www.philips.com/welcome

PD7040

EN User manual 3

DA Brugervejledning 23

DE Benutzerhandbuch 43

ES Manual del usuario 65

FR Mode d’emploi 87

IT Manuale utente 109

NL Gebruiksaanwijzing 131

SV Användarhandbok 153

ČESKA REPUBLIKA

Záruka: Pokud byste zjakéhokoli důvodu přístroj demontovali, vždy nejdříve vytáhněte síťovou zástrčku.

Přístroj chraňte před jakoukoli vlhkostí ipřed kapkami vody.

ČESKA REPUBLIKA

Advarsel: Usynlig laserstråling ved åbning når sikkerhedsafbrydere er ude af funktion. Undgå utsættelse for stråling.

Bemærk: Netafbryderen er sekundært indkoblet og ofbryder ikke strømmen fra nettet. Den indbyggede netdel er derfor tilsluttet til lysnettet så længe netstikket sidder i stikkontakten.

Výstraha! Tento přístroj pracuje s laserovým paprskem. Při nesprávné manipulaci s přístrojem (v rozporu s tímto návodem) můże dojít k nebezpečnému ozáření. Proto přístroj za chodu neotevírejte ani nesnímejte jeho kryty. Jakoukoli opravu vždy svěřte specializovanému servisu.

Nebezpečí! Při sejmutí krytů a odjištění bezpečnostních spínačů hrozí nebezpečí neviditelného laserového záření!

Chraňte se před přímým zásahem laserového paprsku.

Pokud byste z jakéhokoli důvodu přístroj demontovali, vždy nejdříve vytáhněte síťovou zástrčku.

Přístroj chraňte před jakoukoli vlhkostí i před kapkami vody.

Norge

Typeskilt ﬁnnes på apparatens underside.

Observer: Nettbryteren er sekundert innkoplet. Den innebygde netdelen er derfor ikke frakoplet nettet så lenge apparatet er tilsluttet nettkontakten.

For å redusere faren for brann eller elektrisk støt, skal apparatet ikke utsettes for regn eller fuktighet.

Luokan 1 laserlaite Varoitus! Laitteen käyttäminen muulla kuin tässä käyttöohjeessa mainitulla tavalla saattaa altistaa käyttäjän

turvallisuusluokan 1 ylittävälle näkymättömälle lasersäteilylle. Oikeus muutoksiin varataan. Laite ei saa olla alttiina tippu-ja roiskevedelle. Huom. Toiminnanvalitsin

on kytketty toisiopuolelle, eikä se kytke laitetta irti sähköverkosta. Sisäänrakennettu verkkoosa on kytkettynä sähköverkkoon aina silloin, kun pistoke on pistorasiassa.

Huom.Toiminnanvalitsin on kytketty toisiopuolelle, eikä se kytke laitetta irti sähköverkosta. Sisäänrakennettu verkko-osa on kytkettynä sähköverkkoon aina silloin, kun pistoke on pistorasiassa.

Contents

1 Important 4

Important Safety Instructions 4 Hearing safety 5 Notice 6

2 Your portable DVD player 10

Introduction 10 What’s in the box 10 Overview of the main unit 11 Overview of the remote control 13

3 Get started 15

Charge the battery 15

English

Install remote control battery 16 Connect additional equipment 17

4 Use your player 18

Turn on 18 Select OSD language 18 Play discs 18 Play from USB 18 Play options 19 Adjust brightness of screen backlight 19

5 Adjust settings 20

6 Product information 22

7 Troubleshooting 23

1 Important

Important Safety Instructions

a Read these instructions. b Keep these instructions. c Heed all warnings. d Follow all instructions. e Do not use this apparatus near water. f Clean only with dry cloth. g Do not block any ventilation openings. Install in accordance with

the manufacturer’s instructions.

h Do not install near any heat sources such as radiators, heat

registers, stoves, or other apparatus (including ampliﬁers) that produce heat.

i Protect the power cord from being walked on or pinched,

particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

j Only use attachments/accessories speciﬁed by the manufacturer. k Use only with the cart, stand, tripod, bracket, or table speciﬁed by

the manufacturer or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

l Unplug this apparatus during lightning storms or when unused for

long periods of time.

m Refer all servicing to qualiﬁed service personnel. Servicing is

required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

n Battery usage CAUTION – To prevent battery leakage which may

result in bodily injury, property damage, or damage to the unit:

•

Install all batteries correctly, + and - as marked on the unit. Do not mix batteries (old and new or carbon and alkaline, etc.).• Remove batteries when the unit is not used for a long time.•

o Apparatus shall not be exposed to dripping or splashing. p Do not place any sources of danger on the apparatus (e.g. liquid

ﬁlled objects, lighted candles).

Caution

Use of controls or adjustments or performance of procedures other than herein • may result in hazardous radiation exposure or other unsafe operation.

Warning

Never remove the casing of this apparatus. • Never lubricate any part of this apparatus. • Never place this apparatus on other electrical equipment. • Keep this apparatus away from direct sunlight, naked ﬂames or heat. • Never look into the laser beam inside this apparatus. • Ensure that you always have easy access to the power cord, plug or adaptor to • disconnect this apparatus from the power.

English

Hearing safety

Listen at a moderate volume.

•

Using headphones at a high volume can impair your hearing. This product can produce sounds in decibel ranges that may cause hearing loss for a normal person, even for exposure less than a minute. The higher decibel ranges are offered for those that may have already experienced some hearing loss. Sound can be deceiving. Over time your hearing ‘comfort level’ • adapts to higher volumes of sound. So after prolonged listening, what sounds ‘normal’ can actually be loud and harmful to your hearing. To guard against this, set your volume to a safe level before your hearing adapts and leave it there.

To establish a safe volume level:

•

Listen for reasonable periods of time:

•

Be sure to observe the following guidelines when using your headphones.

•

Set your volume control at a low setting. Slowly increase the sound until you can hear it comfortably and • clearly, without distortion.

Prolonged exposure to sound, even at normally ‘safe’ levels, can also cause hearing loss. Be sure to use your equipment reasonably and take appropriate breaks.

Listen at reasonable volumes for reasonable periods of time. Be careful not to adjust the volume as your hearing adapts.• Do not turn up the volume so high that you can’t hear what’s around • you. You should use caution or temporarily discontinue use in potentially hazardous situations. Do not use headphones while operating a motorized vehicle, cycling, skateboarding, etc.; it may create a trafﬁc hazard and is illegal in many areas.

Notice

This product complies with the radio interference requirements of the European Community.

Any changes or modiﬁcations made to this device that are not expressly approved by Philips Consumer Lifestyle may void the user’s authority to operate the equipment.

Recycling

Your product is designed and manufactured with high quality materials and components, which can be recycled and reused.

When you see the crossed-out wheel bin symbol attached to a product, it means the product is covered by the European Directive 2002/96/EC:

Never dispose of your product with other household waste. Please inform yourself about the local rules on the separate collection of electrical and electronic products. The correct disposal of your old product helps prevent potentially negative consequences on the environment and human health.

Your product contains batteries covered by the European Directive 2006/66/EC, which cannot be disposed of with normal household waste.

Please inform yourself about the local rules on separate collection of batteries. The correct disposal of batteries helps prevent potentially negative consequences on the environment and human health.

Environmental information

All unnecessary packaging has been omitted. We have tried to make the packaging easy to separate into three materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet.)

English

Your system consists of materials which can be recycled and reused if disassembled by a specialized company. Please observe the local regulations regarding the disposal of packaging materials, exhausted batteries and old equipment.

Always bring your product to a professional to remove the built-in battery.

The making of unauthorized copies of copy-protected material, including computer programs, ﬁles, broadcasts and sound recordings, may be an infringement of copyrights and constitute a criminal offence. This equipment should not be used for such purposes.

Recording and playback of material might require consent. See Copyright Act 1956 and The Performer’s Protection Acts 1958 to 1972.

This item incorporates copy protection technology that is protected by U.S. patents and other intellectual property rights of Rovi Corporation. Reverse engineering and disassembly are prohibited.

Manufactured under license from Dolby Laboratories. “Dolby” and the double-D symbol are trademarks of Dolby Laboratories.

DivX®, DivX Certiﬁed® and associated logos are trademarks of DivX, Inc. and are used under license.

ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, Inc. This is an ofﬁcial DivX Certiﬁed® device that plays DivX video. Visit divx.com for more information and software tools to convert your ﬁles into DivX video.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certiﬁed® device must be registered in order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod.divx.com for more information on how to complete your registration.

Covered by one or more of the following U.S. patents: 7,295,673; 7,460,668; 7,515,710; 7,519,274

This apparatus includes this label:

2 Your portable DVD player

Congratulations on your purchase, and welcome to Philips! To fully beneﬁt from the support that Philips offers, register your product at www.philips. com/welcome.

Introduction

Your portable DVD player plays digital video discs that conform to the universal DVD Video standard. With it, you can play movies with true cinema picture quality and stereo or multi-channel sound (depending on disc and playback set-up).

You can also select sound track, subtitle languages, and some play options. Besides, you can restrict the play of discs that are not suitable for children. You can play the following discs on the DVD player (including CD-R, CD-

RW, DVD±R and DVD±RW):

•

DVD-Video Video CD• Audio CD•

English

MP3 CD• DivX• Discs with JPEG ﬁles•

What’s in the box

Check and identify the contents of your package:

•

Portable DVD player Remote control• AC power adaptor, ASUC12E-090080 & DSA-9PFB-09 FEU090080• Car adaptor• AV cable• Mounting bag• User manual•

Overview of the main unit

o n m

l k

a Display panel b IR

•

Remote control sensor.

c d

e f g

h i j

Stops disc play.•

d OPTIONS

•

e DC IN

•

Accesses options relating to the current activity or selection.

Power supply socket.

Connects a USB device.•

Headphone jack.•

h AV OUT

•

i VOLUME

j POWER ON/OFF (CHR)

•

k CHR/

l , , ,

•

m ,

Audio/video output jack.

Increases or decreases volume.•

Turns on/off DVD player.

Charging indicator/Power indicator.•

Navigates menus.•

Searches backward/forward at different speeds. •

/OK

Conﬁrms an entry or selection. Starts, pauses or resumes disc play.•

English

Skips to the previous or next title, chapter, or track.•

n DISC MENU

•

o SOURCE

•

p OPEN

For DVD, accesses or exits disc menu. For VCD, turns on or off PBC (Playback Control) mode.• For VCD version 2.0 or SVCD with PBC turned on, returns to • the menu.

Switches between DVD and USB

Opens the disc compartment.•

Overview of the remote control

abcd

k j

SOURCE

SETUP

SUB

ZOOM

a SOURCE

•

b DISPLAY

•

Switches between DVD and USB.

Displays play information.

Adjusts brightness of the screen backlight.•

d MENU

•

e A-B REPEAT

•

f SUB

•

g AUDIO

•

h ZOOM

For DVD, accesses or exits disc menu. For VCD, turns on or off PBC (Playback Control) mode.• For VCD version 2.0 or SVCD with PBC turned on, returns to • the menu. For a USB device, accesses or exits the ﬁle menu.

Marks the section for repeat play.

REPEAT 1/ALL

Repeat a chapter, track, or title.

Selects a DVD subtitle language.

For DVD, selects an audio language. For VCD, selects an audio mode. •

English

•

i 0-9

•

k SETUP

•

l , , ,

•

Zooms into a video scene or picture.

Inputs numbers.

Stops disc play.•

Accesses or exits the setup menu.

Navigates menus.•

Searches backward/forward at different speeds. •

•

Conﬁrms an entry or selection.• Starts, pauses or resumes disc play.•

m /

Skips to the previous or next title, chapter, or track.•

3 Get started

Caution

Use the controls only as stated in this user manual. • Always follow the instructions in this chapter in sequence. •

If you contact Philips, you will be asked for the model and serial number of your player. The model number and serial number are on the bottom of your player. Write the numbers here: Model No. __________________________ Serial No. ___________________________

Charge the battery

Caution

Risk of product damage! Ensure that the power supply voltage corresponds to the • voltage printed on the bottom of the player.

•

Use only the supplied AC adaptor to charge the battery.

Note

The type plate is located on the bottom of the player. • You can only charge the player when it is in power-off mode. •

1 Slide the POWER ON/OFF (CHR) switch to OFF position. 2 Connect the supplied AC adaptor to the player and to the AC outlet.

The charge indicator turns on. It takes about 7.0 hours to fully » charge the battery.

When the battery is fully charged, the charge indicator turns off. »

Install remote control battery

Caution

Risk of explosion! Keep batteries away from heat, sunshine or ﬁre. Never discard • batteries in ﬁre.

•

Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type.

•

Batteries contain chemical substances, they should be disposed of properly. Perchlorate Material - special handling may apply. See www.dtsc.ca.gov/ • hazardouswaste/perchlorate.

English

For ﬁrst-time use:

1 Remove the protective tab to activate the remote control battery.

To replace the remote control battery:

1 Open the battery compartment. 2 Insert one CR2025 battery with correct polarity (+/-) as indicated. 3 Close the battery compartment.

Connect additional equipment

Caution

Turn off your player before connecting to any additional equipment. •

You can connect the player to a TV or an ampliﬁer to enjoy DVDs or Karaoke.

Match the color of the AV cables (not supplied) with the jacks:

•

the yellow cable is for the yellow video jack. the red/white cables are for the red/white audio jacks.•

4 Use your player

Turn on

Slide the POWER ON/OFF (CHR) switch to the ON position.

The »

indicator turns on.

Select OSD language

You can choose a different language for the on-screen display text.

1 Press SETUP.

The setup menu is displayed. »

2 Go to [-- General Setup Page --] > [OSD Language]. 3 Press to select a language option. 4 Press to conﬁrm. 5 Press SETUP to exit.

English

Play discs

Slide OPEN on the player.

2 Insert the disc with label side facing up. 3 Push down to close the disc compartment.

Play starts automatically. If not, press »

• /OK to

• /OK. Press again to resume play.

• STOP twice.

• or .

• or once or more.

If a menu is displayed, select an item, then press start play. To pause, press To stop, press To select the previous/next item, press To start search within video/audio, press

/OK.

Play from USB

This player plays/views DivX, VOB, MP3, or JPEG ﬁles that are stored on USB devices.

1 Press SOURCE to switch to USB mode. 2 Connect the USB device to the player.

The content menu appears. »

3 Select a ﬁle, then press .

Play starts. »

4 To stop play, press or remove the USB device.

Play options

During play, press OPTIONS to select some play options.

2 Follow the on-screen instructions.

Adjust brightness of screen backlight

Note

You can adjusts brightness of the screen backlight to match lighting conditions. •

During play, press repeatedly to select an option.

• [High]

• [Normal]

• [Dim]

Tip

For the longest playtime, select • [Dim].

• [High].

For the best view, select

5 Adjust settings

To maximize your play experience, use SETUP to ﬁne tune your settings.

1 Press SETUP.

The setup menu is displayed. »

2 Press to select an option and press to conﬁrm.

[-- General Setup Page --] [OSD Language] Select on-screen display language. [Screen Saver] Activate/deactivate screen saver. [Last Memory] Select whether to start play from the

point where it was last stopped.

[Angle Mark] Select angle mark display options. [-- Video Setup Page --] [Brightness] Adjust screen brightness. [Contrast] Adjust screen contrast. [TV Display] Select display ratio.

English

[TV Type] Set TV standard. [‘-- Battery Life Setup Page --] [LCD Backlight] Adjust the default brightness level of

screen backlight.

[-- Preference Setup Page --] [Audio] Select audio language. [Subtitle] Select DVD subtitle language. [Disc Menu] Select disc menu language. [Parental] Select parental level. [DivX Subtitle] Select DivX subtitle language. [Password] Change password (3308 by default). [DivX VOD] Get DivX registration code. [Default] Restore original settings.

3 Press to go back to previous menu level. 4 Press SETUP to exit.

6 Product information

Note

Product information is subject to change without prior notice. •

Dimensions 210 x 41 x 160 mm Weight 0.73 kg Power supply Input: 100-240V~ 50/60Hz

Output: DC 9V Power consumption 7.2 W Operating temperature range 0-45°C Laser wavelength 650 nm Video output Format PAL & NTSC Output level 1Vp - p ± 20% Load impedance

Audio line out Audio out (analog audio) Output level: 2V ± 10% Load impedance

Audio distortion + noise Frequency response 20Hz-20KHz ± 1dB

Signal/noise ratio

10 K

-80 (1KHz)

80 dB

0.8A

Channel separation Dynamic range

80 dB 80 dB

7 Troubleshooting

Warning

Risk of electric shock. Never remove the casing of the player. •

To keep the warranty valid, never try to repair the system yourself. If you encounter problems when using the player, check the following points before requesting service. If the problem remains unsolved, register your player and get support at www.philips.com/welcome.

No power

Ensure that both plugs of the mains cord are properly connected. • Ensure that there is power at the AC outlet. • Check if the built-in battery is drained. •

English

No sound

•

Distorted picture

Cannot play disc

Ensure that the AV cable is connected correctly.

Clean the disc. With a clean, soft, lint-free cloth, wipe the disc • outwards from the center. Make sure that the video output format of the disc is compatible with • the TV. Change the video output format to match your TV or program. • The LCD is manufactured using high precision technology. You may, • however, see tiny black points and/or bright points(red, blue, green) that continuously appear on the LCD. This is a normal result of the manufacturing process and does not indicate a malfunction.

Ensure the disc label is upwards. • Clean the disc. With a clean, soft, lint-free cloth, wipe the disc • outwards from the center. Check if the disc is defective by trying another disc. •

No response to the remote control

Ensure that the path between the remote control and the player is • clear from obstacles. From a close distance, point the remote control directly at the player. • Replace the remote control batteries. • The function does not work for this disc. Refer to the disc • instructions.

The player feels warm

•

When the player is in use for a long period of time, its surface will be heated. This is normal.

PHILIPS PD7040 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
