MCD2010

用户手册 27User manual 3

English

Contents

1 Important 4

Know these safety symbols 4 Important Safety Instructions 4 Hearing safety 5 Notice 5

2 Congratulations 7

Feature introduction 7 What's in the box 7 Overview of the main unit 8

3 Before use 11

Place the unit 11 Connect 11 Prepare the remote control 13

7 Setup 20

General setup 20 Video Setup 20 Audio Setup 20 Preference setup 21

8 Other features 22

Set alarm timer 22 Set sleep timer 22 Listen through headphone 22 Listen to external audio device 22

9 Product information 23

Region Code 23

Specications 23

Supported disc formats 24 Supported audio 24 USB playability information 24

4 Get started 13

Turn on 13 Store radio stations automatically 14 Find the correct video input channel 14 Select the correct TV system 14 Select a language for on-screen display 14

5 Play disc/USB 15

Basic operation 15 Play a disc 15

Play recored les 15

Control the play 16 Picture view options 17 Play slideshow and music simultaneously 18 Adjust sound 18

6 Listen to FM radio 18

Tune to FM radio stations 18 Program radio stations automatically 18 Program radio stations manually 19 Tune to a preset radio station 19

10 Troubleshooting 25

1 Important

Know these safety symbols

This 'bolt of lightning' indicates uninsulated material within your unit may cause an electrical shock. For the safety of everyone in your household, please do not remove product covering. The 'exclamation point' calls attention to features for which you should read the enclosed literature closely to prevent operating and maintenance problems.

WARNING: To reduce the risk of re or electric

shock, this apparatus should not be exposed to

rain or moisture and objects lled with liquids,

such as vases, should not be placed on this apparatus. CAUTION: To prevent electric shock, match wide blade of plug to wide slot, fully insert.

Important Safety Instructions

• Heed all warnings.

• Follow all instructions.

• Do not use this device near water.

• Clean only with dry cloth.

• Do not block any ventilation openings.

Install in accordance with the manufacturer's instructions.

• Do not install near any heat sources such as radiators, heat registers, stoves, or other

devices (including ampliers) that produce

heat.

• Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the device.

• Only use attachments/accessories specied

by the manufacturer.

• Unplug this device during lightning storms or when unused for long periods of time.

• Refer all servicing to qualied service personnel. Servicing is required when the

device has been damaged in any way, such as power-supply cord or plug is damaged,

liquid has been spilled or objects have

fallen into the device, the device has been exposed to rain or moisture, does not operate normally, or has been dropped.

• Battery usage CAUTION – to prevent battery leakage which may result in bodily injury, property damage, or damage to the unit:

• Install all batteries correctly, + and - as

marked on the unit.

• Do not mix batteries (old and new or

carbon and alkaline, etc.).

• Remove batteries when the unit is not

used for a long time.

• Batteries (battery pack or batteries

installed) shall not be exposed to excessive heat such as sunshine, re, or

the like.

• Devices shall not be exposed to dripping or splashing.

• Do not place any sources of danger on the device (e.g. liquid lled objects, lighted candles).

• Where the MAINS plug or an appliance

coupler is used as the disconnect device, the disconnect device shall remain readily operable.

English

Warning

• Never remove the casing of this device.

• Never lubricate any part of this device.

• Never place this device on other electrical equipment.

• Keep this device away from direct sunlight, naked

ames or heat.

• Ensure that you always have easy access to the power

cord, plug, or adapter to disconnect the device from the power.

Caution

• Use of controls or adjustments or performance of

procedures other than herein may result in hazardous radiation exposure or other unsafe operation.

Hearing safety

Listen at a moderate volume.

• Using headphones at a high volume can impair your hearing. This product can produce sounds in decibel ranges that may cause hearing loss for a normal person, even for exposure less than a minute. The higher decibel ranges are offered for those that may have already experienced some hearing loss.

• Sound can be deceiving. Over time your hearing 'comfort level' adapts to higher volumes of sound. So after prolonged listening, what sounds 'normal' can actually be loud and harmful to your hearing. To guard against this, set your volume to a safe level before your hearing adapts and leave it there.

To establish a safe volume level:

• Set your volume control at a low setting.

• Slowly increase the sound until you can

hear it comfortably and clearly, without distortion.

Listen for reasonable periods of time:

• Prolonged exposure to sound, even at normally 'safe' levels, can also cause hearing loss.

• Be sure to use your equipment reasonably

and take appropriate breaks.

Be sure to observe the following guidelines when using your headphones.

• Listen at reasonable volumes for reasonable periods of time.

• Be careful not to adjust the volume as your hearing adapts.

• Do not turn up the volume so high that you can't hear what's around you.

• You should use caution or temporarily discontinue use in potentially hazardous situations. Do not use headphones while operating a motorized vehicle, cycling,

skateboarding, etc.; it may create a trafc

hazard and is illegal in many areas.

Notice

Any changes or modications made to this

device that are not expressly approved by Philips Consumer Lifestyle may void the user’s

authority to operate the equipment.

Disposal of your old product and batteries

Your product is designed and manufactured

with high quality materials and components,

which can be recycled and reused. Never dispose of your product with other household waste. Please inform yourself about the local rules on the separate collection of electrical and electronic products and batteries. The correct disposal of these products helps

prevent potentially negative consequences on

the environment and human health.

Your product contains batteries, which cannot be disposed of with normal household waste. Please inform yourself about the local rules on separate collection of batteries. The correct disposal of batteries helps prevent potentially

negative consequences on the environment and

human health. Please visit www.recycle.philips.com for additional information on a recycling center in your area.

Environmental information

All unnecessary packaging has been omitted. We have tried to make the packaging easy to

separate into three materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet.)

Your system consists of materials which can be recycled and reused if disassembled by a specialized company. Please observe the local regulations regarding the disposal of packaging materials, exhausted batteries and old

equipment.

'DVD Video' is a trademark of DVD Format/ Logo Licensing Corporation.

ABOUT DIVX VIDEO: DivX® is a digital video

format created by DivX, Inc. This is an ofcial DivX Certied device that plays DivX video.

Visit www.divx.com for more information and

software tools to convert your les into DivX

video. ABOUT DIVX VIDEO-ON-DEMAND: This

DivX Certied order to play DivX Video-on-Demand (VOD)

content. To generate the registration code, locate the DivX VOD section in the device setup menu. Go to vod.divx.com with this code to complete the registration process and learn more about DivX VOD.

DivX

, DivX Certied® and associated logos

are registered trademarks of DivX, Inc. and are used under license.

device must be registered in

This item incorporates copy protection technology that is protected by U.S. patents and other intellectual property rights of Rovi Corporation. Reverse engineering and disassembly are prohibited.

Trademark notice

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

Note

• The type plate is located on the bottom of the unit.

English

2 Congratulations

What's in the box

Congratulations on your purchase, and

welcome to Philips! To fully benet from the

support that Philips offers, register your product at www.philips.com/welcome. If you contact Philips, you will be asked for the model and serial number of this product. The model number and serial number are on the back of the main unit. Write the numbers here: Model No. __________________________ Serial No. ___________________________

Feature introduction

This unit can

• play videos, audios, and display pictures from discs and USB storage devices

For the details of supported media, refer to

"Specications".

Check and identify the contents of your package:

• Main unit

• 2 X speakers

• Remote control

• Video cable

• User manual

• Quick start guide

Overview of the main unit

b c

a Disc compartment

• Hold the disc.

• USB socket.

c MP3 LINK

• Connect external audio device.

• Headphone socket.

• Turn on the apparatus, switch to

standby mode, or Eco Power standby mode.

f IR sensor

• Detect signals from the remote

control. Always point the remote control at the IR sensor.

hij

g SOURCE

• Select a source.

h TUNING

• Rotate a photo.

• Fast backward or forward.

• Start or pause play.

• Stop play.

• Erase a program.

k PRESET

• Skip to the previous/next track, title, or le.

• Select a programmed radio station.

English

l Display panel

• Show current status.

• Open or close the disc tray.

n VOLUME

• Adjust volume.

• Adjust time.

Overview of remote control

• Switch the micro system on/off.

b DISC/DISC MENU/FM/USB/AUX/MP3

LINK

• Select the source.

• Access the home menu.

d RDS/INFO

• Show the disk information such as title, chapter, time elapsed, total time, biterate etc. (RDS is not available on

this unit.)

e AUDIO / SUBTITLE

• For menus: navigate up/down.

• Invert a picture.

• AUDIO: Toggle between stereo and

mono.

• SUBTITLE: Select a subtitle language for a video.

f OK

• Conrm a selection.

• In FM mode, toggle between mono

and stereo sound output.

g /

• Search in a track or disc.

• Fast backward or forward.

• For menus, navigate left/right.

• Rotate a picture.

• Return to a previous display menu.

• Start, pause or resume play.

j /

• Skip to the previous/next track, title, or le.

• Select a programmed radio station.

k VOL +/-

• Adjust the volume.

l Numeric buttons

• Select a title/chapter/track to play.

m PROG/CLOCK SET

• Program radio stations.

• Set clock.

n TIMER/SLEEP

• Set sleep timer.

• Set alarm timer.

• Mute.

• Stop play.

• Erase a programed radio station.

• Activate/deactivate the demonstration

mode.

q DSC/DBB

• Select a preset sound setting.

• Turn on or off dynamic bass

enhancement.

r MODE/OPTIONS

• Select repeat play or random play.

• Accesses options relating to the

current activity or selection.
