CAUTION
Use of controls or adjustments or
performance of procedures other than
herein may result in hazardous
radiation exposure or other unsafe
operation.
2
![](/html/6c/6c55/6c552f010b21ed2f4df1f9271ccae32188d4388e5f5f0b05d13b2b03f1fd6908/bg5.png)
Index
English ------------------------------------------------ 6
-------------------------------------------------------- 26
English
5
![](/html/6c/6c55/6c552f010b21ed2f4df1f9271ccae32188d4388e5f5f0b05d13b2b03f1fd6908/bg6.png)
Contents
English
General Information
Environmental information ................................ 7
Supplied accessories ............................................ 7
Safety information ................................................ 7
Preparations
Rear connections .......................................... 8 – 9
Optional connection ........................................... 9
Inserting batteries into
the Remote Control ............................................ 9
Controls
Controls on the system and remote
control ............................................................ 10-11
Radio Reception
Tuning to radio stations .................................... 19
Ta pe Operation/Recording
Ta pe playback ...................................................... 19
General information on recording ................. 20
Synchro start CD recording ............................ 20
Recording from the radio................................. 20
Clock/Timer
View clock............................................................ 21
Clock setting ....................................................... 21
Timer setting ................................................. 21-22
Sleep timer setting ............................................. 22
Basic Functions
Switching the system on ................................... 12
Power-saving automatic standby ..................... 12
Adjusting volume and sound............................ 12
Dimming the system’s display .......................... 12
CD/VCD/MP3-CD Operation
Discs for Playback .............................................. 13
Playing a disc ........................................................ 14
Selecting a different track ................................. 14
Finding a passage within a track ...................... 14
Different play modes:
SHUFFLE and REPEAT ...................................... 14
Text display and ID3 Text ................................. 15
Programming the disc tracks ........................... 15
Erasing the program ............ .............................15
Playing a mixed mode disc ............................ 15
VIDEO CD
Adjusting the TV System................................... 16
OSD – On Screen Display ............................... 16
Playing a Video CD with PBC .......................... 16
Return ................................................................... 16
Digest .................................................................... 17
A-B Repeat .......................................................... 17
Go To .................................................................... 17
Resume ................................................................. 17
Slow ....................................................................... 17
Microphone Mixing ............................................ 18
Vocal ...................................................................... 18
Key Control ......................................................... 18
Echo ....................................................................... 18
Specifications ........................................... 23
Maintenance.............................................. 24
Tr oubleshooting ............................. 24–25
6
![](/html/6c/6c55/6c552f010b21ed2f4df1f9271ccae32188d4388e5f5f0b05d13b2b03f1fd6908/bg7.png)
General Information
IMPORTANT!
PLEASE NOTE THAT THE VOLTAGE
SELECTOR LOCATED AT THE REAR OF
THIS SYSTEM IS PRESET AT 220V FROM
THE FACTORY. FOR COUNTRIES THAT
OPERATE AT 110V-127V, PLEASE ADJUST
TO 110V-127V BEFORE YOU SWITCH ON
THE SYSTEM.
Environmental Information
All unnecessary packaging has been omitted. We
have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene (bags,
protective foam sheet).
Your system consists of materials which can be
recycled and reused if disassembled by a
specialized company. Please observe the local
regulations regarding the disposal of packaging
materials, exhausted batteries and old
equipment.
Supplied accessories
– Remote control
– MW loop antenna
– One Video cinch cable
–2 speaker boxes
–AC adapter (not for all versions)
Safety Information
● Before operating the system, check that the
operating voltage indicated on the typeplate (or
the voltage indication beside the voltage
selector) of your system is identical with the
voltage of your local power supply. If not, please
consult your dealer.
● Place the system on a flat, hard and stable
surface.
● Place the system in a location with adequate
ventilation to prevent internal heat build-up in
your system. Allow at least 10 cm (4 inches)
clearance from the rear and the top of the unit
and 5 cm (2 inches) from each side.
● The ventilation should not be impeded by
covering the ventilation openings with items,
such as newspapers, table-cloths, cur tains, etc.
● Do not expose the system, batteries or discs to
excessive moisture, rain, sand or heat sources
caused by heating equipment or direct sunlight.
● No naked flame sources, such as lighted candles,
should be placed on the apparatus.
● No objects filled with liquids, such as vases, shall
be placed on the apparatus.
● The apparatus shall not be exposed to dripping
or splashing.
● Install this unit near the AC outlet and where the
AC power plug can be reached easily.
● If the system is brought directly from a cold to a
warm location, or is placed in a very damp room,
moisture may condense on the lens of the disc
unit inside the system. Should this occur, the CD
player would not operate normally. Leave the
power on for about one hour with no disc in the
system until normal playback is possible.
● The mechanical par ts of the set contain self-
lubricating bearings and must not be oiled or
lubricated.
● When the system is switched to Standby
mode, it is still consuming some power.
To disconnect the system from the
power supply completely, remove the AC
power plug from the wall socket.
English
7
![](/html/6c/6c55/6c552f010b21ed2f4df1f9271ccae32188d4388e5f5f0b05d13b2b03f1fd6908/bg8.png)
Preparations
Fix the claw
to the slot
1
2
3
MW ANTENNA
English
MW loop
antenna
Speaker
(right)
A
AC power cord
B
AM ANTENNA
FM ANTENNA
AUX/CDR
R L
LINE OUT
R
SPEAKERS 6Ω
L
FM wire
antenna
C
–
+
VIDEO OUT
D
110V127V
220V240V
VOLTAGE
SELECTOR
Television
Cr
Cb
Y
L
IN
R
IN
Speaker
(left)
Rear connections
The type plate is located at the rear of the
system.
A Power
Before connecting the AC power cord to the
wall outlet, ensure that the following are done;
– If your system is equipped with a
Voltage Selector, set the VOLTAGE
SELECTOR to the local power line
voltage.
– All other connections have been made.
WARNING!
–For optimal performance, use only the
original power cable.
–Never make or change any connections
with the power switched on.
To avoid overheating of the system, a safety
circuit has been built in. Therefore, your
system may switch to Standby mode
automatically under extreme conditions. If
this happens, let the system cool down
before reusing it (not available for all versions).
8
110V127V
220V240V
B Antennas Connection
MW Antenna
Connect the supplied MW loop antenna to the
“AM antenna” terminal. Adjust the position of
the antenna for optimal reception.
VOLTAGE
SELECTOR
● Position the antenna as far as possible from a TV,
VCR or other radiation source.
FM Antenna
It is unnecessary to connect the FM pigtail
antenna since it is fixed to the main unit.
