Philips HD4916 User Guide

HD4916

4 52 3

2 3 4 5

7 8

ENGLISH

4222.200.0238.3

2/12

Introduction

Congratulations on your purchase and welcome to Philips! To fully benet

from the support that Philips offers, register your product at www.philips. com/welcome. The induction cooker works on the basis of an electromagnet that creates

a powerful, high-frequency electromagnetic eld. When cookware consisting

of magnetic material (e.g. iron) is placed on the induction cooker, the

electromagnetic eld transfers energy to the bottom of the cookware,

which causes the cookware and the food inside it to become hot. The amount of heat generated in the cookware is controlled by varying the

strength of the electromagnetic eld. When the strength of the electromagnetic eld is changed, the temperature of the cookware changes

instantly. Advantages of the induction cooker:

Safe: the induction cooker does not make use of an open ame or re.

It also has a number of safety features, which allow you to enjoy cooking with your family whenever you want. Fast: in induction cooking, the cookware serves as the heat source. This

results in much faster and more even heat transfer, shortening the cooking time by more than 1/3 compared to conventional cooking. Versatile: the induction cooker has 2 preset cooking modes, each with

its own optimal heating pattern. These modes allow you to prepare a great variety of nutritious meals. Very user friendly: the simple and interactive control panel and display

allow you to easily adjust the settings at the touch of a button. Comfortable: the induction cooking process is smoke-free and produces

less grease. Moreover, the cooker and the surrounding area stay cool. This allows you to cook in a cool and comfortable environment. Portable: the induction cooker has a compact design and the cooking

plate stays cool. This means the appliance is always safe to use and allows you to cook anywhere in your home.

General description (Fig. 1)

A Crystalite cooking plate B Cooking zone C Body D Control panel E Mains cord F Air inlet G Air outlet

Control panel

1 Display for cooking time and power level 2 Cooking mode buttons with lights for hot pot and stir-fry modes 3 Cooking time button with cooking time light 4 Star t button with start light 5 Power on/off button with power-on light 6 +/- buttons for setting cooking time and power level 7 Power-level indicator light

Important

Read this user manual carefully before you use the appliance and save it for future reference.

Danger

Never immerse the appliance in water or rinse it under the tap.

Do not cover any part of the cooking plate with aluminium foil to

prevent the risk of electric shock, short circuiting or re.

Warning

Check if the voltage indicated on the appliance corresponds to the local

mains voltage before you connect the appliance. The temperature of accessible surfaces may be high when the appliance

operates. Only connect the appliance to an earthed wall socket. Always make

sure the plug is inserted rmly into the socket.

Do not use the appliance if the plug, the mains cord or the appliance

itself is damaged. If the mains cord is damaged, you must have it replaced by Philips, a

service centre authorised by Philips or similarly qualied persons in

order to avoid a hazard. If the surface of the cooking plate is cracked, switch off the appliance

and do not use it anymore to prevent the risk of electric shock. This appliance is not intended for use by persons (including children)

with reduced physical, sensor y or mental capabilities, or lack of experience and knowledge, unless they have been given super vision or instruction concerning use of the appliance by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the

appliance. Keep the mains cord out of the reach of children. Do not let the mains

cord hang over the edge of the table or worktop on which the appliance stands. Make sure the cooking plate is clean and dry before you switch on the

appliance. Do not cover the air outlet while the induction cooker is operating.

Do not plug in the appliance or operate the control panel with wet

hands. Do not touch the cooking plate after cooking, as it retains heat from the

cookware. Metallic objects such as knives, forks, spoons and lids should not be

placed on the cooking plate since they can get hot.

Caution

Never use any accessories or parts from other manufacturers or that

Philips does not specically recommend. If you use such accessories or

parts, your guarantee becomes invalid. Do not expose the induction cooker to high temperatures, hot gas,

steam or damp heat. Do not place the induction cooker on or near an operating or still hot stove or cooker. Always switch off the appliance before you unplug it.

Always unplug the appliance and let it cool down before you clean it.

This appliance is intended for indoor household use only. If the

appliance is used improperly or for professional or semi-professional purposes or if it is not used according to the instructions in the user manual, the guarantee becomes invalid and Philips will not accept liability for any damage caused. Place the induction cooker on a stable, horizontal and level surface and

make sure there is at least 10cm free space around it to prevent overheating. Do not operate the appliance on a plastic tablecloth.

Do not place anything between the cookware and the cooking plate.

The maximum weight that can be put on the induction cooker is 7kg.

Beware of hot steam that comes out of the cookware during cooking

or when you remove the lid. Do not lift and move the induction cooker while it is operating.

Never put empty cookware on the switched-on induction cooker, as

this could cause the cookware to become distorted or the heating coil to become damaged.

Do not store ammable materials and liquids near or on the induction

cooker. Avoid hard contact between the cookware or other objects and the

crystalite cooking plate. Always place the cookware on the cooking zone during cooking.

Never connect this appliance to an external timer switch or remote

control system in order to avoid a hazardous situation. Do not use cookware with a bottom diameter of more than 16cm to

deep-fry food, as this causes the appliance to malfunction.

Automatic shut-off

The appliance is equipped with automatic shut-off. It switches off automatically in two situations:

In the hot pot mode and manual mode, the appliance switches off

automatically if you do not press any button for 60 minutes. If there is no cookware or unsuitable cookware on the cooking place

when you press the start button or if you remove cookware from the cooking plate during cooking, the cooker beeps continuously, the display shows ‘----’. The cooker automatically switches off after 1 minute unless you put the cookware back onto the cooking plate within this minute.

Electromagnetic elds (EMF)

This Philips appliance complies with all standards regarding electromagnetic

elds (EMF). If handled properly and according to the instructions in this user manual, the appliance is safe to use based on scientic evidence

available today.

Before first use

Remove all packaging material from the induction cooker.

Preparing for use

1 Place the appliance on a dry, stable and level surface.

2 Make sure there is at least 10cm free space around the appliance to

prevent overheating.

3 Always place the cookware on the cooking zone during cooking.

4 Make sure you use cookware of the correct type and size (see the

tables below).

Recommended types and sizes of cookware

4222.200.0238.3

3/12

Suitable cookware for the induction cooker

Material Cookware with a bottom made of iron or magnetic

stainless steel

Shape Cookware with a at bottom

Size Cookware with a bottom diameter of 12-20cm,

depending on the cooking mode (see tips below)

Weight Cookware with a weight of up to 7kg (including

contents)

Cookware NOT suitable for the induction cooker

Material Cookware with a bottom made of non-iron metal,

crystalite, glass, aluminium and copper

Shape Cookware with a concave or convex bottom

Size Cookware with a bottom diameter of less than 11cm

Weight Cookware with a weight over 7kg (including contents)

Tip: When you cook in the manual mode or hot pot mode, you can use cookware with a bottom diameter of 12-20cm.

Tip: To deep-fry food, we advise you to use cookware with a bottom diameter of 12-16cm.

Using the appliance

Only use cookware that is suitable for induction cooking (see chapter ‘Preparing for use’).

Note: Always place and use the appliance on a dry, stable and level surface.

The tables below shows the default settings in the different cooking modes and to what extent these default settings can be adjusted.

Default and adjustable settings

Mode Default

power level

Default cooking time

Adjustable power level

Adjustable cooking time

Display indications

Manual 4 5 1-7 5-180 Power level

Remaining cooking time (if cooking time is set)

Hot

7 - 1-7 - Power level

pot

Stir fry 6 30 1-7 5-60 Power level

Remaining cooking time (if you press cooking time button)

Note: If you want to boil water quickly, simply set to manual mode and set the power level to 7. The suggested boiling time for 1 litre is 3-5 minutes, for 2 litres 6-10 minutes and for 3 litres 9-14 minutes.

The appliance produces a 2-second beep and the power-on light goes

on. The display shows the default power level (4) (Fig. 3).

2 Place the cookware on the cooking zone.

3 Press the start button to operate the appliance manually or press the

button of the preset mode you want to use (Fig. 4). The indicator light above the preset mode button goes on.

If you select one of the preset modes, the appliance is set to the

default settings for manual operation (5 minutes cooking time and a power level of 4) or to the default settings of the selected preset mode.

Note: Before you press the start button to conrm the selected mode, you can

still switch to another mode. If you want to switch to a different mode after you have pressed the start button, you have to switch off the appliance by pressing the power on/off button. Then press the power on/off button again to switch the appliance back on and select the desired mode.

4 If you want to start cooking at the default setting of the selected

preset mode, continue with step 7.

See the default settings and cooking time table above for the default settings in the different cooking modes.

5 If you want to adjust the power level, press the + and -

buttons. (Fig. 5) The power level indicator light goes on.

Note: You can also adjust the power level during cooking.

6 If you want to adjust the cooking time, press the cooking time button

and then adjust the time with the + and - buttons (Fig. 6). The cooking time light goes on.

Note: When you press the + and - buttons briey, the time increases or

decreases by 1 minute. When you press the buttons longer, the time increases or decreases by 5 minutes.

Note: You can also adjust the cooking time during cooking.

Note: You cannot adjust the cooking time in hot pot mode.

7 Press the start button (Fig. 7).

The start light goes on.

The induction cooker automatically starts operating according to the

selected mode.

Note: If you have not adjusted the cooking time or power level, the induction cooker starts operating at the default settings of the manual mode or preset mode.

During cooking, the fan switches on to keep the appliance cool. When

you switch off the appliance, the fan remains on for approx. 1 minute and then switches off automatically. If you have adjusted the power level, the display shows the set power

level. If you have adjusted the cooking time in manual mode, the display

shows the remaining cooking time. During cooking in hot pot mode, the display only shows the power

level. You cannot adjust the cooking time in this mode. If you have adjusted the cooking time in stir-fry mode, the display still

shows the power level. To view the remaining cooking time, press the cooking time button When the cooking time has elapsed, the appliance beeps a few times.

The appliance automatically switches off and the power-on light goes out.

8 Unplug the appliance after use.

Power level settings

Low Mid High

Power

1 2 3 4 5 6 7

level

400 800 1200 1400 1600 1800 2000

wattage

(W)

Using the different modes

You can simply operate the appliance manually or you can choose one of the two preset cooking modes.

1 Put the mains plug in the wall socket and press the Power on/off

button to switch on the appliance. (Fig. 2)

Cleaning and maintenance Cleaning

Never immerse the appliance in water nor rinse it under the tap.

Never use scouring pads, abrasive cleaning agents or aggressive liquids such as petrol or acetone to clean the appliance.

Do not put vinegar on the crystalite cooking plate.

1 Unplug the appliance and let it cool down.

2 Clean the appliance with a damp cloth and if necessary, with some

mild cleaning agent.

Maintenance

Improper use can lead to scratches on the cooking plate. To avoid discolouring and scratches, use the appliance according to the instructions in

this user manual and always clean the appliance and cookware properly

4222.200.0238.3

4/12

after use.

Storage

Do not place heavy objects on the crystalite cooking plate as it is breakable.

Do not store the appliance in a hot place, for example near a cooker.

If you are not going to use the appliance for a longer period of time, we advise you to store the appliance in a dry and safe place.

Environment

Do not throw away the appliance with the normal household waste at

the end of its life, but hand it in at an ofcial collection point for

recycling. By doing this, you help to preserve the environment (Fig. 8).

Guarantee and service

If you need service or information or if you have a problem, please visit the Philips website at www.philips.com or contact the Philips Consumer Care

Centre in your country (you nd its phone number in the worldwide guarantee leaet). If there is no Consumer Care Centre in your country, go

to your local Philips dealer.

Troubleshooting

If your induction cooker does not function properly or if the cooking quality

is insufcient, consult the table below. If you are unable to solve the

problem, contact a Philips ser vice centre or the Customer Care Centre in your country.

Problem Solution

The power-on light does not go on.

There is a connection problem. Check if the induction cooker is connected to the mains and if the plug is

inserted rmly into the wall socket

The light is defective. Take the appliance to your Philips dealer or a service centre authorised by Philips.

When I press a

cooking mode

The light is defective. Take the appliance to your Philips

dealer or a service centre authorised by Philips. button, the onlight of the selected mode does not go on.

The cooking time light does not go on when

You have selected the hot pot cooking mode. You can

only adjust the cooking time in the manual mode and

in the stir-fr y mode. I set the cooking time.

The light is defective. Take the appliance to your Philips

dealer or a service centre authorised by Philips.

The appliance beeps continuously.

You have put unsuitable cookware on the cooking

plate or you have removed the cookware from the

cooking plate during cooking. Place suitable cookware

on the cooking plate.

I cannot switch to a different cooking mode during cooking.

You cannot switch to a different cooking mode during

cooking. If you want to select a different cooking

mode, press the power on/off button to switch off the

cooker. Then press the power on/off button again to

switch the cooker back on.

The fan works but the appliance has not started cooking.

You have to press the start button within 1 minute

after you press the power on/off button.If you do not

press the start button within 1 minute, the induction

cooker switches off and the fan continues to work for

1 minute to cool down the appliance.

Codes on the display

---- There is no

Message What you should do

Place suitable cookware on the

cookware on the

cooking plate. cooking plate or the cookware is not suitable for the induction cooker.

E1 Unstable voltage

in power supply

Check if the voltage in your home is

suitable for the induction cooker. network

Codes on the display

E2 The cooking

Message What you should do

Switch off the appliance and unplug it. plate has overheated.

Let it cool down for approx. 10

minutes and then switch on the

appliance again.

E3 The appliance

malfunctions

Take the appliance to a Philips dealer

or a service centre authorised by

Philips.

E4 The appliance

has overheated

Check if the air outlet is covered. If so,

remove the object covering the air

outlet and let the appliance cool down.

Then switch on the appliance again.

If the air outlet is not covered, check if

the fan works. Switch on the appliance

and press the Start button. If the fan

does not work, take the appliance to

your Philips dealer or a service centre

authorised by Philips.

Recipes Stir-fried mushroom with bell pepper

Preparation time: 30 minutes Ingredients:

120g fresh mushrooms

1 bell pepper

2 pieces spicy dried bean curd

30g fresh lily bulb

2 tablespoons oil

1 tablespoon nely chopped garlic

Some salt and white pepper

Some sesame oil

1 Clean the mushrooms with kitchen towel.

2 Remove the seeds of the bell pepper and cut into wedges.

3 Clean the dried bean curd and shred into thin pieces.

4 Divide the fresh lily bulb into pieces.

5 Heat the oil in the stir-fry mode (see chapter ‘Using the appliance’,

section ‘Using the different modes’) and stir-fry the garlic until fragrant.

6 Add the mushrooms and dried bean curd and stir.

7 Add the bell pepper and lily bulb. Season with salt, white pepper and

sesame oil to taste.

Diced chicken with red and green peppers

Preparation time: 30 minutes Ingredients:

2 chicken breasts

2 red and green peppers

1 tablespoon soy sauce

some salt

1 tablespoon sugar

some vinegar

1 bowl cornstarch water

some sliced scallions, ginger and garlic

some chicken stock

some oil

some sesame oil

1 Dice the chicken breasts and peppers (green and red).

2 Mix the chicken dices properly with salt and cornstarch water.

3 Heat the oil in the stir-fry mode (see chapter ‘Using the appliance’,

section ‘Using the different modes’). Put the chicken dices in the wok and separate them with chopsticks.

4 Put in the green and red pepper dices and stir-fry thoroughly. Then

empty the wok into a strainer.

5 Put the chicken and pepper dices in the wok again. Add various

condiments and cornstarch to thicken.

6 Stir-fry evenly and sprinkle with sesame oil to taste.

Sweet and sour minced beef

Preparation time: 30 minutes. Ingredients:

+ 8 hidden pages
