Micro Hi-Fi System
MCM240
México
Es necesario que lea cuidadosamente su instructivo de
manejo.
PRECAUCIÓN - ADVERTENCIA
No abrir, riesgo de choque eléctrico
Verifique que el voltaje de alimentación
sea el requerido para su aparato
Para evitar el riesgo de choque eléctrico, no quite la tapa.
En caso de requerir servicio, dirijase al personal calificado.
Descripción: Microsistema de Audio
Modelo : MCM240/21
Alimentación: 110–127 / 220–240V~; 50–60 Hz
Consumo: 7 W
Importador: Philips Mexicana, S.A. de C.V.
Domicilio: Av. La Palma No.6
Localidad y Tel: Edo. de México C.P. 52784
Exportador: Philips Electronics HK, Ltd.
País de Origen: China
Nº de Serie: ______________________________
ATENCIÓN
Col. San Fernando La Herradura
Huixquilucan
Tel.52 69 90 00
LEA CUIDADOSAMENTE ESTE INSTRUCTIVO
ANTES DE USAR SU APARATO.
AVISO IMPORTANTE
Philips Mexicana, S.A. de C .V. no se hace
responsable por daños o desperfectos causados por:
– Maltrato, descuido o mal uso, presencia de
insectos o roedores (cucarachas, ratones etc.).
– Cuando el aparato no haya sido operarado
de acuerdo con el instructivo del uso, fuera
de los valores nominales y tolerancias de las
tensiones (voltaje), frecuencia (ciclaje) de
alimentación eléctrica y las características
que deben reunir las instalaciones auxiliares.
– Por fenómenos naturales tales como:
temblores, in
eléctricas, rayos etc. o delitos causados por
terceros (choques asaltos, riñas
2
undaciones, incendios, descargas
, etc.).
CAUTION
Use of controls or
adjustments or performance
of procedures other than
herein may result in
hazardous radiation
exposure or other unsafe
operation.
1
1
3
4
!
7
@
0
8
%
*
3
5
#
$
&
^
(
)
2
5
6
7
8
9
!
0
33
4
Index
English ------------------------------------------------ 6
Français -------------------------------------------- 21
Español --------------------------------------------- 36
-------------------------------------------------------- 51
English
Français
Español
5
Contents
English
General Information
Environmental information ................................ 7
Supplied accessories ............................................ 7
Safety information ................................................ 7
Preparations
Rear connections .......................................... 8 – 9
Optional connection ........................................... 9
Before using the remote control ...................... 9
Replacing battery (lithium CR2025) into the
remote control ..................................................... 9
Controls
Controls on the system and remote
control .................................................................. 10
Connecting other equipment to your system
Radio Reception
Tuning to radio stations .................................... 15
Programming radio stations ............................. 15
Automatic programming
Manual programming
Tuning to preset radio stations ....................... 15
Changing tuning grid .......................................... 16
Clock/Timer
Setting the clock ................................................. 17
Viewing the clock ............................................... 17
Setting the timer ................................................. 17
Activating and deactivating TIMER ................. 17
Activating and deactivating SLEEP .................. 18
Specifications ........................................... 19
Basic Functions
Switching the system on ................................... 11
Switching the system to Standby mode ........ 11
Power Saving Automatic Standby .................... 11
Adjusting volume and sound............................ 11
CD/MP3-CD Operation
Loading a disc ...................................................... 12
Basic playback controls ..................................... 12
Playing an MP3 disc ............................................ 13
Different play modes: SHUFFLE and REPEAT13
Programming track numbers ........................... 13
Reviewing the programme ............................... 14
Erasing the programme ..................................... 14
Maintenance.............................................. 19
Tr oubleshooting .................................... 20
6
General Information
IMPORTANT!
PLEASE NOTE THAT THE VOLTAGE
SELECTOR LOCATED AT THE BOTTOM
OF THIS SYSTEM IS PRESET AT 220V
FROM THE FACTORY. FOR COUNTRIES
THAT OPERATE AT 110V-127V, PLEASE
ADJUST TO 110V-127V BEFORE YOU
SWITCH ON THE SYSTEM.
Environmental Information
All unnecessary packaging has been omitted. We
have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet).
Your system consists of materials which can be
recycled and reused if disassembled by a
specialized company. Please observe the local
regulations regarding the disposal of packaging
materials, exhausted batteries and old
equipment.
Supplied accessories
–2 speaker boxes
– remote control (with battery)
– MW loop antenna
– FM wire antenna
– stand
– screw and plug assembly
Safety Information
● Before operating the system, check that the
operating voltage indicated on the typeplate (or
the voltage indication beside the voltage
selector) of your system is identical with the
voltage of your local power supply. If not, please
consult your dealer.
● Place the system on a flat, hard and stable
surface.
● Place the system in a location with adequate
ventilation to prevent internal heat build-up in
your system. Allow at least 10 cm (4 inches)
clearance from the rear and the top of the unit
and 5 cm (2 inches) from each side.
● The ventilation should not be impeded by
covering the ventilation openings with items,
such as newspapers, table-cloths, cur tains, etc.
● Do not expose the system, batteries or discs to
excessive moisture, rain, sand or heat sources
caused by heating equipment or direct sunlight.
● No naked flame sources, such as lighted candles,
should be placed on the apparatus.
● No objects filled with liquids, such as vases, shall
be placed on the apparatus.
● If the system is brought directly from a cold to a
warm location, or is placed in a very damp room,
moisture may condense on the lens of the disc
unit inside the system. Should this occur, the CD
player would not operate normally. Leave the
power on for about one hour with no disc in the
system until normal playback is possible.
● The mechanical par ts of the set contain self-
lubricating bearings and must not be oiled or
lubricated.
● When the system is switched to Standby
mode, it is still consuming some power.
To disconnect the system from the
power supply completely, remove the AC
power plug from the wall socket.
English
7
Preparations
English
MW loop antenna
FM wire antenna
Speaker
(right)
AC power cord
Rear connections
The type plate is located at the rear of the
system.
A Powe r
– Before connecting the AC power cord to the
wall outlet, ensure that all other connections
have been made.
– If your system is equipped with a Voltage
Selector, set the VOLTAGE SELECTOR to the
local power line voltage.
Warning!
–For optimal performance, use only the
original power cable.
–Never make or change any connections
with the power switched on.
Speaker
(left)
VOLTAGE
SELECTOR
110V127V
220V240V
NOT FOR ALL
VERSIONS
B Antennas Connection
Connect the supplied MW loop antenna and FM
antenna to the respective terminals. Adjust the
position of the antenna for optimal reception.
MW Antenna
To avoid overheating of the system, a safety
circuit has been built in. Therefore, your
system may switch to Standby mode
automatically under extreme conditions. If
this happens, let the system cool down
before reusing it (not available for all versions).
8
● Position the antenna as far as possible from a TV,
VCR or other radiation source.
Preparations
FM Antenna
● For better FM stereo reception, connect an
outdoor FM antenna to the FM ANTENNA
terminal.
C Speakers Connection
Front Speakers
Connect the speaker wires to the SPEAKERS
terminals, right speaker to "RIGHT" and left
speaker to "LEFT", colored (marked) wire to "+"
and black (unmarked) wire to "-".
● Fully inser t the stripped por tion of the speaker
wire into the terminal as shown.
Notes:
–For optimal sound performance, use the
supplied speakers.
– Do not connect more than one speaker to any
one pair of +/- speaker terminals.
– Do not connect speakers with an impedance
lower than the speakers supplied. Please refer to
the SPECIFICATIONS section of this manual.
Before using the remote control
1 Pull out the plastic protective sheet.
2 Select the source you wish to control by
pressing one of the source select keys on the
remote control (for example CD, TUNER).
3 Then select the desired function (for example
ÉÅ , í , ë).
plastic
protective
sheet
Replacing battery (lithium
CR2025) into the remote control
1 Pull out the knob A slightly to the left.
2 Pull out the batter y compar tment B .
3 Replace a new batter y and fully insert the
battery compar tment back to the original
position.
English
Optional connection
The optional equipment and connecting cords are
not supplied. Refer to the operating instr uctions
of the connected equipment for details.
Connecting other equipment to your
system
Connect the audio left and right OUT terminals
of a TV, VCR, Laser Disc player, DVD player or
CD Recorder to the AUX terminals.
Note:
– If you are connecting equipment with a mono
output (a single audio out terminal), connect it to
the AUX left terminal. Alternatively, you can use a
“single to double” cinch cable (the output sound
still remain mono).
CAUTION!
Batteries contain chemical substances, so
they should be disposed of properly.
9
Controls (illustrations on page 3)
English
Controls on the system and
remote control
1 STANDBY-ONB
– switches the system on or to standby.
2 Display screen
– shows the status of the system.
3 OPEN • CLOSEç
– opens/closes the CD door.
4 IR
– remote sensor
5 VOLUME (3 / 4 ) (+/-)
– adjusts the volume level.
– adjusts the hours and minutes for the clock/timer
function.
6 CD Door
7 Mode Selection
ALBUM/ TUNE/ALBUM -/+ (à / á)
for TUNER ........ tunes to a station
for CD/MP3-CD fast searches back and
forward within a track/disc (press
and hold).
for MP3-CD .....skips to the beginning of a
current/previous/subsequent
album.
9 ............................. stops disc playback or erases a
disc programme.
ÉÅ ................... starts or interrupts playback.
PRESET (¡ / ™)
for TUNER ........ selects a preset radio station.
for CD/MP3 -CD skips to the beginning of a
current/previous/subsequent
track
8 DBB (Dynamic Bass Boost)
– enhances the bass.
9 BAND
– selects a waveband.
0 PROGRAM
for CD/MP3-CD programmes tracks and
reviews the programme.
for TUNER ........ programmes tuner stations.
! SOURCE
– selects the respective sound source for CD/
TUNER/ AUX.
10
@ DISPLAY/CLOCK
– sets the clock function.
– displays disc information during playback.
# TIMER
– activates/ deactivates or sets the timer function.
$ SLEEP
– activates/deactivates or selects the sleeper time.
% DSC (Digital Sound Control)
– selects sound characteristics: ROCK/ JAZZ/
POP/ CLASSIC.
^ RDS
–for tuner, displays RDS information. (not for all
versions).
& MUTE
– interr upts and resumes sound reproduction.
* REPEAT
– repeats a track/disc programme/entire disc.
( SHUFFLE
– plays disc tracks in random order.
) n
–connects headphones
Notes for remote control:
– First select the source you wish to
control by pressing one of the source select
keys on the remote control (for example
CD, TUNER).
– Then select the desired function (for
example ÉÅ,í , ë).
Basic Functions
Important!
Before you operate the system, complete
the preparation procedures.
Switching the system on
● Press STANDBY-ON (or B on the remote).
➜ The system will switch to the last selected
source.
● Press CD, TUNER or AUX on the remote
control.
➜ The system will switch to the selected source.
● Press OPEN•CLOSEç.
➜ The system will switch to the CD source.
Adjusting volume and sound
1 Press VOLUME 3 / 4 (+/-) to decrease or
increase the volume.
➜ Display shows the volume level VOL and a
number from MIN1, 2, ...30, 31 MAX.
2 Press DSC repeatedly to select the desired
sound effect: ROCK/ JAZZ/ POP/ CLASSIC.
3 Press DBB to switch bass enhancement on or
off.
➜ Display shows: DBB.
4 Press MUTE on the remote control to
interrupt sound reproduction instantly.
➜ Playback will continue without sound and the
display shows MUTE.
● To activate sound reproduction you can:
– press MUTE again;
– adjust the volume controls;
– change source.
English
Switching the system to Standby
mode
● Press STANDBY-ON (or B on the remote).
➜ The backlight for clock display is dim in
standby.
● The volume level (up to a maximum volume
level of 20), interactive sound settings, last
selected mode, source and tuner presets will be
retained in the player's memory.
Power Saving Automatic
Standby
As a power-saving feature, the system
automatically switches to Standby 15 minutes
after a CD has reached the end and no control
is operated.
11
CD/MP3-CD Operation
English
Basic playback controls
To play a disc
● Press ÉÅ to star t playback.
➜ The current track number and elapsed
playing time of the track are displayed during
disc playback.
To select a different track
● Press PRESETí / ë (or í / ë on the
remote) once or repeatedly until the desired
track number appears in the display.
● If you have selected a track number shortly after
loading a disc or in the PAUSE position, you will
need to press ÉÅ to start playback.
Important!
The lens of the CD player should never be
touched.
Loading a disc
This CD player plays Audio Discs including CD
Recordables, CD-Rewritables and MP3 CD.
● CD-ROM, CD-I, CDV, VCD, DVD or computer
CDs, however, are not possible .
1 Press SOURCE on the front panel of the
system to select CD or press CD on the
remote.
2 Press OPEN•CLOSEç to open the CD
compartment.
➜ OPEN is displayed when the compartment
cover slides up.
3 Inser t a disc with the printed side facing up.
Press OPEN•CLOSEç again to close the
compartment.
➜ READING is displayed as the CD player
scans the contents of a disc, and then the total
number of tracks and playing time (or the total
number of albums and tracks for MP3 disc) are
shown.
Te xt display during playback
In CD mode
● Press DISPLAY to show the current track
number and remaining playback time.
In MP3-CD mode
● Press DISPLAY repeatedly to show the current
album and track numbers followed by ID3
information (if available).
To find a passage within a track
1 Press and hold down on ALBUM/TUNE à /
á (or ALBUM -/+ à /á on the remote).
➜ The disc is played at high speed and low
volume.
2 When you recognize the passage you want,
release ALBUM/TUNE à /á (or ALBUM
-/+ à /á on the remote).
➜ Normal playback continues.
To interrupt playback
● Press ÉÅduring playback.
➜ The display freezes and the elapsed playing
time flashes when playback is interrupted.
➜ To resume, press ÉÅ again.
To stop playback
● Press 9.
12
CD/MP3-CD Operation
Notes:
CD play will also stop when;
– the CD door is opened.
– the disc has reached the end.
– you select another source: TUNER or AUX.
– you select standby.
– the set auto off time arrives.
– no button is pressed within 15 minutes in the
CD PAUSE position.
Playing an MP3 disc
1 Load an MP3 disc.
➜ The disc reading time may exceed 10
seconds due to the large number of songs
compiled into one disc.
➜ The total number of albums and tracks (titles)
are shown.
2 Press ALBUM/TUNE à /á (or ALBUM -/
+ à /á on the remote) to select a desired
album.
3 Press PRESETí / ë (or í / ë on the
remote) to select a desired track.
➜ The album number will change accordingly as
you reach the first track of an album by pressing
í or the last track of an album by pressing ë.
4 Press ÉÅ to star t playback.
Supported MP3 disc formats:
– ISO9660, Joliet, UDF 1.5
– Maximum title number: 400 (depending on
filename length)
– Maximum album number: 40
– Supported sampling frequencies: 32 kHz,
44.1kHz, 48 kHz
– Supported Bit-rates: 32~256 (kbps), variable
bitrates
REPEAT ............ plays the current track
continuously
1 To select your play mode, press SHUFFLE or
REPEAT on the remote control before or
during playback until the display shows the
desired function. (SHUFFLE, REPEAT, REPEAT
ALL)
2 PressÉÅ to start playback if in the STOP
position.
➜ If you have selected SHUFFLE, playback starts
automatically.
3 To return to normal playback, press the
respective SHUFFLE or REPEAT button until
the various SHUFFLE / REPEAT modes are no
longer displayed.
● You can also press 9 to cancel your play mode.
Programming track numbers
Program in the STOP position to select and
store your disc tracks in the desired sequence. If
you like, store any track more than once. Up to
40 tracks can be stored in the memory.
1 Press PROGRAM to enter the programming
mode.
➜ A track number is shown and PROGRAM
flashes.
2 Use PRESETí / ë (or í / ë on the
remote) to select your desired track number.
➜ For MP3 CD, press ALBUM/TUNE à /á
(or ALBUM -/+ à /á on the remote) to
select your desired album.
English
Different play modes: SHUFFLE
and REPEAT
You can select and change the various play
modes before or during playback. The REPEAT
modes can also be combined with PROGRAM.
SHUFFLE .........tracks of the entire disc are
played in random order
SHUFFLE and REPEAT ALL
................................. to repeat the entire disc
continuously in random order
REPEAT ALL ... repeats the entire disc/ program
13
CD/MP3-CD Operation
English
3 Press PROGRAM to confirm the track number
to be stored.
➜ PROG X is shown briefly, followed by the
number of the track (for MP3-CD, the album
and title numbers of the track) you just stored.
X denotes the next program number to be
stored
4 Repeat steps 2-3 to select and store all desired
tracks.
➜ FULL is displayed if you attempt to program
more than 40 tracks.
5 To star t playback of your disc program, press
STOP 9 followed by ÉÅ or press ÉÅ
directly.
Reviewing the program
In STOP mode, press and hold PROGRAM
until the display shows all your stored track
number in sequence.
Erasing the program
You can erase the program by:
● pressing STOP 9 once in the STOP mode;
● pressing STOP 9 twice during playback;
● opening the CD compartment;
➜ PROGRAM disappears, CLEAR scrolls and
then disappears from the display.
14
Tuning to radio stations
1 Press SOURCE on the front panel of the
system or TUNER on the remote to select
TUNER.
➜ TUNER is displayed briefly.
2 Press BAND on the front panel of the system
once or more to select your waveband (FM/
MW).
3 Press and hold ALBUM/TUNE à /á (or
ALBUM -/+ à /á on the remote).
➜ The radio automatically tunes to a station
with sufficient reception. Display indication
during automatic tuning: SEARCH.
4 Repeat step 3 if necessar y until you find the
desired station.
● To tune to a weak station, press ALBUM/
TUNE à /á (or ALBUM -/+ à /á on
the remote) briefly and repeatedly until you
have found optimal reception.
Radio Reception
1 Press PRESETí / ë (or í / ë on the
remote) to select the preset number where
programming should start.
Note:
– If no preset number is selected, default is preset
(1) and all your presets will be overridden.
2 Press PROGRAM for more than 2 seconds to
activate programming.
➜ AUTO is displayed and available stations are
programmed in order of waveband reception
strength: FM followed by MW. The last preset
automatically stored will then be played.
Manual programming
1 Tune to your desired station (see “Tuning to
radio stations”).
2 Press PROGRAM to activate programming.
3 Press PRESETí / ë (or í / ë on the
remote) to allocate a number from 1 to 40 to
this station.
4 Press PROGRAM again to confirm the setting.
➜ The preset number and the frequency of the
preset station are shown.
5 Repeat the above four steps to store other
stations.
● You can override a preset station by storing
another frequency in its place.
Tuning to preset radio stations
● Press PRESETí / ë (or í / ë on the
remote) until the desired preset station is
displayed.
English
Programming radio stations
You can store up to a total of 40 radio stations
in the memory for each band.
Automatic programming
Automatic programming will start with a chosen
preset number. From this preset number
upwards, former programmed radio stations will
be overridden.
15
Radio Reception
English
Changing tuning grid (not available for
all versions)
In North and South America, the frequency step
between adjacent channels in the MW band is
10 kHz (9 kHz in some areas).
Changing the tuning grid will erase all
previously stored preset radio stations.
1 Select TUNER source or in the tuner mode.
2 Press STOP on the set for at least 5 seconds.
➜ The display will show "GRID 9" or
"GRID10".
Notes:
– GRID 9 and GRID 10 indicate that the tuning
grid is in step of 9 kHz and 10 kHz respectively.
– The FM tuning grid also will be changed from
50 kHz to 100 kHz or vice versa.
16
Setting the clock
1 In standby mode or system on, press and hold
DISPLAY/CLOCK on the remote control for
more than 3 seconds.
➜ SET CLOCK scrolls on the display.
➜ The clock digits for the hours flash.
2 Press VOLUME (3 / 4) (+/-) to set the hours.
3 Press DISPLAY/CLOCK again.
➜ The clock digits for the minutes flash.
4 Press VOLUME (3 / 4) (+/-) to set the
minutes.
5 Press DISPLAY/CLOCK to confirm the time.
Note:
– The backlight for clock display is dim in standby.
Viewing the clock
● Press DISPLAY/CLOCK.
➜ The clock time is displayed.
Note:
– There is no time display during disc playback.
Clock/Timer
1 In standby mode or system on, press and hold
TIMER on the remote control for more than 3
seconds.
➜ Display sequence scrolls SET TIMER and
SELECT SOURCE.
➜ Display sequence shows CD, TUNER and
flashes.
2 Press VOLUME (3 / 4) (+/-) to select the
sound source.
3 Press TIMER to confirm your desired mode.
➜ The clock digits for the hours flash.
4 Press VOLUME (3 / 4) (+/-) to set the hours.
5 Press TIMER again.
➜ The clock digits for the minutes flash.
6 Press VOLUME (3 / 4) (+/-) to set the
minutes.
7 Press TIMER to confirm the time.
➜ Display sequence shows VOL12.
8 Press VOLUME (3 / 4) (+/-) to set the timer
volume level.
9 Press TIMER to confirm.
➜ The timer is now set and activated.
Activating and deactivating
TIMER
● Press TIMER on the remote to turn off the
timer or turn on to the last setting again.
➜ If activated, the timer information will display
for a few seconds, then the system resumes to
the last active source or stays in standby mode.
➜ If deactivated, “OFF” appears.
Note:
– The system will exit timer setting mode if no
button is pressed within 30 seconds.
English
Setting the timer
● The system can be used as an alarm clock,
whereby the CD, TUNER is switched on at a set
time. The clock time needs to be set first before
the timer can be used.
● During setting, if no button is pressed within 30
seconds, the system will exit timer setting mode
automatically.
17
Clock/Timer
English
Activating and deactivating
SLEEP
The sleep timer enables the
system to switch off by itself
after a set period of time.
● Press SLEEP on the remote
control once or more.
➜ Display shows SLEEP and one of the sleep
time options in sequence: 90, 60, 45, 30, 15,
OFF, 90... if you have selected a time. Once
SLEEP is activated, SLEEP is display.
● To deactivate, press SLEEP on the remote
control repeatedly until OFF is shown, or press
STANDBY-ON (or B on the remote).
➜ OFF is displayed.
18
Specifications
AMPLIFIER
Output power ..........................................2 x 5 W RMS
......................................................................... 200 W PMPO
Signal-to-noise ratio ....................................... ≥ 62 dBA
Frequency response ......... 63 – 16000 Hz, ± 3 dB
Input sensitivity AUX ....................... 0.5 V (max. 2 V)
Impedance loudspeakers ......................................... 4 Ω
Impedance headphones ....................32 Ω -1000 Ω
......................................................................................... <0.5W
CD PLAYER
Frequency range .................................. 30 – 16000 Hz
Signal-to-noise ratio ............................................ 75 dBA
TUNER
FM wave range ...................................87.5 – 108 MHz
MW wave range (9 kHz) ............. 531 – 1602 kHz
MW wave range (10 kHz)........... 530 – 1700 kHz
Tuning grid ............................................................ 9/10 kHz
Sensitivity at 75 Ω
– mono, 26 dB signal-to-noise ratio ............ 2.8 µV
– stereo, 46 dB signal-to-noise ratio ........ 61.4 µV
Selectivity ................................................................. ≥ 28 dB
Total harmonic distortion ..................................... ≤ 5%
Frequency response ..... 63 – 12500 Hz (± 3 dB)
Signal-to-noise-ratio ...................................... ≥ 50 dBA
SPEAKERS
Bass reflex system
Dimensions (w x h x d) ....166 x 245 x 90 (mm)
GENERAL INFORMATION
AC Po wer
For Version /21-21M .. 110 – 127 / 220 – 240 V;
....................................................... 50/60 Hz Switchable
For Version /30 ........................ 230 – 240 V; 50 Hz
Dimensions (w x h x d) ....250 x 245 x 96 (mm)
Weight(with/without speakers) ........... 4.4 / 2.5 kg
Standby power consumption ............................ <7 W
Specifications and external appearance are
subject to change without notice.
English
Cleaning the Cabinet
● Use a soft cloth slightly moistened with a mild
detergent solution. Do not use a solution
containing alcohol, spirits, ammonia or abrasives.
Cleaning Discs
● When a disc becomes dir ty,
clean it with a cleaning cloth.
Wipe the disc from the centre
out.
● Do not use solvents such as
benzene, thinner, commercially
available cleaners, or antistatic spray intended for
analogue records.
Maintenance
Cleaning the disc lens
● After prolonged use, dirt or dust may
accumulate at the disc lens. To ensure good
playback quality, clean the disc lens with Philips
CD Lens Cleaner or any commercially available
cleaner. Follow the instructions supplied with
cleaner.
19
Troubleshooting
English
WARNING
Under no circumstances should you try to repair the system yourself, as this will invalidate the
warranty. Do not open the system as there is a risk of electric shock.
If a fault occurs, first check the points listed below before taking the system for repair. If you
are unable to remedy a problem by following these hints, consult your dealer or Philips for
help.
Problem
“NO DISC” is displayed.
Radio reception is poor.
The system does not react when buttons
are pressed.
Sound cannot be heard or is of poor
quality.
The left and right sound outputs are
reversed.
The remote control does not function
properly.
The timer is not working.
The Clock/Timer setting is erased.
Solution
✔ Insert a disc.
✔ Check if the disc is inserted upside down.
✔ Wait until the moisture condensation at the lens
has cleared.
✔ Replace or clean the disc, see “Maintenance”.
✔ Use a finalised CD-RW or a correct MP3-CD
format disc.
✔ If the signal is too weak, adjust the antenna or
connect an external antenna for better
reception.
✔ Increase the distance between the Micro HiFi
System and your TV or VCR.
✔ Remove and reconnect the AC power plug and
switch on the system again.
✔ Adjust the volume.
✔ Disconnect the headphones.
✔ Check that the speakers are connected correctly.
✔ Check if the stripped speaker wire is clamped.
✔ Make sure the MP3-CD was recorded within
32~256 kbps bit rate with sampling frequencies
at 48 kHz, 44.1 kHz or 32 kHz.
✔ Check the speaker connections and location.
✔ Select the source (CD or TUNER, for example)
before pressing the function button (ÉÅ,í,
ë).
✔ Reduce the distance between the remote
control and the system.
✔ Insert the battery with its polarities
(+/– signs) aligned as indicated.
✔ Replace the battery.
✔ Point the remote control directly toward
IR sensor on the front of the system.
✔ Set the clock correctly.
✔ Press TIMER to switch on the timer.
✔ Power has been interrupted or the power cord
has been disconnected. Reset the clock/timer.
20
Loading...
