Philips HD8857, HD8855 User Manual

Register your product and get support at

www.philips.com/welcome

Type HD8855 / HD8857

02

English

USER MANUAL

EN

02

PLEASE READ THIS USER MANUAL CAREFULLY BEFORE USING THE MACHINE.

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be
followed, including the following:

1. Read all instructions.

2. Do not touch hot surfaces. Use handles or knobs.

3. To protect against fire, electric shock and injury to persons do not immerse

cord, plugs, or appliance in water or other liquid.

4. Close supervision is necessary when the appliance is used by or near
children.

5. Unplug from outlet when not in use and before cleaning. Allow to cool
before putting on or taking off parts, and before cleaning the appliance.

6. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or has been damaged in any manner. Return
appliance to the nearest authorized service facility for examination, repair
or adjustment.

7. The use of accessory attachments not recommended by the appliance
manufacturer may result in fire, electric shock or injury to persons.

8. Do not use outdoors.

9. Do not let cord hang over edge of table or counter, or touch hot surfaces.

10. Do not place on or near a hot gas or electric burner, or in a heated oven.

11. Always attach plug to appliance first, then plug cord into wall outlet. To

disconnect, turn any control to “off”, then remove plug from wall outlet.

12. Do not use appliance for other than intended use.

13. Save these instructions.

SAVE THESE INSTRUCTIONS

CAUTION

This appliance is for household use only. Any servicing, other than cleaning
and user maintenance, should be performed by an authorized service center.
Do not immerse machine in water. To reduce the risk of fire or electric shock,
do not disassemble the machine. There are no parts inside the machine
serviceable by the user. Repair should be done by authorized service personnel
only.

1. Check voltage to be sure that the voltage indicated on the nameplate
corresponds with your voltage.

2. Never use warm or hot water to fill the water tank. Use cold water only.

3. Keep your hands and the cord away from hot parts of the appliance during

operation.

4. Never clean with scrubbing powders or harsh cleaners. Simply use a soft
cloth dampened with water.

5. For optimal taste of your coffee, use purified or bottled water. Periodic
descaling is still recommended every 2-3 months.

6. Do not use caramelized or flavored coffee beans.

INSTRUCTIONS FOR THE POWER

SUPPLY CORD

A. A short power-supply cord (or detachable power-supply cord) is to be

provided to reduce risks resulting from becoming entangled in or tripping
over a longer cord.

B. Longer detachable power-supply cords or extension cords are available

and may used if care is exercised in their use.

C. If a long detachable power-supply cord or extension cord is used,

1. The marked electrical rating of the detachable power-supply cord or

extension cord should be at least as great as the electrical rating of the
appliance

2. If the appliance is of the grounded type, the extension cord should be a

grounding-type 3-wire cord, and

3. The longer cord should be arranged so that it will not drape over the

counter top or table top where it can be pulled on by children or tripped
over.

2

ENGLISH

Congratulations on your purchase of a Saeco Exprelia EVO
full automatic espresso machine!
To fully bene t from the support that Saeco o ers, please
register your product at www.philips.com/welcome.
This user manual applies to HD8855 and HD8857.
The machine is suitable for preparing espresso co ees using
whole co ee beans. It is supplied with a milk carafe so you
can prepare perfect cappuccino or latte macchiato in a
quick and easy way. In this user manual you will  nd all the
information you need to install, use, clean and descale your
machine.

CONTENTS

IMPORTANT..................................................................................................... 4

Safety instructions ....................................................................................................................................4

Warning ....................................................................................................................................................4

Caution .....................................................................................................................................................5

Compliance with standards ......................................................................................................................5

INSTALLATION ................................................................................................. 6

Product overview ......................................................................................................................................6

General description ................................................................................................................................... 7

PREPARING FOR USE ........................................................................................ 8

Machine packaging ...................................................................................................................................8

Machine installation ................................................................................................................................. 8

USING THE MACHINE FOR THE FIRST TIME ........................................................11

Automatic rinse/self-cleaning cycle ........................................................................................................11

Manual rinse cycle...................................................................................................................................11

Measuring and programming water hardness ........................................................................................13

“INTENZA+” water  lter installation .......................................................................................................15

Replacing the “INTENZA+” water  lter .................................................................................................... 17

ADJUSTMENTS ................................................................................................18

Saeco Adapting System ........................................................................................................................... 18

Adjusting the ceramic co ee grinder....................................................................................................... 18

Adjusting co ee crema and intensity (Saeco Brewing System) ...............................................................19

Adjusting the aroma (co ee strength) ....................................................................................................20

Adjusting the dispensing spout ............................................................................................................... 20

Adjusting the co ee length ....................................................................................................................22

ENGLISH

ESPRESSO, COFFEE AND LONG COFFEE BREWING ...............................................23

Espresso, co ee and long co ee brewing using co ee beans .................................................................23

Espresso, co ee and long co ee brewing using pre-ground co ee .........................................................24

MILK CARAFE..................................................................................................26

Filling the milk carafe .............................................................................................................................. 26

Inserting the milk carafe .........................................................................................................................27

Removing the milk carafe .......................................................................................................................28

Emptying the milk carafe ........................................................................................................................29

CAPPUCCINO BREWING ...................................................................................30

Adjusting the cappuccino length ............................................................................................................. 32

LATTE MACCHIATO BREWING ...........................................................................33

Adjusting the latte macchiato length ......................................................................................................35

SPECIAL BEVERAGES .......................................................................................36

Hot milk .................................................................................................................................................36

Hot water dispensing ..............................................................................................................................37

Steam dispensing .................................................................................................................................... 38

BEVERAGE PROGRAMMING .............................................................................39

Cappuccino programming ....................................................................................................................... 40

Hot water programming .........................................................................................................................41

MACHINE PROGRAMMING ...............................................................................42

General menu .........................................................................................................................................43

Display menu ..........................................................................................................................................43

Water menu ............................................................................................................................................44

Maintenance menu .................................................................................................................................45

Factory Setting ........................................................................................................................................45

CLEANING AND MAINTENANCE ........................................................................46

Daily cleaning of the machine ................................................................................................................. 46

Daily cleaning of water tank .................................................................................................................... 47

Daily cleaning of the milk carafe: AUTO CLEAN cycle (after each use) ......................................................48

Weekly cleaning of the machine ............................................................................................................ 48

Weekly cleaning of the milk carafe ......................................................................................................... 50

Weekly cleaning of the brew group ......................................................................................................... 52

Monthly cleaning of the milk carafe ........................................................................................................54

Monthly lubrication of the brew group...................................................................................................57

Monthly cleaning of the brew group with “Co ee Oil Remover” .............................................................. 58

Monthly cleaning of the co ee bean hopper ...........................................................................................60

DESCALING .....................................................................................................61

MEANING OF THE DISPLAY ...............................................................................65

TROUBLESHOOTING ........................................................................................67

ENERGY SAVING ..............................................................................................70

Stand-by .................................................................................................................................................70

Screen saver ............................................................................................................................................ 70

Disposal .................................................................................................................................................. 71

TECHNICAL SPECIFICATION ..............................................................................72

GUARANTEE AND SERVICE ...............................................................................72

Guarantee ...............................................................................................................................................72

Service .................................................................................................................................................... 72

ORDERING MAINTENANCE PRODUCTS .............................................................73

3

4

ENGLISH

IMPORTANT

Safety instructions

This machine is equipped with safety features. Nevertheless read the safety
instructions carefully and only use the machine as described in these
instructions to avoid accidental injury or damage.

Keep this user manual for future reference.

The term WARNING and this sign warn against possible severe injuries,
danger to life and/or damage to the machine.

The term CAUTION and this sign warn against slight injuries and/or dama-
ge to the machine.

Warning

• Connect the machine to a wall socket which is properly wired. Its main
voltage should comply with the technical data of the appliance.

• Do not let the mains cord hang over the edge of a table or counter, or
touch hot surfaces.

• Never immerse the machine, mains plug or mains cord in water (dan­ger of electrical shock).

• Never direct the hot water jet towards body parts (danger of burning).

• Do not touch hot surfaces. Use handles and knobs.

• Remove the mains plug from the wall socket:

- If a disturbance occurs.

- If the machine will not be used for a long time.

- Before cleaning the machine.

Pull on the plug, not on the mains cord. Do not touch the mains plug

with wet hands.

• Do not use the machine if the mains plug, the mains cord or the machi­ne itself is damaged.

• Do not make any modi cations to the machine or its mains cord. Only
have repairs carried out by a service centre authorized by Philips to
avoid a hazard.

• This machine is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of expe­rience and knowledge, unless they have been given supervision or
instruction concerning use of the machine by a person responsible for
their safety.

ENGLISH

• Children should be supervised to ensure that they do not play with the
machine.

• Never insert  ngers or other objects into the co ee grinder.

Caution

• The machine is for household use only. It is not intended for use in en­vironments such as sta kitchens of shops, o ces, farms or other work
environments.

• Always put the machine on a  at and stable surface.

• Do not place the machine on a hot plate, directly next to a hot oven,
heater or similar source of heat.

• Only put co ee beans into the co ee bean hopper. If ground co ee,
instant co ee or any other substance is put in, it may damage the
machine.

• Allow the machine to cool before putting on or taking o .

• Never use warm or hot water to  ll the water tank. Use cold water only.

• Never clean with scrubbing powders or harsh cleaners. Simply use a
soft cloth dampened with water.

• Descale your machine regularly. The machine indicates when desca­ling is needed. Not doing this will make your appliance stop working
properly. In this case repair is not covered under your warranty!

• Do not keep the machine at temperature below 0 degree Celsius.
Residue water in the heating system may freeze and cause damage.

• Do not leave water in the water tank when the machine is not used
over a longer period of time. The water can become contaminated. Use
fresh water every time you use the machine.

5

5

Compliance with standards

The machine complies with art.13 of the Italian Legislative Decree dated 25
July 2005, no. 151 “Implementation of the directives 2005/95/EC, 2002/96/EC
and 2003/108/EC on the restriction of the use of certain hazardous substan­ces in electrical and electronic equipment, as well as waste disposal”.

This machine complies with EU directive 2002/96/EC.

6

INSTALLATION

Product overview

12

13 14 15

16

17

19

22

23

26

1
2

7
8

9

3

10

4
5

11

6

18

20

27 28 29 3832

21

33

34

24

35

25

37363130

General description

1. Water tank

2. Pre-ground co ee compartment

3. Service door

4. Dispensing spout

5. Hot water/steam wand

6. Full drip tray indicator

7. Co ee bean hopper with lid

8. Grinder adjustment

9. Control panel

10. Carafe coupling cap

11. Drip tray (external)

12. Brew group

13. Co ee grounds drawer

14. Drip tray (internal)

15. Service door button

16. Power cord socket

17. Power button

18. Milk carafe

19. Co ee oil remover – to be purchased separately

20. Descaling solution – to be purchased separately

21. INTENZA+ water  lter – to be purchased separately

22. Pre-ground co ee scoop

23. Grease for brew group

24. Water hardness test

25. Cleaning brush

26. Power cord

27. Espresso button

28. Co ee button

29. Cappuccino button

30. Long Co ee button

31. “Special beverage” button

32. “Aroma” - Pre-ground co ee button

33. “OK” button

34. “ESC” button

35. “MENU” button

36. Carafe cleaning cycle activation button (Clean)

37. Stand-by button

38. Latte macchiato button

ENGLISH

7

7

8

ENGLISH

PREPARING FOR USE

Machine packaging

The original packaging has been designed and constructed to protect the
machine during transport. We recommend keeping the packaging material
for possible future transport.

Machine installation

Remove the drip tray with grill from the packaging.

1

Remove the machine from the packaging.

2

For best use, it is recommended to:

3

• Choose a safe, level surface, where there will be no danger of over­turning it or being injured.

• Choose a location that is su ciently well-lit, clean and near an
easily reachable socket.

• Allow for a minimum distance from the sides of the machine as
shown in the illustration.

Attach the drip tray (external) with grill to the machine. Make sure it is

4

placed correctly.

Note:
The drip tray collects the water that comes out of the dispensing spout
during each rinse/self-cleaning cycle as well as co ee that might be spilled
during beverage preparation. Empty and clean the drip tray daily and each
time the full drip tray indicator is raised.

Caution:
NEVER remove the drip tray when the machine has just been turned
on. Wait a couple of minutes, since the machine will carry out a rinse/
self-cleaning cycle.

ENGLISH

Open the lid and remove the water tank by the handle.

5

Rinse the water tank under fresh water.

6

Fill the tank with fresh water up to the MAX level and re-insert it into

7

the machine. Make sure it is fully inserted.

Caution:
Never  ll the water tank with warm, hot, sparkling water or any other
liquid, as this may cause damage to the water tank and the machine.

Open the lid of the co ee bean hopper and take out the inner lid.

8

9

9

Slowly pour co ee beans into the hopper. Put the inner lid back and

9

close the lid.

Note:
Do not pour too many co ee beans into the co ee bean hopper as this will
reduce the grinding performance of the machine.

Caution:
Only co ee beans must be put into the co ee bean hopper. Ground
co ee, instant co ee, caramelized co ee or any other object may
damage the machine.

10

ENGLISH

LANGUAGE

ITALIANO
ENGLISH

DEUTSCH

Insert the plug into the socket located on the back of the machine.

10

Insert the plug on the other end of the power cord into a wall socket

11

with suitable power voltage.

Switch the power button to “I” to turn on the machine.

12

This page will be displayed. Select the desired language by pressing

13

the scrolling buttons “

” or “ ” .

LANGUAGE

ITALIANO
ENGLISH

DEUTSCH

HEATING UP…

Press the “ ” button to con rm.

14

Note:
If no language is selected, you will be requested to select it the next time
the machine is started.

The machine is heating-up.

15

RINSING

ENGLISH

USING THE MACHINE FOR THE FIRST TIME

Automatic rinse/self-cleaning cycle

When warm-up is completed, the machine automatically performs a rinse/
self-cleaning cycle of the internal circuit with fresh water. This takes less
than a minute.

Place a container under the dispensing spout to catch the small

16

amount of water which will be dispensed.

This page will be displayed. Wait for the cycle to  nish automatically.

17

11

11

STOP

Note:
You can stop dispensing by pressing the “ESC” button.

When the above steps are completed, the machine shows this display.

18

Manual rinse cycle

You need to initiate this, when using the machine for the  rst time.
During this process you activate the co ee brewing cycle and fresh water
 ows through the dispensing spout. This takes a few minutes.

Place a container under the dispensing spout.

1

12

ENGLISH

OK

INSERT

GROUND COFFEE

AND PRESS OK

ESC

Select the pre-ground co ee brewing function by pressing the “ ”

2

button. The machine shows this icon “

Press the “ ” button.

3

Press the “OK” button. The machine starts dispensing water.

4

”.

Note:
Do not add pre-ground co ee into the compartment.

When the dispensing has  nished, empty the container and place it

5

under the hot water/steam wand.

SPECIAL BEVERAGES

HOT MILK

HOT WATER

STEAM

Press the “ ” button.

6

Press the “ ” button to scroll the pages. Press “OK” to select HOT WA-

7

TER.

ENGLISH

Once the water has been dispensed, remove and empty the container.

8

Repeat the process from step 5 to step 8 until the water tank is empty.

9

Then, continue with step 10.

At the end,  ll the water tank again up to the MAX level. Now the ma-

10

chine is ready for brewing co ee.

Note:
When you haven’t used the machine for 2 or more weeks, the machine
will automatically perform an automatic rinse/self-cleaning cycle after
you switch it on. Thereafter you need to initiate the manual rinse cycle as
described above.

The automatic rinse/self-cleaning cycle is also initiated automatically when
starting up the machine (with cold boiler), when the machine is preparing
to go into stand-by mode or after you have pressed the “
o the machine (after a co ee has been brewed).

” button to turn

13

13

Measuring and programming water hardness

Measuring water hardness is very important for de ning the frequency in
which the machine has to be descaled and to install the “INTENZA+” water
 lter (for more detail on the water  lter see next chapter).

To measure the water hardness follow the steps below:

Immerse the water hardness test strip provided with the machine in

1

water for 1 second.

Note:
The test strip can only be used for one measurement.

Wait for one minute.

2

14

Intenza Aroma System

ENGLISH

C

B

A

23 4

Machine water hardness setting

1

Check how many squares have changed the colour to red and then

3

consult the table.

Note:
The numbers on the water hardness test strip correspond to the water
hardness adjustment settings.
More precisely:
1 = 1 (very soft water)
2 = 2 (soft water)
3 = 3 (hard water)
4 = 4 (very hard water)

The letters correspond to the references that are located at the base of the
“INTENZA+” water  lter (see next chapter for this).

Now you can program the water hardness setting. Press “MENU” but-

4

ton to access the machine main menu.

Note:
The machine is supplied with standard water hardness setting, suitable for
most of the type of water.

2

MENU

BEVERAGE MENU

MACHINE MENU

2

MACHINE MENU

DISPLAY MENU

WATER MENU

MAINTENANCE

WATER MENU

HARDNESS

ENABLE FILTER

ACTIVATE FILTER

Press the “ ” button to scroll down the pages. Press “OK” to select

5

MACHINE MENU.

1

Press the “ ” button to select WATER MENU. Press “OK” to con rm.

6

1

Select HARDNESS option by pressing the “OK” button and set the water

7

hardness value.

ENGLISH

15

15

“INTENZA+” water  lter installation

We recommend you to install the “INTENZA+” water  lter as this prevents
lime scale to build up in your machine and preserves a more intense aroma
to your espresso co ee.

You can purchase separately the INTENZA+ water  lter. Please refer to the
ordering maintenance products chapter in this user manual for further
details.
Water is a crucial part of every espresso, so it’s most important to always
have it professionally  ltered. Using the “INTENZA+” water  lter will prevent
mineral deposits from building up and improve your water quality.

Remove the small white  lter from the water tank and store it in a dry

1

place.

Remove the “INTENZA+” water  lter from its packaging, immerse it ver-

2

tically (with the opening positioned upwards) in cold water and gently
press the sides so as to let the air bubbles out.

Set the  lter according to the measurements performed (see previous

3

chapter) and indicated on the base of the  lter:

A = Soft water – equals 1 or 2 on the test strip
B = Hard water (standard) – equals 3 on the test strip
C = Very hard water – equals 4 on the test strip

Put the  lter into the empty water tank. Press it until it cannot move

4

further down.

16

ENGLISH

2

MENU

BEVERAGE MENU

MACHINE MENU

Fill the water tank up to MAX level with fresh water and reinsert it into

5

the machine.

Place a large container (1,5 lt) under the hot water / steam wand.

6

Press the “MENU” button to access the machine main menu.

7

Press the “ ” button to scroll down the pages. Press “OK” to select

8

MACHINE MENU.

1

2

MACHINE MENU

DISPLAY MENU

WATER MENU

MAINTENANCE

2

WATER MENU

ENABLE FILTER

ACTIVATE FILTER

OK

ACTIVATE FILTER?

ESC

Press the “ ” button to select WATER MENU. Press “OK” to con rm.

9

1

Select ACTIVATE FILTER, and then press “OK”.

10

1

Press the “OK” button to con rm that you want to start the  lter activa-

11

tion procedure.

OK

INSERT FILTER.

FILL THE TANK

OK

PLACE A CONTAINER

UNDER THE

WATER SPOUT

ACTIVATE FILTER

ENGLISH

Press the “OK” button to con rm that you have inserted the water  lter

12

and  lled the water tank.

Press the “OK” button to con rm that a container is placed under the

13

water spout.

The machine starts dispensing water. This page will be displayed. Once

14

the machine stop dispensing, remove the container.

17

17

2

WATER MENU

HARDNESS

ENABLE FILTER

ACTIVATE FILTER

Replacing the “INTENZA+” water  lter

When the “INTENZA+” water  lter needs to be replaced with a new one,
this icon is displayed “

Replace the  lter as described in the previous chapter.

1

The machine is now programmed to manage a new  lter.

2

”.

Note:
If the  lter is already installed and you want to remove - but not replace it,
select the “ENABLE FILTER” option and set it to OFF.

If there is no “INTENZA+” water  lter installed, insert the small white  lter

1

previously removed into the water tank.

18

ENGLISH

ADJUSTMENTS

The machine allows for certain adjustments so that you can brew the best
tasting co ee possible.

Saeco Adapting System

Co ee is a natural product and its characteristics may change according to
its origin, blend and roast. The machine is equipped with a self-adjusting
system that allows the use of all types of co ee beans available on the
market (not for caramelized beans).
The machine automatically adjusts itself after brewing several cups of
co ee to optimize the extraction of the co ee to the compactness of the
ground co ee.

Adjusting the ceramic co ee grinder

Ceramic co ee grinders always guarantee accurate grinding for every
co ee blend and prevent the beans from overheating.
This provides for full aroma preservation, delivering the truly Italian taste in
every cup.

Warning:
The ceramic co ee grinder contains moving parts that may be dange­rous. Therefore, do not insert  ngers and/or other objects. Turn o the
machine by pressing the ON/OFF button and remove the plug from
the socket before carrying out any type of operation inside the co ee
bean hopper.

You can adjust the ceramic grinders to set the co ee grinding to your
personal taste.

Warning:
The grinder adjustment knob, inside the co ee bean hopper, must be
turned only when the ceramic co ee grinder is working.

This adjustment can be carried out by pressing and turning the grinder
adjustment knob inside the co ee bean hopper.

Open the lid of the co ee bean hopper.

1

ENGLISH

Press and turn the grinder adjustment knob one notch at a time. You

2

will taste the di erence after brewing 2-3 cups of espresso.

The reference marks on the co ee bean hopper lid indicate the grind

3

setting. There are 8 di erent grind settings to choose from:

19

19

- Very coarse grind (

To

- Very  ne grind (

When you adjust the ceramic co ee grinder to a  ner setting, your co ee
will taste stronger. For a milder co ee taste, adjust the ceramic co ee
grinder to a coarser setting.

) : lighter taste, for dark roasted co ee blends

) : bolder taste, for light roasted co ee blends

Adjusting co ee crema and intensity (Saeco Brewing System)

The Saeco Brewing System (SBS) allows you to control the co ee crema
and taste intensity by adjusting the co ee  ow speed during the brewing
cycle.

- By turning the dial knob counter clock wise you increase the  ow
speed resulting in a milder co ee intensity and less crema.

- By turning the dial knob clock wise you reduce the  ow speed resul­ting in a stronger co ee intensity and more crema.

Note:

The co ee  ow speed may be adjusted while brewing.

20

ENGLISH

CAPPUCCINO

COFFEE QUANTITY

PREBREWING

COFFEE TEMPERATURE

Adjusting the aroma (co ee strength)

Choose your favorite co ee blend and adjust the amount of co ee to be
grounded until they meet your personal taste. You can also select the pre­ground co ee function.

Note:

Selection must be made prior to selecting co ee.

The machine allows you to adjust the right quantity of ground co ee for
each product. The standard adjustment for each product can be set in the
“BEVERAGE MENU” (see the Beverage Programming chapter, Co ee Quanti­ty option).

To temporarily change the amount of co ee ground, press the “ ”

1

button on the control panel.

The aroma changes by one degree, according to the selected amount:

2

= mild dose
= medium dose
= strong dose
= The beverage is brewed by using the pre-ground co ee

Adjusting the dispensing spout

The height of the dispensing spout can be adjusted to better  t the
dimensions of the cups that you wish to use.

Move the dispensing spout up or down with your  ngers to adjust its
height as shown in the image.

ENGLISH

The recommended positions are:
For the use of small cups;

For the use of large cups;

For the use of latte macchiato cups.

Note:
The dispensing spout can also be removed to allow the use of very large
containers.

21

21

Two cups can be placed under the dispensing spout to brew two cups of
co ee at the same time.

22

ENGLISH

Adjusting the co ee length

The machine allows you to adjust the amount of brewed co ee or milk
according to your taste and the size of your cups.
Each time one of the buttons “

”, “ ” and “ ” is pressed, the machi­ne brews a pre-set amount of product. Each button may be individually
programmed for a speci c brew setting.

STOP

ESPRESSO

ESPRESSO

MEMO

MEMO

The following procedure describes the programming of the “

Place a cup under the dispensing spout.

1

Press and hold the “ ” button until the “MEMO” icon is displayed.

2

Then release the button. The machine is now programming.

The machine starts brewing co ee.

When the “STOP” icon is displayed, press the “ESC” button as soon as

3

the desired amount of co ee is reached.

Now the button “

” is programmed; each time it is pressed, the machine

will brew the same amount of espresso that was just programmed.

” button.

Note:

To program the “

”, “ ” and “ ” buttons, the same steps should be
followed.
You should always use the “ESC” button to stop brewing co ee when the
desired amount of co ee is reached.

You can also adjust the beverage length through the “BEVERAGE MENU”
(see the Beverage Programming chapter, Co ee Length option).

ESPRESSO

ENGLISH

23

23

ESPRESSO, COFFEE AND LONG COFFEE BREWING

Before brewing co ee, make sure that there are no warnings shown on the
display, and that the water tank and co ee bean hopper are  lled.

Espresso, co ee and long co ee brewing using co ee beans

Place 1 or 2 cups under the dispensing spout.

1

Press the “ ” button for an espresso, the “ ” button for a co ee,

2

the “

To brew 1 cup of espresso, co ee or long co ee, press the desired

3

” button for a long co ee.

button once. This page will be displayed.

2 x ESPRESSO

ESPRESSO

STOP

ESPRESSO

STOP

To brew 2 cups of espresso, co ee or long co ee, press the desired

4

button twice consecutively. This page will be displayed.

Note:
In this operating mode, the machine automatically grinds and doses the
correct amount of co ee. Brewing two espressos requires two grinding
and brewing cycles, automatically carried out by the machine.

After the pre-brewing cycle, co ee begins to pour out of the dispen-

5

sing spout.

Co ee brewing stops automatically when the pre-programmed level is

6

reached; it is possible to stop earlier by pressing “ESC” button.

24

ENGLISH

Espresso, co ee and long co ee brewing using pre-ground co ee

This function allows to use pre-ground and deca einated co ee.
With the pre-ground co ee function you can only brew one co ee at a
time.

To select the pre-ground co ee function, press the “ ” button until

1

this icon “

Place a cup under the dispensing spout.

2

” is displayed.

OK

INSERT

GROUND COFFEE

AND PRESS OK

ESC

Press the “ ” button for an espresso, the “ ” button for a co ee,

3

the “

This page will be displayed.

4

Lift the pre-ground co ee compartment lid and add one scoop of

5

” button for a long co ee. The brewing cycle starts.

pre-ground co ee to the compartment. Use only the measuring scoop
supplied with the machine. Then close the pre-ground co ee com­partment lid.

Warning:
Add only pre-ground co ee to the pre-ground co ee compartment.
Other substances and objects may cause severe damages to the ma­chine. Such damages will not be covered by warranty.

OK

INSERT

GROUND COFFEE

AND PRESS OK

ESC

ENGLISH

Press “OK” to con rm and start brewing.

6

After the pre-brewing cycle, co ee begins to pour out of the dispen-

7

25

25

sing spout.

Co ee brewing stops automatically when the pre-programmed level is

8

reached; it is possible to stop earlier by pressing the “ESC” button.

After brewing the product, the machines returns to the main menu.

Repeat the steps described above to brew more co ees using pre-ground
co ee.

Note:
If the OK button to start brewing is not pressed within 30 seconds the
machine will return to the main menu and discharge any inserted co ee
into the co ee grounds drawer.

If no pre-ground co ee is poured into the compartment, only water will be
dispensed.
If the dose is excessive and 2 or more measuring scoops of co ee are used,
the machine will not brew the product. Only water will be dispensed and
any ground co ee will be discharged into the co ee grounds drawer.

26

ENGLISH

MILK CARAFE

This chapter explains how to use a milk carafe to prepare a cappuccino,
latte macchiato or hot milk.

Note:
Before using the milk carafe, clean it thoroughly as described in the chap­ter “Cleaning and Maintenance” chapter.
We recommend to  ll it with cold milk (approx. 5°C). After use, put the cara­fe back in the refrigerator. DO NOT leave the milk out of the refrigerator for
more than 15 minutes.

Warning:
Do not pour any other liquid than water for cleaning or milk into the
carafe.

Filling the milk carafe

The milk carafe needs be  lled before use.

Open the milk carafe dispenser by turning it clockwise until it locks

1

into place.

Press the release buttons and lift the lid.

2

Pour the milk into the milk carafe: the milk level must be between the

3

minimum (MIN) and maximum (MAX) level indicator shown on the
milk carafe.

ENGLISH

Place back the lid and close the milk carafe dispenser by turning it

4

counter clockwise.

The milk carafe is now ready to use.

27

27

C

A
D

B B

Inserting the milk carafe

Slightly tilt the milk carafe and then insert the front part into the ma-

1

chine.

At this stage the carafe holes (A) are lower than the couplings (C). The

2

pins (B) are located at the same height of the guides (D).

28

ENGLISH

E

Push the carafe towards the bottom while rotating at the same time,

3

until it is locked at the (external) drip tray (E).

Caution:
Do not use force while inserting the carafe.

Removing the milk carafe

Close the milk carafe dispenser by turning it counter clockwise.

1

Rotate the carafe upwards until it releases from the (external) drip tray

2

(E).

E

Pull away from the machine until it is completely detached.

3

ENGLISH

Emptying the milk carafe

Open the milk carafe dispenser by turning it clockwise.

1

Press the release buttons to allow the lid removal.

2

Lift the lid. Empty the milk carafe and clean it properly.

3

Note:
After each use, clean the milk carafe as described in the “Cleaning and
Maintenance” chapter.

29

29

30

ENGLISH

CAPPUCCINO BREWING

Warning:
Danger of scalding! Dispensing may be preceded by short sprays of
milk and steam. Risk of burning.
Never seize the carafe handle during the cleaning cycle: risk of scal­ding! Wait until the end of the cycle before removing the milk carafe.

Fill the milk carafe with milk. The level must be between the minimum

1

(MIN) and maximum (MAX) indication on the milk carafe.

Note:
Use cold (~5°C / 41°F) milk with a protein content of at least 3% to ensure
optimum results when preparing a cappuccino. You can use whole milk or
low-fat milk depending on your personal taste.

Place back the milk carafe lid and insert the carafe into the machine.

2

Place a cup under the co ee dispensing spout.

3

CAPPUCCINO

Open the milk carafe dispenser by turning it clockwise.

4

Press the “ ” button to start the brewing process.

5

The machine is heating up.

6

ENGLISH

31

31

PLEASE WAIT …

CAPPUCCINO

STOP

CAPPUCCINO

STOP

Note:
The machine requires more waiting time for heating up if the ECOMODE is
activated. For further details see the chapter MACHINE PROGRAMMING.

When the machine shows the following page, the machine pours

7

frothed milk.

The pouring can be stopped earlier by pressing the “ESC” button.

Once the milk froth has been poured, the machine brews co ee. The

8

brewing can be stopped earlier by pressing the “ESC” button.

Remove the cup and close the milk dispenser by turning it counter

9

clockwise.

Wait a few seconds. The machine starts the automatic cleaning process

10

(see the Cleaning and Maintenance chapter).

When the cleaning cycle is  nished, remove the milk carafe and put it

11

in the refrigerator.

For preparing a hot milk, see chapter SPECIAL BEVERAGES.

32

ENGLISH

CAPPUCCINO

PLEASE WAIT …

CAPPUCCINO

STOP

MEMO

MEMO

Adjusting the cappuccino length

Each time the “ ” button is pressed, the machine brews a pre-set quanti­ty of cappuccino into the cup.
The machine allows you to adjust the amount of cappuccino according to
your taste and the size of your cups.

Fill the milk carafe with milk and install it into the machine.

1

Place a cup under the dispensing spout and open the milk carafe

2

dispenser by turning it clockwise.

Press and hold the “ ” button until the “MEMO” notice appears on

3

the display. Then release the button. The machine is now program­ming.

The machine is heating up.

4

When the machine shows this display, it starts to pour milk froth into

5

the cup. Press the “ESC” button as soon as the desired amount of milk
is reached.

CAPPUCCINO

STOP

MEMO

Once the milk froth has been poured, the machine starts brewing

6

co ee. When the desired co ee quantity is reached, press the “ESC”
button.

Now the “

” button is programmed. Every time it is pressed, the machine

will brew the same amount that has just been set.

Note:
You can also adjust the beverage length through the BEVERAGE MENU (see
the Beverage Programming chapter).

ENGLISH

LATTE MACCHIATO BREWING

Warning:
Danger of scalding! Dispensing may be preceded by short sprays of
milk and steam. Risk of burning.
Never seize the carafe handle during the cleaning cycle: risk of scal­ding! Wait until the end of the cycle before removing the milk carafe.

Fill the milk carafe with milk. The level must be between the minimum

1

(MIN) and maximum (MAX) indication on the milk carafe.

Note:
Use cold (~5°C / 41°F) milk with a protein content of at least 3% to ensure
optimum results when preparing a cappuccino. You can use whole milk or
low-fat milk depending on your personal taste.

33

33

Place back the milk carafe lid and insert the carafe into the machine.

2

Place a cup under the co ee dispensing spout.

3

34

ENGLISH

LATTE MACCHIATO

PLEASE WAIT …

LATTE MACCHIATO

STOP

Open the milk carafe dispenser by turning it clockwise.

4

Press the “ ” button to start the brewing process.

5

The machine is heating up.

6

Note:
The machine requires more waiting time for heating up if the ECOMODE is
activated. For further details see the chapter MACHINE PROGRAMMING.

When the machine shows the following page, the machine pours

7

frothed milk. The pouring can be stopped earlier by pressing the “ESC”
button.

LATTE MACCHIATO

STOP

Once the milk froth has been poured, the machine brews co ee. The

8

brewing can be stopped earlier by pressing the “ESC” button.

Remove the cup and close the milk dispenser by turning it counter

9

clockwise.

Wait a few seconds. The machine starts the automatic cleaning process

10

(see the Cleaning and Maintenance chapter).

When the cleaning cycle is  nished, remove the milk carafe and put it

11

in the refrigerator.

LATTE MACCHIATO

PLEASE WAIT …

MEMO

ENGLISH

35

35

Adjusting the latte macchiato length

Each time the “ ” button is pressed, the machine brews a pre-set quantity
of latte macchiato into the cup.
The machine allows you to adjust the amount of latte macchiato according
to your taste and the size of your cup.

Fill the milk carafe with milk and install it into the machine.

1

Place a cup under the dispensing spout and open the milk carafe

2

dispenser by turning it clockwise.

Press and hold the “ ” button until the “MEMO” icon is displayed.

3

Then release the button. The machine is now programming.

The machine is heating up.

4

LATTE MACCHIATO

STOP

LATTE MACCHIATO

STOP

MEMO

MEMO

When the machine shows this display, it starts to pour milk froth into

5

the cup. Press the “ESC” button as soon as the desired amount of milk
is reached.

Once the milk froth has been poured, the machine starts brewing

6

co ee. When the desired co ee quantity is reached, press the “ESC”
button.

Now the “

” button is programmed. Each time it is pressed, the machine

will brew the same amount that was just programmed.

Note:
You can also adjust the beverage length through the BEVERAGE MENU (see
the Beverage Programming chapter).

36

ENGLISH

SPECIAL BEVERAGES

SPECIAL BEVERAGES

HOT MILK

HOT WATER

STEAM

HOT MILK

HOT WATER

STEAM

SPECIAL BEVERAGES

The machine is designed to brew more products than the ones described
before. For this follow the steps below.

Press the “ ” button to enter the SPECIAL BEVERAGES menu.

1

Select the desired beverage by pressing the “ ” or “ ” scrolling but-

2

ton.

When the desired beverage has been selected, press the “OK” button

3

to start the preparation.

Note:
When you press the “

” button, but do not select a product, the machine

returns to the main menu after 10 seconds.

The Special products function allows you to brew only one beverage at a
time. To brew more beverages, just repeat steps 1-3.

Hot milk

Warning:
Danger of scalding! Dispensing may be preceded by short sprays of
milk and steam. Risk of burning.
Never seize the carafe handle during the cleaning cycle: risk of scal­ding! Wait until the end of the cycle before removing the milk carafe.

Insert the milk carafe and place the cup under the dispensing spout.

1

Open the milk dispenser by turning it clockwise.

SPECIAL BEVERAGES

HOT MILK

HOT WATER

STEAM

ENGLISH

Press the “ ” button to enter the SPECIAL BEVERAGES menu.

2

After selecting “HOT MILK” by pressing the “ ” or “ ” scrolling button,

3

con rm with “OK”.

The machine starts pouring hot milk. The pouring can be stopped

4

earlier by pressing the “ESC” button.

37

37

Hot water dispensing

Warning:
Danger of scalding! Dispensing may be preceded by short sprays of
hot water and steam. Risk of burning. Do not touch the hot water/ste­am wand with bare hands.

Place a container under the hot water/steam wand.

1

38

ENGLISH

SPECIAL BEVERAGES

HOT MILK

HOT WATER

STEAM

Press the “ ” button to enter the SPECIAL BEVERAGES menu.

2

After selecting HOT WATER by pressing the “ ” or “ ” scrolling button,

3

con rm with “OK”.

Hot water is dispensed. The dispensing can be stopped earlier by pres-

4

sing the ”ESC” button.

At the end, remove the container with the desired quantity of water.

5

After dispensing, some water always remains in the lines and this may
result in leaking. This is a normal feature of the machine.

Steam dispensing

Warning:
Danger of scalding! Dispensing may be preceded by short sprays of
hot water and steam. Risk of burning. Do not touch the hot water/ste­am wand with bare hands.

Place a container with the desired product you want to heat under the

1

hot water/steam wand.

Press the “ ” button to enter the SPECIAL BEVERAGES menu

2

SPECIAL BEVERAGES

HOT WATER

STEAM

ENGLISH

After selecting STEAM by pressing the “ ” or “ ” scrolling button,

3

39

39

con rm with “OK”.

Steam is dispensed.

4

Immerse the hot water/steam wand in the product to be heated. The

5

dispensing can be stopped earlier by pressing the ”ESC” button.

BEVERAGE PROGRAMMING

You can program the machine to optimize the co ee taste to your personal
preferences. For each beverage it is possible to customize the settings.

Press the “MENU” button to access the machine main menu.

1

MENU

BEVERAGE MENU

MACHINE MENU

Press the “OK” button to access the BEVERAGE MENU.

2

Note:
By pressing the “

” or “ ” scrolling button, and con rming with “OK” you

can choose the option of your choice.

40

ENGLISH

BEVERAGE MENU

CAFFE’ LUNGO

CAPPUCCINO

LATTE MACCHIATO

CAPPUCCINO

COFFEE QUANTITY

PREBREWING

COFFEE TEMPERATURE

Cappuccino programming

The following procedure describes the programming of a cappuccino.

Below the settings of the each submenu are explained. You can select
these by pressing the “

” or “ ” scrolling button. Con rm your settings

with “OK”.

Press “OK” to select CAPPUCCINO from the beverage menu.

COFFEE QUANTITY

PREBREWING

COFFEE TEMPERATURE

This setting adjusts the amount of co ee which will be ground for bevera­ge brewing.

GROUND COFFEE = The beverage is brewed by using the pre-ground
co ee

MILD = mild dose
MEDIUM = medium dose
STRONG = strong dose

This setting enables the pre-brewing function. During pre-brewing the
co ee is slightly dampened to bring out the aroma in full.

OFF: pre-brewing function is not performed.
LOW: pre-brewing function is active.
HIGH: pre-brewing function is longer in order to bring out the co ee

taste.

This setting adjusts the temperature for co ee brewing.

LOW: low temperature.
NORMAL: medium temperature.
HIGH: high temperature.

ENGLISH

41

41

COFFEE LENGTH

COFFEE LENGTH

MILK QUANTITY

MILK QUANTITY

DEFAULT

By adjusting the bar on the display by pressing the “ ” or “ ” scrolling
button, you can choose the quantity of water used for co ee brewing.
Press “OK” to con rm the adjustment.

By adjusting the bar on the display by pressing the “

” or “ ” scrolling
button, you can choose the quantity of milk to be used for the selected
beverage. Press “OK” to con rm the adjustment.

Note:

The milk managing options are only shown for beverages with milk.

For each beverage it is possible to reset the original factory settings. After
selecting this function, the customized settings are deleted.

BEVERAGE MENU

LATTE MACCHIATO

SPECIAL BEVERAGES

To exit programming, press the “ESC” button one or more times until the
main menu is displayed.

Hot water programming

The following procedure describes the programming of hot water.

Select SPECIAL BEVERAGES from the beverage menu by pressing the

1

” or “ ” scrolling button. Press “OK” to con rm.

“

42

ENGLISH

SPECIAL BEVERAGES

HOT MILK

HOT WATER

STEAM

HOT WATER

WATER QUANTITY

DEFAULT

Select HOT WATER by pressing the “ ” or “ ” scrolling button.

2

Press “OK” to con rm.

WATER QUANTITY

WATER QUANTITY

DEFAULT

MENU

BEVERAGE MENU

MACHINE MENU

By adjusting the bar on the display by pressing the “

” or “ ” scrolling
button, you can choose the quantity of hot water to be dispensed.
Press “OK” to con rm the adjustment.

Reset the original factory settings. After selecting this function, the custo­mized settings are deleted.

MACHINE PROGRAMMING

Press the“MENU” button to access the machine main menu.

1

Select MACHINE MENU by pressing the “ ” or “ ” scrolling button.

2

Press the “OK” to con rm.

GENERAL MENU

ENGLISH

General menu

The general menu allows you to change the operation settings.

43

43

TONE

ECOMODE

STAND-BY SETTINGS

DISPLAY MENU

The TONE function de-/activates the sound feedback.

The ECOMODE enables you to save energy by limiting the boiler activation
to one when the machine starts up. If you want to brew more milk bevera­ges, the heating time may be longer.
The function is set ON by default.

The STAND-BY SETTINGS set the time interval for the machine when to go
into stand-by mode after the last brewing. The stand-by time varies from
15, 30, 60 and 180 minutes.
The default time value is 30 minutes.

Display menu

The display menu allows you to set the language and the display bright­ness.

LANGUAGE

BRIGHTNESS

This setting is important to automatically adjust the parameters of the
machine according to your country.

44

ENGLISH

WATER MENU

Water menu

The WATER MENU allows adjusting water parameters for optimal co ee.

HARDNESS

ENABLE FILTER

ACTIVATE FILTER

Under HARDNESS, you can set the level of water hardness.
To measure water hardness, refer to chapter “MEASURING AND PROGRAM­MING WATER HARDNESS”

By enabling the  lter, the machine noti es the user when the water  lter
needs to be replaced.

OFF: warning disabled.
ON: warning enabled (the warning is automatically set when the  lter is

activated).

To activate the  lter after its installation or replacement. Refer to the chap­ter “INTENZA+ Water Filter Installation”.

MAINTENANCE

ENGLISH

Maintenance menu

The MAINTENANCE MENU allows setting all the functions for correct ma­chine maintenance.

45

45

COUNTERS

BREW GROUP CLEAN

CARAFE CLEANING

DESCALING

CARAFE CLEAN

The COUNTERS function shows how many products have been brewed for
every single type of co ee since the last reset.

The BREW GROUP CLEAN function enables the monthly cleaning of the
brew group (please see chapter “Monthly cleaning of the brew group”).

The CARAFE CLEANING function enables the monthly cleaning of the milk
carafe (please see chapter “Monthly cleaning of the milk carafe”).

The DESCALING function activates the descaling cycle (please see chapter
“Descaling”).

The CARAFE CLEAN function activates the automatic self-cleaning of the
milk carafe. The function is set ON by default.

FACTORY SETTINGS

Factory Setting

Activating the FACTORY SETTINGS will restore all machine settings to
default values. In this case all the personal parameters will be lost.

46

ENGLISH

CLEANING AND MAINTENANCE

Daily cleaning of the machine

Caution:
Timely cleaning and maintenance of your machine is very important
as it prolongs the life of your machine. Your machine gets exposed to
moist, co ee and lime scale continuously!
In this chapter it is described in detail which activities you need to
perform at which frequency. Not doing this will ultimately make
your machine stop working properly. This repair is NOT covered by
your warranty!

Note:

- Use a soft, dampened cloth to clean the machine.

- Do not wash any of its parts in the dishwasher.

- Do not use alcohol, solvents, and/or abrasive objects to clean the
machine.

- Do not immerse the machine in water.

- Do not dry the machine and/or its components using a microwave
and/or standard oven.

Empty and clean the co ee ground drawer and (internal) drip tray daily
with the machine turned on. Please follow the steps below:

Press the button and open the service door.

1

Remove the (internal) drip tray and co ee grounds drawer.

2

ENGLISH

Empty the co ee grounds drawer and wash it with fresh water.

3

Empty and wash the (internal) drip tray and the cover with fresh water.

4

Correctly reinstall all the components.

5

47

47

Insert the tray and the co ee grounds drawer and close the service

6

door.

Note:
If the co ee ground drawer is emptied when the machine is o , the co ee
grounds counter is not reset. In this case the machine might display the
“EMPTY COFFEE GROUNDS DRAWER” message too soon.

Daily cleaning of water tank

Remove the small white  lter or the “INTENZA+” water  lter (if instal-

1

led) from the water tank and wash it with fresh water.

Put the small white  lter back or the “INTENZA+” water  lter (if instal-

2

led) in its housing by gently pressing and turning it at the same time.

Fill the water tank with fresh water.

3

48

ENGLISH

Daily cleaning of the milk carafe: AUTO CLEAN cycle (after each
use)

After each brewing of a milk beverage the machine performs an automatic
cleaning cycle by routing shots of steam through the milk dispenser.

This cycle may also be manually activated by pressing the “
the control panel. This can be done at any time.

Insert the milk carafe into the machine as described in the milk carafe

1

chapter. Close the milk dispenser.

Press the “ ” button to start the cleaning cycle.

2

” button on

Weekly cleaning of the machine

Turn o the machine and unplug it.

1

Take out the (external) drip tray.

2

ENGLISH

Remove the grill and wash it thoroughly.

3

Remove the support under the grill. Wash the support and the drip

4

tray.

Dry, reassemble and reinsert it in the machine.

5

49

49

Remove the dispensing spout and wash it with water.

6

Clean the pre-ground co ee compartment with a brush or a dry cloth.

7

50

ENGLISH

Clean the hot water/steam wand and the display with a dry cloth.

8

Weekly cleaning of the milk carafe

The weekly cleaning is more thorough as it removes any milk residues from
the milk dispenser of the carafe.

The carafe must be removed from the machine and emptied before

1

cleaning.

Open the milk dispenser by rotating it clockwise.

2

Press on the sides and lift the lid.

3

Rotate the handle counter-clockwise to the unlock position up to the

4

” symbol.

“

Remove the connector which is in contact with the machine.

5

Remove the handle with the suction tube.

6

Remove the suction tube.

7

ENGLISH

51

51

Pull out the external  tting.

8

Remove the internal  tting.

9

Clean all the parts thoroughly with lukewarm water.

10

Reassemble the parts following the reverse order.

11

Caution:
Do NOT wash the carafe components in the dishwasher.

52

ENGLISH

Weekly cleaning of the brew group

The brew group should be cleaned every time the co ee bean hopper is
 lled or at least once a week.

Press the button and open the service door.

1

Remove the (internal) drip tray and co ee grounds drawer.

2

To remove the brew group, press the «PUSH» button and pull it by the

3

handle.

Thoroughly wash the brew group with fresh, lukewarm water and

4

carefully clean the upper  lter.

Caution:
Do not use detergent/soap to clean the brew group.

Let the brew group air-dry thoroughly.

5

Thoroughly clean the inside of the machine using a soft, dampened

6

cloth.

Make sure the brew group is in the rest position; the two reference

7

signs must match. If they do no match, proceed as described in step
(8).

ENGLISH

Gently pull down the lever until it is in contact with the brew group

8

base and the two reference signs on the side of the brew group do
match.

Make sure the hook to lock the brew group is in the correct position

9

by  rmly pressing the “PUSH” button until you hear a click. Check if the
hook is at the top end position. If it is not, please try again.

53

53

Insert the brew group in its seat again until it locks into place without

10

pressing the “PUSH” button.

Insert the (internal) drip tray and co ee grounds drawer and close the

11

service door.

54

ENGLISH

BREW GROUP CLEAN

OK

ESC

MAINTENANCE

CARAFE CLEANING

DESCALING

START CARAFE

WASHING?

Monthly cleaning of the milk carafe

In the monthly cleaning cycle we use the Saeco Milk Circuit Cleaner to
keep the entire circuit clean of milk residues. You can purchase separately
the Milk Circuit Cleaner. Please refer to the maintenance products page for
further details.

Select the MAINTENANCE option in the machine menu.

1

Select CARAFE CLEANING and press the “OK” button to con rm.

2

Press the “OK” button to con rm.

3

OK

REFILL

WATER TANK

Fill the tank with fresh water up to the MAX level. Press the “OK” but-

4

ton.

Fill the milk carafe with fresh drinking water up to the MAX level. Pour

5

one milk cleaner bag into the milk carafe and let it dissolve completely.

ENGLISH

Put the lid back on.

6

Rotate the milk dispenser counter-clockwise to the lock position.

7

55

55

Insert the milk carafe into the machine.

8

Place a large container (1,5 lt ) under co ee the dispensing spout.

9

Open the milk dispenser by turning it clockwise.

56

ENGLISH

OK

POUR DETERGENT

INTO CARAFE & FILL

WITH WATER

CARAFE CLEANING

OK

REFILL

WATER TANK

Press the “OK” button to start the cycle. The machine starts dispensing

10

the cleaning solution through the milk dispenser.

This icon is displayed. The bar shows the cycle progress.

11

Warning:
Never drink the solution dispensed during the procedure.

When the machine stops dispensing,  ll the tank with fresh water up to

12

the MAX level. Press the “OK” button to con rm.

Remove the milk carafe and the container from the machine.

13

OK

FILL CARAFE

WITH FRESH WATER

Wash the milk carafe thoroughly and  ll it with fresh water. Insert the

14

milk carafe into the machine. Press the “OK” button to con rm.

Empty the container and place it back under the co ee dispensing

15

spout. Open the milk dispenser by turning it clockwise.

CARAFE RINSING

ENGLISH

The machine starts dispensing water from both the co ee and the milk

16

dispensing spout. The bar shows the cycle progress.

At the end of the cycle, the machine returns to the product brew menu

17

page.

Disassemble and wash the milk carafe as described in the “Weekly

18

cleaning of the milk carafe” chapter.

Monthly lubrication of the brew group

Lubricate the brew group after approximately 500 cups of co ee or once a
month.
You can purchase separately the Saeco grease to lubricate the brew group.
Please refer to the maintenance products page in this user manual for
further details.

57

57

Caution:
Before lubricating the brew group, clean it under fresh water and dry
it, as described in the “Weekly Cleaning of the Brew Group” chapter.

Apply the lubricant evenly on both side guides.

1

58

ENGLISH

Lubricate the shaft too.

2

Insert the brew group in its seat until it locks into place (see “Weekly

3

Cleaning of the Brew Group” chapter).

Insert the (internal) drip tray and co ee grounds drawer and close the

4

service door.

Monthly cleaning of the brew group with “Co ee Oil Remover”

Besides weekly cleaning, we recommend running this cleaning cycle with
the “Co ee Oil Remover” after approximately 500 cups of co ee or once
a month. This operation completes the maintenance process of the brew
group.
You can purchase separately the “Co ee Oil Remover” and the “Maintenan­ce Kit”. Please refer to the maintenance products page for further details.

MAINTENANCE

COUNTERS

BREW GROUP CLEAN

CARAFE CLEANING

Caution:
The “Co ee Oil Remover” tablets are to be used for cleaning only and
do not have a descaling function. For the descaling procedure use the
Saeco descaling solution and follow the procedure described in the
“Descaling” chapter.

Select the “MAINTENANCE” option in the machine menu.

1

Select “BREW GROUP CLEAN”. Press the “OK” button.

2

OK

PERFORM BREW

GROUP CLEANING?

ESC

OK

REFILL

WATER TANK

OK

INSERT GROUP

CLEAN TAB

ENGLISH

Press the “OK” button to con rm.

3

Fill the water tank with fresh water up to the MAX level. Press the “OK”

4

button.

Put a “Co ee Oil Remover” tablet in the pre-ground co ee com-

5

partment. Press the “OK” button.

59

59

OK

PLACE A CONTAINER

UNDER THE

DISPENSING SPOUT

Place a container (1,5 lt) under the co ee dispensing spout.

6

Press the “OK” button to start the cleaning cycle.

60

ENGLISH

BREW GROUP CLEAN

This icon is displayed. The bar shows the cycle progress.

7

Warning:
Never drink the solution dispensed during the procedure.

When the machine stops dispensing, remove and empty the container.

8

Clean the brew group as described in the chapter “Weekly Cleaning of

9

the Brew Group.

Monthly cleaning of the co ee bean hopper

Clean the co ee bean hopper once a month when it is empty with a damp
cloth to remove co ee oil. Thereafter re ll it with co ee beans.

ENGLISH

61

61

DESCALING

The descaling process takes approx. 35 minutes.

Lime scale builds up inside the machine during use. It needs to be remo­ved regularly as it may clog the water and co ee circuit of your machine.
The machine indicates when descaling is needed.

Caution:
Not doing this will ultimately make your machine stop working pro­perly, and in this case repair is NOT covered by your warranty.

Use the Saeco decalci er only. Its formula has been designed to ensure
better machine performance.
You can purchase separately the Saeco decalci er. Please refer to chapter
“Ordering Maintenance Products” for further information.

Warning:
Never drink the decalci er or any products dispensed until the cycle
has been carried out to the end. Never use vinegar as a decalci er.

Note:
During the descaling cycle do not switch o the machine. If this has happe­ned, you need to restart the descaling cycle from the very beginning.

MAINTENANCE

CARAFE CLEANING

DESCALING

CARAFE CLEAN

OK

START DESCALING?

ESC

To execute the descaling cycle, follow the steps below:

In the MACHINE MENU, select the “MAINTENANCE” option.

1

Select “DESCALING” and con rm with “OK” .

2

Note:
If you press the “OK” button by mistake, press the “ESC” button to quit.

Press “OK” button to con rm.

3

62

ENGLISH

OK

DESCALING SOLUTION

OK

EMPTY TRAY UNDER

OK

WITH WATER. INSERT

OK

PLACE A CONTAINER
UNDER HOT WATER &
CARAFE DISP SPOUT

FILL TANK WITH

BREW GROUP

FILL HALF CARAFE

IN BREW. POSITION

Remove the water tank, and if installed, remove the INTENZA+ water

4

 lter. Pour the entire content of the Saeco decalci er.

Then  ll the water tank with fresh water up to the MAX level. Press the

“OK”

button.

Empty the (internal) / (external) drip tray. Press the “OK” button.

5

Fill half the milk carafe with fresh water. Insert the carafe and open the

6

milk dispenser by turning it clockwise. Press the “OK” button.

Place a large container (1,5 lt) under the hot water/steam wand and

7

milk dispenser spout of the carafe. Press the “OK” button.

STEP 1/2 DESCALING

PAUS E

OK

RINSE TANK &

FILL WITH WATER

The machine will start dispensing the descaling solution at intervals.

8

The bar on the display shows the cycle progress.

Note:
To empty the container during the process, the descaling cycle may be
paused by pressing the “ESC” button. To resume the cycle, press the “OK”
button.

The message indicates the end of the  rst step. The water tank needs

9

to be rinsed. Fill the water tank with fresh water up to the MAX level.
Press the “OK” button.

OK

EMPTY TRAY UNDER

BREW GROUP

OK

FILL HALF CARAFE

WITH WATER. INSERT

IN BREW. POSITION

OK

PLACE A CONTAINER
UNDER HOT WATER &
CARAFE DISP SPOUT

STEP 2/2 RINSING

ENGLISH

Empty the (internal) drip tray and place it back. Then, press the “OK”

10

button.

Empty the milk carafe and  ll it with fresh water. Insert it back in the

11

machine. Press the “OK” button.

Empty the container and place it back under the hot water/steam

12

wand and milk dispensing spout of the carafe. Press the “OK” button.

The rinsing cycle is activated. The bar shows the cycle progress.

13

63

63

PAUS E

When the amount of water needed for the rinse cycle has been

14

completely dispensed, the machine automatically ends the descaling
process by showing this display after a short heating up phase.

Remove and empty the container.

15

Disassemble and wash the milk carafe as described in the “Weekly

16

cleaning of the milk carafe” chapter.

Empty the (internal) drip tray and place it back.

17

Place back the “INTENZA+” water  lter into the water tank if it was

18

installed.

64

ENGLISH

The descaling cycle is now complete.

19

Note:
At the end of the descaling cycle, wash the brew group as described in the
“Weekly Cleaning of the Brew Group” chapter.

The rinsing cycle is performed in order to have the circuit cleaned with
a preset amount of water to ensure proper machine performance. If the
water tank is not  lled up to MAX level, the machine might require two or
more cycles.

MEANING OF THE DISPLAY

Help Message Displayed How to Reset the Message

CLOSE

HOPPER DOOR

Close the bean hopper inner cover.

ENGLISH

65

65

ADD COFFEE

INSERT BREW GROUP

INSERT COFFEE

GROUNDS DRAWER

EMPTY COFFEE

GROUNDS DRAWER

CLOSE

FRONT DOOR

REFILL

WATER TANK

EMPTY DRIP TRAY

TURN CARAFE

INTO

BREWING POSITION

ESC

Fill the co ee beans hopper.

The brew group must be inserted into the machine.

Insert the co ee grounds drawer and the internal drip tray.

Empty the co ee grounds drawer.

Note:
The used grounds drawer must be emptied only when the machine
requires it and with the machine on. If you empty the drawer with the
machine turned o it will not record the emptying operation.

Close the service door.

Remove the water tank and  ll it.

Open the service door and empty the internal drip tray.

Warning:
If this operation is performed when the machine is on, it will record
the used grounds drawer emptying and will reset the counter; there­fore, it is necessary to empty the co ee grounds as well.

Open the milk dispenser of the carafe to brew products.
Press the button “ESC” to exit.

TURN CARAFE

INTO

RINSING POSITION

ESC

Close the milk dispenser of the carafe to start the rinsing cycle of the
carafe.
Press the button “ESC” to exit.

66

ENGLISH

Help Message Displayed How to Reset the Message

INSERT CARAFE

ESC

RESTART TO SOLVE

Insert the milk carafe to start brewing. Press “ESC” to exit.

The machine needs to be descaled. Follow the steps described in the
“Descaling” chapter of this manual.
Please note that not descaling your machine will ultimately make it stop
working properly. In this case repair is NOT covered under your warranty.

The machine needs the “INTENZA+” water  lter to be replaced.

Red light  ashes. Press the “ ” button to exit the stand-by mode.

Take note of the code (E xx) shown in the display at the bottom.
Turn o the machine. After 30 seconds, turn it on again. Try this 2 or 3
times.
If the machine does not start, contact the Philips SAECO hotline in your
country and tell them the code shown in the display. You can  nd its
contact details in the warranty booklet by-packed separately or on
www.philips.com/support.

ENGLISH

TROUBLESHOOTING

This chapter summarizes the most common problems you could en­counter with your machine. If you are unable to solve the problem with the
information below, visit www.philips.com/support for a list of frequently
asked questions or contact the Philips Saeco hotline in your country. You
 nd its contact details in the warranty booklet by-packed separately or on

www.philips.com/support.

Machine actions Causes Solutions

The machine does not
switch on.

The drip tray gets  lled
although no water is
drained.

Co ee is not hot enough. The cups are cold. Preheat the cups with hot water or use

No hot water is dispensed. The hot water/steam wand is clog-

The machine is not  lling
the cup.

Co ee has not enough
crema.
(See note)

The milk was not frothed. The Carafe is dirty or not inserted

The machine is not connected to
the electric network.

The power button is set on “0”. Check that the power button is set to

Sometimes water is drained auto­matically by the machine into the
drip tray to manage the rinsing of
the circuits and ensure optimum
machine performance.

Beverage temperature in the pro­gramming menu is set to low.

Cold milk is being added to the
co ee.

ged or dirty.

The machine has not been pro­grammed.

The blend is unsuitable, co ee is
not freshly roasted or the grind is
too coarse.

The co ee beans or the pre­ground co ee are too old.

correctly.

Connect the machine to the electric
network.

“I”.

This is seen as normal machine beha­vior.

the hot water dispenser.

Ensure that the temperature is set to
Normal or High in the beverage pro­gramming menu.

Cold milk will reduce the temperature
of the end product. Therefore please
pre-heat the milk before adding it.

Clean the hot water/steam wand
(please refer to chapter “Cleaning and
maintenance”).
Check if it is clogged by looking into
the spout. Use a pin or needle to make
a hole through the limestone.

Enter the beverage programming
menu and adjust the co ee length set­ting to your liking for every beverage.

Change co ee blend or adjust the
grind as explained in chapter “Adju­sting the Ceramic Co ee Grinder”.

Ensure that fresh co ee beans or pre­ground co ee are being used.

Verify the correct cleaning of the carafe
and its insertion.

67

67

68

ENGLISH

Machine actions Causes Solutions

The machine takes a
long time to warm up or

The machine circuit is clogged by
limescale.

Descale the machine.

the amount of water dis­pensed from the wand is
too little.

The brew group cannot
be removed.

The brew group is out of place. Turn the machine on. Close the ser-

vice door. The brew group automati­cally returns to the initial position.

The brew group cannot be
inserted.

There is a lot of co ee
ground under or on the
brew group.

The machine produces
co ee grounds that are
either too wet or too dry.

The co ee grounds drawer is
inserted.

The brew group is not in rest
position.

Gear is not in initial position. Insert the drip tray with the co ee

The co ee you are using may not
be suitable for automatic machi­nes.

The machine is adjusting the
grinder due to new co ee beans or
pre-ground co ee.

The grinder needs to be adjusted. By adjusting the ceramic co ee grinder,

Remove the co ee grounds drawer
before removing the brew group.

Ensure that the brew group is in
rest position. Both arrows must look
towards each other. Please refer to
chapter “Monthly Lubrication of the
Brew Group” how to do that.

grounds drawer and then close the
service door. Turn the machine on. The
gear automatically returns to the initial
position so the brew group can be
inserted.

It may be necessary to change the type
of co ee or the co ee grinder settings
(please refer to chapter “Adjusting the
ceraminc co ee grinder”).

The machine automatically adjusts
itself after brewing several cups of
co ee to optimize the extraction of
the co ee to the compactness of the
ground co ee.
It may take toup to 2-3 products until
the grinder is adjusted.
This is not a failure of your machine.

the quality of the puck can be adjusted.
When the pucks are too wet, make the
grind coarser.
When the pucks are too dry, make the
grind  ner.
Please refer to chapter “Adjusting the
Ceramic Co ee Grinder”.

Machine actions Causes Solutions

The machine grinds the
co ee beans but no co ee
comes out.
(See note)

Co ee is too weak.
(See note)

Co ee is brewed slowly.
(See note)

Co ee leaks out of the
dispensing spout.

There is no water. Fill the water tank and prime the circuit

(please refer to chapter “Manual rinse
cycle”).

The brew group is dirty. Clean the brew group (“Weekly clea-

ning of brew group” chapter).

This might occur when the machi­ne is automatically adjusting the
dose.

The dispensing spout is dirty. Clean the dispensing spout.

This might occur when the machi­ne is automatically adjusting the
dose.

The co ee is too coarse. Change co ee blend or adjust the

The co ee grind is too  ne. Change co ee blend or adjust the

Circuits are clogged. Perform a descaling cycle.

The brew group is dirty. Clean the brew group (please refer to

The dispensing spout is clogged. Clean the dispensing spout and its

Brew a few co ees as described in
chapter “Saeco Adapting System”.

Brew a few co ees as described in
chapter “Saeco Adapting System”.

grind as explained in chapter “Adju­sting the ceramic co ee grinder”.

grind as explained in chapter “Adju­sting the ceraminc co ee grinder”.

chapter “Weekly cleaning of the brew
group”).

holes.

ENGLISH

69

69

Note:
These problems can be considered normal if the co ee blend has been
changed or if the machine has just been installed. In this case wait until
the machine performs a self-adjusting operation as described in chapter
“Saeco Adapting System”.

70

ENGLISH

ENERGY SAVING

Stand-by

The Saeco full automatic espresso machine is designed for energy saving­proven by the Class A energy label.

After a certain time of inactivity that can be programmed individually (see
chapter “Machine Programming”), the machine turns o automatically. If a
product has been brewed, the machine performs a rinsing cycle.
In stand-by mode, the energy consumption is below 1Wh.

To turn on the machine, press “
the machine is set to “I”). If the boiler is cold the machine performs a rinsing
cycle.

The machine status can be manually changed to stand-by mode by hol­ding the STAND-BY button for 3 seconds.

Note:

The stand-by mode cannot be activated if the service door is left open.

1

When the stand-by mode is activated, the machine may perform a

2

rinse cycle. The cycle can be interrupted by pressing the “STOP” button.

The machine can be turned on again by

pressing any of the control panel buttons.

1

opening the service door (when closing the door the machine goes

2

back to standby mode).

The red light on the “
mode.

” button  ashes when the machine is in stand-by

” button (if power button on the back of

Screen saver

The machine comes with a screen saver to extend the life of the display.
After 5 minutes of inactivity, the machine logo will start  oating.
In this condition, the machine is active and pressing any button will imme­diately activate all functions.

Note:
The screen saver is not activated if a warning signal is active.

ENGLISH

71

71

Disposal

Do not throw away the machine with the normal household waste at the
end of its life, but hand it in at an o cial collection point for recycling. By
doing this, you help to preserve the environment.

- The packing materials can be recycled.

- Machine: unplug the machine and cut the power cord

- Deliver the appliance and power cord to a service center or public
waste disposal facility.

This product complies with EU directive 2002/96/EC.
The symbol on the product or on its packaging indicates that this product
may not be treated as household waste.
Instead it shall be handed over to the applicable collection point for the
recycling of electrical and electronic equipment.
By ensuring this product is disposed of correctly, you will help prevent
potential negative consequences for the environment and human health,
which could otherwise be caused by inappropriate waste handling of this
product. For more detailed information about recycling of this product,
please contact your local city o ce, your household waste disposal service
or the shop where you purchased the product.

72

ENGLISH

TECHNICAL SPECIFICATION

The manufacturer reserves the right to make changes to the technical
speci cations of the product

Nominal Voltage - Power Rating ­Power Supply

Housing material Thermoplastic material

Size (w x h x d) 245 x 360 x 420 mm

Weight 13.4 Kg

Power Cord Length 1200 mm

Control Panel On the front

Size of cup 110mm

Water Tank 1.5 liters – Removable type

Co ee bean hopper capacity 300 gr

Co ee grounds drawer capacity 11

Pump pressure 15 bar

Boiler Stainless steel type

Safety mechanisms Boiler pressure safety valve – Dou-

Safety mechanisms Thermal fuse

See label on the appliance

ble safety thermostat.

GUARANTEE AND SERVICE

Guarantee

For detailed information on your warranty and related conditions, please
read the warranty booklet by-packed separately.

Service

We want to ensure that you remain satis ed with your machine. If not done
already, please register your product on www.philips.com/welcome so
that we can stay in contact with you and send you cleaning and descaling
reminders.

If you need service or support, please visit the Philips website at
www.philips.com/support or contact the Philips Saeco hotline in
your country. You  nd its phone number in the warranty booklet by
packed separately or on www.philips.com/support.

ENGLISH

73

73

ORDERING MAINTENANCE PRODUCTS

For cleaning and descaling, use Saeco maintenance products only.
You can purchase these at the Philips online shop at www.shop.philips.com/
service, your local dealer or at authorised service centers.
If you have any di culties obtaining maintenance products for your machi­ne, please contact the Philips Saeco hotline in your country.
You  nd its contact details in the warranty booklet by-packed separately or
on www.philips.com/support.

Overview of maintenance products

- Decalci er CA6700

- INTENZA+ Water Filter CA6702

- Grease HD5061

- Co ee Oil Remover CA6704

74

ENGLISH

- Milk Circuit Cleaner CA6705

- Maintenance Kit CA 6706
