Philips Key 0061 User Manual
wearable digital audio
key 003
key 004
key 005
key 006
User
Manual
Contents
Quick start guide .................................................................................. 3
Safety & maintenance ....................................................................... 4-5
Controls .............................................................................................. 6-9
About KEY audio .................................................................................. 9
Supplied accessories ............................................................................ 9
Installation
Minimum computer system requirements ................................... 10
Software installation .................................................................... 11-12
Power supply
Charging the built-in battery via USB
(connecting the player to your computer) .................................. 13
AAA battery back-up ........................................................................ 14
General operation
Switching on/ off ........................................................................... 15-16
Playback and pause
Adjusting volume +,
Selecting a different track
Auto power down ............................................................................. 16
Transferring data ........................................................................... 17-21
Updating software .............................................................................. 21
Upgrading your device ...................................................................... 21
Troubleshooting ....................................................................... 22-24
Technical data ...................................................................................... 25
2; ...................................................................... 15
– ........................................................................ 15
∞ , § ................................................... 15
© Koninklijke Philips Electronics N.V.,2003.
All rights reserved. Reproduction, copying, usage, modifying, hiring, renting, public performance,
transmission and / or broadcasting in whole or in part is prohibited without the wr itten consent of Philips.
2
Quick start guide
PLAYBACK
/
DOWNLOAD
OFF
/
CHARGE
Thank you for buying this Philips wearable digital audio player. To get started, follow
the steps as shown.
1 Charge
•
Charge up your player (5 hours) before
using it. Adjust the function switch on the
player to OFF/CHARGE. Switch on
your computer. Detach the USB cover
and connect the player to your
computer's USB port. (Windows 98 users, please install required drivers
first*) While charging, the indicator on your player lights up green.
2 Download
•
Adjust the function switch to PLAYBACK/
DOWNLOAD. Connect the player to your
computer's USB port. To transfer MP3 or WMA
files from your computer to the player simply
drag and drop in Windows Explorer. Alternatively use
MUSICMATCH Jukebox to transfer your files.To install this program,
insert the by-packed CD-ROM into your computer's CD-ROM drive. The
installation menu is automatically launched for first-time application users.
3 Play
•
Make sure the function switch is in the
PLAYBACK/ DOWNLOAD position. To listen
to your music, connect the remote control &
headphones to your player and press 2;.
Find more information on the by-packed CD-ROM or visit
www.philips.com/support
*CAUTION!
To avoid problems with playback, do not connect the player
to the USB port until after you complete step 2: Download.
Windows 98 users:
3
Safety & maintenance
Safety & satisfaction
• To enjoy your Philips product, please read and operate the set according to
the instructions inside our user manual (on the CD-ROM.)
• Child safety:The remote control neckstrap (included with KEY004,
KEY006 models only) is not a toy. Special care should be taken if handled
by young children. Avoid placing the neckstrap around the neck of a child
to prevent strangulation!
Take care when using headphones
• Hearing safety: listen at a moderate volume. Using headphones at high
volume can impair your hearing.
• Traffic safety: do not use while driving or cycling as you may cause an
accident
CAUTION!
To avoid damage or malfunction:
• Do not twist or bend the remote control neckstrap as this is a precision
electronic accessory.
• do not expose to excessive heat caused by heating equipment or direct
sunlight.
• do not drop your player or allow objects to fall on it. Strong shocks and
vibrations may cause malfunction.
• this product is not waterproof: do not allow your player or remote
control neck strap to be submersed in water, and avoid exposing the USB
socket to water.Water entering the player may cause major damage.
• do not use any cleaning agents containing alcohol, ammonia, benzene,
or abrasives as these may harm the player and neck strap.To clean, use a
soft damp cloth.
• active mobile phones & strong magnetic fields in the vicinity may
cause interference.
• the supplied software CD-ROM is not an audio CD. Playing CD-ROMs
on audio equipment may damage your audio equipment!
4
Safety & maintenance
Environmental information
We have reduced the packaging to its minimum and made it easy to separate
into mono materials: PET,paper and aluminum foil.
Your player consists of material which can be recycled if disassembled by a
specialized company. Please obser ve the local regulations to dispose of
packaging, and old equipment.
5
Controls
6
1
2
3
4
5
Safety & satisfaction
To enjoy your Philips product, please read and operate the set according to
the instructions inside our user manual.
6
Controls
Remote control
neck strap
supplied with
key004 &
key006
wire remote
supplied with
key003 &
key005
7
Controls
metal pin
1
you can thread and attach a neck or wrist strap (optional) here.
2
remote control jack
Insert your remote control plug here and then connect your headphones to
your remote control
3
indicator
lights up/ blinks according to different functions:
green: during charging the built-in battery
orange: power on/ off and during file transfer.
4
USB port
– Connect the audio player’s USB port to your computer’s USB port to
charge the player or transfer data.
– For back-up power supply, connect the supplied battery box here, loaded
with a fresh AAA alkaline battery.
USB cover
5
detach the protective USB cover to reveal the player’s USB port.
6
OFF / CHARGE and PLAYBACK / DOWNLOAD
Adjust the switch to select function:
OFF / CHARGE charges the built-in battery when connected to USB por t
of your computer.
Note: playback is not possible in this position.
PLAYBACK / DOWNLOAD
– ready to download data when connected to USB port of your computer
– ready to start playback of MP3/ WMA files
The model and production numbers can be found next to the USB port
(please remove the USB cover to see)
8
Controls,accessories
Remote control
2; starts, pauses playback and to switch off the player
∞ , §skips to the previous/ next track
– , + decreases/ increases the volume
Supplied accessories
Make sure these items are in the package. If any item is missing, please contact
your dealer:
1x CD-ROM (installation software & user manual)
1x Quick start guide
1 x earphone, HE570
1 x AAA battery box AY3381 or AY3382 (AAA battery not included)
1x 5-key wire remote control AY3782 or AY3784 (KEY003 and KEY005
models only)
1x neck strap remote control AY3783 or AY3780 (KEY004 and KEY006
models only)
1 x Safety & Warranty booklet
About KEY audio
KEY003/004/005/006 is a solid state, wearable digital audio player:
– plays MP3, WMA (Windows Media Audio) and future digital audio
formats files e.g. digitized and compressed CD tracks, tape tracks, audio
books, newspapers, sound effects, etc., that are encoded into format MP3
or WMA.
– downloads MP3 or WMA without DRM(Digital Rights Management).
– software upgradeable
– can transfer files and other data using Windows File Manager or
Windows Explorer, when the player is connected via USB to your
computer
– directly powered through your computer during file transfer to the player.
9
