Philips HDD1620 BROCHURE

Page 1

Philips GoGear Micro jukebox

6GB*

HDD1620

Touch your tunes and photos

Distinctly sleek and ultra-intuitive, the 6GB* GoGear HDD1620 lets you effortlessly enjoy your world of MP3 and WMA music and pictures with Sensory Touchpad SuperScroll. PlaysforSure ensures your GoGear works with your Windows XP PC.

Experience music - anytime, anyplace

• 6GB* to store up to 3000* songs or 1600* pictures

• Enjoy MP3 and WMA playback

• Small and wearable - goes where you go

• Large backlit colour display for comfortable viewing anywhere

Super-fast music and picture management

• Touch sensitive keys for intuitive control

• SuperScroll™ navigation finds songs in a simple, fast way

• Picture viewing on 1.5 inch 65K colour LCD

• Easily create and edit playlists on the go

• Make voice recordings

Your music and pictures on the go, every day

• Enjoy up to 18-hour* music playtime

• Auto-synch with Windows Media Player

• PlaysForSure* with Windows XP only

Page 2

Micro jukebox

HDD1620/05

6GB*

Specifications Product highlights

Picture/Display

• Type: CSTN-Transmissive

• Diagonal screen size (inch): 1.5 inch

• Resolution: 128 x 128 pixels, 65K color

• Lines of text: 7

• Backlight colour: White

Sound

• Equaliser: 5-bands

• Equalizer settings: Classic, Jazz, Hip Hop, Spoken word, Rock, Pop, RnB, Dance, Electronica, Lounge

• Frequency response: 20 - 16 000 Hz

• THD: 0.1%

• Signal to noise ratio: >82 dB

• Output Power: 2x5mW (16 Ohm)

• Sensitivity: 100dB

• Equalizer customizable

• Bass enhancement: SRS WOW

Audio Playback

• Compression format: MP3, Windows Media™ Audio, WAV

• MP3 bit rates: 8-320 kbps and VBR

• WMA bit rates: 32 - 192 kbps

• WMA sample rates: 8,11.025,16,22.050,32,44.1,48

• Buffer memory: 32 MB

• ID3 Tag support: Album title and artist name, Genre title, Track title and artist name

Audio Capturing

• Voice recording

• Built-in microphone: mono

• Audio file format: WAV

It, Ch smpl, Ch trad, Jap, Korean

• Superscroll

Accessories

• AC/DC Adaptor/Charger: Multi-voltage (AY4109)

• USB cable: combined with AC/ DC adaptor in Y cable

• Headphones: SHE9500BI/00

• Pouch: Protective rubber pouch (AY4237)

• CD-ROM: with installer, PC software, manuals

• User Guide on CD-ROM: EN, FR, ES, NL, DE, PO, SV, IT, SU, DA, CS, RU, HU, EL, PL, SL

Green Specifications

• Lead-free soldered product

System Requirements

• PC OS: Windows XP (SP1 or above)

• Processor: Pentium II or better

• Hard disk space: 100 MB

• RAM memory: 64 MB

•CD-ROM drive

•Sound card

•Video card

Dimensions

• Master carton quantity: 3

• Packaging dimensions (W x H x D): 153

x 95 x 153 mm

• Product dimension (WxDxH) inch: 2.11 x 3.39 x

0.64 inch

• Packaging type: D-box

• Master carton dimensions: 165 x 305 x 165 mm

• Product weight: 0.087 kg

SuperScroll™ navigation

Do ubl e ac tion sea rch key s al low easy spe ed c ont rol when scrolling through large libraries. You can choose to move through your play list one song at a time or just press and hold down a little harder to SuperScroll™ swiftly to your desired track.

PlaysForSure*

Enjoying your GoGear device is simple with PlaysForSure which ensures compatibility with Windows Media Player 10 and Windows XP. Using Windows Media player you can easily manage music on your GoGear digital audio player and auto-synchronise your PC music collection. Also, enjoy the widest online shopping selection by simply looking for the PlaysForSure logo at your choice of online store. Then rest assured knowing any music you purchase there will work with your GoGear player.

Storage Media

• Built-in memory type: Hard disc

• Hard Disk Capacity: 6* GB

• Music memory capacity: Up to 3000 songs*

Connectivity

• DC in: 5V

• Headphone: 3.5 mm

• USB: USB 2.0

• Connector: Philips dock connector

Convenience

• Battery charging indication

• Battery full indication

• Battery low indication

• Function: Keypad lock

• Language support: Eng,Fr,Spa,Dutch,Ge,Port,Swe,

Power

• Battery capacity: 610 mAh

• Battery Type: Li-ion

• Charging time: 1 hour fast charge (70%), 4 hrs full charge

• Rechargeable

• Playtime on internal battery: up to 17 hours*

Still Picture Playback

• Picture compression format: JPEG

•Slide show

Software

• Windows Media Player 10

• Device manager

• PlaysForSure: Audio Download, Audio Subscription

•

Issue date 2007-11-25

Version: 3.0

12 NC: 9073 101 02285 EAN: 87 10895 92554 9

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips Electronics N.V. or their respective owners.

www.philips.com

* 1GB = 1 billion bytes; available storage capacity will be less. * Rechargeable batteries have a limited number of charge cycles and

may eventually need to be replaced. Battery life and number of charge cycles vary by use and settings.

* Storage capacity based on 4 minutes per song and 64 kbps WMA or

128 kbps MP3 encoding. * Storage capacity based on 5 Mpixel pictures. * The PlaysForSure, Windows Media and the Windows logo are

trademarks, or registered trademarks of Microsoft Corporation in

the United States and/or other countries. * Actual transfer speed may vary based on your operating system and

software configuration. * This feature requires an additional accessory which is sold

separately.
