Philips MCD183 98 User Manual

www.philips.com/welcome

MCD183

EN User manual

=+7: Ԛʹ˫

⚻⵵#❃῏✻

Contents

1 Important 4

Safety 4

Important Safety Instructions 4 Hearing safety 5

Notice 6

2 Your DVD Micro Theater 7

Introduction 7 What’s in the box 7 Overview of the main unit 8 Overview of the remote control 9

3 Connect 12

Place the unit 12 Connect speakers and subwoofer 12 Connect FM antenna 12 Connect TV 13

Connect video cables 13 Option 1: Connect through component

video 13

Option 2: Connect through S-Video

Option 3: Connect through composite

video 14

Connect audio cables 14

Connect power 14

4 Get started 15

Prepare the remote control 15 Set clock 15 Turn on 15

Switch to standby mode 15 Find the correct viewing channel 15 Select the correct TV system 16 Change system menu language 16 Turn on Progressive Scan 16

5 Play 18

Play a disc 18

Use the disc menu 18 Select an audio language 18

Select a subtitle language 18 Play from USB 18 Play DivX video 19 Play MP3/WMA/picture ﬁ les 19 Play control 19

Select repeat/shufﬂ e play options 19

Repeat A-B (DVD/VCD/CD/MP3/

WMA) 20 Search forward/backward 20 Search by time or chapter/track

number 20 Resume video play from last stopped

point 20

Play options 20

Display play information 20 Program 20 Zoom in/out image 21 Slow-motion play 21 Change the audio channel 21 Select a camera angle 21

Picture view options 21

Preview pictures 21 Select a slide show play mode 21 Rotate picture 21

6 Adjust settings 22

General setup 22 Audio setup 22 Video setup 23 Preference setup 23

7 Tune to FM radio stations 25

Program radio stations automatically 25 Program radio stations manually 25 Tune to a preset radio station 25

English

8 Adjust volume level and sound effect

Adjust volume level 26 Select a sound effect 26

Select a preset sound effect 26 Enhance bass 26

Select automatic loudness control 26 Mute sound 26 Listen through headphone 26

9 Other features 27

Activate demonstration mode 27 Adjust brightness of display panel 27 Set the alarm timer 27 Set the sleep timer 27 Connect other devices 27

Listen to an audio player 27

Record to a digital recorder 28

10 Product information 29

Speciﬁ cations 29

Ampliﬁ er 29

Disc 29

Tuner (FM) 29

Speakers 29

General information 29 Supported disc formats 30 USB playability information 30

11 Troubleshooting 31

1 Important

g Do not block any ventilation openings.

Install in accordance with the manufacturer’s instructions.

Safety

Know these safety symbols

This ‘bolt of lightning’ indicates uninsulated material within your unit may cause an electrical shock. For the safety of everyone in your household, please do not remove product covering. The ‘exclamation point’ calls attention to features for which you should read the enclosed literature closely to prevent operating and maintenance problems. WARNING: To reduce the risk of ﬁ re or electric shock, this apparatus should not be exposed to rain or moisture and objects ﬁ lled with liquids, such as vases, should not be placed on this apparatus. CAUTION: To prevent electric shock, match wide blade of plug to wide slot, fully insert.

Important Safety Instructions

a Read these instructions. b Keep these instructions.

h Do not install near any heat sources such

as radiators, heat registers, stoves, or other apparatus (including ampliﬁ ers) that produce heat.

i Protect the power cord from being

walked on or pinched, particularly at plugs, convenience receptacles, and the point where they exit from the apparatus.

j Only use attachments/accessories

speciﬁ ed by the manufacturer.

k Use only with the cart, stand, tripod,

bracket, or table speciﬁ ed by the manufacturer or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

l Unplug this apparatus during lightning

storms or when unused for long periods of time.

m Refer all servicing to qualiﬁ ed service

personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

English

c Heed all warnings. d Follow all instructions. e Do not use this apparatus near water. f Clean only with dry cloth.

n Battery usage CAUTION – To prevent

battery leakage which may result in bodily injury, property damage, or damage to the unit:

Install all batteries correctly, + and - as • marked on the unit.

Do not mix batteries (old and new or • carbon and alkaline, etc.). Remove batteries when the unit is not • used for a long time.

o Apparatus shall not be exposed to

dripping or splashing.

p Do not place any sources of danger on

the apparatus (e.g. liquid ﬁ lled objects, lighted candles).

q This product may contain lead and

mercury. Disposal of these materials may be regulated due to environmental considerations. For disposal or recycling information, please contact your local authorities or the Electronic Industries Alliance: www.eiae.org.

Caution

Use of controls or adjustments or performance of • procedures other than herein may result in hazardous radiation exposure or other unsafe operation.

Warning

Never remove the casing of this unit. • Never lubricate any part of this unit.• Place this unit on a ﬂ at, hard and stable surface.• Never place this unit on other electrical equipment.• Only use this unit indoors. Keep this unit away from • water, moisture and liquid-ﬁ lled objects.

•

Keep this unit away from direct sunlight, naked ﬂ ames or heat.

•

Never look into the laser beam inside the unit.

Warning

Where the MAINS plug or an appliance coupler is used • as the disconnect device, the disconnect device shall remain readily operable.

Hearing safety

Listen at a moderate volume.

Using headphones at a high volume can • impair your hearing. This product can produce sounds in decibel ranges that may cause hearing loss for a normal person, even for exposure less than a minute. The higher decibel ranges are offered for those that may have already experienced some hearing loss. Sound can be deceiving. Over time your • hearing ‘comfort level’ adapts to higher volumes of sound. So after prolonged listening, what sounds ‘normal’ can actually be loud and harmful to your hearing. To guard against this, set your volume to a safe level before your hearing adapts and leave it there.

To establish a safe volume level:

Set your volume control at a low setting. • Slowly increase the sound until you can • hear it comfortably and clearly, without distortion.

Listen for reasonable periods of time:

Prolonged exposure to sound, even at • normally ‘safe’ levels, can also cause hearing loss. Be sure to use your equipment reasonably • and take appropriate breaks.

Be sure to observe the following guidelines when using your headphones.

Listen at reasonable volumes for • reasonable periods of time. Be careful not to adjust the volume as your • hearing adapts. Do not turn up the volume so high that • you can’t hear what’s around you. You should use caution or temporarily • discontinue use in potentially hazardous situations. Do not use headphones while operating a motorized vehicle, cycling, skateboarding, etc.; it may create a trafﬁ c hazard and is illegal in many areas.

Notice

Any changes or modiﬁ cations made to this device that are not expressly approved by Philips Consumer Lifestyle may void the user’s authority to operate the equipment.

Environmental information

All unnecessary packaging has been omitted. We have tried to make the packaging easy to separate into three materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet.) Your system consists of materials which can be recycled and reused if disassembled by a specialized company. Please observe the local regulations regarding the disposal of packaging materials, exhausted batteries and old equipment.

DivX, DivX Certiﬁ ed, and associated logos are trademarks of DivX, Inc. and are used under license.

English

The USB-IF Logos are trademarks of Universal Serial Bus Implementers Forum, inc.

This apparatus includes this label:

Note

The making of unauthorized copies of copyprotected material, including computer programs, ﬁ les, broadcasts and sound recordings, may be an infringement of copyrights and constitute a criminal offence. This equipment should not be used for such purposes.

‘DVD Video’ is a trademark of DVD Format/ Logo Licensing Corporation.

The type plate is located on the bottom of the • apparatus.

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

2 Your DVD

Micro Theater

Congratulations on your purchase, and welcome to Philips! To fully beneﬁ t from the support that Philips offers, register your product at www.Philips.com/welcome.

DVD region code Countries

Asia Paciﬁ c, Taiwan, Korea

Australia, New Zealand

What’s in the box

Introduction

With this unit, you can:

watch video from DVD/VCD/SVCD or • USB devices enjoy audio from discs or USB devices• view pictures from discs or USB devices• Listen to FM radio•

You can enrich sound output with these sound effects:

Digital Sound Control (DSC)• Dynamic Bass Boost (DBB)• Bass/treble enhancement•

The unit supports these media/disc formats:

Recordable

Check and identify the contents of your package:

Main unit• 2 speakers• Subwoofer• Remote control with battery• Composite video cable (yellow)• Power cord• FM wire antenna• MP3 Link cable• User manual• Quick start guide•

ReWritable

You can play DVD discs with the following region codes:

Overview of the main unit

m l

English

a b

Turn on the apparatus; switch to • standby mode.

b SOURCE

Select a source.•

c VOL -/+

Adjust volume.• Adjust time.• During timer setting, select a source.•

d /

Skip to the previous/next track.• Skip to the previous/next title or • chapter. Select a preset radio station. •

e Disc compartment f

Headphone socket.•

g MP3-LINK

Jack for an external audio device.•

f g h

h USB DIRECT

USB socket.•

Open or close the disc compartment.•

j MODE

Select repeat play modes.• Select shufﬂ e play modes.•

Overview of the remote control

k Remote control sensor l

Start or pause play.•

Stop play.• Erase a program.• In demo mode, activate or deactivate • demonstration.

n Display panel

Display current status.•

w v

t s

d e

Turn on the apparatus; switch to • standby mode.

b Source selection keys

Select a source.•

m n

c DISPLAY/RDS (RDS function unavailable

for this version)

Display play information on a • connected TV.

d DISC MENU

For video discs: access or exit the disc • menu. For video discs with playback • control(PBC): turn on/off PBC.

e AUDIO

For VCD, select stereo, mono-left or • mono-right channel. For DVD/DivX video, select an audio • language.

Search within a track.• Tune to a radio station.• For menus, navigate left/right.• Move an enlarged picture left/right.• Rotate or invert pictures.•

SLOW / ZOOM

For menus, navigate up/down.• Move an enlarged picture up/down.• Rotate or invert pictures.• (•

SLOW) For video discs: select a slow play mode. (•

ZOOM) For pictures or video: zoom in/out.

h LOUD/DBB

Turn on or off automatic loudness • adjustment. Turn on or off dynamic bass • enhancement.

i VOL +/-

Adjust volume.• Adjust time.• During timer setting, select a source.•

l SLEEP/TIMER

Set the sleep timer.• Set the alarm timer.•

m SUBTITLE

Select a subtitle language.•

n GOTO

During disc play, specify a position to • start play.

o ANGLE/PROG

Select a DVD camera angle.• Program tracks.• Program titles/chapters for DVD play.• Program radio stations.•

p Numeric keypad

Select a title/chapter/track directly.•

Stop play.• Erase a program.•

Skip to the previous/next track.• Skip to the previous/next title or • chapter. Select a preset radio station.•

Start or pause play.•

t DSC

Select a preset sound setting.•

u OK

Conﬁ rm a selection.•

v A-B

Repeat a speciﬁ c section within a • track/disc.

w SYSTEM MENU

Access or exit the system setup menu.•

English

j MUTE

Mute or restore volume.•

k CLOCK

Set the clock.•

x MODE/DIM

Select repeat play modes.• Select shufﬂ e play modes.• Select a brightness level for the display • screen.
