PEMB1; PUMB1

PNP/PNP resistor-equipped
transistors; R1 = 22 kΩ, R2 = 22 kΩ

Product data sheet
Supersedes data of 2001 Sep 13

2003 Oct 15

NXP Semiconductors Product data sheet

PNP/PNP resistor-equipped transistors;
R1 = 22 kΩ, R2 = 22 kΩ

FEATURES

• Built-in bias resistors

• Simplified circuit design

• Reduction of component count

• Reduced pick and place costs.

APPLICATIONS

• Low current peripheral drivers

• Replacement of general purpose transis tor s in digital

applications.

DESCRIPTION

PNP/PNP resistor-equipped transistors (see “Simplified
outline, symbol and pinning” for package details).

PRODUCT OVERVIEW

PEMB1; PUMB1

QUICK REFERENCE DATA

SYMBOL PARAMETER TYP. MAX. UNIT

V

CEO

I

O

TR1 PNP − − −
TR2 PNP − − −
R1 bias resistor 22 − kΩ
R2 bias resistor 22 − kΩ

collector-emitter

− −50 V

voltage
output current (DC) − −100 mA

T YPE NUMBER

PACKAGE

MARKING CODE

PHILIPS EIAJ

NPN/PNP

COMPLEMENT

NPN/NPN

COMPLEMENT

PEMB1 SOT666 − Z4 PEMD2 PEMH1
PUMB1 SOT363 SC-88 B*3

(1)

PUMD2 PUMH1

Note

1. * = p: Made in Hong Kong.
* = t: Made in Malaysia.
* = W: Made in China.

SIMPLIFIED OUTLINE, SYMBOL AND PINNING

PINNING

T YPE NUMBER SIMPLIFIED OUTLINE AND SYMBOL

PIN DESCRIPTION

PEMB1 1 emitter TR1

46

PUMB1 2 base TR1

Top view

5

123

MAM477

654

R1 R2

TR1

R2

123

TR2

R1

3 collector TR2
4 emitter TR2
5 base TR2
6 collector TR1

2003 Oct 15 2

NXP Semiconductors Product data sheet

PNP/PNP resistor-equipped transistors;

PEMB1; PUMB1

R1 = 22 kΩ, R2 = 22 kΩ

ORDERING INFORMATION

T YPE NUMBER

NAME DESCRIPTION VERSION

PEMB1 − plastic surface mounted package; 6 leads SOT666
PUMB1 − plastic surface mounted package; 6 leads SOT363

LIMITING VALUES

In accordance with the Absolute Maximum Rating System (IEC 60134).

SYMBOL PARAMETER CONDITIONS MIN. MAX. UNIT

Per transistor

V
V
V
V

CBO
CEO
EBO
I

collector-base voltage open emitter − −50 V
collector-emitter voltage open base − −50 V
emitter-base voltage open collector − −10 V
input voltage

positive − +10 V

negative − −40 V
I
I
P

O
CM

tot

output current (DC) − −100 mA
peak collector current − −100 mA
total power dissipation T

amb

≤ 25 °C
SOT363 note 1 − 200 mW
SOT666 notes 1 and 2 − 200 mW

T

stg

T

j

T

amb

storage temperature −65 +150 °C
junction temperature − 150 °C
operating ambient temperature −65 +150 °C

Per device

P

tot

total power dissipation T

amb

≤ 25 °C
SOT363 note 1 − 300 mW
SOT666 notes 1 and 2 − 300 mW

PACKAGE

Notes

1. Device mounted on an FR4 printed-circuit board, si ngle-sided copper, standard footprint.

2. Reflow soldering is the only recommended soldering method.

2003 Oct 15 3

NXP Semiconductors Product data sheet

PNP/PNP resistor-equipped transistors;

PEMB1; PUMB1

R1 = 22 kΩ, R2 = 22 kΩ

THERMAL CHARACTERISTICS

SYMBOL PARAMETER CONDITIONS VALUE UNIT

Per transistor

R

th j-a

Per device

R

th j-a

Notes

1. Device mounted on an FR4 printed-circuit board, si ngle-sided copper, standard footprint.

2. Reflow soldering is the only recommended soldering method.

CHARACTERISTICS

T

= 25 °C unless otherwise specified.

amb

thermal resistance from junction to ambient T

amb

≤ 25 °C
SOT363 note 1 625 K/W
SOT666 notes 1 and 2 625 K/W

thermal resistance from junction to ambient T

amb

≤ 25 °C
SOT363 note 1 416 K/W
SOT666 note 1 416 K/W

SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT

I

CBO

I

CEO

collector-base cut-off curren t VCB = −50 V; IE = 0 − − −100 nA
collector-emitter cut-off current VCE = −30 V; IB = 0 − − −1 μA

VCE = −30 V; IB = 0; Tj = 150 °C − − −50 μA

I

EBO

h
V
V
V

FE

CEsat
i(off)
i(on)

emitter-base cut-off current VEB = −5 V; IC = 0 − − −180 μA
DC current gain VCE = −5 V; IC = −5 mA 60 − −
saturation voltage IC = −10 mA; IB = −0.5 mA − − −150 mV
input-off voltage VCE = −5 V; IC = −100 μA − −1.1 −0.8 V
input-on voltage VCE = −0.3 V; IC = −5 mA −2.5 −1.7 − V

R1 input resistor 15.4 22 28.6 kΩ

R2

------- ­R1

C

c

resistor ratio 0.8 1 1.2

collector capacitance IE = ie = 0; VCB = −10 V;

f

= 1 MHz

− − 3 pF

2003 Oct 15 4

NXP Semiconductors Product data sheet

6

PNP/PNP resistor-equipped transistors;

PEMB1; PUMB1

R1 = 22 kΩ, R2 = 22 kΩ

PACKAGE OUTLINES

Plastic surface mounted package; 6 leads SOT66

D

S

YS

A

E

H

E

X

pin 1 index

123

e

DIMENSIONS (mm are the original dimensions)

UNIT b

mm

A

0.6

0.5

0.27

0.17

p

cD

0.18

0.08

1

1.7

1.5

b

p

e

E

1.3

1.1

456

A

w M

A

0 1 2 mm

scale

e

H

L

1.0

e

1

E

1.7

0.5

1.5

0.3

0.1

p

w

0.1y0.1

detail X

c

L

p

OUTLINE
VERSION

SOT666

REFERENCES

IEC JEDEC EIAJ

EUROPEAN

PROJECTION

ISSUE DATE

01-01-04
01-08-27

2003 Oct 15 5

NXP Semiconductors Product data sheet

Plastic surface mounted package; 6 leads SOT363

PNP/PNP resistor-equipped transistors;

PEMB1; PUMB1

R1 = 22 kΩ, R2 = 22 kΩ

y

D

56

4

E

H

E

AB

X

v

M

A

pin 1
index

132

e

1

DIMENSIONS (mm are the original dimensions)

A

UNIT

mm

A

1.1

0.8

max

0.1

1

b

p

0.30

0.25

0.20

0.10

b

p

e

cD

2.2

1.8

A

wB

M

0 1 2 mm

scale

H

e

e

E

1.35

1.15

1.3

0.65

E

1

2.2

0.45

2.0

0.15

Q

A

1

c

L

p

detail X

L

Qywv

p

0.25

0.15

0.2 0.10.2

OUTLINE
VERSION

SOT363 SC-88

IEC JEDEC EIAJ

REFERENCES

EUROPEAN

PROJECTION

ISSUE DATE

97-02-28

2003 Oct 15 6

NXP Semiconductors Product data sheet

PNP/PNP resistor-equipped transistors;

PEMB1; PUMB1

R1 = 22 kΩ, R2 = 22 kΩ

DATA SHEET STATUS

DOCUMENT

STATUS

Objective data sheet Development This document contains data from the objective specification for product

Preliminary data sheet Qualification This document contains data from the preliminary specification.
Product data sheet Production This document contains the product specification.

Notes

1. Please consult the most recently issued document before initiating or completing a design.

2. The product status of device(s) described in this document may have changed since this do cument was published
and may differ in case of multiple devices. The latest product status information is available on the Internet at

http://www.nxp.com.

URL

DISCLAIMERS
General ⎯ Information in this document is believed to be

accurate and reliable. However, NXP Semiconductors
does not give any representations or warranties,
expressed or implied, as to the accuracy or completeness
of such information and shall have no liability for the
consequences of use of such information.

Right to make changes ⎯ NXP Semiconductors
reserves the right to make changes to information
published in this document, including without limitation
specifications and product descriptions, at any time and
without notice. This document supersedes and replaces all
information supplied prior to the publication hereof.

Suitability for use ⎯ NXP Semiconductors products are
not designed, authorized or warranted to be su itable for
use in medical, military, aircraft, space or life support
equipment, nor in applications where failure or malfunction
of an NXP Semiconductors product can reasonably be
expected to result in personal injury, death or severe
property or environmental damage. NXP Semiconductors
accepts no liability for inclusion and/or use of NXP
Semiconductors products in such equipment or
applications and therefore such inclusion and/or use is at
the customer’s own risk.

Applications ⎯ Applications that are described herein for
any of these products are for illustrative purposes only.
NXP Semiconductors makes no representation or
warranty that such applications will be suitable for the
specified use without further testing or modificati on .

(1)

PRODUCT
STATUS

(2)

DEFINITION

development.

above those given in the Characteristics sections of this
document is not implied. Exposure to limiting values for
extended periods may affect device reliability.

Terms and conditions of sale ⎯ NXP Semiconductors
products are sold subject to the general terms and
conditions of commercial sale, as published at
http://www.nxp.com/profile/terms, including those
pertaining to warranty, intellectual property rights
infringement and limitation of liability, unless explicitly
otherwise agreed to in writing by NXP Semiconductors. In
case of any inconsistency or conflict between information
in this document and such terms and conditions, the latter
will prevail.

No offer to sell or license ⎯ Nothing in this document
may be interpreted or construed as an offer to sell products
that is open for acceptance or the grant, conveya nce or
implication of any license under any copyrights, patents or
other industrial or intellectual property rights.

Export control ⎯ This document as well as the item(s)
described herein may be subject to export control
regulations. Export might require a prior authorization from
national authorities.

Quick reference data ⎯ The Quick reference data is an
extract of the product data given in the Limiting values and
Characteristics sections of this document, and as such is
not complete, exhaustive or legally binding.

Limiting values ⎯ Stress above one or more limiting
values (as defined in the Absolute Maximum Ratings
System of IEC
the device. Limiting values are stress ratings only an d
operation of the device at these or any other conditions

2003 Oct 15 7

60134) may cause permanent damage to
