Philips OQ2535HP-C4, OQ2535WC-C4 Datasheet

DATA SH EET

Product specification
Supersedes data of 1997 Nov 27
File under Integrated Circuits, IC19

1999 Oct 04

INTEGRATED CIRCUITS

OQ2535HP

SDH/SONET STM16/OC48
multiplexer

1999 Oct 04 2

Philips Semiconductors Product specification

SDH/SONET STM16/OC48 multiplexer OQ2535HP

FEATURES

• Normal and loop (test) modes

• 3.3 V TTL compatible data inputs

• Differential Current-Mode Logic (CML) clock and data

outputs

• 5 V TTL clock output (low speed interface)

• High input sensitivity (100 mV for the high speed clock

input)

• Boundary Scan Test (BST) at low speed interface, in
accordance with

“IEEE Std 1149.1-1990”

• Low power dissipation (typically 1.65 W).

GENERAL DESCRIPTION

The OQ2535HP is a 32-channel multiplexer intended for
use inSTM16/OC48 applications. It combines data from a
total of 32 × 78 Mbits/s input channels onto a single

2.5 Gbits/s output channel. It features 3.3 V TTL data
inputs and a 5 V TTL clock output at the low speed
interface, and CML compatible inputs and outputs at the
high speed interface.

ORDERING INFORMATION

BLOCK DIAGRAM

TYPE

NUMBER

PACKAGE

NAME DESCRIPTION VERSION

OQ2535HP HLQFP100 plastic heat-dissipating low profile quad flat package; 100 leads;

body 14 × 14 × 1.4 mm

SOT470-1

handbook, full pagewidth

MGK351

4

ENL

SYNSEL1
SYNSEL2

TRST

TMS

TCK

TDI

TDO

CDIV

DOUT
DOUTQ

COUT
COUTQ

DLOOP
DLOOPQ

CLOOP

CIN
CINQ

DIOA
DIOC

CLOOPQ

clock

4 : 1 MUX

SYNCHRONIZATION

DIVIDE BY 4

622 MHz

OQ2535HP

78 MHz

2.5 GHz

BAND GAP

REFERENCE 2

BAND GAP

REFERENCE 1

DIVIDE BY 8

BST LOGIC

4 ×

8 : 1 MUX

622 Mbits/s

2.5 Gbits/s

78

Mbits/s

load

pulse

2

58

59

62

32

5
3
7
6

13

10 78

5

14, 37,
63, 85, 86

V

DD

4

12, 39,
87, 88

V

EE

60

V

CC

V

CC(T)

BGCAP2BGCAP1

31

(2)

(1)

GND

16

REFC2

38

REFC1

61

90
91

82
83

65
66

68
69

71
72

74
75

D0

to

D31

Fig.1 Block diagram.

(1) See Chapter “Pinning” for D0 to D31 pin numbers.
(2) Pins 1, 4, 8, 9, 11, 15, 17, 21, 25, 36, 40, 56, 64, 67, 70, 73, 76, 77, 79, 80, 81, 84, 89, 92 to 98 and 100.

1999 Oct 04 3

Philips Semiconductors Product specification

SDH/SONET STM16/OC48 multiplexer OQ2535HP

PINNING

SYMBOL PIN TYPE

(1)

DESCRIPTION

GND 1 S ground
TRS 2 I test reset input for BST mode (active LOW)
TCK 3 I test clock input for BST mode
GND 4 S ground
TMS 5 I test mode select input for BST mode
TDO 6 O serial test data output for BST mode
TDI 7 I serial test data input for BST mode
GND 8 S ground
GND 9 S ground
BGCAP1 10 A pin for connecting external band gap decoupling capacitor (4 × 8 : 1 MUX)
GND 11 S ground
V

EE

12 S supply voltage (−4.5 V)
CDIV 13 O 78 MHz clock output
V

DD

14 S supply voltage (+3.3 V)
GND 15 S ground
V

CC(T)

16 S supply voltage for TTL buffer (+5.0 V); not connected internally to V

CC

GND 17 S ground
D31 18 I 78 Mbits/s data input channel for D31
D27 19 I 78 Mbits/s data input channel for D27
D23 20 I 78 Mbits/s data input channel for D23
GND 21 S ground
D19 22 I 78 Mbits/s data input channel for D19
D15 23 I 78 Mbits/s data input channel for D15
D11 24 I 78 Mbits/s data input channel for D11
GND 25 S ground
D7 26 I 78 Mbits/s data input channel for D7
D3 27 I 78 Mbits/s data input channel for D3
D30 28 I 78 Mbits/s data input channel for D30
D26 29 I 78 Mbits/s data input channel for D26
D22 30 I 78 Mbits/s data input channel for D22
D18 31 I 78 Mbits/s data input channel for D18
D14 32 I 78 Mbits/s data input channel for D14
D10 33 I 78 Mbits/s data input channel for D10
D6 34 I 78 Mbits/s data input channel for D6
D2 35 I 78 Mbits/s data input channel for D2
GND 36 S ground
V

DD

37 S supply voltage (+3.3 V)
REFC2 38 A pin for connecting external reference decoupling capacitor (3.3 V CMOS

reference)

V

EE

39 S supply voltage (−4.5 V)

1999 Oct 04 4

Philips Semiconductors Product specification

SDH/SONET STM16/OC48 multiplexer OQ2535HP

GND 40 S ground
D29 41 I 78 Mbits/s data input channel for D29
D25 42 I 78 Mbits/s data input channel for D25
D21 43 I 78 Mbits/s data input channel for D21
D17 44 I 78 Mbits/s data input channel for D17
D13 45 I 78 Mbits/s data input channel for D13
D9 46 I 78 Mbits/s data input channel for D9
D5 47 I 78 Mbits/s data input channel for D5
D1 48 I 78 Mbits/s data input channel for D1
D28 49 I 78 Mbits/s data input channel for D28
D24 50 I 78 Mbits/s data input channel for D24
D20 51 I 78 Mbits/s data input channel for D20
D16 52 I 78 Mbits/s data input channel for D16
D12 53 I 78 Mbits/s data input channel for D12
D8 54 I 78 Mbits/s data input channel for D8
D4 55 I 78 Mbits/s data input channel for D4
GND 56 S ground
D0 57 I 78 Mbits/s data input channel for D0
SYNSEL2 58 I selection input 2 for synchronization pulse timing
SYNSEL1 59 I selection input 1 for synchronization pulse timing
V

CC

60 S supply voltage (+5.0 V)
REFC1 61 A pin for connecting external reference decoupling capacitor (for standard

TTL reference)
ENL 62 I loop mode enable (active LOW)
V

DD

63 S supply voltage (+3.3 V)
GND 64 S ground
DLOOP 65 O data output to demultiplexer IC OQ2536 (loop mode)
DLOOPQ 66 O inverted data output to demultiplexer IC OQ2536 (loop mode)
GND 67 S ground
CLOOP 68 O clock output to demultiplexer IC OQ2536 (loop mode)
CLOOPQ 69 O inverted clock output to demultiplexer IC OQ2536 (loop mode)
GND 70 S ground
CIN 71 I clock input from VCO IC
CINQ 72 I inverted clock input from VCO IC
GND 73 S ground
DIOA 74 A anode of temperature diode array
DIOC 75 A cathode of temperature diode array
GND 76 S ground
GND 77 S ground
BGCAP2 78 A pin for connecting external band gap decoupling capacitor (4 : 1 MUX)
GND 79 S ground

SYMBOL PIN TYPE

(1)

DESCRIPTION

1999 Oct 04 5

Philips Semiconductors Product specification

SDH/SONET STM16/OC48 multiplexer OQ2535HP

Note

1. Pin type abbreviations: O = Output, I = Input, S = power Supply, A = Analog function.

GND 80 S ground
GND 81 S ground
COUT 82 O clock output to laser driver IC
COUTQ 83 O inverted clock output to laser driver IC
GND 84 S ground
V

DD

85 S supply voltage (+3.3 V)
V

DD

86 S supply voltage (+3.3 V)
V

EE

87 S supply voltage (−4.5 V)
V

EE

88 S supply voltage (−4.5 V)
GND 89 S ground
DOUT 90 O data output to laser driver IC
DOUTQ 91 O inverted data output to laser driver IC
GND 92 S ground
GND 93 S ground
GND 94 S ground
GND 95 S ground
GND 96 S ground
GND 97 S ground
GND 98 S ground
i.c. 99 − internally connected, to be left open-circuit
GND 100 S ground

SYMBOL PIN TYPE

(1)

DESCRIPTION

1999 Oct 04 6

Philips Semiconductors Product specification

SDH/SONET STM16/OC48 multiplexer OQ2535HP

Fig.2 Pin configuration.

handbook, full pagewidth

75
74
73
72
71
70
69
68
67
66
65
64
63
62
61
60
59
58
57
56
55
54
53
52
51

8079787776

DIOC
DIOA
GND
CINQ
CIN
GND
CLOOPQ
CLOOP
GND
DLOOPQ
DLOOP
GND
V

DD
ENL
REFC1

V

CC
SYNSEL1

SYNSEL2
D0
GND
D4
D8
D12
D16
D20

MGK350

GND

TRST

TCK

GND

TMS
TDO

TDI
GND
GND

BGCAP1

GND

V

EE

CDIV

V

DD

GND

V

CC(T)

GND

D31
D27
D23

GND

D19
D15
D11

GND

GND

GND

BGCAP2

GND

GND

GND

i.c.

GND

GND

GND

GND

GND

GND

GND

DOUTQ

DOUT

GND

VEEVEEVDDVDDGND

COUTQ

COUT

GND

D18

D14

D10

D6

D2

GND

V

DD

REFC2

V

EE

GND

D29

D25

D21

D17

D13

D9D5D1

D28

D24

D7

D3

D30

D26

D22

30

29

28

27

26

25

24

23

22

21

20

19

18

17

16

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

100

99989796959493929190898887868584838281

31323334353637383940414243444546474849

50

OQ2535HP

1999 Oct 04 7

Philips Semiconductors Product specification

SDH/SONET STM16/OC48 multiplexer OQ2535HP

FUNCTIONAL DESCRIPTION

The OQ2535HP is a 32-channel multiplexer intended for
use in STM16/OC48 applications. It multiplexes
32 × 78 Mbits/s input channels onto a single 2.5 Gbits/s
output channel.

The multiplexing is performed in two stages. The 32 input
channels are fed into four 8 : 1 multiplexers to generate
four 622 Mbits/s channels. These four channels are then
combined into a single 2.5 Gbits/s data stream.

The ENL control input is used for switching between
normal and loop modes. When loop mode is enabled,
(ENL = LOW),the output signal is switched to DLOOPand
DLOOPQ (these outputs could be connected to the
DLOOP and DLOOPQ inputs on the OQ2536HP
demultiplexer to form part of a test loop).

The 2.5 GHz clock at CIN and CINQis used asthe system
reference. It is divided down to 78 MHz and made
available on the CDIV TTL output for timing the input data
(D0 to D31).

Low bit rate stage: 4 × 8 : 1 MUX

This part of the circuit consists of four 8-bit shift registers,
each acting as an 8 : 1 multiplexer, together with a
synchronization block.

The32 data input signals are loadedinto the shift registers
before being shifted out on a 622 MHz clock.

The load pulse for the shift registers is generated in the
synchronization block. The inputs SYNSEL1 and
SYNSEL2 can be used to adjust the phase of the load
pulse with respect to the input data (see Table 3) to
synchronize the data and clock signals.

High bit rate stage: 4 : 1 MUX

The four 622 Mbits/s data outputs from the low bit rate
stage are combined into a single 2.5 Gbits/s data stream
in two stages: two 2 : 1 multiplexers are used to generate
two 1244 Mbits/s data streams; these signals are then fed
into a third 2 : 1 multiplexer to generate the 2.5 Gbits/s
data stream.

The 2.5 Gbits/s serial data stream is passed either to the
DOUT and DOUTQ outputs (normal mode), or to the
DLOOP and DLOOPQ outputs (loop mode). The output
sequence is D31 (MSB) to D0 (LSB). Data and clock
output buffers are terminated internally with 100 Ω
resistors to GND and are capable of driving 50 Ω loads.
The unused output buffers are switched off to help
minimize power dissipation.

The outputs CLOOP, CLOOPQ, DLOOP and DLOOPQ
are terminated internally with 100 Ω resistors to GND and
are specifically designed to drive 50 Ω printed-circuit
board transmission lines.

The 2.5 GHz clock connected to CIN and CINQ is
terminated internally with 50 Ω to GND.

Power supply connections

The power supply pins need to be individually decoupled
using chip capacitors mounted as close as possible to the
IC. If multiple decoupling capacitors are used for a single
supply node, they must be placed close to each other to
avoid RF resonance.

Tominimizelow frequency switching noise in thevicinityof
the OQ2535HP, all power supply lines should be filtered
once by an LC-circuit with a low cut-off frequency (as
shown in the application diagram, Fig.6). V

CC(T)

needs to
be filtered separately via an LC-circuit because of the high
switching currents present at the CDIV TTL output. As this
current contains only 78 MHz harmonics, filtering can be
achieved with relatively small values of L and C.

Ground connection

The ground connection on the printed-circuit board needs
to be a large copper area fill connected to a common
ground plane with low inductance.

RF connections

A coupled stripline or microstrip with an odd mode
characteristic impedance of 50 Ω (nominal value) should
be used for the RF connections on the printed-circuit
board. The connections should be kept as short as
possible.This applies to theCML differential line pairsCIN
and CINQ, DOUT and DOUTQ, COUT and COUTQ,
DLOOP and DLOOPQ, and CLOOP and CLOOPQ. In
addition, the following lines should not vary in length by
more than 5 mm:

• CIN and CINQ

• DOUT, DOUTQ, COUT and COUTQ

• DLOOP, DLOOPQ, CLOOP and CLOOPQ.

Interface to transmit logic

The 78 Mbits/s interface lines, CDIV and D0 to D31,
should not vary in length by more than 20 mm.
The parasitic capacitance of these lines should be as
small as possible.

1999 Oct 04 8

Philips Semiconductors Product specification

SDH/SONET STM16/OC48 multiplexer OQ2535HP

ESD protection

All pads are protected by ESD protection diodes with the
exception of the high frequency outputs DOUT, DOUTQ,
DLOOP, DLOOPQ, COUT, COUTQ, CLOOP and
CLOOPQ and clock inputs CIN and CINQ.

Cooling

In many cases it is necessary to mount a special cooling
device on the package. The thermal resistance from
junctionto case, R

th j-c

andfrom junction to ambient, R

th j-a

,
are given in Chapter “Thermal characteristics”. Since the
heat-slug in the package is connected to the die, the
cooling device should be electrically isolated.

To calculate if a heatsink is necessary, the maximum
allowed total thermal resistance Rth is calculated as:

(1)

where:

Rth= totalthermal resistance from junction to ambientin
the application

Tj= junction temperature
T

amb

= ambient temperature.

As long as Rth is greater than R

th j-a

of the OQ2536HP
including environmental conditions such as air flow and
board layout, no heatsink is necessary.
For example if Tj= 120 °C, T

amb

=55°C and

P

tot

= 1.65 W, then:

(2)

which is more than the worst case R

th j-a

= 33 K/W, so no

heatsink is necessary.
Another example; if for safety reasons Tj should stay as

low as 110 °C, while T

amb

=85°C and P

tot

= 2 W, then:

(3)

In this case extra cooling is needed. The thermal
resistance of the heatsink is calculated as follows:

(4)

where:

R

th h-a

= thermal resistance from heatsink to ambient

R

th c-h

= thermal resistance from case to heatsink

R

th j-c

= thermal resistance from junction to case,

see Chapter “Thermal characteristics”.

If for instance R

th c-h

= 0.5 K/W and R

th j-a

= 33 K/W then:

(5)

Built in temperature sensor

Three series-connected diodes have been integrated for
measuring junction temperature. The diode array,
accessed by means of the DIOA (anode) and DIOC
(cathode) pins, has a temperature dependency of
approximately−6 mV/°C.Witha diode current of 1 mA, the
voltage will be somewhere in the range of 1.7 to 2.5 V,
depending on temperature.

Boundary Scan Test (BST) interface

Boundary scan test logic has been implemented for all
digitalinputsand outputs on the low frequency interface,in
accordance with

“IEEE Std 1149.1-1990”

. All scan tests
other than SAMPLE mode are available. The boundary
scan test logic consists of a TAP controller, a BYPASS
register, a 2-bit instruction register, a 32-bit identification
register and a 36-bit boundary scan register (the last two
are combined). The architecture of the TAP controller and
the BYPASS register is in accordance with IEEE
recommendations.Thefour command modes, selected by
means of the instruction register, are: EXTEST (00),
PRELOAD (01), IDCODE (10) and BYPASS (11). All
boundary scan test inputs, TDI, TMS, TCK and TRST,
have internal pull-up resistors. The maximum test clock
frequency at TCK is 12 MHz.

R

th

TjT

amb

–

P

tot

----------------------- -

=

R

th

120 55–()

1.65

---------------------------

39.4 K/W==

R

th

110 85–()

2.0

---------------------------

12.5 K/W==

R

th h-a

1

R

th

--------

1

R

th j-a

--------------

–





1–

R

th j-c

– R

th c-h

–≤

R

th h-a

1

12.5

-----------

1

33

------

–





1

–

3.1–

17.0 K/W

≤

≤

Table 1 BST identifier code

Note

1. LSB is shifted out first on the TDO pin.

VERSION OQ 2535 (BINARY) PHILIPS SEMICONDUCTORS LSB

(1)

0001 01 00 1001 1110 0111 0000 0010 101 1

1999 Oct 04 9

Philips Semiconductors Product specification

SDH/SONET STM16/OC48 multiplexer OQ2535HP

Table 2 BST bit order

Note

1. LSB is shifted out first on the TDO pin.

BIT NUMBER SYMBOL PIN

35 (MSB) CDIV 13
34 ENL 62
33 SYNSEL2 58
32 SYNSEL1 59
31 D31 18
30 D30 28
29 D29 41
28 D28 49
27 D27 19
26 D26 29
25 D25 42
24 D24 50
23 D23 20
22 D22 30
21 D21 43
20 D20 51
19 D19 22
18 D18 31
17 D17 44
16 D16 52
15 D15 23
14 D14 32
13 D13 45
12 D12 53
11 D11 24
10 D10 33
9D9 46
8D8 54
7D7 26
6D6 34
5D5 47
4D4 55
3D3 27
2D2 35
1D1 48
0 (LSB)

(1)

D0 57

1999 Oct 04 10

Philips Semiconductors Product specification

SDH/SONET STM16/OC48 multiplexer OQ2535HP

LIMITING VALUES

In accordance with the Absolute Maximum Rating System (IEC 134).

THERMAL CHARACTERISTICS

Note

1. The thermal resistance from junction to ambient is strongly depending on the board design and airflow. The values
given in the table are typical values and are measured on a single sided test board with dimensions of
76 × 114 × 1.6 mm. Better values can be obtained when mounted on multilayer boards with large ground planes.

SYMBOL PARAMETER MIN. MAX. UNIT

V

CC

, V

CC(T)

supply voltage −0.5 +6.0 V

V

EE

supply voltage −6.0 +0.5 V

V

DD

supply voltage −0.5 +5.0 V

V

n

DC voltage

pins 18 to 20, 22 to 24, 26 to 35, 41 to 55 and 57 −0.5 V

DD

+ 0.5 V

pins 2, 3, 5, 7, 38, 61 and 62 −0.5 V

CC

+ 0.5 V
pins 65, 66, 68, 69, 71, 72, 82, 83, 90 and 91 −1.0 +0.5 V
pins 10 and 78 V

EE

− 0.5 0.5 V

pins 74 and 75 V

EE

− 0.5 VCC+ 0.5 V

I

n

DC current

pins 6 and 13 − 50 mA
pins 74 and 75 − 10 mA

P

tot

total power dissipation − 2.35 W

T

j

junction temperature − 120 °C

T

stg

storage temperature −65 +150 °C

SYMBOL PARAMETER CONDITIONS VALUE UNIT

R

th j-c

thermal resistance from junction to
case

2.6 K/W

R

th j-a

thermal resistance from junction to
ambient

see note 1

airflow = 0 ft/min 33 K/W
airflow = 100 ft/min 28 K/W
airflow = 200 ft/min 25 K/W
airflow = 400 ft/min 22 K/W
airflow = 600 ft/min 20 K/W

1999 Oct 04 11

Philips Semiconductors Product specification

SDH/SONET STM16/OC48 multiplexer OQ2535HP

DC CHARACTERISTICS

All typical values are at T

amb

=25°C and at typical supply voltages; minimum and maximum values are valid over the

entire ambient temperature range and supply voltage range.

SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT

General

V

CC

, V

CC(T)

supply voltage note 1 4.75 5.0 5.25 V

V

EE

supply voltage −4.75 −4.5 −4.25 V

V

DD

supply voltage 3.14 3.3 3.47 V

I

CC

supply current − 2.3 4 mA

I

CC(T)

supply current − 20 40 mA

I

EE

supply current − 265 400 mA

I

DD

supply current − 20 28 mA

P

tot

total power dissipation − 1.65 2.35 W

T

j

junction temperature −−120 °C

T

amb

ambient temperature −40 − +85 °C
TTL 3.3 V inputs: D0 to D31; note 2
V

IL

LOW-level input voltage −−0.8 V
V

IH

HIGH-level input voltage 2.0 −−V
I

IL

LOW-level input current −65 − 0 µA
I

IH

HIGH-level input current 0 − 110 µA

TTL inputs: ENL, SYNSEL1, SYNSEL2, TDI, TCK, TMS and TRST

V

IL

LOW-level input voltage −−0.8 V
V

IH

HIGH-level input voltage 2.0 −−V
I

IL

LOW-level input current note 3 −100 − 0 µA
I

IH

HIGH-level input current note 3 0 − 210 µA
CML clock inputs: CIN and CINQ; note 4
V

i(p-p)

input voltage (peak-to-peak value) 50 Ω

measurement
system

100 250 500 mV

V

IO

permitted input offset voltage −25 − +25 mV
V

I,VIQ

input voltages −600 − +250 mV
Z

i

single ended input impedance for DC signal − 50 −Ω
TTL outputs: CDIV and TDO; note 5
V

OL

LOW-level output voltage IOL=4mA − 0.3 0.5 V
V

OH

HIGH-level output voltage IOH= −400 µA 2.4 4.0 − V
I

OZ

output current in high-impedance state −−1µA
CML outputs in normal mode: COUT, COUTQ, DOUT and DOUTQ; note 4
V

o(p-p)

output voltage (peak-to-peak value) outputs

terminated
externally with
50 Ω resistors

230 300 500 mV

V

OO

output offset voltage −25 0 +25 mV
V

O,VOQ

output voltages −600 − 0mV
Z

o

output impedance for DC signal − 100 −Ω

1999 Oct 04 12

Philips Semiconductors Product specification

SDH/SONET STM16/OC48 multiplexer OQ2535HP

Notes

1. VCCand V

CC(T)

require the same power supply voltage. However, a filter is needed to isolate V

CC(T)

because of the

high peak currents that occur at 78 MHz.

2. The output sequence is D31 (MSB) to D0 (LSB).

3. Only for inputs ENL, SYNSEL1 and SYNSEL2. TDI, TMS, TCK and TRST are connected to VCC through 90 kΩ
resistors.

4. See Fig.3 for symbol definitions.

5. TDO is switched to high impedance state if BST is inactive.

6. The temperature diode array can be used to measure the temperature of the die. The temperature dependency of
this voltage is approximately −6 mV/K.

CML outputs in loop mode: CLOOP, CLOOPQ, DLOOP and DLOOPQ; note 4
V

o(p-p)

output voltage (peak-to-peak value) outputs

terminated
externally with
50 Ω

230 300 500 mV

V

OO

output offset voltage −25 0 +25 mV

V

O,VOQ

output voltages −600 − 0mV

Z

o

output impedance for DC signal − 100 −Ω

Temperature diode array

∆V

DIOA-DIOC

diode voltage range; note 6 I

I(d)

=1mA − 2.1 − V

SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT

Fig.3 Logic level symbol definitions for CML.

handbook, full pagewidth

MGK144

V

IO

V

I(max)

V

IQH

V

IH

V

IQL

V

IL

V

I(min)

V

i(p-p)

GND

CML INPUT

V

OO

V

O(max)

V

OQH

V

OH

V

OQL

V

OL

V

O(min)

V

o(p-p)

GND

CML OUTPUT

1999 Oct 04 13

Philips Semiconductors Product specification

SDH/SONET STM16/OC48 multiplexer OQ2535HP

TIMING

Typical values at T

amb

=25°C and at typical supply voltages; minimum and maximum values are valid over the entire

ambient temperature range and supply voltage range.

Notes

1. The set-up and hold times given are valid for SYNSEL1 = SYNSEL2 = HIGH. Different SYNSEL1, SYNSEL2
combinations will produce different set-up and hold times (see Table 3).

2. All CML outputs must be terminated externally with 50 Ω to GND.The specified timing characteristics are applicable
in both normal and loop modes.

Table 3 Timing relationship between the clock edge and the data valid region (minimum values)

SYMBOL PARAMETER CONDITIONS MIN. TYP. MAX. UNIT

TTL input timing

f

clk(CDIV)

low speed output clock frequency f

clk(CIN)

= 2.488 GHz − 77.76 − MHz

t

r(CDIV),tf(CDIV)

CDIV rise/fall time capacitive load of 15 pF −−2600 ps

t

su

input data set-up time note 1 1200 −−ps

t

h

input data hold time note 1 2600 −−ps
CML output timing; note 2
f

clk(COUT)

output clock frequency f

clk(CIN)

= 2.488 GHz − 2.488 − GHz

t

CDV

clock edge to data valid time −−250 ps
t

DI

data invalid time −−120 ps
t

r(CML),tf(CML)

CML output rise/fall time −−150 ps

δ

COUT

output clock duty factor 45 50 55 %

SYNSEL2 SYNSEL1 t

su

t

h

UNIT

HIGH HIGH 1200 2600 ps
HIGH LOW 2800 1000 ps

LOW HIGH 1700 2100 ps
LOW LOW 3300 500 ps

1999 Oct 04 14

Philips Semiconductors Product specification

SDH/SONET STM16/OC48 multiplexer OQ2535HP

Fig.4 TTL input timing.

handbook, full pagewidth

t

r

t

f

t

su

t

h

valid data

MGK352

1.5 V

D0 to D31

CDIV

T

cy(CDIV)

1.5 V

2.0 V

0.8 V

Fig.5 CML output timing.

handbook, full pagewidth

+100 mV

0 V

−100 mV

+100 mV

−100 mV

t

CDV

t

DI

T

cy(COUT)

COUT − COUTQ,
CLOOP − CLOOPQ

DOUT − DOUTQ,
DLOOP − DLOOPQ

t

f

t

r

MGK353

1999 Oct 04 15

Philips Semiconductors Product specification

SDH/SONET STM16/OC48 multiplexer OQ2535HP

APPLICATION INFORMATION

handbook, full pagewidth

MGK354

TMS

TCK

TDO

TDI

DOUT

GND

or

V

CC

DOUTQ

COUT

COUTQ

DDQ

CL

CLQ

SYNSEL1

REFC2

SYNSEL2

DLOOP

DLOOPQ

CLOOP

CIN
CINQ

CLOOPQ

DLOOP

DLOOPQ

CLOOP

CLOOPQ

VCO

2.488 GHz

PLL

LOOP

FILTER

PHASE

DETECTOR

DATA

INTERFACE

BOUNDARY SCAN
TEST EQUIPMENT

micro-

controller

OQ2536

DMUX

OQ2545

LASER DRIVER

LASER DIODE

OQ2535

2

62

5

3

7

6

GND

90

91

82

83

LA

LAQ

65
66
68
69

ENL

TRST

(2)

(1)

16

60

72

71

58

59

38

61

78

10

13

68 nF

REFC1

BGCAP2

68 nF

10 nF

V

EE

BGCAP1

CDIV

10 nF

D0 to D31

D0 to D31

V

EE

(3)

system reference

ferrite

bead

ferrite

bead

ferrite

bead

ferrite

bead

1 µF

100

nF

V

CC

V

EE

1 µF

100

nF

V

DD

1 µF

100

nF

1 µF

100

nF

V

CC(T)

Fig.6 Application diagram.

(1) VDD pins 14, 37, 63, 85 and 86 should be

connected together, and to the filter network.

(2) V

EE

pins 12, 39, 87 and 88 should be connected

together, and to the filter network.

(3) All GND pins(pins 1,4,8, 9, 11,15, 17, 21,25,36,

40, 56, 64, 67, 70, 73, 76, 77, 79, 80, 81, 84, 89,
92 to 98 and 100) must be connected directly to
the printed-circuit board ground plane.

1999 Oct 04 16

Philips Semiconductors Product specification

SDH/SONET STM16/OC48 multiplexer OQ2535HP

PACKAGE OUTLINE

UNIT

A

max.

A1A2A3bpcE

(1)

eH

E

LL

p

Zywv θ

REFERENCES

OUTLINE
VERSION

EUROPEAN

PROJECTION

ISSUE DATE

IEC JEDEC EIAJ

mm

1.6

0.20

0.05

1.5

1.3

0.25

0.28

0.16

0.18

0.12

14.1

13.9

0.5

16.25

15.75

1.15

0.85

7
0

o
o

0.12 0.10.21.0

J

(2)

DIMENSIONS (mm are the original dimensions)

Notes

1. Plastic or metal protrusions of 0.25 mm maximum per side are not included.

2. Heatsink intrusion 0.0127 maximum.

0.75

0.45

10.15

9.15

SOT470-1

97-01-13

D

(1) (1)(1)

14.1

13.9

H

D

16.25

15.75

E

Z

1.15

0.85

D

b

p

e

E

detail X

J

B

25

c

D

H

b

p

E

H

A

1

A

A

2

v M

B

D

Z

D

A

Z

E

e

v M

A

X

1

100

76

75

51

50

26

θ

L

p

L

(A )

3

y

w M

w M

0 5 10 mm

scale

HLQFP100: plastic heat-dissipating low profile quad flat package;
100 leads; body 14 x 14 x 1.4 mm

SOT470-1

pin 1 index

1999 Oct 04 17

Philips Semiconductors Product specification

SDH/SONET STM16/OC48 multiplexer OQ2535HP

SOLDERING
Introduction to soldering surface mount packages

Thistextgivesa very brief insight to a complex technology.
A more in-depth account of soldering ICs can be found in
our

“Data Handbook IC26; Integrated Circuit Packages”

(document order number 9398 652 90011).
There is no soldering method that is ideal for all surface

mount IC packages. Wavesoldering is not always suitable
for surface mount ICs, or for printed-circuit boards with
high population densities. In these situations reflow
soldering is often used.

Reflow soldering

Reflow soldering requires solder paste (a suspension of
fine solder particles, flux and binding agent) to be applied
tothe printed-circuit board by screen printing,stencilling or
pressure-syringe dispensing before package placement.

Several methods exist for reflowing; for example,
infrared/convection heating in a conveyor type oven.
Throughput times (preheating, soldering and cooling)vary
between 100 and 200 seconds depending on heating
method.

Typical reflow peak temperatures range from
215 to 250 °C. The top-surface temperature of the
packages should preferable be kept below 230 °C.

Wave soldering

Conventional single wave soldering is not recommended
forsurfacemountdevices(SMDs) or printed-circuit boards
with a high component density, as solder bridging and
non-wetting can present major problems.

To overcome these problems the double-wave soldering
method was specifically developed.

If wave soldering is used the following conditions must be
observed for optimal results:

• Use a double-wave soldering method comprising a
turbulent wave with high upward pressure followed by a
smooth laminar wave.

• For packages with leads on two sides and a pitch (e):
– larger than or equal to 1.27 mm, the footprint

longitudinal axis is preferred to be parallel to the
transport direction of the printed-circuit board;

– smaller than 1.27 mm, the footprint longitudinal axis

must be parallel to the transport direction of the
printed-circuit board.

The footprint must incorporate solder thieves at the
downstream end.

• Forpackageswithleadson four sides, the footprint must
be placed at a 45° angle to the transport direction of the
printed-circuit board. The footprint must incorporate
solder thieves downstream and at the side corners.

During placement and before soldering, thepackage must
be fixed with a droplet of adhesive. The adhesive can be
applied by screen printing, pin transfer or syringe
dispensing. The package can be soldered after the
adhesive is cured.

Typical dwell time is 4 seconds at 250 °C.
A mildly-activated flux will eliminate the need for removal
of corrosive residues in most applications.

Manual soldering

Fix the component by first soldering two
diagonally-opposite end leads. Use a low voltage (24 V or
less) soldering iron applied to the flat part of the lead.
Contact time must be limited to 10 seconds at up to
300 °C.

When using a dedicated tool, all other leads can be
soldered in one operation within 2 to 5 seconds between
270 and 320 °C.

1999 Oct 04 18

Philips Semiconductors Product specification

SDH/SONET STM16/OC48 multiplexer OQ2535HP

Suitability of surface mount IC packages for wave and reflow soldering methods

Notes

1. All surface mount (SMD) packages are moisture sensitive. Depending upon the moisture content, the maximum
temperature (with respect to time) and body size of the package, there is a risk that internal or external package
cracks may occur due to vaporization of the moisture in them (the so called popcorn effect). For details, refer to the
Drypack information in the

“Data Handbook IC26; Integrated Circuit Packages; Section: Packing Methods”

.

2. These packages are not suitable for wave soldering as a solder joint between the printed-circuit board and heatsink
(at bottom version) can not be achieved, and as solder may stick to the heatsink (on top version).

3. If wave soldering is considered, then the package must be placed at a 45° angle to the solder wave direction.
The package footprint must incorporate solder thieves downstream and at the side corners.

4. Wave soldering is only suitable for LQFP, TQFP and QFP packages with a pitch (e) equal to or larger than 0.8 mm;
it is definitely not suitable for packages with a pitch (e) equal to or smaller than 0.65 mm.

5. Wave soldering is only suitable for SSOP and TSSOP packages with a pitch (e) equal to or larger than 0.65 mm; it is
definitely not suitable for packages with a pitch (e) equal to or smaller than 0.5 mm.

DEFINITIONS

LIFE SUPPORT APPLICATIONS

These products are not designed for use in life support appliances, devices, or systems where malfunction of these
products can reasonably be expected to result in personal injury. Philips customers using or selling these products for
use in such applications do so at their own risk and agree to fully indemnify Philips for any damages resulting from such
improper use or sale.

PACKAGE

SOLDERING METHOD

WAVE REFLOW

(1)

BGA, LFBGA, SQFP, TFBGA not suitable suitable
HBCC, HLQFP, HSQFP, HSOP, HTQFP, HTSSOP, SMS not suitable

(2)

suitable

PLCC

(3)

, SO, SOJ suitable suitable

LQFP, QFP, TQFP not recommended

(3)(4)

suitable

SSOP, TSSOP, VSO not recommended

(5)

suitable

Data sheet status

Objective specification This data sheet contains target or goal specifications for product development.
Preliminary specification This data sheet contains preliminary data; supplementary data may be published later.
Product specification This data sheet contains final product specifications.

Limiting values

Limiting values given are in accordance with the Absolute Maximum Rating System (IEC 134). Stress above one or
more of the limiting values may cause permanent damage to the device. These are stress ratings only and operation
of the device at these or at any other conditions above those given in the Characteristics sections of the specification
is not implied. Exposure to limiting values for extended periods may affect device reliability.

Application information

Where application information is given, it is advisory and does not form part of the specification.

1999 Oct 04 19

Philips Semiconductors Product specification

SDH/SONET STM16/OC48 multiplexer OQ2535HP

NOTES

© Philips Electronics N.V. SCA
All rights are reserved. Reproduction in whole or in part is prohibited without the prior written consent of the copyright owner.

The information presented in this document does not form part of any quotation or contract, is believed to be accurate and reliable and may be changed
without notice. No liability will be accepted by the publisher for any consequence of its use. Publication thereof does not convey nor imply any license
under patent- or other industrial or intellectual property rights.

Internet: http://www.semiconductors.philips.com

1999

68

Philips Semiconductors – a w orldwide compan y

For all other countries apply to: Philips Semiconductors,

International Marketing & Sales Communications, Building BE-p, P.O. Box 218,
5600 MD EINDHOVEN, The Netherlands, Fax. [phone]

Argentina: see South America
Australia: 3 Figtree Drive, HOMEBUSH, NSW 2140,

Tel. [phone], Fax. [phone]
Austria: Computerstr. 6, A-1101 WIEN, P.O. Box 213,

Tel. [phone], Fax. [phone]
Belarus: Hotel Minsk Business Center, Bld. 3, r. 1211, Volodarski Str. 6,

220050 MINSK, Tel. [phone], Fax. [phone]

Belgium: see The Netherlands
Brazil: see South America
Bulgaria: Philips Bulgaria Ltd., Energoproject, 15th floor,

51 James Bourchier Blvd., 1407 SOFIA,
Tel. [phone], Fax. [phone]

Canada: PHILIPS SEMICONDUCTORS/COMPONENTS,
Tel. [phone], Fax. [phone]

China/Hong Kong: 501 Hong Kong Industrial Technology Centre,
72 Tat Chee Avenue, Kowloon Tong, HONG KONG,
Tel. [phone], Fax. [phone]

Colombia: see South America
Czech Republic: see Austria
Denmark: Sydhavnsgade 23, 1780 COPENHAGEN V,

Tel. [phone], Fax. [phone]
Finland: Sinikalliontie 3, FIN-02630 ESPOO,

Tel. [phone], Fax. [phone]
France: 51 Rue Carnot, BP317, 92156 SURESNES Cedex,

Tel. [phone], Fax. [phone]
Germany: Hammerbrookstraße 69, D-20097 HAMBURG,

Tel. [phone], Fax. [phone]

Hungary: see Austria
India: Philips INDIA Ltd, Band Box Building, 2nd floor,

254-D, Dr. Annie Besant Road, Worli, MUMBAI 400 025,
Tel. [phone], Fax. [phone]

Indonesia: PTPhilips Development Corporation,Semiconductors Division,
Gedung Philips, Jl. Buncit Raya Kav.99-100, JAKARTA 12510,
Tel. [phone] ext. 2501, Fax. [phone]

Ireland: Newstead, Clonskeagh, DUBLIN 14,
Tel. [phone], Fax. [phone]

Israel: RAPAC Electronics, 7 Kehilat Saloniki St, PO Box 18053,
TEL AVIV 61180, Tel. [phone], Fax. [phone]

Italy: PHILIPS SEMICONDUCTORS, Via Casati,23 - 20052 MONZA (MI),
Tel. [phone], Fax [phone]

Japan: Philips Bldg 13-37, Kohnan 2-chome, Minato-ku,
TOKYO 108-8507, Tel. [phone], Fax. [phone]

Korea: Philips House, 260-199 Itaewon-dong, Yongsan-ku, SEOUL,
Tel. [phone], Fax. [phone]

Malaysia: No. 76 Jalan Universiti, 46200 PETALING JAYA, SELANGOR,
Tel. [phone], Fax. [phone]

Mexico: 5900 Gateway East, Suite 200, EL PASO, TEXAS 79905,
Tel. [phone], Fax [phone]

Middle East: see Italy

Netherlands: Postbus 90050, 5600 PB EINDHOVEN, Bldg. VB,

Tel. [phone], Fax. [phone]
New Zealand: 2 Wagener Place, C.P.O. Box 1041, AUCKLAND,

Tel. [phone], Fax. [phone]
Norway: Box 1, Manglerud 0612, OSLO,

Tel. [phone], Fax. [phone]

Pakistan: see Singapore
Philippines: Philips Semiconductors Philippines Inc.,

106 Valero St. Salcedo Village, P.O. Box 2108 MCC, MAKATI,
Metro MANILA, Tel. [phone], Fax. [phone]

Poland: Al.Jerozolimskie 195 B, 02-222 WARSAW,
Tel. [phone], Fax. [phone]

Portugal: see Spain
Romania: see Italy
Russia: Philips Russia, Ul. Usatcheva 35A, 119048 MOSCOW,

Tel. [phone], Fax. [phone]
Singapore: Lorong 1, Toa Payoh, SINGAPORE 319762,

Tel. [phone], Fax. [phone]

Slovakia: see Austria
Slovenia: see Italy
South Africa: S.A. PHILIPS Pty Ltd., 195-215 Main Road Martindale,

2092 JOHANNESBURG, P.O. Box 58088 Newville 2114,
Tel. [phone], Fax. [phone]

South America: Al. Vicente Pinzon, 173, 6th floor,
04547-130 SÃO PAULO, SP, Brazil,
Tel. [phone], Fax. [phone]

Spain: Balmes 22, 08007 BARCELONA,
Tel. [phone], Fax. [phone]

Sweden: Kottbygatan 7, Akalla, S-16485 STOCKHOLM,
Tel. [phone], Fax. [phone]

Switzerland: Allmendstrasse 140, CH-8027 ZÜRICH,
Tel. [phone] Fax. [phone]

Taiwan: Philips Semiconductors, 6F, No. 96, Chien Kuo N. Rd., Sec. 1,
TAIPEI, Taiwan Tel. [phone], Fax. [phone]

Thailand: PHILIPS ELECTRONICS (THAILAND) Ltd.,
209/2 Sanpavuth-Bangna Road Prakanong, BANGKOK 10260,
Tel. [phone], Fax. [phone]

Turkey: Yukari Dudullu, Org. San. Blg., 2.Cad. Nr. 28 81260 Umraniye,
ISTANBUL, Tel. [phone], Fax. [phone]

Ukraine: PHILIPS UKRAINE, 4 Patrice Lumumba str., Building B, Floor 7,
252042 KIEV, Tel. [phone], Fax. [phone]

United Kingdom: Philips Semiconductors Ltd., 276 Bath Road, Hayes,
MIDDLESEX UB3 5BX, Tel. [phone], Fax. [phone]

United States: 811 East Arques Avenue, SUNNYVALE, CA 94088-3409,
Tel. [phone], Fax. [phone]

Uruguay: see South America
Vietnam: see Singapore
Yugoslavia: PHILIPS, Trg N. Pasica 5/v, 11000 BEOGRAD,

Tel. [phone], Fax.[phone]

Printed in The Netherlands 465012/50/02/pp20 Date of release: 1999 Oct 04 Document order number: 9397 750 03901
