Philips
DVD Micro Theater
MCD700
Rich movie and great
sound experience
With a mirror-finished center-unit that adds a touch of stylishness to any interior. The
wood-finished speakers deliver high quality sound and with DVD playability, you can now
satisfy both your audio and video needs on one micro system.
Enrich your movie experience
• Play DVD, (S)VCD, MP3-CD, WMA-CD, CD(RW) & Picture CD
• 12-bit/108MHz video processing for sharp, natural images
• Progressive Scan component video for optimized image quality
• Dolby Digital for ultimate movie experience
• Dolby Digital, DTS Digital Out
Enrich your sound experience
• Digital Sound Control for optimized music style settings
• Dynamic Bass Boost for deep and dramatic sound
• Loudness for bass and treble enhancement
• 2x25W RMS/50W Total Power
Design that blends into your interior(s)
• High-end component design with stand
• Elegant wood-finished speakers
• High quality remote control for comfortable use
Page 2
DVD Micro Theater
Highlights
12-bit/108MHz video DAC
Progressive Scan
MCD700/37
High-end component design
12-bit Video DAC is a superior Digital-toAnalogue-Converter that preserves every
detail of the authentic picture quality. It shows
subtle shades and smoother graduation of
colors, resulting in a more vibrant and natural
picture. The limitation of the usual 10bit DAC
become in particular apparent while using large
screens and projectors.
Progressive Scan doubles the vertical
resolution of the image resulting in a noticeably
sharper picture. Instead of sending a field
comprising the odd lines to the screen first,
followed by the field with the even lines, both
fields are written at one time. A full image is
created instantaneously, using the maximum
resolution. At such a speed, your eye perceives
a sharper picture with no line structure.
Loudness for bass and treble
In the sound spectrum, high and low
frequencies are relatively less audible to human
ears - especially at low volumes. By activating
the Loudness feature, the bass and treble will
be amplified so you can savor a more balanced
sound perception overall.
The component-designed DVD micro system
comes with a stand that features four
triangular feet. It can prevent any audio
frequency distortion due to vibration,
overheating and electromagnetic interference
generated from the amplifier and DVD loader.
The result is smooth and excellent and sound
reproduction.
High quality remote Control
The remote control is a perfect balance of
dimensions and weight. Sleek and
ergonomically designed, the bottom cover of
remote control features a soft rubber-paint
finish to ensure comfort in usage.
Page 3
DVD Micro Theater
Specifications
MCD700/37
Sound
• Output Power: 50 watts Total power
• Sound Enhancement: Loudness, Digital Sound
Control 4 modes, Dynamic Bass Boost, Reverb
Mode
• Sound System: Dolby Digital
Loudspeakers
• Main Speaker: 2 way, 4" woofer, Bass Reflex
Speaker System, Speaker grilles detachable
Video Playback
• Playback Media: DVD+RW, DVD-Video, Video
CD/SVCD, Picture CD
• Video Enhancement: Progressive Scan
• Disc Playback Modes: Parental control, Angle,
Zoom, Slow Motion, Dynamic Range
Compression, PBC, A-B Repeat
•DVD Region.: 1
Audio Playback
• Playback Media: WMA-CD, MP3-CD, CD-RW,
CD-R, CD
• Disc Playback Modes: 20-Track Programmable,
Repeat/one/all/program, Shuffle Play
• Loader Type: Motorised, Top
Tuner/Reception/Transmission
• Auto digital tuning
• Station presets: 40
• Tuner Bands: FM Stereo, AM
Connectivity
• Video Output - Analog: Component Y Pb Pr
(cinch), Composite CVBS (yellow cinch), S-Video
(on Hosiden)
• Other connections: Active subwoofer Pre-out,
Digital audio coaxial out, Digital optical out, FM
Antenna, AM Antenna
• Aux in: 2x(L/R)/ RCA
• Headphone: 3.5 mm
Convenience
• Alarms: CD Alarm, Sleep timer
• Clock: On main display
• Display Type: White FTD
• OSD Languages: English, French, Spanish
Accessories
• Included Accessories: Control cable, Composite
video cable (Y), FM/MW Antenna
• Remote control: 49-key with 2xAAA batteries
Dimensions
• Set dimensions (W x H x D): 208 x 156 x 268 mm
• Main speaker dimensions (W x H x D):
145
x 230 x 210 mm
• Packaging dimensions (W x H x D):
475
x 275 x 335 mm
• Weight incl. Packaging: 11 kg
•
Issue date 2009-06-24
Version: 6.2.10
12 NC: 9073 100 13003
UPC: 0 37849 96572 6
© 2009 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
