ENGLISH
Introduction
Congratulations on your purchase and welcome to Philips! To fully
benet from the support that Philips offers, register your product
at www.philips.com/welcome.
Your new airfryer allows you to prepare your favourite ingredients and
snacks in a healthier way.
The airfryer uses hot air in combination with high-speed air circulation
(Rapid Air) and a top grill to prepare a variety of tasty dishes in a healthy,
fast and easy way. Your ingredients are heated from all sides at once and
there is no need to add oil to most of the ingredients.
For more inspiration for recipes and information about the airfryer,
visit www.philips.com/kitchen.
General description (Fig. 1)
1 Basket
2 MAX indication
3 Basket handle
4 Pan
5 Control panel
- A Power on/off button
- B START/STOP button
- C Preset button
- D Temperature increase and decrease buttons
- E Time/temperature indication
- F Timer increase and decrease buttons
6 Drawer
7 Air outlet openings
8 Air inlet
Important
Read this user manual carefully before you use the
appliance and save it for future reference.
Danger
- Never immerse the housing, which contains electrical
components and the heating elements, in water nor
rinse it under the tap.
- Do not let any water or other liquid enter the
appliance to prevent electric shock.
- Always put the ingredients to be fried in the basket,
to prevent them from coming into contact with the
heating elements.
- Do not cover the air inlet and the air outlet openings
while the appliance is operating.
- Do not ll the pan with oil as this may cause a re
hazard.
- Never touch the inside of the appliance while it is
operating.
Warning
- Check if the voltage indicated on the appliance
corresponds to the local mains voltage before you
connect the appliance.
- Do not use the appliance if the plug, the mains cord
or the appliance itself is damaged.
- If the mains cord is damaged, you must have it replaced
by Philips, a service centre authorised by Philips or
similarly qualied persons in order to avoid a hazard.
- This appliance can be used by children aged from
8 years and above and by persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and if they understand the
hazards involved.
- Cleaning and user maintenance shall not be made by
children unless they are older than 8 and supervised.
- Keep the appliance and its cord out of the reach of
children aged less than 8 years.
- Keep the mains cord away from hot surfaces.
- Do not plug in the appliance or operate the control
panel with wet hands.
- Only connect the appliance to an earthed wall socket.
Always make sure that the plug is inserted into the
wall socket properly.
- This appliance is not intended to be operated by
means of an external timer or a separate remotecontrol system.
- Do not place the appliance on or near combustible
materials such as a tablecloth or curtain.
- Do not place the appliance against a wall or against
other appliances. Leave at least 10cm free space at
the back, on both sides and above the appliance.
Do not place anything on top of the appliance.
- Do not use the appliance for any other purpose than
described in this manual.
- Do not let the appliance operate unattended.
- During hot air frying, hot steam is released through
the air outlet openings. Keep your hands and face at a
safe distance from the steam and from the air outlet
openings. Also be careful of hot steam and air when
you pull the pan out of the appliance.
- The accessible surfaces may become hot during
use (Fig. 2).
- Immediately unplug the appliance if you see dark
smoke coming out of the appliance. Wait for the
smoke emission to stop before you pull the pan out
of the appliance.
- The pan becomes hot all over when it is used in the
airfryer. Let the pan cool down before you handle it.
Caution
- Place the appliance on a horizontal, even and stable
surface.
- This appliance is intended for normal household
use only. It is not intended for use in environments
such as staff kitchens of shops, ofces, farms or other
work environments. Nor is it intended to be used by
clients in hotels, motels, bed and breakfasts and other
residential environments.
- If the appliance is used improperly or for professional
or semi-professional purposes or if it is not used
according to the instructions in the user manual, the
guarantee becomes invalid and Philips refuses any
liability for damage caused.
- Always return the appliance to a service centre
authorised by Philips for examination or repair.
Do not attempt to repair the appliance yourself,
otherwise the guarantee becomes invalid.
- Always unplug the appliance after use.
- Let the appliance cool down for approx. 30 minutes
before you handle or clean it.
- Make sure the ingredients prepared in this appliance
come out golden-yellow instead of dark or brown.
Remove burnt remnants. Do not fry fresh potatoes
at a temperature above 180°C (to minimise the
production of acrylamide).
Automatic switch-off
This appliance is equipped with an automatic switch-off. If you do not press a
button within 30 minutes, the appliance switches off automatically. To switch
off the appliance manually, press the power on/off button.
Electromagnetic elds (EMF)
This Philips appliance complies with all standards regarding electromagnetic
elds (EMF). If handled properly and according to the instructions in this
user manual, the appliance is safe to use based on scientic evidence
available today.
Before first use
1 Remove all packaging material.
2 Remove the foil from the control panel and any stickers or labels
from the appliance.
3 Open the drawer by pulling at the handle. (Fig. 3)
4 Remove the basket by lifting the handle (1). To remove the pan, tilt it
backwards and lift it off the rails (2). (Fig. 4)
5 Thoroughly clean the basket and pan with hot water, some washing-
up liquid and a non-abrasive sponge.
Note: You can also clean these parts in the dishwasher.
6 Wipe the inside and outside of the appliance with a moist cloth.
7 Place the pan in the drawer (1) and put the basket in the pan (2) (Fig. 5).
8 Slide the drawer back into the airfryer by the handle.
Preparing for use
1 Place the appliance on a stable, horizontal and level surface.
Do not place the operating appliance on non-heat-resistant surfaces.
Do not place the operating appliance near or underneath objects that
could be damaged by steam, such as walls and cupboards.
Note: Place the appliance on a worktop in such a way that the drawer can be
opened completely.
2 Pull the mains cord out of the cord storage compartment at the back
of the appliance.
This airfryer works on hot air. Do not ll the pan with oil, frying fat or
any other liquid.
Do not put anything on top of the appliance. This disrupts the airow and
affects the hot air frying result.
Using the appliance
The airfryer can prepare a large range of ingredients. The recipe booklet
included helps you get to know the appliance. You can nd more recipes at
www.philips.com/kitchen.
Preheating
1 Put the mains plug in an earthed wall socket.
2 Press the power on/off button to switch on the appliance. (Fig. 6)
, The display shows the last selected temperature.
3 Press the temperature increase or decrease button to set the
required temperature. See section ‘Settings’ in this chapter to
determine the right temperature. (Fig. 7)
Tip: Press the increase or decrease button longer to put the temperature
forward or backward more quickly.
Note: If you do not want to preheat, but want to start frying immediately, skip
step 4 and follow the instructions in section ‘Hot air frying’ in this chapter.
4 Press the START/STOP button. (Fig. 8)
, The appliance starts to heat up.
, The set temperature ashes until the set temperature has been
reached. Then the appliance beeps and the set temperature is
displayed continuously. The appliance stops beeping if you set the
required cooking time (see step 4 in section ‘Hot air frying’).
Note: You can also start the preheating process manually by setting the temperature
and then pressing the timer decrease button until ‘- -’ appears. (Fig. 9)
Hot air frying
1 Open the drawer by pulling at the handle. (Fig. 3)
2 Put the ingredients in the basket (Fig. 10).
Note: Never ll the basket beyond the MAX indication or exceed the amount
indicated in the table (see section ‘Settings’ in this chapter), as this could affect
the quality of the end result.
3 Slide the drawer back into the airfryer by the handle (Fig. 11).
Never use the pan without the basket in it. If you heat up the appliance
without basket, use oven gloves to open the drawer. The edges and inside
of the drawer become very hot.
Caution: Do not touch the pan during and some time after use, as it gets
very hot.
4 Press the timer increase or decrease button to set the timer to
the required cooking time. See section ‘Settings’ in this chapter to
determine the correct cooking time. (Fig. 12)
Tip: Press the timer increase or decrease button longer to put the time forward
or backward more quickly.
Note: If you have not preheated the appliance, add 3 minutes to the cooking time.
Note: If you do not set the required cooking time within 5 minutes, the
appliance switches off automatically for safety reasons.
5 Press the START/STOP button to start the cooking process. (Fig. 13)
, The display starts counting down the set cooking time.
, Excess oil from the ingredients is collected on the bottom of the pan.
6 When the appliance starts to beep, the set cooking time has elapsed.
Note: You can also stop the cooking process manually. To do this, press the
START/STOP button (Fig. 8).
7 Open the drawer by pulling at the handle and check if the ingredients
are ready. (Fig. 14)
If the ingredients are not ready yet, simply slide the drawer back into the
airfryer by the handle and add a few extra minutes to the set time.
8 To remove small ingredients (e.g. fries), lift the basket out of the pan
by the handle. (Fig. 15)
After the cooking process, the pan, the basket and the ingredients are hot.
Depending on the type of ingredients in the airfryer, steam may escape
from the pan.
9 Empty the basket into a bowl or onto a plate. (Fig. 16)
Tip: To remove large or fragile ingredients, use a pair of tongs to lift the
ingredients out of the basket (Fig. 17).
10 When a batch of ingredients is ready, the airfryer is instantly ready
for preparing another batch.
Note: Repeat steps 1 to 9 if you want to prepare another batch.
Note: If you prepare another batch within 30 minutes, it is not necessary to
preheat the appliance again.
11 Press the power on/off button to switch off the airfryer.
Preset button
You can program the appliance to prepare your favourite ingredients at a
specic temperature for a specic length of time.
Note: The appliance can only memorise one temperature and one cooking time.
To set your favourite settings:
1 Press the power on/off button to switch on the appliance. (Fig. 6)
2 Press the preset button (star symbol). (Fig. 18)
, The display shows the current saved settings.
3 Press the temperature increase or decrease button to set the desired
temperature. (Fig. 7)
, The star symbol starts ashing.
4 Press the timer increase or decrease button to set the desired
time. (Fig. 12)
5 Press the preset button (star symbol). (Fig. 18)
, You hear a beep and the star symbol lights up continuously to
indicate that the settings have been saved.
From now on, the appliance memorises your favourite settings. Just press
the preset button to recall the saved settings. Press the START/STOP button
to start the program.
Note: If you want to change the saved settings, simply perform steps 1 to 5 again.
Settings
The table below helps you to select the basic settings for the ingredients
you want to prepare.
Note: Keep in mind that these settings are indications. As ingredients differ in
origin, size, shape as well as brand, we cannot guarantee the best setting for
your ingredients.
Because the Rapid Air technology instantly reheats the air inside
the appliance, pulling the pan briey out of the appliance during
cooking barely disturbs the process.
Tips
- Smaller ingredients usually require a slightly shorter cooking time than
larger ingredients.
- A larger amount of ingredients only requires a slightly longer cooking
time, a smaller amount of ingredients only requires a slightly shorter
cooking time.
- Shake smaller ingredients halfway through the cooking time to
redistribute them. This improves the end result and helps to prevent
unevenly cooked ingredients.
- Add some oil to fresh potatoes for a crispy result. Fry your ingredients
in the airfryer within a few minutes after you added the oil.
- Do not prepare extremely greasy ingredients such as sausages in the airfryer.
- Snacks that can be prepared in an oven can also be prepared in the airfryer.
- The optimal amount for preparing crispy fries is 750 grams.
- Use pre-made dough to prepare lled snacks quickly and easily. Pre-made
dough also requires a shorter cooking time than home-made dough.
- Place a baking tray or oven dish in the airfryer basket if you want to bake a
cake or quiche or if you want to fry fragile ingredients or lled ingredients.
- You can also use the airfryer to reheat ingredients. To reheat ingredients,
set the temperature to 150°C for up to 10 minutes.
Min-max
amount
(g)
Potatoes &
fries
Thin frozen
fries
Thick frozen
fries
Homemade fries
(8x8mm)
Home-made
potato
wedges
Snacks
Spring rolls 100g-
Frozen
chicken nuggets
Frozen sh
ngers
Roasted
vegetables
Meat rolls 1-5 6 200
Hamburger 100g -
Baking
Cake 500g 50 150 Use baking
Quiche 400g 20 190 Use baking
Mufns 400g 15 180 Use baking
Meat & poultry
Steak* 100g 5 at 180°C and 4 at 100°C
Drumsticks* 1 (80g) 10 at 200°C and 10 at 150°C
Chicken breast* 100g 8 at 140°C and 6 at 180°C
300g1000g
300g1000g
300g1200g
300g900g
400g
400g 6 200 Shake Use oven-
4-12 8-10 200 Use oven-
750g 15 200
400g
Cooking time
(min.)
8-16 200 Shake
13-19 200 Shake
20-30 180 Shake add 1/2 tbsp
18-24 180 Shake add 1/2 tbsp
7 200 Shake Use oven-
6-7 180
Min-max Amount
(g)
600g 6 at 180°C and 4 at 100°C
7 (600g) 10 at 200°C and 10 at 150°C
800g 8 at 140°C and 8 at 180°C
Temperature
(°C)
Cooking time (min.) at temperature
(°C)
Shake Extra infor-
mation
of oil
of oil
ready
ready
ready
tray
tray/oven dish
tray
* Always start cooking at the highest temperature and then continue at a lower
temperature until done.
Note: When you use ingredients that rise (such as with cake, quiche or mufns)
the baking tray should not be lled more than halfway.
Note: The cooking time does not include the time needed for preheating the
appliance.
Making home-made fries
For the best results, we advise you to use pre-baked (e.g. frozen) fries.
If you want to make home-made fries, follow the steps below.
1 Peel the potatoes and cut them into sticks.
2 Soak the potato sticks in a bowl for at least 30 minutes, take them
out and dry them with kitchen paper.
3 Pour ½ tablespoon of olive oil in a bowl, put the sticks on top and
mix until the sticks are coated with oil.
4 Remove the sticks from the bowl with your ngers or a kitchen
utensil so that excess oil stays behind in the bowl. Put the sticks in
the basket.
Note: Do not tilt the bowl to put all the sticks in the basket in one go, to prevent
excess oil from ending up on the bottom of the pan.
5 Fry the potato sticks according to the instructions in this chapter.
Cleaning
Clean the appliance after every use. Remove oil from the bottom of the
pan after each cooking process to prevent the development of smoke.
Open the drawer to let the airfryer cool down more quickly. Let the pan
cool down before you remove it from the appliance.
The pan, basket and the inside of the appliance have a non-stick coating.
Do not use metal kitchen utensils or abrasive cleaning materials to clean
them, as this may damage the non-stick coating.
1 Remove the mains plug from the wall socket and let the appliance
cool down.
2 Wipe the outside of the appliance with a moist cloth.
Note: Make sure no moisture remains behind on the control panel. Dry the
control panel with a cloth after you have cleaned it.
3 Clean the pan and the basket with hot water, some washing-up liquid
and a non-abrasive sponge.
You can use a degreasing liquid to remove any remaining dirt.
Note: The pan and basket are dishwasher-proof.
Tip: If dirt sticks to the basket or the bottom of the pan, ll the pan with hot
water with some washing-up liquid. Put the basket in the pan and let the pan
and the basket soak for approximately 10 minutes.
4 Clean the inside of the appliance with hot water and a non-abrasive
sponge.
5 Clean the heating element with a cleaning brush to remove any food
residues.
Storage
1 Unplug the appliance and let it cool down.
2 Make sure all parts are clean and dry.
3 Insert the cord into the cord storage compartment.
Ordering accessories
To purchase accessories for this appliance, please visit our online shop at
www.shop.philips.com/service. If the online shop is not available in
your country, go to your Philips dealer or a Philips service centre. If you have
any difculties obtaining accessories for your appliance, please contact the
Philips Consumer Care Centre in your country. You nd its contact details in
the worldwide guarantee leaet.
Environment
- Do not throw away the appliance with the normal household waste
at the end of its life, but hand it in at an ofcial collection point for
recycling. By doing this, you help to preserve the environment (Fig. 19).
Guarantee and service
If you need service or information or if you have a problem, please visit
the Philips website at www.philips.com/support or contact the Philips
Consumer Care Centre in your country. You nd its phone number in the
worldwide guarantee leaet. If there is no Consumer Care Centre in your
country, go to your local Philips dealer.
Loading...
