Philips HTS5580W F7 User Manual
For product support, visit
www.philips.com/welcome
EN User manual
HTS5580W
ES Manual del usuario
FR-CA Manuel d’utilisation
EN: For further assistance, call the customer support service in your country.
• To obtain assistance in the U.S.A ., Canada, Puer to Rico, or the U.S. Virgin Islands, contac t
Philips Customer Care Center at 1-866-309-0866
• To obtain assistance in Mexico, contact Philips Customer Care Center at 01 800 504 6200
ES: Para obtener mas informacion, llame al servicio de soporte al cliente de su pais.
• Para obtener asistencia en los Es tados Unidos, en Canada, Puer to Rico o en las Islas Virgenes de los Estados
Unidos, comuniquese con Centro de atencion al cliente de Philips al 1-866-309-866
• Solo para Mexico CENTRO DE ATENCION A CLIENTES LADA, 01 80 0 504 62 00 Solo Para Mexico.
FR: Pour obtenir de l’aide supplementaire, communiquez avec le centre de service a la clientele de votre pays.
• Pour obtenir de l’aide aux Etats-Unis, au Canada, a Puerto Rico ou aux lles Vierges americaines, communiquez
avec le centre de ser vice a la clientele Philips au : 1-866-309-0866
• Pour obtenir l’aide au Mexique, entrez en contact avec le centre de soin de client de Philips a 01 800 504 62 00
Contents
1 Notice 2
Copyright 2
Compliance 2
Open source software 2
About Progressive Scan 2
Trademarks 3
6 Change settings 20
Access the setup menu 20
Change video settings 20
Change audio settings 21
Set up network 21
Set up EasyLink 21
Change preference settings 22
Change advanced settings 22
English
2 Important 4
Safety 4
Product care 5
Disposal of your old product and batteries 6
3 Your home theater 6
Main unit 6
Remote control 7
4 Connect your home theater 10
Connectors 10
Connect to the TV 10
Connect audio from TV or other devices 11
Connect to a computer network and the
Internet
12
7 Update software 23
Check software version 23
Update software from the network 23
Update software from a USB 23
8 Productspecications 24
9 Troubleshooting 25
10 Index 27
5 Use your home theater 13
Before you start 13
Access the home menu 13
Choose your sound 13
Play a disc 15
Use Bonus View on Blu-ray 15
Access BD-Live on Blu-ray 16
Play from a USB storage device 16
More play features for disc or USB 16
Play from PC (DLNA) 17
Play from radio 18
Play audio from TV or other devices 19
Play from an MP3 player 19
Play from an iPod or iPhone 19
Use Philips EasyLink 19
EN
1
1 Notice
Copyright
This item incorporates copy protection technology
that is protected by U.S. patents and other
intellectual property rights of Rovi Corporation.
Reverse engineering and disassembly are
prohibited.
Compliance
Notice for USA
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to par t 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a
residential installation. This equipment generates,
uses and can radiate radio frequency energy
and, if not installed and used in accordance
with the instruction manual, may cause harmful
interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. Of this
equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off and
on, the user is encouraged to try to correct the
inter ference by one or more of the following
measures:
• Relocate the receiving antenna.
• Increase the separation between equipment
and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/
TV technician for help.
Notice for Canada
Class B Clause
This digital apparatus does not exceed the Class
B limits for radio noise emissions from digital
apparatus as set out in the Radio Interference
Regulations of the Canadian Department of
Communications.
This Class B digital apparatus complies with
Canadian ICES-003.
Open source software
Philips Electronics Singapore Pte Ltd hereby offers
to deliver, upon request, a copy of the complete
corresponding source code for the copyrighted
open source software packages used in this
product for which such offer is requested by the
respective licenses. This offer is valid up to three
years after product purchase to anyone in receipt
of this information. To obtain source code, please
contact open.source@philips.com. If you prefer not
to use email or if you do not receive conrmation
receipt within a week after mailing to this email
address, please write in English to “Open Source
Team, Philips Intellectual Property & Standards, P.O.
Box 220, 5600 AE Eindhoven, The Netherlands”.
If you do not receive timely conrmation of your
letter, please email to the email address above.
The texts of the licenses and acknowledgements
for open source software used in this product are
included on a separate leaet.
About Progressive Scan
Consumers should note that not all high denition
television sets are fully compatible with this
product and may cause artifacts to be displayed in
the picture. In case of 525 or 625 progressive scan
picture problems, it is recommended that the user
switch the connection to the ‘standard denition’
output. If there are questions regarding our TV set
compatibility with this model 525p and 625p DVD
player, please contact our customer service center.
2
EN
Trademarks
BONUSVIEW™
‘BD LIVE’ and ‘BONUSVIEW’ are trademarks of
Blu-ray Disc Association.
Java and all other Java trademarks and logos are
trademarks or registered trademarks of Sun
Microsystems, Inc. in the United States and/or
other countries.
‘AVCHD’ and ‘AVCHD’ logo are trademarks of
Matsushita Electric Industrial Co., Ltd and Sony
Corporation.
‘x.v.Colour’ is a trademar k of Sony Corporation.
DLNA®, the DLNA Logo and DLNA
CERTIFIED
certication marks of the Digital Living Network
Alliance.
®
are trademarks, ser vice marks, or
Manufactured under license under U.S. Patent
#’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762;
6,226,616; 6,487,535; 7,392,195; 7,272, 567;
7,333,929; 7,212,872 & other U.S. and worldwide
patents issued & pending. DTS and the Symbol
are registered trademarks, & DTS-HD, and DTSHD Master Audio | Essential and the DTS logos
are trademarks of DTS, Inc. Product includes
software.
DTS, Inc. All Rights Reserved.
DivX®, DivX Cer tied® and associated logos are
registered trademarks of DivX, Inc. and are used
under license.
DivX Ultra
advanced features and premium content.
ABOUT DIV X VIDEO: DivX
format created by DivX, Inc. This is an ofcial
DivX Certied device that plays DivX video. Visit
www.divx.com for more information and software
tools to conver t your les into DivX video.
ABOUT DIV X VIDEO-ON-DEMAND: This
DivX Cer tied
order to play DivX Video-on-Demand ( VOD)
content. To generate the registration code,
locate the DivX VOD section in your device
setup menu. Go to vod.divx.com with this code
to complete the registration process and learn
more about DivX VOD.
®
Cer tied to play DivX® video with
®
is a digital video
®
device must be registered in
English
Manufactured under licence from Dolby
Laboratories. Dolby, Pro Logic, and the
double-D symbol are trademarks of Dolby
Laboratories.
Windows Media and the Windows logo are
trademarks, or registered trademarks of
Microsoft Corporation in the United States and/
or other countries.
HDMI, and HDMI logo, and High-Denition
Multimedia Interface are trademarks or
registered trademarks of HDMI licensing LLC in
the United States and other countries.
EN
3
CLASS 1
LASER PRODUCT
The USB-IF Logos are trademarks of Universal
Serial Bus Implementers Forum, inc.
Class II equipment symbol
This symbol indicates that the unit has a double
insulation system.
2 Important
Read and understand all instructions before you use
your home theater. If damage is caused by failure to
follow instructions, the warranty does not apply.
Safety
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
• Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (including ampliers) that
produce heat.
• Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than
the other. A grounding type plug has two
blades and a third grounding prong. The
wide blade or the third prong are provided
for your safety. If the provided plug does not
t into your outlet, consult an electrician for
replacement of the obsolete outlet.
• Protect the power cord from being
walked on or pinched, particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
• Only use attachments/accessories specied
by the manufacturer.
4
EN
• Use only with the cart, stand, tripod,
bracket or table specied by the
manufacturer or sold with the apparatus.
When a cart is used, use caution when
moving the car t /apparatus combination to
avoid injury from tip-over.
Know these safety symbols
• Use only with the cart, stand, tripod,
bracket or table specied by the
manufacturer or sold with the apparatus.
When a cart is used, use caution when
moving the car t /apparatus combination to
avoid injury from tip-over.
• Unplug this apparatus during lightning
storm or when unused for long periods of
time.
• Refer all servicing to qualied ser vice
personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does
not operate normally, or has been dropped.
• Battery usage CAUTION - To prevent
battery leakage which may result in bodily
injur y, property damage, or damage to the
unit:
• Install all batteries correctly, + and - as
marked on the unit.
• Do not mix batteries (old and new or
carbon and alkaline, etc.).
• Remove batteries when the unit is not
used for a long time.
• Apparatus shall not be exposed to dripping
or splashing.
• Do not place any sources of danger on the
apparatus (for example. liquid lled objects,
lighted candles).
• This product may contain lead and mercury.
Dispose according to local, State or Federal
laws. For disposal or recycling information,
please contact your local authorities. For
additional assistance on recycling options,
please contact www.mygreenelectronics.
com or www.eiae.org or w ww.recycle.
philips.com.
• Use of controls or adjustments or
performance of procedures other than
herein may result in hazardous radiation
exposure or other unsafe operation.
• Where the MAINS plug or an appliance
coupler is used as the disconnect device,
the disconnect device shall remain readily
operable.
English
This ‘bolt of lightning’ indicates uninsulated material
within your unit may cause an electrical shock. For
the safety of everyone in your household, please
do not remove product covering.
The ‘exclamation point’ calls attention to features
for which you should read the enclosed literature
closely to prevent operating and maintenance
problems.
WARNING: To reduce the risk of re or electric
shock, this apparatus should not be exposed to
rain or moisture and objects lled with liquids, such
as vases, should not be placed on this apparatus.
CAUTION: To prevent electric shock, match wide
blade of plug to wide slot, fully insert.
Product care
• Do not insert any objects other than
discs into the disc compartment.
• Do not insert warped or cracked discs
into the disc compar tment.
• Remove discs from the disc
compar tment if you are not using the
product for an extended period of
time.
• Only use microber cloth to clean the
product.
EN
5
Disposal of your old product and batteries
Your product is designed and manufactured with
high quality materials and components, which can
be recycled and reused.
Never dispose of your product with other
household waste. Please inform yourself about
the local rules on the separate collection of
electrical and electronic products and batteries.
The correct disposal of these products helps
prevent potentially negative consequences on the
environment and human health.
Your product contains batteries, which cannot be
disposed of with normal household waste.
Please inform yourself about the local rules on
separate collection of batteries. The correct
disposal of batteries helps prevent potentially
negative consequences on the environment and
human health.
Please visit www.recycle.philips.com for additional
information on a recycling center in your area.
3 Your home theater
Congratulations on your purchase, and welcome
to Philips! To fully benet from the support that
Philips offers, visit www.philips.com/welcome.
Main unit
a Disc compartment
b (Open/Close)
Opens or closes the disc compar tment.
c (Play/Pause)
Starts, pauses or resumes play.
d (Stop)
• Stops play.
• In radio mode, erases the current
preset radio station.
e (Standby-On)
Switches the home theater on or to
st andby.
f SOURCE
Selects an audio/video source for the home
theater.
g /
• Skips to the previous or next track,
chapter or le.
• In radio mode, selects a preset radio
station.
h Display panel
i Volume control wheel
6
EN
Remote control
2
5
6
7
10
11
12
1
3
4
8
14
13
9
17
18
19
15
16
Note
Your home theater is supplied with one of the
•
following remote controls.
Remote control - A
a (Standby-On)
• Switches the home theater on or to
st andby.
• When EasyLink is enabled, press
and hold for at least three seconds
to switch all connected HDMI CEC
compliant devices to standby.
b (Home)
Accesses the home menu.
c SOUND SETTINGS
Accesses or exits various sound options.
d Navigation buttons
• Navigates menus.
• In radio mode, press lef t or right to
start auto search.
e OK
• Conrms an entry or selection.
f OPTIONS
• Accesses more play options during
playback.
• In radio mode, programs radio stations.
g +/- (Volume)
Increases or decreases volume.
h (Play)
Star ts or resumes play.
i (Pause)
Pauses play.
j / (Fast Backward/Fast Forward)
Fast backwards or fast for wards. Press
repeatedly to change the search speed.
k Alphanumeric buttons
Enters values or letters (using SMS style
entry).
l SUBTITLE
Selects subtitle language for video.
m TOP MENU
Accesses the main menu of a video disc.
n / (Previous/Next)
• Skips to the previous or next track,
chapter or le.
• In radio mode, selects a preset radio
station.
English
EN
7
3
4
6
7
8
9
11
12
13
14
1
2
5
15
5
16
10
18
17
o (Stop) / (Eject / Open/Close)
• Stops play.
• Press and hold to eject the disc or
open the disc compartment.
• In radio mode, erases the current
preset radio station.
p (Mute)
Mutes or restores volume.
q BACK
Returns to a previous menu screen.
r POP-UP MENU/DISC MENU
Accesses or exits the disc menu.
s Source buttons
• Color buttons (for Blu-ray discs):
Selects tasks or options.
• DISC: Switches to disc source.
• RADIO: Switches to FM radio.
• DOCK for iPod: Switches to Philips
Dock for iPod/iPhone.
• SOURCE: Selects an audio input
source.
Remote control - B
8
EN
a (Standby-On)
• Switches the home theater on or to
st andby.
• When EasyLink is enabled, press
and hold for at least three seconds
to switch all connected HDMI CEC
compliant devices to standby.
b (Home)
Accesses the home menu.
c (Disc menu)
Accesses or exits the disc menu.
d Navigation buttons
• Navigates menus.
• In radio mode, press lef t or right to
start auto search.
e / (Previous/Next)
• Skips to the previous or next track,
chapter or le.
• In radio mode, selects a preset radio
station.
f OK
Conrms an entry or selection.
g (Sound options)
Accesses or exits various sound options.
h (Options)
• Accesses more play options during
playback.
• In radio mode, programs radio stations.
i (Play)
Star ts or resumes play.
j +/- (Volume)
Increases or decreases volume.
k (Pause)
Pauses play.
l Source buttons / Color buttons
• Blu-ray discs: Selects tasks or options.
• AUDIO SOURCE: Selects an audio
input source.
• DOCK for iPod: Switches to Philips
Dock for iPod/iPhone.
• RADIO: Switches to FM radio.
• DISC: Switches to disc source.
m Alphanumeric buttons
Enters values or letters (using SMS style
entry).
n TOP MENU
Accesses the main menu of a video disc.
o SUBTITLE
Selects subtitle language for video.
p (Stop)
• Stops play.
• Press and hold to eject the disc or
open the disc compartment.
• In radio mode, erases the current
preset radio station.
q / (Fast Backward/Fast Forward)
Fast backwards or fast for wards. Press
repeatedly to change the search speed.
r (Back)
Returns to a previous menu screen.
English
EN
9
Loading...
