Philips HD4482 User Manual

waffle maker

Belgian style

HD4482

10. Do not place on or near a hot gas or electric
burner, in heated oven or in a microwave.

11. This appliance is intended for household use ONLY;
it is not for commercial or industrial use.

12. Any service of the Waffle Maker should be performed
by the retail location where it was purchased.

13. Do not operate while unattended. Unplug after each use.

14. When using this appliance, provide adequate air space
above and on all sides for air circulation. On surfaces
where heat may cause a problem, an insulated hot pad
is recommended.

15. Extreme caution must be used when moving an
appliance containing hot oil or hot batter or liquid.

16. To disconnect appliance, allow the green indicator
light to go OFF and then grasp plug body and remove
plug from electrical outlet. Never yank or twist cord
to unplug.

SAVE THESE
INSTRUCTIONS

SPECIAL INSTRUCTIONS

The Waffle Maker has a short cord to reduce the hazards
of becoming entangled in or tripping over a longer cord.
An extension cord may be used if the rating is equal to or
greater than the rating of the Waffle Maker. Use an
extension cord rated 13 amperes or greater. Care must be
taken to arrange extension cord so that it will not drape
over countertop or tabletop where it can be pulled on by
children or tripped over unintentionally.

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions
should always be followed including the following:

Read all instructions before using.

1. Do not touch hot surfaces. Use handles or knobs.

2. To protect against electrical shock, do not immerse
cord, plug, or Waffle Maker in water or other liquid.

3. Close supervision is necessary when any appliance is
used by or near children.

4. Unplug from outlet when not in use and before
cleaning.Allow to cool completely before putting
on or taking off parts and before cleaning appliance.

5. Do not operate this appliance with a damaged cord
or plug, if it is not working properly, if it has been
dropped or damaged, or dropped into water. Return
the Waffle Maker to the retail location where it was
purchased for examination, repair, or adjustment.

6. To avoid the risk of electrical shock, do not
disassemble. Incorrect reassembly can cause a risk
of electrical shock when Waffle Maker is used.

7. Use this appliance only for its intended use as
described in this manual. Do not use accessories or
attachments not recommended by Philips Electronics
North America Corporation as they may cause fire,
electric shock or injury.

8. Do not use outdoors or operate where oxygen is
being administered or in the presence of explosive
and/or flammable fumes.

9. Do not let cord hang over edge of table or counter,
or touch hot surfaces. Let the Waffle Maker cool
completely before moving it on or off the counter,
before cleaning or before putting away.

Table of Contents

Features 2

Before First Use 3

Helpful Hints 3

How to Make Waffles 3-4

Cleaning 4

Recipes 5-6

For Assistance 7

Warranty Back Cover

Operating the Waffle Maker and another appliance at the
same time from the same electrical circuit could cause an
electrical overload condition, which would blow the fuse
or trip the circuit breaker.

SPECIAL POLARIZED
PLUG INSTRUCTIONS

This Philips Waffle Maker has a polarized plug for an
added safety feature.

• Plug will fit into polarized outlet only one way.

• If plug does not properly fit outlet at first, reverse it.

• If plug still does not fit, contact a qualified electrician.

DO NOT ATTEMPT TO DEFEAT
THIS SAFETY FEATURE

Before First Use

Before using for the first time, the baking surfaces should be cleaned
with a moist cloth. DO NOT IMMERSE UNIT IN WATER.
We recommend lightly greasing the baking surfaces when using for
the first time.This will not be necessary on subsequent occasions.
The first set of waffles should not be eaten.

Helpful Hints

1 Always preheat the Waffle Maker before baking. Plug the

Waffle Maker in first, and prepare the batter while the Waffle
Maker is heating.

2 If you wish to have lighter toasted waffles, remove them before

the green ready indicator light goes off (after approximately 4
minutes). Or if you prefer darker toasted waffles, leave them in
a little longer time.

3 If the lid resists lifting, allow the waffles to bake a little longer,

then try lifting the lid again.

4 If the waffles stick to the top cooking plates, remove them

using a plastic or wooden spatula only. Do not use sharp or
metal utensils as they may damage non-stick coating.

5 Let waffles cool slightly before eating to avoid possible burns.

6 Top baked waffles with different fruits or ice cream to create

your own specialties.

OHow to Make Waffles

1 Plug cord into 120V AC electrical outlet.The red power

light comes on.

2 Close the Waffle Maker and prepare batter while the Waffle

Maker is heating.

3 The green indicator light will come on when Waffle Maker

reaches proper temperature (after about 5 minutes).The Waffle
Maker is ready for baking.
CAUTION: Touch unit only by the latch or handles during use
or directly after using. Be careful not to touch hot surfaces.

C

4 Open the appliance and pour waffle batter onto the center of

each section of the lower baking plate, being careful not to
overfill. Close the appliance carefully and lock the two handles
with the latch.
Do not force shut. Steam may be ejected from between the
grids.The green indicator light may cycle on and off during
cooking as the thermostat maintains the unit at the proper
cooking temperature.

32

Features

Green Ready
Indicator Light

Red Power Light

Latch

Handles

• Non-stick coating on baking plate surfaces

• Thermostatically Controlled

• Cool Touch Latch

• Cord Storage

54

NOTE:

• Care must be taken to ensure that fingers do not come into
contact with the baking grids.

• Bake only with top cover closed.

5 Your waffle will be baked in approximately 4 minutes or longer

according to your personal taste. When baking is finished, open
the Waffle Maker and remove the waffles using a plastic or
wooden spatula. Never use a metal knife as this may damage
the non-stick coating.

6 The appliance should be kept closed in-between the baking of

successive waffles to maintain optimum temperature.

7 After use, allow green indicator light to go off and then unplug

cord from electrical outlet.

. least 1˝ (3 cm) from heating elements.

Cleaning

• Unplug cord from electrical outlet before cleaning and allow the

appliance to cool completely before cleaning or storing.

• Never dip the appliance into water or hold it under running water.

• Wipe down the unit with a moist cloth only.

• Clean the baking surfaces after they have cooled completely with

a moist cloth or with a very soft cloth. Wipe dr y before storing.

• To remove baked-on batter, use a nylon pad or non-abrasive

cleanser.

• Never use sharp or pointed objects or any abrasive cleaning agents

for cleaning purposes as they will damage non-stick coating.

Never immerse the appliance in water or other liquid.

• Store appliance in closed position. Unit stands on end for convenient

storage. Loop cord around cord wrap on the bottom of the unit.

Recipes

NOTE:

• In order to achieve even results, all ingredients should be at room
temperature before preparing the batter.

• Pour about 2/3 cup of waffle batter onto center of bottom hot grids.

Breakfast Waffles

3 egg yolks
a bare 1-1/2 cup (3/8 liter) milk
1 cup (250 grams) flour
2 teaspoons baking powder
3 teaspoons sugar
1/2 teaspoon salt
8 tablespoons oil
3 egg whites

Mix egg yolks and milk.Add flour, baking powder, sugar, salt and
mix well.Add the oil. Beat egg whites until stiff and then fold
into the batter.

Buttermilk Waffles

1/2 cup (1 stick) (125 grams ) softened butter
1/4 cup (50 grams ) sugar
1/8 teaspoon vanilla sugar
pinch of salt
4 eggs
1 cup (250 grams ) flour
1 teaspoon baking powder

1 cup (1/4 liter ) buttermilk

Cream the soft butter, sugar,vanilla sugar and salt. Mix in the eggs
one by one. Mix flour and baking powder and add these together
with the buttermilk to the other ingredients. Mix thoroughly to
an even batter.

Sponge Waffles

5 egg yolks
5 tablespoons hot water
1/3 cup (100 grams ) sugar
grated rind of one lemon
2/3 cup (150 grams ) flour
1/2 teaspoon baking powder
5 egg whites

Cream the egg yolks, water,sugar and lemon rind. Mix the flour and
baking powder together and stir them into the other ingredients.
Beat the egg whites until stiff and fold into the batter.

C

76

Vanilla Waffles

1 3/4 sticks (14T) (200 grams ) softened butter
1/4 cup (50 grams ) sugar
1/8 teaspoon vanilla
pinch of salt
6 eggs
1-1/4 cup (300 grams ) flour
2 teaspoons baking powder
1 cup (1/4 liter ) milk
1 tablespoon rum

Cream the butter, sugar,vanilla and salt. Mix the flour and
baking powder and add these together with the milk and eggs
bit by bit, stirring continuously. Finally stir in the rum.

Cheese Waffles

6 tablespoons (100 grams ) butter
8 egg yolks
1/2 teaspoon salt
2 cups (500 grams ) flour
1/2 teaspoon baking powder
1/4 cup (50 grams ) grated Parmesan cheese
8 egg whites

Cream the butter. Mix the flour and baking powder. Add one after
another: the egg yolks, salt,flour and cheese. Then fold in the stiffly­beaten egg whites.

Traditional Waffles

2 eggs
2 cups all-purpose flour
1/2 cup vegetable oil or 1/2 cup (1 stick) margarine or butter, melted
1-3/4 cups milk
1 tablespoon granulated or brown sugar
4 teaspoons baking powder
1/4 teaspoon salt

Beat eggs with wire whisk or hand beater in medium bowl until
fluffy. Beat in remaining ingredients just until smooth.

For assistance

For assistance call toll free:

1-800-243-7884
or visit our website: www.philipsonline.com.

FULL ONE YEAR WARRANTY

Philips Electronics North America Corporation warrants each new
Philips product, model HD4482 (except cord), against defects in materi­als or workmanship for a period of one year from the date of purchase.

IMPORTANT: This warranty does not cover damage resulting
from accident, misuse or abuse, lack of reasonable care, the affixing
of any attachment not provided with the product or loss of parts or
subjecting the product to any but the specified voltage.*

PHILIPS ELECTRONICS NORTH AMERICA CORPORATION
WILL NOT PAY FOR UNAUTHORIZED SERVICE OF ANY
TYPE.

NO RESPONSIBILITY IS ASSUMED FOR ANY SPECIAL,
INCIDENTAL OR CONSEQUENTIAL DAMAGES.

In order to address warranty issues, simply take or ship the product
back to the retail location where it was purchased.

* Read enclosed instructions carefully.

Manufactured for:
Norelco Consumer Products Company
A Division of Philips Electronics North America Corporation
1010 Washington Blvd., Stamford, CT 06912-0015

For Assistance call 1-800-243-7884

MADE IN CHINA.

This symbol on the product’s nameplate means

it is listed by Underwriters’ Laboratories, Inc.

PHILIPS and Philips Shield are Registered Trademarks of Koninklijke
Philips Electronics N.V.

© 2000 Philips Electronics North America Corporation.
All Rights Reserved.

HD4482

4222.001.9327
