Prezado Consumidor,
PARABÉNS POR TER ADQUIRIDO ESTE
PRODUTO...
E BEM VINDO À FAMÍLIA PHILIPS.
Agradecemos pela sua confiança na Philips e temos a
certeza de que seu Sistema de Home Theater lhe trará
muitos momentos agradáveis, pois ele é um produto
de tecnologia moderna e com muitos recursos. Para
usufruir de todo seu potencial, basta ler atentamente
este manual e seguir as orientações dadas.
Atenciosamente,
Contents
1 Notice 2
Copyright 2
Open source software 2
Trademarks 2
2 Important 3
Safety 3
Product care 4
Health warning 4
Disposal of your old product and batteries 4
6 Change settings 15
Access the setup menu 15
Change video settings 15
Change audio settings 15
Set up network 16
Set up EasyLink 16
Change preference settings 16
Change advanced settings 17
7 Update software 17
Check software version 17
Update software from the network 17
Update software from a USB 18
3 Your home theater 5
Main unit 5
Remote control 5
4 Connect your home theater 7
Connectors 7
Connect to the TV 7
Connect audio from TV or other devices 8
Connect to the internet 8
5 Use your home theater 9
Before you start 9
Access the home menu 9
Choose your sound 10
Play a disc 11
Use Bonus View on Blu-ray 11
Access BD-Live on Blu-ray 11
Play 3D video 12
Play from a USB storage device 12
More play features for disc or USB 12
Play from radio 13
Play audio from TV or other devices 14
Play from an MP3 player 14
Use Philips EasyLink 14
8 Productspecications 18
9 Troubleshooting 20
10 Index 21
English
EN
1
©
1 Notice
Copyright
This item incorporates copy protection technology
that is protected by U.S. patents and other
intellectual property rights of Rovi Corporation.
Reverse engineering and disassembly are
prohibited.
Open source software
Philips Electronics Singapore Pte Ltd hereby offers
to deliver, upon request, a copy of the complete
corresponding source code for the copyrighted
open source software packages used in this
product for which such offer is requested by the
respective licenses. This offer is valid up to three
years after product purchase to anyone in receipt
of this information. To obtain source code, please
contact open.source@philips.com. If you prefer not
to use email or if you do not receive conrmation
receipt within a week after mailing to this email
address, please write to “Open Source Team,
Philips Intellectual Property & Standards, P.O. Box
220, 5600 AE Eindhoven, The Netherlands”. If you
do not receive timely conrmation of your letter,
please email to the email address above. The texts
of the licenses and acknowledgements for open
source software used in this product are included
on a separate leaet.
Trademarks
“Blu-ray 3D” and “Blu-ray 3D” logo are
trademarks of Blu-ray Disc Association.
BONUSVIEW™
‘BD LIVE’ and ‘BONUSVIEW’ are trademarks of
Blu-ray Disc Association.
Java and all other Java trademarks and logos are
trademarks or registered trademarks of Sun
Microsystems, Inc. in the United States and/or
other countries.
‘x.v.Colour’ is a trademark of Sony Corporation.
Manufactured under license from Dolby
Laboratories. Dolby, Pro Logic, and the
double-D symbol are trademarks of Dolby
Laboratories.
Manufactured under license under U.S. Patent
#’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762;
6,226,616; 6,487,535; 7,392,195; 7,272,567;
7,333,929; 7,212,872 & other U.S. and worldwide
patents issued & pending. DTS and the Symbol
are registered trademarks, & DTS-HD, and DTSHD Master Audio | Essential and the DTS logos
are trademarks of DTS, Inc. Product includes
software.
2
EN
DTS, Inc. All Rights Reser ved.
2 Important
®
LASER RADIATION
DO NOT VIEW DIRECTLY
WITH OPTICAL INSTRUMENTS
CLASS 1M LASER PRODUCT
DivX®, DivX Cer tied® and associated logos are
registered trademarks of DivX, Inc. and are used
under license.
DivX Ultra
advanced features and premium content.
ABOUT DIVX VIDEO: DivX
format created by DivX, Inc. This is an ofcial
DivX Cer tied device that plays DivX video.
Visit www.divx.com for more information and
software tools to conver t your les into DivX
video.
ABOUT DIVX VIDEO-ON-DEMAND: This
DivX Cer tied
order to play DivX Video-on-Demand (VOD)
content. To generate the registration code,
locate the DivX VOD section in your device
setup menu. Go to vod.divx.com with this code
to complete the registration process and learn
more about DivX VOD.
Cer tied to play DivX® video with
®
is a digital video
®
device must be registered in
HDMI, and HDMI logo and High-Denition
Multimedia Interface are trademarks or
registered trademarks of HDMI licensing LLC.
Read and understand all instructions before you
use your home theater. If damage is caused by
failure to follow instructions, the warranty does
not apply.
Safety
Riskofelectricshockorre!
• Never expose the product and accessories
to rain or water. Never place liquid
containers, such as vases, near the product.
If liquids are spilt on or into the product,
disconnect it from the power outlet
immediately. Contact Philips Consumer
Care to have the produc t checked before
use.
• Never place the product and accessories
near naked ames or other heat sources,
including direct sunlight.
• Never inser t objects into the ventilation
slots or other openings on the product.
• Where the mains plug or an appliance
coupler is used as the disconnect device,
the disconnect device shall remain readily
operable.
• Disconnect the product from the power
outlet before lightning storms.
• When you disconnect the power cord,
always pull the plug, never the cable.
Riskofshortcircuitorre!
• Before you connect the product to the
power outlet, ensure that the power
voltage matches the value printed on the
back or bottom of the product. Never
connect the product to the power outlet if
the voltage is different.
Riskofinjuryordamagetothehometheater!
• For wall-mountable products, use only the
supplied wall mount bracket. Secure the
wall mount to a wall that can support the
combined weight of the product and the
wall mount. Koninklijke Philips Electronics
N.V. bears no responsibility for improper
wall mounting that results in accident, injury
or damage.
English
EN
3
• For speakers with stands, use only the
supplied stands. Secure the stands to the
speakers tightly. Place the assembled stands
on at, level surfaces that can suppor t the
combined weight of the speaker and stand.
• Never place the product or any objects
on power cords or on other electrical
equipment.
• If the product is transported in
temperatures below 5°C, unpack the
product and wait until its temperature
matches room temperature before
connecting it to the power outlet.
• Visible and invisible laser radiation when
open. Avoid exposure to beam.
• Do not touch the disc optical lens inside the
disc compartment.
Riskofoverheating!
• Never install this product in a conned
space. Always leave a space of at least four
inches around the product for ventilation.
Ensure curtains or other objects never
cover the ventilation slots on the product.
Riskofcontamination!
• Do not mix batteries (old and new or
carbon and alkaline, etc.).
• Remove batteries if they are exhausted or
if the remote control is not to be used for a
long time.
• Batteries contain chemical substances, they
should be disposed of properly.
Product care
• Do not insert any objects other than discs
into the disc compartment.
• Do not insert warped or cracked discs into
the disc compar tment.
• Remove discs from the disc compartment
if you are not using the product for an
extended period of time.
• Only use microber cloth to clean the
product.
To avoid discomfor t such as dizziness, headache
or disorientation, we recommend not watching
3D for ex tended periods of time. If you
experience any discomfort, stop watching 3D
and do not immediately engage in any potentially
hazardous activity (for example driving a car)
until your symptoms have disappeared. If
symptoms persist, do not resume watching 3D
without consulting a medical professional rst.
Parents should monitor their children during 3D
viewing and ensure they do not experience any
discomfort as mentioned above. Watching 3D is
not recommended for children under six years of
age as their visual system is not fully developed yet.
Disposal of your old product
and batteries
Your product is designed and manufactured with
high quality materials and components, which can
be recycled and reused.
When this crossed-out wheeled bin symbol is
attached to a product it means that the product
is covered by the European Directive 2002/96/
EC. Please inform yourself about the local separate
collection system for electrical and electronic
products.
Please act according to your local rules and do not
dispose of your old products with your normal
household waste.
Correct disposal of your old product helps to
prevent potential negative consequences for the
environment and human health.
Health warning
If you or your family has a histor y of epilepsy
or photosensitive seizures, consult a medical
professional before exposing yourself to ashing
light sources, rapid image sequences or 3D
viewing.
4
EN
Your product contains batteries covered by the
European Directive 2006/66/EC, which cannot be
disposed with normal household waste.
Please inform yourself about the local rules on
separate collection of batteries because correct
disposal helps to prevent negative consequences
for the environmental and human health.
1
2
7
3
4
5
6
9
8
10
11
19
20
21
12
13
14
15
16
17
18
3 Your home theater
6
7
98
Congratulations on your purchase, and welcome
to Philips! To fully benet from the support that
Philips offers, register your home theater at
www.philips.com/welcome.
Main unit
a Disc compartment
b (Open/Close)
Opens or closes the disc compar tment.
c (Play/Pause)
Starts, pauses or resumes play.
d (Stop)
• Stops play.
• In radio mode, erases the current
preset radio station.
e (Standby-On)
Switches the home theater on or to
st andby.
f SOURCE
Selects an audio/video source for the home
theater.
g /
• Skips to the previous or nex t track,
chapter or le.
• In radio mode, selects a preset radio
station.
h Display panel
i Volume control wheel
Remote control
English
a (Standby-On)
• Switches the home theater on or to
st andby.
• When EasyLink is enabled, press
and hold for at least three seconds
to switch all connected HDMI CEC
compliant devices to standby.
EN
5
b (Home)
Accesses the home menu.
c TOP MENU
Accesses the main menu of a video disc.
d (Options)
• Accesses more play options during
playback.
• In radio mode, programs radio stations.
e Navigation buttons
• Navigates menus.
• In radio mode, press left or right to
start auto search.
f OK
Conrms an entry or selection.
g / (Previous/Next)
• Skips to the previous or nex t track,
chapter or le.
• In radio mode, selects a preset radio
station.
h (Play)
Star ts or resumes play.
i (Pause)
Pauses play.
j / (Fast Backward / Fast Forward)
Fast backwards or fast forwards. Press
repeatedly to change the search speed.
k (Mute)
Mutes or restores volume.
l AUDIO
In video mode, toggle between audio
languages.
In radio mode, toggle between stereo and
mono.
m Numeric buttons
Selects an item to play.
n SUBTITLE
Selects subtitle language for video.
o Color buttons
Blu-ray discs only: Select a task or option.
p REPE AT
Selects or turns off repeat mode.
q (Sound options)
Accesses or exits various sound options.
r +/- (Volume)
Increases or decreases volume.
s (Stop)
• Stops play.
• Press and hold to eject the disc or
open the disc compartment.
• In radio mode, erases the current
preset radio station.
t (Back)
Returns to a previous menu screen.
u Source buttons
• DISC / POP-UP MENU: Switch to disc
source. Access the disc menu of a DVD
disc or the pop-up menu of a Blu-ray
disc.
• RADIO : Switches to FM radio.
• AUDIO SOURCE : Selects an audio
input source.
6
EN
TV
4 Connect your home
theater
This section helps you connect your home theater
to a TV and other devices. The basic connections of
the home theater with its accessories are provided
in the Quick Start. For a comprehensive interactive
guide, see www.connectivityguide.philips.com.
Note
• Refer to the type plate at the back or bot tom of
the product for identication and supply ratings.
• Before you make or change any connections,
ensure that all devices are disconnected from
the power outlet.
Connectors
Back connectors
Side connectors
a (USB)
Audio, video or picture input from a USB
storage device.
b MP3 LINK
Audio input from an MP3 player.
Connect to the TV
English
Connect your home theater directly to a T V
through one of the following connectors (from
highest to basic quality video):
a HDMI
b Composite video
Option 1: Connect to the TV through
HDMI
a AC MAINS~
Connects to the power supply.
b SPEAKERS
Connects to the supplied speakers and
subwoofer.
c LAN
Connects to the LAN input on a broadband
modem or router.
d HDMI OUT
Connects to the HDMI input on the TV.
e VIDEO OUT
Connects to the composite video input on
the TV.
f FM ANTENNA
Connects the FM antenna for radio reception.
g AUDIO IN
Connects to the analog audio output on the
TV or an analog device.
Note
• If the HDTV has a DVI connector, connect
using an HDMI/DVI adapter.
• If the TV supports EasyLink HDMI CEC,
control the home theater and TV with one
remote control (see ‘Use Philips EasyLink’ on
page 14).
EN
7
Loading...
