Philips HTB5540D/93, HTB5570D/93 Operation Manual

Always there to help you

Question?

Contact

Philips

Register your product and get support at

www.philips.com/support

HTB5510D
HTB5540D
HTB5570D

User manual

Contents

Energy saving settings 27
Speaker settings 27
Restore default settings 28

1 Important 2

Safety 2
3D health warning 3
Care for your product 3
Care of the environment 3

2 Your home theater 4

Main unit 4
Remote control 4
Connectors 5

3 Connect and set up 7

Connect speakers 7
Connect to TV 8
Connect digital devices through HDMI 9
Connect audio from TV and other

devices 10
Set up speakers 11
Set up EasyLink (HDMI-CEC control) 11
Connect and set up a home network 12

4 Use your home theater 14

Access the home menu 14
Discs 14
Play audio through Bluetooth 16

Data les 16

USB storage devices 17
Audio, video, and picture options 18
Radio 19
MP3 player 20
iPod or iPhone 20
Smartphone control 20
Browse PC through DLNA 21
Karaoke 23
Choose sound 24

6 Update software 29

Check software version 29
Update software through USB 29
Update software through the Internet 30

7 Productspecications 31

8 Troubleshooting 35

9 Notice 38

Copyright 38
Open source software 38
RMVB end user agreement 38
Trademarks 39

10 Language code 41

11 Index 42

5 Change settings 26

Language settings 26
Picture and video settings 26
Audio settings 26
Parental control settings 27
Display settings 27

1EN

1 Important

Read and understand all instructions before you
use your product. If damage is caused by failure
to follow instructions, the warranty does not
apply.

Safety

Riskofelectricshockorre!

• Never expose the product and accessories
to rain or water. Never place liquid
containers, such as vases, near the product.
If liquids are spilt on or into the product,
disconnect it from the power outlet
immediately. Contact Philips Consumer
Care to have the product checked before
use.

• Never place the product and accessories

near naked ames or other heat sources,

including direct sunlight.

• Never insert objects into the ventilation
slots or other openings on the product.

• Where the mains plug or an appliance
coupler is used as the disconnect device,
the disconnect device shall remain readily
operable.

• Batteries (battery pack or batteries
installed) shall not be exposed to excessive

heat such as sunshine, re or the like.

• Disconnect the product from the power
outlet before lightning storms.

• When you disconnect the power cord,
always pull the plug, never the cable.

Riskofshortcircuitorre!

• Before you connect the product to the
power outlet, ensure that the power
voltage matches the value printed on the
back or bottom of the product. Never
connect the product to the power outlet if
the voltage is different.

Riskofinjuryordamagetothehometheater!

• For wall-mountable products, use only the
supplied wall mount bracket. Secure the

wall mount to a wall that can support the
combined weight of the product and the
wall mount. Koninklijke Philips Electronics
N.V. bears no responsibility for improper
wall mounting that results in accident,
injury or damage.

• For speakers with stands, use only the
supplied stands. Secure the stands to the
speakers tightly. Place the assembled stands

on at, level surfaces that can support the

combined weight of the speaker and stand.

• Never place the product or any objects
on power cords or on other electrical
equipment.

• If the product is transported in
temperatures below 5°C, unpack the
product and wait until its temperature
matches room temperature before
connecting it to the power outlet.

• Visible and invisible laser radiation when
open. Avoid exposure to beam.

• Do not touch the disc optical lens inside
the disc compartment.

• Parts of this product can be made of
glass. Handle with care to avoid injury and
damage.

Riskofoverheating!

• Never install this product in a conned
space. Always leave a space of at least four
inches around the product for ventilation.
Ensure curtains or other objects never
cover the ventilation slots on the product.

Riskofcontamination!

• Do not mix batteries (old and new or
carbon and alkaine, etc.).

• Danger of explosion if batteries are
incorrectly replaced. Replace only with the
same or equivalent type.

• Remove batteries if they are exhausted or
if the remote control is not to be used for
a long time.

• Batteries contain chemical substances, they
should be disposed of properly.

Riskofswallowingbatteries!

• The product/remote control may contain
a coin/button type battery, which can be
swallowed. Keep the battery out of reach

2 EN

of children at all times! If swallowed, the
battery can cause serious injury or death.
Severe internal burns can occur within two
hours of ingestion.

• If you suspect that a battery has been
swallowed or placed inside any part of the
body, seek immediate medical attention.

• When you change the batteries, always
keep all new and used batteries out of
reach of children. Ensure that the battery
compartment is completely secure after
you replace the battery.

• If the battery compar tment cannot be
completely secured, discontinue use of the
product. Keep out of reach of children and
contact the manufacturer.

This is CLASS II apparatus with double
insulation, and no protective earth provided.

3D health warning

• If you or your family has a history of
epilepsy or photosensitive seizures, consult
a medical professional before exposing

yourself to ashing light sources, rapid

image sequences or 3D viewing.

• To avoid discomfort such as dizziness,
headache or disorientation, we
recommend not watching 3D for extended
periods of time. If you experience any
discomfort, stop watching 3D and do
not immediately engage in any potentially
hazardous activity (for example driving a
car) until your symptoms have disappeared.
If symptoms persist, do not resume
watching 3D without consulting a medical

professional rst.

• Parents should monitor their children
during 3D viewing and ensure they do not
experience any discomfort as mentioned
above. Watching 3D is not recommended

for children under six years of age as their
visual system is not fully developed yet.

Care for your product

• Do not insert any objects other than discs
into the disc compartment.

• Do not insert warped or cracked discs into
the disc compartment.

• Remove discs from the disc compartment
if you are not using the product for an
extended period of time.

• Use only microber cloth to clean the
product.

Care of the environment

Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.
Never dispose of your product with other
household waste. Please inform yourself about
the local rules on the separate collection of
electrical and electronic products and batteries.
The correct disposal of these products helps
prevent potentially negative consequences on
the environment and human health.
Your product contains batteries, which cannot
be disposed of with normal household waste.
Please inform yourself about the local rules on
separate collection of batteries. The correct
disposal of batteries helps prevent potentially
negative consequences on the environment and
human health.
Please visit www.recycle.philips.com for
additional information on a recycling center in
your area.

3EN

2 Your home

a

b

c

d

e

f

g

h

i

j

k

l

m

u

t

s

r

q

p

o

n

Remote control

theater

Congratulations on your purchase, and

welcome to Philips! To fully benet from the
support that Philips offers(e.g. notication

of product software upgrade), register your
product at www.philips.com/welcome.

Main unit

This section includes an overview of the main
unit.

fa b c de

a (Open/Close)

Open or close the disc compartment.

b

(Play/Pause)

Start, pause or resume play.

c

(Stop)

Stop play.

d SOURCE

Select an audio, video, radio source or
Bluetooth mode for the home theater.

e

+/- (Volume)

Increase or decrease volume.

f

(Standby-On)

Switch the home theater on or to standby.

This section includes an overview of the
remote control.

a (Standby-On)

• Switch the home theater on or to

standby.

• When EasyLink is enabled, press

and hold for at least three seconds
to switch all connected HDMI CEC
compliant devices to standby.

b

(Home)

Access the home menu.

4 EN

c Source buttons

• DISC/POP-UP MENU : Switch to disc
source.Access or exit the disc menu
when you play a disc.

• RADIO : Switch to FM radio.

• SOURCE : Select an audio input
source or Bluetooth mode.

d

BACK

• Return to a previous menu screen.

• In radio mode, press and hold to erase
the current preset radio stations.

e Navigation buttons

• Navigate menus.

• In radio mode, press left or right to
start auto search.

• In radio mode, press up or down to
tune the radio frequency.

f OK

Conrm an entry or selection.

g

/ (Previous/Next)

• Skip to the previous or next track,

chapter or le.

• In radio mode, select a preset radio
station.

h

(Stop) / (Eject/Open/Close)

• Stop play.

• Press and hold for three seconds to
open or close the disc compartment,
or eject the disc.

i

/ (Fast Backward / Fast Forward)

Search backwards or forward. Press
repeatedly to change the search speed.

j

+/- (Volume)

Increase or decrease volume.

k SMART TV

This function is not available on this model.

l Alphanumeric buttons

Enter values or letters (using SMS style
entry).

m AUDIO

Select an audio language or channel.

n TOP MENU

Access the main menu of a disc.

o

OPTIONS

• Access more play options while playing
a disc or a USB storage device.

• In radio mode, set a radio station.

p

(Play)

Start or resume play.

q

(Pause)

Pause play.

r

(Mute)

Mute or restore volume.

s

Access or exit sound options.

t SUBTITLE

Select subtitle language for video.

u Color buttons

• Select tasks or options for Blu-ray discs.

• Select iPod/iPhone source.

Connectors

This section includes an overview of the
connectors available on your home theater.

Front connectors

cab d

a MIC 1

Audio input from a microphone.

b MIC 2

Audio input from a microphone.

c AUDIO IN

Audio input from an MP3 player (3.5mm
jack).

iPod/iPhone

5EN

d iPod/iPhone (USB)

• Audio, video or picture input from a
USB storage device.

• Connect to an iPod or iPhone.

• Connect a USB mass storage to access
BD-Live.

Note

When you connect an MP3 player to the home theater

•

with a 3.5mm audio cable, make sure that you connect
the MP3 player to the AUDIO IN connector, not to the
MIC 1 or MIC 2 connector, to ensure normal function
of the home theater.

Rear connectors

h

a AC MAINS

Fixed AC power cable.

b SPEAKERS

Connect to the supplied speakers and
subwoofer.

c Wireless Rear Audio

Connect to a Philips wireless module.
(Model: Philips RWSS5512, optionally
available in your region)

d DIGITAL IN-COAXIAL

Connect to a coaxial audio output on the
TV or a digital device.

e AUDIO IN-AUX

Connect to an analog audio output on the
TV or an analog device.

f HDMI IN1 / HDMI IN2

Connect to the HDMI output on a digital
device.

ijk

g (USB)

Audio, video or picture input from a USB
storage device.

h VIDEO OUT

Connect to the composite video input on
the TV.

i DIGITAL IN-OPTICAL

Connect to an optical audio output on the
TV or a digital device.

j HDMI OUT (ARC)

Connect to the HDMI input on the TV.

k LAN

Connect to the LAN input on a
broadband modem or router.

l FM ANTENNA

Connect to the supplied FM antenna.

l

6 EN

3 Connect and set

up

This section helps you connect your home
theater to a TV and other devices, and then set
it up.
For information about the basic connections
of your home theater and accessories, see the
quick start guide.

SUB

WOOFER

REAR
LEFT

FRONT

LEFT

FRONT

CENTER

FRONT
RIGHT

REAR
RIGHT

Note

For identication and supply ratings, see the type plate

•

at the back or bottom of the product.

• Before you make or change any connections, make sure

that all devices are disconnected from the power outlet.

Connect speakers

The speaker cables are color-coded for easy
connection. To connect a speaker to your home
theater, match the color on the speaker cable to
the color on the connector.

Speaker position plays a critical role in setting
up a surround sound effect. For best effect,
position all the speakers towards the seating
position and place them close to your ear level
(seated).

* The actual speaker shapes may vary from the
illustration above.

Note

Surround sound depends on factors such as room

•

shape and size, type of wall and ceiling, windows and

reective surfaces, and speaker acoustics. Experiment
with the speaker positions to nd the optimum setting

for you.

Follow these general guidelines for speakers
placement.

1 Seating position:

This is the center of your listening area.

2 FRONT CENTER (front center) speaker:

Place the center speaker directly in front of
the seating position, either above or below
your TV.

3 FRONT LEFT (front left) and FRONT

RIGHT (front right) speakers:

Place the left and right speakers in the
front, and at equal distance from the center
speaker. Make sure that the left, right, and
the center speakers are at equal distance
from your seating position.

4 REAR LEFT (rear left) and REAR RIGHT

(rear right) speakers:
Place the rear surround speakers to the
left and right side of your seating position,
either in line with it or slightly behind it.

7EN

5 SUBWOOFER (subwoofer):

Place the subwoofer at least one meter
to the left or right of the TV. Leave about
10-centimeter clearance from the wall.

Make your rear speakers wireless

Connect the rear speakers to your home
theater wirelessly using a wireless module
accessory. For details, see the wireless module
user manual.

What you need

• A Philips wireless module. (Model: Philips
RWSS5512, optionally available in your
region)

1 Connect the wireless transmitter to the

Wireless Rear Audio connector on your

home theater.

2 Connect the rear speakers to the wireless

receiver.

3 Connect the wireless receiver to the

power supply.

Connect to TV

Connect your home theater to a TV to watch
videos. You can listen to the TV audio through
your home theater speakers.

Use the best quality connection available on
your home theater and TV.

Option 1: Connect to TV through
HDMI (ARC)

Best quality video

Your home theater supports HDMI version
with Audio Return Channel (ARC). If your TV
is HDMI ARC compliant, you can hear the TV
audio through your home theater by using a
single HDMI cable.

TV

1 Using a High Speed HDMI cable, connect

the HDMI OUT (ARC) connector on
your home theater to the HDMI ARC
connector on the TV.

• The HDMI ARC connector on the TV
might be labeled differently. For details,
see the TV user manual.

2 On your TV, turn on HDMI-CEC

operations. For details, see the TV user
manual.

• HDMI-CEC is a feature that enables
CEC compliant devices that are
connected through HDMI to be
controlled by a single remote control,
such as volume control for both the
TV and the home theater. (see 'Set
up EasyLink (HDMI-CEC control)' on
page 11)

3 If you cannot hear the TV audio through

your home theater, set up the audio
manually. (see 'Set up the audio' on page

12)

8 EN

Option 2: Connect to TV through
standard HDMI

Best quality video

If your TV is not HDMI ARC compliant, connect
your home theater to the TV through a
standard HDMI connection.

Option 3: Connect to the TV through
composite video

Basic quality video

If your TV does not have HDMI connectors, use
a composite video connection. A composite

connection does not support high-denition

video.

TV

1 Using a High Speed HDMI cable, connect

the HDMI OUT (ARC) connector on your
home theater to the HDMI connector on
the TV.

2 Connect an audio cable to hear the TV

audio through your home theater (see
'Connect audio from TV and other devices'
on page 10).

3 On your TV, turn on HDMI-CEC

operations. For details, see the TV user
manual.

• HDMI-CEC is a feature that enables
CEC compliant devices that are
connected through HDMI to be
controlled by a single remote control,
such as volume control for both the
TV and the home theater. (see 'Set
up EasyLink (HDMI-CEC control)' on
page 11)

4 If you cannot hear the TV audio through

your home theater, set up the audio
manually. (see 'Set up the audio' on page

12)

Note

If your TV has a DVI connector, you can use an HDMI/

•

DVI adapter to connect to TV. However, some of the
features may not be available.

TV

1 Using a composite video cable, connect

the VIDEO OUT connector on your
home theater to the VIDEO IN connector
on the TV.

• The composite video connector might
be labeled AV IN, COMPOSITE, or

BASEBAND.

2 Connect an audio cable to hear the TV

audio through your home theater (see
'Connect audio from TV and other devices'
on page 10).

3 When you watch TV programs, press

SOURCE on your home theater

repeatedly to select the correct audio
input.

4 When you watch videos, switch your TV to

the correct video input. For details, see the
TV user manual.

Connect digital devices through HDMI

Connect a digital device such as a set-top box,
games console, or camcorder to your home
theater through a single HDMI connection.
When you connect the devices in this way and

play a le or game, the

9EN

• video is automatically displayed on your
TV, and

• audio is automatically played on your home
theater.

1 Using a High Speed HDMI cable, connect

the HDMI OUT connector on your digital
device to the HDMI IN 1/2 on your home
theater.

2 Connect your home theater to TV through

HDMI OUT (ARC).

• If the TV is not HDMI CEC compliant,

select the correct video input on your
TV.

3 On the connected device, turn on HDMI-

CEC operations. For details, see the user
manual of the device.

• If you cannot hear the digital device

audio through your home theater, set
up the audio manually. (see 'Set up the
audio' on page 12)

• You can also press SOURCE on your

home theater repeatedly to select the
correct HDMI input.

Option 1: Connect audio through a
digital optical cable

Best quality audio

TV

1 Using an optical cable, connect the

OPTICAL connector on your home

theater to the OPTICAL OUT connector
on the TV or other device.

• The digital optical connector might be
labeled SPDIF or SPDIF OUT.

Option 2: Connect audio through a
digital coaxial cable

Good quality audio

Connect audio from TV and other devices

Play audio from TV or other devices through
your home theater speakers.
Use the best quality connection available on
your TV, home theater, and other devices.

Note

When your home theater and TV are connected

•

through HDMI ARC, an audio connection is not
required (see 'Option 1: Connect to TV through HDMI
(ARC)' on page 8).

10 EN

1 Using a coaxial cable, connect the

COAXIAL connector on your home

theater to the COAXIAL/DIGITAL OUT
connector on the TV or other device.

• The digital coaxial connector might be
labeled DIGITAL AUDIO OUT.

Option 3: Connect audio through
analog audio cables

compliant devices that are connected through
HDMI can be controlled by a single remote
control.

Basic quality audio

1 Using an analog cable, connect the AUX

connectors on your home theater to the
AUDIO OUT connectors on the TV or
other device.

VCR

Set up speakers

Set up the speakers manually to experience
customized surround sound.

Before you start

Make the necessary connections described in
the quick start guide, and then switch the TV to
the correct source for your home theater.

1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Audio] > [Speaker Setup].
4 Enter the distance for each speaker, and

then listen to the test tones and change
the volume. Experiment with the speaker

positions to nd the ideal setting.

Set up EasyLink (HDMI-CEC control)

This home theater supports Philips EasyLink,
which uses the HDMI-CEC (Consumer
Electronics Control) protocol. EasyLink-

Note

Depending on the manufacturer, HDMI-CEC is known

•

by many names. For information on your device, see
the user manual of the device.

• Philips does not guarantee 100% interoperability with

all HDMI-CEC devices.

Before you start

• Connect your home theater to the HDMI­CEC compliant device through HDMI
connection.

• Make the necessary connections described
in the quick start guide, and then switch
the TV to the correct source for your
home theater.

Enable EasyLink

1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [EasyLink] > [EasyLink] > [On] .
4 On your TV and other connected devices,

turn on HDMI-CEC control. For details, see
the user manual of the TV or other devices.

• On your TV, set the audio output to

'Amplier' (instead of TV speakers).

For details, see the TV user manual.

EasyLink controls

With EasyLink, you can control your home
theater, TV, and other connected HDMI-CEC
compliant devices with a single remote control.

• [One Touch Play] (One-touch play): When
a video disc is in the disc compartment,
press

(Play) to wake up the TV from

standby, and then play a disc.

• [One Touch Standby] (One-touch
standby): If one-touch standby is enabled,
your home theater can switch to standby

11EN

with the remote control of the TV or other
HDMI-CEC devices.

• [System Audio Control] (System audio
control): If system audio control is enabled,
the audio of the connected device is
output through your home theater
speakers automatically when you play the
device.

• [Audio Input Mapping] (Audio input
mapping):If system audio control does not
work, map the connected device to the
correct audio input connector on your
home theater. (see 'Set up the audio' on
page 12)

Note

• To change the EasyLink control settings, press

(Home), select [Setup] > [EasyLink].

• If you connect your home theater
to the TV through an HDMI ARC
connection, make sure that the TV
audio is mapped to the ARC input on
your home theater.

Connect and set up a home network

Connect your home theater to a network
router for a network setup, and enjoy:

• Streamed multimedia content (see 'Browse
PC through DLNA' on page 21)

• Smartphone control (see 'Smartphone
control' on page 20)

• BD Live applications (see 'BD-Live on Blu­ray' on page 15)

• Software update (see 'Update software
through the Internet' on page 30)

Set up the audio

If you cannot hear the audio output of a
connected device through your home theater
speakers, do the following:

• Check that you have enabled EasyLink
on all the devices, (see 'Set up EasyLink
(HDMI-CEC control)' on page 11) and

• on your TV, set the audio output to

"Amplier" (instead of TV speakers). For

details, see the TV user manual, and

• setup the EasyLink audio control.

1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [EasyLink] > [System Audio

Control] > [On].

• To play the audio from the TV

speakers, select [Off], and skip the
following steps.

4 Select [EasyLink] > [Audio Input

Mapping].

5 Follow the onscreen instructions to map

the connected device to the audio inputs
on your home theater.

Caution

Familiarize yourself with the network router, media

•

server software and networking principles. If necessary,
read documentation that accompanies the network
components. Philips is not responsible for lost, damaged,
or corrupt data.

Before you start

• For software updates, make sure that the
network router has access to the Internet
with high-speed connection and is not

restricted by rewalls or other security

systems.

• Make the necessary connections described
in the quick start guide, and then switch
the TV to the correct source for your
home theater.

Set up the wired network

What you need

• A network cable (RJ45 straight cable).

• A network router (with DHCP enabled).

12 EN

LAN

www

1 Using a network cable, connect the LAN

connector on your home theater to the
network router.

2 Press (Home).
3 Select [Setup], and then press OK.
4 Select [Network] > [Network

installation] > [Wired (Ethernet)].

5 Follow the onscreen instructions to

complete the setup.

• If connection fails, select [Retry], and
then press OK.

6 Select [Finish], and then press OK to exit.

• To view the network settings, select

[Setup] > [Network] > [View
network settings].

Set up the wireless network

Your home theater has a built-in Wi-Fi for easy
access to a wireless network.

What you need

• A network router (with DHCP enabled).
For best wireless performance, coverage,
and compatibility, use 802.11n router.

www

1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Network] > [Network

installation] > [Wireless (Wi-Fi)], and
then press OK.

4 Follow the onscreen instructions to select

and set up the wireless network.

• If connection fails, select [Retry], and
then press OK.

5 Select [Finish], and then press OK to exit.

• To view the network settings, select

[Setup] > [Network] > [View
wireless settings].

Personalize the network name

Name your home theater to easily identify it on
your home network.

1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Network] > [Name your

Product:].

4 Press the Alphanumeric buttons to enter

the name.

5 Select [Done], and then press OK to exit.

13EN

4 Use your home

3 Press (Home) to exit.

theater

This section helps you use the home theater to
play media from a wide range of sources.

Before you start

• Make the necessary connections described
in the quick start guide and the user
manual.

• Complete the rst-time setup. First-time
setup appears when you turn on your

home theater for the rst time or if you do

not complete the setup.

• Switch the TV to the correct source for
your home theater (for example, HDMI,
AV IN).

Access the home menu

The home menu provides easy access to
connected devices, setup and other useful
features in your home theater.

1 Press (Home).

» The home menu is displayed.

2 Press the Navigation buttons and OK to

select the following:

• [play Disc]: Start disc play.

• [browse USB]: Access the USB

content browser.

• [iPod Music]: Access music les from

iPod or iPhone.

• [browse PC]: Access the computer

content browser.

• [HDMI 1]: Select the digital device

connected to HDMI IN 1 on your
home theater.

• [HDMI 2]: Select the digital device

connected to HDMI IN 2 on your
home theater.

• [Setup]: Access menus to change video,

audio and other settings.

Discs

Your home theater can play DVDs, VCDs, CDs,
and Blu-ray discs. It can also play discs that
you’ve made at home, such as CD-R discs of
photos, videos, and music.

1 Insert a disc into the home theater.
2 If the disc does not play automatically, press

DISC or select [play Disc] from the home

menu.

3 Use the remote control to control play

(see 'Play buttons' on page 14).

• It is normal to hear a little noise when
you play a Blu-ray disc. This does not
mean that your home theater is faulty.

Play buttons

Button Action

Navigation
buttons

OK Conrm an entry or selection.

(Play) Start or resume play.

/ Stop play.

/ Skip to the previous or next track,

/ Search fast backwards or forward.

REPEAT Select or turn off repeat mode.
SUBTITLE Select subtitle language for video.
DISC/

POP-UP
MENU

Navigate menus.
Up/Down: Rotate the picture
clockwise or counter-clockwise.

Pause play.

Press and hold for three seconds
to open or close the disc
compartment.

chapter or le.

When a video is paused, search
slow backwards or forward.

Access or exit the disc menu.

14 EN

Button Action

OPTIONS Access the advanced options

when you play your audio, video,

or media les (see 'Audio, video,

and picture options' on page 18).

Synchronize picture and sound

If the audio and video are not synchronized,
delay the audio to match the video.

1 Press .
2 Press the Navigation buttons (left/right) to

select [Audio sync], and then press OK.

3 Press the Navigation buttons (up/down)

to synchronize the audio with the video.

4 Press OK to conrm.

Play Blu-ray 3D disc

Your home theater can play Blu-ray 3D video.
Read the 3D health warning before playing a
3D disc.

What you need

• A 3D TV

• A pair of 3D glasses that are compatible
with your 3D TV

• A 3D Blu-ray video

• A high speed HDMI cable

1 Using the high speed HDMI cable, connect

your home theater to a 3D compatible TV.

2 Make sure that the 3D video setting is

enabled. Press
[Video] > [Watch 3D video] > [Auto].

• To play 3D discs in 2D mode, select

[Off].

(Home), select [Setup] >

3 Play a Blu-ray 3D disc and put on the 3D

glasses.

• During video search and in certain play

modes, the video is displayed in 2D.
The video display returns to 3D when
you resume play.

Note

To avoid ickering, change the brightness of the display.

•

Bonus View on Blu-ray

On Blu-ray discs that support the Bonus View,
enjoy extra content such as commentaries in a
small screen window. Bonus View is also known
as picture-in-picture.

1 Enable Bonus View in the Blu-ray disc

menu.

2 While you play the movie, press

OPTIONS.

» The options menu is displayed.

3 Select [PIP selection] > [PIP].

• Depending on the video, PIP menu [1]
or [2] is displayed.

• To disable Bonus View, select [Off].

4 Select [2nd audio language] or [2nd

Subtitle Language].

5 Select the language, and then press OK.

BD-Live on Blu-ray

Access additional features on the Blu-ray discs
with BD-Live content, such as internet chats
with the director, the latest movie trailers,
games, wallpaper, and ringtones.
BD-Live services and content var y from disc to
disc.

What you need

• Blu-ray disc with BD-Live content

• a USB storage device, with at least 1 GB of
memory

1 Connect your home theater to a home

network with Internet access (see
'Connect and set up a home network' on
page 12).

2 Connect a USB storage device to the

(USB) connector at the front of your

home theater for BD-Live download.

15EN

3 Press (Home) and select [Setup] >

[Advanced] > [BD-Live security] > [Off].

• To disable BD-Live, select [On].

4 Select the BD-Live icon in the disc menu,

and then press OK.

» BD-Live starts to load. The loading

time depends on the disc and your
internet connection.

5 Press the Navigation buttons to navigate

BD-Live, and then press OK to select an
option.

Note

To clear the memory on the storage device, press

•

(Home), select [Setup] > [Advanced] > [Clear

memory].

3 Wait until BT_READY is displayed on the

display panel.

» When the Bluetooth connection

succeeds, BT_READY is displayed on
the display panel.

» If the connection fails, BT on the

display panel is still displayed.

4 Select and play audio les or music on

your Bluetooth device.

• During play, if a call is coming, music

play is paused.

• If music streaming is interrupted, place

the Bluetooth device closer to the
home theater.

5 To exit Bluetooth, select other source.

• When your switch back to Bluetooth

mode, Bluetooth connection remains
active.

Play audio through Bluetooth

Through Bluetooth, connect the home theater
with your Bluetooth device (such as an iPad,
iPhone, iPod touch, Android phone, or laptop),

and then you can listen to the audio les stored

on the device through your home theater
speakers.

What you need

• A Bluetooth device which supports

Bluetooth prole A2DP, and with Bluetooth

version as 2.1 + EDR.

• The operational range between the
home theater and a Bluetooth device is
approximately 10 meters (30 feet).

1 Press SOURCE repeatedly to select

Bluetooth mode.

» BT is displayed on the display panel.

2 On the Bluetooth device, switch on

Bluetooth, search for and select the name
of your home theater to start connection
(see the user manual of the Bluetooth
device on how to enable Bluetooth).

• If prompted for a password, enter

"0000".

Note

The music streaming may be interrupted by obstacles

•

between the device and home theater, such as wall,
metallic casing that covers the device, or other devices
nearby that operate in the same frequency.

• If you want to connect your home theater with another

Bluetooth device, press and hold
control (or
currently connected Bluetooth device.

• Philips does not guarantee 100% compatibility with all

Bluetooth devices.

on the main unit) to disable the

on the remote

Datales

Your home theater can play pictures, audio and

video les contained in a disc or a USB storage
device. Before you play a le, check that the le

format is supported by your home theater (see
'File formats' on page 31).

1 Play the les from a disc or USB storage

device.

2 To stop play, press .

• To resume the video from where you
stopped, press

(Play).

16 EN

• To play the video from the start, press

OK.

Note

To play DivX DRM protected les, connect your home

•

theater to a TV through an HDMI cable.

Subtitles

If your video has subtitles in multiple languages,
select a subtitle language.

VOD code for DivX

Before you purchase DivX videos and play
them on your home theater, register the home
theater on www.divx.com using the DivX VOD
code.

1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Advanced] > [DivX® VOD Code].

» The DivX VOD registration code for

your home theater is displayed.

Note

Make sure that the subtitle le has the exact same

•

name as the video le. For example, if the video le is
named 'movie.avi', name the subtitle le as 'movie.sr t'

or 'movie.sub'.

• Your home theater supports the following le formats:

.srt, .sub, .txt, .ssa, .ass, smi, and .sami. If the subtitles do
not appear correctly, change the character set.

1 While playing video, press SUBTITLE to

select a language.

2 For DivX or RMVB/RM videos, if the

subtitles do not appear correctly, continue
the following steps to change the character
set.

3 Press OPTIONS.

» The options menu is displayed.

4 Select [Character set], and then select a

character set that supports the subtitle.

Asia Pacic and China

Character Set Language

[Standard] Albanian, Danish, Dutch,

English, Finnish, French, Gaelic,
German, Italian, Kurdish (Latin),
Norwegian, Portuguese,
Spanish, Swedish, Tur kish

[Chinese] Simplied Chinese
[Chinese-

Traditional]
[Korean] English and Korean

Traditional Chinese

USB storage devices

Enjoy pictures, audio, and video stored on a
USB storage device such as an MP4 player or
digital camera.

What you need

• A USB storage device that is formatted for

FAT or NTFS le systems, and complies

with the Mass Storage Class.

• A media le in one of the supported le
formats (see 'File formats' on page 31).

Note

If you use a USB extension cable, USB HUB, or USB

•

multi-reader, the USB storage device may not be
recognized.

1 Connect a USB storage device to the

(USB) connector on your home theater.

2 Press (Home).
3 Select [browse USB], and then press OK.

» A content browser is displayed.

4 Select a le, and then press OK.
5 Press the play buttons to control play (see

'Play buttons' on page 14).

17EN

Audio, video, and picture options

Use advanced features when you play pictures,

audio and video les from a disc or a USB

storage device.

Audio options

While playing audio, repeat an audio track, a
disc, or a folder.

1 Press OPTIONS repeatedly to cycle

through the following functions:

• Repeat the current track or le.

• Repeat all the tracks on the disc or the
folder.

• Turn off the repeat mode.

Video options

While watching video, select options such
as subtitles, audio language, time search, and
picture settings. Depending on the video source,
some options are not available.

1 Press OPTIONS.

» The video options menu is displayed.

2 Press the Navigation buttons and OK to

select and change:

• [Audio language]: Select audio
language for video.

• [Subtitle Language]: Select subtitle
language for video.

• [Subtitle shift]: Change the subtitle
position on the screen.

• [Info]: Display information about what
is playing.

• [Character set]: Select a character set
that supports the DivX subtitle.

• [Time search]: Skip to a specic part
of the video by entering the time of
the scene.

• [2nd audio language]: Select the
second audio language for Blu-ray
video.

• [2nd Subtitle Language]: Select the
second subtitle language for Blu-ray
video.

• [Titles]: Select a specic title.

• [Chapters]: Select a specic chapter.

• [Karaoke]: Change the karaoke
settings.

• [Angle list]: Select a different camera
angle.

• [Menus]: Display the disc menu.

• [PIP selection]: Display Picture-in­Picture window when playing a Blu-ray
disc that supports the Bonus View.

• [Zoom]: Zoom into a video scene or
picture. Press the Navigation buttons
(left/right) to select a zoom factor.

• [Repeat]: Repeat a chapter or title.

• [Repeat A-B]: Mark two points within a
chapter or track to repeat play, or turn
off the repeat mode.

• [Picture settings]: Select a predened
color setting.

Picture options

While viewing a picture, zoom into the picture,
rotate it, add animation to a slideshow, and
change the picture settings.

1 Press OPTIONS.

» The picture options menu appears.

2 Press the Navigation buttons and OK to

select and change the following settings:

• [Info]: Display picture information.

• [Rotate +90]: Rotate the picture 90
degree clockwise.

• [Rotate -90]: Rotate the picture 90
degree counter-clockwise.

• [Zoom]: Zoom into a video scene or
picture. Press the Navigation buttons

(left/right) to select a zoom factor.

• [Duration per slide]: Select the display

speed for each picture in a slide show.

• [Slide animation]: Select animation for

the slide show.

• [Picture settings]: Select a predened

color setting.

18 EN

• [Repeat]: Repeat a selected folder.

Musical slideshow

If the picture and audio les are from the same

disc or USB storage device, you can create a
musical slideshow.

1 Select an audio track, and then press OK.
2 Press BACK, and go to the picture folder.
3 Select a picture, and then press (Play) to

start the slideshow.

4 Press to stop slideshow.
5 Press again to stop music.

Note

Make sure that the picture and audio formats are

•

supported by your home theater (see 'File formats' on
page 31).

Radio

Listen to FM radio on your home theater, and
store up to 40 radio stations.

Note

AM and digital radio are not supported.

•

• If no stereo signal is detected, you are prompted to

install the radio stations again.

INSTALL...PRESS PLAY appears on
the display panel. Press
install radio stations.

(Play) to

3 Use the remote control to listen or to

change radio stations.

Play buttons

Button Action

/

or

Alphanumeric
buttons

Navigation
buttons

BACK Press and hold to erase the

OPTIONS Manual:

SUBTITLE Toggle between the stereo

Select a preset radio station.

Left/Right: Search for a radio
station.
Up/Down: Fine tune a radio
frequency.

Press to stop the installation
of radio stations.

preset radio station.

1) Press OPTIONS. 2) Press
/ to select your preset.

3) Press OPTIONS again to

store the radio station.
Automatic: Press and hold for
three seconds to reinstall the
radio stations.

and mono sounds.

1 Connect the FM antenna to the FM

ANTENNA on your home theater.

• For the best reception, place the
antenna away from your TV or other
sources of radiation.

2 Press RADIO on the remote control to

switch to radio source.

» If you have already installed the radio

stations, the last channel that you
listened to is played.

» If you have not installed any radio

stations, the message AUTO

Tuning grid

In some countries, you can toggle the FM tuning
grid between 50 kHz and 100 kHz.

1 Press RADIO on the remote control to

switch to radio source.

2 Press .
3 Press and hold (Play) to toggle between

50 kHz or 100 kHz.

19EN

MP3 player

Connect a MP3 player to play audio les.

What you need

• An MP3 player.

• A 3.5mm stereo audio cable.

1 Using the 3.5mm stereo audio cable,

connect the MP3 player to the AUDIO-IN
connector on your home theater.

• If you use 6.5mm stereo audio cable,
connect the MP3 player to your
home theater using a 3.5mm - 6.5mm
converter jack.

2 Press SOURCE repeatedly until AUDIO-

IN appears on the display panel.

3 Press the buttons on the MP3 player to

select and play audio les.

iPod or iPhone

Through the home theater, you can play audio

les from your iPod or iPhone.

1 With an iPod/iPhone USB cable, connect

your iPod or iPhone to the iPod/iPhone
(USB) connector at the side panel of your
home theater.

2 Press iPod/iPhone on the home theater

remote control.

• Charge your iPod/iPhone while the
home theater is in iPod/iPhone mode.

3 Browse your iPod or iPhone screen to

select the music.

4 Play the music on your iPod or iPhone.

» The music is heard on your home

theater.

Note

The USB connector at the back of the home theater is

•

500mA and not for Apple devices.

• A device with more than 500mA cannot be charged via

the USB connector at the back of the home theater.

Smartphone control

Use your mobile device such as iPhone (iOS

3.1.3 and above), Android phone (2.1 and
above), iPad, or tablet to:

• Control your home theater

• Browse a data disc or USB storage device

• Stream and share content from the devices
on your home network

Before you start

• Connect your home theater, mobile device,
and other DLNA-compatible devices to
the same home network.

• For better video quality, use wired

connection whenever possible.

• Personalize the network name for your
home theater (see 'Personalize the
network name' on page 13).

• Download Philips MyRemote application
on your mobile device.

• For iPhone or iPad, search for the app

in App Store (App Store).

• For Android based phone or tablet,

search for the app in Market (Market).

Control your home theater

1 On the mobile device, access MyRemote

application.

2 Select your home theater (by its network

name) from the home screen.

» A browsing bar is displayed at the

bottom of the screen.

• If your home theater is not found,

check the network connection or tap
the Devices tab on your mobile device
to search again.

20 EN

3 Select one of the following tabs to access

more options.

• To return to the previous screen, press
back button.

Option Action

App
Home

Media DISC: Browse and play a le stored

Remote Access the remote control on your

Return to the home screen of your
device.

on a data disc.

USB: Browse and play a le stored

on a USB storage device.

mobile device. Swipe the screen
to the left or right to access more
buttons. Only the relevant buttons
are enabled on your mobile device.
Some functions such as switch-on
from standby and long press, are not
available on the mobile device.

4 Follow the onscreen instructions to select

an option or complete the set up.

automatically detected and displayed
on the screen.

3 Select a device on the network.

» The folders in the selected device are

displayed. Depending on the media
server, the folder names may vary.

• If you cannot see the folders, make
sure that you enable media sharing on
the selected device so that the content
is available for sharing.

4 Select a media le to play.
5 From the menu on your mobile device,

select the home theater to stream the

media le to your home theater.

• Some media les may not display
or play due to compatibility issues.
For your home theater, check the

supported le formats.

6 Use your mobile device to control play.

Browse PC through DLNA

Stream multimedia content
(SimplyShare)

Philips SimplyShare allows you to use your
smartphone to stream multimedia content

(such as pictures, audio and video les), and play

through your home theater or any DLNA­compatible device in the same home network.

Before you start

• Install a DLNA-compliant media server
application on your mobile device, such as
Twonky Media Server.

• Enable media sharing of les. For details,
check the user manual of the media server
software software.

1 On the mobile device, launch the media

server application. For iPhone or Android
phone, access MyRemote application.

2 From the menu of your mobile device,

select SimplyShare.

» Your home theater and other

devices on the home network are

Access and play the pictures, audio and video

les from a computer or media server on the

home network through your home theater.

Before you start

• Install a DLNA-compliant media server
application on your device. Make sure that
you download an application that works
best for you. For example,

• Windows Media Player 11 or higher

for PC

• Twonky Media Server for Mac or PC

• Enable media sharing of les. For ease of
use, we have included the steps for the
following applications:

• Windows Media Player 11 (see

'Microsoft Windows Media Player 11'
on page 22)

• Windows Media Player 12 (see

'Microsoft Windows Media Player 12'
on page 22)

21EN

• Twonky Media for Mac (see 'Macintosh
OS X Twonky Media (v4.4.2)' on page

23)

Note

For additional help on these applications or other

•

media servers, check the user manual of the media
server software software.

Set up media server software

To enable media sharing, set up the media
server software.

Before you start

• Connect your home theater to a home
network. For better video quality, use wired
connection whenever possible.

• Connect the computer and other DLNA­compatible devices to the same home
network.

• Make sure that your PC rewall allows
you to run Media Player programs (or

the rewall’s exemption list has the media

server software included).

• Switch on your computer and the router.

Microsoft Windows Media Player 11

1 Star t Windows Media Player on your PC.
2 Click the Library tab, and then select

Media Sharing.

3 The rst time you select Media Sharing on

your PC,a pop-up screen appears. Check
the Share my media box and click OK.

» The Media Sharing screen is displayed.

4 In the Media Sharing screen, make sure

that you see a device marked as Unknown
Device.

» If you don't see an unknown device

after a minute or so, check that

your PC rewall is not blocking the

connection.

5 Select the unknown device and click Allow.

» A green tick appears next to the

device.

6 By default, Windows Media Player shares

from these folders: My Music, My Pictures,
and My Videos. If your les are in other
folders, select Library > Add to Library.

» The Add to Library screen is displayed.

• If necessary, select Advanced options
to display a list of monitored folders.

7 Select My folders and those of others I

can access, and then click Add.

8 Follow the onscreen instructions to add

the other folders that contain your media

les.

Microsoft Windows Media Player 12

1 Star t Windows Media Player on your PC.
2 In Windows Media Player, click the Stream

tab, and then select Turn on media
streaming.

» The Media streaming options screen

is displayed.

3 Click Turn on media streaming.

» You return to Windows Media Player

screen.

4 Click the Stream tab and select More

streaming options.

» The Media streaming options screen

is displayed.

5 Make sure that you see a media program

in the Local network screen.

» If you don't see a media program,

check that your PC rewall is not

blocking the connection.

6 Select the media program and click

Allowed.

» A green arrow appears next to the

media program.

7 By default, Windows Media Player shares

from these folders: My Music, My Pictures,
and My Videos. If your les are in other
folders, click the Organize tab and select
Manage libraries > Music.

» The Music Library Locations screen is

displayed.

22 EN

8 Follow the onscreen instructions to add

the other folders that contain your media

les.

Macintosh OS X Twonky Media (v4.4.2)

1 Visit www.twonkymedia.com to purchase

the software, or download a free 30-day
trial to your Macintosh.

2 Star t Twonky Media on the Macintosh.
3 In the Twonky Media Server screen, select

Basic Setup and First Steps.

» The First steps screen is displayed.

4 Type a name for your media server, and

then click Save changes.

5 Back in the Twonky Media screen, select

Basic Setup and Sharing.

» The Sharing screen is displayed.

6 Browse and select folders to share, and

then select Save Changes.

» Your Macintosh rescans the folders

automatically so that they are ready to
share.

• Some media les may not play due

to compatibility issues. Check the le

formats supported by your home
theater.

5 Press the play buttons to control play (see

'Play buttons' on page 14).

Karaoke

Play a Karaoke disc on your home theater and
sing along with the music.

What you need

• A Karaoke microphone.

• Karaoke discs.

Note

To prevent loud feedback or unexpected noise, turn

•

the microphone volume to the minimum before you
connect the microphone to your home theater.

PlaylesfromyourPC

Note

Before you play multimedia content from the computer,

•

make sure that the home theater is connected to
the home network, and the media server software is
properly set up.

1 Press (Home).
2 Select [browse PC], and then press OK.

» A content browser is displayed.

3 Select a device on the network.

» The folders in the selected device are

displayed. Depending on the media
server, the folder names may vary.

• If you cannot see the folders, check
that you have enabled media sharing
on the selected device so that the
content is available for sharing.

4 Select a le, and then press OK.

Play karaoke music

1 While playing a karaoke disc, press

OPTIONS.

» The options menu is displayed.

2 Press the Navigation buttons to select

[Karaoke], and then press OK.

» The karaoke setup menu is displayed.

3 Press the Navigation buttons (up/down)

and OK to change the following settings:

• [Microphone]: Turn the microphone
on or off.

• [Microphone volume]: Change the
microphone volume.

• [Echo]: Change the echo level.

• [Key]: Change the pitch to match your
voice.

• [Vocal support]: Select an audio mode,
or turn the vocal on or off.

23EN

Choose sound

This section helps you choose the ideal sound
for your video or music.

1 Press .
2 Press the Navigation buttons (left/right) to

access the sound options on the display.

Sound
options

[Surround] Select surround sound or stereo

[Sound] Select a sound mode.
[Audio

sync]
[Auto

volume]

Description

sound.

Delay the audio to match the
video.

Reduce sudden changes in
volume, for example, during TV
commercials.

3 Select an option, and then press OK.
4 Press BACK to exit.

• If you do not press a button within a
minute, the menu exits automatically.

Surround sound mode

Experience an immersive audio experience with
surround sound modes.

1 Press .
2 Select [Surround], and then press OK.
3 Press the Navigation buttons (up/down)

to select a setting from your display:

• [Auto]: Surround sound based on the
audio stream.

• [Multi-channel]: Traditional 5.1
channel for a more relaxing cinematic
experience.

• [5-channel stereo]: Enhanced stereo
sound. Ideal for party music.

• [Stereo]: 2-channel stereo sound. Ideal
for listening to music.

4 Press OK to conrm.

Sound mode

Select predened sound modes to suit your

video or music.

1 Make sure that audio post processing is

enabled at the speakers (see 'Speaker
settings' on page 27).

2 Press .
3 Select [Sound], and then press OK.
4 Press the Navigation buttons (up/down)

to select a setting on the display:

• [Auto]: Automatically select a sound
setting based on the sound stream.

• [Balanced]: Experience the original
sound of your movies and music,
without added sound effects.

• [Powerful]: Enjoy thrilling arcade
sounds, ideal for action-packed videos
and loud parties.

• [Bright]: Spice up your dull movies and
music with added sound effects.

• [Clear]: Hear every detail in your
music and clear voices in your movies.

• [Warm]: Experience spoken words
and music vocals in comfort.

• [Personal]: Personalize the sound
based on your preferences.

5 Press OK to conrm.

Equalizer

Change the high frequency (treble), mid
frequency (mid), and low frequency (bass)
settings of the home theater.

1 Press .
2 Select [Sound] > [Personal], and then

press Navigation buttons (right).

3 Press the Navigation buttons (up/down)

to change bass, mid or treble frequency.

4 Press OK to conrm.

24 EN

Auto volume

Turn on auto volume to reduce sudden changes
in volume, for example, during TV commercials.

1 Press .
2 Select [Auto volume], and then press OK.
3 Press the Navigation buttons (up/down)

to select [On] or [Off].

4 Press OK to conrm.

25EN

5 Change settings

The home theater settings are already

congured for optimal performance. Unless

you have a reason to change a setting, we
recommend that you keep the default setting.

Note

You cannot change a setting that is grayed out.

•

• To return to the previous menu, press BACK. To

exit the menu, press

Language settings

1

Press (Home).

2 Select [Setup], and then press OK.
3 Select [Preference], and then press OK.
4 Press the Navigation buttons and OK to

select and change:

• [Menu language]: Select a display
language for menu.

• [Audio]: Select an audio language for
discs.

• [Subtitle]: Select a subtitle language
for discs.

• [Disc menu]: Select a menu language
for discs.

Note

If your preferred disc language is not available, select

•

[Others] from the list, and enter the 4-digit language
code found at the end of this user manual (see
'Language code' on page 41).

• If you select a language that is not available on a disc,

the home theater uses the default language of the disc.

(Home).

Picture and video settings

1

Press (Home).

2 Select [Setup], and then press OK.
3 Select [Video], and then press OK.
4 Press the Navigation buttons and OK to

select and change:

• [Tv type]: If the video does not appear
correctly, select a TV type (color
system).

• [TV display]: Select a picture format to

t the TV screen.

• [HDMI video]: Select the resolution of
video signal that is output from HDMI
OUT (ARC) on your home theater.
To enjoy the selected resolution,
make sure that your TV suppor ts the
selected resolution.

• [HDMI Deep Color]: Recreate the
natural world on your TV screen by
displaying vivid images using billion
colors. Your home theater must be
connected to a Deep Color enabled
TV through an HDMI cable.

• [Picture settings]: Select pre dened
color settings for the video display.

• [Watch 3D video]: Set HDMI video to
support 3D or 2D video.

Note

If you change a setting, make sure that the TV supports

•

the new setting.

Audio settings

1

Press (Home).

2 Select [Setup], and then press OK.
3 Select [Audio], and then press OK.
4 Press the Navigation buttons and OK to

select and change:

26 EN

• [Night mode]: For quiet listening,
decrease the volume of loud sounds
on your home theater. Night mode
is only available in DVDs and Blu-ray
discs with Dolby Digital, Dolby Digital
Plus, and Dolby True HD soundtracks.

• [HDMI Audio]: Set the HDMI audio
output from your TV, or disable HDMI
audio output from the TV.

• [Speaker Setup]: Set up speakers for
best surround sound experience.

• [Default sound settings]: Restore
the equalizer settings of all the sound
modes to the default values.

Parental control settings

1

Press (Home).

2 Select [Setup], and then press OK.
3 Select [Preference], and then press OK.
4 Press the Navigation buttons and OK to

select and change:

• [Change Password]: Set or change
your password for parental control
access. If you do not have a password
or have forgotten your password, enter

0000.

• [Parental control]: Restrict access
to discs that are recorded with age
ratings. To play all discs, irrespective of
the ratings, select 8 or [Off].

Display settings

1

Press (Home).

2 Select [Setup], and then press OK.
3 Select [Preference], and then press OK.
4 Press the Navigation buttons and OK to

select and change:

• [Auto subtitle shift]: Enable or disable
automatic repositioning of subtitles on
TVs that support this feature.

• [Display panel]: Set the brightness of
the home theater front panel display.

• [VCD PBC]: Enable or disable the
content menu navigation of VCD and
SVCD discs with Play Back Control
feature.

Energy saving settings

1

Press (Home).

2 Select [Setup], and then press OK.
3 Select [Preference], and then press OK.
4 Press the Navigation buttons and OK to

select and change:

• [Screen saver]: Switch the home
theater to screen saver mode after 10
minutes of inactivity.

• [Auto standby]: Switch the home
theater to standby after 30 minutes of
inactivity. This timer works only when a
disc or USB play is paused or stopped.

• [Sleep timer]: Set the duration of the
sleep timer so that the home theater is

switched to standby after the specied

period.

Speaker settings

1

Press (Home).

2 Select [Setup], and then press OK.
3 Select [Advanced], and then press OK.
4 Press the Navigation buttons and OK to

select and change:

• [Enhanced audio]: Select [On] to
enable audio post processing at the
speaker and enable karaoke settings
(if your product supports Karaoke).
To play the original audio of the disc,
select [Off].

27EN

Tip

Enable audio post processing before you select a

•

predened sound mode (see 'Sound mode' on page

24).

Restore default settings

1

Press (Home).

2 Select [Setup], and then press OK.
3 Select [Advanced] > [Restore default

settings], and then press OK.

4 Select [OK], and then press OK to

conrm.

» Your home theater is reset to its

default settings except for some
settings such as parental control and
DivX VOD registration code.

28 EN

6 Update software

Philips continually tries to improve its products.
To get the best features and support, update
your home theater with the latest software.

Compare the version of your current software
with the latest version on www.philips.com/
support. If the current version is lower than the
latest version available on the Philips support
website, upgrade your home theater with the
latest software.

Caution

Do not install a lower version of software than the

•

current version installed on your product. Philips is not
liable for problems caused due to software downgrade.

Step 1: Download the latest software

1 Connect a USB ash drive to your

computer.

2 In your web browser, go to www.philips.

com/support.

3 At the Philips Suppor t website, nd your

product and locate the Software and
drivers.

» The software update is available as a

zip le.

4 Save the zip le in the root directory of

your USB ash drive.

5 Use the archive utility to extract the

software update le in the root directory.

» The les are extracted under the

UPG_ALL folder of your USB ash

drive.

6 Disconnect the USB ash drive from your

computer.

Check software version

Check the version of the current software
installed on your home theater.

1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Advanced] > [Version

information].

» The software version is displayed.

Update software through USB

What you need

• A USB ash drive that is FAT or NTFS-
formatted, with at least 256MB of memory.
Do not use a USB hard drive.

• A computer with Internet access.

• An archive utility that supports the ZIP le
format.

Step 2: Update the software

Caution

Do not switch off the home theater or remove the

•

USB ash drive during the update.

1 Connect the USB ash drive containing the

downloaded le to your home theater.

• Make sure that the disc compartment
is closed and no disc inside.

2 Press (Home).
3 Select [Setup], and then press OK.
4 Select [Advanced] > [Software update]

> [USB].

5 Follow the onscreen instructions to

conrm the update.

» Update process takes about 5 minutes

to complete.

29EN

Update software through the Internet

1 Connect your home theater to a home

network with a high-speed Internet access
(see 'Connect and set up a home network'
on page 12).

2 Press (Home).
3 Select [Setup], and then press OK.
4 Select [Advanced] > [Software update] >

[Network].

» If an upgrade media is detected, you

are prompted to start or cancel the
update.

» Downloading of the upgrading le may

take long, depending on your home
network condition.

5 Follow the onscreen instructions to

conrm the update.

» Update process takes about 5 minutes

to complete.

» Once complete, the home theater

automatically switches off and restarts.
If it does not, disconnect the power
cord for a few seconds and then
reconnect it.

30 EN

7 Product

specifications

Note

Specications and design are subject to change without

•

notice.

Region codes

The type plate on the back or bottom of the
home theater shows which regions it supports.

Country

Europe,
United Kingdom

Asia Pacific, Taiwan,

Korea

New Zealand

DVD BD

AA

Latin America

AA

Australia,

Russia, India

CC

China

CC

Media formats

• AVCHD, BD, BD-R/ BD-RE, BD-Video,
DVD-Video, DVD+R/+RW, DVD-R/-RW,
DVD+R/-R DL, CD-R/CD-RW, Audio CD,

Video CD/SVCD, Picture les, MP3 media,

WMA media, DivX Plus HD media, USB
storage device

File formats

• Audio:

• .aac, .mka, .mp3, .wma, .wav, .mp4, .m4a,

.ac, .ogg

• .ra (Available only in Asia Pacic and
China)

• Video:

• .avi, .divx, .mp4, .m4v, .mkv, .asf, .wmv,

.m2ts, .mpg, .mpeg, .v, .3gp

• .rmvb, .rm, .rv (Available only in Asia

Pacic and China)

• Picture: .jpg, .jpeg, .jpe, .gif, .png

Bluetooth

• Bluetooth proles: A2DP

• Bluetooth version: 2.1 + EDR

Audio formats

Your home theater supports the following

audio les.

(.ralesaresupportedonlyinAsiaPacicand

China)

Extension Container Audio

codec

.mp3 MP3 MP3 Upto 320

.wma ASF WMA Upto 192

.aac AAC AAC ,

HE­AAC

.wav WAV PCM 27.648

.m4a MKV AAC 192 kbps
.mka MKA PCM 27.648

Dolby
Digital

DTS
core

MPEG 912 kbps

Bit rate

kbps

kbps
Upto 192

kbps

Mbps

Mbps
640 kbps

1.54 Mbps

31EN

MP3 Upto 320

kbps

WMA Upto 192

kbps

AAC ,
HE-

Upto 192
kbps

AAC

.ra RM AAC ,

HE-

Upto 192
kbps

AAC
Cook 96469 bps

.ac FLAC FLAC Upto 24

bps

.ogg OGG Vorbis Variable

bit rate,
maximum
block size
4096

MP3 Upto 320

kbps

Video formats

If you have a high denition TV, your home
theater allows you to play your video les with:

• Resolution: 1920 x 1080 pixels at

• Frame rate: 6 ~ 30 frames per second.

.avilesinAVIcontainer

Audio
codec

PCM,
Dolby
Digital,
DTS core,
MP3,
WMA

Video codec Bit rate

DivX 3.11, DivX 4.x,
DivX 5.x, DivX 6.x

10 Mbps
max

MPEG 1, MPEG 2 40 Mbps
MPEG 4 SP / ASP 38.4

Mbps

H.264/AVC upto

25 Mbps

HiP@4.2
WMV9 45 Mbps

.divxlesinAVIcontainer

Audio codec Video codec Bit rate

PCM, Dolby
Digital, MP3,
WMA

DivX 3.11,
DivX 4.x, DivX 5.x,
DivX 6.x

10
Mbps
max

.mp4or.m4vlesinMP4container

Audio codec Video codec Bit rate

Dolby Digital,
MPEG, MP3,

MPEG 1,
MPEG 2

40 Mbps

AAC, HE-AAC,
DD+

MPEG 4 ASP 38.4

Mbps

H.264/AVC

25 Mbps

HiP@4.2

.mkvlesinMKVcontainer

Audio codec Video codec Bit rate

PCM, Dolby

DivX Plus HD 30 Mbps
Digital, DTS core,
MPEG, MP3,
WMA, AAC, HE­AAC, DD+

MPEG 1,

40 Mbps

MPEG 2

MPEG 4 ASP 38.4

Mbps

H.264/AVC

25 Mbps

HiP@4.2

WMV9 45 Mbps

.m2tslesinMKVcontainer

Audio codec Video codec Bit rate

PCM, Dolby Digital,
DTS core, MPEG,

MPEG 1,
MPEG 2

40 Mbps

MP3, WMA, AAC,
HE-AAC, DD+

MPEG 4 ASP 38.4

Mbps

H.264/AVC

25 Mbps

HiP@4.2
WMV9 45 Mbps

32 EN

.asfand.wmvlesinASFcontainer

Audio codec Video codec Bit rate

Dolby Digital,
MP3, WMA,
DD+

MPEG 4 ASP 38.4 Mbps

H.264/AVC
HiP@4.2

WMV9 45 Mbps

25 Mbps

• Input sensitivity:

• AUX: 2 V

• AUDIO IN: 1 V

Video

• Signal system: PAL / NTSC

• HDMI output: 480i/576i, 480p/576p, 720p,

1080i, 1080p, 1080p24

.mpgand.mpeglesinPScontainer

Audio codec Video codec Bit rate

PCM, DTS core,
MPEG, MP3

.vlesinFLVcontainer

Audio
codec

MP3,
AAC

.3gplesin3GPcontainer

Audio
codec

AAC, HE­AAC

.rm,.rv,and.rmvblesinRMcontainer
(AvailableonlyinAsiaPacicandChina)

Audio codec Video codec Bit rate

AAC, COOK RV30, RV40 40 Mbps

Video codec Bit rate

H.264/AVC upto
HiP@4.2

H.263 38.4 Mbps

Video codec Bit rate

MPEG 4 ASP 38.4 Mbps

H.264/AVC upto
HiP@4.2

MPEG 1,
MPEG 2

40
Mbps

25 Mbps

25 Mbps
max

Amplier

• Total output power: 1000W RMS (30%
THD)

• Frequency response: 20 Hz-20 kHz / ±3
dB

• Signal-to-noise ratio: > 65 dB (CCIR) /
(A-weighted)

Audio

• S/PDIF Digital audio input:

• Coaxial: IEC 60958-3

• Optical: TOSLINK

• Sampling frequency:

• MP3: 32 kHz, 44.1 kHz, 48 kHz

• WMA: 44.1 kHz, 48 kHz

• Constant bit rate:

• MP3: 32 kbps - 320 kbps

• WMA: 48 kbps - 192 kbps

Radio

• Tuning range:

• Europe/Russia/China: FM 87.5-108
MHz (50 kHz)

• Asia Pacic/Latin America: FM 87.5-108
MHz (50/100 kHz)

• Signal-to-noise ratio: FM 50 dB

• Frequency response: FM 180 Hz-12.5 kHz
/ ±3 dB

USB

• Compatibility: Hi-Speed USB (2.0)

• Class support: USB Mass Storage Class
(MSC)

• File system: FAT16, FAT32, NTFS

• USB connector:

• Front panel: 5V

• Rear panel: 5V

, 1A

, 500mA

Main unit

• Power supply:

• Europe/China: 220-240 V~, 50 Hz

33EN

• Latin America/Asia Pacic: 110-127
V/220-240 V~, 50-60 Hz

• Russia/India: 220-240 V~, 50 Hz

• Power consumption: 160 W

• Standby power consumption: ≤ 0.5 W

• Dimensions (WxHxD):
435 x 58 x 280 mm

• Weight: 2.66 kg

Subwoofer

• Output power: 166 W RMS (30% THD)

• Impedance: 4 ohm

• Speaker drivers: 203 mm (8") woofer

• Dimensions (WxHxD): 233 x 365 x 310
mm

• Weight: 4.81 kg

• Cable length: 3 m

Speakers

Center speaker:

• Output power: 166 W RMS (30% THD)

• Speaker impedance: 4 ohm

• Speaker drivers: 1 x 78 mm (3") full range

• Dimensions (WxHxD): 314 x 111 x 83
mm

• Weight: 1 kg

• Cable length: 2 m

Front/Rear speaker:

• Output power: 4 x 166 W RMS (30%
THD)

• Speaker impedance: 4 ohm

• Speaker drivers: 1 x 78 mm (3") full range

• Dimensions (WxHxD):

• HTB5510D: 100 x 228 x 130 mm

(front); 100 x 191 x 125 (rear)

• HTB5540D: 250 x 1179 x 250 mm

(front); 100 x 191 x 125 mm (rear)

• HTB5570D: 250 x 1179 x 250 mm

(front/rear)

• Weight:

• HTB5510D: 0.63 kg/each (front); 0.60

kg/each (rear)

• HTB5540D: 3.6 kg/each (front); 0.61

kg/each (rear)

• HTB5570D: 3.6 kg/each (front); 3.6 kg/
each (rear)

• Cable length:

• HTB5510D: 3 m (front); 10 m (rear)

• HTB5540D: 4 m (front); 10 m (rear)

• HTB5570D: 4 m (front); 11 m (rear)

Remote control batteries

• 2 x AAA-R03-1.5 V

Laser

• Laser Type (Diode): InGaN/AIGaN (BD),
AIGaInP (DVD/CD)

• Wave length: 405 +7 nm/-7 nm (BD), 655
+10 nm/-10 nm (DVD), 790 +10 nm/-20
nm (CD)

• Output power (Max. ratings): 20 mW
(BD), 6 mW (DVD), 7 mW (CD)

34 EN

8 Troubleshooting

Warning

•

Risk of electric shock. Never remove the casing of the
product.

To keep the warranty valid, never try to repair
the product yourself.
If you have problems using this product, check
the following points before you request service.
If you still have a problem, get support at www.
philips.com/support.

Main unit

The buttons on the home theater do not
work.

• Disconnect the home theater from the
power supply for a few minutes, then
reconnect.

• Make sure that the touch buttons surface
is not in contact with any conductive
material, like water drop, metal, etc.


No picture.

• Make sure that the TV is switched to the
correct source for the home theater.

No picture on a TV connected through HDMI.

• Make sure that you use a High Speed
HDMI cable to connect the home theater
and TV. Some Standard HDMI cables do
not display properly for some images, 3D
video, or Deep Color.

• Make sure that the HDMI cable is not
faulty. If it is faulty, replace it with a new
cable.

• Press

(Home) and then 731 on the
remote control to restore the default
picture resolution.

• Change the HDMI video setting, or wait
for 10 seconds for auto recovery (see
'Picture and video settings' on page 26).

Discdoesnotplayhigh-denitionvideo.

• Make sure that the disc contains high-

denition video.

• Make sure that the TV supports high-

denition video.

• Use an HDMI cable to connect to the TV.

Sound

No sound from home theater speakers.

• Connect the audio cable from your home
theater to your TV or other devices.
However, you do not need a separate
audio connection when:

• the home theater and TV are

connected through an HDMI ARC
connection, or

• a device is connected to the HDMI IN

connector on your home theater.

• Set up the audio for the connected device
(see 'Set up the audio' on page 12).

• Reset your home theater to its factory
settings (see 'Restore default settings' on
page 28), and then switch it off and switch
on again.

• On your home theater, press SOURCE
repeatedly to select the correct audio
input.

Distorted sound or echo.

• If you play audio from the TV through the
home theater, make sure that the TV is
muted.

Audio and video are not synchronized.

• 1) Press

buttons (left/right) to select [Audio
sync], and then press OK. 3) Press

the Navigation buttons (up/down) to
synchronize the audio with the video.

. 2) Press the Navigation

35EN

Play

Cannot play a disc.

• Clean the disc.

• Make sure that the home theater supports
the type of disc (see 'Media formats' on
page 31).

• Make sure that the home theater supports
the region code of the disc (see 'Region
codes' on page 31).

• If the disc is a DVD±RW or DVD±R disc,

make sure that it is nalized.

CannotplayaDivXle.

• Make sure that the DivX le is encoded
according to the 'Home Theater Prole'

with the DivX encoder.

• Make sure that the DivX le is complete.

DivX or RMVB/RM subtitles do not display
correctly.

• Make sure that the subtitle le name is
the same as the movie le name (see

'Subtitles' on page 17).

• Select the correct character set: 1) Press
OPTIONS. 2) Select [Character set]. 3)
Select the supported character set. 4)
Press OK.

Cannot read the contents of a USB storage
device.

• Make sure that the format of the USB
storage device is compatible with the
home theater.

• Make sure that the le system on the USB
storage device is supported by the home
theater.

'No entry' or 'x' sign appears on the TV.

• The operation is not possible.

EasyLink does not work.

• Make sure that the home theater is
connected to a Philips brand EasyLink TV,
and the EasyLink option is turned on (see
'Set up EasyLink (HDMI-CEC control)' on
page 11).

• For TVs from different manufacturers, the
HDMI CEC could be called differently.

Check theTV user manual on how to
enable it.

When you switch on the TV, the home theater
automatically switches on.

• This behavior is normal when you are using
Philips EasyLink (HDMI-CEC). To make the
home theater work independently, switch
off EasyLink.

Cannot access BD-Live features.

• Make sure that the home theater is
connected to the network. Use a wired
network connection (see 'Set up the wired
network' on page 12), or wireless network
connection (see 'Set up the wireless
network' on page 13).

• Make sure that the network is set up.
Use a wired network installation (see 'Set
up the wired network' on page 12), or
wireless network installation (see 'Set up
the wireless network' on page 13).

• Make sure that the Blu-ray disc supports
BD-Live features.

• Clear memory storage (see 'BD-Live on
Blu-ray' on page 15).

My 3D video played in 2D mode.

• Make sure that your home theater is
connected to a 3D TV through an HDMI
cable.

• Make sure that the disc is a Blu-ray 3D disc,
and the Blu-ray 3D video option is on (see
'BD-Live on Blu-ray' on page 15).

TV screen is black when you play a Blu-ray 3D
video or a DivX copy protected video.

• Make sure that the home theater is
connected to the TV through an HDMI
cable.

• Switch to the correct HDMI source on
the TV.

Bluetooth

A device cannot connect with the home
theater.

36 EN

• The device does not support the

compatible proles required for the home

theater.

• You have not enabled the Bluetooth
function of the device. See the user manual
of the device on how to enable the
function.

• The device is not correctly connected.
Connect the device correctly. (see 'Play
audio through Bluetooth' on page 16)

• The home theater is already connected
with another Bluetooth device. Disconnect
the connected device, then try again.

Quality of audio play from a connected
Bluetooth device is poor.

• The Bluetooth reception is poor. Move
the device closer to the home theater, or
remove any obstacle between the device
and the home theater.

The connected Bluetooth device connects and
disconnects constantly.

• The Bluetooth reception is poor. Move
the device closer to the home theater, or
remove any obstacle between the device
and the home theater.

• Turn off Wi-Fi function on the Bluetooth
device to avoid interference.

• For some Bluetooth, the Bluetooth
connection can be deactivated
automatically to save power. This does
not indicate any malfunction of the home
theater.

Network

Wireless network distorted or not found.

• Make sure that the wireless network is
not disturbed by microwave ovens, DECT
phones, or other neighboring Wi-Fi devices.

• Place the wireless router and the home

theater within ve meters of each other.

• If the wireless network does not work
properly, try a wired network installation
(see 'Set up the wired network' on page

12).

37EN

9 Notice

Open source software

This section contains the legal and trademark
notices.

Copyright

This item incorporates copy protection
technology that is protected by U.S. patents
and other intellectual property rights of
Rovi Corporation. Reverse engineering and
disassembly are prohibited.
This product incorporates proprietar y
technology under license from Verance
Corporation and is protected by U.S. Patent
7,369,677 and other U.S. and worldwide
patents issued and pending as well as copyright
and trade secret protection for certain aspects
of such technology. Cinavia is a trademark of
Verance Corporation. Copyright 2004-2010
Verance Corporation. All rights reserved by
Verance. Reverse engineering or disassembly is
prohibited.

Cinavia notice

This product uses Cinavia technology to
limit the use of unauthorized copies of some

commercially-produced lm and videos and

their soundtracks. When a prohibited use of an
unauthorized copy is detected, a message will
be displayed and playback or copying will be
interrupted.
More information about Cinavia technology
is provided at the Cinavia Online Consumer
Information Center at http://www.cinavia.com.
To request additional information about Cinavia
by mail, send a postcard with your mailing
address to: Cinavia Consumer Information
Center, P.O. Box 86851, San Diego, CA, 92138,
USA.

Open source software

Philips Electronics Hong Kong Ltd. hereby offers
to deliver, upon request, a copy of the complete
corresponding source code for the copyrighted
open source software packages used in this
product for which such offer is requested by
the respective licenses.
This offer is valid up to three years after
product purchase to anyone in receipt of this
information. To obtain source code, please
contact [e-mail]. If you prefer
not to use email or if you do not receive

conrmation receipt within a week after mailing

to this email address, please write to "Open
Source Team, Philips Intellectual Property &
Standards, P.O. Box 220, 5600 AE Eindhoven,
The Netherlands." If you do not receive timely

conrmation of your letter, please email to the

email address above.

RMVB end user agreement

Notes to End User:

By using this product with RealNetworks
software and services, the end user agrees to
the following terms of REALNETWORKS, INC:

• End User may only use the software for
private, non-commercial use in accordance
with the terms of RealNetworks EULA .

• End User is not allowed to modify,
translate, reverse engineer, decompile,
dissemble or use other means to discover
the source code or otherwise replicate
the functionality of the Real Format
Client Code, except to the extent that
this restriction is expressly prohibited by
applicable law.

• RealNetworks Inc. disclaims all warranties
and conditions other than those set forth
in this Agreement which are in lieu of
all other warranties, whether express
and implied, including but not limited to
any implied warranties or conditions of

38 EN

merchantability and tness for a particular

purpose; and effectively exclude all
liability for indirect, special, incidental and
consequential damages, such as but not

limited to lost prots.

Trademarks

Manufactured under license from Dolby
Laboratories. Dolby, Pro Logic, and the
double-D symbol are trademarks of Dolby
Laboratories.

"Blu-ray 3D " and "Blu-ray 3D " logo are
trademarks of Blu-ray Disc Association.

'DVD Video' is a trademark of DVD Format/
Logo Licensing Corporation.

Java and all other Java trademarks and logos are
trademarks or registered trademarks of Sun
Microsystems, Inc. in the United States and/or
other countries.

Manufactured under license under U.S. Patent
Nos: 5,956,674; 5,974,380; 6,226,616; 6,487,535;
7,392,195; 7,272,567; 7,333,929; 7,212,872
& other U.S. and worldwide patents issued
& pending. DTS-HD, the Symbol, & DTS­HD and the Symbol together are registered
trademarks & DTS-HD Master Audio | Essential
is a trademark of DTS, Inc. Product includes
software.

DTS, Inc. All Rights Reserved.

DivX , DivX Certied , DivX Plus HD
and associated logos are trademarks of Rovi
Corporation or its subsidiaries and are used
under license.
ABOUT DIVX VIDEO: DivX
format created by DivX, LLC, a subsidiary

of Rovi Corporation. This is an ofcial DivX
Certied

divx.com for more information and software

tools to convert your les into DivX videos.

ABOUT DIVX VIDEO-ON-DEMAND: This

DivX Certied

in order to play purchased DivX Video-on­Demand (VOD) movies. To obtain your
registration code, locate the DivX VOD section
in your device setup menu. Go to vod.divx.com
for more information on how to complete your
registration.

DivX Certied

HD (H.264/MKV) video up to 1080p HD

including premium content.

device that plays DivX video. Visit

device must be registered

to play DivX and DivX Plus

The terms HDMI and HDMI High-Denition

Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.

is a digital video

39EN

The Bluetooth word mark and logos are
registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by Philips
is under license. Other trademarks and trade
names are those of their respective owners.

RealNetworks, Real, the Real logo, RealPlayer,
and the RealPlayer logo are trademarks or
registered trademarks of RealNetworks, Inc.

CLASS 1

LASER PRODUCT

40 EN

10 Language code

Abkhazian 6566
Afar 6565
Afrikaans 6570
Amharic 6577
Arabic 6582
Armenian 7289
Assamese 6583
Avestan 6569
Aymara 6589
Azerhaijani 6590
Bahasa Melayu 7783
Bashkir 6665
Belarusian 6669
Bengali 6678
Bihari 6672
Bislama 6673
Bokmål, Norwegian 7866
Bosanski 6683
Brezhoneg 6682
Bulgarian 6671
Burmese 7789
Castellano, Español 6983
Catalán 6765
Chamorro 6772
Chechen 6769
Chewa; Chichewa; Nyanja 7889
9072

Ё᭛

Chuang; Zhuang 9065
Church Slavic; Slavonic 6785
Chuvash 6786
Corsican 6779
Česky 6783
Dansk 6865
Deutsch 6869
Dzongkha 6890
English 6978
Esperanto 6979
Estonian 6984
Euskara 6985
 6976
Faroese 7079
Français 7082
Frysk 7089
Fijian 7074
Gaelic; Scottish Gaelic 7168
Gallegan 7176
Georgian 7565
Gikuyu; Kikuyu 7573
Guarani 7178
Gujarati 7185
Hausa 7265
Herero 7290
Hindi 7273
Hiri Motu 7279
Hrwatski 6779
Ido 7379
Interlingua (International)7365
Interlingue 7365
Inuktitut 7385

Inupiaq 7375
Irish 7165

Íslenska 7383
Italiano 7384
Ivrit 7269
Japanese 7465
Javanese 7486
Kalaallisut 7576
Kannada 7578
Kashmiri 7583
Kazakh 7575
Kernewek 7587
Khmer 7577
Kinyarwanda 8287
Kirghiz 7589
Komi 7586
Korean 7579
Kuanyama; Kwanyama 7574
Kurdish 7585
Lao 7679
Latina 7665
Latvian 7686
Letzeburgesch; 7666
Limburgan; Limburger 7673
Lingala 7678
Lithuanian 7684
Luxembourgish; 7666
Macedonian 7775
Malagasy 7771
Magyar 7285
Malayalam 7776
Maltese 7784
Manx 7186
Maori 7773
Marathi 7782
Marshallese 7772
Moldavian 7779
Mongolian 7778
Nauru 7865
Navaho; Navajo 7886
Ndebele, North 7868
Ndebele, South 7882
Ndonga 7871
Nederlands 7876
Nepali 7869
Norsk 7879
Northern Sami 8369
North Ndebele 7868
Norwegian Nynorsk; 7878
Occitan; Provencal 7967
Old Bulgarian; Old Slavonic 6785
Oriya 7982
Oromo 7977
Ossetian; Ossetic 7983
Pali 8073
Panjabi 8065
Persian 7065
Polski 8076
Po

rtuguês 8084

Pushto 8083
Russian 8285
Quechua 8185
Raeto-Romance 8277
Romanian 8279
Rundi 8278
Samoan 8377
Sango 8371
Sanskrit 8365
Sardinian 8367
Serbian 8382
Shona 8378
Shqip 8381
Sindhi 8368
Sinhalese 8373
Slovensky 8373
Slovenian 8376
Somali 8379
Sotho; Southern 8384
South Ndebele 7882
Sundanese 8385
Suomi 7073
Swahili 8387
Swati 8383
Svenska 8386
Tagalog 8476
Tahitian 8489
Tajik 8471
Tamil 8465
Tatar 8484
Telugu 8469
Thai 8472
Tibetan 6679
Tigrinya 8473
To nga (Tonga Islands) 8479
Tsonga 8483
Tswana 8478
Türkçe 8482
Tu rkmen 8475
Tw i 8487
Uighur 8571
Ukrainian 8575
Urdu 8582
Uzbek 8590
Vietnamese 8673
Volapuk 8679
Walloon 8765
Welsh 6789
Wolof 8779
Xhosa 8872
Yiddish 8973
Yo ruba 8979
Zulu 9085

41EN

11 Index

2

2nd audio language 15
2nd subtitle language 15

3

3D disc in 2D mode 15
3D safety 3
3D video 15

5

5.1 speakers 7

A

advanced settings 27

amplier 33

audio connection (analog cable) 11
audio connection (HDMI ARC) 8
audio formats 31
audio from other devices 10
audio language 26
audio options 18
audio post processing 27
audio settings 26
auto standby 27
auto subtitle shift 27
auto volume 25

connect to TV 8
connectors 5
control buttons (disc) 14
control buttons (USB) 14

D

datales 16

deep color 26
default settings 28
device name 13
disc language 26
disc menu 26
display panel 27
DivX 16

E

Easylink (HDMI-CEC) 11
eject disc 4
enhanced audio 27

F

factory settings 28

leformats 31

H

HDMI ARC 8
HDMI audio 26
HDMI-CEC 11
home menu 14
home network 12

B

batteries 34
BD-Live 15
Blu-ray 14
Bonus View 15
brightness 27

C

change password 27
character set 17
clear BD-Live memory 15
connect a digital device (HDMI) 9

42 EN

I

internet 12
iPod or iPhone 20

L

language code 41

M

main unit 4
manual setup 11
media formats 31

media sharing 21
menu language 26
musical slideshows 19

subtitle position 27
surround sound 24
synchronize picture and sound 15

N

network 12
night mode 26

O

one-touch play 11
one-touch standby 11
options 18

P

parental control 27
PBC (play back control) 27
picture options 18
picture resolution 26
picture settings 26
picture-in-picture 15
play disc 14
play from iPod 20
play from PC 23
play USB storage device 17
power settings 27

predenedsoundmode 24

preference 26

R

region codes 31
remote control 4
repeat 18

T

troubleshooting (network) 37
troubleshooting (picture) 35
troubleshooting (play) 36
troubleshooting (sound) 35
tuning grid 19

U

update software (through Internet) 30
USB storage device 17

V

VCD 27
video connection (composite video) 9
video connection (HDMI ARC) 8
video connection (standard HDMI) 9
video formats 33
video options 18
video settings 26
VOD code (DivX) 17

W

watch 3D 15
wired network 12
wireless network 13
wireless rear audio 8
wireless speakers 8

S

shufe 18

sleep timer 27
slide animation 18
software update 29
software version 29
sound 24
speaker position 7
speaker setup 11

speakerspecications 31

subtitle language 26

43EN

O O O O O O

O O O O O O

O O O O O O

X O O O O O

X O O O O O

X O O O O O

O: Indicates that this toxic or hazardous substance contained in all of the homogeneous
materials for this part is below the limit requirement in SJ/T11363 – 2006.

X: Indicates that this toxic or hazardous substance contained in at least one of the
homogeneous materials used for this part is above the limit requirement in SJ/T11363 - 2006.

10

Environmental Protection Use Period

This logo refers to the period ( 10 years ) during which the toxic or hazardous substances or elements
contained in electronic information products will not leak or mutate so that the use of these [substances or
elements] will not result in any severe environmental pollution, any bodily injury or damage to any assets.

Battery labeling logo

This logo refers to the period ( 5 years ) during which the toxic or hazardous substances or elements
contained in the battery will not leak or mutate so that the use of these [substances or elements] will not
result in any severe environmental pollution, any bodily injury or damage to any assets.

44

Environmental Protection Use Period

Specifications are subject to change without notice
© 2016 Koninklijke Philips N.V. All rights reserved.
Trademarks are the property of Koninklijke Philips N.V. or their respective owners.

HTB5510D/5540D/5570D_93_UM_V2.0
