Philips KX-TAW848 User Manual

Advanced Hybrid & Wireless PBX

Installation Manual

Model No. KX-TAW848

Thank you for purchasing a Panasonic Advanced Hybrid & Wireless PBX.
Please read this manual carefully before using this product and save this manual for future use.

KX-TAW848: MPR Version 2.0

SD Logo is
a trademark.

System Components

System Components Table

Model Description

Main Unit KX-TAW848 Main Unit

CO Line Cards KX-TAW84880 4-Port Analog Trunk Card (LCOT4)

KX-TAW84893 4-Port Caller ID Card (CID4)

Extension Cards KX-TAW84870 4-Port Hybrid Extension Card (HLC4)

KX-TAW84874 8-Port Single Line Telephone Extension Card (SLC8)

KX-TAW84875 4-Port Proprietary Extension Card (PLC4)

KX-TAW84876 8-Port Proprietary Extension Card (PLC8)

Other Cards KX-TAW84861 4-Port Doorphone Card (DPH4)

KX-TAW84866 8-Channel Echo Canceller Card (ECHO8)

KX-TAW84868 Extension Caller ID Card (EXT-CID)

KX-TAW84891 2-Channel Message Card (MSG2)

KX-TAW84896 Remote Card (RMT)

Cell Station (CS) KX-T0141 2-Channel Cell Station Unit for 2.4 GHz Portable Station

Proprietary Equipment KX-T30865 Doorphone

Available Proprietary Telephones

The PBX supports Panasonic KX-T7000 and KX-TD7000 series telephones:

• Analog proprietary telephones (e.g., KX-T7730)

• Portable stations (e.g., KX-TD7690)

• DSS consoles (e.g., KX-T7740)

Note

The PBX does not support the following telephones:

• Digital proprietary telephones

• KX-T30800 series Proprietary Telephones and DSS consoles

• KX-T61600 series Proprietary Telephones and DSS consoles

• KX-T123200 series Proprietary Telephones and DSS consoles

*1

For the equipment (e.g., Headset
manual.

For other equipment that can be connected to the PBX, refer to "1.2.2 System Connection Diagram".

) that can be connected to a particular telephone, refer to the telephone's

*1

The KX-T7090 headset can be connected to the KX-T7000 and KX-T7300 series telephones.

2 Installation Manual

Abbreviations in this manual

Analog proprietary telephone: APT
Portable station: PS
Single line telephone: SLT

Installation Manual 3

Important Safety Instructions

SAFETY REQUIREMENTS

When using your telephone equipment, basic safety precautions should always be followed to reduce the
risk of fire, electric shock and injury to persons, including the following:

1. Read and understand all instructions.

2. Follow all warnings and instructions marked on the product.

3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners.

Clean with a damp cloth.

4. Do not use this product near water, for example, near a bathtub, wash bowl, kitchen sink, or laundry

tub, in a wet basement, or near a swimming pool.

5. Do not place the product on an unstable surface, as a fall may cause serious internal damage.

6. Slots and openings in the front, back and bottom of the cabinet are provided for ventilation; to protect

it from overheating, these openings must not be blocked or covered. The openings should never be
blocked by placing the product on a bed, sofa, rug, or other similar surface while in use. The product
should never be placed near or over a radiator or other heat source. This product should not be placed
in a sealed environment unless proper ventilation is provided.

7. The product should only be connected to the type of electrical power supply specified on the product

label. If you are not sure of the type of power supply to your home, consult your dealer or local power
company.

8. For safety purposes this unit is equipped with a grounded plug. If you do not have a grounded outlet,

please have one installed. Do not bypass this safety feature by tampering with the plug.

9. Do not allow anything to rest on the power cord. Do not locate this product where the power cord may

be stepped on or tripped on.

10. To reduce the risk of fire or electric shock, do not overload wall outlets and extension cords.

11. Do not insert objects of any kind into this product through its slots and openings, as they may touch

dangerous voltage points or short out parts that could result in a risk of fire or electric shock. Never spill
liquid of any kind on or in the product.

12. To reduce the risk of electric shock, do not disassemble this product. Only qualified personnel should

service this product. Opening or removing covers may expose you to dangerous voltages or other risks.
Incorrect reassembly can cause electric shock.

13. Unplug this product from the wall outlet and have it serviced by qualified service personnel in the

following cases:

a) When the power supply cord or plug is damaged or frayed.
b) If liquid has been spilled into the product.
c) If the product has been exposed to rain or water.
d) If the product does not operate according to the operating instructions. Adjust only the controls that

are explained in the operating instructions. Improper adjustment of other controls may result in
damage and may require service by a qualified technician to restore the product to normal
operation.

e) If the product has been dropped or the cabinet has been damaged.
f) If product performance deteriorates.

14. Avoid using wired telephones during an electrical storm. There is a remote risk of electric shock from

lightning.

15. Do not use a telephone in the vicinity of a gas leak to report the leak.

4 Installation Manual

SAVE THESE INSTRUCTIONS

Installation Manual 5

Precaution

WARNING

DO NOT REMOVE
SD MEMORY CARD
WHILE POWER IS
SUPPLIED TO THE
ADVANCED HYBRID &
WIRELESS PBX

Doing so may cause the PBX to fail to
start when you restart the system.

6 Installation Manual

• Keep the unit away from heating appliances and devices that generate electrical noise such as
fluorescent lamps, motors and televisions. These noise sources can interfere with the performance of
the PBX.

• This unit should be kept free of dust, moisture, high temperature (more than 40 °C [104 °F]) and
vibration, and should not be exposed to direct sunlight.

• If you are having problems making calls to outside destinations, follow this procedure to test the CO
lines:

1. Disconnect the PBX from all CO lines.

2. Connect known working SLTs to those CO lines.

3. Make a call to an external destination using those SLTs.

If a call cannot be carried out correctly, there may be a problem with the CO line that the SLT is
connected to. Contact your telephone company.
If all SLTs operate properly, there may be a problem with your PBX. Do not reconnect the PBX to the
CO lines until it has been serviced by an authorized Panasonic Factory Servicenter.

• Wipe the unit with a soft cloth. Do not clean with abrasive powders or with chemical agents such as
benzene or thinner.

WARNING

• THIS UNIT MAY ONLY BE INSTALLED AND SERVICED BY QUALIFIED SERVICE

PERSONNEL.

• IF DAMAGE TO THE UNIT EXPOSES ANY INTERNAL PARTS, DISCONNECT THE

POWER SUPPLY CORD IMMEDIATELY AND RETURN THE UNIT TO YOUR DEALER.

• UNPLUG THIS UNIT FROM THE AC OUTLET IF IT EMITS SMOKE, AN ABNORMAL

SMELL OR MAKES UNUSUAL NOISE. THESE CONDITIONS CAN CAUSE FIRE OR
ELECTRIC SHOCK. CONFIRM THAT SMOKE HAS STOPPED AND CONTACT AN
AUTHORIZED PANASONIC FACTORY SERVICENTER.

• WHEN RELOCATING THE EQUIPMENT, FIRST DISCONNECT THE TELECOM

CONNECTION BEFORE DISCONNECTING THE POWER CONNECTION. WHEN THE
UNIT IS INSTALLED IN THE NEW LOCATION, RECONNECT THE POWER FIRST,
AND THEN RECONNECT THE TELECOM CONNECTION.

• TO PREVENT POSSIBLE FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS

PRODUCT TO RAIN OR MOISTURE.

• THE POWER SUPPLY CORD IS USED AS THE MAIN DISCONNECT DEVICE.

EUSURE THAT THE AC OUTLET IS LOCATED NEAR THE EQUIPMENT AND IS
EASILY ACCESSIBLE.

CAUTION

DANGER OF EXPLOSION EXISTS IF A BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY
WITH THE SAME OR EQUIVALENT TYPE RECOMMENDED BY THE BATTERY MANUFACTURER.
DISPOSE OF USED BATTERIES ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.

Installation Manual 7

When you ship the product

Carefully pack and send it prepaid, adequately insured and preferably in the original carton. Attach a
postage-paid letter, detailing the symptom, to the outside of the carton. DO NOT send the product to the
Executive or Regional Sales offices. They are NOT equipped to make repairs.

Product Service

Panasonic Factory Servicenters for this product are listed in the servicenter directory. Consult your dealer
for detailed instructions.

For Future Reference

Please print, record, and retain the following information for future reference.

Note

The serial number of this product can be found on the label affixed to the unit. You should record the
model number and the serial number of this unit as a permanent record of your purchase to aid in
identification in the event of theft.

MODEL NO.

SERIAL NO.

DATE OF PURCHASE

NAME OF DEALER

DEALER'S ADDRESS

DEALER'S TEL. NO.

8 Installation Manual

Introduction

This Installation Manual is designed to serve as an overall technical reference for the Panasonic Advanced
Hybrid & Wireless PBX, KX-TAW848. It provides instructions for installing the hardware, and programming
the PBX using the KX-TAW848 Maintenance Console.

The Structure of this Manual

This manual contains the following sections:

Section 1 System Outline

Provides general information on the PBX, including the system capacity and specifications.

Section 2 Installation

Describes the procedures to install the PBX. Detailed instructions for planning the installation site,
installing the optional service cards, and cabling of peripheral equipment are provided. Further
information on system expansion and peripheral equipment installation is included.

Section 3 Guide for the PC Programming Software

Explains the installation procedure, structure, and basic information of the KX-TAW848 Maintenance
Console.

Section 4 Troubleshooting

Provides information on the PBX and telephone troubleshooting.

About the Other Manuals

Along with this Installation Manual, the following manuals are available:

Feature Guide

Describes all basic, optional and programmable features of the PBX, and step-by-step instruction for
performing system programming using a proprietary telephone or a personal computer (PC).

User Manual

Provides operating instructions for end users using an APT, SLT, PS, or DSS Console.

Trademarks

• Microsoft and Windows are either registered trademarks or trademarks of Microsoft Corporation in

the United States and/or other countries.

• Intel and Pentium are trademarks or registered trademarks of Intel Corporation or its subsidiaries

in the United States and other countries.

• All other trademarks identified herein are the property of their respective owners.

• Screen shots reprinted with permission from Microsoft Corporation.

Installation Manual 9

F.C.C. REQUIREMENTS AND RELEVANT INFORMATION

1. Notification to the Telephone Company

This equipment complies with Part 68 of the FCC rules and the requirements adopted by the ACTA. On
the side of this equipment is a label that contains, among other information, a product identifier in the
format US: ACJMF03AKX-TDA50. If requested, this number must be provided to the telephone
company.

Installation must be performed by a qualified professional installer. If required, provide the telephone
company with the following technical information:

• Telephone numbers to which the system will be connected

• Make: Panasonic

• Model: KX-TAW848

• Certification No.: found on the side of the unit

• Ringer Equivalence No.: 0.3A

• Facility Interface Code: 02LS2

• Service Order Code: 9.0F

• Required Network Interface Jack: RJ11

2. Ringer Equivalence Number (REN)

The REN is used to determine the number of devices that may be connected to a telephone line.
Excessive RENs on a telephone line may result in the devices not ringing in response to an incoming
call. In most, but not all areas, the sum of RENs should not exceed five (5.0). To be certain of the
number of devices that may be connected to a line, as determined by the total RENs, contact the local
telephone company. The REN for this product is part of the product identifier that has the format US:
ACJMF03AKX-TDA50. The digits represented by 03 are the REN without a decimal point (e.g., 03 is a
REN of 0.3). For earlier products, the REN is separately shown on the label.

3. Incidence of Harm to the Telephone Lines

If this equipment causes harm to the telephone network, the telephone company will notify you in
advance that temporary discontinuance of service may be required. But if advance notice isn't practical,
the telephone company will notify the customer as soon as possible. Also, you will be advised of your
right to file a complaint with the FCC if you believe it is necessary.

4. Changes in Telephone Company Communications Facilities, Equipment, Operations and

Procedures

The telephone company may make changes in its facilities, equipment, operations or procedures that
could affect the operation of the equipment. If this happens the telephone company will provide
advance notice in order for you to make necessary modifications to maintain uninterrupted service.

5. Trouble with this equipment

If trouble is experienced with this equipment, for repair or warranty information, please see the attached
warranty, which includes the Servicenter Directory. If the equipment is causing harm to the telephone
network, the telephone company may request that you disconnect the equipment until the problem is
resolved.

6. Connection to Party Line

Connection to party line service is subject to state tariffs. Contact the state public utility commission,
public service commission or corporation commission for information.

10 Installation Manual

7. Combined Use with Alarm Equipment

If your home has specially wired alarm equipment connected to the telephone line, ensure the
installation of this equipment does not disable your alarm equipment. If you have questions about what
will disable alarm equipment, consult your telephone company or a qualified installer.

Note

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

CAUTION

Any changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate this device.

When programming emergency numbers and/or making test calls to emergency numbers:

1. Remain on the line and briefly explain to the dispatcher the reason for the call before hanging up.

2. Perform such activities in the off-peak hours, such as early morning hours or late evenings.

Installation Manual 11

For Cell Station

CAUTION

Any changes or modifications not expressly approved by the party responsible for compliance could
void user's authority to operate this device.

Note

This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

Some wireless telephones operate at frequencies that may cause interference to nearby TVs and
VCRs. To minimize or prevent such interference, the base of the wireless telephone should not be
placed near or on top of a TV or VCR. If interference is experienced, move the wireless telephone
further away from the TV or VCR. This will often reduce, or eliminate, interference.
Operating near 2.4 GHz electrical appliances may cause interference. Move away from the electrical
appliances.

CAUTION

To comply with FCC RF exposure requirements in uncontrolled environment:

• This equipment must be installed and operated in accordance with provided instructions and a
minimum 20 cm (8 in) spacing must be provided between antenna and all person's body (excluding
extremities of hands, wrist and feet) during wireless modes of operation.

• This transmitter must not be co-located or operated in conjunction with any other antenna or
transmitter.

Medical—consult the manufacturer of any personal medical devices, such as pacemakers, to
determine if they are adequately shielded from external RF (radio frequency) energy. (The unit operates
in the frequency range of 2401 MHz to 2480 MHz, and the power output level can range from 0.004 W
to 0.4 W.) Do not use the unit in health care facilities if any regulations posted in the area instruct you
not to do so. Hospitals or health care facilities may be using equipment that could be sensitive to
external RF (radio frequency) energy.

12 Installation Manual

Table of Contents

1 System Outline .....................................................................................15

1.1 System Highlights .......................................................................................................... 16

1.1.1 System Highlights .............................................................................................................16

1.2 Basic System Construction ...........................................................................................17

1.2.1 Main Unit........................................................................................................................... 17

1.2.2 System Connection Diagram ............................................................................................ 18

1.3 Options ............................................................................................................................ 20

1.3.1 Options ............................................................................................................................. 20

1.4 Specifications .................................................................................................................21

1.4.1 General Description .......................................................................................................... 21

1.4.2 Characteristics .................................................................................................................. 23

1.4.3 System Capacity...............................................................................................................24

2 Installation............................................................................................. 25

2.1 Before Installation........................................................................................................... 26

2.1.1 Before Installation .............................................................................................................26

2.2 Installation of the PBX.................................................................................................... 28

2.2.1 Unpacking......................................................................................................................... 28

2.2.2 Names and Locations .......................................................................................................29

2.2.3 Opening/Closing the Covers.............................................................................................30

2.2.4 Installation of the SD Memory Card.................................................................................. 33

2.2.5 Frame Ground Connection ...............................................................................................34

2.2.6 Installing/Removing the Optional Service Cards .............................................................. 35

2.2.7 Types of Connectors ......................................................................................................... 43

2.2.8 Wall Mounting (KX-TAW848) ............................................................................................44

2.2.9 Wall Mounting (AC Adaptor) .............................................................................................47

2.2.10 Surge Protector Installation ..............................................................................................50

2.3 Installation of the CO Line Cards .................................................................................. 53

2.3.1 LCOT4 Card......................................................................................................................53

2.3.2 CID4 Card .........................................................................................................................54

2.4 Installation of the Extension Cards............................................................................... 55

2.4.1 HLC4 Card........................................................................................................................ 55

2.4.2 PLC4 Card ........................................................................................................................ 56

2.4.3 SLC8 Card ........................................................................................................................ 57

2.4.4 PLC8 Card ........................................................................................................................ 58

2.5 Installation of the Other Cards ...................................................................................... 59

2.5.1 DPH4 Card .......................................................................................................................59

2.5.2 ECHO8 Card..................................................................................................................... 62

2.5.3 MSG2 Card ....................................................................................................................... 63

2.5.4 EXT-CID Card ................................................................................................................... 64

2.5.5 RMT Card .........................................................................................................................65

2.6 Connection of Extensions.............................................................................................. 67

2.6.1 Maximum Cabling Distances of the Extension Wiring (Twisted Cable)............................. 67

2.6.2 Parallel Connection of the Extensions ..............................................................................68

2.7 Connection of 2.4 GHz Portable Stations ..................................................................... 69

2.7.1 Overview ...........................................................................................................................69

2.7.2 Procedure Overview .........................................................................................................70

Installation Manual 13

2.7.3 Site Planning ..................................................................................................................... 72

2.7.4 Before Site Survey ............................................................................................................ 76

2.7.5 Site Survey........................................................................................................................78

2.7.6 After Site Survey ...............................................................................................................82

2.7.7 Connecting a Cell Station to the PBX ...............................................................................83

2.7.8 Wall Mounting ...................................................................................................................89

2.8

2.8.1 Connection of Doorphones, Door Openers, External Sensors, and External Relays .......91

2.9 Connection of Peripherals .............................................................................................95

2.9.1 Connection of Peripherals.................................................................................................95

2.10 Power Failure Connections............................................................................................99

2.10.1 Power Failure Connections ...............................................................................................99

2.11 Starting the PBX............................................................................................................ 100

2.11.1 Starting the PBX .............................................................................................................100

Connection of Doorphones, Door Openers, External Sensors, and External Relays

...... 91

3 Guide for the PC Programming Software......................................... 103

3.1 Overview ........................................................................................................................104

3.1.1 Overview .........................................................................................................................104

3.2 Connection ....................................................................................................................105

3.2.1 Connection...................................................................................................................... 105

3.3 Installation of the PC Programming Software ............................................................ 107

3.3.1 Installing and Starting the KX-TAW848 Maintenance Console .......................................107

4 Troubleshooting.................................................................................. 111

4.1 Troubleshooting ............................................................................................................112

4.1.1 Installation ....................................................................................................................... 112

4.1.2 Connection...................................................................................................................... 113

4.1.3 Operation ........................................................................................................................115

4.1.4 Using the Reset Button ................................................................................................... 116

4.1.5 Troubleshooting by Error Log .......................................................................................... 117

5 Appendix ............................................................................................. 123

5.1 Revision History............................................................................................................124

5.1.1 MPR Version 2.0 .............................................................................................................124

Index .......................................................................................................... 125

14 Installation Manual

Section 1

System Outline

This section provides general information on the PBX,
including the system capacity and specifications.

Installation Manual 15

1.1 System Highlights

1.1 System Highlights

1.1.1 System Highlights

Voice Mail Features

A Voice Processing System (VPS) can be connected to the PBX to provide Voice Mail (VM) and Automated
Attendant (AA) services. A Panasonic VPS which supports DPT (Digital) Integration can be connected to
the PBX effortlessly and with minimal setup required. Conventional DTMF (analog) voice mail systems,
including those from other manufacturers, are also supported.

Paralleled Telephone Features

By connecting telephones in parallel, you can increase the number of telephones connected to the PBX
without adding additional extension cards.
An SLT can be connected to an APT which is connected to a Hybrid Port of the PBX. The SLT shares the
same extension number with the APT.

Portable Station (PS) Features

A Panasonic PS can be used in place of an APT to provide wireless access to PBX features and call
handling. When in Wireless XDP Parallel Mode, a PS can share an extension number with a wired
telephone, allowing extension users to use their PSs when they are away from their desks to answer or make
calls as if they were using their wired telephones.

16 Installation Manual

1.2 Basic System Construction

1.2 Basic System Construction

1.2.1 Main Unit

The main unit is equipped with 4 analog trunk ports (one LCOT4 card) and 4 extension ports (Hybrid Ports).
For system expansion, optional service cards can be installed.

Construction of Main Unit

LCOT4 card

(installed by default)

Front Cover Cable Cover

Main Board

Installation Manual 17

1.2 Basic System Construction

1.2.2 System Connection Diagram

Telephone Company

(Analog CO Lines)

Remote PC

Advanced Hybrid & Wireless PBX

PC

Printer

External Sensor/

External Relay Device

Doorphone & Door Opener

BGM/Music On Hold (MOH)

Pager/

Speaker

Amplifier

Wireless Phone

PS

CS

Voice Processing

System

SLT

APT

Fax Machine

DSS Console

18 Installation Manual

Telephone

Analog

CO Line

Company

Analog

Analog

CO Line

CO Line

1

LCOT4

(KX-TAW84880)

(KX-TAW84893)

(KX-TAW84870)

*

CID4

HLC4

Advanced Hybrid &
Wireless PBX

APT DSS Console

1.2 Basic System Construction

Voice
Processing
System

AC Cord & AC Adaptor

Station Message

Detail Recording (SMDR)

PC

SLC8

(KX-TAW84874)

PLC8

(KX-TAW84876)

PLC4

(KX-TAW84875)

DPH4

(KX-TAW84861)

ECHO8

(KX-TAW84866)

EXT-CID

(KX-TAW84868)

MSG2

(KX-TAW84891)

RMT

(KX-TAW84896)

4 Hybrid Ports

SLT Wireless Phone Fax Machine

SLT Wireless Phone Fax Machine

DSS ConsoleAPT

Doorphone & Door Opener

Radio

Amplifier Pager/Speaker

2

*

APT DSS Console

External Sensor/External Relay Device

CS PS

Voice
Processing
System

Voice
Processing
System

Main Board

*1 One LCOT4 card is installed by default.
*2 The PBX has 4 Hybrid Ports pre-installed.

SLT Wireless Phone Fax Machine

CS PS

Installation Manual 19

1.3 Options

1.3 Options

1.3.1 Options

Model No. Model Name Description

KX-TAW84861 4-Port Doorphone Card

(DPH4)

KX-TAW84866 8-Channel Echo Canceller

Card (ECHO8)

KX-TAW84868 Extension Caller ID Card

(EXT-CID)

KX-TAW84870 4-Port Hybrid Extension

Card (HLC4)

KX-TAW84874 8-Port Single Line

Telephone Extension Card
(SLC8)

KX-TAW84875 4-Port Proprietary

Extension Card (PLC4)

KX-TAW84876 8-Port Proprietary

Extension Card (PLC8)

KX-TAW84880 4-Port Analog Trunk Card

(LCOT4)

4-port doorphone card for 4 doorphones, 4 door
openers or external relays, and 4 external
sensors.

8-channel card for echo cancellation during
conferences.

Sends Caller ID signals to extension ports. 1

4-port extension card for SLTs, APTs, DSS
consoles, a Voice Processing System (VPS),
and CSs.

8-port extension card for SLTs. 2

4-port extension card for APTs, DSS consoles,
and a VPS.

8-port extension card for APTs, DSS consoles,
and a VPS.

4-port analog CO line card with 2 power failure
transfer (PFT) ports.

Maximum

Quantity

1

1

1

1

2

*1

1

KX-TAW84891 2-Channel Message Card

(MSG2)

KX-TAW84893 4-Port Caller ID Card

(CID4)

KX-TAW84896 Remote Card (RMT) Analog modem card for remote communication

*1

One LCOT4 card is installed by default. One more LCOT4 card can be installed in the PBX as an option.

20 Installation Manual

2-channel message card. 2

4-port Caller ID signal type FSK/FSK (with Call
Waiting Caller ID [Visual Caller ID])/DTMF. To
be mounted on the LCOT4 card.

with the PBX. ITU-T V.90 support.

2

1

1.4 Specifications

1.4.1 General Description

Switching Non-blocking

AC Adaptor AC Input 100 V AC to 240 V AC, 1.5 A, 50 Hz/60 Hz

DC Output 40 V, 1.38 A (55.2 W)

DC Input 40 V, 1.38 A (55.2 W)

Maximum Power Failure Tolerance 300 ms

Memory Backup Duration 7 years

Dialing CO Line Dial Pulse (DP) 10 pps, 20 pps

Tone (DTMF) Dialing

Extension Dial Pulse (DP) 10 pps, 20 pps

Tone (DTMF) Dialing

1.4 Specifications

Connectors CO Line RJ11 (2 wire) × each CO ports

Extension RJ11 (4 wire) × each extension ports

Paging Output 1 conductor jack

External MOH
(Music on Hold)
Output

Mode Conversion DP-DTMF, DTMF-DP

Ring Frequency 20 Hz/25 Hz (selectable)

Central Office Loop Limit 1600 Ω maximum

Operating
Environment

Conference Call CO Line From 10 × 3-party conference call to 4 × 8-party conference call

Music on Hold 1 port (Level Control: -11 dB to +11 dB in 1 dB steps)

Paging Internal Level Control: -15 dB to +6 dB in 3 dB steps

Serial Interface
Port

Tem perature 0 °C to 40 °C (32 °F to 104 °F)

Humidity 10 % to 90 % (non-condensing)

External 1 port (Volume Control: -15 dB to +15 dB in 1 dB steps)

RS-232C 1 (maximum 115.2 kbps)

USB 1

1 conductor jack

Selectable Tone/External Music Source port

Extension Connection Cable SLT 1-pair wire (T, R)

APT 2-pair wire (T, R, D1, D2)

DSS Console 1-pair wire (D1, D2)

CS 1-pair wire (D1, D2)

Installation Manual 21

1.4 Specifications

Dimension 275 mm (W) × 376 mm (H) × 117 mm (D)

(10-4/5 in × 14-4/5 in × 4-3/5 in)

Weight (when fully mounted) Under 3.5 kg (7.72 lb)

22 Installation Manual

1.4.2 Characteristics

Terminal Equipment Loop Limit • APT: 40 Ω

• SLT: 600 Ω including set

• Doorphone: 20 Ω

• CS: 65 Ω

Minimum Leakage Resistance 15 000 Ω minimum

1.4 Specifications

Maximum Number of Extension
Instruments per Line

Ring Voltage 75 Vrms at 20 Hz/25 Hz depending on the Ringing Load

Central Office Loop Limit 1600 Ω maximum

Hookswitch Flash Timing Range 24 ms to 2032 ms

Door Opener Current Limit 24 V DC/30 V AC, 1 A maximum

External Relay Current Limit 24 V DC/30 V AC, 1 A maximum

External Sensor Current Limit Power to the external sensor is provided from the DPH4 card and must be

Paging Terminal Impedance 600 Ω

MOH Terminal Impedance 10 000 Ω

1 for APT or SLT

2 by Parallel connection of an APT and an SLT

grounded through the DPH4 card. For the connection diagram, refer to
"2.5.1 DPH4 Card". The PBX detects input from the sensor when the
signal is under 100 Ω.

Installation Manual 23

1.4 Specifications

1.4.3 System Capacity

Maximum CO Line and Extension Cards

The following number of CO line and extension cards can be installed in the PBX for expansion.

Card Type Maximum Number

CO Line Card 2

Extension Card 3

Notes

• For each card, the maximum number that can be installed in the PBX is listed in "1.3.1 Options".

• Any card that exceeds the capacity of the PBX will be ignored.

• When the PBX starts up with an invalid configuration, some cards will be ignored.

Maximum Terminal Equipment

The following number of items of terminal equipment can be supported by the PBX.

Terminal Equipment Type Maximum Number

SLT 24

APT 24

DSS console 4

CS 4

PS 28

VPS

SLT, PT, DSS console, and VPS Total 28

Doorphone 4

Door Opener/External Relay 4

External Sensor 4

*1

A maximum of 4 ports (8 channels) of a single VPS can be connected to the PBX.

Note

Devices connected to the PBX that exceed the system capacity will not function.

4 ports (1 VPS)

*1

24 Installation Manual

Section 2

Installation

This section describes the procedures to install the PBX.
Detailed instructions for planning the installation site, installing
the optional service cards, and cabling of peripheral
equipment are provided. Further information on system
expansion and peripheral equipment installation is included.

Installation Manual 25

2.1 Before Installation

2.1 Before Installation

2.1.1 Before Installation

Please read the following notes concerning installation and connection before installing the PBX and
terminal equipment.
Be sure to comply with all applicable laws, regulations, and guidelines.

Safety Installation Instructions

When installing telephone wiring, basic safety precautions should always be followed to reduce the risk of
fire, electric shock and injury to persons, including the following:

1. Never install telephone wiring during a lightning storm.

2. Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations.

3. Never touch uninsulated telephone wires or terminals unless the telephone line has been disconnected

at the network interface.

4. Use caution when installing or modifying telephone lines.

Installation Precautions

This PBX is designed for wall mounting only, and should be installed in a location where it is accessible for
inspections and maintenance.
To prevent malfunction, noise, or discoloration, avoid installing the system in the following locations:

1. In direct sunlight and hot, cold, or humid places. (Temperature range: 0 °C to 40 °C [32 °F to 104 °F])

2. Areas where sulfuric gases may be present, such as near thermal springs.

3. Areas where shocks or vibrations are frequent or strong.

4. High-dust areas, or places the system may come into contact with water or oil.

5. Near devices that generate high frequencies, such as sewing machines or electric welders.

6. On or near computers, telexes, or other office equipment, as well as microwave ovens or air

conditioners. (It is preferable not to install the system in the same room as the above equipment.)

7. Within 1.8 m (6 ft) of radios and televisions. (Both the PBX and PTs should be at least 1.8 m [6ft] away

from such devices.)

8. Locations where other objects will obstruct the area around the PBX. Be especially careful to leave at

least 20 cm (8 in) of space above and 10 cm (4 in) to the sides of the PBX for ventilation.

9. Do not stack up the optional service cards. To avoid damage to the optional service cards, always use

the extension bolts.

Wiring Precautions

Be sure to follow these instructions when wiring the unit:

1. Do not run unshielded telephone cables near AC power cables, computer cables, AC power sources,

etc. When running cables near other noise-generating devices or cables, use shielded telephone
cables or shield the telephone cables with metal tubing.

2. If cables are run on the floor, use protectors to prevent the cables from being stepped on. Avoid running

cables under carpets.

3. Avoid using the same AC outlet for computers, telexes, and other office equipment, as noise generated

by such equipment may hamper system performance or interrupt the system.

26 Installation Manual

2.1 Before Installation

4. Use 2-pair telephone cables when connecting PTs.

Use 1-pair telephone cables when connecting SLTs, data terminals, answering machines, computers,
Voice Processing Systems, etc.

5. Unplug the system from its power source when wiring, and plug the system back in only after all wiring

is completed.

6. Mis-wiring may cause the PBX to operate improperly. Refer to Section 2 "Installation" when wiring the

system.

7. If an extension does not operate properly, disconnect the telephone from the extension line and connect

it again, or turn off the PBX using power switch then turn it on again.

8. For safety purposes this unit is equipped with a grounded plug. If you do not have a grounded outlet,

please have one installed. Do not bypass this safety feature by tampering with the plug.

9. Use twisted pair cable for CO line connection.

10. CO lines should be installed with surge protectors. For details, refer to "2.2.10 Surge Protector

Installation".

11. To assure good quality telephone connection, it is recommended new and modifications to existing

installation of customer premise wiring shall use solid twisted pair copper conductors with minimum 24
gauge that comply with the electrical specifications for Category 3 wiring as detailed in ANSI/EIA/TIA­570A Building Wiring Standards.

Installation Manual 27

2.2 Installation of the PBX

2.2 Installation of the PBX

2.2.1 Unpacking

Unpack the box and check the items below:

Main Unit 1

AC Cord 1

AC Adaptor 1

Screws for Wall Mounting 5

Washers for Wall Mounting 5

Mini Plug (for pager and music source) 2

SD Memory Card 1

Main Strap 1

Strap (for the pre-installed LCOT4 card) 1

Optional Card Label Sheet 1

28 Installation Manual

2.2.2 Names and Locations

Ground Terminal

2.2 Installation of the PBX

SD Memory
Card Slot Cover

Reset Button

System Initialize
Switch

MOH port
Pager port

Hybrid Ports

RS-232C port

DC IN 1

Power Switch

USB port

Installation Manual 29

2.2 Installation of the PBX

2.2.3 Opening/Closing the Covers

Opening the Covers

1. Pull the slide button to the right and, holding it, slide the cable cover upwards. Then turn the cable cover

slightly to remove it.

1

Slide Button

Cable Cover

2. Remove the three screws.

Screw

3. Holding the protrusions on both sides of the front cover, swing the cover open.

30 Installation Manual

Removing/Attaching the Front Cover

If you prefer, you can remove the front cover.

Removing the Front Cover

Holding the front cover open at about a 45° angle, remove the front cover by pushing it in the direction
of the arrow as shown below.

2.2 Installation of the PBX

Attaching the Front Cover

Fit the front cover to the main unit as shown below, and then close the front cover.

Installation Manual 31

2.2 Installation of the PBX

Closing the Covers

1. Close the front cover, then tighten the three screws.

Screw

2. Attach the rear hooks on the cable cover to the main unit, then swing the cable cover closed so that the

front hooks fit in place.

Cable Cover

3. Slide the cable cover down until it locks.

32 Installation Manual

2.2.4 Installation of the SD Memory Card

LED

2.2 Installation of the PBX

SD Memory Card
Slot Cover

SD Memory
Card

CAUTION

• Use only the SD Memory Card included with the PBX.

• The SD Memory Card contains software for all the processes of the PBX and all the customer data.

The SD Memory Card must be inserted before start up.

• Do not remove the SD Memory Card while power is supplied to the PBX. Doing so may cause the
PBX to fail to start when you try to restart the system.

Note

If you need to remove the SD Memory Card:

LED Indications

Indication Color Description

SD ACCESS Green SD memory card status

• ON: Accessing

Installation Manual 33

2.2 Installation of the PBX

2.2.5 Frame Ground Connection

IMPORTANT

Connect the frame of the PBX to ground.

1. Loosen the screw.

Screw

2. Insert a grounding wire (user-supplied)*.

3. Tighten the screw.

4. Connect the grounding wire to ground.

Grounding

wire

To ground

* For grounding wire, green-and-yellow insulation is required, and the cross-sectional area of the

conductor must be more than 0.75 mm

• Be sure to comply with applicable local regulations (e.g., law, guidelines).

• Proper grounding (connection to ground) is very important to protect the PBX from the bad effects of

external noise or to reduce the risk to the user of electrocution in the case of a lightning strike.

• The ground wire of the AC cable has an effect against external noise and lightning strikes, but it may
not be enough to protect the PBX. A permanent connection between ground and the ground terminal
of the PBX must be made.

In most of the continental United States, the ground provided by the "Third wire ground" at the commercial
power outlet will be satisfactory. However, in a small percentage of cases this ground may be installed
incorrectly. Therefore, the following test procedure should be performed.

2

or 18 AWG.

Test Procedure

1. Obtain a suitable voltmeter and set it for a possible reading of up to 250 V AC.

2. Connect the meter probes between the 2 main AC voltage points on the wall outlet. The reading

obtained should be 108 V AC to 132 V AC.

3. Move one of the meter probes to the 3rd prong terminal (GND).

Either the same reading or a reading of 0 volt should be obtained.

4. If a reading of 0 volt at one terminal and a reading of 108 V AC to 132 V AC at the other terminal

is not obtained, the outlet is not properly grounded.
This condition should be corrected by a qualified electrician (per article 250 of the National
Electrical Code).

5. If a reading of 0 volt at one terminal and a reading of 108 V AC to 132 V AC at the other terminal

is obtained, then set the meter to the "OHMS/RX1" scale, place one probe at the GND Terminal
and the other probe at the terminal which gave a reading of 0 volt.
A reading of less than 1 ohm should be obtained. If the reading is not obtained, the outlet is not
adequately grounded. See qualified electrician.

34 Installation Manual

2.2 Installation of the PBX

2.2.6 Installing/Removing the Optional Service Cards

Slot Position

1

11*

1

10

*

04

09

08

1

Slots 10 and 11 accept only cards that do not have external ports. Therefore, these slots do not have

*

03

02*

01*

2

3

06

05

removable cover plates.

2

Slot 02 has an LCOT4 card pre-installed.

*

3

Slot 01 contains the pre-installed Hybrid Ports. No optional service card can be installed.

*

Slot Condition

The following table shows the slot condition. " " indicates that the slot supports the optional service card.

Card Slot Number

Type Max 020304050608091011

LCOT4

HLC4

PLC4

*1

2

*2

1

SLC8

*3

2

PLC8

DPH4 1

ECHO8 1

EXT-CID 1

MSG2 2

*1

Including one LCOT4 card that is installed by default.

*2

Only one of HLC or PLC4 card can be installed.

*3

A maximum of two SLC8 and PLC8 cards can be installed.

CAUTION

To protect the main board from static electricity, do not touch parts on the main board or on the optional
service cards. To discharge static electricity, touch ground or wear an grounding strap.

Installation Manual 35

2.2 Installation of the PBX

Note

When installing or removing the optional service cards, the power switch of the PBX must be in the off
position.

Installing Optional Service Cards

1. Before installing the optional service cards, cut and remove the appropriate dummy cover plates from

the main unit.

Dummy Cover Plate

CAUTION

For safety reasons, smooth the cut edges after removing the dummy cover plates.

2. Position the card in the open slot, making sure that the tabs on the both sides of the card fit into place.

Then, holding the card firmly in place, lower the rear end so that the hole of the card fits over the
extension bolt.

Optional Service Card

1

2

Extension Bolt

CAUTION

When installing the optional service cards, do not put pressure on any parts of the main board. Doing
so may result in damage.

36 Installation Manual

2.2 Installation of the PBX

3. Insert the new extension bolt (included with the card) into the hole on the card, and tighten it to secure

the card.

Extension Bolt

4. Stick an appropriate optional card label (included) to the left side of the corresponding card.

Optional Card Label

5. Connect a cable to an appropriate port of the card.

For details about pin assignments, refer to the appropriate section in "2.3 Installation of the CO Line
Cards" and "2.4 Installation of the Extension Cards".

Note

Make sure to connect cables after installing the card in the PBX, not before.

Installation Manual 37

2.2 Installation of the PBX

6. Repeat the procedure for other cards.

• When installing a card in Slot 11, tighten the card using the screw included with the card, instead

of the extension bolt.

Screw

38 Installation Manual

Handling of the Cables

Attach the strap included with the card to one of the connected cables.

1.

Strap

2.2 Installation of the PBX

2. Bind all the connected cables together using the strap.

3. Repeat the procedure for other cards.

Installation Manual 39

2.2 Installation of the PBX

4. Attach the main strap (included with the PBX) to any of the 5 rails depending on your preference.

Main Strap

2

1

40 Installation Manual

2.2 Installation of the PBX

5. Bind all the connected cables together using the main strap, and then close the cable cover. For

how to close the cable cover, refer to "2.2.3 Opening/Closing the Covers".

Cable Cover

Main Strap

Notes

• For safety reasons, do not stretch, bend, or pinch the cables.

• If you prefer, you can cut the other side of the cable cover and run the cables through that

opening. For safety reasons, smooth the cut edges.

Installation Manual 41

2.2 Installation of the PBX

Removing the Optional Service Cards

1. Loosen the extension bolt.

2. Holding the protrusions of the card, pull the card in the direction of the arrows.

CAUTION

When removing the optional service cards, do not put pressure on any parts of the main board. Doing
so may result in damage.

42 Installation Manual

2.2.7 Types of Connectors

Connector Type Pin Number Used for

2.2 Installation of the PBX

RJ11

(Twisted pair cable)

10-pin
Terminal Block

8-pin
Terminal Block

RS-232C

USB

4 1

1 5

6 9

2

1

• DPH4 (TAW84861)

• HLC4 (TAW84871)

• SLC8 (TAW84874)

• PLC4 (TAW84875)

• PLC8 (TAW84876)

• LCOT4 (TAW84880)

• Hybrid Ports (Main Board)

• DPH4 (KX-TAW84861)

81

101

• Main Board

• Main Board

Mini Plug

3

4

• Main Board (Pager port, MOH port)

+

-

Installation Manual 43

2.2 Installation of the PBX

2.2.8 Wall Mounting (KX-TAW848)

Mounting on Wooden Wall

1. Place the reference for wall mounting on the wall to mark the three screw positions.

130 mm (5-1/8 in)

250 mm

(9-13/16 in)

2. Install the screws and washers (included) in the wall.

Washer

Drive the screw
to this position.

Notes

• Make sure that the screw heads are at the same distance from the wall.

• Install the screws perpendicular to the wall.

3. Hook the main unit on the screw heads.

Notes

• Do not block the openings of the cabinet. Leave at least 20 cm (8 in) of space above and 10 cm (4

in) to the sides of the PBX for ventilation.

• Make sure that the wall behind the cabinet is flat and free of obstacles, so that the openings on the

back of the cabinet will not be blocked.

• Be careful not to drop the cabinet.

44 Installation Manual

Mounting on Concrete or Mortar Wall

CAUTION

Drive mounting screws into the wall. Be careful to avoid touching any metal laths, wire laths or metal
plates in the wall.

1. Place the reference for wall mounting on the wall to mark the three screw positions.

130 mm (5-1/8 in)

250 mm

(9-13/16 in)

2. Install three anchor plugs (user-supplied) in the wall.

2.2 Installation of the PBX

Hammer

Anchor Plug

6.4 mm
(1/4 in)

29 mm
(1-1/8 in)

3. Install the screws (included) in the wall.

Drive the screw
to this position.

4. Hook the main unit on the screw heads.

Installation Manual 45

2.2 Installation of the PBX

Notes

• Do not block the openings of the cabinet. Leave at least 20 cm (8 in) of space above and 10 cm (4

in) to the sides of the PBX for ventilation.

• Make sure that the wall behind the cabinet is flat and free of obstacles, so that the openings on the

back of the cabinet will not be blocked.

• Be careful not to drop the cabinet.

46 Installation Manual

2.2 Installation of the PBX

2.2.9 Wall Mounting (AC Adaptor)

Mounting on Wooden Wall

1. Place the reference for wall mounting (on the following page) on the wall to mark the two screw

positions.

110 mm

(4-5/16 in)

2. Install the screws and washers (included) in the wall.

Washer

Drive the screw
to this position.

Notes

• Make sure that the screw heads are at the same distance from the wall.

• Install the screws perpendicular to the wall.

3. Hook the AC adaptor on the screw heads.

Note

Be careful not to drop the AC adaptor.

Installation Manual 47

2.2 Installation of the PBX

Mounting on Concrete or Mortar Wall

CAUTION

Drive mounting screws into the wall. Be careful to avoid touching any metal laths, wire laths or metal
plates in the wall.

1. Place the reference for wall mounting (on the following page) on the wall to mark the two screw

positions.

110 mm

(4-5/16 in)

2. Install two anchor plugs (user-supplied) in the wall.

Hammer

Anchor Plug

6.4 mm
(1/4 in)

29 mm
(1-1/8 in)

3. Install the screws (included) in the wall.

Drive the screw
to this position.

4. Hook the AC adaptor on the screw heads.

Note

Be careful not to drop the AC adaptor.

48 Installation Manual

Reference for Wall Mounting

Please copy this page and use as a reference for wall mounting.

Install a screw here.

110 mm

(4-5/16 in)

2.2 Installation of the PBX

Install a screw here.

Note

Make sure to set the print size to correspond with the size of this page. If the dimension of the paper
output still deviates slightly from the measurement indicated here, use the measurement indicated
here.

Installation Manual 49

2.2 Installation of the PBX

2.2.10 Surge Protector Installation

Overview

A massive electrical surge can be caused if lightning strikes a telephone cable 10 m (33 ft) above ground,
or if a telephone line comes into contact with a power line. A surge protector is a device that is connected
to a CO line to prevent potentially dangerous electrical surges from entering the building via the CO line and
damaging the PBX and connected equipment.

To protect the system from electrical surges, we strongly recommend connecting the system to a surge
protector that meets the following specifications:

• Surge arrestor type: 3-electrode arrestor

• DC spark-over voltage: 230 V

• Maximum peak current: at least 10 kA

Additionally, proper grounding is very important for the protection of the system (refer to "2.2.5 Frame
Ground Connection").

Many countries/areas have regulations requiring surge protection. Be sure to comply with all applicable
laws, regulations, and guidelines.

Installation

CO Line CO Line CO Line

Surge

Protector

Terminal

Ground

Board

Extn. Extn. Extn.

SLT

APT

Extn.

CS

PBX

Frame
Ground

Extn.: Extension line

50 Installation Manual

Outside Installation

(Main Building)

2.2 Installation of the PBX

CO Line

If you install an extension outside of the building, the following precautions are recommended:

Surge Protector

CO Line

Terminal

Board

Extn. Extn.

APT

Extn.

CSSLT

PBX

Extn.

Surge

Protector

Ground

(Another Building)

SLT

APT

CS

Extn.: Extension Line

a. Install the extension wire underground.
b. Use a conduit to protect the wire.

Note

The surge protector for an extension and CS is different from that for a CO line.

Installation of a Ground Rod

Surge Protector

CO Line

Grounding

Wire

(Underground)

Ground Rod

PBX

Installation Manual 51

2.2 Installation of the PBX

1. Connect the ground rod to the surge protector using a grounding wire with a cross-sectional area of at

2

least 1.3 mm

.

2. Bury the ground rod near the protector. The grounding wire should be as short as possible.

3. The grounding wire should run straight to the ground rod. Do not run the wire around other objects.

4. Bury the ground rod at least 50 cm (20 in) underground.

Notes

• The above figures are recommendations only.

• The length of ground rod and the required depth depend on the composition of the soil.

52 Installation Manual

2.3 Installation of the CO Line Cards

2.3 Installation of the CO Line Cards

2.3.1 LCOT4 Card

Function

4-port analog CO line card with 2 power failure transfer (PFT) ports. One CID4 card can be mounted on the
LCOT4 card (refer to "2.3.2 CID4 Card").

PFT Port 2

PFT Port 1

RJ11

To CO line

Accessories and User-supplied Items

Accessories (included): Extension Bolt × 1, Strap × 1
User-supplied (not included): RJ11 connector

Notes

• To confirm the CO line connection, refer to "Confirming the CO Line Connection" in "2.11.1 Starting
the PBX".

• For details about power failure transfer, refer to "2.10.1 Power Failure Connections".

Pin Assignments

RJ11 Connector

Signal Name Function

T R

4 1

RRing

TTip

– Reserved

Installation Manual 53

2.3 Installation of the CO Line Cards

2.3.2 CID4 Card

Function

4-port Caller ID signal type FSK/FSK (with Call Waiting Caller ID [Visual Caller ID])/DTMF. To be mounted
on the LCOT4 card.

CID4 Card

LCOT4 Card

Accessories and User-supplied Items

Accessories (included): none
User-supplied (not included): none

Note

If you need to remove the CID4 card:

54 Installation Manual

2.4 Installation of the Extension Cards

2.4 Installation of the Extension Cards

2.4.1 HLC4 Card

Function

4-port extension card for SLTs, APTs, DSS consoles, a Voice Processing System (VPS), and CSs.

RJ11

To extension

Accessories and User-supplied Items

Accessories (included): Extension Bolt × 1, Strap × 1
User-supplied (not included): RJ11 connector

Note

For details about connecting the CS, refer to "2.7.7 Connecting a Cell Station to the PBX".

Pin Assignments

RJ11 Connector

Signal Name Function

D2 D1

R T

4 1

D1 Data port (High)

TTip

RRing

D2 Data port (Low)

Installation Manual 55

2.4 Installation of the Extension Cards

2.4.2 PLC4 Card

Function

4-port extension card for APTs, DSS consoles, and a VPS.

RJ11

To extension

Accessories and User-supplied Items

Accessories (included): Extension Bolt × 1, Strap × 1
User-supplied (not included): RJ11 connector

Pin Assignments

RJ11 Connector

D2 D1

R T

4 1

Signal Name Function

D1 Data port (High)

TTip

RRing

D2 Data port (Low)

56 Installation Manual

2.4.3 SLC8 Card

Function

8-port extension card for SLTs.

RJ11

2.4 Installation of the Extension Cards

To extensions

Accessories and User-supplied Items

Accessories (included): Extension Bolt × 1, Strap × 1
User-supplied (not included): RJ11 connector

Pin Assignments

RJ11 Connector

Signal Name Function

R T

4 1

TTip

RRing

– Reserved

Installation Manual 57

2.4 Installation of the Extension Cards

2.4.4 PLC8 Card

Function

8-port extension card for APTs, DSS consoles, and a VPS.

RJ11

To extensions

Accessories and User-supplied Items

Accessories (included): Extension Bolt × 1, Strap × 1
User-supplied (not included): RJ11 connector

Pin Assignments

RJ11 Connector

Signal Name Function

D2 D1

R T

4 1

D1 Data port (High)

TTip

RRing

D2 Data port (Low)

58 Installation Manual

2.5 Installation of the Other Cards

2.5 Installation of the Other Cards

2.5.1 DPH4 Card

Function

4-port doorphone card for 4 doorphones, 4 door openers or external relays, and 4 external sensors.

10-pin

8-pin

RJ11

To external sensors

Telephone Line Cord

To door openers/
external relays

To doorphones

Accessories and User-supplied Items

Accessories (included): Extension Bolt × 1, Strap × 1, 8-pin terminal block × 1, 10-pin terminal block ×

1, Telephone Line Cord × 2, Terminal Box × 2

User-supplied (not included): Copper wire

Note

For details about connection to doorphones, door openers, external sensors, and external relays, refer
to "2.8.1 Connection of Doorphones, Door Openers, External Sensors, and External Relays".

Pin Assignments

RJ11 Connector

Signal Name Function

DP2 Doorphone 2 transmit

5 81 4

DP1 Doorphone 1 transmit

DP2

DP1

com1

com2

DP4

DP3

com3

com4

com1 Doorphone 1 receive

com2 Doorphone 2 receive

DP4 Doorphone 4 transmit

DP3 Doorphone 3 transmit

com3 Doorphone 3 receive

com4 Doorphone 4 receive

Installation Manual 59

2.5 Installation of the Other Cards

8-pin Terminal Block

Signal Name Function

SENS 1a

SENS 1b

SENS 2a

SENS 2b

SENS 3a

SENS 3b

SENS 4a

SENS 4b

1

10-pin Terminal Block

OP1b (RL1b)

OP1a (RL1a)

OP2b (RL2b)

OP2a (RL2a)

OP3b (RL3b)

OP3a (RL3a)

OP4b (RL4b)

OP4a (RL4a)

1

SENS 1a Sensor Input 1

SENS 1b com 1

SENS 2a Sensor Input 2

SENS 2b com 2

SENS 3a Sensor Input 3

8

SENS 3b com 3

SENS 4a Sensor Input 4

SENS 4b com 4

Signal Name Function

OP1b (RL1b) Door opener 1 (Relay 1)

OP1a (RL1a) Door opener 1 com (Relay 1 com)

OP2b (RL2b) Door opener 2 (Relay 2)

OP2a (RL2a) Door opener 2 com (Relay 2 com)

OP3b (RL3b) Door opener 3 (Relay 3)

10

OP3a (RL3a) Door opener 3 com (Relay 3 com)

OP4b (RL4b) Door opener 4 (Relay 4)

OP4a (RL4a) Door opener 4 com (Relay 4 com)

– Reserved

60 Installation Manual

2.5 Installation of the Other Cards

Connection Diagram for External Sensors and External Relays

Power to the external sensor is provided from the DPH4 card and must be grounded through the DPH4 card
as indicated in the diagram below. A pair of "sensor" and "common" lines must be connected to the DPH4
card for each external sensor. The PBX detects input from the sensor when the signal is under 100 Ω.

Sensor 4

Sensor 3

Sensor 2

Sensor 1

sensor

common

sensor

common

sensor

common

sensor

common

10

2.2K

47K

5 V

10K Ω

5 V

33 Ω

33 Ω

2.2K

47K

5 V

10K Ω

5 V

33 Ω

33 Ω

2.2K

47K

5 V

10K Ω

5 V

33 Ω

33 Ω

5 V

10K Ω

2.2K

47K

5 V

33 Ω

8

33 Ω

7
6
5
4
3
2
1

9
8
7
6

Relay 4

Relay 3

5
4
3
2
1

Relay 2

Relay 1

Installation Manual 61

2.5 Installation of the Other Cards

2.5.2 ECHO8 Card

Function

8-channel card for echo cancellation during conferences.

Accessories and User-supplied Items

Accessories (included): Extension Bolt × 1, Screw × 1
User-supplied (not included): none

Note

To establish a conference call involving 6 to 8 parties, install an ECHO8 card and enable the echo
cancellation for conference using the KX-TAW848 Maintenance Console. For details, refer to the on­line help of the KX-TAW848 Maintenance Console.

62 Installation Manual

2.5.3 MSG2 Card

Function

2-channel message card.

Accessories and User-supplied Items

Accessories (included): Extension Bolt × 1, Screw × 1
User-supplied (not included): none

2.5 Installation of the Other Cards

Installation Manual 63

2.5 Installation of the Other Cards

2.5.4 EXT-CID Card

Function

Sends Caller ID signals to extension ports.

Accessories and User-supplied Items

Accessories (included): Extension Bolt × 1, Screw × 1
User-supplied (not included): none

64 Installation Manual

2.5.5 RMT Card

Function

Analog modem card for remote communication with the PBX. ITU-T V.90 support.

RMT Card

2.5 Installation of the Other Cards

RMT Slot

Accessories and User-supplied Items

Accessories (included): none
User-supplied (not included): none

CAUTION

Make sure to insert the RMT card between the guide rails until it locks into the RMT slot. Push the card
firmly into place until you hear a clicking sound.

Installation Manual 65

2.5 Installation of the Other Cards

Removing the RMT Card

Pull open the guide rails using a flathead screwdriver and, while holding them open, remove the RMT card.

66 Installation Manual

2.6 Connection of Extensions

2.6 Connection of Extensions

2.6.1 Maximum Cabling Distances of the Extension Wiring (Twisted Cable)

Cable Maximum Distance
26 AWG: 222 m (728 ft)
24 AWG: 347 m (1138 ft)
22 AWG: 500 m (1640 ft)
CAT 5: 347 m (1138 ft)

Cable Maximum Distance
26 AWG: 140 m (459 ft)
24 AWG: 229 m (751 ft)
22 AWG: 360 m (1181 ft)
CAT 5: 229 m (751 ft)

Cable Maximum Distance
26 AWG: 698 m (2289 ft)
24 AWG: 1128 m (3700 ft)
22 AWG: 1798 m (5897 ft)
CAT 5: 1128 m (3700 ft)

CS

APT and DSS Console

SLT

Notice

The maximum cabling distance may vary depending on the conditions.

CS APT DSS Console SLT

Hybrid Ports
(Main Board)

SLC8 Card

PLC4, PLC8 Cards

HLC4 Card

" " indicates that the extension card or Hybrid Ports support the terminal.

Installation Manual 67

2.6 Connection of Extensions

2.6.2 Parallel Connection of the Extensions

Any SLT can be connected in parallel with an APT as follows:

To a Hybrid Port

Modular
T-Adaptor

2-conductor wiring cord

Connect pins "T" and "R".
4-conductor wiring cord
Connect pins "T", "R", "D1",
and "D2".

SLTAPT

Note

In addition to an SLT, an answering machine, a fax machine or a modem (PC) can be connected in
parallel with APTs.

68 Installation Manual

2.7 Connection of 2.4 GHz Portable Stations

2.7 Connection of 2.4 GHz Portable Stations

2.7.1 Overview

The following equipment is required to connect the wireless system:

CS: Cell Station (KX-T0141)

This unit determines the area covered by the wireless system. Up to 2 calls can be made at the same time
through each CS.

PS: 2.4 GHz Portable Station (KX-TD7680/KX-TD7690)

The KX-TAW848 can support up to 28 PSs. For more details about the PS, refer to the PS Operating
Instructions.

CAUTION

• The CS should be kept free of dust, moisture, high temperature (more than 40 °C [104 °F]), low
temperature (less than 0 °C [32 °F]), vibration, and should not be exposed to direct sunlight.

• The CS should not be placed outdoors (use indoors).

• The CS should not be placed near high voltage equipment.

• The CS should not be placed on a metal object.

• Systems using 2.4 GHz ISM (Industrial, Scientific and Medical) band may interfere with the

wireless system. Examples of such systems are cordless telephones, wireless LAN, Home RF,
microwave ovens and other ISM devices. These systems may cause minor noise.

• Keeping some distance between the equipment listed below may prevent interference. (The
distance may vary depending on the environment.)

Equipment Distance

CS and office equipment such as a computer, telex, fax
machine, etc.

CS and PS More than 1 m (3 ft 3 in)

Each PS More than 0.5 m (1 ft 8 in)

PBX and CS More than 2 m (6 ft 7 in)

CS and CS More than 15 m (49 ft)

Please take into consideration the distance between the CSs when site planning. Please consult
your dealer for details.
However, the required distance between CSs may vary depending on the environment of the
installation site and conditions in which the wireless system is used. Conduct the site survey to
determine the appropriate distance.

More than 2 m (6 ft 7 in)

Installation Manual 69

2.7 Connection of 2.4 GHz Portable Stations

9

2.7.2 Procedure Overview

When connecting the wireless system, use extreme care to conduct a site survey. Inadvertent site survey
can result in poor service area, frequent noise, and disconnection of calls.

1. Investigate the installation site

Refer to "2.7.3 Site Planning".

a. Obtain the map of the CS installation site.
b. Consider the service area demanded by the user on the map.
c. Plan the locations of each CS, taking account of distance, building materials and etc.

2. Prepare the CS for site survey

Refer to "2.7.4 Before Site Survey".

a. Assign a CS number to each CS by setting the DIP switches on the back of the CS.
b. Supply electricity to each CS using an AC adaptor or a battery box.
c. Install each CS temporarily as planned.

Notes

• Install at least 2 m (6 ft 7 in) above the floor.

• Keep the antennas in the upright position.

3. Conduct the site survey

Refer to "2.7.5 Site Survey".

a. Test the radio signal strength using the PS.

Confirm that the radio signal strength level is "12" near the CS.

Using the KX-TD7680

9

1

Press 1, 9, and POWER
for more than 2 seconds.

Using the KX-TD7690

9

1

Press 1, 9, and POWER
for more than 2 seconds.

b. By walking away from the CS with the PS, check the radio signal strength. The radio signal strength

weakens as you walk away from the CS.

c. Map the CS coverage area at radio signal strength levels "3" and "8".
d. Make sure that adjacent CS coverage areas overlap where the radio signal strength level is "8" by

at least 5 m (16 ft).

e. Make sure that the radio signal strength level is greater than "3" at any location within the service

area demanded by the user.

0

Display example:

CS No.

1 to 9

0

CS No.

1 to 9

<< SEARCHING >>

Display example:

<< SEARCHING >>

CS NO.1 LEVEL:12

SAVE:0123456789

CS NO.1 LEVEL:12

SAVE:0123456789

70 Installation Manual

2.7 Connection of 2.4 GHz Portable Stations

4. Finish the site survey

Refer to "2.7.6 After Site Survey".

a. Return all DIP switches of each CS to the OFF position, and stop supplying power.
b. Turn off the PS.

5. Connect the CS and PS to the PBX and test the operation

Refer to "2.7.7 Connecting a Cell Station to the PBX".

a. Connect the CSs to the PBX.
b. Register the PSs to the PBX.
c. Walk around the service area while having a conversation using a registered PS. If noise is

frequent or conversations disconnect, relocate the CSs or install an additional CS.

6. Mount the CS on the wall

Refer to "2.7.8 Wall Mounting".

a. Assuming everything goes as planned, mount the CS on the wall.

Installation Manual 71

2.7 Connection of 2.4 GHz Portable Stations

2.7.3 Site Planning

Choosing the best site for the CS requires careful planning and testing of essential areas. The best location
may not always be convenient for installation. Read the following information before installing the unit.

Understanding the Radio Waves

Characteristics of Radio Waves

The transmission of radio waves and the CS coverage area depend on the structure and materials of the
building.

Office equipment, such as computers and fax machines, can interfere with radio waves. Such equipment
may create noise or interfere with the performance of the PS.

The illustration below shows the special transmitting patterns of radio waves.

1. Radio waves are reflected by objects such as those made of metal.

2. Radio waves are diffracted by objects such as metallic columns.

3. Radio waves penetrate objects such as those made of glass.

CS

1. Reflection

Column

2. Diffraction

3. Penetration

Relationships Between Radio Waves and Building Structure and Materials

• The CS coverage area is affected more by the building materials and their thickness than the number
of obstacles.

• Radio waves tend to be reflected or diffracted by conductive objects and rarely penetrate them.

• Radio waves tend to penetrate insulated objects and are rarely reflected by them.

• Radio waves penetrate thin objects more than thick objects.

• The table below shows the transmission tendency of radio waves when they reach objects made from

various materials.

72 Installation Manual

2.7 Connection of 2.4 GHz Portable Stations

Object Material Transmission Tendency

Wall Concrete The thicker they are, the less radio waves penetrate them.

Ferroconcrete Radio waves can penetrate them, but the more iron there is,

the more radio waves are reflected.

Window Glass Radio waves usually penetrate them.

Glass with wire nets Radio waves can penetrate them, but tend to be reflected.

Glass covered with
heat-resistant film

Radio waves are weakened considerably when they penetrate
windows.

Floor Ferroconcrete Radio waves can penetrate them, but the more iron there is,

the more radio waves are reflected.

Partition Steel Radio waves are reflected and rarely penetrate them.

Plywood, Glass Radio waves usually penetrate them.

Column Ferroconcrete Radio waves can penetrate them, but the more iron there is,

the more radio waves tend to be reflected or diffracted.

Metal Radio waves tend to be reflected or diffracted.

Cabinet Steel Radio waves are usually reflected or diffracted, and rarely

penetrate them.

Wood Radio waves can penetrate them, but they are weakened.

Installation Manual 73

2.7 Connection of 2.4 GHz Portable Stations

CS Coverage Area

The example below shows the size of the coverage area of 1 CS if it is installed where there is no obstacle.

Note

Radio signal strength levels are measured during the site survey (refer to "2.7.5 Site Survey").

Coverage Area

A

Radio signal strength level is
greater than "3".
(About 50 m to 60 m

A

B

Gray Zone:

Conversation will be

intermittent

[164 ft to 197 ft])

Good Coverage Area

B

Radio signal strength
level is greater than "8".
(About 30 m to 40 m
[98 ft to 131 ft])
Good conversation
will be kept.

Out of Service:

C

Cannot make/receive calls

Radio Signal Strength Levels

Level: 00
Level: 01 to 02
Level: 03 to 07
Level: 08 to 10
Level: 11 to 12

Out of range
Receives noise easily or disconnects
May receive noise
Good
Better

Site Survey Preparation

1. Obtain the map and investigate the installation site.
a. Check the obstacles (e.g., shelves, columns, and partitions).
b. Check the materials of the structures (e.g., metal, concrete, and plywood).
c. Check the layout and dimensions of the room, corridor, etc.
d. Write down the above information to the map.

2. Examine the service area demanded by the user on the map, referring to the following example.
a. Draw the coverage area around a CS. Extend the coverage area to 30 to 60 meters (98 to 197 feet)

in one direction, depending on the materials of the building structures and obstacles in the
installation site. Note that a CS cannot be installed outside a building.

b. If one CS cannot cover the entire service area, install additional CSs as required. Overlap the

coverage areas of adjacent CSs.
Where CS coverage areas overlap, the PS will start call handover to the next CS if the signal from

74 Installation Manual

one CS becomes weak. However, if a PS moves away from a CS and there are no CSs available
for handover, the PS may go out of range and the call could be lost.
If the signal from the CS fades, due to the structure of the building, there may be some handover
delay. The user will hear a range warning before handover in this case. This also applies in the case
of interference from 2.4 GHz apparatus.

Example: Installing in a Room Separated by Walls

Things to take note of:

• The room is separated by walls.

• The room is surrounded by concrete walls.

CS installation plan:

• The coverage area of each CS will not extend as far as when there is no obstacle, because the
radio signals will be weakened by separating walls. Therefore, you will need 4 CSs to cover the
entire room.

100 m (328 ft)

2.7 Connection of 2.4 GHz Portable Stations

70 m

(230 ft)

CS no. 1

CS no. 3

CS no. 2

CS no. 4

Installation Manual 75

2.7 Connection of 2.4 GHz Portable Stations

2.7.4 Before Site Survey

Setting and Installing the CS Temporarily for Site Survey

1. Switch the Radio Signal Test switch from OFF to ON.

2. Set the CS number switches as desired.

DIP Switch

OFF ON

1

2

CS Number Switch

3

4

5

6

Radio Signal
Test Switch

CS no. 1 CS no. 2 CS no. 3 CS no. 4 CS no. 5 CS no. 6 CS no. 7 CS no. 8 CS no. 9

1

2

3

4

1

2

3

4

1

2

3

4

1

2

3

4

1

2

3

4

1

2

3

4

1

2

3

4

1

2

3

4

1

2

3

4

Notes

• To see the radio signal strength of more than 1 CS, a CS number must be set for each CS.

• If more than 1 CS is in Radio Signal Test mode, each CS must have a unique CS number.

76 Installation Manual

2.7 Connection of 2.4 GHz Portable Stations

3. After setting the DIP switch, connect an AC adaptor or battery box to the CS using a power supply

adaptor.

Note

The AC adaptor should be connected to a vertically oriented or floor-mounted AC outlet. Do not connect
the AC adaptor to a ceiling-mounted AC outlet, as the weight of the adaptor may cause it to become
disconnected.

Telephone Cord

Power Supply Adaptor

Modular

(PSZZ1TDA0142)

To AC Adaptor (KX-A11/KX-TCA1)/
Battery Box (PSZZTD142CE)

4. Install the CS temporarily for the site survey. Install the CS at least 2 m (6 ft 7 in) above the floor, keeping

the antennas in the upright position.

Installation Manual 77

2.7 Connection of 2.4 GHz Portable Stations

9

9

2.7.5 Site Survey

The PS has a Radio Signal Test mode that monitors the state of the radio link to the CS. After installing the
CSs temporarily, set the PS to the Radio Signal Test mode and measure each CS coverage area. Then,
record the results on the map of the installation site.

Testing the Radio Signal Strength

Note

The display language for the site survey is only in English.

1. Enter the Radio Signal Test mode.

Using the KX-TD7680

9

1

Press 1, 9, and POWER
for more than 2 seconds.

To store the scan data

Display example:

0

CS No.

1 to 9

<< SEARCHING >>

CS NO.1 LEVEL:12

SAVE:0123456789

*

1

*

2

Scan Data No.

0 to 9

Using the KX-TD7690

9

1

Press 1, 9, and POWER
for more than 2 seconds.

To store the scan data

Display example:

0

CS No.

1 to 9

<< SEARCHING >>

CS NO.1 LEVEL:12

SAVE:0123456789

*

1

*

2

Scan Data No.

0 to 9

Notes

*1: CS number and radio signal strength level.
*2: Scan data (test result) number. Empty memory space will be indicated by a number; stored memory

space will be indicated by a "-".

78 Installation Manual

2.7 Connection of 2.4 GHz Portable Stations

2. Measure the radio signal strength by moving to and away from the CS.
a. Move to the CS until the point the radio signal strength level becomes "12".
b. Move away from the CS and identify the CS coverage area within which the radio signal strength

level is greater than "8". Draw the area on the map.

c. Move away from the CS and identify the CS coverage area within which the radio signal strength

level is greater than "3". Draw the area on the map.

PS

CS no. 1

Radio Signal Strength Levels

Level: 00
Level: 01 to 02
Level: 03 to 07
Level: 08 to 10
Level: 11 to 12

CS NO.1 LEVEL:12

PS

Out of range
Receives noise easily or disconnects
May receive noise
Good
Better

CS NO.1 LEVEL:8

PS

CS NO.1 LEVEL:3

3. Repeat the steps 1 and 2 for other CSs, and relocate the CSs when necessary.
a. Overlap adjacent CS coverage areas where the radio signal strength level is "8" by 5 to 10 meters

(16 to 33 feet).

CS no. 1 CS no. 2

5 m to 10 m

(16 ft to 33 ft)

Installation Manual 79

2.7 Connection of 2.4 GHz Portable Stations

b. Overlap the CS coverage areas of at least 2 CSs at any location in the installation site.

CS no. 1 CS no. 2

CS no. 3

c. Make sure that the radio signal strength level is greater than "3" at any location in the service area

demanded by the user.

Referring to the Stored Scan Data

Using the KX-TD7680

9

1

Press 1, 9, and POWER
for more than 2 seconds.

Using the KX-TD7690

9

1

Press 1, 9, and POWER
for more than 2 seconds.

1

1

Scan Data No.

0 to 9

To the Desired Scan Data No.

Scan Data No.

0 to 9

To the Desired Scan Data No.

CS no. 4

Display example:

When there is scan data

NO.1
CS No.2 LEVEL: 9

When there is no scan data

NO.0
NOT SAVED

Display example:

When there is scan data

NO.1
CS No.2 LEVEL: 9

When there is no scan data

NO.0
NOT SAVED

80 Installation Manual

Deleting the Stored Scan Data

Using the KX-TD7680

9

1

Press 1, 9, and POWER
for more than 2 seconds.

Using the KX-TD7690

2

Scan Data No.

0 to 9, or # for all data

To the Desired Scan Data No.

2.7 Connection of 2.4 GHz Portable Stations

9

1

Press 1, 9, and POWER
for more than 2 seconds.

2

Scan Data No.

0 to 9, or # for all data

To the Desired Scan Data No.

Installation Manual 81

2.7 Connection of 2.4 GHz Portable Stations

2.7.6 After Site Survey

After obtaining the proper measurement results, exit the Radio Signal Test mode before connecting the CS
to the PBX.

1. Keep pressing POWER button on the PS until the PS is turned OFF.

2. Disconnect the AC adaptor or battery box from the CS and stop supplying electricity.

3. Switch all DIP switches on the CS from ON to OFF.

OFF ON

1

2

3

4

5

6

82 Installation Manual

2.7 Connection of 2.4 GHz Portable Stations

2.7.7 Connecting a Cell Station to the PBX

Refer to the following example to connect a CS to the PBX.

Hybrid Port

Cable Maximum Distance
26 AWG: 222 m (728 ft)
24 AWG: 347 m (1138 ft)
22 AWG: 500 m (1640 ft)
CAT 5: 347 m (1138 ft)

A Hybrid Port or HLC4 card (RJ11)

Signal Name

D1

D2

Pin No.

1
2
3

4

Accessories and User-supplied Items for the CS

Accessories (included): Screws × 2, Washers × 2
User-supplied (not included): RJ11 connector

Note

For details about HLC4 card, refer to "2.4.1 HLC4 Card".

Pin No.

1
2

3
4

CS (RJ11)

Signal Name

D1

D2

Installation Manual 83

2.7 Connection of 2.4 GHz Portable Stations

Connecting the CS

1. Connect the cable from a Hybrid Port or the HLC4card to the CS.

Modular

To a Hybrid Port,
or HLC4 card

2. Pass the cable through the groove of the CS (in any direction depending on your preference).

To a Hybrid Port,
or HLC4 card

TO MAIN UNIT

/ PABX

84 Installation Manual

2.7 Connection of 2.4 GHz Portable Stations

Registering the PS

The PS must be registered to the PBX before it can be used. Programming of both the PS and PBX is
required. An APT with multiline display (e.g., KX-T7735) is required for the PBX system programming.

Note

For details about system programming using an APT, refer to "2.3.2 PT Programming" and "3.3 PT
Programming" in the Feature Guide.

Entering the System Programming Mode

APT (Administrator Level)

System Password for Administrator—

PROGRAM/

#

PAUSE

PS (Using the KX-TD7680)

FUNC

Press POWER
for 2 seconds.

If required

System Lock Password

4 digits

for PT Programming

Select
"PS PROGRAM".

= 1234

Select
"SYSTEM SET".

System Setting Menu

Programming No.

3 digits

PS (Using the KX-TD7690)

MENU SEL

Press POWER
for 2 seconds.

If required

S1 S1

System Lock Password

4 digits

Note

means default value throughout this section.

Select
"PS PROGRAM".

ENTR

S1

SEL

S1

Select
"SYSTEM SETTING".

System Setting Menu

Installation Manual 85

2.7 Connection of 2.4 GHz Portable Stations

PS Registration

[690]

STORE

PS No.

001 to 028

Extn. No.

1 to 4 digits

STORE

To the PS
operation
below

END

When the PS has not been registered yet

When registering the PS for the first time, it is possible to select the desired language for the display.
(You do not need to enter the PS system programming mode when registering for the first time.)

Using the KX-TD7680

[ F3 ]

Press S3
for 2
seconds.

C.Tone
Press
POWER for
2 seconds.

[ F2 ]

Press S2 repeatedly
to select the desired
language.

Using the KX-TD7690

F3

Press S3
for 2
seconds.

C.Tone
Press
POWER for
2 seconds.

F2

Press S2 repeatedly
to select the desired
language.

When the PS has already been registered to another PBX

One PS can be registered to a maximum of 4 different PBXs.

Using the KX-TD7680

Select
"REGISTRATION".

Choose
"SYSTEM 1–4".

C.Tone

Using the KX-TD7690

SEL SEL

Select
"REGISTRATION".

Choose
"SYSTEM 1–4".

C.Tone

S1S1

Setting the System Lock

When a system lock has been set, the system lock password will be required for PS system setting.

Using the KX-TD7680

Select
"SYSTEM LOCK".

ENABLE

DISABLE

C.Tone

System Lock Password

4 digits

Choose
"Enable/Disable".

System Lock Password

4 digits

86 Installation Manual

Using the KX-TD7690

2.7 Connection of 2.4 GHz Portable Stations

Select
"SYSTEM LOCK".

SEL

ENABLE

S1

DISABLE

ENTR

C.Tone

S1

SEL

S1

System Lock Password

CHNG

S1

4 digits

Choose
"Enable/Disable".

ENTR

S1

System Lock Password

4 digits

Setting the Personal Identification Number (PIN) for PS Registration

To prevent registering the PS to a wrong PBX, a PIN for PS registration can be set to the PBX. Before
registering the PS to the PBX, register the PIN set to the PBX into the PS. By doing so, the PS will only be
registered to the PBX with the matching PIN.

Notes

• By default, the PIN for PS registration is "1234" for both the PBX and PS. Therefore, the PS can
be registered to the PBX without setting the PIN.

• The PIN for PS registration will only be used when registering the PS to the PBX. Therefore, even
when there is more than 1 PBX with the same PIN near the PS, the PS will not be linked to a
different PBX during normal operation after registration.

Setting the PIN for PBX

[692]

STORE

Setting the PIN for PS

Using the KX-TD7680

Select
"CHANGE PIN"

Using the KX-TD7690

SEL

Select
"CHANGE PIN"

S1

PIN for PS Registration

1 to 4 digits

1234

PIN for PS Registration

1 to 4 digits

1234

PIN for PS Registration

1 to 4 digits

1234

STORE

ENTR

S1

END

C.Tone

C.Tone

Installation Manual 87

2.7 Connection of 2.4 GHz Portable Stations

PS Termination

Confirm the following before canceling the PS registration:

• PS is turned on.

• PS is within the range.

[691]

STORE STORE

If "Rejected" or "Time out" is displayed

CLEAR

PS No.

001 to 028

STORE

END

If the registration information is still stored in the PS

Using the KX-TD7680

Select "DELETE
SYSTEM".

C.Tone

Select the
desired item.

Using the KX-TD7690

SEL SEL

Select "DELETE
SYSTEM".

SEL

C.Tone

S1

Select the
desired item.

S1S1

To the PS
operation
below

Select "YES".

Select "YES".

Testing the Operation

Walk around the service area while having a conversation using a registered PS. If noise is frequent or
conversations disconnect, relocate the CSs or install an additional CS.

88 Installation Manual

2.7 Connection of 2.4 GHz Portable Stations

2.7.8 Wall Mounting

1. Place the reference for wall mounting (on the following page) on the wall to mark the 2 screw positions.

2. Install the 2 screws and washers (included) into the wall.

Notes

• Make sure that the screw heads are at the same distance from the wall.

• Install the screws perpendicular to the wall.

3. Hook the CS on the screw heads.

Installation Manual 89

2.7 Connection of 2.4 GHz Portable Stations

Reference for Wall Mounting

Please copy this page and use as a reference for wall mounting.

Install a screw here.

71 mm

(2-13/16 in)

Install a screw here.

Note

Make sure to set the print size to correspond with the size of this page. If the dimension of the paper
output still deviates slightly from the measurement indicated here, use the measurement indicated
here.

90 Installation Manual

2.8 Connection of Doorphones, Door Openers, External Sensors, and External Relays

2.8 Connection of Doorphones, Door Openers,
External Sensors, and External Relays

2.8.1 Connection of Doorphones, Door Openers, External Sensors, and External Relays

A maximum of 4 doorphones (KX-T30865), 4 door openers or external relays, and 4 external sensors can
be connected to the PBX.

Note

Doorphones, door openers, external sensors, and external relays are user-supplied.

Maximum Cabling Distance

Cable Maximum Distance
26 AWG: 70 m (230 ft)
24 AWG: 113 m (371 ft)
22 AWG: 180 m (590 ft)
CAT 5: 113 m (371 ft)

Installing the Doorphone (KX-T30865)

1. Loosen the screw to separate the doorphone into 2 halves.

ic

n

o

s

a

n

a

P

Screw

Doorphone

Door Opener

External Sensor/

External Relay Device

Installation Manual 91

2.8 Connection of Doorphones, Door Openers, External Sensors, and External Relays

2. Pass the wires through the hole in the base cover, and attach the base cover to a wall using 2 screws.

Screw

To terminal box

Note

Two kinds of screws are included with KX-T30865. Please choose the appropriate kind for your wall
type.

: when a doorphone plate has been fixed to the wall

: when you wish to install the doorphone directly to the wall

3. Connect the wires to the screws located in the front cover.

To terminal box

4. Re-attach the 2 halves and re-insert the screw.

92 Installation Manual

2.8 Connection of Doorphones, Door Openers, External Sensors, and External Relays

Panasonic

Panasonic

Panasonic

Panasonic

Connection of Doorphones

1. Connect DPH4 Card to the terminal boxes using telephone line cords.

Refer to "2.5.1 DPH4 Card" for pin assignments.

2. Connect the wires of doorphones 1 and 3 to the red and green screws on the terminal box.

3. Connect the wires of doorphones 2 and 4 to the yellow and black screws on the terminal box.

To DPH4 card

Telephone Line Cord

Terminal Box

Yellow

Red

Panasonic

Black
Green

Panasonic

Doorphone 3 Doorphone 4

Telephone Line Cord

Yellow

Red

Panasonic

Black
Green

Panasonic

Doorphone 1 Doorphone 2

Installation Manual 93

2.8 Connection of Doorphones, Door Openers, External Sensors, and External Relays

Connection of Door Openers, External Sensors, and External Relays

Use 8-pin and 10-pin terminal block (included with the card) for connection.

1. While pressing down on the hole at the top of the terminal block using a screwdriver, insert the wire into

the side hole as shown below. Repeat this procedure for other door openers, external sensors, and
external relays.
Refer to "2.5.1 DPH4 Card" for pin assignments.

Door Opener

External Sensor/

External Relay Device

2. Attach the terminal blocks to the connectors of the DPH4 card in the PBX.

To door openers/
external relays

To external sensors

94 Installation Manual

2.9 Connection of Peripherals

2.9.1 Connection of Peripherals

Cable Maximum Distance
26 AWG to 22 AWG: 10 m (32 ft)
CAT 5: 10 m (32 ft)

2.9 Connection of Peripherals

Cable Maximum Distance
26 AWG to 22 AWG: 10 m (32 ft)
CAT 5: 10 m (32 ft)

Maximum Distance
2 m (6 ft)

Maximum Distance
5 m (16 ft)

BGM/
Music on Hold

Pager:
Amplifier/Speaker

PC

Printer

PC

BGM/MOH

The PBX provides Background Music and Music on Hold. Only 1 external music source (e.g., a user­supplied radio) can be connected to the PBX.

CAUTION

• Wiring should be done carefully to prevent undue force being exerted on the plug. Otherwise,
music may be intermittent.

• An External Music Jack is a SELV port and should only be connected to an approved SELV device.

Note

When the PBX and external music sources are not connected to the same ground, hum noise may be
induced into Background Music and Music on Hold.

Installation Manual 95

2.9 Connection of Peripherals

Pager

Only one paging device (user-supplied) can be connected to the PBX.

CAUTION

An External Paging Jack is a SELV port and should only be connected to an approved SELV device.

PC/Printer (via RS-232C)

The PBX is equipped with an RS-232C interface. This interface provides communication between the PBX
and the user-supplied devices such as PC or line printers. The RS-232C port is used for system
programming, SMDR, diagnostics and external system database storage (save/load) functions.
When using special accessories such as cable, the user should use those specified in this installation
manual to comply with the limits for a Class B digital device pursuant to the FCC Rules.

Note

Use an RS-232C cross cable for connection between the PBX and PC.

Pin Assignments

No. Signal Name Function

1 5

6 9

2 RD (RXD) Receive Data BB 104

34 SD (TXD)

ER (DTR)

56 SG

DR (DSR)

78 RS (RTS)

CS (CTS)

Transmit Data
Data Terminal Ready

Signal Ground
Data Set Ready

Request To Send
Clear To Send

Connection Charts

For connecting a printer/PC with a 9-pin RS-232C connector

PBX Printer/PC

Circuit Type

(EIA)

BB RD (RXD) 2

BA SD (TXD) 3

CD ER (DTR) 4

Signal

Name

Pin No. Pin No.

Signal
Name

2 RD (RXD) BB

3 SD (TXD) BA

4 ER (DTR) CD

Circuit Type

(EIA)

Circuit Type

EIA CCITT

BA
CD

AB
CC

CA
CB

103

108.2

102
107

105
106

AB SG 5

CC DR (DSR) 6

CA RS (RTS) 7

CB CS (CTS) 8

96 Installation Manual

5SG AB

6 DR (DSR) CC

7 RS (RTS) CA

8 CS (CTS) CB

For connecting a printer/PC with a 25-pin RS-232C connector

PBX Printer/PC

2.9 Connection of Peripherals

Circuit Type

(EIA)

Signal
Name

Pin No.

BB RD (RXD) 2

BA SD (TXD) 3

CD ER (DTR) 4

AB SG 5

CC DR (DSR) 6

CA RS (RTS) 7

CB

CS (CTS) 8

RS-232C Signals

• Receive Data (RXD):…(input)
Conveys signals from the printer or the PC.

• Transmit Data (TXD):…(output)
Conveys signals from the unit to the printer or the PC. A "Mark" condition is held unless data or
BREAK signals are being transmitted.

• Data Terminal Ready (DTR):…(output)
This signal line is turned ON by the unit to indicate that it is ON LINE. Circuit ER (DTR) ON does
not indicate that communication has been established with the printer or the PC. It is switched OFF
when the unit is OFF LINE.

• Signal Ground (SG)

Connects to the DC ground of the unit for all interface signals.

• Data Set Ready (DSR):…(input)
An ON condition of circuit DR (DSR) indicates the printer or the PC is ready. Circuit DR (DSR) ON
does not indicate that communication has been established with the printer or the PC.

• Request To Send (RTS):…(output)
This lead is held ON whenever DR (DSR) is ON.

• Clear To Send (CTS):…(input)
An ON condition of circuit CS (CTS) indicates that the printer or the PC is ready to receive data
from the unit. The unit does not attempt to transfer data or receive data when circuit CS (CTS) is
OFF.

• Frame Ground (FG)

Connects to the unit frame and the earth ground conductor of the AC power cord.

Pin No.

Signal
Name

Circuit Type

(EIA)

1FG AA

3 RD (RXD) BB

2 SD (TXD) BA

20 ER (DTR) CD

7SG AB

5 CS (CTS) CB

6

DR (DSR) CC

CF4 RS (RTS)

Installation Manual 97

2.9 Connection of Peripherals

PC (via USB version 1.1)

The PBX is equipped with a USB interface. This interface provides communication between the PBX and a
PC.

The PC is used for system programming, diagnostics and external system database storage (save/load)
functions.

Pin Assignments

No. Signal Name

2

3

1VBUS

1

2USB D-

4

3USB D+

4GND

98 Installation Manual

2.10 Power Failure Connections

2.10 Power Failure Connections

2.10.1 Power Failure Connections

When the power supply to the PBX fails, power failure transfer (PFT) will switch from the current connection
to the Power Failure Connection. Refer to "2.4.1 Power Failure Transfer" in the Feature Guide for further
information.

Note

If DC power is provided by backup batteries, the PBX will remain fully operational and the connection
will not switch to the Power Failure Connection.

Using CO Line Card and Hybrid Ports

In the event of power failure, SLTs connected to Ports 1 and 2 of the Hybrid Ports (on the Main Board) are
automatically connected to PFT ports 1 and 2 of the first LCOT4 card (installed in the least slot number).

Note

Even when the power returns, the conversation established during power failure will be maintained.

Installation Manual 99

2.11 Starting the PBX

2.11 Starting the PBX

2.11.1 Starting the PBX

CAUTION

• SD Memory Card must be inserted in the SD Memory Card slot of the main board before start up.

• Before touching the System Initialize Switch, discharge static electricity by touching ground or

wearing a grounding strap.

• Once you have started the PBX and if you unplug the PBX, do not perform the following procedures
to start the PBX again. Otherwise, your programmed data is cleared. To restart the PBX, refer to
"4.1.4 Using the Reset Button".

• The PBX will continue to be powered even if the power switch is turned "OFF".

• The power supply cord is used as the main disconnect device. Ensure that the AC outlet is located

near the equipment and is easily accessible.

1. Set the System Initialize Switch to the "SYSTEM INITIALIZE" position.

RUN Indicator

ALARM Indicator

Reset Button

System Initialize Switch

100 Installation Manual
