features:
ProScreen PXG10
Super High Bright XGA performance
• 2200 ANSI Lumens
• True XGA resolution
ProScreen
High Advanced compatibility
Motorised Zoom and Focus Lens system
Low Acoustical Fan Noise (35 dBA)
Easy Plug & Play
3122 435 64720
Philips Creative Display Solutions: P.O. Box 364 3500 Hasselt Belgium fax: +800 30 30 06 00
Design and specifications are subject to change without notice
* Available in the US,Western Europe. Check with your dealer for similar coverage in other regions.
main target specifications
LCD 3x 1.3" HT Poly Silicon Active Matrix with u-lenses
2,359,296 pixels, RGB stripe (1024x768)
Brightness 2200 ANSI lumens with 90% uniformity (CCR)
Contrast 200:1
Lamp UHP 150;End user replaceable
2000 hours
Lens F1.7 - 2.3; f= 49.1 – 63.8 mm
1.3x Motor Zoom / Focus
Proj. Dist. 1.4 – 1.9 (40"), 3,7 – 4,9m (100"), 11– 14,3m (300")
Diagonal 40 – 300"
Input signals
Video NTSC 3.85, 4.43 /PAL-CCIR, Secam
DTV/HDTV (1080i,720p,480p with 4:3 and 16:9 aspect ratios)
and DVD compatible.
Data 1 and 2 PC and Mac compatible, Multi scan VGA, S-VGA, XGA, SXGA
UXGA via LIMESCO kind full screen true XGA display; Auto
Identification; Plug & Play VESA, DDC 1/2b
Hor.scan rate: 15 – 125 kHz; Vert. Refresh rate 43 – 200 Hz;
12 – 230 Dot clock
Power in 120 - 120 V / 220 - 240 V; 50/60 Hz; 265 W
Input connections
Video S-Video (Y/C DIN)/Video (RCA)/ Stereo Audio (2x RCA)
Data 1 Mini D-sub data (15 pin)/PC,RGBHV, PbPrY Csync (via BNC)
Stereo Audio (M3)
Data 2 Mini D-sub data (15 pin)/PC Stereo Audio (M3)
RS232C 9-pin mini DIN
Mains Mains input socket (3 pin)
Output connections
Data out Mini D-sub data (15pin)
Audio Stereo Audio (M3)
Specialities Multi Input projector for Data as well for Video applications (3D Y/C separation,
3 line Digital comb filter,3D Noise reduction, Colour transient and Y delay)
Long life and almost constant light output over entire lamp life projection lamp
Automatic perfect Multi Scan data input handling,VGA up to UXGA resolutions.
Low Acoustical Noise (35dBA)
Intuitive Graphic User Interface for Ease of Use
Auto Source and Interlaced/Progressive (I/P)scan conversion
Power save modes (4)
Auto Image; Phase,Clock, Position H/V
Optional lenses: Tele and Wide lenses which can be fit in combination with the
existing zoom lens
Dimensions 261 x 129 x 356 mm (WxHxD); 12 dm
3
Net weight 7,2 kg;<16 lbs
Package ProScreen PXG10 + lenscap
2x Power cord;USA version plus Continental Europe version
Remote Control + 3x AA batteries + USB Mouse receiver
VGA cable
RCA cable (Video/Audio stereo) + RCA - BNC adapters (3x)
S-Video cable
Scart – RCA adapter
DIN-D sub RS232C cable
User Guide (CD-ROM) plus Quick Reference,Registration card
Extra Air filter
Executions LC 1041/00 Global version
Optional acc. UHP 150 Projection lamp
soft carrying bag
Exchangeable lenses; Tele and Wide lenses
Ceiling mount brackets (High, Low ceilings)
Mac adapter
Image diagonal size
Standard mode (4:3)
For wide mode (16:9) different projection distances are applicable.
Projection distance
Tele zoom Wide zoom
[inch] [meters] [inch] [meters] [inch] [meters]
40
60
72
84
100
150
200
300
1,02
1,52
1,83
2,13
2,54
3,81
5,08
7,62
55
87
146
220
291
433
102
122
75
193
283
386
563
134
157
114
1,4
2,2
2,6
3,1
3,7
5,6
7,4
11,0
1,9
2,9
3,4
4,0
4,9
7,2
9,8
14,3
Minimum
Maximum
• Long-lasting - up to 2000 hours – 150 Watt
UHP™ (Ultra High Performance) lamp for uniform images, rich colours and brightness over
time, without hot spots
• High Advanced Full- and Semi- Automatic scaling
technology, guarantees compatibility with all
video and PC/Mac data sources up to UXGA
• High degree on compatibility via multiple Inputs
for Computer, Standard and High Definition
(HD) Video applications
• HDTV Compatible – 480i / 480p / 720p / 1080i
(4:3 & 16:9 aspect ratios)
• Component Video Input
• Superior Video Quality: 3D Y/C circuitry, Digital
comb filter,3D Noise reduction, Interlaced (I) or
Progressive (P) scan,Digital motion correction
• Motorised Lens functions (1: 1.3x), by Power
Zoom / Focus also operating in combination
with the optional available snap-off Wide & Tele
Lenses;
• Multiple projection application; Ceiling and Desk
operation in front- as well in rear projection.
• Digital picture enhance technologies; Digital
Zoom, Digital Freeze, Digital Keystones
• Auto voltage for safe usage around the globe
• Audience size up to over 300 people (boardroom, lecture hall or auditorium)
• Portable weight (7,2 kg), compact design with
integrated carrying handle, which makes the
product also suitable for portable use
• Slot for optional Kensington lock
• Free remote control included
• Full wired remote control possible via RS-232C
port for fixed installation operation
Free support:
• First Choice* support
• Free toll-free support*
www.pcstuff.philips.com/projectors tel:
More information
Big picture...
eye for detail
