Philips MC230E 22 User Manual

Micro Hi-Fi System

MC230E

user manual manuel d'utilisation manual del usario benutzerhandbuch manuale per l'utente

manual do usuário

Instrukcje obsługi uživatelské příručky používateľské príručky felhasználói útmutatók

Important notes for users in the U.K.

Mains plug

This apparatus is fitted with an approved 13 Amp plug. To change a fuse in this type of plug proceed as follows:

1 Remove fuse cover and fuse.

2 Fix new fuse which should be a BS1362 5 Amp,

A.S.T.A. or BSI approved type.

3 Refit the fuse cover.

If the fitted plug is not suitable for your socket outlets, it should be cut off and an appropriate plug fitted in its place. If the mains plug contains a fuse, this should have a value of 5 Amp. If a plug without a fuse is used, the fuse at the distribution board should not be greater than 5 Amp.

Note: The severed plug must be disposed of to avoid a possible shock hazard should it be inserted into a 13 Amp socket elsewhere.

How to connect a plug

The wires in the mains lead are coloured with the following code: blue = neutral (N), brown = live (L).

¶ As these colour s may not correspond with the

colour markings identifying the terminals in your plug, proceed as follows: – Connect the blue wire to the terminal marked N or coloured black. – Connect the brown wire to the terminal marked L or coloured red. – Do not connect either wire to the earth terminal in the plug, marked E (or e) or coloured green (or green and yellow).

Before replacing the plug cover, make certain that the cord grip is clamped over the sheath of the lead - not simply over the two wires.

Italia

DICHIARAZIONE DI CONFORMITA’

Si dichiara che l’apparecchio MC230E Philips risponde alle prescrizioni dell’ar t. 2 comma 1 del D.M. 28 Agosto 1995 n. 548.

Fatto a Eindhoven

Philips Consumer Electronics

Philips, Glaslaan 2

5616 JB Eindhoven, The Netherlands

CAUTION

Use of controls or adjustments or performance of procedures other than herein may result in hazardous radiation exposure or other unsafe operation.

Recording and playback of material may require consent. See Copyright Act 1956 and The Performer’s Protection Acts 1958 to 1972.

1 3 4

@ 0

8 % *

& ^

(

MAGYARORSZÁG

ČESKA REPUBLIKÁ

Minőségtanúsítás

A garanciajegyen feltüntetett forgalombahozó vállalat a 2/1984. (III.10.) BkM-IpM együttes rendelet értelmében tanúsítja, hogy ezen készülék megfelel a műszaki adatokban megadott értékeknek.

Figyelem! A meghibásodott készüléket – beleértve a hálózati csatlakozót is – csak szakember (szerviz) javíthatja. Ne tegye ki a készüléket esőnek vagy nedvesség hatásának!

Garancia

A forgalombahozó vállalat a termékre 12 hónap garanciát vállal.

Névleges feszültség .......................220-230 V / 50 Hz

Elemes működéshez ................................. 1 x CR2025

Névleges frekvencia .......... 50 Hz (vagy 50-60 Hz)

Teljesítmény

maximális ...................................................................... 40 W

névleges ......................................................................... 10 W

készenléti állapotban ............................................ < 3 W

Érintésvédelmi osztály II.

Tömeg ............................................................................ 4.2 kg

Befoglaló méretek

szélesség ............................................................. 582 mm

magasság ............................................................. 245 mm

mélység ................................................................... 96 mm

Vystraha! Tento přístroj pracuje s laserovým paprskem. Při nesprávné manipulaci s přístrojem (v rozporu s tímto návodem) můņe dojít k nebezpečnému ozáření. Proto přístroj za chodu neotevírejte ani nesnímejte jeho kryty. Jakoukoli opravu vždy svěřte specializovanému servisu.

Nebezpečí! Při sejmutí krytů a odjištění bezpečnostních spínačů hrozí nebezpečí neviditelného laserového záření!

Chraňte se před přímým zásahem laserového paprsku.

Záruka: Pokud byste z jakéhokoli důvodu přístroj demontovali, vždy nejdříve vytáhněte síťovou zástrčku.

Přístroj chraňte před jakoukoli vlhkostí i před kapkami

SLOVAK REPUBLIC

Prístroj sa nesmie používať v mokrom a vlhkom prostredí! Chránte pred striekajúcou a kvapkajúcou vodou!

Rádiórész vételi tartomány

URH .......................................................... 87,5 – 108 MHz

MW .......................................................... 531 – 1602 KHz

Erősítő rész

Kimeneti teljesítmény .......................... 200 W PMPO

........................................................................... 2 x 5 W RMS

Index

English ------------------------------------------------ 6

Français -------------------------------------------- 20

Español --------------------------------------------- 35

Deutsch --------------------------------------------- 49

Italiano ---------------------------------------------- 64

Por tuguês ------------------------------------------ 79

Polski ------------------------------------------------ 94

English

Français

EspañolDeutschItaliano

Por tuguês

PolskiČeskySlovensky

Česky ---------------------------------------------- 109

Slovensky ---------------------------------------- 124

Magyar -------------------------------------------- 139

Magyar

Contents

English

General Information

Environmental information ................................ 7

Supplied accessories ............................................ 7

Safety information ................................................ 7

Preparations

Rear connections .......................................... 8 – 9

Optional connection ........................................... 9

Before using the remote control ...................... 9

Replacing battery (lithium CR2025) into the

remote control ..................................................... 9

Clock/Timer

Setting the clock ................................................. 17

Viewing the clock ............................................... 17

Setting the timer ................................................. 17

Activating and deactivating TIMER ................. 17

Activating and deactivating SLEEP .................. 17

Specifications ........................................... 18

Maintenance.............................................. 18

Controls

Controls on the system and remote

control .................................................................. 10

Basic Functions

Switching the system on ................................... 11

Switching the system to Standby mode ........ 11

Power Saving Automatic Standby .................... 11

Adjusting volume and sound............................ 11

CD Operation

Playing a disc ........................................................ 12

Selecting a different track ................................. 12

Finding a passage within a track ...................... 12

Different play modes: Shuffle and Repeat ..... 13

Programming track numbers ........................... 13

Reviewing the programme ............................... 13

Erasing the programme ..................................... 13

Radio Reception

Tuning to radio stations .................................... 14

Programming radio stations ............................. 14

Tuning to preset radio stations ....................... 14

RDS ....................................................................... 15

Setting the RDS clock ....................................... 15

Searching programme type (PTY) .................. 15

RDS News and Traffic Announcement (TA) . 16

Troubleshooting .................................... 19
