAC address of PI4010G to the list of devices that
are allowed to join the network. To nd the Wi-Fi MAC
address, go to Settings > About tablet > Status on
the Home screen.
• To refresh the list of networks, select > Scan at the
upper-right corner of the screen.
• If you have disabled SSID broadcasting or hidden the
Service Set Identier (SSID) of the router, manually
enter the SSID or public name for the network. Go to
Settings > Wi-Fi. On the top bar, select .
• If the DHCP (Dynamic Host Conguration Protocol)
is unavailable or disabled on the router, manually enter
the IP address of PI4010G.
Connect through the mobile network
With your SIM card, you can connect PI4010G
to the Internet through the mobile network.
Consult your service provider for more
information.
1 Mount your SIM card onto PI4010G.
2 On the drag-down menu, tap to switch
on .
Connect to your computer
Connect PI4010G to a computer through the
USB cable.
Page 17
15EN
You can transfer apps or media les from your
PC to PI4010G,the internal storage or SD card.
Use a Micro SD card
Insert a Micro SD card (up to 32 GB) into
PI4010G. You can expand the memory size of
PI4010G.
Connect to Bluetooth
Through Bluetooth, you can do the following
wirelessly on PI4010G:
• Receive or send les from or to
another connected Bluetooth device;
• Listen to music through stereo
Bluetooth headphones;
• Listen to music through Bluetooth
speakers, like Philips SHOQBOX.
Connect with Bluetooth devices
You can connect PI4010G with Bluetooth
devices in the following ways:
• Connect another Bluetooth device;
• Get connected by another Bluetooth
device.
Tip
• Before the connection, consult the user manual of the
Bluetooth device to get its Bluetooth pairing passcode.
Or, try 0000 or 1234.
Connect another Bluetooth devices
1 Make sure that the device is discoverable
by another Bluetooth device.
• Consult the user manual of the
Bluetooth device for information.
2 On PI4010G, search for the Bluetooth
device:
a From the Home screen, tap
Settings > Bluetooth.
b Select the option to switch on
Bluetooth.
» is displayed on the status bar.
c Tap SEARCH FOR DEVICES.
» The device is displayed under
AVAILABLE DEVICES after it is
discovered.
3 Pair with the device:
• On PI4010G, tap the device, and enter
the passcode as prompted;
• On the device, enter the passcode as
prompted.
Page 18
16 EN
» A message is displayed when the
pairing is complete.
Get connected by another Bluetooth
devices
1 Make sure that PI4010G is discoverable by
another Bluetooth device:
a From the Home screen, tap
Settings > Bluetooth.
b Select the option to switch on
Bluetooth.
c Tap PI4010G.
» *PI4010G is discoverable for two
minutes.
2 On the Bluetooth device, search for and
pair with PI4010G.
• For information about the steps,
consult the user manual of the
Bluetooth device.
Tip
• * To change the device name of PI4010G, go to
Settings > Bluetooth, tap and select Rename tablet.
Sendorreceivelesthrough
Bluetooth
Send les to another Bluetooth device
1 Make sure that
• you have paired PI4010G with the
Bluetooth device;
• on PI4010G and Bluetooth device,
Bluetooth is on.
2 On PI4010G, send les through Bluetooth:
a In Gallery, play a photo. Tap >
Bluetooth.
b Tap the paired device to start sending.
» When sending or receiving is in
progress, is displayed at the top
of the screen.
3 On the Bluetooth device, receive the les:
• Conrm as prompted.
• Save the les as prompted.
Receive les from Bluetooth device
1 Make sure that
• you have paired PI4010G with the
Bluetooth device;
• on PI4010Gand Bluetooth device,
Bluetooth is on.
2 On the Bluetooth device, send les to
PI4010G through Bluetooth.
3 On PI4010G, receive the les:
• At the top of the screen, tap .
Conrm as prompted.
» You can also nd the received
les in Settings> Bluetooth. Tap
and select Showreceivedles.
Listen to music through stereo
Bluetooth headphones and speakers
Connect the stereo Bluetooth headphones or
speakers
» Follow the steps under"Connect
another Bluetooth device".After
successful connection, is
displayed .
» Next time you switch on
Bluetooth on the devices, the
Bluetooth connection is established
automatically.
Listen to music through the stereo Bluetooth
headphones or speakers
• Play music on PI4010G.
» You listen to the music through the
connected Bluetooth headphones
or speakers.
Page 19
17EN
Connect to GPS
To access location services, switch on the GPS
function to connect to GPS (Global Positioning
System).
• From the Home screen, tap Settings >
Location access > Access to my location.
Switch on GPS satellites.
• Alternatively, use the drag-down menu
to switch the GPS function on or off
(see 'Use the drag-down menu of setup
options' on page 7).
Portable hotspot
PI4010G can work as a Wi-Fi hotspot. Through
PI4010G, you can have your wireless devices
connected to the Internet.
To connect to the Internet through PI4010G,
1 Connect PI4010G to the Internet through
the mobile network.
2 In More... > Tethering & portable hotspot,
switch on Wi-Fi hotspot.
3 Tap Wi-Fi hotspot to select Set up Wi-
Fi hotspot. You can check and edit the
network name (SSID) and password.
4 On your wireless devices, search for and
connect to PI4010G.
Page 20
18 EN
6 Apps
With apps, you can access functions, services,
and different audio/ video content on PI4010G.
Install apps
On PI4010G, you can install apps from
• (Play Store) over the Internet; or
• other sources, such as
other online sources,
the internal storage of PI4010G, and
the Micro SD card that you have
inserted into PI4010G.
Play Store
1 Log in to or create your Google account
to access Google services.
To add a Google account, do the following:
a Go to (Play Store). Tap >
Accounts.
b Select Add account.
c Follow onscreen instructions to add
an account.
2 Search for apps as needed.
• Tap for keyword search.
3 Download the app:
• Tap the app. Conrm as needed.
» When the downloading is
complete, installation starts
automatically.
» Check the status bar to nd the
status. If necessary, tap the icon to
start installation as prompted.
Tip
• To manage your accounts, go to Settings >
ACCOUNTS. Tap an account to select your options.
Other sources
Allow the installation from unknown sources
• From the Home screen, go to >
Security. Tap to switch on Unknown
sources.
» If the function is enabled, the tick
box is selected.
Download/ transfer apps
• To download apps from online sources,
follow the onscreen instructions;
• To transfer apps to the internal
memory or SD card of the device, use
the USB cable to connect PI4010G to
your PC.
Start installation
• The downloaded apps start installation
automatically;
• To nd the apps that you have
transferred to the internal memory or
SD card, go to . Find the apps and
tap the option to start installation.
Manage apps
You can manage the apps on PI4010G, for
example, install/ uninstall apps, stop running
apps, or select other options.
1 From the Home screen, select Settings
> Apps:
Page 21
19EN
• In DOWNLOADED, nd the apps
that you have downloaded from the
Play Store or other sources.
• In RUNNING, nd the apps that are
running on PI4010G.
• In ALL, nd all the apps that you have
installed on PI4010G.
2 Tap an app.
» Options and information are displayed.
3 Tap to select an option.
Page 22
20 EN
7 Browser
With , you can browse Web pages.
1 From the Home screen, tap .
2 Tap the icons or text box to do the
following:
a Enter the address of web pages. Tap
to start search.
b Tap the icons to search backwards,
forward, or refresh the Web page.
c Close the Web page.
d Open a new Web page.
To switch between Web pages,
• At the top bar, tap the tab of the selected
Web page.
Add a bookmark
Add a bookmark. You can quickly access a
visited Web page.
ab c d
a Add a bookmark to current Web
page.
b Go to the bookmarked Web pages.
a
b
Page 23
21EN
8 Email
On PI4010G, you can receive and send email as
you do on a computer. Do the following:
• Set up your email accounts on the
device.
Set up your email account
On PI4010G, set up your email accounts in the
following ways:
• Set up your POP3 or IMAP mail
accounts, or
• Set up your Microsoft Exchange
account to access your Exchange
mailbox at work (see 'Set up your
Microsoft Exchange account' on page
25).
Set up your POP3/ IMAP account
1 From the Home screen, go to .
2 Set up your email account:
• Enter the information about your
account;
• Select pop3 or IMAP account.
3 Follow the onscreen instructions to
complete the setup.
• Consult your email service provider
for the setup information, such as the
outgoing server, incoming server.
Select account settings
1 On the screen of mail list, tap > Settings.
» A pop-up screen is displayed.
• If necessary, tap repeatedly to
return to the screen of mail list.
2 Select your options for the account.
To add an account,
• On > Settings, tap Add account.
To remove an account,
• On > Settings, select Remove account.
» Current account is removed.
Check your email messages
You can check your email messages in the
following ways:
• Check one combined mailbox;
Page 24
22 EN
• Check messages by account;
• Check starred messages;
• Check unread messages.
To check one combined mailbox,
1 On the screen of mail list, tap the account
name.
» A drop-down list of account names is
displayed.
• If necessary, tap repeatedly to
return to the screen of mail list.
2 Tap Combined view.
» Different colors are used to mark the
messages from different accounts.
To check messages from a single account,
1 Repeat Step 1 in "To check one combined
mailbox".
2 Tap the selected account.
» Messages from the account are
displayed.
To check starred messages,
• Tap the star next to the message.
» The message is added to the Starred
folder.
To check unread messages,
• On the screen of mail list, the unread
messages are in white.
Compose email messages
a
b c d
When you read a message, tap the icons to do
the following:
a Compose a new message
b Reply
c Reply all
d Forward
Organize email messages
1 On the screen of mail list, select messages
you want to manage:
• Tap the check boxes next to the
messages.
» Selected messages are highlighted.
2 Tap the icons to do the following:
a Delete the messages.
b Move the messages to the selected
folder.
c Mark the messages as read or unread.
d Add the messages to the Starred
folder.
a
b
c
d
Page 25
23EN
9 Tools
Camera
With the 0.3 and 2.0 Mega-pixel lens at the
front and back respectively, you can do the
following on PI4010G:
• Shoot photos or videos by using the
camera or video recorder;
• Through apps, video chats with friends
over the Internet.
Take photos or record videos
a Selector for camera, video recorder, or
panorama mode
b Shutter
c Options menu
1 From the Home screen, go to .
» The onscreen buttons are displayed.
2 Tap , , or to switch to the camera,
video recorder, or panorama mode.
3 Tap > to switch to the camera lens
at the front or back.
4 To take photos:
a Point the lens at objects.
b Ta p .
c The photo is taken.
To record videos:
c
b
a
• Tap / to start or stop video
recording.
To take a panoramic picture:
a Point the lens at the view.
b Ta p to start shooting.
c Sweep through the view by moving
the device slowly and steadily.
» When the progress bar comes
to the end, the shooting stops. A
panoramic picture is generated.
To view photos/ videos
• Go to Gallery.
Select settings
Tap to display the options menu:
• Tap to select your options for the
camera or video recorder.
• Tap to select an exposure value
according to the lighting conditions.
• Drag around the circle to select
a scene suitable to your shooting
environment.
Page 26
24 EN
Calendar
On the device, you can sync the calendar with:
• the calendar of your Microsoft
Exchange account (see 'Set up your
Microsoft Exchange account' on page
25).
Page 27
25EN
10 Use the device
in corporate
networks
You can use PI4010G in corporate networks.
Install the secure credentials or security
certicates before you access corporate
networks.
The access to corporate network may allow
you to set up your Microsoft Exchange account
and add VPN on the device. With the Microsoft
Exchange account, you can access your
exchange mailbox at work.
Install secure credentials
Ask your network administrator for secure
credentials or security certicates.
To install the secure credentials,
1 Make sure that you transfer the les of
secure credentials from a PC to the SD
card that you have mounted onto the
device.
Note
• On PI4010G, make sure that the secure credentials are
saved to the root directory of the SD card, instead of
under a folder.
2 Install the secure credentials:
a From the Home screen, go to >
Security > Install from SD card.
b Taptheletostartinstallation.
c Set the password and name for the
credentials as prompted.
To apply the secure credentials,
1 In , select Security > Trusted credentials.
2 Make sure that the credential is selected.
» If the function is enabled, the tick box
is selected.
» On the device, you allow the
applications to use the secure
credentials.
Set up your Microsoft
Exchange account
1 From the Home screen, go to .
2 Set up your email account:
• Enter the information about your
account, and select Exchange as the
account type.
• If you have set up other email
accounts, select > Settings on the
screen of mail list. Tap Add account.
3 Follow the onscreen instructions to
complete the setup.
• For the server address, enter the web
address for your Outlook web access,
for example, owa.company name.com
or mail. company name.com/owa.
• For other setup information, such as
domain name, user name, check with
your system administrator.
Note
• The device can work with Microsft Exchange 2003
and 2007.
Add VPN
Virtual private network (VPN) allows you to
connect to private networks through secure
access.
Sometimes, you need VPN access to connect to
corporate networks.
To add VPN on the device
Page 28
26 EN
1 Ask your network administrator for the
conguration information.
2 From the Home screen, go to >
Wireless & networks > More > VPN.
3 Congure the VPN as prompted.
4 Install the secure credentials as needed
(see 'Install secure credentials' on page 25).
To connect to the VPN,
1 Make sure that you have connected
PI4010G to the Internet.
2 From the Home screen, go to >
Wireless & networks > More.
» A list of VPNs is displayed.
3 Tap the VPN to start connection.
Page 29
27EN
11 Settings
To select your settings,
1 Go to from the Home screen.
2 Swipe up or down to scroll through lists of
options.
3 Tap an option to select it.
SIM management
In SIM management, check or select the settings
of your SIM card.
WIRELESS & NETWORKS
Wi-Fi
In WIRELESS & NETWORKS > Wi-Fi, select
your Wi-Fi settings on the device (see 'Connect
through Wi-Fi' on page 14).
Add Wi-Fi network
Enter SSID manually
SSID (Service Set Identier) is the name of a
router. By the name, the router is recognized by
other Wi-Fi devices. If you have hidden the SSID
of the router (for example, disable the SSID
broadcasting), the router is invisible in the list of
available networks. To connect PI4010G to the
router, enter the SSID of the router manually
before you search for available networks on the
PI4010G.
1 In Wi-Fi, drag the slider to switch on Wi-Fi.
2 On the top bar, tap .
3 Enter the SSID of the router.
» The PI4010G starts searching for the
network.
» You can nd the network in the list of
networks.
4 Connect PI4010G to the network.
Network notication
Switch on Networknotication. At the base of
the screen, is displayed when an open Wi-Fi
network is available.
1 In Wi-Fi, drag the slider to switch on Wi-Fi.
2 At the top bar, tap and select Advanced
> Networknotication.
Airplane mode
Switch on the airplane mode when:
• you need to disable the access
to wireless connection for safety
purposes, such as on an airplane.
In WIRELESS & NETWORKS, select More >
Airplane mode. You can disable or enable the
access to wireless connection.
VPN settings
Use VPN settings to access private networks,
such as corporate networks (see 'Use the
device in corporate networks' on page 25).
DEVICE
Sound
In Sound, select sound settings for your device.
Volume Drag the slider to select
the volume level for media,
notications, and alarms.
Notication
Sound
Set an audio le as ringtone.
Touch
sounds
Sounds play when you tap on
the screen.
Screen lock
sound
Sounds play when you lock/
unlock the screen.
Display
In Display, select your display settings:
Lockscreennotications
Page 30
28 EN
• Switch on to show notications on the
lock screen.
Wallpaper
• Set the wallpaper of the device.
Auto-rotate screen
• Tap to switch on or off screen rotation.
Brightness
• Drag the slider to change the display
brightness.
Daydream
• Select your screen saver options: what
screen saver to display and when to
display the screen saver. When the
screen saver is on, tap on the screen
to exit.
Font size
• Select font size for the on-screen
display.
Sleep
• After the selected time duration, the
screen switches off automatically. To
save battery power, select a low value.
Storage
In Storage, learn the space information about
the internal storage and SD card on your
PI4010G.
Battery
In Battery, check the battery use by
applications.
Apps
In Apps, manage the apps on the internal
storage of PI4010G (see 'Manage apps' on page
18).
Location access
• In Access to my location, switch on or off
the options.
» If the function is enabled, the tick box
is selected.
» You can allow or disallow your location
information to be used in online
location services of Google, such as
Maps, or other relevant services and
applications.
• In GPS satellite, switch on to use the
location services that requires GPS
assistance.
Security
Screen lock
By default, to unlock the screen of PI4010G,
press the power/ lock button and then, drag the
lock to an icon.
In Screen lock, you can set a pattern, pin, or
password as the unlock security. To unlock the
screen, such unlock security is required.
None Switch off the lock.
Slide Slide to unlock the screen
(default).
Pattern Set a pattern as the unlock
security.
PIN Set a PIN that consists of
numbers.
Password Set a password that consists of a
combination of numbers, letters,
and symbols.
Find Me Back
With the Google service, locate the device and
protect your personal data when PI4010G is
lost.
Page 31
29EN
Visible passwords
Your password consists of several characters. To
make sure that you have entered the characters
correctly, show the characters as you type the
password. Switch Make passwords visible on or
off as needed.
• Tap the tick box.
» If the function is enabled, the tick
box is selected.
Device administrators
Applications in corporate networks require the
rights of device administrator, such as the email
and calendar under your Microsoft Exchange
account.
Before you uninstall such an application, disable
the rights of device administrator.
• In Device administrators, tap an
application.
» The rights of device administrator are
disabled.
» You cannot sync data for the
application.
Unknown sources
On PI4010G, you can install applications that
you download from (Play Store), or from
sources other than .
• For the applications from sources
other than , tap Unknown sources
to allow installation on the PI4010G.
» If the function is enabled, the tick
box is selected.
Language & input
Language
In Language, select the language for the
onscreen instructions of PI4010G.
Personal dictionary
In Personal dictionary, add or remove words
or phrases to/ from the user dictionary. You
can customize the word suggestions that are
displayed on the pop-up screen during your
text entry on the Google keyboard.
To add a word or phrase,
• Tap to add a word or phrase.
To edit a word or phrase,
1 Tap on the word or phrase.
» A pop-up screen is displayed.
2 Edit the word or phrase.
To remove a word or phrase,
• Tap next to the word or phrase.
Voice Search
In Voice Search, select your options for Google
Voice Search.
Text-to-speech output
In Text-to-speech output, select your options
for:
• voice output for the accessibility
function on the device.
Install voice data
Download the voice data for speech synthesis.
1 Connect the device to the Internet.
2 Select your preferred text-to-speech
engine. Tap > Install voice data.
» Select and download the voice data.
Select your options for the voice output
1 In Speech rate, select a speed at which the
text is read, normal, fast, or slow.
2 Tap Listen to an example.
» Your options are used to play the
demo of speech synthesis.
Page 32
30 EN
Reset
In Backup & reset > Factory data reset, you
can erase all the data that you have stored on
the internal storage of PI4010G.
ACCOUNTS
In ACCOUNTS, add, remove, or manage an
account.
• Tap Add account to add an account.
• Tap an account to manage the account,
for example, remove the account or
select sync options.
Date & time
Automatic setting
Over the Internet, you can sync the date and
time on PI4010G from Philips online services.
To switch on the automatic clock setting,
1 In Date & time, tap to switch on
Automatic date & time.
» If the function is enabled, the tick
box is selected.
2 In Select time zone, select your current
time zone.
3 In Use 24-hour format and Select date
format, select your options for time and
date display.
Manual setting
1 In Date & time, tap to switch off
Automatic date & time.
» If the function is disabled, the tick box
is deselected.
2 Tap to set date, time, and time zone in Set
date, Set time, and Set time zone.
• To select a date, tap the date in the
calendar.
Accessibility
With the accessibility function, actions on the
screen of the device are read out through
the text-to-speech technology, such as the
taps, selection of menu items. For people who
cannot read the screen clearly, the function
allows them to use the device in an easier way.
Use the accessibility function
1 Tap TalkBack to switch on.
2 In Text-to-speech output, select your
options for voice output (see 'Text-tospeech output' on page 29).
Auto-rotate screen
In Auto-rotate screen, tap to switch on or off
screen rotation.
About tablet
In About tablet, learn the status and
information about your PI4010G.
System updates
In System updates, check for the system
updates of PI4010G. Make sure that you have
connected the device to the Internet.
Status and information about the
device
In Status,
• Battery status: Display the status of
power charging.
• Battery level: Display remaining power
by percentage.
• IP address: Display the IP address
that is assigned to PI4010G when the
device is connected a Wi-Fi network.
Page 33
31EN
• Wi-Fi MAC address: Display the
unique identier that is assigned to
the network adapter of PI4010G. If
MAC address ltering is enabled on
your router, add the MAC address of
PI4010G to the list of devices that are
allowed to join the network.
• Bluetooth address: Display the
Bluetooth address of PI4010G when
the Bluetooth function is switched on.
Legal information: Legal information for
PI4010G
Model number: Model no. of the device
Android version:Firmware version of the
Android platform that the deviceis running on
Build number: Software version of PI4010G
Page 34
32 EN
12 Check for
firmware update
Connect PI4010G to Wi-Fi. You can receive
notications about rmware updates. Drag
down the top bar to check the notications.
Updatethermwareonline
On PI4010G, you can update the rmware
through our online services over the Internet
(see 'System updates' on page 30).
Page 35
33EN
13 Technical data
Power
• Power adapter
CBA0015AK2C1
Input: 100-240 V~ 50/60 Hz, 0.5 A
Output: DC 5.0 V, 2 A
• Power supply: 3,240 mAh Li-ion polymer
internal rechargeable battery
• Play time¹
video streaming through Wi-Fi: 2 hours
Operating temperature
• 0°C to 45°C
Storage temperature
• -10°C to 60°C
Display
• Type: LCD Touch-sensitive screen
• Diagonal screen size (inch): 8
• Resolution: 1024 x 600 pixels
Platform
Android™ 4.2.2
Connectivity
• Headphone: 3.5 mm
• USB: 2.0 High speed, Micro type
• Wireless LAN: Wi-Fi 802.11 b/g/n
• Mobile network
GPRS/ EDGE (850, 900, 1800, 1900 MHz)
HSPA+ (900, 2100 MHz)
• Bluetooth
Bluetooth proles: A2DP, AVRCP, Object
push prole
Bluetooth version: 2.1+EDR
• GPS
Headphone sound
• Channel separation: > 45 dB
• Frequency response: 60-18,000 Hz
• Output power: 2 x 5 mW (maximum)
• Signal to noise ratio: > 80 dB
Speaker sound
• Frequency response: 100-15,000 Hz
• Output power: 600 mW
• Signal to noise ratio: > 60 dB
Audio playback
• Supported formats:
WAV, MP3, AAC /. m4a, OGG Vorbis, 3GPP,
AMR-NB (mono), AMR-WB (stereo),
FLAC,
MIDI (Type 0 and 1 (.mid, .xmf,.mxmf)),
RTTTL/RTX (.rtttl, .rtx), OTA (.ota), and
iMelody(.imy)
Audio capturing
• AMR-NB
Bitrate: 4.75 to 12.2 kbps
Sampling rate: 8 kHz
File supported: 3GPP (.3gp)
• Specied
Bitrate: 128 kbps
Sampling rate: 44.1 kHz
File format: MP3
• Built-in microphone: mono
Video playback
• Supported formats:
MPEG-4 (.3gp), H.264 AVC (3gp, .mp4),
H.263 (3gp, .mp4), VP8 (.webm, .mkv),
RMVB (.rm, .rmvb)
Video capturing
• H.264 Aspect ratio (4:3 or 16:9 selectable)
• Video resolution: VGA (640 x 480)
• Frame rate: 30 frames per second
• Container: .mp4
• Audio format: MP3
• Lens: Fixed focus length
• Recording time: Depending on the storage
Still picture playback
• Supported formats:
JPEG, BMP, PNG, GIF
Still picture capturing
• Picture resolution: VGA (640 x 480)
• Picture format: JPEG, PNG
• Lens: Fixed focus length
Storage media
• Built-in memory capacity²:
8 GB NAND Flash
• External storage:
Micro SD memory card slot (Maximum
memory card capacity: 32 GB)
Preloaded applications
• Play Store, Google Search, Voice Search,
Chrome, Maps, Earth (available in some
countries) Google+, Blogger, Gmail,
Hangouts, Drive, Orkut,Youtube, Play
Page 36
34 EN
Movies & TV(available in some countries),
Play Music, Play Books(available in some
countries), Translate
• Browser, Gallery, Movie Studio, Camera,
Email, Calendar, Clock, Calculator
• ES File Explorer, Deezer (available in some
countries), AccuWeather
Note
• ¹ Rechargeable batteries have a limited number of
charge cycles. Battery life and number of charge cycles
vary by use and settings.
• ² 1GB = 1 billion bytes; available storage capacity is less.
Full memory capacity may not be available as some
memory is reser ved for the device. Storage capacity
is based on 4 minutes per song and 128 kbps MP3
encoding.
Page 37
35EN
14 Warranty
Any of the following misuse conditions seen or
perceived on this device may void the user’s
warranty of this device:
• Defects or damages resulting from
abnormal use of the product by the
customer, such as plastic surfaces and
other externally exposed parts scratched,
cracked or broken, clean disagree with the
operating instructions, as well as spill food
or liquids of any kind;
• Defects or damage resulting from testing,
installation, alteration, modication of
any kind in our products as well as repair
workshops conducted by an unauthorized
technical assistance;
• Breakage or damage were not observed
upon acquisition (cabinet, cables, screen,
etc..);
• Products which have had the serial number
removed, adulterated or made illegible;
• Defects and damage resulting from the use
of components not compatible with Philips
brand ; (cabinet, cables, cards, power supply,
general parts, etc..);
• Defects and damage caused by natural
agents (ooding, salt spray, and other
electrical discharge) or exposure to
excessive heat;
• Defects or damage caused by the use
of software and (or) hardware not
compatible with the specications of Philips
products;
• Parts that wear out with regular use, such
as cables, battery, buttons, etc.;
• Incidents of accidental damage, such as falls,
misuse, contact and/or immersion with
liquid.
Page 38
Specifications are subject to change without notice
2014 © WOOX Innovations Limited. All rights reserved.
Philips and the Philips’ Shield Emblem are registered trademarks of
Koninklijke Philips N.V. and are used by WOOX Innovations Limited
under license from Koninklijke Philips N.V. PI4010G_58_UM_V1.0_WK1413.5
Loading...
