Philips Econova
Eco Smart LED TV with
Pixel Plus HD
117 cm (46")
Full HD 1080p DVB T/C/S2
46PFL6806K
Designed with the future in mind
Energy class A++
Awarded as the European Green TV 2011-2012 by EISA, the Philips Econova 46PFL6806
ECO Smart LED TV has clear, vivid Full HD pictures and authentic sound. With Smart
TV, you can easily surf the Internet and download movies.
Your entertainment in brilliant detail.
• Full HD TV with Pixel Plus HD for better details and clarity
• Brilliant LED images with incredible contrast
• 400 Hz Perfect Motion Rate (PMR) for superb motion sharpness
Enjoy the online world with Smart TV
• A wealth of online apps, videos to rent and catch-up TV
• Control the TV with your smart phone, tablet or keyboard
• Enjoy photos, music and movies from any device on your TV
• Find, schedule, record and pause TV
• Wi-Fi Ready to use Net TV Apps and SimplyShare wirelessly
Greener every day
• Zero power consumption at a flick of the 0 Watt hard switch
• 2-in-1 stand for easy use on a table and a wall mount
• Solar rechargeable remote control means never replacing batteries
• Energy Class A++
46PFL6806K/02
Highlights
Eco Smart LED TV with Pixel Plus HD
117 cm (46") Full HD 1080p DVB T/C/S2
Pixel Plus HD
Pixel Plus HD offers the unique combination of
ul
timate sharpness, natural detail, vivid colours
and smooth natural motion on all qualities of
HD, standard TV signals and multimedia
content, for high definition displays. Artifacts
and noise in all sources from multimedia to
standard definition TV and also in highly
compressed HD are detected and reduced,
ensuring that the picture is clear and razor
sharp.
Full HD LED TV
The most advanced LED lighting technology in
th
is Full HD LED TV combines an eye-catching
minimalistic design with stunning image quality
as well as the lowest power consumption in its
category. On top of that, LED lighting
technology does not contain any hazardous
materials. Thus, with LED backlights you can
enjoy low power consumption, high
brightness, incredible contrast, sharpness and
vibrant colours.
400 Hz Perfect Motion Rate
400 Hz Perfect Motion Rate (PMR) creates
ex
treme motion sharpness for clear and
vibrant images in fast action movies. The new
Philips PMR standard shows the combined
visible effect of the fastest panel refresh rate,
HD Natural Motion and a unique processing
formula, for unprecedented motion sharpness
Zero Watt power switch
Zero power consumption at a flick of the 0
Watt hard swit
ch
2-in-1 stand
This TV comes with a revolutionary tabletop
stand that can also be use to wall-mount your
television. There is no need to buy additional
wall-mount brackets. The environment
benefits even more because an unnecessary
source of waste is eliminated as you do not
need to discard any parts.
Solar powered remote control
With this Solar powered rechargeable remote
control you never need to replace or dispose
of batteries again. Designed for maximum
sustainability, the solar cell will recharge the
remote control from a freely available source
of energy: daylight. And even in darker winter
times there is no need to worry: the built in
accumulator has a large energy reserve to keep
the remote control going, and keep you in
charge!
100% recyclable packaging
100% recyclable packaging for the lowest
i
mpact on the environment. A lot of detail and
breakthrough innovation went into the design
of this packaging. By eliminating polystyrene
buffers, this TV makes yet another
contribution to a more sustainable
environment. In a highly innovative
development for this size of TV, it only uses
paper and cardboard, so the whole packaging
can be easily recycled.
Energy Class A ++
EU Energy Label
For many years Philips has been proactively working on the reduction of both
on-mode and standby power
consumption of its televisions, and as a
result, most Philips televisions achieved
green EU energy labels in 2011. The
greener the label, the lower the on-mode
power consumption, the lower your
energy bill and the friendlier it is to the
environment.
Smart TV
Smart TV for a simpler TV experience in
four areas. Net TV lets you rent films,
watch catch-up TV and enjoy social media.
Control your TV with your Smartphone
or tablet. Use SimplyShare to enjoy
multimedia content from your computer,
phone and tablet on your TV. Record
your TV programmes easily without
additional bulky devices.
European Green TV
EISA European Green TV
This TV has been awarded
the
European Best Green
TV by EISA because of the
television's high energy
efficiency, usage of post-recycled plastics
and solar powered remote control.
Full HD
LED
Perfect Motion Rate
remote control
energy
savings
Issue date 2011-10-20
Version: 8.0.6
12 NC: 8670 000 83132
EAN: 87 12581 62390 6
© 2011 Koninklijke Philips Electronics N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips
Electronics N.V. or their respective owners.
www.philips.com
46PFL6806K/02
Specifications
Eco Smart LED TV with Pixel Plus HD
117 cm (46") Full HD 1080p DVB T/C/S2
Picture/Display
• Display: edge LED backlight
• Diagonal screen size: 46 inch / 117 cm
• Panel resolution: 1920 x 1080p
• Aspect ratio: 16:9
• Peak Luminance ratio: 65 %
• Dynamic screen contrast: 500,000:1
• Response time (typical): 2 ms
• Picture enhancement: Pixel Plus HD, H
D Natural
Motion, Active Control + Light sensor, Super
Resolution, 400 Hz Perfect Motion Rate
Sound
• Output power (RMS): 28 W (2 x 14 W)
• Sound Enhancement: Ambi-wOOx, Auto Volume
Lev
eller, Clear Sound, Incredible Surround, Treble
and Bass Control
Smart TV Applications
• Control: MyRemote app (iOS & Android), USB
Keyboard and Mouse support
• SimplyShare: DLNA media browser, USB media
bro
wser
• Net TV: Catch-up TV, Online Video shops, Open
In
ternet browser, Online apps
• Programme: Pause TV, USB recording
Connectivity
• Number of HDMI connections: 3
•HDMI features: Audio R
eturn Channel
• EasyLink (HDMI-CEC): Remote control passth
rough, System audio control, System standby,
Plug and play add to Homescreen, Auto subtitle
shift (Philips), Pixel Plus link (Philips), One touch
play
• Number of components in (YPbPr): 1
•Number of scarts (RGB/CVBS): 1
• Number of USBs: 1
• Other connections: Antenna IEC75, Antenna Ft
ype, Common Interface Plus (CI+), Ethernet-LAN
RJ-45, SD card slot (Videostore), Digital audio out
(coaxial), PC-in VGA + Audio L/R in, Headphone
out, Service connector
• Wireless connections: Wireless LAN ready
Multimedia Applications
• Video Playback Formats: Codec support:,
Containers: AVI, MKV, H264/MPEG-4 AVC,
MPEG-1, MPEG-2, MPEG-4, WMV9/VC1
• Music Playback Formats: AAC, MP3, WMA (v2 up
to
v9.2)
• Picture Playback Formats: JPEG
• Net TV: Included
Supported Display Resolution
• Computer inputs: up to 1920 x 1080 @ 60 Hz
• Video inputs: 24, 25, 30, 50, 60 Hz, up to 1920 x
10
80p
Convenience
• PC network link: DLNA 1.5 certified
• Electronic Programme Guide: 8-day Electronic
Pro
gramme Guide*
• Ease of Installation: Auto detect Philips devices,
Channel i
nstallation wizard, Device connection
wizard, Network installation wizard, Settings
assistant wizard, 2-in-1 Wallmount Stand
• Ease of Use: One-stop Ho
me button, On-screen
User manual, Touch control buttons
• Screen Format Adjustments: Autofill, Autozoom,
Movie exp
and 16:9, Super Zoom, Unscaled,
Widescreen
• Signal strength indication
• Teletext: 1200-page Hypertext
• Firmware upgradeable: Firmware auto upgrade
wizar
d, Firmware upgradeable via USB, Online
firmware upgrade
Tuner/Reception/Transmission
• Digital TV: DVB-C MPEG2*, DVB-C MPEG4*,
DVB-S2 MPEG4 HD, DVB-T MPEG2*, DVB-T
MPEG4*, DVB-S HD+ support (Astra)
• Video Playback: NTSC, PAL, SECAM
Power
• Mains power: 220-240 V ~ ;50-60 Hz
• Ambient temperature: 5°C to 40°C
• Energy Label Class: A++
• EU Energy Label power: 45.5 W
• Annual energy consumption: 63.1 kW·h
• Standby power consumption: < 0.15 W
• Power Saving Features: 0 Watt Power-off switch,
Au
to switch-off timer, Eco mode, Eco settings
menu, Light sensor, Picture mute (for radio)
• Presence of lead: Yes*
• Off mode power consumption: < 0.01 W
Dimensions
•Box dimensions (W x H x D):
1324 x 773 x 198 mm
•Set dimensions (W x H x D):
10
81 x 653 x 39.9 mm
• Set dimensions with stand (W x H x D):
10
81 x
705 x 265 mm
• Product weight: 16.4 kg
• Product weight (+stand): 20 kg
• Compatible wall mount: 400 x 400 mm
Accessories
• Included accessories: Power cord, Solar powered
remote control, Quick start guide, Legal and safety
brochure, Warranty Leaflet, Charging cable USB A
> Micro-B
• Optional accessories: Wireless USB adapter
(PT
A01), Philips Wall Mount SQM 6375, Philips
Wall Mount SQM 6485
Sustainability
• Energy Efficiency: Ambient light sensor, Energy
saving options, Lowest power in the Ultra-thin TV
category, Solar rechargeable Remote Control,
Low power LED display, 60% less power vs. LCD/
CCFL
• Material: 2-in-1 Stand avoids waste, Minimal
c
omponent Architecture, Minimal industrial metal
waste, Minimised internal cable
• Packaging: 100% paper monomaterials, Full
ca
rdboard cushions, Minimised dimensions
• Recycling and disposal: Designed for disassembly,
High
est % recyclable content, packaging materials
100% paper
• Removal of hazardous subs
tances: Full Halogen and
PVC-free design
• User manual: 28-language E-user manual,
I
ntegrated E- user manual, No paper user manual
•
* Net TV: Visit www.philips.com/smarttv to discover the services
available in your country.
* The TV supports DVB reception for 'Free to air' broadcast. Specific
DV
B operators may not be supported. An up to date list can be
found in the FAQ section of the Philips support website. For some
operators Conditional Access and subscription are required.
Contact your operator for more information.
* 8 days EPG, service not available in all countries
* Annual energy consumption is calculated using the typical power
consumption of 4 hours per day, 365 days per year.
* This television contains lead only in certain parts or components
where no technology alternatives exist in accordance with existing
exemption clauses under the RoHS Directive.
