PHILIPS
FW338C Mini HiFi System
0 II G 0 Q D 0
FW62C i —
-------------------------
'*3 3
MAGNÂVOX
5*8 4 * !
Owner's Manual
Mode d'emploi
Instructivo de manejo
Toll Free Help Une
Ligne d'assistance en service libre
Línea de ayuda telefónica sin cargo
800-53I-0039
Return your Warranty Registration card today to
ensure you receive all the benefits you’re entitled to.
' Once your Philips Magnavox purchase is registered, you’re eligible
to receive all the privileges of owning a Philips Magnavox product
^Warranty i
Verification
Registering your product within 10 days
confirms your right to maximum protection
under the terms and conditions of your
Philips Magnavox warranty.
Know these
A
A
0
This “bolt of lightning” indicates uninsulated material
within your unit may cause an electrical shock. For the
safety of everyone in your household, please do not
remove product covering.
The “exclamation point” calls attention to features for
which you should read the enclosed literature closely to
prevent operating and maintenance problems.
symbols
• So complete and return die Warranty Registration Card enclosed
with your purchase at once. And take advantage of these
Important benefits.
^ Owner I
Confirmation
Your completed Warranty Registration
Card serves as verification of ownership in
the event of product theft or loss.
RISK OF ELECTRIC SHOCK
A
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER.SERVICEABLE PARTS
INSIDE. REFER SERVICING TO CUAUHED SERVICE PERSONNEL
DO NOT OPEN
A
WARNING: to prevent fire or shock
HAZARD, DO NOT EXPOSE THIS EQUIPMENT TO RAIN
OR MOISTURE.
CAUTION: To prevent electric shock, match wide
blade of plug to wide slot, and fully insert.
^ Model I
Registration
Returning your Warranty Registration Card
right away guarantees you'll receive all
the information and special offers which you
qualify for as the owner of your model.
For Customer Use
Enter below the Señal No. which is located on the
rear of the cabinet Retain this information for
future reference.
Model No.
Serial No. _
PHILIPS
Visit our Worid Wide Web Site at http:/Avww.magnavox.com
PHILIPS
Congratulations on your purchase,
and welcome to the “family!”
MAGNAVOX
Dear Philips Magnavox product owner:
Thank you for your confidence in Philips Magnavox.You’ve
selected one of the best-built, best-backed products available
today. And we’ll do everything in our power to keep you
happy with your purchase for many years to come.
As a member of the Philips Magnavox “family,” you’re
entitled to protection by one of the most comprehensive
warranties and outstanding service networks in the
industry.
What’s more, your purchase guarantees you’ll receive all
the information and special offers for which you qualify,
plus easy access to accessories from our convenient home
shopping network.
And most importantly you can count
on our uncompromising commitment to your total
satisfaction.
All of this is our way of saying welcome-and thanks for
investing in a Philips Magnavox product
Sincerely,
Robert Minkhorst
President and Chief Executive Officer
P.S. Remember, to get the most from your Philips
Magnavox product, you must return your
Warranty Registration Card within 10 days. So
please mail it to us right now!
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO OUALIFIED SERVICE PERSONNEL.
This symbol v.'srns the user that uninsulated voltage
Within the umt may have sufficient magnitude to cause
A
A
The set complies with the FCC-Rules, Part 15 and with 21
This digital apparatus does not exceed the Class B limits
for radio noise emissions from digital apparatus as set out
electric shock. Therefore, it is dangerous to make
any kind of contact with any inside part of this umt
This symbol alerts the user that important literature
1% concerning the operation and maintenance of this
I \ unit has been included. Therefore, it should be read
carefully in order to avoid any problems.
WARNING
To reduce the risk of fire or electric shock, do not
expose this appliance to rain or moisture.
CAUTION
Use of controls or adjustments or performance of
procedures other than herein may result in
hazardous radiation exposure.
CFR 1040.10.
Canada
in the Radio Interference Regulations of the Canadian
Department of Communications.
AVIS
RISQUE DE CHOCS ELECTRIQUES
NE PAS OUVRIR
Attention: Afin de prévenir le risque de chocs électriques,
Toute réparation devrait être confiée à un personnel qualifié.
A
^ I \ l'appareil contient d'importantes
I \ recommandations quant au fonctionnement et
A
AVIS
Afin de réduire tout risque d'incendie ou de choc
électrique, il ne faut pas exposer cet appareil à la
pluie ou à l'humidité.
AHENTION
L'utilisation des commandes ou réglages ou le nonrespect des procédures ci-incluses peuvent se
traduire par une exposition dangereuse à
l'irradiation.
L'appareil répond aux normes FCC, Part 15 et 21 CFR
1040,10.
Canada
Cet appareil numérique n'emet pas de bruits
radioélectriques dépassant les limites applicables aux
appareils numériques de Class B prescrites dans le
Règlement sur le Brouillage Radioélectrique édicté par le
Ministère des Communications du Canada.
ne pas retirer les vis.
Ce symbole indique la présence d‘une tension
suffisamment élevée pour engendrer un risque de
chocs électriques.
Ce symbole indique que le manuel d'installation
à l'entretien de ce dernier.
AVISO
RIESGO DE CHOQUE ELECTRICO
NO ABRIR
Atención: Para reducir el riesgo de choque elúcríco,
no quíte la tapa (o el panel posterior).
En su interior no hay piezas quo el usuario pueda reparar.
Para servicio diríjase a personal calificado.
Este símbolo t<ene por finalidad advertir al usuario de
A
A
la presencia do tensión
la caja del aparato, quo puedo ser lo suficicntomeme
fuerte para constituir un peligro de choque clcctnco
Este
Símbolo
presencia de instrucciones do mancjo y
mantenimiento (sea-icio) importanlcs en el manual
que acompaña ai aparato.
peligrosa
sia'e para advertir al usuario de fe
AVISO
Para reducir el riesgo de fuego o choque eléctrica,
no exponga el aparato a la lluvia o humedad.
ATENCIÓN
El uso de mando o ajustes o la ejecucción de
métodos que no sean los aquí descritos puede
ocasionar peligro de exposición a radiación.
El aparato cumple las normas FCC, Parte 15 y 21 CFR
1040.10.
México
Es necesario que !ea cuidadosamente su instructivo de
manejo.
I Wr.P.QUC Qül CL voltaje de AU.V.E.’,TACjO*J I
I CEACtRIaUEP-ЭOPAгACUAPA'^ATO
PA-'ÄEViTA’IEl FXSGO CE CKOÛUE ElXCTT ÇÙ t.O OUiTC LA TA7A
üí CACO DE CESV-Cí C” D “X'ACE Ai PEKC0*JA1 AüTO.XiZACO C E f!
NOM
E
no
ansiad 3 dentro
de
English
........
Frangais....
Espahol.....
INDEX
.............
.
..........
...........
28
54
\
6
)
J
>
! i* !
>
SAFETY INSTRUCTIONS - Read before operating equipment
This product was designed and manufactured to meet strict quality and safety standards.
There are, however, some installation and operation precautions which you should be
particularly aware of.
1.
Read Instructions - All the safety and operating instructions should be read
before the appliance is operated.
Retain Instructions - The safety and operating instructions should be retained
for future reference.
Heed Warnings - All warnings on the appliance and in the operating instructions
should be adhered to.
4.
Follow Instructions - All operating and use instructions should be followed.
5.
Wafer and Moisture - The appliance should not be used near water - for
example, near a bathtub, washbowl, kitchen sink, laundry tub or swimming pool,
or in a wet basement.
Carts and Stands - The appliance should be used only with a cart or stand that
is recommended by the manufacturer.
6A.
An appliance and cart combination should be moved with care. Quick
stops, excessive force, and uneven surfaces may cause the
appliance and cart combination to overturn.
Wall or Ceiling Mounting - The appliance should be mounted to a wall or
ceiling only as recommended by the manufacturer.
Ventilation - The appliance should be situated so that its location or position
does not interfere with its proper ventilation. For example, the appliance should
not be situated on a bed, sofa, rug, or similar surface that may block the
ventilation openings; or, placed in a built-in installation, such as a bookcase or
cabinet that may impede the flow of air through the ventilation openings.
Heat - The appliance should be situated away from heat sources such as
radiators, heat registers, stoves, or other appliances (including amplifiers) that
produce heat.
10.
Power Sources - The appliance should be connected to a power supply only of
the ty'pe described in the operating instructions or as marked on the appliance.
Grounding or Polarization - Precautions should be taken so that the grounding
11.
or polarization means of an appliance is not defeated.
CAUTION: To prevent electric shock, match the
wide blade of this plug to the wide slot and fully insert.,
Do not use this (polarized) plug with an extension cord,
receptacle or other outlet unless the blades can be fully inserted to prevent blade
exposure.
I>AC
^Polarized Plug
12. Power Cord Protection - Power supply cords should be routed so that they are
not likely to be walked on or pinched by items placed upon or against them, paying
particular attention to cords and plugs, convenience receptacles, and the point
where they exit from the appliance.
13. Cleaning - The appliance should be cleaned only as recommended by the
manufacturer.
14. Power Lines - An outdoor antenna should be located away from power lines.
15. Outdoor Antenna Grounding - If an outside antenna is connected to the
receiver, be sure the antenna system is grounded so as to provide some protection
against voltage surges and built up static charges.
Section 810 of the National Electrical Code, ANSI/NFPA No, 70-1984, provides
information with respect to proper grounding of the mast and supporting structure,
grounding of the lead-in wire to an antenna discharge unit, size of grounding
connectors, location of antenna-discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode See figure below
16. Nonuse Periods - The power cord of the appliance should be unplugged from the
outlet when left unused for a long period of time.
17. Object and Liquid Entry - Care should be taken so that objects do not fall and
liquids are not spilled into the enclosure through openings.
18. Damage Requiring Service - The appliance should be serviced by qualified
service personnel when:
A. The power supply cord or the plug has been damaged, or
B. Objects have fallen, or liquid has spilled into the appliance; or
C. The appliance has been exposed to rain; or
D. The appliance does not appear to operate normally or exhibits a marked
change in performance; or
E. The appliance has been dropped, or the enclosure damaged.
19. Servicing - The user should not attempt to seiwce the appliance beyond that
described in the operating instructions. All other servicing should be referred to
qualified service personnel.
SAFETY INSTRUCTIONS
Note to the CATV system installer
This reminder is provided to call the CATV system installer's attention to Article 820-40 of the NEC that provides guidelines for proper grounding and, in particular,
specifies that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as practical.
Example of Antenna Grounding as per NEC - National Electrical Code
92/11
EL 4562-1
AUDIO SYSTEM
One Year Free Labor
One Year Free Service on Parts
This product must be carried in for repair.
WHO IS COVERED?
You must have proof of purchase to receive warranty
service. A sales receipt or other document showing that
you purchased the product is considered proof of purchase.
WHAT IS COVERED?
Warranty coverage begins the day you buy your product.
For one year thereafter, all parts v/ill be repaired or replaced,
and labor is free.After one year from the day of purchase,
you pay for the replacement or repair of all parts, and for
all labor charges.
All parts. Including repaired and replaced parts, are covered
only for the original v/arranty period.When the warranty
on the product expires, the v/arranty on all replaced and
repaired parts also expires.
WHAT IS EXCLUDED?
Your warranty does not cover:
• labor charges for installation or setup of the product,
adjustment of customer controls on the product, and
installation or repair of antenna systems outside of the
product.
• product repair and/or part replacement because of misuse,
accident, unauthorized repair or other cause not within
the control of Philips Consumer Electronics Company.
• reception problems caused by signal conditions or cable
or antenna systems outside the unit.
• a product that requires modification or adaptation to
enable it to operate in any country other than tiie
country for which it was designed, manufaaured,
approved and/or authorized, or repair of products
damaged by these modifications.
• incidental or consequential damages resulting from the
product (Some states do not allov/ the exclusion of
incidental or consequential damages, so the above
exclusion may not apply to you.This includes, but is not
limited to, prerecorded material, whether copyrighted or
not copyrighted.)
LIMITED WARRANTY
* a product that is used for commercial or institutional
purposes.
WHERE IS SERVICE AVAILABLE?
Warranty service is available in ail countri^ where the
product is officially distributed by Philips Consumer
Electronics Company. In countries where Philips Consumer
Electronics Company does not distribute tiie product, the
local Philips service organization will attempt to provide
service (although there may be a delay if the appropriate
spare parts and technical manual(s) are not readily
available).
MAKE SUREYOU KEEP...
Please keep your sales receipt or other document showing
proof of purchase. Attach it to this owner’s manual and
keep both nearby.AIso keep the original box and packing
material In case you need to return your product.
BEFORE REQUESTING SERVICE...
Please check your owner’s manual before requesting
service.Adjustments of the controls discussed there may
save you a service call.
TO GET WARRANTY SERVICE IN
U.S.A., PUERTO RICO OR U.S. VIRGIN
ISLANDS...
Take the product to a Philips factory service center (see
enclosed list) or authorized service center for repair.When
the product has been repaired, you muse pick up the unit at
the center. Centers may keep defective parts.
(In U.SA, Puerto Rico and U.S.Virgin Islands, all implied
warranties, including implied warranties of merchantability
and fitness for a particular purpose, are limited in duration
to the duration of this express warranty. But, because some
states do not allov/ limitations on how long an implied
warranty may last, this limitation may not apply to you.).
TO GET WARRANTY SERVICE IN
CANADA...
Please contact Philips cc
1-800-661-6162 (French Speaking)
1-800-363 7278 (English Speaking)
(In Canada, this v/arranty is given in lieu of all other
warranties. No other v/anranties are expressed or implied.
Including any implied warranties of merchantability or
fitness for a particular purpose. Philips is not liable under
any circumstances for any direct, indirect, special, incidental
or consequential damages, hov/soever incurred, even if
notified of the possibility of such damages.)
REMEMBER...
Please record the model and serial numbers found on the
product below.AIso, please fill out and mail your v.-arranty
registration card promptiy.lt will be easier for us to notify
you if necessary.
MODEL# ______________________________________
SERIAL# ______________________________________
This warrant/ ^ives you spsofc legal r>ghts.Yo'j may ha.c cthy
rjghts a/hc/) vjty from stcte^pro.ince co stcte/prvf.nce
Philips Service Company, P.O. Box 555, Jefferson
City,Tennessee 37760,(423) 475-8869
a45SS K-DS / MAC 4110/1-97
CONTENTS
GENERAL INFORMATION
SAFETY INFORMATION
General Information
Safety Information...................................9 ' The type plate (which contains
Preparation
.........................................
................................
10-11 • Recording is permissible if copyright or other
9 General Information____________________
number) is located at the rear of the system.
rights of third parties are not infringed.
Controls
Operating The System
CD
..............................................
r = ' ¡hg foUovi/ing two conditions:
.....................................................
......................
12-14 , jijjg ¡¡effjge complies with the FCC rules, part 15
14-16 with 21CFR 1040.10. Operation issubjectto
16-18 - This device may not cause harmful
interference, and
Tuner
................................................
19-20 _ This device must accept any interference
71.99 received, including interference that may
^ ..................................................... cause undesired operation.
...............................................................
r^lnflf 9?
........................................................
^ Environmental Information
All unnecessary packaging material has been omitted.
_________
Timer........................................................23 We have done our utmost to make the packaging easily
Recording
„ . , „ foam sheet).
...........................................
24-25 polystyrene foam (buffer) and polythene (bags, protective
separable into three mono-materials: cardboard (box),
Your system consists of materials which can be recycled
Specifications...........................................26 gnd reused if disassembled by a specialized company.
Trniihiochnnfinn 91 Please observe the local regulations regarding the
disposal of packaging materials, exhausted batteries and
old equipment.
Accessories (Supplied)_________________
- Remote control
- Batteries (2 x AAA size) for remote control
- Alvi loop antenna
- FM antenna wire
- AC power cord
- 1 pair of surround speakers
Safety Information
Before operating the system, check that the operating
voltage indicated on the typeplate (or the voltage
indication beside the voltage selector) of your system
is identical with the voltage of your local power
supply. If not, please consult your dealer. The type
plate is located at the rear of your system.
When the system is switched on, do not move it
around.
Place the system on a solid base (e.g. a cabinet).
Place the system in a location with adequate
ventilation to prevent internal heat build-up in your
system.
Do not expose the system to excessive moisture, rain,
sand or heat sources.
Under no circumstances should you repair the system
yourself, as this will invalidate the warranty!
If the system is brought directly from a cold to a warm
location, or is placed in a very damp room, moisture
may condense on the lens of the CD unit inside the
system. Should this occur, the CD player will not
operate normally. Leave the power on for about one
hour with no disc in the system until normal playback
is possible.
' Electrostatic discharge may cause unexpected
problems. See whether these problems disappear if
you unplug tbe AC power cord and plug it in again
after a few seconds.
To disconnect the system from the power supply
completely, remove the AC power plug from the
wall socket.
PREPARATION
Rear Connections
L_.
10
PREPARATION
@ AM Antenna Connection
Connect the supplied loop antenna to the AM AERIAL
terminal. Place the AM loop antenna far away from the
system and adjust Its position for the best reception.
(B) FM Wire Antenna Connection
Connect the supplied FM wire antenna to the FM 300 £1
terminal. Adjust the position of the FM antenna for the
best reception.
_____________
_________
Outdoor Antenna
For better FM stereo reception connect an outdoor FM
antenna to the FM AERIAL 300 £2 terminal using a 300 £2
dipole wire.
(c) Front Speakers Connections
• Connect the right speaker to Front terminal R, with the
red wire to + and the black wire to —.
• Connect the left speaker to Front terminal L, with the
red wire to + and the
black wire to —.
Clip the stripped portion
of the speaker wire as
shown.
UNLOCK LOCK
rci) Surround Speakers Connection
_________
* •
4-Speakers Connection
• Front speakers; Connect the black wires to the black
FRONT terminals and the red wires to the red FRONT
terminals.
• Rear (surround) speakers: Connect the black or
non-marked wires to the black REAR terminals and the
white or marked wires to the grey REAR terminals.
Positioning the Speakers
To get the best surround sound effect, place the speakers
as follow.
FROrJT
t£FT
SURROUND
LEFT
□
Front Left and Right Speakers
For best listening effect, it is recommended to have the
Left and Right speakers to form an angle of
approximately 45 degrees to the listener. Should the
magnetic field from the speakers affect the picture of the
television, you should Increase the separation distance.
Rear (surround) Speakers
The surround speaker should be placed at normal
listening ear level. It can also be mounted on the wall at
the back of the room. Most important, sometimes you
need to experiment creatively when placing the surround
speakers in order to obtain the most ideal sound
projection.
@ Connecting other equipment to your i ^
system
___________________________
You can connect the audio left and right OUT terminals of
a TV, VCR, Laser Oise or OVD player to the AUX IN
terminals at the rear of the system.
(E) Subwoofer Out Connection
You can connect either an optional active subwoofer
(recommended Philips FB 201) or an optional wireless
active subwoofer (recommended Philips FB 202W) to the
SUBWOOFER OUT terminal. The wireless system uses a
radio frequency transmitter. The subwoofer reproduces
just the low bass effect (e.g. explosions, the rumble of
the spaceships, etc.). Be sure to follow the instmetions
supplied with the subwoofer unit.
Note:
- Availability of wireless transmitter and its peripherals
are subjected to the approval of local authorities.
Please check with respective local safety or approving
authority.
(f) AC Power Supply
After all other connections have been made, connect the
AC power cord to the system and to the wall outlet.
___________________
__________
l.i
CONTROLS
I
£
■m
u
2
A
15!
12
CONTROLS
Controls on the system and remote
control
______________________________
Q] STANDBY-ON
- to switch the system on or to standby mode.
- to store radio stations automatically by pressing and
holding for 2 seconds,
[2] SOURCE: to select the following.
CD/(CD1<CD2*CD3)
- to select CD mode. When CO in stop mode; to select
the respective disc tray.
TUNER/(BAND)
- to select Tuner mode. When in tuner mode; to select
the waveband; FM or AM.
TAPE/{TAPE1»TAPE2)
- to select Tape mode.
AUX/ (VIDEO)
- to select sound from an external source (e.g. TV,
Laser Disc, DVD or VCR player).
[a] MODE SELECTION
SEARCH ►►(TUNING ◄◄ ►>)
for CD
.........
for TUNER
to search backward/forward.
....
to tune to a lower or higher radio
frequency.
STOP ■ (CLEAR)
for CO
.........
to stop CD playback or clear a
for TUNER
program.
....
to stop programming.
PLAY PAUSE ► II
for CD
.........
to start or interrupt playback.
PREV N/NEXT M (PRESETAT)
for CD
.........
to skip to the beginning of the current
for TUNER
or previous/next track.
....
to select a preset station in memory.
Q] DUBBING
- to dub a tape in normal or high speed.
[5] DIGITAL SOUND CONTROL (DSC)
- to select the desired sound effect: OPTIMAL, JAZZ.
ROCK or TECHNO.
(D DIGITAL SOUND CONTROL DISPLAY PANEL
- to view the selected DSC display.
¡H DYNAMIC BASS BOOST (DBB)
- to switch on bass boost to enhance bass response or
to switch off bass boost.
m DISPLAY
- to view the current setting of the system,
m CD CAROUSELTRAY
d 3 CD DIRECT PLAY
- to select a CD tray for playback,
d OPEN'CLOSE
- to open or close the CD carousel tray,
fl! DISC CHANGE
- to change CD(s).
d CLOCK»TIMER
- to view clock, set clock or timer,
d PROGRAM
- to program CD tracks in CD mode or preset radio
stations in tuner mode.
d VOLUME
- to adjust the volume level,
d HEADPHONES ¡Ti
- to connect headphones.
RtI tape deck 2
TAPEDECK20PERATIDN
PUY ►
.............
....................to rewind the tape.
►►
...................
STOP*OPEN
PAUSE
...............
to start playback.
to fast fonward the tape.
......
to stop playback or to open the
tape door.
to interrupt playback.
TAPE DECK 1 OPERATION
RECORD...........to start recording.
PLAY ►
.............
...................
►►
..................
to start playback.
to rewind the tape.
to fast forward the tape.
STOP»OPEN.......to stop playback/recording or to
PAUSE
...............
open the tape door.
to interrupt playback or
recording.
TAPE DECK 1
REPEAT (only on remote controll
to repeat a CD track.
SHUFFLE ¡only on remote controll
to play all the available discs and their tracks in
random order.
MUTE ¡only on remote controll
to switch off the sound temporarily.
(!) (only on remote controll
to switch the system to standby mode.
Notes for remote control:
- First select the source you wish to control by pressing
one of the source select keys on the remote control
(e.g. CO, TUNER. TAPE 1/2 orAUXI.
- Then select the desired function (PIAY, NEXT, etc.l.
S'
13
CONTROLS
Inserting batteries into the Remote Control
_____________________________
• Insert the batteries (Type R03 or AAA) into the
remote control as shown in the battery compartment.
To avoid damage from possible battery leakage,
remove dead batteries or batteries that will not be
used for a long time. For replacement, use type R03 or
AAA batteries.
the preparation procedures.
Demonstration mode
The system has a demonstration mode that shows the
various features offered by the system. Whenever the
system is switched on from the wall socket, the
demonstration mode will start automatically.
Note:
- During demonstration mode, if you press any source
lor standby-onj button, the system will switch to the
respective (or standby} mode.
- When the system is switched to standby mode. 5
seconds later, the demonstration mode will resume.
OPERATING THE SYSTEM
seconds to stop the demonstration.
The demonstration mode will be switched off
permanently.
-* The system will switch to standby mode.
14
OPERATING THE SYSTEM
Easy Set
EASY SET allows you to store all available radio stations
in a particular band (FM or AM) automatically.
• Press and hold STANDBY«ON (on the system only)
for 2 seconds; when the system is in standby or
demonstration mode.
— TfISy SET" will be displayed and followed by
"TUrCR".
— EASY SET will start with the last active band.
— All available radio stations with sufficient signal
strength will be stored or until 40 presets are filled.
Notes:
- When EASY SET is used, all previously stored stations
will be erased.
-The last preset station will appear on the display
when EASY SET is completed.
Switching the system ON
• Press STANDBY* *ON (on the system only), CD,
TUNER, TAPE or AUX.
You can also switch on the system by pressing any one of
the 3 CD DIRECT PLAY buttons.
Switching the system to standby mode
• Press STANDBY'ON again.
-♦ The system will switch to standby mode.
Selecting the Source
• Press the respective source selection button; CD.
TUNER, TAPE or AUX.
— The display indicates the selected source.
Note:
- For an external source, make sure that you have
connected the audio left and right OUT terminals of
the external equipment ¡TV, VCR, Laser Disc or DVD
player) to the AUX IN terminals.
Sound Control
Volume Adjustment
Adjust VOLUME to increase or decrease the sound level.
For Personal Listening
Connect the headphones plug to the 0 socket at the
front of the system. The speakers will be muted.
Digital Sound Control (DSC)
The DSC feature enables you to enjoy special sound
effects that have preset equalizer settings, providing the
best music reproduction.
• Press DIGITAL SOUND CONTROL (DSC) to select
OPTIMAL, JAZZ, ROCK or TECHNO.
— The Digital Sound Control display panel will light up
respectively.
-"DPTIHRL, JHZZ, RGCK or TECHfja"will
be displayed.
Automatic DSC-DBB selection
The best setting for the DBB is automatically generated
for the respective DSC selection. You can manually select
the DBB setting that best suits your listening
environment.
DSC Selection
Optimal
Ttfchno
Rock -—Jazz
--------
------
------
-----
-----
-----
--------
--------
-------
------- Off
DBB On/OfT
On
On
Off
Dynamic Bass Boost (DBB)
The DBB mode enhances the bass response.
• Press DBB to switch on bass boost.
The DBB button lights up.
“UBS utJ" will be displayed.
DBB DBB
DBB DBB
OFF ON
To switch off DBB
• Press DBB again.
-* The DBB button light is switched off.
— “B3B uPr” will be displayed.
Note:
- Some CDs or tapes might be recorded in high
modulation. It may cause a distortion at high volume.
If this occurs, switch off DBB level or reduce the
volume.
15
OPERATING THE SYSTEM
„ Mute (only on remote controll
g This feature allows you to temporarily switch off the
, sound of the system without switching off the system
when you require a moment of silence.
Press MUTE on the remote
control to switch off the sound.
— "flUTE" will be displayed.
Press MUTE again on the remote
control or increase the VOLUME
level to switch on the sound.
EHO ic j ’I
(10 ll [lO ll [lo ll ¡1 ll
(r')^
r Tl
L 11
CUCZl
CD
3CD
CCrAtfO,\?CO\TPCl
E
C01>C&2*CS3
MlNrHIFI SYSTEM
uZED; id
Warning!
1) This system is tiesigned for conventional CDs. Do not use any accessories like disc stabilizer rings or
CD treatment sheets, etc., which may damage the CD mechanism.
2) Do not load more than one disc into each tray.
3) When the CD changer is loaded with CD(s), do not turn over or shake the system. This may jam the
changer.
You can load up to three discs in the CD changer for continuous playback without interruption.
16
CD
Loading the CD Changer
1 Press CD to select CD mode.
2 Press OPEN'CLOSE.
— The CD compartment slides out.
3 Load a CD with the printed side up in the right tray.
• You can load another disc in the left tray.
• To load the third disc, press the DISC CHANGE
button.
— The CD changer carousel will rotate until the empty
tray is at the right hand side and is ready for
loading.
-• Playback will always start with the disc in the outer
right disc tray.
4 Press DPEN»CLOSE to close the CD compartment.
— The total number of tracks and playing time of the
last selected disc appear on the display.
3 CD Direct Play
You can play a CD directly by pressing the 3 CD DIRECT
PLAY (1 - 3) buttons. The CD player will stop at the end
of playback of the selected disc.
- When the button is lighted, it indicates that there is a
disc loaded in the disc tray.
Playing a CD
1 Press PLAY ► to start playback,
-* The disc tray, track number and elapsed playing
time of the current track appear on the display.
• To interrupt playback, press PAUSE II.
-* The playing time flashes.
• To resume playback, press PLAY ► again.
2 To stop playback, press STOP ■.
Note:
- All the available discs will play once, then stop. When
the CD has stopped playing, the system will switch to
the standby mode after 15 minutes if no button is
pressed.
Disc Change__________________________
You can change the outer 2 discs while the third inner
disc is at the stop or playing mode.
1 Press DISC CHANGE.
— The CD compartment slides out.
2 Replace the discs in the left and right disc trays.
• If you press DISC CHANGE again during playback,
the CD will stop playing.
— The CD carousel tray will rotate until the inner tray
is at the right hand side and is ready for changing.
3 Press OPEN»CLOSE to close the CD compartment.
Selecting a desired track
Selecting a desired track at the stop mode
1 Press PREV M or NEXT ►! until the desired track
appears on the display,
2 Press PLAY ► to start playback.
— The selected track number and elapsed playing
time appear on the display.
Selecting a desired track during playback
1 Press PREV H or NEXT ►! until the desired track
appears on the display.
— The selected track number and elapsed playing
time appear on the display.
• If you press PREV M once it will skip to the
beginning of the current track and play the track again.
Searching for a particular passage
during playback_______________________
• Press and hold or ►► until the desired passage is
located.
— The volume will be reduced.
• Play returns to normal when « or ►► is released.
17
CD
^ ProaTamming Tracks
Programming tracks of a loaded CD is possible in the stop
mode. The display will indicate the total tracks stored in
the program. Up to 40 tracks can be stored in the memory
in any order. When 40 tracks are stored and you attempt
to store another track, the display will show "PROSRPi/1
rULL".
1 Load the desired discs in the disc trays.
2 Press PROGRAM to start programming.
— The PROGRAM flag starts flashing.
3 Press the CD 1* *CD 2»CD 3 button to select the disc.
4 Press PREV M or NEXT ►! to select the desired
track.
5 Press PROGRAM to store the track.
• Repeat steps 3to 5to store other discs and tracks.
6 Press STOP ■ once to end programming mode.
— The total number of tracks programmed and total
playing time appear on the display.
Note:
- If the total playing time is more than ''33:53" or if
one of the programmed tracks has a number greater
than 30, then -; - -" appears in the display instead
of the total playing time.
- During programming, if no button is pressed within 20
seconds, the system will exit program mode
automatically.
Playing the program
1 Press PLAY ► to start program playback.
— "PLRy PRDERRfr appears on the display.
The track number and elapsed playing time of the
current track will appear on the display.
• If you press REPEAT during program playback, the
current track will be played repeatedly.
The REPEAT and PROGRAM flags will be displayed.
2 Press STOP ■ to stop program playback.
Note:
- If you press any of the 3 CD DIRECT PLAY buttons, the
system will play the selected disc or track and the
stored program will be ignored temporarily. The
PROGRAM flag will also temporarily disappear from
the display and then reappear when the playback for
the selected disc ends.
Reviewing the program
Reviewing of the program is only possible in the stop
mode.
• Press PREV M or NEXT H repeatedly to review the
programmed tracks.
• Press STOP ■ to exit review mode.
________________
Erasing the program (In the stop model
• Press CLEAR on the system.
"PROGRRM CLERRE3" will be displayed.
Note:
- The program will be erased when the system is
disconnected from the power supply. If the CD
carousel is opened, the tracks belonging to the outer
two trays will be erased and the display will show
'CLERRES".
Shuffle ¡only on remote control)
It will play all the available discs and their tracks in
random order. Shuffle may also be used when tracks are
programmed.
To shuffle all the discs and tracks
1 Press SHUFFLE.
"SHurPLE" will be displayed.
The SHUFFLE flag, the disc and the track selected
at random appear on the display,
• The discs and the tracks will norv be played in random
order until you press STOP ■.
• If you press REPEAT during shuffle, the current track
will be played repeatedly.
— The REPEAT and PROGRAM flags will be displayed,
2 Press SHUFFLE again to resume normal playback.
— The SHUFFLE flag disappears from the display.
Repeat (only on remote control!
It will play the current track repeatedly.
1 Press REPEAT during CD playback.
- "REPERT TRRCK" will be displayed.
The REPEAT flag appears on the display.
• The track will now be played repeatedly until you
press STOP ■.
2 Press REPEAT again to resume normal playback.
-* The REPEAT flag disappears from the display.
18
EASY SET allows you to store all available radio stations
in a particular band (FM or AM) automatically.
• Press and hold STANDBY*ON (on the system only!
for 2 seconds; when the system is in standby or
demonstration mode.
— TRSy SET" will be displayed and followed by
■rUNEf?".
— EASY SET will start with the last active band.
— All available radio stations with sufficient signal
strength will be stored or until 40 presets are filled.
Notes:
- When EASY SET Is used, all previously stored radio
stations will be erased.
~ The last preset radio station will appear on the display
when EASYSETh completed.
1 Press TUNER to select TUNER mode.
— "TUNCR" will be displayed.
A few seconds later, the current frequency or the
radio station name if available will be displayed.
2 Press TUNER (BAND) again to select the desired
waveband ;FM or AM.
3 Press TUNING or ►► for more than one second,
then release.
-* The display will show '5EFÌRCH' until a radio
station with sufficient signal strength is found.
• Repeat this procedure until the desired station is
reached.
• To tune to a weak station, briefly press TUNING ◄◄
or ►► until the display shows the desired frequency
and/or when the best reception has been obtained.
TUNER
Storing Preset Stations
You can store up to 40 radio stations in the memory.
When a preset radio station is selected, the preset
number appears next to the frequency on the display.
Automatic programming
1 Press TUNER.
2 Press TUNER (BAND) again to select the desired
waveband: FM or AM.
3 Press PROGRAM for more than one second.
— PROGRAM flag starts flashing and 'RUTO' will be
displayed.
-* Every available station for the selected waveband
will be stored automatically. The frequency and
preset number will be displayed briefly.
— The system will stop searching when all the
available radio stations are stored or when the
memory for 40 preset radio stations is used.
The system will remain tuned to the last stored
preset radio station.
• Repeat the above procedure to store other preset radio
stations for the other waveband. Remember to select
the next available preset number before proceeding. If
not, some of the preset radio stations may be erased.
Notes:
- You can cancel the automatic programming by
pressing PROGRAM or STOP ■ on the system only.
- If you want to reserve a section of preset numbers, for
example preset numbers 1 to 9, select preset 10
before starting automatic programming: now only the
preset numbers 10 to 40 will be programmed.
s
19
TUNER
Manual programming
1 Press TUNER.
2 Press TUNER (BAND) to select the desired waveband
:FMorAM.
3 Press PROGRAM for less than one second.
— PROGRAM flag, the frequency and preset number
start flashing.
— The next available preset number will be displayed
for selection.
4 Press TUNING •« or ►► to tune to the desired
frequency.
• If you wish to store the radio station to another preset
number, press PRESET T or A to select the desired
preset number.
5 Press PROGRAM again.
— PROGRAM flag will stop flashing, and the radio
station will be stored.
• Repeat the above procedure to store other preset radio
stations.
Notes:
- When 40 radio stations are stored and you attempt to
store another radio station, the display will show
’ PROGRRtl ruLLIf you want to change an
existing preset number: repeat steps 4 and 5.
-You can cancel manual programming by pressing
STOP ■ on the system only.
- During programming, if no button is pressed within 20
seconds, the system will exit program mode
automatically.
Tuning to Preset Radio Stations
• Press PRESET T or A to select the desired preset
number.
— The preset number, frequency and waveband
appear on the display
_______
20
TAPE
Loadinn a tape
Press STOP'OPEN.
The tape deck door opens.
Load the tape with the open
side downward and the full
spool to the left.
Close the tape deck door.
Tape Playback
1 Press TAPE to select TAPE mode.
— "TFIPE“ will be displayed.
2 Load the tape into the selected tape deck.
3 Press PLAY ► to start playback.
• To interrupt playback, press PAUSE.
• To resume playback, press PAUSE again.
4 Press STOP'OPEN to end playback.
Rewind/Fast Forward
At the stop mode
1 You can rewind or fast forward a tape by pressing <4
or ►► respectively.
-* The tape will stop automatically at the end of
rewinding or fast forwarding.
2 Press STOP»OPEN to stop rewinding or fast
forwarding.
J’
21
inrc AUX
CLOCK
Continuous Playback From Tape Deck 2
I
to Tape Deck 1________________________
g:
1 Press TAPE to select TAPE mode.
Z Load the tapes in tape deck 1 and 2.
3 Press PLAY ► on tape deck 2.
4 Press PAUSE on tape deck 1.
5 Press PLAY ►on tape deck 1.
-* * Playback will begin with tape deck 2 and will
continue with tape deck 1 when playback on tape
deck 2 ends.
6 Press STOP*OPEN if you want to stop playback
before the end of the tape in tape deck 1 or tape
deck 2.
Notes:
- During rewinding or fast forwarding of a tape, it is
also possible to select another source mode (e.g. CD,
TUNER or AUX mode).
- Check and tighten slack tape before use with a pencil.
Slack tape may get jammed or may burst in the
mechanism.
- C-120 tape is extremely thin and is easily deformed or
damaged. It is not recommended for use in this
system.
- Store the tapes at room temperature and do not put
them too close to a magnetic field (for example, a
transformer, W or loudspeaker boxes).
Selecting External Equipment
If you have connected the audio out terminals of the
external equipment (TV, VCR, Laser Disc or DVD player) to
the AUX IN terminals, you can hear the enhanced sound
from the system.
• Press AUX to select the external mode.
— ■SL):.'" will be displayed.
Note:
-All the sound control features (e.g. DSC, DBB, etc.) are
available for selection.
___________
View Clock
You can view the clock (if it is set) at standby or any
source mode. It will be displayed for about 7 seconds.
• Press CLOCK'TIMER briefly.
" IS-CS PM" (the current time) will be displayed,
will ba displayed if the clock is not set
Clock Setting
The clock is set in 12-hour mode, e.g." 1B:00 AM" or
" l¿':GO PM". Before setting the clock, you must be in
the View Clock mode.
1 Press CLO CK»TIMER to select clock mode.
— " AM" or the current time starts flashing.
— M . M, Klightup.
2 Set the hour with or
3 Set the minute with (◄or ►(.
4 Press CLOCK«TIMER again to store the setting.
-* The clock starts running.
• To exit without storing the setting, press STOP ■
Notes:
- During clock setting, if no button Is pressed within SO
seconds, the system will exit clock setting mode
automatically.
- When a power interruption occurs, the clock setting is
erased.
22
Timer Setting
• The system can switch on to CD or TUNER mode
automatically at a preset time. It can serve as an
alarm to wake you up. After half an hour from the
preset time, the system will return to the standby
mode if no button is pressed.
• Before setting the timer, make sure the clock is set
correctly.
• The timer has to be reset or start again for each
subsequent preset time.
• Tho volume of the timer will be at the last setting
before the set is switched to standby mode.
1 Press and hold CLOCK*TIMER for more than 2
seconds to select timer mode.
— "OW IS:00 AM" or the last set timer starts
flashing. The TIMER flag flashes.
— The last selected source is lighted while other
available sources are flashing.
— "-<◄, ►►, M , H, ■" light up.
2 Press CD or TUNER to select the desired source.
3 Press« or ►► to set the hour for the timer to start.
4 Press M or ►! to set the minute for the timer to
start.
5 Press CLOCK*TilVIER to store the start time.
-* The TIMER is now set.
— The TIMER flag remains on the display.
• To exit without storing the setting, press STOP ■.
• At the preset time, the TIMER will be activated.
— The selected source will be played.
— The TIMER flag disappears from the display.
TIMER
Notes:
- During timer setting, if no button is pressed within 90
seconds, the system will exit timer setting mode
automatically.
- If the source selected is TUNER, the last tuned
frequency will be switched on.
- If the source selected Is CD, playback will begin with
the first track of the last selected disc. If the CD trays
are empty, the TUNER will be selected Instead.
To cancel the TIMER
1 Press CLOCK»TIMER for more than 2 seconds.
2 Press PAUSE II to cancel the timer.
— "CRNCEL" will be displayed.
— The TIMER flag disappears from the display.
To start the TIMER again (forthesame time}
1 Press CLOCK»TIMER for more than 2 seconds.
2 Press CLOCK»TIMER again to store the start time
and the selected source.
23
RECORDING
Notes:
- For recording, use only tape of lEC type I {normal tape!.
- The tape is secured at both ends with leader tape. At
the beginning and end of tape, nothing will be
recorded for six to seven seconds.
- The recording level is set automatically, regardless of
the position of VOLUME or DBB.
- To prevent accidental recording, break out the tab on
the left shoulder of the tape side you want to protect
One Touch Recordinfl
• For One Touch Recording, as soon as you press
RECORD, the current source will be recorded on tape
deckl.
1 Load a blank tape in tape deck 1.
2 Press RECORD on tape deck 1 to start recording,
— The REC flag starts flashing.
3 Press PAUSE to interrupt recording.
4 Press STOP»OPEN on tape deck 1 to stop recording.
_________________
24
Dubbing tapes (from tape deck2 to tape deck II CD Synchro Start Recording
1 Load the prerecorded tape into tape deck 2 and a
blank tape into tape deck 1.
— Make sure that both tapes have their full spool to
the left.
2 Press DUBBING to switch between normal and high
speed dubbing.
— "fJDi?f1RL" (normal speed) or TR5P" (high speed)
will be displayed.
— HSD flag appears on the display for high speed
dubbing.
3 Press PAUSE on tape deck 1.
4 Press RECORD on tape deck 1.
5 Press PLAY on tape deck 2.
— Recording will start automatically.
-♦ The REC flag starts flashing.
6 Press STOP»OPEN on tape deck! and tape deck 2 to
stop dubbing.
Notes.
- At the end of side A, flip the tapes to side B and
repeat the procedure.
- Dubbing of tapes is only possible from tape deck 2 to
tape deck 1.
- To ensure good dubbing, use tapes of the same length.
- During high speed dubbing in Tape mode, the sound is
reduced to a low volume.
During CD synchro start recording,
• It is not advisable to fast forward/rewind your tape in
tape deck 2.
• It is not possible to listen to another source.
1 Load a blank tape into tape deck 1 and a disc into the
disc tray.
2 Press CD.
• You can program the tracks in the order you want them
to be recorded (see Programming Tracks). If not, the
tracks are recorded according to the selected disc.
3 Press RECORD on tape deck 1 to start recording.
4 Press STOP »OPEN on tape deck 1 to stop recording
and STOP ■ to stop CD playback.
. Recording from other sources (only on tape
deck 1}
____________________________________________
Load a blank tape into tape deck 1.
Press CD. TUNER, TAPE or AUX.
Start playback of the selected source.
Press RECORD on tape deck 1 to start recording.
— The REC flag is flashing.
Press PAUSE to interrupt recording.
Press STOP»OPEN on tape deck 1 to stop recording.
Note:
- During recording, it is not possible to listen to another
sound source.
RECORDING
25
MAINTENANCE
SPECIFICATIONS
Maintenance
Cleaning the Cabinet
• Use a soft cloth slightly moistened with a mild
detergent solution. Do not use a solution containing
alcohol, spirits, ammonia or abrasives.
Cleaning Discs
• When a disc becomes dirty, clean it with a cleaning
cloth. Wipe the disc from the center out.
• Do not use solvents such as benzine, thinner,
commercially available cleaners, or antistatic spray
intended for analog records.
Cleaning the CD lens
After prolonged usage, dirt or dust may accumulate at the
CD lens. To ensure good playback quality, clean the CD
lens with Philips-Wlagnavox CD Lens Cleaner or any
commercially available. Follow the instructions supplied
with the Lens Cleaner.
Cleaning the Heads and the Tape Paths
• To ensure good recording and playback quality, clean
the heads, the capstanis), and pressure roller(s) after
every 50 hours of tape operation.
• Use a cotton swab slightly moistened with cleaning
fluid or alcohol.
• You can also clean the heads by playing a cleaning
tape through once.
Demagnetizing the heads
• Use a demagnetizing tape available at your dealer.
Specifications
AMPLIFIER
Signal-to-noise ratio
Frequency response
Input sensitivity
Auxin
...................................................
Output
Speakers(Left/Right)
Surround Speakers
Headphones.................................32 £7-1000 ii
Subwoofer
At maximum volume
Impedance............................................ <2k£J
Load impedance
Frequency response (±3 dB)
CD PLAYER
Number of programmable tracks........................... 40
Frequency range................................ 20 - 20000 Hz
Signal-to-noise ratio
Channel separation ........................... S 60 dB (1 kHz)
Total harmonic distortion............................. < 0.003%
TUNER
FM wave range............................... 87.5-108 tVHz
AM wave range
Number of presets
Antenna FM................................ 300 £1 dipole wire
AM
...........................
...........................
....................................
......................................
.............................
.....................................
............
.................................
................................
...........................................
...................................
>75 dBA (lEC)
60-16000 Hz
500mV
>60
S6i2
1.5 Vrms
>22k£i
60 -16000 Hz
>80 dBA
530-1700 kHz
40
Loop antenna
TAPE DECK
Frequency range
Normal tape {type I)
Signal-to-noise ratio
Normal tape (type I) .............................. > 43 dBA
Wow and flutter
.................
......................................
80-12500 Hz (8 dB)
<04%J1S
SPEAKERS (Front Left/Right)
System
......................
Impedance
Woofer.................................................. 1x55’
Tweeter
Dimensions(wxhxd)
Weight
....................................................
..................................................
................................... , 3 25 kg approx.
2-way; Double port bass reflex
......................
210x310x230(mm)
6 £7
1,x2.5’
SPEAKERS (Surround)
System
........................................
Impedance........................................................ 6 £2
Speaker
.......................................
Dimensions (wxhxd)
Weight
...................................................
....................
closed satellite
1x3 full range
225 x 98 x 225 (mm)
0.76 kg
GENERAL INFORMATION
Material/finish....................................... Polystyrene
AC Power....................................... 120 V/60 Hz
Power Consumption
Active......................................................44 W
Standby
Dimensions (wxhxd) .................. 265 x 310 x 330 (mm)
Weight (without speakers)
..............................................
....................
< 14 W
5.2 kg approx.
Subject to modification
26
TROUBLESHOOTING
Warning! Under no circumstances should you try
to repair the system yourseif, as this will invalidate
the warranty.
• If a fault occurs, check the points listed below before
taking the system for repair.
• Should any problems persist after you have made
these checks, consult your nearest dealer or service
center,
CD Player Operation
"fJQ DISC" is displayed.
• The disc is inserted upside down.
-> Place CD with printed side up.
___________________
• Moisture condensation at the lens.
— Wait until lens has adjusted to normal room
temperature.
• There is no disc in the CD tray.
— Insert a CD
• The CD is dirty, badly scratched or warped.
Clean or replace the CD.
• The CD lens is dirty or dusty
— See section under Maintenance.
Radio Reception
Poor radio reception
• The signal strength is too weak.
— Adjust the antenna.
______________________
• The TV or VCR is too close to the stereo system.
-* Separate the stereo system from the TV or VCR.
— Connect an external antenna for better reception.
Tape Deck Operation
"RCCORIirwG RCrii'C" is displayed.
• A recording is in progress.
— Stop the recording or wait until it is finished.
“TRPC " is displayed.
• Tape dubbing is only possible in tape mode.
Switch source to tape mode.
Recording or playback cannot be made or there is a
decrease in audio level.
• Dirty tape heads, capstans or pressure rollers.
— See section on tape deck maintenance.
• Magnetic build-up in the record/playback head.
-* Use demagnetizing tape.
General
_____________________________
System does not react when any button is pressed.
• Electrostatic discharge.
Press STANDBY-ON to switch the system off. Remove
the AC power plug from the wall outlet, then
reconnect and switch on the system again.
No or poor sound.
• Volume is not turned up.
--Adjust VOLUME.
• The headphones are connected.
— Disconnect the headphones.
• Speakers are not connected or are connected wrongly.
-* Check that the speakers are connected correctly.
Make sure that the stripped speaker wire is clamped.
Reversed left and right sound.
• Speakers are connected wrongly.
— Check the speaker connections and location.
Lack of bass sound or apparently imprecise
physical location of musical instruments. | -|
• Speakers are connected wrongly. ki
-* Check the speaker connection for proper phasing, red/
black wires to red/biack terminals.
Remote control has no effect on the system.
• The distance to the system is too large.
-* Reduce the distance.
• Batteries are inserted incorrectly.
-* Insert the batteries with their polarities {+/- signs) as
indicated..
• Batteries are exhausted.
-* Replace the batteries.
• Wrong source is selected.
-* Select the source (CD, TUNER, etc.) before pressing
the function button, (PLAY, PREV/NEXT, etc.).
Timer not working.
• Timer is not switched on.
-* Press CLOCK• TIMER to switch on the timer.
• Dubbing/recording is in progress.
— Stop dubbing/recording.
System displays features automatically; buttons
flash continuously.
• Demonstration mode is switched on.
— Press and hold STOP ■ for 3 seconds to switch off
the demonstration.
27
FW 338C
FW62C
/XV
3139 116 17592
IB8002T001 TL-9803/37-3
Loading...
