Page 1
Philips Voice Tracer
digital recorder with
ClearVoice
Speech to text
LFH0617
I write for you
With mobile dictation and speech recognition
The Voice Tracer digital recorder lets you dictate documents and notes on the move. Back
in the office, simply plug the recorder into your PC, transfer your files and let the included
software automatically turn your talk into text.
Note-taking at its best
• ClearVoice for clear and vivid voice playback
• Index function for simply finding relevant passages
• One-touch operation for instant recording
• Rapidly transfer recordings and data via USB 2.0
• Record in the popular MP3 format
• Voice-activation function for hands-free recording
Turn talk into type
• Speech-to-tex: Dragon NaturallySpeaking DVR Edition included
• Automatically transcribe your dictation files
• Create documents three times faster than most people type
• More accurate than ever, delivering up to 99% accuracy
Page 2
Digital recorder with ClearVoice
Speech to text
Highlights
LFH0617/27
ClearVoice
Recording with good audio quality at lectures or
presentations can be a challenge. Especially if
you do not sit in the front row, the voice of the
speaker may be to quiet too record in
acceptable quality. The ClearVoice feature
adjusts quiet passages dynamically, thus
improving the intelligibility of quieter voices.
MP3 recording
Speech-to-text
Turn talk into type with the Dragon
NaturallySpeaking software delivering more
accurate results than ever.
Automatic transcription
Up to 99% accuracy
The powerful software solution now more
accurate than ever! Delivering up to 99%
accuracy for an efficient workflow.
Rapidly transfer recordings
The MP3 format is the common audio format
for consumer audio storage, as well as a de facto
standard encoding for the transfer and playback
of recordings.
One-touch operation
Press and hold the record button for a moment
to switch the Voice Tracer on and start
recording instantly.
With our state-of-the-art software just plug the
recorder into the PC, transfer your file and let it
turn your talk into text.
Create documents faster
With the innovative speech recognition
software you can now convert your dictation
files into text files automatically and avoid timeconsuming retyping.
Thanks to the fast data transfer of a hi-speed 2.0
USB connection, transfering recordings to your
PC is up to 40 times faster compared with the
original USB standard.
Index function
The index function helps and eases finding
relevant passages in an instant.
Page 3
Digital recorder with ClearVoice
Speech to text
Specifications
LFH0617/27
Connectivity
• Headphones: 3.5 mm
• Microphone: 3.5 mm
• USB: High-speed USB 2.0
Display
•Type: LCD
• Diagonal screen size: 34.5 mm/1.4 in.
• Backlight: no
Storage media
• Built-in memory capacity: 1 GB
• Buit-in memory type: NAND Flash
• Mass storage class compliant
Audio recording
• Recording formats: MPEG1 layer 3 (MP3)
• Built-in microphone: mono
• Recording modes: HQ (MP3/mono), SP (MP3/
mono), LP (MP3/mono), SL
• Bit rate: 8, 32, 48, 64 kbps
• Recording time: 277 hours (SLP), 70 hours (LP), 46
urs (SP), 35 hours (HQ)
ho
• Sample rate: 22 kHz (HQ), 16 kHz (SP/LP/SLP)
P (MP3/mono)
Sound
• Speaker type: built-in round dynamic speaker
• Speaker diameter: 23 mm
• Speaker output power: 110 mW
• Sound enhancement: ClearVoice
• Frequency response: 250-2000 Hz (SLP), 60-3500
(LP), 60-5500 Hz (SP), 60-7000 Hz (HQ)
Hz
Speech recognition
• Language support: Dutch, English, French, German,
Italian, Spanish
• Software edition: Dragon NaturallySpeaking 10.1
oice Recorder Edition (supports portable
Digital V
recorders only)
Convenience
• Instant one-touch recording
• Voice-activated recording
•Keypad lock
• Firmware upgradeable
• Variable playback speed
• Optimized for notes
Power
• Battery type: AAA/LR03 Alkaline
• Number of batteries: 1
• Rechargeable: no
• Battery lifetime: up to 15 hours in SLP recording
mode
•Battery included
System requirements
• Operating system: Windows 7 (32/64-bit), Windows
Vista (32/64-bit), Windows XP (32-bit, SP2+)
• Processor: AMD Athlon 64 1GHz or later, Intel
entium 4 or later, L2 Cache: 512 KB
P
• RAM memory: 512 MB (1 GB for Win 7/Vista)
• Hard disk space: 1 GB english, 2 GB all other
•DVD-ROM drive
• Free USB port
Green specifications
• Lead-free soldered product
Accessories
•USB cable
• 1 × AAA battery
• Quick start guide
Design and finishing
• Color(s): clear white/platinum chrome
Product dimensions
• Product dimensions (W x H x D):
3.8 x 10.5 x 1.64 cm
• Product dimensions (W x H x D):
1.5 x 4.1 x 0.6 inch
• Weight: 0.042 kg
• Weight: 0.093 lb
•
Issue date 2012-06-04
Version: 3.1.5
12 NC: 8670 000 67079
UPC: 6 09585 19199 0
© 2012 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject t
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
