Page 1

DVP620VR/07Digital Video Disc Player &

Video Cassette Recorder

Owner’s Manual

THANK YOU FOR CHOOSING PHILIPS.

EED HELP FAST?

READ YOUR QUICK-USE GUIDE AND/OR OWNER’S MANUAL FIRST FOR

QUICK TIPS THAT MAKE USING YOUR

PHILIPS PRODUCT MORE ENJOYABLE.

FYOU HAVE READ YOUR INSTRUCTIONS AND STILL NEED ASSISTANCE,

YOUMAY A CCESS OUR ONLINE HELP AT WWW.P4C.PHILIPS.COM

OR CALL

1-800-531-0039 WHILE WITH YOUR PRODUCT.

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 1

Page 2

Registering your model with PHILIPS makes you eligible for all of the valuable benefits listed below, so don't miss out. Complete and return your Product Registration Card at once to ensure:

Return your Product Registration Card today

to get the very most from your purchase.

Know these

safety symbols

*Proof of Purchase

Returning the enclosed card guarantees that your date of purchase will be on file, so no additional paperwork will be required from you to obtain warranty service.

*Product Safety Notification

By registering your product, you'll receive notification - directly from the manufacturer - in the rare case of a product recall or safety defect.

*Additional Benefits of Product Ownership

Registering your product guarantees that you'll receive all of the privileges to which you're entitled, including special money-saving offers.

Visit our World Wide Web Site at http://www.philips.com

Congratulations on your purchase, and welcome to the “family!”

Dear PHILIPS product owner:

Thank you for your confidence in PHILIPS.You’ve selected one of the best-built, best-backed products available today.We’ll do everything in our power to keep you happy with your purchase for many years to come.

As a member of the PHILIPS “family,” you’re entitled to protection by one of the most comprehensive warranties and outstanding service networks in the industry.What’s more, your purchase guarantees you’ll receive all the information and special offers for which you qualify, plus easy access to accessories from our convenient home shopping network.

Most importantly, you can count on our uncompromising commitment to your total satisfaction.

All of this is our way of saying welcome - and thanks for investing in a PHILIPS product.

P.S. To get the most from your PHILIPS purchase, be sure to complete and return your Product Registration Card at once.

For Customer Use

Enter below the Serial No. which is located on the rear of the cabinet. Retain this information for future reference.

Model No. ________________________ Serial No. ________________________

This “bolt of lightning” indicates uninsu-

lated material within your unit may cause an electrical shock. For the safety of everyone in your household, please do not remove product covering.

The “exclamation point” calls attention

to features for which you should read the enclosed literature closely to prevent operating and maintenance problems.

WARNING: To r educe the risk of fire or electric shock, this apparatus should not be exposed to rain or moisture, and objects filled with liquids, such as vases, should not be placed on this apparatus.

CAUTION: To prevent electric shock, match wide blade of plug to wide slot, fully insert.

ATTENTION:Pour éviter les choc électriques, introduire la lame la plus large de la fiche dans la borne correspondante de la prise et pousser jusqu’au fond.

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 2

Page 3

Safety and General Information

Safety Precautions

Warning: To prevent fire or shock hazard, do not expose this equipment to rain or

moisture. Federal Communications Commission (FCC) Warning: Any unauthorized changes or modifications to this equipment void the user’s authority to operate it. Department of Health and Human Services (DHHS) Certification: Complies with 2

1 Center for Radiation (CFR) chapter 1 subchapter J applicable at time of manufacture.

Laser Safety: This unit employs a laser.Only a qualified service person should remove

the cover or attempt to service this device, due to possible eye injury. CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. CAUTION:VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN AND INTERLOCK DEFEATED. DO NOT STARE INTO BEAM.THE BEAM IS LOCATED INSIDE, NEAR THE DECK MECHANISM.

Special Information for Canadian Users: This Class B digital apparatus

complies with Canadian ICES-003. Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

Radio/TV Interference: This equipment has been tested and found to comply

with the limits for a Class B digital device, pursuant to Part

15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

1) Reorient or relocate the receiving antenna.

2) Increase the separation between the equipment and the receiver.

3) Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

4) Consult the dealer or an experienced radio/TV technician for help.

lending of Discs are prohibited.This product incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners.Use of this copyright protection technology must be authorized by Macrovision Corporation and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

Notice for Progressive Scan Use: Consumers should note that not all high

definition television sets are fully compatible with this product and may cause artifacts to be displayed in the picture. In case of 525 progressive scan picture problems,it is recommended that the user switch the connection to the ‘standard definition’ output. If there are questions regarding your TV set compatibility with this model 525p DVD player, please contact our customer service center.

Note to the Cable TV System Installer: This reminder is provided to call

the Cable TV system installer’s attention to Article 820-40 of the National Electrical Code, which provides guidelines for proper grounding – in particular, specifying that the cable ground shall be connected to the grounding system of the building, as close to the point of cable entry as possible.

Declaration of Conformity

Model Number: DVP620VR/07 Trade Name: Philips Responsible Party: Philips Consumer Electronics North America

P. O . Box

14810

Knoxville,TN 379

14-1810

(865) 52

1-4316

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 3

Page 4

Table of Contents

General Information

Safety and General Information . . . . . . . . . . . . . . . . .3

Table of Contents . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Playable Discs and Video Cassettes . . . . . . . . . . . . . .6

Initial DVD/VCR Setup

Hookups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-15

Remote Control Setup . . . . . . . . . . . . . . . . . . . . . .16

First-time DVD/VCR Setup . . . . . . . . . . . . . . . . . . .17

Basic Playback

Video Cassette Playback . . . . . . . . . . . . . . . . . . . . .18

Disc Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Basic DVD/VCR Controls

Display Panel (DVD) . . . . . . . . . . . . . . . . . . . . . . . .20

Display Panel (VCR) . . . . . . . . . . . . . . . . . . . . . . . .21

Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Rear Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Remote Control . . . . . . . . . . . . . . . . . . . . . . . .24-25

Additional VCR Setup

Channel Setup . . . . . . . . . . . . . . . . . . . . . . . . . .26-27

Clock (VCR) . . . . . . . . . . . . . . . . . . . . . . . . . . . .28-29

Language (VCR) . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

VCR Status Displays . . . . . . . . . . . . . . . . . . . . . . . .31

VCR Recording Options

Videotape Recording . . . . . . . . . . . . . . . . . . . . . . . .32

Recording One Channel/Watching Another . . . . . .33

One-Touch Recording . . . . . . . . . . . . . . . . . . . . . . .34

Rerecording (Tape Duplication) . . . . . . . . . . . . . . . .35

Timer Recording . . . . . . . . . . . . . . . . . . . . . . . .36-38

DVD to Videotape Duplication . . . . . . . . . . . . . . . .39

Video Cassette Playing Options

Repeat Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

Ta pe Counter . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

Time Search, Index Search . . . . . . . . . . . . . . . . . . . .42

Special Effects Playback . . . . . . . . . . . . . . . . . . . . . .43

Automatic Operation Features . . . . . . . . . . . . . . . .44

Additional VCR Features

Multi-Channel Television Sound . . . . . . . . . . . . .45-46

Hi-Fi Stereo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47

Disc Playback Features

DVD Disc Menus . . . . . . . . . . . . . . . . . . . . . . . . . .48

Fast Forward/Reverse Search . . . . . . . . . . . . . . . . .49

Title/Chapter Playback, Specific Time Playback . . . .50

Track Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51

Paused and Step-by-Step Playback, Resume On . . .52

Repeat,A-B Repeat . . . . . . . . . . . . . . . . . . . . . . . . .53

Markers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54

Subtitles, Camera Angles . . . . . . . . . . . . . . . . . . . . .55

Parental Controls Password . . . . . . . . . . . . . . . . . .56

Parental Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57

Audio Language, Stereo Sound Mode . . . . . . . . . . .58

Slow Motion, Zoom . . . . . . . . . . . . . . . . . . . . . . . .59

Programmed Playback . . . . . . . . . . . . . . . . . . . . . . .60

Random Playback . . . . . . . . . . . . . . . . . . . . . . . . . . .61

MP3/JPEG Playback . . . . . . . . . . . . . . . . . . . . . . . . .62

MP3/JPEG Displays . . . . . . . . . . . . . . . . . . . . . . . . .63

DVD Player Setup Options

Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64-65

Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66-67

Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68

On-Screen Displays . . . . . . . . . . . . . . . . . . . . . . . . .69

Black Level,Virtual Surround . . . . . . . . . . . . . . . . . .70

Initializing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .71

Information You May Need

Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73

Helpful Hints . . . . . . . . . . . . . . . . . . . . . . . . . . .74-77

Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . .78

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . .79

Information Index . . . . . . . . . . . . . . . . . . . . . . . . . .80

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 4

Page 5

Introduction

VCR Features

• Automatic Head Cleaner

• Channel Setup

• English, French, and Spanish menus and dis-

plays

• Multi-Channel TV Sound

• 19 Micron head

• Recording: One-Touch and Timer

• Repeat Play

• Searching:Time, Index, Forward, and Reverse

• Slow Motion

• Still Picture

•Tape Counter

•Tracking Adjustment

Welcome!

This DVD/VCR combines a Digital Video Disc (DVD) Player and a Hi-Fi Video Cassette Recorder (VCR) into one unit, letting you play DVDs,Audio Compact Discs (Audio CDs), and Video Cassettes on one piece of equipment. Read this owner’s manual carefully to learn how to use the features listed below.

Package Contents

The following items are provided with your new DVD/VCR.

• Remote Control and two AA batteries

• One black RF coaxial cable, 75 ohm

• One set of Audio (red and white tips) and Video (yellow tips) cables

• This Owner’s Manual and Quick-Use Guide

DVD Disc Menus...

Some explanations in this manual describe DVD Disc menus. DVD manufacturers set the menus, which vary among DVDs. Not all DVDs have menus. If the DVD has a menu, access it by pressing DVD, then DISC/VCR/MENU on the remote control.

Details are on page 48.

DVD Player Setup Menu...

Some instructions explain how to use the DVD Player’s Setup menu to set up features of the DVD Player or a DVD.Access the DVD Player menu by pressing SYSTEM/MENU on the remote control when playback is stopped. Even if a feature is set in the DVD Player’s menu, it may not be available if the current DVD does not include that feature.

Available Disc Features...

All features described in this manual are not available on every Disc. If the feature is not available on the Disc, you cannot use the DVD/VCR to make it available.An “X” will appear in the top right corner of the TV screen if you try to access a feature that is not currently available.

Disc Features

• Audio Language choices*

• Bit Rate display

• Camera Angle*

• Dolby Digital Sound*

•DVD to Videotape Duplication

• Dynamic Range Control

• Fast/Paused/Slow/Step-by-Step Playback

• Markers

• Parental Controls*

•Program Playback

• Progressive Scan

• Random Playback

• Repeat, Repeat A-B

• Screen Saver

• Search (Title/Chapter,Time,Track)

• Subtitles*

• Virtual Surround

•Zoom

* If available on the DVD

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 5

Page 6

Playable Discs and Video Cassettes

Region Codes

This DVD/VCR has a Region One (1) DVD Player. DVDs must be labeled for ALL regions or for Region 1 in order to play on the DVD Player.You cannot play DVDs that are labeled for other regions. Look for the symbols below on your DVDs. If these region symbols do not appear on your DVD, you cannot play the DVD in this DVD Player.

The number inside the globe refers to a region of the world. Region 1 represents the United States, Canada, upper regions of North America, Bermuda, the U.S.Virgin Islands, and small regions near Australia. A DVD labelled for a specific region can only play on DVD Players with the same region code.

Color Systems

DVDs are recorded in different color systems throughout the world.The most common color systems are NTSC (which is used primarily in the United States and North America), PAL, and SECAM. This DVD Player will play both NTSC and PAL DVDs.You cannot play DVDs recorded in other formats.The color system of the DVD may be listed on the DVD or on the Disc case.Your TV must have the NTSC and/or PAL color system as well.

Playable Video Cassettes

The VCR of this DVD/VCR has a High Quality (HQ) system and is compatible with existing Video Home System (VHS) equipment. Use only video cassettes that have the

mark.The use of other tapes may result in poor picture quality and excessive deposits on the video heads, which may not be covered by the warranty if damage occurs. The VCR also has a 19 micron head, which provides a better picture when you view tapes recorded in slow speed (SLP).

Playable Discs

The DVD Player will play Digital Video Discs (DVDs);Audio Compact Discs (CDs); finalized Digital Video Discs Rewritable (DVD+RW); finalized Compact Discs Rewritable (CDRW) and Compact Discs Recordable (CD-R); and Video Compact Discs (VCDs). To play a DVD, make sure it meets the requirements for Region Codes and Color Systems as described below. Discs that have the following logos will play on the DVD Player. Other Disc types are not guaranteed to play in the DVD/VCR. On a Super Audio CD, only the sound on the normal CD layer can be heard.The sound on the high-density Super Audio CD layer cannot be heard.

DVD Audio CD CD-RW/CD-R Video CD DVD+RW

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 6

Recordable

ReWritable

Page 7

Hookups

Determining the best possible connection...

Your hookup will be determined primarily by your existing equipment, especially your TV.These guidelines describe which options have the best picture and sound quality.You will not use all the jacks on the DVD/VCR.

If your TV only has an RF-style jack, usually labelled Antenna In, RF In, or 75 ohm, use the ANT-OUT jack of the DVD/VCR to connect to the TV.This hookup provides both audio and video in a single cable. Set your TV to channel 3 or 4 - the output channel of the DVD/VCR.This connection allows you to use both the DVD and VCR features.

See page eight.

★★★★ If your TV has Component Video In jacks (which could be labelled Y CR CB,Y PR PB, or YUV and may be

green, blue, and red), use the Component Video jacks (Y C

B/PB CR/PR) for the best picture quality. If you use

only this video connection, only the DVD picture will be available.To see DVD features on the TV,set the TV to its Component Video In channel. Component Video provides the best picture quality.

See page 12.

Progressive Scan provides less flickering and higher image resolution than traditional (525i/480i or interlace) TV signals. If your TV has Progressive Scan (525p/480p or progressive), connect the TV to the DVD/VCR’s COMPONENT VIDEO OUT (Y C

B/PB CR/PR) jacks.

Set PROGRESSIVE to ON in the DVD/VCR’s DISPLAY menu.

See pages 64-65. P.SCAN will appear on the

DVD/VCR’s display panel. Set your TV to Progressive Scan also. If your TV does not have Progressive Scan but has Component Video In jacks, connect them to the DVD/VCR’s COMPONENT VIDEO OUT jacks (Y C

B/PB CR/PR). Set PROGRESSIVE to OFF either in the

DISPLAY menu or by pressing and holding the PLAY

B (DVD) button on the front of the DVD/VCR for

more than five seconds.

See pages 12 and 64-65.

★★★ If your TV has an S-Video In jack (which also may be labelled Y/C or S-VHS), use the S-VIDEO OUT jack for

excellent picture quality. If you use only this video connection, only the DVD picture will be available.To see DVD features on the TV, set the TV to its S-Video In channel.

See page 13.

★★ If your TV has a single yellow Video In jack (which also may be labelled CVBS, Composite, or baseband), use

the yellow DVD/VCR VIDEO OUT jack for good picture quality.This connection provides a picture for both the DVD Player and the VCR.To see DVD or VCR features on the TV,set the TV to its Video In channel.

See

page

11.

★★★★ If you have a Stereo with a Coaxial Digital Audio In jack, this provides the clearest sound for the DVD Player.

Connect the DVD/VCR’s COAXIAL DIGITAL AUDIO OUT jack to your Stereo for the best sound quality.If you use only this audio connection,only Disc sound (no VCR) will be available.

See page 15.

★★★ If digital audio connections are not possible, connect the DVD/VCR’s red and white DVD/VCR AUDIO OUT

jacks to the Audio In jacks of your Stereo or TV.This connection provides sound for both the DVD Player and the VCR.

See pages 11-14.

Before you begin...

● Refer to the manuals of your TV, Cable Box, Stereo, or other devices as necessary. Note the style of jacks and con-

nectors on the other equipment. Determine how to choose different Audio and Video In channels on your other equipment so you can see and hear the DVD/VCR material playing on the TV, Stereo, etc.

● Disconnect all equipment from the power outlets. Connect the equipment to power only after you have finished

hooking up everything. Never make or change connections with equipment connected to power.

Remember...

● Set the TV to the correct Video In channel. Such channels may be called AUX or AUXILIARY IN,AUDIO/VIDEO or

A/V IN, EXT

1 or External In, etc.These channels often are located near channel zero (0).Or,your TV’s remote may have a button or switch that selects the Video Input channel. See your TV manual for details. If you do not see the DVD or VCR playback on the TV, go to the lowest TV channel (0

1 or 02) and change channels downward until you see the DVD or VCR picture on the TV. Or, if your TV has only a single Antenna In jack and you are using the RF coaxial cable (as described on page eight), set the TV to channel 3 or 4. To help you find the right Audio/Video In channel, turn on the DVD/VCR. Press DVD to put the DVD/VCR in DVD mode.With no Disc in the Player, a large DVD Video logo will appear on the TV screen when you get the TV on the correct Audio/Video In channel or channel 3 or 4.

● Set the Stereo to the correct channel or “source” mode.

● Depending on your connection, you may need to purchase additional cables or adaptors. If your TV or monitor has

BNC-type connectors, you will need an adaptor.

● If you set Progressive Scan on or off when the power is on, the DVD/VCR will turn off.When you turn on the

DVD Player again, the last selected scanning system will be active.

● To use the VCR features, you must include a connection with the supplied yellow video cable and

red/white audio cables or with the supplied RF coaxial cable.

Once you determine the best option, find your choice on pages 8-

15. Follow the steps for the hookup

you choose.Then, go to page

17 to complete the first-time setup.

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 7

Page 8

ANT /

CABLE

ANT - IN

ANT-OUT

DIGITAL

AUDIO OUT

COAXIAL

AUDIO OUT

DVD

LRL

S-VIDEO OUT

COMPONENT VIDEO OUT

AUDIO OUT

DVD/VCR

VCR

ANT - IN

ANT-OUT

VIDEO OUT

AUDIO IN

VIDEO IN

CR / P

Black RF

coaxial cable

(supplied)

Antenna or

Cable TV

signal

Antenna In Jack (on back of TV)

example only

Hookups (cont’d)

Disconnect the antenna or Cable TV signal from your TV and connect it to the ANT-IN (Antenna In) jack of your DVD/VCR.

Connect the supplied black RF coaxial cable to the ANT-OUT (Antenna Out) jack on the back of the DVD/VCR and to the ANTENNA IN JACK on the TV. The ANTENNA IN jack on the TV may be

labelled TV IN, RF IN, 75Ω (ohm), or ANT-IN. See your TV owner’s manual for assistance.

Plug in the power cords of the TV and the DVD/VCR.

Set your TV to channel 3 or 4. The DVD/VCR’s output channel is 3 when you purchase it. So, set your TV to channel 3 when the DVD/VCR is new. If you cannot use channel 3 at your TV, you can change the DVD/VCR’s output channel to channel 4.To do so, press the VCR button to put the DVD/VCR in VCR mode.The VCR light will be on the front of the DVD/VCR. Insert a videotape and press PLAY B to start playback. During playback, press and

hold the (VCR) PLAY B button on the front of the DVD/VCR for three to five seconds. Each time you do this, the DVD/VCR’s output chan-

nel switches between 3 and 4, and the selected channel number appears on the display panel. Change your TV to channel 3 or 4 accordingly. (You cannot change the DVD/VCR’s output channel while adjusting tracking manually. Press STOP C to stop play and cancel manual tracking, then press PLAY B to resume playing and change the output channel.) There is not a channel 3/4 switch on the DVD/VCR (as customary with most VCRs).

You are ready to turn on the DVD/VCR. Go to page 17 before turning on the DVD/VCR.

DVD/VCR to TV only

Simplest connection using only the supplied black RF coaxial cable

This connection will let you use the features of both the VCR and the DVD Player.

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 8

Page 9

Hookups (cont’d)

DIGITAL

AUDIO OUT

COAXIAL

AUDIO

OUT

DVD

LRL

S-VIDEO

OUT

COMPONENT VIDEO OUT

AUDIO OUT

DVD/VCR

VCR

ANT - IN

ANT-OUT

VIDEO OUT

AUDIO IN

VIDEO IN

CR / P

OUT

ANT /

CABLE

TV’s ANTENNA

IN Jack

Cable Box/Satellite Receiver

DVD/VCR

Connections

Connect a Cable TV or Satellite signal to the IN jack on the Cable Box/Satellite Receiver.

Use an RF coaxial cable (as the one supplied) to connect the OUT jack on the Cable Box/Satellite Receiver to the ANT-IN (Antenna In) jack on the DVD/VCR.

Use a second RF coaxial cable to connect the ANTOUT (Antenna Out) jack on the DVD/VCR to the TV’s Antenna In jack.

Remember...

There are two ways to connect your Cable Box/Satellite Receiver to the DVD/VCR.With the connection on this page:

● Select TV channels at the Cable Box/Satellite Receiver, not the

DVD/VCR.To record or view TV channels, follow these steps:

1) Press VCR to put the DVD/VCR in VCR mode.The VCR light will appear on the front of the DVD/VCR.

2) Press SKIP ∑/CH o or SKIP w/CH p to set the DVD/VCR to the Cable Box/Satellite Receiver output channel (03 or 04).

3) Set the TV to the DVD/VCR’s output channel (03 or 04).The DVD/VCR’s output channel is channel 3 when the DVD/VCR is new.To change it from 3 to 4, press and hold the (VCR) PLAY B button on the DVD/VCR for 3-5 seconds during tape playback. For more details, see step 4 on page eight.

4) Select the channel you want to view/record at the Cable Box/Satellite Receiver.

●

You may not view a channel other than the one you are recording.

●

You can only program a timer recording for one channel at a time. Set your Cable Box/Satellite Receiver to the channel you want to record.When you enter the channel you want to record in a timer recording, select channel 03 or 04 (the Cable Box/Satellite Receiver output channel). (This is step 8 on page 37.) Leave the Cable Box/Satellite Receiver on for a timer recording.

Cable

Signal

RF coaxial cable

DVD/VCR to Cable Box or Satellite Receiver and TV

Using only basic RF coaxial cables

This connection will let you use the features of both the VCR and the DVD Player.

• If your Cable Box or Satellite Receiver has Audio and Video Out jacks, use audio and video cables to connect them to the VCR AUDIO IN and VIDEO IN jacks on the rear of the DVD/VCR.You will not need the RF coaxial cable connection between the Cable Box/Satellite Receiver and the DVD/VCR as described at step 2.

Helpful Hint

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 9

Page 10

Hookups (cont’d)

ANT - IN

ANT-OUT

OUT

NT /

ABLE

TV’s ANTENNA

IN Jack

Cable Box/Satellite Receiver

DVD/VCR

Connections

Connect a Cable TV or Satellite signal to the DVD/VCR’s ANT-IN (Antenna In) jack.

Use an RF coaxial cable (as the one supplied) to connect the ANT-OUT (Antenna Out) jack on the DVD/VCR to the IN jack on the Cable Box/Satellite Receiver.

Use a second RF coaxial cable to connect the OUT jack on the Cable Box/Satellite Receiver to the ANTENNA IN jack on the TV.

Remember...

There are two ways to connect your Cable Box/Satellite Receiver to the DVD/VCR.With the connection on this page:

● You may watch one channel while recording another. Follow these

steps:

1) Put the Cable Box/Satellite Receiver on the same channel as the DVD/VCR’s output channel (03 or 04).The DVD/VCR’s output channel is channel 3 when the DVD/VCR is new.To alternate it between 3 and 4, press and hold the (VCR) PLAY

B button on the

front of the DVD/VCR for 3-5 seconds during tape playback.

For

details, see step 4 on page eight. Set the TV to the Cable

Box/Satellite Receiver output channel (03 or 04).

2) Press VCR to put the DVD/VCR in VCR mode.The VCR light will appear on the front of the DVD/VCR.

3) Press VCR/TV on the remote to choose VCR position.

4) Press SKIP ∑/CH o or SKIP w/CH p to select the channel you want to record at the DVD/VCR. Press RECORD

I to start

the recording.

5) Press VCR/TV on the remote once to put the DVD/VCR in TV position.

6) Select the channel you want to watch at the Cable Box/Satellite Receiver.

● When you play a tape or Disc, make sure the Cable Box/Satellite

Receiver is set to the DVD/VCR’s output channel (03 or 04). Set the TV to the Cable Box/Satellite Receiver output channel (03

or 04).

Cable Signal

RF coaxial cable

DVD/VCR to Cable Box or Satellite Receiver and TV

Using only basic RF coaxial cables

This connection will let you use the features of both the VCR and the DVD Player.

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 10

Page 11

Hookups (cont’d)

DIGITAL

AUDIO OUT

COAXIAL

AUDIO

OUT

DVD

LRL

S-VIDEO

OUT

COMPONENT VIDEO OUT

AUDIO OUT

DVD/VCR

VCR

ANT - IN

ANT-OUT

VIDEO OUT

AUDIO IN

VIDEO IN

CR / P

AUDIO IN

VIDEO IN

Antenna or Cable TV Signal to ANT-IN Jack

Audio Cables

Video Cable

Audio and

Video IN Jacks

on TV

Connect the antenna or Cable TV signal to the ANT-IN (Antenna In) jack of your DVD/VCR.

Connect the red and white audio cables (supplied) to the red and white DVD/VCR AUDIO OUT jacks on the DVD/VCR and to the red and white AUDIO IN jacks on the TV. Match the cable colors to the jack

colors. If the TV has a single AUDIO IN jack, use the white audio cable to connect the DVD/VCR’s white DVD/VCR AUDIO OUT (left) jack to the TV’s AUDIO IN jack.You will not use the red cable. Or, purchase a “splitter” audio cable to go from the left/right AUDIO OUT jacks of the DVD/VCR to the TV’s single AUDIO IN jack.

Connect the yellow video cable (supplied) to the DVD/VCR VIDEO OUT jack on the DVD/VCR and to the VIDEO IN jack on the TV.

The VIDEO IN jack on the TV is usually yellow and may be labelled CVBS, Composite, or Baseband video.

Connect the power cords of the TV and the DVD/VCR to a power outlet.Turn on the TV and set it to the correct Audio/Video In channel. Go to your lowest TV channel (01 or 02), then change channels down-

ward until you see VCR or DVD playback on the TV screen.

To help you find the right Audio/Video In channel, turn on the DVD/VCR. Press DVD to put the DVD/VCR in DVD mode.With no Disc in the Player, a large DVD Video logo will appear on the TV screen when you get the TV on the correct Audio/Video In channel. Make sure PROGRESSIVE is OFF and P.SCAN does not appear on the DVD/VCR’s display panel. Disable

Progressive Scan either in the DISPLAY menu or by pressing and holding PLAY B (DVD) on the front of the DVD/VCR for more than five seconds. Details are on pages seven and 64-65.

You are ready to turn on the DVD/VCR. Go to page 17 to complete the first-time setup.

DVD/VCR to a TV that has Audio and Video In jacks

Using the supplied red, white, and yellow cables

This connection will let you use the features of both the VCR and the DVD Player.

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 11

Page 12

Hookups (cont’d)

DVD/VCR to a TV that has Component Video In jacks

AUDIO IN

Cb/Pb

Cr/Pr

COMPONENT

VIDEO IN

DIGITAL

AUDIO OUT

COAXIAL

AUDIO

OUT

DVD

LRL

S-VIDEO

OUT

COMPONENT VIDEO OUT

AUDIO OUT

DVD/VCR

VCR

ANT - IN

ANT-OUT

VIDEO OUT

AUDIO IN

VIDEO IN

CR / P

Connect the antenna or Cable TV signal to the ANT-IN (Antenna In) jack of your DVD/VCR.

Connect the supplied red and white audio cables to the red and white DVD/VCR AUDIO OUT jacks on the DVD/VCR and to the red and white AUDIO IN jacks on the TV. Match the cable colors to the jack

colors.

Connect component video cable (not supplied) to the COMPONENT VIDEO OUT jacks on the DVD/VCR and to the COMPONENT VIDEO IN jacks on the TV. The Component Video In jacks on the

TV are usually red, blue, and green.

The Component Video connection only supplies video (picture) for the DVD Player of the DVD/VCR.Therefore, in order to use the VCR features or view TV channels at the DVD/VCR, you still need to either connect the RF coaxial cable between the ANT-OUT jack of the DVD/VCR and the TV’s Antenna In jack, or connect the yellow video cable.To connect the supplied RF coaxial cable, see step 2 on page eight.To connect the supplied yellow video cable, see step 3 on page 11. If your TV is compatible with Progressive Scan (525p/480p), set PROGRESSIVE to ON in the DISPLAY menu so P. SCAN appears on the display panel. Details are on pages 64-65. If your TV is not compatible with Progressive Scan, disable Progressive Scan either in the DISPLAY menu or by pressing and holding PLAY B(DVD) on the front of the DVD/VCR for more than five seconds so P. SCAN does not appear on the display panel. Details are on pages 64-65.

Connect the power cords of the DVD/VCR and TV to a power outlet. Turn on the TV and set it to the Component Video In channel for DVD Player features.

If you are using the RF coaxial cable for VCR playback, choose channel 3 or 4 at the TV. If you are using the yellow video cable for VCR playback, choose the Video In channel at your TV. Go to your lowest TV channel and change channels down until you see VCR or DVD playback on the TV screen, or try channel 3 or 4 at the TV.

You are ready to turn on the DVD/VCR. Go to page 17 before turning on the DVD/VCR.

Antenna or

Cable TV

Signal

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 12

Page 13

Hookups (cont’d)

DVD/VCR to a TV that has an S-Video In jack

DIGITAL

AUDIO OUT

COAXIAL

AUDIO

OUT

DVD

LRL

S-VIDEO

OUT

COMPONENT VIDEO OUT

AUDIO OUT

DVD/VCR

VCR

ANT - IN

ANT-OUT

VIDEO OUT

AUDIO IN

VIDEO IN

CR / P

AUDIO IN

LEFT

RIGHT

S-VIDEO IN

Connect the antenna or Cable TV signal to the ANT-IN (Antenna In) jack of your DVD/VCR.

Connect the supplied red and white audio cables to the red and white DVD/VCR AUDIO OUT jacks on the DVD/VCR and to the red and white AUDIO IN jacks on the TV.

Match the cable colors to the jack

colors.

Connect an S-Video cable (not supplied) to the S-VIDEO OUT jack on the DVD/VCR and to the S-VIDEO IN jack on the TV.

The S-Video connection only supplies video (picture) for the DVD Player of the DVD/VCR.Therefore, in order to use the VCR features or view TV channels at the DVD/VCR, you still need to either connect the RF coaxial cable between the ANT-OUT jack of the DVD/VCR and the TV’s Antenna In jack, or connect the yellow video cable. To connect the supplied RF coaxial cable, see step 2 on page eight.To connect the supplied yellow video cable, see step 3 on page 11.

Connect the power cords of the DVD/VCR and TV to a power outlet. Turn on the TV and set it to the S-Video In channel for DVD Player features.

If you are using the RF coaxial cable for VCR playback, choose channel 3 or 4 at the TV. If you are using the yellow video cable for VCR playback, choose the Video In channel at your TV.To find the correct Video In channel, go to your lowest TV channel and change channels downward until you see VCR playback on the TV screen.

To help you find the right S-Video In channel, turn on the DVD/VCR. Press DVD to put the DVD/VCR in DVD mode.With no Disc in the Player, a large DVD Video logo will appear on the TV screen when you get the TV on the S-Video In channel. Make sure PROGRESSIVE is OFF and P.SCAN does not appear on the DVD/VCR display panel. Disable

Progressive Scan either in the DISPLAY menu or by pressing and holding PLAY B (DVD) on the front of the DVD/VCR for more than five seconds so P.SCAN does not appear on the display panel. Details are on

pages 64-65.

You are ready to turn on the DVD/VCR. Go to page 17 before turning on the DVD/VCR.

Antenna/Cable

TV Signal

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 13

Page 14

Hookups (cont’d)

DVD/VCR to a TV and a Stereo

DIGITAL

AUDIO OUT

COAXIAL

AUDIO

OUT

DVD

LRL

S-VIDEO

OUT

COMPONENT VIDEO OUT

AUDIO OUT

DVD/VCR

VCR

ANT - IN

ANT-OUT

VIDEO OUT

AUDIO IN

VIDEO IN

CR / P

VIDEO IN

AUDIO (LEFT) IN

AUDIO (RIGHT) IN

Connect the antenna or Cable TV signal to the ANT-IN (Antenna In) jack of your DVD/VCR.

Connect the supplied red and white audio cables to the red and white DVD/VCR AUDIO OUT jacks on the DVD/VCR and to the red and white AUDIO IN jacks on the Stereo. Match the cable colors to the

jack colors.

Connect the supplied yellow video cable to the DVD/VCR VIDEO OUT jack on the DVD/VCR and to the VIDEO IN jack on the TV.

To use Component Video cable or S-Video cable instead for the DVD Player, see pages

12-13.You will still need the yellow video cable or RF coaxial cable

for VCR features.

Connect the power cords of the DVD/VCR,TV, and Stereo to a power outlet.Turn on the TV and set it to the Video In channel. Or,

simply go to your TV’s lowest channel (02 or 03) and continue changing channels downward at the TV until you see VCR or DVD playback on the TV screen.

To help you find the right Video In channel at the TV, turn on the DVD/VCR. Press DVD to put the DVD/VCR in DVD mode.With no Disc in the Player, a large DVD Video logo will appear on the TV screen when you get the TV on the correct Video In channel.

Turn on the Stereo and set it to the correct Auxiliary or Source mode.

Check your Stereo manual for details.

You are ready to turn on the DVD/VCR. Go to page 17 before turning on the DVD/VCR.

Antenna/Cable

TV Signal

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 14

Page 15

Connect the antenna or Cable TV signal to the ANT-IN (Antenna In) jack of your DVD/VCR.

Connect a coaxial digital audio cable (not supplied) to the DVD/VCR’s COAXIAL DIGITAL AUDIO OUT jack and to the COAXIAL DIGITAL AUDIO IN jack on the Stereo.

This digital audio connection only provides sound for the DVD Player of the DVD/VCR. So, in order to use the VCR features or hear TV channels at the DVD/VCR, you still need to either connect the RF coaxial cable between the ANT-OUT jack of the DVD/VCR and the TV’s Antenna In jack, or connect the supplied red/white audio cables.To connect the supplied RF coaxial cable, see step 2 on page eight.To connect the red/white audio cables, see step 2 on page

11.

Connect the supplied yellow video cable to the yellow DVD/VCR VIDEO OUT jack on the DVD/VCR and to the VIDEO IN jack on the TV.

To use

component video cable or S-Video cable instead for the DVD Player, see pages

12-

13.You will still need the yellow video cable or RF coaxial cable for VCR features.

Plug in the power cords of the Stereo,TV, and DVD/VCR.Turn on the Stereo and select its Auxiliary IN channel.Turn on the TV and set it to the correct Video In channel.

Go to your TV’s lowest channel (01 or 02) and change channels downward until you see DVD or VCR material on the TV screen. To help you find the right Video In channel on the TV, turn on the DVD/VCR. Press DVD to put the DVD/VCR in DVD mode.With no Disc in the Player, a large DVD Video logo will appear on the TV screen when you get the TV on the correct Video In channel.

Make sure PROGRESSIVE is OFF and P.SCAN does not appear on the DVD/VCR’s display panel. Disable

Progressive Scan either in the DISPLAY menu or by pressing and holding PLAY B (DVD) on the front of the DVD/VCR for more than five seconds. Details are on pages seven and 64-65.

You are ready to turn on the DVD/VCR. Go to page 17 before turning on the DVD/VCR.

Remember...

Some DVDs are recorded in Dolby Digital 5.1 channel Surround Sound.Select Dolby Digital

5.1 channel Surround Sound in the DVD Disc menu. If Dolby Digital Surround Sound is not recorded on the Disc, you will not have surround sound available. If you connect the DVD/VCR to a Dolby Digital Stereo, set DOLBY DIGITAL to ON in the DVD Player’s Setup menu.

Details are on page 68. If the DVD/VCR is not connected to a

Dolby Digital-compatible Stereo,set DOLBY DIGITAL to OFF. Incorrect settings may cause noise distortion and damage the speakers.

Hookups (cont’d)

DVD/VCR to a TV and to a Stereo that is Dolby Digital-compatible

Using Digital Audio connections

DIGITAL

AUDIO OUT

COAXIAL

AUDIO

OUT

DVD

LRL

S-VIDEO

OUT

COMPONENT

VIDEO OUT

AUDIO OUT

DVD/VCR

VCR

ANT - IN

ANT-OUT

VIDEO OUT

AUDIO IN

VIDEO IN

CR / P

VIDEO IN

COAXIAL DIGITAL AUDIO IN

Back of TV

(example only)

Stereo

Antenna/Cable TV Signal

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 15

Page 16

Remote Control Setup

Putting Batteries in the Remote Control

Remove the battery compartment lid on the bottom of the remote control by pressing the tab, then lifting the lid.

Place two AA batteries inside the battery compartment

with their +and –ends aligned as indicated.

Replace the battery compartment lid.

Using the Remote Control

● Point the remote control at the DVD/VCR’s remote sensor (see

page 22) when using the remote to operate the DVD/VCR. Do not point the remote at the TV.

● Do not put objects between the remote and the DVD/VCR.

Recycling Guidelines/Battery Safety

● Your new product and its packaging contain materials that can

be recycled and reused. Specialized companies can recycle your product to increase the amount that needs to be properly disposed.Your product uses batteries that should not be thrown away when depleted but should be disposed of as small chemical waste. Please find out about the local regulations on disposal of your old product, batteries, and packaging whenever you replace existing equipment.

● Battery Usage CAUTION - To prevent battery leakage that may

result in bodily injury, property damage, or damage to the unit: Install ALL batteries correctly, with the + and - markings on the battery aligned as indicated on the unit; Do not mix batteries, for example, old with new or carbon with alkaline; and Remove batteries when the unit will not be used for a long time.

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 16

Page 17

First-time DVD/VCR Setup

Press o or p to select English, French, or Spanish as the language for VCR on-screen displays and menus.

Then,

press B.

Press B to begin channel programming. AUTO SETUP will flash on the TV screen during the channel search.The DVD/VCR will memorize all available channels. When channel programming is complete, the lowest available channel will appear on the TV. These channels will be available when you want to watch TV while in VCR mode.To put the DVD/VCR in VCR mode, press VCR so the VCR light appears. Use the SKIP ∑/CH o or SKIP w/CH p buttons to select memorized channels.To select non-memorized channels, use the Number buttons.

• To skip this feature and play a tape immediately, insert a tape with its record tab removed.

• To skip step 3, press DISC/VCR/MENU.VCR menus and displays will be in English.

• If you try to program channels when there is no antenna or Cable TV signal connected to the ANT-IN jack of the DVD/VCR, programming will stop.AUTO SET UP will stop flashing. Connect an antenna or Cable TV signal to the DVD/VCR’s ANT-IN jack and press Bagain.

• Repeat this process if the power fails.

•To stop the Channel Setup while AUTO SET UP is flashing, press DISC/VCR/MENU.

Helpful Hints

Before turning on your DVD/VCR, make sure batteries are in the remote control and the DVD/VCR and TV are connected correctly. You cannot program channels if you are using a Cable Box or a Satellite Receiver.

These menus may not appear if you have already turned on the DVD/VCR.

Turn on the TV. Set it to channel 3 or 4 or its AUDIO/VIDEO IN channel, depending on how you con-

nected the DVD/VCR to a TV.

Press VCR, then press STANDBY-ON yy. The VCR light will appear on the front of the DVD/VCR.The display shown below will appear. These menus may not appear if you have already turned on the DVD/VCR.You may have turned on the DVD/VCR before to find the Audio/Video In channel of the TV, for example. If so, follow the steps on page 26 to set up channels and page 30 to select a language for the VCR menus.

Turn on the TV.

AUTO SET UP

PUSH B

3-4

LANGUAGE SELECT

BENGLISH [ON]

FRANCAIS ESPAÑOL

PUSH

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 17

SEARCH MODE

REPEAT REPEAT

SUBTITLE ZOOM

RETURN TITLE

DISC/VCR

SPEED

STANDBY-ON

DISPLAY

AUDIO

A-B

ANGLE

CLEAR/RESET SLOW

DVDVCR VCR/TV

MENU MENU

SYSTEM

PLAY

PAUSESTOP

MARKER RECORDTIMER SET

1 2 3

+10

SKIP / CH

Page 18

Video Cassette Playback

• Other tape playback features are on pages 40-47.

• If AUTO REPEAT is ON, playback will begin when you insert a tape, even when the record tab is intact. Details are on page 40.

• You must connect the DVD/VCR to a TV using the RF coaxial cable or the audio/video cables in order to use the VCR features.These hookups are explained on pages eight and

11.

Helpful Hints

Read and follow the steps below to play a tape.

Turn on the TV. Set it to channel 3 or 4 or its AUDIO/VIDEO IN channel. This depends on how you

connected the DVD/VCR to a TV.

Details are on pages 7-15.

With the DVD/VCR power off, insert a tape in the cassette compartment of the DVD/VCR.The VCR

light will appear on the front of the DVD/VCR. If the tape’s record tab has been removed, play will start automatically. If the DVD/VCR power is already on, press VCR to put the DVD/VCR in VCR mode if necessary.The VCR light will appear on the front of the DVD/VCR.

If playback does not start automatically, press VCR, then press PLAY B.

Press STOP C to stop playback.

Press h to rewind the tape.

After the tape stops, press STOP/EJECT CA on the front of the DVD/VCR to remove the tape.

1 2

Press STOP/EJECT C A on the DVD/VCR.

Turn on the TV.

Insert a tape in the DVD/VCR.

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 18

SEARCH MODE

REPEAT REPEAT

SUBTITLE ZOOM

RETURN TITLE

DISC/VCR

MENU MENU

SPEED

A-B

1 2 3

STANDBY-ON

DISPLAY

AUDIO

ANGLE

CLEAR/RESET SLOW

PLAY

MARKER RECORDTIMER SET

SKIP / CH

DVDVCR VCR/TV

SYSTEM

PAUSESTOP

+10

Page 19

Disc Playback

• An “X” may appear at the top right corner of the TV screen when you try a feature. Either the feature is not available on the Disc, or the DVD/VCR cannot access the feature at this time.This does not indicate a problem with the DVD/VCR.

• If a Disc is dirty or scratched, the picture may appear distorted or playback may stop. Remove the Disc and turn off the DVD/VCR. Disconnect the power cord, then reconnect it. Clean the Disc, then turn on the DVD/VCR again and reinsert the Disc for playback.

• When the DVD or CD light appears on the display panel, the Disc is loaded and ready for playback.

• When you press OPEN/CLOSE

or PLAY (DVD) on the front of the DVD/VCR when the power is off,the DVD/VCR will turn on in DVD mode. Otherwise, the DVD/VCR will turn on in the mode in which it was turned off.

Helpful Hints

Before you begin, turn on the TV, Stereo, and other equipment connected to the DVD/VCR. Make sure the TV and the Stereo (if applicable) are set to the correct channel.

Details are on pages 7-15.

Press STANDBY-ON yyto turn on the DVD/VCR.

Press DVD so the DVD light appears on the front of the DVD/VCR.

Press OPEN/CLOSE A (to the left of the disc tray on the front of the DVD/VCR) to open the Disc tray.

Place a Disc into the tray. If the DVD is recorded on only one side, place the Disc in the tray with the label facing up and the shiny side facing down. Some DVDs are recorded on both sides. Make sure the label of the side you want to play is facing up.

Press PLAY B. The tray will close and play will begin at the first Chapter or Track. If a DVD menu appears instead, see page 48. With some Audio CDs, playback will not begin unless you press PLAY B. Or, press OPEN/CLOSE A or press the tray toward the DVD/VCR to close the tray. With MP3 and JPEG files, playback will begin from the beginning of the disc.

Press STOP C to stop playback.

Insert a Disc.

Remember, this DVD/VCR

will play only certain Discs.

See page six for details.

Press OPEN/CLOSE A

on the DVD/VCR.

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 19

SEARCH MODE

REPEAT REPEAT

SUBTITLE ZOOM

RETURN TITLE

DISC/VCR

MENU MENU

DISPLAY

AUDIO

A-B

ANGLE

CLEAR/RESET SLOW

PLAY

MARKER RECORDTIMER SET

STANDBY-ON

SKIP / CH

DVDVCR VCR/TV

SYSTEM

PAUSESTOP

Page 20

Display Panel (DVD)

Display

Messages about current Disc operations appear here. See Display Messages below.

STANDBY-ON

SOURCE

POWER ON

VIDEO AUDIO REW F.FWD PLAY

RECORD CHANNEL

VCR

OPEN/CLOSE

DVD

STOP PLAY

ONE TOUCH RECORDING • LONG PLAY

STOP/EJECT

GROUP P.SCAN

DVD

VCD

DVD light

This light appears when the DVD/VCR is in DVD mode.You can only watch DVDs when the DVD light is on.To make the DVD light come on, press SOURCE on the front of the DVD/VCR or DVD on the remote.

Disc tray

Insert a Disc here.

Appears after the disc tray closes if the tray is empty, if there is an error reading the disc, or if an unacceptable disc is installed.

Tr ay is opening or is open.

Tr ay is closing.

Disc is loading.

Appears when Playback Control is active (Video CD).

Display Messages

Appears when a repeat function is active

Appears when A-B Repeat is on

Appears during Disc play

Appears during slow motion play (DVD, Video CD)

Appears when Progressive Scan is active

Displays the current Disc type

• DVD: DVD

• CD:Audio CD,MP3, JPEG

• VCD:Video CD

Displays the elapsed playing time of the current Title or Track; briefly displays a Track, Chapter, or Title number when play begins.

Appears when ALL Repeat is on

Appears when Disc play is paused

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 20

Page 21

STANDBY-ON

SOURCE

POWER ON

VIDEO AUDIO REW F.FWD PLAY

RECORD CHANNEL

VCR

OPEN/CLOSE

DVD

STOP PLAY

ONE TOUCH RECORDING • LONG PLAY

STOP/EJECT

VCR REC

Display Panel (VCR)

Cassette Compartment

Insert a video cassette here.

VCR light

This light appears when the DVD/VCR is in VCR mode.You can only watch videotapes or access VCR features and TV channels when the VCR light is on. To make the VCR light come on, press VCR on the remote control or SOURCE on the front of the DVD/VCR.

Indicates a tape is in the DVD/VCR.

Indicates VCR position

Appears if Repeat Play is active

Appears if tape play is paused or during slow motion tape play

Appears during tape play

Appears when a timer recording or an OTR has been set

Appears during recording; flashes when recording is paused

Indicates current time is P.M. There is no A.M. indication.

Indicates the elapsed playing time of a tape; also displays a channel number, tape speed, remaining time for an OTR, or the current time

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 21

Page 22

Front Panel

STANDBY-ON

SOURCE

POWER ON

VIDEO AUDIO REW F.FWD PLAY

RECORD CHANNEL

VCR

OPEN/CLOSE

DVD

STOP PLAY

ONE TOUCH RECORDING • LONG PLAY

STOP/EJECT

OPEN/CLOSE A Button (DVD)

Press to open or close the Disc tray.

CHANNEL op Buttons

Press to select TV channels at the VCR.

PLAY B Button (VCR)

Press to play a video cassette. Press to release Slow, Search, or Still mode and return to playback.

Details are on page 43.

STOP/EJECT C A Button (VCR)

Press once to stop tape playback.When play is stopped, press to eject the tape.

RECORD I button (VCR)

Press once to start a recording. Press repeatedly to start a One-Touch Recording. Details are on page 34.

Remote Sensor

Receives a signal from your remote control so you can work your DVD/VCR from a distance. Point the remote here, not at your TV.

STANDBY-ON yyButton

Press to turn the power on or off.

POWER ON Light

Appears when the DVD/VCR power is on

AUDIO and VIDEO In Jacks

Connect audio and video cables from a camcorder,VCR, etc. here. This will be useful if you want to copy a videotape or watch material that is playing on other equipment.

Details are on page 35.

STOP C Button (DVD)

Press to stop Disc playback.

Details are on page 19.

PLAY B Button (DVD)

Press to start Disc playback.

Details are on page 19.

Press and hold for more than five seconds to disable Progressive Scan.

Details are on pages seven and 64-65.

SOURCE Button

Press to select DVD mode or VCR mode.The DVD light appears in DVD mode.The VCR light appears in VCR mode.

REW h Button (VCR)

Press to rewind the tape. Details

are on page 43.

F. FWD g Button (VCR)

Press to fast forward the tape. Details are

on page 43.

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 22

Page 23

Rear Panel

DVD COMPONENT VIDEO OUT

(Y CB/PB CR/PR) Jacks (green, blue, red)

Connect component video cables (not supplied) here and to the Component Video In jacks of a TV.This supplies the picture only for the DVD Player. Details are on page 12.

DIGITAL

AUDIO OUT

COAXIAL

AUDIO

OUT

DVD

LRL

S-VIDEO

OUT

COMPONENT VIDEO OUT

B /

AUDIO OUT

DVD/VCR

VCR

ANT - IN

ANT-OUT

VIDEO OUT

AUDIO IN

VIDEO IN

CR / PR

AC Power Cord

Connect to a standard AC outlet to supply power to the DVD/VCR.

DVD S-VIDEO OUT Jack

Connect an S-Video cable (not supplied) here and to the S-Video In jack of a TV. This supplies the picture only for the DVD Player. Details are on page 13.

DVD/VCR VIDEO OUT Jack (yellow)

Connect the yellow video cable (supplied) here and to the TV’s Video In jack.This supplies the picture for both the VCR and the DVD Player. Details are on page 11.

DVD AUDIO OUT jacks Left (white) and Right (red)

Connect the supplied audio cables here and to the Audio In jacks of a TV or Stereo.These jacks only supply audio for the DVD Player. Use these for a second connection to a TV, etc.

DVD COAXIAL DIGITAL AUDIO OUT Jack (black)

Connect a coaxial digital audio cable (not supplied) here and to the Coaxial Digital Audio In jack of a Stereo.This supplies audio only for the DVD Player. Details are on page 15.

ANT-IN (Antenna In) jack

Connect your antenna or Cable TV signal here.

Details are on pages 8-15.

ANT-OUT (Antenna Out) Jack

Use the supplied RF coaxial cable to connect this jack to the ANTENNA IN jack on your TV, Cable Box, or Satellite Receiver. Details are on pages 8-10.

VCR VIDEO IN Jack (yellow)

Connect a video cable from a camcorder,VCR, or DVD Player here. Details are on page 35.

VCR AUDIO IN jacks Left (white) and Right (red)

Connect audio cables coming from the audio out jacks of a camcorder, another VCR, another DVD Player, or Stereo here. Details are on page 35. This will be useful if you want to copy a videotape or watch material that is playing on other equipment.

• The DVD S-VIDEO OUT, DVD COMPONENT VIDEO OUT, DVD AUDIO OUT and DVD COAXIAL DIGITAL AUDIO OUT jacks are only useful in DVD mode.To have sound and picture in VCR mode, you must connect either the RF coaxial cable or the audio/video cables supplied. Details are on pages eight and 11.

Helpful Hint

DVD/VCR AUDIO OUT Jacks Left (white) and Right (red)

Connect the supplied audio cables here and to the Audio In jacks of a TV or Stereo. Details are on pages 11-14. These jacks provide audio for both the DVD Player and the VCR.

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 23

Page 24

Remote Control

• For DVD Player features, press DVD before pressing other buttons.To put the DVD/VCR in DVD mode, press DVD or SOURCE so the DVD light appears on the front of the DVD/VCR.

• For VCR features, press VCR before pressing any other buttons.To put the DVD/VCR in VCR mode, press VCR or SOURCE so the VCR light appears on the front of the DVD/VCR.

Helpful Hints

STANDBY-ON

PLAY

DVD

VCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

STANDBY-ON yyButton

Press to turn the power on or off.

sB KLButtons

Press to select an item in a menu.

g (Fast Forward) Button

In DVD mode, press to fast forward the Disc. Details are on page

49. Press when DVD/Video CD play is paused to start slow motion play. Details are on page

59.

In VCR mode, press to fast

forward the tape. Details are on

page 43.

DISPLAY Button

In VCR mode, press to see status displays. Details are on page 31. In DVD mode, press to access Disc information.

Details are on page 69.

REPEAT Button

Press to play a Track, Audio CD,Title, or Chapter repeatedly. Details are on page 53.

A-B REPEAT Button

Press to set up A-B Repeat.

Details are on page 53.

RETURN Button

Press to return to the previous level of the DVD Player’s Setup menu or to remove the Setup menu.

SKIP ∑∑/CH ooor SKIP ww/ CH

In DVD mode, press to skip Chapters or Tracks. In VCR mode, press to change TV channels at the DVD/VCR. Press to adjust tracking.

Details are on page 44.

RECORD I Button

Press to start a VCR recording. Details are on page 32. Press repeatedly to start a One-Touch Recording.

Details are on page 34.

SEARCH Button

In DVD mode, press to search for a specific Title/Chapter/Track/Time. Details

are on pages 50-51.

In VCR mode, press for a Time Search or an Index Search.

Details are on page 42.

SLOW Button

Press to view a videotape in slow motion. Details are on page 43.

CLEAR/RESET Button

Press to remove VCR menus. Press to reset the tape counter.

Details are on page 41.

Press to reset a menu item in DVD mode.

PAUSE k Button

Press to pause Disc playback. Press repeatedly to advance the DVD or Video CD picture step by step (or one frame at a time). Details are on page 52. Press to pause or resume VCR recording. Details are on page

32. Press to pause a tape. Details are on page 43.

STOP C Button

Press to stop Disc playback, tape playback, or recording.

MARKER Button

Press to see the Markers, which give you quick access to points you select on a Disc.

Details are on page 54.

TITLE Button

Press to see a DVD Title menu. Details are on page 48.

PLAY B Button

Press to begin Disc or tape playback.

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 24

Page 25

Remote Control (cont’d)

TIMER SET Button

Press to set a timer recording that you have programmed.

Details are on pages 36-38.

SUBTITLE Button

Press to select a language for DVD subtitles. Details are on

page 55.

VCR Button

Press before using the remote control for VCR features. Press to put the DVD/VCR in VCR mode.

OK Button

Press to confirm or select menu items.

ANGLE Button

Press to see a DVD picture from a different angle. Details

are on page 55.

Number Buttons

In DVD mode, press to select a Track or Chapter for playback. Use the +10 button for items 10 and above.

Details are on page 51.

In VCR mode, use to select TV channels. Enter channel numbers as a twodigit number for the quickest results (to select channel 6, press 0,6). For channels 100 and above, enter a three-digit number (for channel 117, press 1, 1, 7). If you have Cable TV, channels 1-125 are available. If you have an antenna, channels 2-69 are available.The +10 button has no effect in VCR mode.

ZOOM Button

Press to enlarge the DVD, Video CD, or JPEG image.

Details are on page 59.

STANDBY-ON

PLAY

DVD

VCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

MODE Button

Press to set a Program. Details are on page 60. Press to start

Random playback.

Details are on page 61.

SYSTEM/MENU Button

Press to access or remove the DVD Player’s Setup menu.

VCR/TV Button

Press to select VCR or TV position. In VCR position, watch a tape or watch/record TV programs (changing channels at the VCR). Use TV position to watch TV channels (changing channels at the TV) or watch one program while recording another.

Details are on page 33.

h (Rewind) Button

Press to fast reverse a Disc. Details are on page 49. Press when DVD playback is paused to start reverse slow motion playback.

Details are on page

59. Press to rewind a tape. Details are on page 43.

AUDIO Button

Press to choose a DVD audio language or an Audio CD sound mode.

Details are on page 58.

DISC/VCR/MENU Button

Press to access or remove a DVD Disc menu or the VCR menu.

DVD Button

Press before using the remote control for DVD features. Press to put the DVD/VCR in DVD mode.

SPEED Button

Press to select the VCR’s recording speed (SP or SLP).

Details are

on pages 32, 35, and 72.

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 25

Page 26

Channel Setup

CH01

AUTO SET UP

- M E N U -

BTIMER PROGRAMMING

AUTO REPEAT [OFF] CHANNEL SET UP CLOCK SET LANGUAGE SELECT AUDIO OUT TV STEREO [ON] SAP

• You cannot program channels if you are using a Cable Box or Satellite Receiver.

• If you have an antenna, channels 2-69 will be possible. If you have Cable TV, channels

1-125 will be

possible.

•To stop Channel Setup, press DISC/VCR/MENU while AUTO SET UP is flashing.

Helpful Hints

Although your DVD/VCR may automatically memorize the channels you receive when you turn it on for the first time, you can set up the channels again.

Press VCR, then press DISC/VCR/MENU so MENU appears.

Press o or p to select CHANNEL SET UP.Then, press B.

Press o or p to select AUTO SET UP. Press B.

AUTO SET UP will flash while the DVD/VCR sets up the available channels.When setup is complete, the lowest available channel will appear on the TV. Now when you press SKIP ∑∑/CH ooor SKIP ww/CH

,you will scan only through available channels.You still can

select any channel using the Number buttons.

CHANNEL SET UP

BAUTO SET UP

MANUAL SET UP

2-3

- M E N U -

TIMER PROGRAMMING AUTO REPEAT [OFF]

BCHANNEL SET UP

CLOCK SET LANGUAGE SELECT AUDIO OUT TV STEREO [ON] SAP

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 26

Page 27

Channel Setup (cont’d)

Adding/Deleting Channels

You may want to add or delete TV channels if your channel lineup changes or if you no longer watch some channels.

Press VCR, then press DISC/VCR/MENU so MENU appears.

Press o or p to select CHANNEL SET UP, then press B.

Press o or p to select MANUAL SET UP, then press B.

CHANNEL SET UP

AUTO SET UP

BMANUAL SET UP

MANUAL SET UP

CHANNEL 30 (CATV)

ADD

Press B or s so ADD or DELETE flashes on the screen.

While your choice is flashing, press CLEAR/RESET.

The channel you added or deleted will be the current channel.Added channels are available when you flip through channels using the SKIP

∑/CH o and SKIP w/ CH p but- tons.You still can select deleted channels with the Number buttons.

Press o or p until the channel number you want to add or delete appears on the screen.

2-5

STANDBY-ON

PLAY

DVD

VCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 27

Page 28

Clock (VCR)

CLOCK SET

MONTH DAY YEAR

0 3 / 2 0 – – – –

HOUR MINUTE AM/PM

– – : – – – –

While the DAY space is flashing, press o or p until the day appears.Then, press

While the YEAR space is flashing, press o or p until the year appears. Press B. The day of the week will

appear automatically.

CLOCK SET

MONTH DAY YEAR

0 3 / 2 1 SAT 2 0 0 4

HOUR MINUTE AM/PM

– – : – – – –

CLOCK SET

MONTH DAY YEAR

0 3 / – – – – – –

HOUR MINUTE AM/PM

– – : – – – –

• If the clock has never been set, the CLOCK SET menu may appear when you press DISC/VCR/MENU. If so, follow the instructions from step 3 above.

• Press DISPLAY until the time appears on the TV screen.

• Power failures of more than 30 seconds can erase the clock setting.

Helpful Hints

2-5

- M E N U -

BTIMER PROGRAMMING

AUTO REPEAT [OFF] CHANNEL SET UP CLOCK SET LANGUAGE SELECT AUDIO OUT TV STEREO [ON] SAP

Follow these steps to set the VCR clock. Make sure:

Press VCR, then press DISC/VCR/MENU so MENU appears.

Press o or p to select CLOCK SET, then press B.

While the MONTH space is flashing, press o or p until the month appears.Then, press B.

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 28

STANDBY-ON

SEARCH MODE

REPEAT REPEAT

SUBTITLE ZOOM

RETURN TITLE

DISC/VCR

MENU MENU

SPEED

DISPLAY

AUDIO

A-B

ANGLE

CLEAR/RESET SLOW

PLAY

MARKER RECORDTIMER SET

1 2 3

SKIP / CH

DVDVCR VCR/TV

SYSTEM

PAUSESTOP

+10

Page 29

Clock (VCR) (cont’d)

While the HOUR space is flashing, press o or p until the hour appears.Then, press B.

CLOCK SET

MONTH DAY YEAR

0 3 / 2 1 SAT 2 0 0 4

HOUR MINUTE AM/PM

0 5 : – – – –

While the MINUTE space is flashing, press o or p until the minute appears.Then, press B.

CLOCK SET

MONTH DAY YEAR

0 3 / 2 1 SAT 2 0 0 4

HOUR MINUTE AM/PM

0 5 : 4 0 – –

While the AM or PM space is flashing, press o or p to point to AM or PM.

Your selection will flash on the screen in the AM/PM space.

CLOCK SET

MONTH DAY YEAR

0 3 / 2 1 SAT 2 0 0 4

HOUR MINUTE AM/PM

0 5 : 4 0 P M AM

B PM

Press CLEAR/RESET or B to start the clock.

• To reset the clock, follow steps 1-2 on page 28. Select the information you want to change usingBor

.When the information is flash-

ing, use

or pto enter the correct information. Press CLEAR/RESET to set the clock.

Helpful Hint

6-9

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 29

SEARCH MODE

REPEAT REPEAT

A-B

SUBTITLE ZOOM

RETURN TITLE

DISC/VCR

SPEED

CLEAR/RESET SLOW

MENU MENU

PLAY

MARKER RECORDTIMER SET

1 2 3

STANDBY-ON

DISPLAY

AUDIO

ANGLE

SYSTEM

SKIP / CH

DVDVCR VCR/TV

PAUSESTOP

+10

Page 30

Language (VCR)

Follow the steps below to change the language of the VCR onscreen displays and menus.

Press VCR, then press DISC/VCR/MENU so MENU appears.

Press o or p to choose LANGUAGE SELECT, then press B.

Press o or p to choose ENGLISH, FRANCAIS (French), or ESPAÑOL (Spanish).

Press CLEAR/RESET to remove the menu.

• If you select FRANCAIS (French), or ESPAÑOL (Spanish) and need English:

1) Press DISC/VCR/MENU so MENU appears.

2) Presspto choose SELECTION LANGUE or SELEC. IDIOMA, then press

3) Press

or pto select ENGLISH.

4) Press CLEAR/RESET.

Helpful Hint

LANGUAGE SELECT

BENGLISH [ON]

FRANCAIS ESPAÑOL

2-3

- M E N U -

BTIMER PROGRAMMING

AUTO REPEAT [OFF] CHANNEL SET UP CLOCK SET LANGUAGE SELECT AUDIO OUT TV STEREO [ON] SAP

- M E N U -

TIMER PROGRAMMING AUTO REPEAT [OFF] CHANNEL SET UP CLOCK SET

BLANGUAGE SELECT

AUDIO OUT TV STEREO [ON] SAP

STANDBY-ON

PLAY

DVD

VCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 30

Page 31

VCR Status Displays

You may access status displays by pressing DISPLAY.The displays may include the current time, channel, and other information.

Press DISPLAY. The COUNT display will appear for five seconds.After five seconds, only the real-time tape counter will appear.This counter shows you the elapsed playing time of the tape (from the point at which the counter was set to zero).The counter also will appear on the display panel on the front of the DVD/VCR.

Press DISPLAY again. The CLOCK display will appear for five seconds.After five seconds, only the time will appear (the clock must be set). (If you are watching TV, the channel number and the availability of stereo or second audio will also appear.) The time also will appear on the display panel on the front of the DVD/VCR.

Press DISPLAY again to remove all the displays.

• If the channel you select has no broadcast, the screen will be solid blue.

• You cannot access a status display when viewing a still picture, during slow motion, or during forward and reverse searching.

• Channel numbers appear on the screen for a few seconds each time you change channels.

Helpful Hints

STOP

SLP 0:

12:34 HIFI

STOP 5:40 PM

CH 02

STEREO

SAP

SLP

1-3

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 31

STANDBY-ON

SEARCH MODE

REPEAT REPEAT

SUBTITLE ZOOM

RETURN TITLE

DISC/VCR

MENU MENU

SPEED

DISPLAY

AUDIO

A-B

ANGLE

CLEAR/RESET SLOW

PLAY

MARKER RECORDTIMER SET

1 2 3

SKIP / CH

DVDVCR VCR/TV

SYSTEM

PAUSESTOP

+10

Page 32

Videotape Recording

Read and follow the steps below to record a television program onto a videotape.

● Before you begin, make sure the DVD/VCR is in VCR mode.

Press VCR so the VCR light appears on the front of the DVD/VCR.

Turn on the TV and set it to channel 3 or 4 or the Video In channel. If you connected the DVD/VCR to the

TV using the supplied audio and video cables, select your TV’s Video In channel. Details are on page 11. If you connected the DVD/VCR to the TV using the supplied RF coaxial cable, choose channel 3 (or 4) at the TV.

Details are on pages 8-10.

Insert a tape with its record tab intact into the cassette compartment of the DVD/VCR. If tape playback

begins, press STOP C.

Press SPEED until the desired tape speed (SP or SLP) appears briefly on the screen. Details about tape

speed are on page 72.

Press SKIP ∑∑/CH ooor SKIP ww/CH ppor the Number buttons to select the TV channel to record.

Press RECORD I to start recording. REC will appear on the DVD/VCR’s display panel.

To pause the recording, press PAUSE k once. REC will flash.

To r esume recording, press RECORD I or

press PAUSE k again. REC will reappear.

To stop recording, press STOP C.

Recording Prevention

Video cassettes have record tabs to ensure that recordings are not accidentally erased.

To prevent recording, break off the tab with a screwdriver.

To allow recording, cover the hole with clear tape.

• Other recording options are on pages 33-39.

• The VCR will record in a preset volume.

• Pause will switch to Stop after five minutes to protect the VCR and the tape from damage.When a recording is paused, review the pause time remaining with the

■

marks on the screen. Each

■

mark equals one minute remaining. During the last minute of paused recording, the ■mark will flash.

• If any menu is on the TV screen, the RECORD Ibutton on the remote does not function. Press CLEAR/RESET to remove the menu.Then, press RECORD I.Or, use the RECORD Ibutton on the front of the DVD/VCR.

Helpful Hints

Turn on the TV.

Insert a tape in the DVD/VCR.

Remove the tab to prevent recording.

Cover the hole to allow recording.

5-6

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 32

STANDBY-ON

SEARCH MODE

REPEAT REPEAT

SUBTITLE ZOOM

RETURN TITLE

DISC/VCR

MENU MENU

SPEED

DISPLAY

AUDIO

A-B

ANGLE

CLEAR/RESET SLOW

PLAY

MARKER RECORDTIMER SET

1 2 3

SKIP / CH

DVDVCR VCR/TV

SYSTEM

PAUSESTOP

+10

Page 33

Recording One Channel/Watching Another

• If you use a Cable Box or Satellite Receiver, you may not be able to watch one channel while recording another. See pages 9-10 for details.

Helpful Hint

Select the channel you want to watch at the TV.

Reselect channel 03, 04, or Video In at the TV.

Press VCR, then press RECORD I to record the current TV channel. Details are on page 32.

Press VCR/TV once to put the DVD/VCR in TV position. The VCR light will disappear from the DVD/VCR’s

display panel.

Use the TV remote control to select the channel you want to watch at the TV.

To r eturn to the channel being recorded, use the TV remote control to return to channel 03 or 04 at the TV. Details are on page eight. Or, if you connected the

DVD/VCR to the TV using audio and video cables, return to the TV’s correct Video In channel. Details are on page 11.

Press VCR/TV on the DVD/VCR remote control to put the DVD/VCR in VCR position.

(The VCR light will appear in the DVD/VCR’s display panel again.) The channel being recorded will appear on the TV screen.

Press STOP C to stop the recording.

2,5

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 33

STANDBY-ON

SEARCH MODE

REPEAT REPEAT

SUBTITLE ZOOM

RETURN TITLE

VCR VCR/TV

DISC/VCR

MENU MENU

SPEED

A-B

DISPLAY

AUDIO

ANGLE

CLEAR/RESET SLOW

PLAY

MARKER RECORDTIMER SET

1 2 3

SKIP / CH

DVD

SYSTEM

PAUSESTOP

+10

Page 34

One-Touch Recording

OTR (0:30)

One-Touch Recording (OTR) lets you set a timed recording 30 minutes to eight hours long of the current TV channel. Before you begin:

● Place the DVD/VCR in VCR mode. Press VCR so the VCR light

appears on the front of the DVD/VCR.

● Select a recording speed (SP, SLP) with the SPEED button.

● Put a videotape in the cassette compartment. Make sure the

tape’s record tab is intact and the tape is long enough to record the program(s).

Press VCR, then press SKIP ∑/CH o or SKIP w/CH p or the Number buttons to select the channel you want to record.

Press RECORD I repeatedly until the desired recording length (30 minutes to eight hours) appears on the TV screen. Recording will begin. REC

and will appear on the DVD/VCR’s display panel.

Stopping an OTR

To stop an OTR before recording is finished, press STOP C on the remote control or STOP/EJECT C A (VCR) on the front of the DVD/VCR. To cancel the OTR but continue recording, press RECORD I repeatedly until RECORD appears in the upper left corner of the TV screen. When an OTR finishes, the DVD/VCR will either switch to DVD mode or turn itself off. If it changes to DVD mode, press STANDBY-ON y to turn it off. After an OTR, flashes because the VCR is still on standby for timer recordings. Press TIMER SET on the remote or STOP/EJECT C A (VCR) on the DVD/VCR to cancel timer standby and use the VCR normally again.

• The remaining recording time will appear on the display panel during an OTR. Press DISPLAY to see it on the TV screen.

• To change the recording length while an OTR is in progress, press RECORD I repeatedly.

• You cannot pause an OTR.

• If the preset time for a timer recording comes up during an OTR, the OTR has priority.The timer recording will not take place.

• If the end of the tape is reached during an OTR, the VCR will stop recording, eject the tape, and switch to DVD mode or turn off.

Helpful Hints

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 34

STANDBY-ON

SEARCH MODE

REPEAT REPEAT

SUBTITLE ZOOM

RETURN TITLE

DISC/VCR

MENU MENU

SPEED

DISPLAY

AUDIO

A-B

ANGLE

CLEAR/RESET SLOW

PLAY

MARKER RECORDTIMER SET

1 2 3

SKIP / CH

DVDVCR VCR/TV

SYSTEM

PAUSESTOP

+10

Page 35

Rerecording (Tape Duplication)

Make the connections shown above.

DVD/VCR 1 will play your tape. Put a prerecorded tape into the cassette compartment of DVD/VCR 1.

Press VCR to put the unit in VCR mode if necessary.

DVD/VCR 2 will record your tape. Insert a blank tape in the cassette compartment of DVD/VCR 2.

Press VCR

to put the unit in VCR mode if necessary.

Turn on the TV and set it to channel 03 or 04 (the RF output channel of DVD/VCR 2).To determine the DVD/VCR’s output channel, see step 4 on page eight.

Point the remote control at DVD/VCR 2. Press Number buttons 0, 0, 1 or 0, 0, 2. (See Helpful Hints to

the right.)

Press SPEED to select SP or SLP at DVD/VCR 2.

Press PLAY B (VCR) on the front of DVD/VCR 1 and RECORD I on the front of DVD/VCR 2 at the same time.

To stop recording, press STOP/EJECT C A (VCR) on DVD/VCR 1, then press STOP/EJECT C A (VCR) on DVD/VCR 2.

DIGITAL

AUDIO OUT

COAXIAL

AUDIO

OUT

DVD

LRL

S-VIDEO

OUT

COMPONENT VIDEO OUT

AUDIO OUT

DVD/VCR

VCR

ANT - IN

ANT-OUT

VIDEO OUT

AUDIO IN

VIDEO IN

CR / P

DIGITAL

AUDIO OUT

COAXIAL

AUDIO

OUT

DVD

LRL

S-VIDEO

OUT

COMPONENT VIDEO OUT

AUDIO OUT

DVD/VCR

VCR

ANT - IN

ANT-OUT

VIDEO OUT

AUDIO IN

VIDEO IN

CR / P

DVD/VCR 1

Playing unit

DVD/VCR 2

Recording unit

1. Audio cables from AUDIO OUT jacks (red and white)

of DVD/VCR 1 to AUDIO IN jacks of DVD/VCR 2

3. RF coaxial cable from the ANT-OUT

(Antenna Out) jack of DVD/VCR 2

to the TV’s ANTENNA IN jack

• If you use the AUDIO and VIDEO IN jacks on the back of DVD/VCR 2, press Number buttons 0, 0, 1 at step 5. L1 will appear on the TV screen.

• If you use the AUDIO and VIDEO In jacks on the front of DVD/VCR 2, press Number buttons 0, 0, 2 at step 5. L2 will appear on the TV screen.

• Unauthorized recording of copyrighted television programs, video tapes, or other materials may infringe on the rights of copyright owners and violate copyright laws.

• If a program has copyright protection, it may not be recorded clearly.

Helpful Hints

These instructions show you how to copy videotapes.The illustration uses two DVD/VCRs. Other VCRs or Camcorders may operate differently.

2. Video cable from yellow VIDEO

OUT jack of DVD/VCR 1 to VIDEO IN jack of DVD/VCR 2

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 35

Page 36

Timer Recording

PROGRAM NUMBER 1 DATE – – / – – START TIME – – :– – – – END TIME – – : – – – – CHANNEL – – REC SPEED – –

Follow the steps below to program the VCR of the DVD/VCR to record TV programs while you’re away from home. Before you begin:

● Set up the TV channels at the DVD/VCR. Details are on page 26.

● Set the clock. Details are on pages 28-29.

● Put a tape in the cassette compartment of the DVD/VCR. Make

sure the tape’s record tab is intact and the tape is long enough to record the program(s).

● Press VCR so the VCR light appears on the front of the

DVD/VCR.

Press DISC/VCR/MENU so MENU appears.

Press

o or p

to select TIMER PROGRAMMING.Then,

pressB. Program numbers that do not have a timer recording

stored will flash.

TIMER PROGRAMMING

PROG. 12345678 DATE START TIME END TIME CHANNEL REC SPEED

Press o or p to select an empty program.Then, press

PROGRAM NUMBER 1

B ONCE

DAILY WEEKLY

Press o or p to select ONCE, DAILY, or WEEKLY. Then, press B.

● ONCE - The VCR will record a TV program on any day you

choose, up to

12 months away.

● DAILY -

The VCR will record a TV program at the same time

on the same channel every day, Monday through Friday.

● WEEKLY - The VCR will record a TV program at the same

time on the same channel every week, for example, every Monday.

• You cannot access the TIMER PROGRAMMING menu at step 2 if the clock is not set.The CLOCK SET menu will appear. Follow the steps on pages 28-29 to set the clock.

• Only programs that will air MondayFriday can be recorded on a DAILY basis. If you select DAILY at step 4, then enter a Saturday or Sunday DATE at step 5, the correct program will not be recorded.The VCR will alter the recording date and record a different program than the one you intended.

Helpful Hints

2-4

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 36

STANDBY-ON

SEARCH MODE

REPEAT REPEAT

SUBTITLE ZOOM

RETURN TITLE

DISC/VCR

MENU MENU

SPEED

DISPLAY

AUDIO

A-B

ANGLE

CLEAR/RESET SLOW

PLAY

MARKER RECORDTIMER SET

1 2 3

SKIP / CH

DVDVCR VCR/TV

SYSTEM

PAUSESTOP

+10

Page 37

Timer Recording (cont’d)

To enter the recording date, press o or p until the month appears.Then, press

B. Next, press o or p until the day appears.Then, press

B. The day of the week will appear. You cannot

record more than one year in advance.

Instructions continue on page 38.

• If you are recording from other equipment, set CHANNEL to L1 or L2 at step 8. If you connected the other equipment to the AUDIO and VIDEO In jacks on the front of the DVD/VCR,choose L2. If you connected the equipment to the AUDIO IN and VIDEO IN jacks on the back of the DVD/VCR, choose L1.

• Enter the information while the space is flashing.

• To stop a started timer recording, press STOP/EJECT

C A

(VCR) on the front of the DVD/VCR. (You cannot stop a started timer recording with the STOPCbutton on the remote.)

More Helpful Hints are on page 76.

Helpful Hints

To enter the recording’s start time, press o or p until the hour appears. Press

Press

o or p until the minute appears. Press B.

Finally, press o or p to point to AM or PM. AM or

PM will flash beside the start time.

Press B.

ONE TIME PROGRAM

PROGRAM NUMBER

DATE 0 5 / 0 4 TUE START TIME – – : – – – – END TIME – – : – – – – CHANNEL – – REC SPEED – –

Repeat the procedure in step 6 to set the recording’s end time.

Press o or p until the channel number appears. Then, press

● If you are using a standard antenna/Cable TV hookup (as

shown on page eight), select the channel of the TV program you want to record.

● If you are recording from other equipment, select L1 or

L2.To determine L

1 or L2, refer to the Helpful Hints on

page 38.

● If you are using a Cable Box/Satellite Receiver, select the

Cable Box/Satellite Receiver output channel (03 or 04). Then, at the Cable Box/Satellite Receiver, select the channel you want to record. Leave the Cable Box/Satellite Receiver on for the timer recording.

Details are on page nine.

ONE TIME PROGRAM

PROGRAM NUMBER

DATE 0 5 / 0 4 TUE START TIME 0 7 : 3 0 P M END TIME – – : – – – – CHANNEL – – REC SPEED – –

BPM

ONE TIME PROGRAM

PROGRAM NUMBER

DATE 0 5 / 0 4 TUE START TIME 0 7 : 3 0 P M END TIME 0 8 : 3 0 P M CHANNEL

REC SPEED – –

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

5-8

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 37

Page 38

Timer Recording (cont’d)

Cancelling Timer Recordings

PressVCR, then press DISC/VCR/MENU so MENU appears.

Press o or p to select TIMER PROGRAMMING, then press B.

Press o or p to find the program you want to cancel.

While the program number is flashing, press s to clear all the information for that program.

Press CLEAR/RESET to remove the menu.

ONE TIME PROGRAM

PROGRAM NUMBER

DATE 05/04 TUE START TIME 07:30 PM END TIME 08:30 PM CHANNEL

REC SPEED SP

Press o or p to select a recording tape speed. The arrow will appear beside your choice.The selected speed will flash beside REC SPEED. Details about tape speed are on

page 72.

Press CLEAR/RESET to store the timer recording.

Press TIMER SET. The DVD/VCR will turn off and will appear in the display panel. In some cases, the DVD/VCR will switch to DVD mode instead.You may use the DVD Player during a timer recording. If you want to use the VCR until time for the recording, don’t press TIMER SET until a few minutes before the recording should start. Or, press TIMER SET only when you know you won’t be using the VCR anymore (until after the recording).When appears, you cannot put the DVD/VCR in VCR mode by pressing VCR or SOURCE.You must first press TIMER SET to cancel the timer recording temporarily.Then, you can use the VCR features again.

ONE TIME PROGRAM

PROGRAM NUMBER

DATE 0 5 / 0 4 TUE START TIME 0 7 : 3 0 P M END TIME 0 8 : 3 0 P M CHANNEL

1 6

REC SPEED S P

B SP

SLP

• To change incorrect information, press

or Bto choose the item

you want to change. Press

to adjust the information.

• If a timer recording is set and appears, pressing STOP/EJECT

(VCR) will turn on the DVD/VCR and/or cancel the timer recording.The will disappear. Press STOP/EJECT

(VCR) again to remove the tape. Insert a tape and press TIMER SET to reset the timer recording.

• If there is no tape in the VCR when you press TIMER SET, will flash. Insert a tape.

Helpful Hints

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 38

STANDBY-ON

SEARCH MODE

REPEAT REPEAT

SUBTITLE ZOOM

RETURN TITLE

DISC/VCR

MENU MENU

SPEED

DISPLAY

AUDIO

A-B

ANGLE

CLEAR/RESET SLOW

PLAY

MARKER RECORDTIMER SET

1 2 3

SKIP / CH

DVDVCR VCR/TV

SYSTEM

PAUSESTOP

+10

Page 39

DVD to Videotape Duplication

Follow the steps below to copy a DVD to a videotape. This will be possible only if the DVD is not copy protected.

Before you begin:

● Put a videotape in the cassette compartment. Make sure the

tape’s record tab is intact and the tape is long enough to record the DVD.

● Put the DVD you want to copy in the disc tray.

● Press VCR so the VCR light appears on the front of the

DVD/VCR.

●

Turn on the TV and set it to channel 3, 4, or its Video Input.

Point the remote control at the DVD/VCR. Press Number buttons 0, 0, 3. “DISC” will appear on the TV

screen.

Press SPEED until the desired tape speed (SP or SLP) appears briefly on the screen. Details about tape

speed are on page 72.

Press RECORD Ito start recording. ‘REC’ will appear on the display panel.

Press DVD. Press

PLAY B

to play the disc.

To pause the recording, press VCR, then press PAUSE

once. REC will flash. To r esume recording, press

RECORD Ior press PAUSE kagain. REC will reappear.

To stop recording, press VCR, then press STOP C.

DISC

3,5

5,6

• A timer recording is not possible during DVD to videotape duplication.

•You cannot copy a DVD to a videotape if you are using Progressive Scan. Details are on page 12.

Helpful Hints

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 39

STANDBY-ON

SEARCH MODE

REPEAT REPEAT

SUBTITLE ZOOM

RETURN TITLE

DISC/VCR

MENU MENU

SPEED

DISPLAY

AUDIO

A-B

ANGLE

CLEAR/RESET SLOW

PLAY

MARKER RECORDTIMER SET

1 2 3

SKIP / CH

DVDVCR VCR/TV

SYSTEM

PAUSESTOP

+10

Page 40

4040

Repeat Play

Follow the steps below to play a videotape repeatedly.

Press VCR, then press DISC/VCR/MENU so MENU appears.

Press o or p to select AUTO REPEAT.

Press B so ON appears next to AUTO REPEAT.

Ta pe playback will begin immediately.AUTO REPEAT B will appear on the TV screen briefly. (If you are fast forwarding or rewinding the tape, press CLEAR/RESET to remove the menu, then press PLAY B to begin tape playback.) The tape will play to the end, rewind, then play again. (TV programming will appear on the screen while the tape is rewinding.)

- M E N U -

BTIMER PROGRAMMING

AUTO REPEAT [OFF] CHANNEL SET UP CLOCK SET LANGUAGE SELECT AUDIO OUT TV STEREO [ON] SAP

- M E N U -

TIMER PROGRAMMING

BAUTO REPEAT [OFF]

CHANNEL SET UP CLOCK SET LANGUAGE SELECT AUDIO OUT TV STEREO [ON] SAP

- M E N U -

TIMER PROGRAMMING

BAUTO REPEAT [ON]

CHANNEL SET UP CLOCK SET LANGUAGE SELECT AUDIO OUT TV STEREO [ON] SAP

• To cancel AUTO REPEAT, follow steps 1-2. At step 3, press Bso OFF appears beside AUTO REPEAT. Press CLEAR/RESET.

Helpful Hint

2-3

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 40

Page 41

Tape Counter

• You may only set the counter to zero at one location at a time. Setting the counter to zero at a second location will erase the previous zero setting.

• If you remove the tape, the counter will reset to zero at the point at which you last stopped playback whenever you reinsert the tape.

Helpful Hints

STOP

SLP

1 : 23 : 45 HIFI

Follow the steps below to reset the VCR’s real-time tape counter to zero at a tape location you want to refer to later.

Press VCR, then play, fast forward, or rewind a tape to the location that you would like to refer to later. Press STOP C to stop the tape.

Press DISPLAY to see the status display.

While the counter is on the screen, press CLEAR/RESET to reset the counter to zero.

STOP

SLP 0 : 00 : 00 HIFI

When you later want to return to this point on the tape, press DISPLAY so you can see the counter (while tape play is stopped). Press h or g.

As the tape rewinds or forwards, watch the counter.When it reaches zero,

press PLAY B to play the tape.

2,4

STANDBY-ON

PLAY

DVD

VCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 41

Page 42

4242

Time Search, Index Search

Time Search

Follow the steps below to search forward or backward on a tape a specific length of time.There must be a tape in the cassette compartment.

Press VCR, then press SEARCH until the TIME SEARCH screen appears.

• Time Search and Index Search are not available during recording.

• To remove a Search display, press CLEAR/RESET.

• To cancel a search, press STOP C.

Helpful Hints

TIME SEARCH

- : - -

Within 30 seconds, press o or p until your desired length of time appears. Or, press and hold o or p until

you reach the desired length of time. You can set a Time Search for up to 9 hours and 59 minutes (9:59).

Within 30 seconds, press s (for a reverse search) or B (for a forward search). The VCR begins rewinding or fast forwarding the tape.When the tape finishes rewinding or fast forwarding the time you specified,playback will begin. The time will count down beneath TIME SEARCH during the search. If the end of the tape is reached during the search, the search will stop and the tape may rewind.

Details are on page 44.

Index Search

An Index Mark is made automatically at the beginning of each recording. Essentially, an Index Mark is a “bookmark.” Find the start of a recording by following these steps.

Press VCR, then press SEARCH until the INDEX SEARCH screen appears.

Within 30 seconds, press o or p until the number of programs you want to skip appears beneath INDEX SEARCH. Include the current program in your number.

Within 30 seconds, press s (for a reverse search) or B (for a forward search). When the tape finishes rewinding or forwarding, playback will start.The program numbers will count down beneath INDEX SEARCH during the search. If the end of the tape is reached during the search, the search will stop and the tape may rewind.

Details are on page 44.

Recordings should be at least one minute long in SP speed, two minutes in LP, and three minutes in SLP. Otherwise, the Index Mark will not be available.

Details on tape recording

speeds are on page 72.

INDEX SEARCH

_ _

2-3

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 42

STANDBY-ON

SEARCH MODE

REPEAT REPEAT

SUBTITLE ZOOM

RETURN TITLE

VCR VCR/TV

DISC/VCR

MENU MENU

DISPLAY

AUDIO

A-B

ANGLE

CLEAR/RESET SLOW

PLAY

MARKER RECORDTIMER SET

SKIP / CH

DVD

SYSTEM

PAUSESTOP

STANDBY-ON

SEARCH MODE

REPEAT REPEAT

SUBTITLE ZOOM

RETURN TITLE

DISC/VCR

MENU MENU

DISPLAY

AUDIO

A-B

ANGLE

CLEAR/RESET SLOW

PLAY

MARKER RECORDTIMER SET

SKIP / CH

DVDVCR VCR/TV

SYSTEM

PAUSESTOP

Page 43

Special Effects Playback

● Before you begin, press VCR so the VCR light appears on the

front of the DVD/VCR.

Forward and Reverse Searching (SP/LP/SLP)

During tape playback, press and release g or h.

A fast forward or reverse picture search will begin.

To r eturn to playback, press PLAY B.

Super High Speed Searching (LP/SLP)

During tape playback, press g or h, then press again. The search speed will increase. Repeatedly pressing

g or h will switch between regular and high speed searching.

To r eturn to normal playback, press PLAY B.

Viewing a Still Picture

During tape playback, press PAUSE k. A still picture will appear on the screen.

To advance the still picture one frame at a time, press PAUSE

k repeatedly.

To r elease the still picture and return to playback, press PLAY B.

Viewing a Slow Motion Picture

During tape playback, press SLOW. The tape will play in slow motion.

To r eturn to normal playback, press PLAY B.

• Slow and Still modes will switch to Stop mode after five minutes to protect the DVD/VCR and the tape from damage.

• SP/LP/SLP means this feature will work with tapes recorded in Standard Play, Long Play, or Super Long Play. LP/SLP means this feature will work with tapes recorded in Long Play or Super Long Play. Tape speed details are on page 72.

Helpful Hints

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 43

STANDBY-ON

SEARCH MODE

REPEAT REPEAT

SUBTITLE ZOOM

RETURN TITLE

VCR VCR/TV

DISC/VCR

MENU MENU

SPEED

A-B

1 2 3

DISPLAY

AUDIO

ANGLE

CLEAR/RESET SLOW

PLAY

MARKER RECORDTIMER SET

SKIP / CH

DVD

SYSTEM

PAUSESTOP

+10

Page 44

4444

Automatic Operation Features

The following tape features are available in VCR mode. Press VCR so the VCR light appears on the front of the DVD/VCR,if necessary.

Automatic Playback

When you put a tape in the DVD/VCR, the power will come on. If the tape’s record tab is missing, playback will begin. If a timer recording is set and is flashing in the display panel, the power will not come on automatically when you insert a tape with the record tab intact. If a timer recording is set and is flashing in the display panel, the DVD/VCR will eject the tape if the record tab is missing.

Automatic Rewind, Eject

When a tape is played, fast forwarded, or recorded to its end, the tape will rewind to the beginning, stop, and eject itself. This feature does not operate if AUTO REPEAT is ON. Details are

on page 40.

Ta pe Eject

A tape can be ejected with the DVD/VCR power on or off (but the DVD/VCR must be plugged in). If a timer recording is set and appears on the display panel, pressing STOP/EJECT C A (VCR) will turn on the DVD/VCR and/or cancel the timer recording.The will turn off. Press STOP/EJECT C A (VCR) again to remove the tape. Remember to insert a tape and press TIMER SET to reset the timer recording.

Automatic Tracking Adjustment

The VCR adjusts tracking automatically to give you the best possible picture quality.With some recordings, however, you may get a better picture using manual tracking.

Manual Tracking

To manually adjust the tracking during normal playback and slow motion playback of a videotape, press SKIP

∑/CH o or SKIP

w/CH p on the remote.

Tracking will return to Automatic Tracking when you press STOP C or insert a tape. You can also press SKIP ∑/CH o or SKIP w/CH p to remove vertical jitter in a Still picture.

Before Tracking Adjustment

After Tracking Adjustment

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 44

Page 45

Multi-Channel Television Sound

To play programs in stereo, connect the DVD/VCR to a Stereo or TV as described on pages 11 and 14.You will use the red and white AUDIO OUT jacks on the DVD/VCR.

Your DVD/VCR can play tapes recorded in Hi-Fi (high fidelity) stereo, which produces a crisp, clear sound from the left and right audio channels.Your DVD/VCR also can play tapes recorded in a second audio (usually, that means your program is recorded in a second language). Of course, your DVD/VCR will play tapes recorded in monaural (single-source) sound as well. Your DVD/VCR also will record on a video cassette in Hi-Fi stereo or in second audio, so when you play that tape on the DVD/VCR, it will be in stereo or second audio. Read the directions on this page to familiarize yourself with the stereo and second audio setups.Then follow the directions on page 46 to record in stereo or second audio, or follow the directions on page 47 to play tapes recorded in Hi-Fi stereo.

Understanding Displays

When you watch TV channels through the DVD/VCR, portions of the display shown below will appear when you press DISPLAY twice.

If SAP or STEREO appears, the program is available in second audio or stereo. Even though a program is available in second audio or stereo, you must program the DVD/VCR to receive or record the program. Follow the directions on page 46. This display is not available during tape playback.

STOP 5:40 PM

CH 02

STEREO

SAP

SLP

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 45

Page 46

4646

Multi-Channel Television Sound (cont’d)

Press o or p to select TV STEREO or SAP (Second Audio Program). Press B so ON appears beside your

selection.

Press DISC/VCR/MENU to remove the menu.

- M E N U -

TIMER PROGRAMMING AUTO REPEAT [OFF] CHANNEL SET UP CLOCK SET LANGUAGE SELECT AUDIO OUT

BTV STEREO [ON]

SAP

• You can only receive and record in stereo or second audio programs that are broadcast in stereo or second audio.You can only play a tape in Stereo or second audio if it was recorded in stereo or second audio. Please see page 45 to determine if the program is in stereo or second audio.

• If SAP is ON but the program is not broadcast in Second Audio, you will hear and record the program in normal audio.

Helpful Hints

- M E N U -

BTIMER PROGRAMMING

AUTO REPEAT [OFF] CHANNEL SET UP CLOCK SET LANGUAGE SELECT AUDIO OUT TV STEREO [ON] SAP

To set the DVD/VCR to receive programs in stereo or second audio, follow these steps.

Press VCR, then press DISC/VCR/MENU so MENU appears.

1,3

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 46

Page 47

Hi-Fi Stereo

Press o or p to select AUDIO OUT. Then, press B.

Multi-Channel Television Sound system broadcasts are recorded in Hi-Fi stereo.To play in Hi-Fi stereo the tapes recorded in Hi-Fi stereo, follow these steps.

Press VCR, then press DISC/VCR/MENU so MENU appears.

Press o or p to select HIFI. ON will appear beside HIFI.

Press DISC/VCR/MENU to remove the menu.

- M E N U -

TIMER PROGRAMMING AUTO REPEAT [OFF] CHANNEL SET UP CLOCK SET LANGUAGE SELECT

BAUDIO OUT

TV STEREO [ON] SAP

• Programs are recorded in both HiFi stereo sound and in monaural (single-channel) sound.

• The audio level of a tape recorded in Hi-Fi stereo will differ from the audio level of a tape not recorded in Hi-Fi stereo.

• You can change to MONO if you want monaural audio playback. Follow steps 1-2, then press oor

to select MONO at step 3. Press DISC/VCR/MENU. HIFI will disappear from the status display.

• If you play non-Hi-Fi tapes while AUDIO OUT is set to HIFI, HIFI will not appear on the status display. The tape will play in monaural sound.

Please see additional notes on page 77.

Helpful Hints

AUDIO OUT

BHIFI [ON]

MONO

- M E N U -

BTIMER PROGRAMMING

AUTO REPEAT [OFF] CHANNEL SET UP CLOCK SET LANGUAGE SELECT AUDIO OUT TV STEREO [ON] SAP

2-3

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

1,4

H9621CD(EN)_1.qx4 04.4.7 0:00 PM Page 47

Page 48

Using the Title Menu

Some DVDs have a Title Menu, which lists the Titles available on the DVD. Use the Title Menu to play a specific Title.

Press DVD to put the DVD/VCR in DVD mode.The DVD light will appear on the front of the DVD/VCR.

Press TITLE. The Title menu will appear. If a Title menu is not available, the “X” may appear on the TV screen. Or, if the DVD only has a main Disc menu as described above, it may appear when you press TITLE.

Press o, p, s, or B to select a Title, then press OK.

Play will begin at the Title you selected.

• Menus vary among DVDs. Follow the information accompanying the DVD.

• Not all DVDs have Disc or Title menus.

• Some DVDs may refer to Chapters as “scenes.”Some DVDs may refer to the Title Menu as the “scene index.”

• The TITLE button will not be active with all DVDs.

Helpful Hints

48 DVD Disc Menus

DVDs contain menus that describe the contents of the DVD or allow you to customize DVD playback. For example, the menu may offer choices for subtitle languages, special features, or scene selection.To use the DVD Disc menu and select playback features, follow these steps.

Press DVD to put the DVD/VCR in DVD mode.The DVD light will appear on the front of the DVD/VCR.

Press DISC/VCR/MENU. The DVD’s main Disc menu will appear.

Press o, p, s, or B to select an item, then press OK. Continue this process to set up all the features you

want.

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 48

STANDBY-ON

SEARCH MODE

REPEAT REPEAT

SUBTITLE ZOOM

RETURN TITLE

DISC/VCR

MENU MENU

DISPLAY

AUDIO

A-B

ANGLE

CLEAR/RESET SLOW

PLAY

SKIP / CH

DVDVCR VCR/TV

SYSTEM

PAUSESTOP

Page 49

Fast Forward/Reverse Search 49

Press DVD to put the DVD/VCR in DVD mode.The DVD light will appear on the front of the DVD/VCR.

During playback, press g or h.

Use g for a for-

ward search. Press h for a reverse search.

●

During DVD playback, pressing g or h will forward or reverse the picture at approximately two, eight, 50, or 100 times the normal playback speed.The speed may vary depending on the Disc. An

g1,g2,g

3, or

4 will indicate fast forward searching. An

h1,h2,h

3, or

4 will appear briefly on the TV screen to indicate fast reverse searching. Sound will be mute during searching.

● For Audio CDs, the approximate searching speed is 16

times the normal play speed.An g or h will appear briefly on the TV screen. Sound will be intermittent during searching on an Audio CD.

● During Video CD play, pressing g or h will forward

or reverse the picture at approximately two, eight, or 30 times the normal play speed.The speed may vary depending on the Disc. An g 1, g 2, or g 3 will indicate fast forward searching. An h 1, h 2, or h3 will appear briefly on the TV screen to indicate fast reverse searching.

● For MP3, the approximate search speed is eight times the

normal play speed.An

g or h will appear briefly on

the TV.

Press PLAY B to return to normal playback.

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 49

Example: Playing a DVD in reverse at twice the normal playing speed.

Page 50

Specific Time Playback

Press DVD to put the DVD/VCR in DVD mode.The DVD light will appear on the front of the DVD/VCR.

During DVD,Audio CD, or Video CD (without PBC) play, press SEARCH

until the Time Search display

appears.

50 Title/Chapter Playback, Specific Time Playback

Title/Chapter Playback

Press DVD to put the DVD/VCR in DVD mode.The DVD light will appear on the front of the DVD/VCR.

During DVD playback, press SEARCH until CH (for Chapter) or TT (for Title) appears on the TV.The number of available Titles or Chapters will appear at the right ( /4, for example).

Enter the Title or Chapter number using the Number buttons.

The Title or Chapter will play.

● To select a single-digit Track number when there are

more than 10 tracks, press OK to play the Track.

● If you enter a Track number that is not available on the

Disc, play will not begin (or the current Track will continue to play).

Within 30 seconds, use the Number buttons to enter the elapsed playing time (of the Track or Title) at which you want play to begin.

Enter the time in hours, minutes, and seconds. Within a few seconds, play will start at the specified time.

● Example: 1 hour, 23 minutes, and 30 seconds

1 → 2 → 3 → 3 → 0

● Make sure the time you enter is within the total time of

the current Title or Track. If it is not, the time space will clear and play will continue at its current point.The total time available in the current Track or Title will appear in the Time Search display.

● If you make a mistake entering the time, press

CLEAR/RESET to clear the time area. Enter the correct information.

12/17 4 / 4

TOTAL

1:29:00

_:_ _:_ _

• When play is stopped, use the Number buttons to select a Title for immediate play. During play, use the Number buttons to choose a Chapter for immediate play.

• Title/Chapter playback is not available with some DVDs.

Helpful Hints

PLAY

DVD

VCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

H9621CD(EN)_2.qx4 04.4.13 6:02 PM Page 50

Page 51

There are three ways to play a specific Audio CD,Video CD (without PBC), MP3, or JPEG Track: Use the Number buttons, the SEARCH button, or SKIP

∑/CH o or SKIP w/ CH p.

● Before you begin, press DVD so the DVD light appears on the

front of the DVD/VCR.

Using the Number Buttons

Press the Number buttons to enter a Track number. Play

will start at the selected Track. For Tracks 10 and above, press the +10 button so the Search display (TR _ _ /12 - an example of total tracks) appears on the TV. Press the Number button of the first digit, then press the Number button of the second digit. For example, to play Track 26, press +10, then Number 2, then Number 6. For single-digit Tracks (1-9), press a single Number button. If you enter a Track number that is not available on the Disc, play will not begin (or the current Track will continue to play).

Using SEARCH

Press SEARCH so the Track Search display (TR) appears. Within 30 seconds, press the Number buttons to select the Track number. Play will begin at the selected Track. For a single-

digit Track (1-9), enter a zero first. For example, to play Track 5, press 0, 5. You do not have to use the +10 button in Search Mode.

Using SKIP ∑∑/CH oo or SKIP ww/ CH

During play, press SKIP ∑∑/CH ooto skip the current Track

and move to the next Track.

The Track number will appear

briefly on the DVD/VCR display panel.

Or, during play,press SKIP ww/ CH ppto return to the beginning of the current Track. Press SKIP

/ CH

repeatedly to go to previous Tracks. The Track number will appear briefly on the DVD/VCR display panel.

Track Playback 51

•You cannot use SKIP ∑/CH oto go from the last Track on the Disc to the first Track.

Helpful Hint

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

A,B

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 51

Page 52

52 Paused and Step-by-Step Playback, Resume On

Resume On

Press DVD to put the DVD/VCR in DVD mode.The DVD light will appear on the front of the DVD/VCR.

Press STOP C during playback. In a few seconds, the following Resume message will appear on the TV screen.

Press PLAY B. In a few seconds, play will resume from the point at which it stopped last.You can resume playing at the same point even if you turn off the DVD/VCR, then turn it on again later. However, opening the disc tray will cancel the Resume feature. Play will start at the beginning the next time you insert the Disc. For MP3, play will resume from the beginning of the current Track. To cancel Resume and start playing the Disc from the beginning, press STOP C a second time while playback is stopped. The Stop symbol (C) will appear briefly on the TV screen. Press PLAY B to start playing the Disc from the beginning.

Press 'PLAY' to play from here. To play the beginning, press 'STOP' first and then 'PLAY'.

Paused and Step-by-Step Playback

Press DVD to put the DVD/VCR in DVD mode.The DVD light will appear on the front of the DVD/VCR.

During playback, press PAUSE k. Play will pause and the sound will be mute.

Press PAUSE k repeatedly to see a DVD or Video CD picture advance one frame (or step) at a time.

The sound will remain mute. Pressing PAUSE

k repeatedly during Audio CD, MP3, or

JPEG play will have no effect.

Press PLAY B to resume play.

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

2-3

• Set STILL MODE to FIELD in the DISPLAY menu if paused images are blurry. Details are on pages 64-65.

Helpful Hint

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 52

Page 53

Repeat, A-B Repeat 53

• Repeat play and A-B Repeat are not available with all Discs.

• The entire A-B Repeat section must be within a single Title or Track. If you do not enter Point B before the end of the Track or Title is reached, the end of the Track or Title will become Point B automatically.

• Point B must be later on the Disc than Point A.

Helpful Hints

Repeat

Press DVD to put the DVD/VCR in DVD mode.The DVD light will appear on the front of the DVD/VCR.

During play, press REPEAT until the repeat mode you want appears on the TV.

On a DVD, select CHAPTER,TITLE, or OFF. On an Audio CD and Video CD (without PBC), select TRACK,ALL (all Tracks on the Disc), or OFF.With MP3 or JPEG files, select TRACK, GROUP (all Tracks in the current folder), or ALL. Selecting a new Track, Chapter, or Title will cancel repeat play.

A-B Repeat

Follow these steps to play a section of a DVD,Audio CD, or Video CD repeatedly.

Press DVD to put the DVD/VCR in DVD mode.The DVD light will appear on the front of the DVD/VCR.

Press PLAY B to play the Disc to the point at which you want repeated play to begin.

Press A-B REPEAT to set the starting point (A).

A - will appear on the TV screen.

Play or fast forward the Disc to the point at which you want repeated play to end, then press A-B REPEAT again. A-B will appear on the TV. The sec-

tion will begin to play repeatedly.

To cancel A-B Repeat, press A-B REPEAT. OFF will appear on the TV screen. Regular play will resume.

Example: Repeat a

DVD Chapter

Example: Repeat an

Audio CD or

Video CD Track

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

3-5

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 53

Page 54

54 Markers

Use Markers to remember your favorite places on a DVD, Audio CD, or Video CD (without PBC).To set the Markers, follow these steps.

● Before you begin, place the DVD/VCR in DVD mode. Press

DVD so the DVD light appears on the front of the DVD/VCR.

Play the Disc to within 30 seconds of the point at which you want to set the Marker. Press MARKER.

The markers will appear at the top of the TV screen.

Within 30 seconds, press s or B to select a Marker (

1-10). Make sure _ _ : _ _ :_ _ appears beneath the number.

Play the Disc to the point at which you want to set the Marker (up to 30 seconds away). When the Disc reaches the point you want to remember, press OK. The Title or Track number and its

elapsed playing time will appear beneath the markers.

To r eturn to a Marker during play, press MARKER until you see the Markers. Press s or B to choose the Marker you want, then press OK. Disc play will continue from the marked point.

• Opening the disc tray or turning off the DVD/VCR will erase all the Markers.

•To erase a single Marker, press MARKER until you see the Markers. Press sor Bto select a Marker. Press CLEAR/RESET. Press RETURN or MARKER to remove the display.

•To erase all the Markers, press MARKER until you see the Markers. Press Bto select AC, then press OK. Press MARKER or RETURN to remove the display.

Helpful Hints

2,4

1,4

3-4

STANDBY-ON

PLAY

DVD

VCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

Example: DVD

Example:Audio CD

or Video CD

Example: DVD

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 54

Page 55

• On some DVDs, you must select a subtitle language in the Disc menu.

• If the language does not appear after pressing SUBTITLE several times, the Disc does not have subtitles in that language.

• Opening the disc tray will cancel your subtitle setting.

• If the current portion of the Disc has multiple camera angles, will appear on the TV screen. ANGLE ICON must be ON. Details are on pages 64-65.

Helpful Hints

Subtitles

You can select a language for DVD subtitles during playback.You can select only languages that are available on the DVD.

Press DVD to put the DVD/VCR in DVD mode.The DVD light will appear on the front of the DVD/VCR.

During play, press SUBTITLE repeatedly to select a subtitle language. The number of available languages

appears at the right of the subtitle display. In the example below, six languages are available ( /6).After a few seconds, the subtitles will appear. Or, press SUBTITLE repeatedly to turn off subtitles. When no subtitles are available,“NOT AVAILABLE” appears at the right of the subtitle display.

Camera Angles

Some DVDs contain scenes recorded from different angles.The camera angle will not change if the DVD does not contain sequences recorded from different perspectives.

Press DVD to put the DVD/VCR in DVD mode.The DVD light will appear on the front of the DVD/VCR.

During DVD play, press ANGLE repeatedly to select a different angle. The number of available angles appears

at the right of the Angle display. In this example, eight angles are available ( /8).

Subtitles, Camera Angles 55

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 55

SEARCH MODE

REPEAT REPEAT

SUBTITLE ZOOM

RETURN TITLE

DISC/VCR

MENU MENU

SEARCH MODE

REPEAT REPEAT

SUBTITLE ZOOM

RETURN TITLE

DISC/VCR

MENU MENU

DISPLAY

AUDIO

A-B

ANGLE

CLEAR/RESET SLOW

PLAY

STANDBY-ON

DISPLAY

AUDIO

A-B

ANGLE

CLEAR/RESET SLOW

STANDBY-ON

SKIP / CH

DVDVCR VCR/TV

SYSTEM

PAUSESTOP

SKIP / CH

DVDVCR VCR/TV

SYSTEM

Page 56

56 Parental Controls Password

Parental Controls prevents viewing of DVDs that exceed your rating limits.This feature will not limit viewing if the DVD is not rated or coded. Check your DVDs and settings before letting children access the DVD/VCR. Follow these steps to change your password.

Press DVD to put the DVD/VCR in DVD mode.The DVD light will appear on the front of the DVD/VCR. Press STOP C to stop Disc playback.

Press SYSTEM/MENU.

Press s or B to select (the lock), then press OK.

The first time you set a password, this menu will appear.

Press the Number buttons to enter a four-digit password. The password will appear on the screen.Write it

down so you don’t forget it.

Press OK.You are finished! Go to step 7.

If you have set a password before, this menu will appear.

Press the Number buttons to enter your current four-digit password. Asterisks (*) will appear instead of

your password.This protects its identity.

Press p to select CHANGE, then press OK.

Press the Number buttons to enter a four-digit password. The password numbers will appear on the screen. Write down the password so you will not forget it. Press OK. The previous menu will reappear.

Press SYSTEM/MENU to remove the menu.

QUICK SETUP

PLAYER MENU ENGLISH TV ASPECT

4:3 LETTER BOX

DOLBY DIGITAL ON

• The default password is 4737. If you forget your password, press Number buttons 4, 7, 3, 7 at step

4.You will be prompted to enter a new four-digit password. Use the Number buttons to enter a new four-digit password, then press OK. PARENTAL LEVEL will reset to ALL. See page 57 to reset PARENTAL LEVEL as you desire.

• A power failure will not erase your password.

Helpful Hints

PASSWORD

Press s or B to select CUSTOM, then press OK.

LANGUAGE

AUDIO ORIGINAL SUBTITLE OFF DISC MENU ENGLISH PLAYER MENU ENGLISH

4,6

3-5

2,7

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 56

PARENTAL LEVEL ALL

CHANGE

PARENTAL

Page 57

Parental Levels 57

Follow these steps to set the rating level for your DVDs. DVDs whose ratings exceed the level you set will not play.

Press DVD to put the DVD/VCR in DVD mode.The DVD light will appear on the front of the DVD/VCR. Press STOP C to stop Disc playback if necessary.

Press SYSTEM/MENU.

Press the Number buttons to enter your four-digit password.

Press o or p to select PARENTAL LEVEL, then press OK.

QUICK SETUP

PLAYER MENU ENGLISH TV ASPECT

4:3 LETTER BOX

DOLBY DIGITAL ON

Press o or p to select a level, then press OK. The rating levels continue on two menu screens. Press o or p repeatedly to move to the next or previous screen to find the rating level you want. After making your selection, the previous menu will appear. The level you selected will appear beside PARENTAL LEVEL.

PARENTAL

CHANGE

PARENTAL LEVEL ALL

PARENTAL

PARENTAL LEVEL ALL

8 7 [NC-17] 6 [R] 5 4 [PG13] 3 [PG]

• When you try to play a DVD whose rating exceeds the level you set, an on-screen message will indicate the DVD cannot play. Remove the DVD, then set PARENTAL LEVEL to ALL. Reload the DVD and begin playback. Some DVDs may let you enter your four-digit password to begin playback. Follow the on-screen messages as prompted.

• You cannot use the default password (4737) to play a DVD.

Helpful Hints

• ALL - Parental Controls is inactive; all discs can play.

•8 - Adult material

•7 - NC-17 - Not appropriate for children under 17

•6 - R - Restricted; parental approval required for viewers under 18.

•4 - PG13 Unsuitable for children under 13

•3 - PG - Parental Guidance suggested.

•1- G - General Audience; recommended for all ages.

Press s or B to select CUSTOM, then press OK.

Press SYSTEM/MENU to remove the menu.

3-4, 6-7

LANGUAGE

AUDIO ORIGINAL SUBTITLE OFF DISC MENU ENGLISH PLAYER MENU ENGLISH

RATING

EXPLANATIONS

Press s or B to select (the lock), then press OK.

2,8

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 57

Page 58

58 Audio Language, Stereo Sound Mode

Audio Language

You can select a language for DVDs during playback if multiple languages are available.

Press DVD to put the DVD/VCR in DVD mode.The DVD light will appear on the front of the DVD/VCR.

During DVD playback, press AUDIO repeatedly to choose one of the available languages. The new audio

will be heard.The display will disappear after about five seconds. The Audio display may show if the DVD has Dolby Digital or multi-channel (5.1 CH) sound or its sampling rate (48 k, for example).The number of available languages appears after the “ / ” at the right of the display ( /3, for example).

• If a language is not available after pressing AUDIO several times, the DVD does not have that language.

• Some DVDs only let you change the language in the Disc menu.

• Audio languages may be abbreviated (such as ENG for English). Or, three dashes (- - -) may appear instead of an abbreviation.

•You cannot adjust the Stereo Sound Mode when Virtual Surround is active. Details are on page 70.

Helpful Hints

Stereo Sound Mode

Adjust Stereo Sound to determine whether you will hear the left channel, the right channel, or both channels (stereo) during Audio CD or Video CD playback. If you connected the DVD/VCR to a Stereo using the COAXIAL DIGITAL AUDIO OUT jack as described on page 15, or if you connected to a TV with only the RF coaxial cable, you cannot adjust Stereo Sound Mode.

Press AUDIO repeatedly during Audio CD or Video CD play to choose STEREO, L-CH, or RCH.

STEREO

Only the right channel is heard.

L-CH

R-CH

Only the left channel is heard.

Both right and left channels are heard (stereo).

1.ENG Dolby D 3/2.1ch 48k/3

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 58

Page 59

• The sound will be mute during slow motion play.

• The SLOW button on the remote does not activate slow motion of Discs.

• The x4 zooming is not active with some Discs. Only x2 zooming is available for Video CDs and JPEGs.

Helpful Hints

DVD Slow Motion, Zoom 59

Slow Motion

Press PAUSE F during DVD or Video CD play.

Press D or h. Slow motion play will begin. Press D or h repeatedly during slow motion play to play a DVD forward or backward at approximately 1/16, 1/8, or 1/2 the normal speed. Reverse slow motion is not available on a Video CD. An 1 (1/16), 2 (1/8), or 3 (1/2) will appear briefly on the TV screen to indicate slow forward play. An 1 (1/16), 2 (1/8), or 3 (1/2) will indicate slow reverse play.

Press PLAY B to return to normal play.

Zoom

You can enlarge a DVD,Video CD, or JPEG picture to two or four times larger than normal.

Press ZOOM during playback or when play is paused. The picture will appear twice as large. Press

ZOOM again to make the picture four times larger than normal. Either x2 or x4 will appear beside the zoom icon on the TV screen.

While the picture is enlarged, press o, p, s, or B to move the zoomed image up, down, left, or right.

The gray box with an inner blue box that shows during Zoomed playback is the position guide.To remove it or show it, press OK.The position of the blue box inside the gray box indicates the position of the zoomed image within the overall picture.

To r eturn the picture to normal, press ZOOM.

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

1,3

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 59

Example: Playing a DVD forward at half the normal speed.

STANDBY-ON

SEARCH MODE

REPEAT REPEAT

SUBTITLE ZOOM

RETURN TITLE

DISC/VCR

MENU MENU

SPEED

DISPLAY

AUDIO

A-B

ANGLE

CLEAR/RESET SLOW

PLAY

MARKER RECORDTIMER SET

1 2 3

SKIP / CH

DVDVCR VCR/TV

SYSTEM

PAUSESTOP

Page 60

60 Programmed Playback

You may determine the order in which Audio CD, MP3, or JPEG Tracks will play.To set a Program, follow these steps.

Press DVD to put the DVD/VCR in DVD mode.The DVD light will appear on the front of the DVD/VCR.

While playback is stopped, press MODE.

The PROGRAM screen will appear.

Press o or p to select a track you want to play, then press OK. Repeat this step until you have selected

all the Tracks you wish to play in the Program. Press CLEAR/RESET to erase the last Track in the Program if you make an error. Additional Tracks may be on other screens. Press p or o to see all the Tracks. To see Tracks in a Program when there are more than eight tracks, use SKIP ∑/CH o and SKIP w/ CH p to see all the Tracks. While an MP3/ JPEG folder is open, press s or B to go to the previous or next level of Files or Folders. Press TITLE to return to the first item in the highest level of Files or Folders.

Press PLAY B. The Tracks will play once in the order you set.Turning off the DVD/VCR or opening the disc tray will erase the Program.

•You cannot use the Number buttons or SEARCH to select another Track while playing a Program. Use SKIP ∑/CH oor SKIP w/ CH

to select other Tracks in a

Program.

•You cannot combine Random play with a Program.

•You may play a Program or a Track within a Program repeatedly. During Program play, press REPEAT so ALL (all Tracks in the Program) or TRACK appears.The entire Program or the current Track will play over and over.

•You cannot alter a Program during play.

•You can start Program play only while in the PROGRAM screen.

•A Program can have a maximum of 99 Tracks.

•To erase all Tracks in the Program, select ALL CLEAR at step 3.

Helpful Hints

Example: Audio CD

1 3

STANDBY-ON

PLAY

DVD

VCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

H9621CD(EN)_2.qx4 04.4.14 6:37 PM Page 60

TOTAL 0:08:40

CD-DA

Page 61

Random Playback 61

You may play Audio CD, JPEG, or MP3 Tracks in Random order instead of the order in which they are recorded (1,2,3...).

Press DVD to put the DVD/VCR in DVD mode.The DVD light will appear on the front of the DVD/VCR.

While play is stopped, press MODE twice so the RANDOM screen appears.

While the RANDOM screen appears, press PLAY

B. The Tracks will play in random order. After all

the Tracks play once, play will stop.

Example: Audio CD

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 61

Page 62

62 MP3/JPEG Playback

The DVD Player will play MP3 and JPEG files that you record and finalize on a CD-RW (Compact Disc-Rewritable) or CD-R (Compact Disc-Recordable).

These Discs may contain pictures in a JPEG format or audio Tracks in an MP3 format. You may copy or download MP3 music files from certain legal Internet sites, then copy those files onto a CDR or CD-RW. You cannot make or record such Discs using this DVD/VCR. See your computer manual for details on recording.

Keep these characteristics in mind when making Discs you intend to play on the DVD Player of this DVD/VCR.

● Record MP3 Tracks at a sampling frequency of 44.1 kHz or

48 kHz. Record in a constant bit rate between 112 kbps and 320 kbps.

● When recording JPEG Files, the size of the picture should be

between 32 x 32 and 6300 x 5100 dots.

Press DVD to put the DVD/VCR in DVD mode.The DVD light will appear on the front of the DVD/VCR.

When you put a CD-RW or CD-R with MP3 or JPEG files in the DVD/VCR and press MENU, the File List will appear on the TV screen.

Press o or p to select a Folder, MP3 Track, or JPEG File.

If you choose a Track or File, press PLAY B or OK.

Starting with the Track or File you selected, the Tracks/Files will play in the order they were recorded, i.e.

1,2,3,...

If you select a Folder and press OK, the Tracks or Files within that Folder will appear. Press

K or L to

select the Track or File you want, then press

PLAY

or OK.

● Press TITLE to return to the first item in the highest

level of Folders or Files.

● Press { or B to return to previous or next levels.

● During JPEG play, press MODE to choose a transition

mode (Cut In/Out or Fade In/Out). If you chose Cut In/Out, the images will cut in and out sharply as play progresses. If you choose Fade In/Out, then the images fade in and out as play progresses. Press MODE again to remove the transition modes.

● During JPEG play, press B or { to rotate a picture 90

degrees clockwise or counter-clockwise.

To stop play, press STOP C.

• JPEG images and MP3 Tracks are known as Files. Groups of Files are called Folders.

•Folders have the icon.

• MP3 Tracks have the icon.

• JPEG Files have the icon.

•A maximum of 255 Folders can be recognized.A maximum of 512 Files can be recognized.

• During play, use the Number buttons or

SKIP ∑/CH o or SKIP

w/ CH p to change Tracks.

• If a Track is not available,“X” will appear on the TV. Play may resume at an incorrect Track or may continue with its current Tra ck.

• Specific Time play is not possible with MP3 Tracks.

Helpful Hints

2-3

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 62

Page 63

MP3/JPEG Displays 63

You can review MP3 and JPEG information during play.

● Before you begin, place the DVD/VCR in DVD mode. Press

DVD so the DVD light appears on the front of the DVD/VCR.

Press DISPLAY during play.

The current Track name will

show on the TV screen.

Press

DISPLAY

again. The current Track number, total

Tracks available, and elapsed playing time of the current Track will appear (MP3 only).

The following may appear to indicate Repeat play.

T: The current Track will play repeatedly.

G: Tracks in the current Folder will play repeatedly.

A: All Tracks will play repeatedly.

Press

DISPLAY

again to remove the display.

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

1-3

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 63

TR (Track): Current Track number /Total Tracks

TR 2/25 0:01:15

Current repeat setting

Elapsed playing time of the current Track (MP3 only)

Page 64

• Selecting a different TV ASPECT setting is only effective if it is available on the DVD. Check the DVD Disc menu or case for details.

•You also can adjust TV ASPECT in the QUICK SETUP menu that appears when you first press the SYSTEM/MENU button.With QUICK selected, press OK. Press

to select TV ASPECT, then press OK. Press oor pto choose a setting, then press OK. Press SYSTEM/MENU to remove the menu.

Helpful Hints

Press o or p to select an item, then press OK.

● If you selected TV ASPECT, press o or p to select

a setting, then press OK.

Choose 4:3 LETTER BOX if you want to see the entire, widened picture with black bars at the top and bottom of the screen.This looks like the picture you see when watching movies in a theater.This setting is possible only if the DVD was recorded in the letterbox or widescreen format.

Choose 4:3 PAN & SCAN for a full height picture, with both sides trimmed. Some companies refer to this as reformatting the picture to fit your TV screen and may call it the regular or normal format. Choose

16:9 WIDE if a widescreen TV is connected to

the DVD/VCR.

● If you selected STILL MODE, press K or L to

select a setting, then press OK.

This function allows you to adjust the quality of a still image. AUTO is the default setting. If you select FIELD, still images will be stabilized but coarse due to the small amount of data. If you select FRAME, still images will be highly defined due to the simultaneous output of two fields.

64 Display

You can change the TV Aspect ratio, Still Mode clarity,Angle Icon availability, Automatic Power Off, and Progressive Scan features of the DVD Player in the Display menu.

Press DVD to put the DVD/VCR in DVD mode.The DVD light will appear on the front of the DVD/VCR.

When play is stopped, press SYSTEM/MENU. The QUICK SETUP screen will appear.

DISPLAY

TV ASPECT 4:3 LETTERBOX STILL MODE AUTO ANGLE ICON ON AUTO POWER OFF ON PROGRESSIVE OFF

Press s or B to select (display), then press OK.

QUICK SETUP

PLAYER MENU ENGLISH TV ASPECT

4:3 LETTER BOX

DOLBY DIGITAL ON

Press s or B to select CUSTOM at the top of the menu, then press OK.

LANGUAGE

AUDIO ORIGINAL SUBTITLE OFF DISC MENU ENGLISH PLAYER MENU ENGLISH

3-5

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 64

Page 65

Display (cont’d) 65

DISPLAY

TV ASPECT

4:3 LETTERBOX STILL MODE AUTO ANGLE ICON ON AUTO POWER OFF

PROGRESSIVE OFF

DISPLAY

TV ASPECT

4:3 LETTERBOX STILL MODE AUTO ANGLE ICON ON AUTO POWER OFF

ON PROGRESSIVE OFF

Press SYSTEM/MENU to remove the menus.

● If

PROGRESSIVE is ON, this message appears:

Press

o or p to make a selection, then press OK. If you select NO, the menu disappears and PROGRESSIVE is OFF. If you select YES, this appears:

Confirm your setting, then press OK. The menu will disappear and PROGRESSIVE will be ON. If you do not press any buttons for 15 seconds, the Progressive Scan will switch to OFF.

DISPLAY

TV ASPECT

4:3

LETTER BOX

4:3

PAN & SCAN

16:9

WIDE

TV ASPECT ANGLE ICON

PROGRESSIVE

● If you selected ANGLE ICON, press OK repeatedly

to turn it ON or OFF. The default setting is ON. Choose ON to see the Angle icon when multiple camera angles are available during DVD playback. Details are on page 55. Choose OFF to disable the Angle icon.

● If you selected AUTO POWER OFF, press OK

repeatedly to turn it ON or OFF.The default setting is ON. Choose ON if you want the DVD/VCR to switch to VCR mode automatically if there is no activity at the DVD Player for 35 minutes.

● If you chose PROGRESSIVE, press OK repeatedly

to turn PROGRESSIVE ON or OFF.The default setting is OFF. Choose ON if your TV has Progressive Scan and if the TV is connected to the Player’s COMPONENT VIDEO OUT jacks. Choose OFF otherwise.

AUTO FIELD FRAME

DISPLAY

STILL MODE

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

DISPLAY

TV ASPECT

4:3 LETTERBOX STILL MODE AUTO ANGLE ICON ON AUTO POWER OFF

ON PROGRESSIVE OFF

AUTO POWER OFF

•You can set PROGRESSIVE to OFF either in the DISPLAY menu or by pressing and holding the PLAY

(DVD) button on the front of the DVD/VCR for more than five seconds.

Helpful Hints

Confirm again to use progressive scan. If Picture is good, Select “YES”.

SELECT: K / L SET:OK

NO YESNOYES

5-6

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 65

Page 66

66 Language

You can use the LANGUAGE settings to select different languages for the Audio or Subtitles of DVDs, as well as languages for DVD Disc menus and the menus of the DVD Player SETUP menus.

Press DVD to put the DVD/VCR in DVD mode.The DVD light will appear on the front of the DVD/VCR.

While playback is stopped, press SYSTEM/MENU.

The QUICK SETUP screen appears.

The Language menu ( ) will be selected. Press OK.

Press ooor ppto select AUDIO, SUBTITLE, DISC MENU, or PLAYER MENU.Then, press OK.

The lan-

guage options for the selected item will appear.

QUICK SETUP

PLAYER MENU ENGLISH TV ASPECT

4:3 LETTER BOX

DOLBY DIGITAL ON

AUDIO:The DVD’s audio plays in the selected language.

SUBTITLE: Subtitles appear in the chosen language.

DISC MENU:A DVD’s Disc menu appears in the chosen language.

PLAYER MENU:The DVD Player’s Setup menu can be in English, French, or Spanish only.

LANGUAGE

AUDIO

ORIGINAL ENGLISH FRENCH SPANISH GERMAN

ITALIAN SWEDISH

LANGUAGE

SUBTITLE

OFF ENGLISH FRENCH SPANISH GERMAN

ITALIAN SWEDISH

LANGUAGE DISC MENU

ENGLISH FRENCH SPANISH GERMAN

ITALIAN SWEDISH DUTCH

LANGUAGE

PLAYER MENU

ENGLISH FRANÇAIS ESPAÑOL

Press s or B to select CUSTOM at the top of the menu, then press OK.

• If the DVD’s default settings for Audio and Subtitle are the same language, the subtitles may not show unless you turn them on.

• Use the AUDIO and SUBTITLE buttons to select Audio and Subtitles available on the DVD. Details are on pages 55 and 58.

• If you set AUDIO to ORIGINAL, the default setting of the DVD Audio will play.

•

If you set PLAYER MENU to FRANÇAIS (French), or ESPAÑOL (Spanish) and need English: Follow steps

1-3.At step 4, the IDIOMA or LANGUE menu will appear. Press OK. Press

to select MENU DU LECTEUR or MENU REPRODUC., then press OK. Press

to select ENGLISH, then press OK.The menus will change to English. Press SYSTEM/MENU to remove the menus.

•You can change the PLAYER MENU language in the QUICK SETUP menu that appears when you first press SYSTEM/MENU. With QUICK selected, press OK. PLAYER MENU will be selected. Press OK. Press oor pto choose a language, then press OK. Press SYSTEM/MENU to remove the menu.

Helpful Hints

3-5

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 66

Page 67

Language (cont’d) 67

Press o or p to select a language, then press OK. The language list continues on multiple screens.

Press o or p to move to the other screens.

● If you select OTHER for AUDIO, SUBTITLE, or

DISC MENU, press four Number buttons to enter the code for the language you desire. Use the Language Codes below.The language or language code you select will appear in the Language menu beside AUDIO, SUBTITLE, or DISC MENU.

● You can select other languages for AUDIO,

SUBTITLE, and DISC MENU only if the language is available on the Disc. If the language you select is not recorded on the DVD, changing these settings will have no effect.

Press SYSTEM/MENU to remove the menu.

LANGUAGE

LANGUAGE CODE

Please enter a 4-digit language code.

A-B

Abkhazian 4748 Afar 4747 Afrikaans 4752 Albanian 6563 Amharic 4759 Arabic 4764 Armenian 547

Assamese 4765 Aymara 4771 Azerbaijani 4772 Bangla 4860 Bashkir 4847 Basque 5167 Bengali 4860 Bhutani 5072 Bihari 4854 Bislama 4855 Breton 4864 Bulgarian 4853 Burmese 5971 Byelorussian 4851

C-E

Cambodian 5759 Catalan 4947 Chinese 7254 Corsican 4961 Croatian 5464 Czech 4965 Danish 5047 Dutch 6058

English 5

160 Esperanto 5161 Estonian 5166

F-H

Faroese 5261 Fiji 5256 Finnish 5255 French 5264 Frisian 527

Gaelic (Scots) 5350 Galician 5358 Georgian 5747 German 5051 Greek 5158 Greenlandic 5758 Guarani 5360 Gujarati 5367 Hausa 5447 Hebrew 5569 Hindi 5455 Hungarian 5467

I-K

Icelandic 5565 Indonesian 5560 Interlingua 5547 Interlingue 5551 Inupiak 5557 Irish 5347 Italian 5566 Japanese 5647 Javanese 5669

Kannada 5760 Kashmiri 5765 Kazakh 5757 Kinyarwanda 6469 Kirghiz 577

Kirundi 6460 Korean 5761 Kurdish 5767

L-N

Laothian 5861 Latin 5847 Latvian 5868 Lettish 5868 Lingala 5860 Lithuanian 5866 Macedonian 5957 Malagasy 5953 Malay 5965 Malayalam 5958 Maltese 5966 Maori 5955 Marathi 5964 Moldavian 5961 Mongolian 5960 Nauru 6047 Nepali 6051 Norwegian 6061

O-R

Occitan 6149 Oriya 6164 Oromo (Afan)6159

Panjabi 6247 Pashto 6265 Persian 5247 Polish 6258 Portuguese 6266 Pushto 6265 Quechua 6367

Rhaeto-Romance 6459

Romanian 6461 Russian 6467

Samoan 6559 Sangho 6553 Sanskrit 6547 Serbian 6564 Serbo-Croatian

6554 Sesotho 6566 Setswana 6660 Shona 6560 Sindhi 6550 Singhalese 6555 Siswat 6565 Slovak 6557 Slovenian 6558 Somali 6561 Spanish 5165 Sundanese 6567 Swahili 6569 Swedish 6568

Tagalog 6658 Tajik 6653 Tamil 6647 Tatar 6666 Telugu 6651 Thai 6654 Tibetan 486

Tigrinya 6655 Tonga 6661 Tsonga 6665 Turkish 6664 Turkmen 6657 Tw i 6669

U-Z

Ukrainian 6757 Urdu 6764 Uzbek 6772 Vietnamese 6855 Volapuk 6861 Wels h 4971 Wolo f 6961 Xhosa 7054 Yiddish 5655 Yoruba 7161 Zulu 7267

Language Codes

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 67

Page 68

Change Audio settings based on other equipment you connected to the DVD/VCR or according to your Disc sound features.These settings only affect the Audio from the DVD Player of the DVD/VCR.

Press DVD to put the DVD/VCR in DVD mode.The DVD light will appear on the front of the DVD/VCR.

While play is stopped, press SYSTEM/MENU. The QUICK SETUP screen will appear.

Press s or B to select CUSTOM at the top of the menu, then press OK.

Press s or B to select AUDIO ( ). Press OK.

Press ooor ppto select DRC, DOLBY DIGITAL, or DOWN SAMPLING, then follow step 6 accordingly.

●

If you selected DRC, press OK repeatedly to turn Dynamic Range Control (DRC) ON or OFF. Choosing ON compresses the range of volume by suppressing loud sounds and raising low sounds. DRC is available only on Discs recorded in the Dolby Digital format.

●

If you selected DOWN SAMPLING, press OK repeatedly to choose ON or OFF. ON sets downsampling to 48 kHz. OFF sets downsampling to 96 kHz. DOWN SAMPLING is available only when the unit is connected to a Stereo using the COAXIAL DIGITAL AUDIO OUT jack.

●

If you selected DOLBY DIGITAL, press OK repeatedly to select ON or OFF. Select ON if you used the COAXIAL DIGITAL AUDIO OUT jack to connect the DVD/VCR to a stereo that is Dolby Digital compatible. Details are on page 15. Otherwise, choose OFF.

68 Audio

2,7

QUICK SETUP

PLAYER MENU ENGLISH TV ASPECT

4:3 LETTER BOX

DOLBY DIGITAL ON

LANGUAGE

AUDIO ORIGINAL SUBTITLE OFF DISC MENU ENGLISH PLAYER MENU ENGLISH

• Dolby Digital sound must be available on the DVD.

•You can adjust DOLBY DIGITAL in the QUICK SETUP menu that appears when you first press SYSTEM/MENU.With QUICK selected, press OK. Press pto select DOLBY DIGITAL. Press OK to choose ON or OFF. Press SYSTEM/MENU to remove the menu.

• When you play a Disc that has copyright protection, downsampling will be at 48 kHz, even if you set DOWN SAMPLING to OFF.

Helpful Hints

3-6

Dolby Digital

DRC

Down Sampling

Press SYSTEM/MENU to remove the menu.

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 68

AUDIO

DRC DOWN SAMPLING DOLBY DIGITAL

ON ON ON

DRC DOWN SAMPLING DOLBY DIGITAL

AUDIO

ON ON ON

AUDIO

DRC DOWN SAMPLING DOLBY DIGITAL

ON ON ON

Page 69

On-Screen Displays 69

Audio CD and Video CD Displays

Press DVD to put the DVD/VCR in DVD mode. The DVD light will appear on the front of the DVD/VCR.

Press DISPLAY repeatedly to see the following displays during Audio CD or Video CD (without PBC) play.

Press DISPLAY repeatedly

or press RETURN to

remove the display.

Press DISPLAY repeatedly or press RETURN to remove the display.

BIT RATE: The amount of audio and video data currently being read.

Layer number, appears only when playing a two-layered Disc. L0: Layer 0 is playing L1: Layer 1 is playing

Current Repeat setting, if active C: Chapter repeat T: Title repeat A B: A-B repeat

TR 4/12 0:03:21 - 0:02:15

TR (Track): Current Track number / total Tracks

Elapsed playing time of the current Track; remaining playing time of the current Track

ALL 4/12 0:13:45 - 0:45:40

ALL: Current track number / total Tracks

Elapsed playing time of the current Audio CD; remaining playing time of the current Audio CD

Current Repeat setting, if active T: Track repeat A: All Tracks repeat A B: A-B repeat

CH 7/49 0:01:46 - 0:03:27

CH (Chapter): Current Chapter number / total Chapters

Elapsed playing time of the current Chapter; remaining playing time of the current Chapter

2-3

TT 1/2 0:00:00 - 1:23:45

TT (Title): Current Title number / Total Titles

Elapsed playing time of the current Title; remaining playing time of the current Title

2-3

DVD Displays

Press DVD to put the DVD/VCR in DVD mode.The DVD light will appear on the front of the DVD/VCR.

Press DISPLAY repeatedly to see the following displays during DVD playback.

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 69

Page 70

70 Black Level,Virtual Surround

Black Level

Adjust Black Level to brighten the DVD and Video CD picture during playback.

Press DVD to put the DVD/VCR in DVD mode.The DVD light will appear on the front of the DVD/VCR.

During DVD or Video CD play, press MODE so the Black Level icon shows in the top left corner of the TV screen.

Within 10 seconds, press OK repeatedly to choose ON or OFF.

ON brightens the dark parts of the picture.

OFF shows the original picture as recorded.

Virtual Surround

You can enjoy improved stereo sound when you play DVDs,Audio CDs,Video CDs, or MP3 files recorded in Dolby Digital or Pulse Code Modulation (PCM). Check the Disc case for details on availability.

Press DVD to put the DVD/VCR in DVD mode. The DVD light will appear on the front of the DVD/VCR.

During Disc play, press MODE so the Virtual Surround icon appears in the top left corner of the TV screen.

While the Virtual Surround icon appears, press OK to choose

1, 2, or OFF. The default setting is OFF.

The icon will disappear after about 10 seconds.

• Virtual Surround is available only when the DVD/VCR is connected to a Stereo or TV using the red and white DVD/VCR AUDIO OUT jacks on the DVD/VCR.

• Virtual Surround is active only if you set Stereo Sound Mode to Stereo. Details are on page 58.

• Virtual Surround and Black Level settings will be saved even if the DVD/VCR is turned off.

Helpful Hints

STANDBY-ON

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

STANDBY-ON

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 70

OFF

Page 71

Initializing 71

Press SYSTEM/MENU to remove the menu.

Press s or B to select INIT. (INITIALIZE) at the top of the menu, then press OK.

2,5

3-4

STANDBY-ON

PLAY

DVDVCR VCR/TV

MENU MENU

DISC/VCR

RETURN TITLE

A-B

CLEAR/RESET SLOW

SUBTITLE ZOOM

ANGLE

REPEAT REPEAT

AUDIO

SEARCH MODE

DISPLAY

SKIP / CH

SYSTEM

PAUSESTOP

MARKER RECORDTIMER SET

SPEED

1 2 3

+10

Press ooor ppto select YES.Then, press OK twice. To cancel, select NO instead.

INITIALIZE

Initialize?

NO YES

INITIALIZE

Initialize?

NO YES

Initializing

Use INITIALIZE to return all the DVD Player’s Setup menu items (except for PARENTAL) to their default settings.

Press DVD to put the DVD/VCR in DVD mode.The DVD light will appear on the front of the DVD/VCR.

While play is stopped, press SYSTEM/MENU. The QUICK SETUP screen appears.

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 71

QUICK SETUP

PLAYER MENU ENGLISH TV ASPECT DOLBY DIGITAL ON

4:3 LETTER BOX

Page 72

72 Glossary

AUDIO IN/OUT Jacks: jacks on the front and back of the DVD/VCR that receive audio from another source (IN) or send audio to another system (OUT).These jacks are red (right) and white (left).

Automatic Channel Setup: process in which the VCR memorizes all available TV channels.Then, when you press SKIP ∑/CH o or SKIP w/ CH p in VCR mode, you only scan through channels you receive.

Bands: settings that allow you to tune channels.

• Antenna – VHF (very high frequency; channels 2-13) and UHF (ultra high frequen-

cy; channels 14-69).

• Cable – standard channels 1-125 can be available without a Cable Box. Cable Box/Satellite Receiver Output Channel: 03 or 04. COAXIAL DIGITAL AUDIO OUT jack: Sends digital audio to a Stereo, allowing

you to adjust the volume at the Stereo.This connection provides the 5.1 channel surround sound as heard in movie theaters.This jack on the DVD/VCR is black.

COMPONENT VIDEO OUT (Y CB/PBCR/PR) Jacks:jacks on the back of the DVD/VCR that send high-quality DVD video to a TV with Component Video In jacks. This connection provides the best picture quality for the DVD Player of the DVD/VCR.

Dolby Digital:A surround sound system that provides 5.1 channel sound as used in movie theaters.

Dubbing: copying a video cassette using another VCR. HQ: high quality; a feature in the VCR circuitry which provides enhanced picture

detail. Line Input: The channel to which you set your DVD/VCR during video cassette

copying. If you connected the other video equipment to the AUDIO and VIDEO In jacks on the front of the DVD/VCR, select L2. If you used the AUDIO and VIDEO IN jacks on the back of the DVD/VCR, select L

1.If you accidentally enter Line Input mode, press SKIP ∑/CH o or SKIP w/ CH p or the Number buttons to select another channel.

OTR: One-Touch Recording; a timed recording on the VCR that starts immediately and records for 30 minutes to 8 hours.

RF coaxial cable: A black cable supplied with your DVD/VCR. Use it to connect your DVD/VCR to your TV, Cable Box, or Satellite Receiver.

S-Video: Produces a clearer DVD picture by sending separate signals for the luminance and the color. S-Video only provides a picture for the DVD Player of the DVD/VCR.

Tape Speeds: how fast the video cassette travels during a recording or playback.The faster the tape speed, the better the picture quality. Slower tape speeds affect picture quality, but you can record more onto a videotape.

• SP (standard play) – fastest tape speed (recording time for a T120 tape is approxi-

mately two hours); best picture quality.

• LP (long play) – average tape speed.You cannot record in LP with this VCR. If tapes

were recorded on a different VCR in LP speed, the tape will play in LP on the DVD/VCR.

• SLP (super long play) – slowest tape speed (recording time for a T120 tape is

approximately six hours).This speed allows the maximum recording on a single videotape.

VIDEO IN/OUT Jacks: jacks on the front and back of the DVD/VCR that receive video from another source (IN) or send video to other video equipment or a TV (OUT).These jacks are yellow.

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 72

Page 73

Specifications 73

VCR Video Heads

Four heads - Hi-Fi

Antenna

VHF/UHF – 75 ohm external antenna terminal

VHF Output Signal

Channel 03 or 04 75 ohms unbalanced

DVD Color System

NTSC

Frequency Response

DVD (linear sound): 20 Hz to 22 kHz (sample rate: 48 kHz) 20 Hz to 44 kHz (sample rate: 96 kHz) Audio CD: 20 Hz to 20 kHz

Signal-to-Noise Ratio

Audio CD: 120 dB JEITIA (Japan Electronics and Information Technology Industries Association)

Dynamic Range

DVD (linear sound): 102 dB Audio CD: 99 dB (JEITIA)

Total Distortion Factor

Audio CD: 0.003% (JEITIA) DVD: 0.0025%

Wow and Flutter

Below the measurement limitation (±0.001% W PEAK) (JEITIA)

Power Requirement

120V AC +/- 10%, 60 Hz +/- 0.5%

Power Consumption

Power on: 21 W Power off: 3.6 W

Operating Temperature

41°F (5°C) to 104°F (40°C)

Relative Humidity

30% to 80%

Dimensions

17-3/16” (W) x 3-3/4” (H) x 9-3/16” (D) (435mm x 94mm x 233mm)

Weight

6.0 lbs. (2.7 kg.)

NOTE: Designs and specifications are subject to change without notice.

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 73

Page 74

74 Helpful Hints

If you are having problems with your product, check this list of problems and possible solutions before requesting service.You may be able to solve the problem yourself. If you need to call a customer service representative, please know the model number and serial number of your product before you call.This information is displayed on the back of the product. Also, please take a moment to identify the problem you are having, and be prepared to explain this to the representative. If you believe the representative will need to help you with operations, please stay near the product. Our representatives will be happy to assist you.

The DVD/VCR has no power.

•Make sure the power cord is connected completely to an AC (alternating current) outlet.

•Press the STANDBY-ON

button to turn on the DVD/VCR.The DVD/VCR usually turns on in the mode it was in when you turned it off. If there has been a power failure, it will turn on in VCR mode. Press DVD to put the unit in DVD mode. Press VCR to put the unit in VCR mode. Or, press SOURCE on the front of the DVD/VCR to switch between the two modes.

The remote control will not operate the DVD/VCR.

• Aim the remote control directly at the remote sensor on the front of the DVD/VCR, not toward the TV.

Details are on page 22.

• Remove all obstacles between the remote control and the DVD/VCR.

• Inspect and/or replace the batteries in the remote control. Details are on page 16.

• Use the remote control within 23 feet of the DVD/VCR.

• When using the DVD Player, press the DVD button, then try the other DVD feature buttons. Press DVD so the DVD light appears on the front of the DVD/VCR.This means the DVD/VCR is in DVD mode.

•To use the VCR, press VCR, then try the other VCR feature buttons. Press VCR so the VCR light appears on the front of the DVD/VCR.This means the DVD/VCR is in VCR mode.

There is no picture in DVD mode.

•Make sure the video cable is connected correctly.You may connect either the yellow video cable (supplied), an optional S-Video cable, or optional component video cables. Make sure the TV is set to the correct Video In channel (usually the AUX IN,A/V IN,Auxiliary In, EXT or External In, Component Video In, or S-Video In channel). Check your TV owner’s manual for details.

Details are on pages seven and 11-15.

•If you only used the supplied black RF coaxial cable, details are on pages 8-10. Make sure the TV is set to channel 3 or 4 (the output channel of the DVD/VCR). Or, if you have a Cable Box/Satellite Receiver, make sure the TV is set to the Cable Box/Satellite Receiver output channel (usually 03 or 04).

• Insert a DVD that is playable on this DVD/VCR. Details are on page six.

•Make sure the DVD/VCR is in DVD mode. Press DVD or SOURCE so the DVD light appears on the front of the DVD/VCR.

• Check if Progressive Scan is set correctly according to your connection to a TV. Details are on page seven. Enable Progressive Scan at the DVD Player only if you used the Component Video connection to a TV that has Progressive Scan. Details are on pages seven, 12, and 64-65

Disc cannot be played.

• Insert a playable Disc. Details are on page six.

• Place the Disc correctly in the Disc tray. If the Disc is one-sided, place the Disc in the tray with the label facing up. If the Disc is two-sided, make sure the label of the side you want to play is facing up.

•Clean the Disc. Make sure the Disc is not scratched or warped.

• Cancel the Parental Controls, enter the password, or change the control level. Details are on pages 56-57.

•Make sure the Disc is labelled for use in Region 1 or ALL regions and is NTSC or PAL compatible. Details

are on page six.

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 74

Page 75

Helpful Hints (cont’d) 75

There is no sound.

• Connect the audio cables firmly. Make sure the cables are connected to the AUDIO IN jacks on the TV

or Stereo. Details are on pages 11-14.

• Check the audio settings of the DVD Player. Details are on page 68.

• Check the audio settings of the DVD. For example, you may have selected “soundtrack” playback or an

unavailable sound setting (such as Dolby Digital). Details are on pages 58 and 68. Tr y other sound options provided in the DVD Disc menu.

• If you used audio cables (instead of only using the supplied black RF coaxial cable) make sure the TV or Stereo is set to the correct Audio In channel (usually the AUX IN,Auxiliary In, A/V IN,Audio In, or External In channel). See your TV or Stereo owner’s manual for details.

The picture is distorted.

• Connect the DVD/VCR directly to the TV. Details are on pages 7-15. Do not connect the DVD/VCR to a VCR, then connect the VCR to the TV. Copyright protection systems in the VCR could distort the picture playing on the DVD/VCR.

• There are some cases where a Disc or videotape picture may be distorted slightly because of the quality in which it was recorded.This is not a malfunction of the DVD/VCR.

•Make sure the Disc is compatible with the DVD Player of the DVD/VCR. Details are on page six.

• If your TV is not PAL compatible, DVDs recorded in the PAL color system may play only in black and white, the picture may roll continuously, or the picture may appear distorted.

You cannot change the camera angle of a DVD.

• The DVD might not contain segments recorded from different camera angles. See if multiple angles are available by referring to the Disc case or DVD Disc menu.

Details are on page 55.

You cannot change the audio or subtitle language of a DVD.

• The DVD does not contain audio or subtitles in the desired language. Not all DVDs contain audio or subtitles in multiple languages. See if other languages are available by referring to the Disc case or DVD Disc menu. Details are on pages 55 and 58.

An X appears in the top right corner of the TV screen when you try a DVD feature.

• The operation is not available at the current time or the feature is not available on the Disc. Some features are only available during playback. Others can be accessed only if play is stopped.Try stopping or playing the Disc, then try the feature again.

The DVD/VCR switches from DVD mode to VCR mode after 35 minutes of no activity.

• When AUTO POWER OFF is set to ON, the DVD/VCR switches itself from DVD mode to VCR mode if Disc playback stops for more than 35 minutes and you press no buttons on the remote or the DVD/VCR. Details are on pages 64-65. This prevents possible damage to your TV’s picture tube that can occur if a still image is left on too long.

A screen saver appears on the TV screen during DVD mode.

• The DVD logo will appear on the TV screen when you stop Disc playback.You cannot remove it.

You want to use the DVD Player during a VCR timer recording or while appears on the display panel.

•Press STANDBY-ON y to turn on the DVD/VCR. Press DVD to choose DVD mode, then continue with other DVD features as described in this manual.

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 75

Page 76

Power Failure

• Clock setting, language selection, and channel setup may be lost if the power fails. See pages 26-30 to set up the channels, clock, and language again.

The VCR will not record a TV program.

• Put the DVD/VCR in VCR mode. Press VCR or SOURCE so the VCR light appears on the front of the DVD/VCR.

• Check the connections between the DVD/VCR,TV, antenna/Cable TV signal, and Cable Box/Satellite Receiver (if applicable). Details are on pages 8-15.For VCR features, you must connect the DVD/VCR to a TV with the RF coaxial cable or the yellow video cable as described on pages 8-11.

• Make sure the video cassette has a record tab. Details are on page 32.

The VCR will not perform a timer recording.

• Make sure the recording start and stop times are set correctly. Details are on pages 36-38.

• Make sure a tape is in the VCR and the tape has a record tab. Details are on page 32. If, after programming

a timer recording, you press TIMER SET without putting a tape in the DVD/VCR, will blink on the display panel.

• If the record tab on a tape is missing, the DVD/VCR will eject the tape. will blink.

• Press TIMER SET to put the DVD/VCR in standby mode for the timer recording.

• Make sure the VCR clock is set. Details are on pages 28-29.

• The VCR may not perform or continue a timer recording if the power fails.

• If you have a Cable Box/Satellite Receiver, set timer recordings differently. Details are on page nine.

• Finish programming a timer recording at least five minutes before it is set to begin.

• 12 p.m. is noon; 12 a.m. is midnight.

There is no picture or the picture is noisy or has streaks during video cassette playback.

• Put the DVD/VCR in VCR mode. Press VCR or SOURCE so the VCR light appears on the front of the DVD/VCR.

• If you used the supplied RF coaxial cable to connect the DVD/VCR to the TV, make sure the TV is on the same channel as the DVD/VCR’s output channel (03 or 04). The DVD/VCR’s output channel is channel 3 when you receive it.To change it to channel 4, see page eight. Make sure channel 03 or 04 is properly adjusted at the TV. Or, if you connected the DVD/VCR to the TV using audio and video cables, select the correct Video In channel at the TV. Details are on pages seven and 11.

• Adjust the tracking. Details are on page 44.

• TVs placed too close to the DVD/VCR can cause interference during tape playback. Move the DVD/VCR

away from the TV.

The Number buttons won’t work for TV channels above 69.

• Enter channel numbers as a two-digit number. If you want to select channels 100 and above, enter chan- nel numbers as a three-digit number. If you do not have Cable TV, only channels 2-69 are available.

TV programs cannot be watched normally.

• Check the connections between the DVD/VCR,TV, antenna/Cable TV signal, and Cable Box/Satellite Receiver (if applicable).

Details are on pages 8-15.

Poor reception

• You may need to tune your TV again. Or, reset channels at the VCR using CHANNEL SET UP. Details are on pages 26-27.

76 Helpful Hints (cont’d)

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 76

Page 77

You cannot insert a video cassette.

• Insert the tape, window side up, with the record tab facing you.

• Make sure a tape isn’t already in the VCR by pressing STOP/EJECT C A (VCR) on the front of the

DVD/VCR.

• Gently push on the center of the tape when putting it in the VCR. Never force the tape into the VCR.

• If a timer recording is set, you cannot insert a tape without a record tab.

You cannot remove the tape.

• Make sure the power plug is completely connected to a power outlet.

• If you have set a timer recording, press TIMER SET to delay the recording.The will disappear from the

display panel.Then, press STOP/EJECT C A (VCR) on the front of the DVD/VCR to eject the tape. Insert another tape and press TIMER SET to reset the timer recording.

•

Unplug the DVD/VCR power cord for five minutes.Then, plug in the power cord again and press STANDBYON y on the DVD/VCR. Press

STOP/EJECT C A (VCR)

on the DVD/VCR three to five times. If the tape

still does not eject, you may need to have an authorized servicer remove the tape.

DVD/VCR ejects the tape when you press RECORD I or TIMER SET.

• Make sure the tape has a record tab. Details are on page 32.

Satellite Receiver Hookups

• Watching one TV channel while recording another may not be possible if you have a Satellite Receiver. Set

your TV to channel 03 or 04, then make your channel selections at the Satellite Receiver.

• With many Satellite Receiver hookups, if you use audio and video cables to connect your DVD/VCR to

your TV, you will have to put your DVD/VCR in Line Input mode (L1 or L2).

Line Input mode

• If you accidentally enter Line Input mode (L1 or L2 will appear on your TV screen briefly), press SKIP

∑/CH o or SKIP w/ CH p or the Number buttons to select another channel.

Hi-Fi Stereo Sound

•

During playback, Hi-Fi audio may normally revert to normal audio when you adjust tracking.

• When connecting the DVD/VCR to a TV with the red and white audio cables, you will only get stereo sound if you connect the DVD/VCR AUDIO OUT jacks on the DVD/VCR to the AUDIO IN jacks on your TV, and if the TV is on its Audio/Video In channel. See your TV owner’s manual for details.

• When you connect the DVD/VCR AUDIO OUT jacks on the DVD/VCR to the AUDIO IN jacks on your TV, the stereo light on the TV might not glow. If the status display indicates you are receiving stereo, you are.

Details are on page 45.

• Only tapes recorded in Hi-Fi audio will play in Hi-Fi audio.Tapes recorded in normal audio will play in monaural (single-channel) audio.

Cleaning the Video Heads

• Your DVD/VCR automatically cleans the video heads of the VCR each time you insert a tape. However, the heads may become dirty. If so, have an authorized servicer clean the video heads. Eventually, the heads may need to be replaced.

The playback picture is too dim, too bright, or fluctuates in brightness.

• Some programs may be broadcast with copyright protection technology in order to protect the rights of copyright owners.This technology is used on programs that are recorded on video cassettes or DVDs, as well as some programs broadcast by antenna/cable/satellite television channels. Programs broadcast with copyright protection may not record clearly. Likewise, if you play a tape that is a recording of a copyright protected program, the picture may not be clear.Tapes of copyright protected programs may have a picture that is dark or dim, or the brightness of the picture may fluctuate.Therefore, avoid recording or playing copies of copyright protected programs.

• This DVD/VCR incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection technology must be authorized by Macrovision Corporation and is intended for home and other limited viewing uses only, unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

Helpful Hints (cont’d) 77

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 77

Page 78

78 Care and Maintenance

Cleaning the DVD/VCR

• Wipe the front panel and other exterior surfaces of the DVD/VCR with a soft, slightly damp cloth.

• Never use a solvent, thinner, benzene, or alcohol to clean the DVD/VCR. Do not spray insecticide liquid near the DVD/VCR. Such chemicals may discolor the surface or damage the DVD/VCR.

Cleaning a Disc

• Use a soft, dry cloth to wipe the Disc.

• Wipe the Disc in a straight line from the center to the edge. Never wipe the Disc in a circular motion.

• Do not use detergent or abrasive cleaning agents.

• Handle the Discs so fingerprints and dust do not adhere to the Discs.

• Always store the Disc in its protective case when it is not in use.

Checking the Laser

• If the DVD/VCR does not operate as described in this manual, the DVD Player’s laser may be dirty. Consult an Authorized Service Center for inspection and cleaning of the laser.

Caring for Video Cassettes

• Use only cassettes with the mark.

• Remove any light adhesive stick-on notes from the video cassette before putting the cassette in the VCR. Removable labels can jam the VCR.

Caring for the VCR’s Video Heads

• Periodic maintenance is required to maintain your DVD/VCR’s excellent performance.The VCR has an Automatic Head Cleaner. However, the video heads will require replacement eventually. Only an authorized service center should perform this service.

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 78

Page 79

Limited Warranty 79

Philips, P.O. Box 520890, Miami, FL 33152 (402) 536-4171

Ninety (90) Days Free Product Exchange

Ninety-One (91) Days-One (1) Year Reduced-Cost Exchange

PHILIPS LIMITED WARRANTY

PHILIPS CONSUMER ELECTRONICS warrants

this product against defect in material or workmanship, subject to any conditions set forth as follows:

PROOF OF PURCHASE:

You must have proof of the date of purchase to exchange the product.A sales receipt or other document showing the product and the date that you purchased the product, as well as the authorized retailer included, is considered such proof.

COVERAGE:

Warranty coverage begins the day you buy your product. For a period of ninety (90) days from the date of purchase, if the product is determined to be defective, Philips will exchange the defective product with a new or renewed product, at its option, at no charge. From ninety-one (91) days to one year from the date of purchase, you will pay a preset exchange fee to obtain a new or renewed product. Contact the Customer Care Center for limited exchange pricing.This exchange opportunity ends one year after the date of purchase. The replacement product is covered only for the warranty period of the original product.When the warranty on the original product expires, the warranty on all replaced products also expires.When it is necessary for you to ship the product to Philips for exchange, you will pay the shipping cost for shipment to Philips. Philips will pay the shipping costs when returning a product to you.

Note:The exchange model supplied will be the most comparable one in Philips current inventory. Shipping of your product to Philips implies intent to follow the specified requirements of the warranty and exchange program. Product received by Philips cannot be returned. Replacement product can only be sent if all warranty requirements are met. Failure to follow all requirements can result in delay of exchange process.

EXCLUDED FROM WARRANTY COVERAGE

Your warranty does not cover:

• Shipping charges to return defective product.

• Labor charges for installation or setup of the product, adjustment of customer controls on the product, and installation or repair of antenna systems outside of the product.

•Product repair and/or part replacement because of improper installation, connections to improper voltage supply, abuse, neglect, misuse, accident, unauthorized repair or other cause not within the control of Philips.

• Damage occurring to product during shipping when improperly packaged or cost associated with packaging.

•A product that requires modification or adaptation to enable it to operate in any country other than the country for which it was designed, manufactured, approved and/or authorized, or repair of products damaged by these modifications.

•A product used for commercial or institutional purposes (including but not limited to rental purposes).

•Product lost in shipment and no signature verification receipt can be provided.

•Products sold AS IS or RENEWED.

WHERE WARRANTY EXCHANGE IS AVAILABLE:

Exchange is available in all countries where Philips officially distributes the product. In countries where Philips does not distribute the product, the local Philips organization will attempt to exchange the product, although there may be a delay if the appropriate product is not readily available, or special customs processes are implied.

FOR EXCHANGE IN THE U.S.A., PUERTO RICO, OR U.S.VIRGIN ISLANDS…

Contact Philips Customer Care Center at:

1-800-531-0039

FOR EXCHANGE IN CANADA…

1-800-661-6162 (French Speaking) 1-800-531-0039 (English or Spanish Speaking)

REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY FOR THE CONSUMER. PHILIPS SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY.

Some states do not allow the exclusions or limitation of incidental or consequential damages, or allow limitations on how long an implied warranty lasts, so the above limitations or exclusions may not apply to you. In addition, if you enter into a service contract agreement with the PHILIPS partnership within ninety (90) days of the date of sale, the limitation on how long an implied warranty lasts does not apply.

EL6589E001 / 01-04

This warranty gives you specific legal rights. You may have other rights which vary from state/province to state/province.

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 79

Page 80

80 Information Index

ac power cord . . . . . . . . . . . . . . . . .23

angle button . . . . . . . . . . . . . . . .25, 55

angle icon . . . . . . . . . . . . . . . . . . . . .64

ant-in (antenna in) jack . . . . . .8-

15, 23 ant-out (antenna out) jack . . .8-10, 23

arrow buttons . . . . . . . . . . . . . . . . .24

audio button . . . . . . . . . . . . . . . .25, 58

audio in/out jacks . . . . .

11-14, 22-23, 35

audio settings . . . . . . . . . . . . . . . . . .68

auto power off . . . . . . . . . . . . . .64-65

auto repeat . . . . . . . . . . . . . . . . . . .40

automatic

tape playback . . . . . . . . . . . . . . . .44

tape rewind, eject . . . . . . . . . . . . .44

a-b repeat . . . . . . . . . . . . . . . . . . . .53

a-b repeat button . . . . . . . . . . . .24, 53

batteries . . . . . . . . . . . . . . . . . . . . . .

bit-rate display . . . . . . . . . . . . . . . . .69

black level . . . . . . . . . . . . . . . . . . . .70

camera angle . . . . . . . . . . . . . . . . . .55

cassette compartment . . . . . . . . . . .

channel

adding . . . . . . . . . . . . . . . . . . . . . .27

deleting . . . . . . . . . . . . . . . . . . . .27

selection . . . . . . . . . . . . . . . . .24-25

setup . . . . . . . . . . . . . . . . .

17, 26, 27

chapters . . . . . . . . . . . . . . . . . . . . . .50

clear/reset button . . . . . . . . . . . .24, 41

clock . . . . . . . . . . . . . . . . . . .2

1, 28-29

coaxial digital audio out jack . . .

15, 23

component video out jacks . . . .

12, 23

connections . . . . . . . . . . . . . . . . .7-

contents, table of . . . . . . . . . . . . . . . .4

controls

dvd/vcr . . . . . . . . . . . . . . . . . . . . .

remote . . . . . . . . . . . . . . . . . .24-25

counter . . . . . . . . . . . . . . . . .21, 3

1,41

disc menus . . . . . . . . . . . . . . . . .48, 66

disc tray . . . . . . . . . . . . . . . . . . . . . .20

disc/vcr/menu button . . . . . . . . .24, 48

display button . . . . . . . . . . . .24, 3

1,69

display messages . . . . . . . . . . . . . . . .20

display panel . . . . . . . . . . . . . . . .

20-21

displays . . . . . . . . . . . . . . . . .31, 63, 69

dolby digital . . . . . . . . . . . . . . . . . . .68

down sampling . . . . . . . . . . . . . . . . .68

drc (dynamic range control) . . . . . .68

duplication (dvd to videotape) . . . . .39

duplication (tape) . . . . . . . . . . . . . . .35

dvd button . . . . . . . . . . . . . . . . . . . .25

dvd light . . . . . . . . . . . . . . . . . . . . . .20

ejecting a tape . . . . . . . . . . . .22, 44, 77

fast forward . . . . . . . . . . . . . . . .43, 49

D (fast forward) button . . . . . . . .24

front panel . . . . . . . . . . . . . . . . . . . .22

glossary . . . . . . . . . . . . . . . . . . . . . .72

head cleaner . . . . . . . . . . . . . . . . . . .77

helpful hints . . . . . . . . . . . . . . . .74-77

hi-fi stereo sound . . . . . . . . . . . . . . .47

hookups

cable box/satellite receiver . . . .9-

component video . . . . . . . . . . . . .

S-video . . . . . . . . . . . . . . . . . . . . .

stereo . . . . . . . . . . . . . . . . . . .14-15

tv . . . . . . . . . . . . . . . . . . . . . . .8-15

index search . . . . . . . . . . . . . . . . . . .42

initializing . . . . . . . . . . . . . . . . . . . . .71

jpeg . . . . . . . . . . . . . . . . . . . . . . .62-63

language (dvd) . . . . . . . . . . . . . . .66-67

language (vcr) . . . . . . . . . . . . . . . . . .30

line input mode . . . . . . . . . . . . .35, 77

long play . . . . . . . . . . . . . . . . . . . . . .72

lp . . . . . . . . . . . . . . . . . . . . . . . . . . .72

markers . . . . . . . . . . . . . . . . . . . . . .54

menus . . . . . . . . . . . . . . . . . . . . . .5, 48

mode button . . . . . . . . . . . . .25, 60-61

mp3 display . . . . . . . . . . . . . . . . . . .63

mp3 playback . . . . . . . . . . . . . . . . . .62

number buttons . . . . . . . . . . . . . . . .25

ok button . . . . . . . . . . . . . . . . . . . . .25

on-screen status displays (vcr) . . . . .3

one-touch recording . . . . . . . . . . . .34

open/close

A button . . . . . . . . .19, 22

parental controls . . . . . . . . . . . . .56-57

password . . . . . . . . . . . . . . . . . . . . .56

pause button . . . . . . . . . .24, 43, 52, 59

play button . . . . . . . . . . . .

18-19, 22, 24

player menu . . . . . . . . . . . . . . . . . . .66

playing discs . . . . . . . . . . . . . . . . . . .

playing tapes . . . . . . . . . . . . . . . . . . .18

power

cord . . . . . . . . . . . . . . . . . . . . . . .23

on light . . . . . . . . . . . . . . . . . . . . .

program . . . . . . . . . . . . . . . . . . . . . .60

quick setup . . . . . . . . . . . . . .65, 66, 68

random . . . . . . . . . . . . . . . . . . . . . .61

rear panel . . . . . . . . . . . . . . . . . . . . .23

rec (record) light . . . . . . . . . . . . . . .

record I button . . . . . . .22, 24, 32, 34

recording

basic . . . . . . . . . . . . . . . . . . . . . . .32

one channel/watching another . . .33

prevention . . . . . . . . . . . . . . . . . .32

timer . . . . . . . . . . . . . . . . . . . .36-38

remote control

batteries . . . . . . . . . . . . . . . . . . . .

buttons . . . . . . . . . . . . . . . . . .24-25

sensor . . . . . . . . . . . . . . . . . . . . .22

repeat button . . . . . . . . . . . . . . .24, 53

repeat (discs) . . . . . . . . . . . . . . . . . .53

repeat (tape) . . . . . . . . . . . . . . . . . .40

rerecording . . . . . . . . . . . . . . . . . . .35

resume on . . . . . . . . . . . . . . . . . . . .52

return button . . . . . . . . . . . . . . . . . .24

reverse searching . . . . . . . . . . . .43, 49

E (rewind) button . . . . . . .25, 43, 49

rf coaxial cable . . . . . . . . . . . . . . .8-10

safety precautions . . . . . . . . . . . . . . .3

sap (second audio program) . . . .45-46

search button . . . . . . . . . .24, 42, 50-51

searching . . . . . . . . . . . . . . . . . . .43, 49

sensor (remote) . . . . . . . . . . . . . . . .22

skip

∑/ch o, skip w/ ch p . . . .25, 51

slow button . . . . . . . . . . . . . . . .24, 43

slow motion . . . . . . . . . . . . . . . .43, 59

slp . . . . . . . . . . . . . . . . . . . . . . . . . .72

source button . . . . . . . . . . . . . . . . .22

sp . . . . . . . . . . . . . . . . . . . . . . . . . . .72

specifications . . . . . . . . . . . . . . . . . .73

speed button . . . . . . . . . . . . . . .25, 32

standard play . . . . . . . . . . . . . . . . . .72

standby-on

y button . . . . . . . . .22, 24

status display (vcr) . . . . . . . . . . . . . .31

step-by-step playback . . . . . . . . . . . .52

stereo broadcast

hookups . . . . . . . . . . . . . . . . .

11, 14

receiving/recording . . . . . . . . .45-46

stereo sound . . . . . . . . . . . . . . . . . .58

stereo TV hookups . . . . . . . . . . . . .

still picture . . . . . . . . . . . . . . . . .43, 52

stop C button . . . . . . . . . . . . . . . . .24

stop/eject

C A (vcr) button . . . . . . .22

subtitle button . . . . . . . . . . . . . .25, 55

super high speed searching . . . . . . .43

super long play . . . . . . . . . . . . . . . . .72

s-video out jack . . . . . . . . . . . . .

13,23

table of contents . . . . . . . . . . . . . . . .4

tape

duplication . . . . . . . . . . . . . . . . . .35

eject . . . . . . . . . . . . . . . . .22, 44, 77

speed . . . . . . . . . . . . . . . . . . . . . .72

time search . . . . . . . . . . . . . . . . . . .42

timer recording

cancelling . . . . . . . . . . . . . . . . . . .38

setting . . . . . . . . . . . . . . . . . . .36-38

timer set button . . . . . . . . . . . . .25, 38

title button . . . . . . . . . . . . . . . . .24, 48

titles . . . . . . . . . . . . . . . . . . . . . . . . .48

tracking . . . . . . . . . . . . . . . . . . . . . .44

tracks . . . . . . . . . . . . . . . . . . . . . . . .51

tv aspect . . . . . . . . . . . . . . . . . . .64-65

tv hookups . . . . . . . . . . . . . . . . . .8-

vcr

button . . . . . . . . . . . . . . . . . . . . .25

light . . . . . . . . . . . . . . . . . . . . . . .2

vcr/tv button . . . . . . . . . . . . . . . . . .25

video in/out jacks . . . . .

11, 14-15, 22-23

virtual surround . . . . . . . . . . . . . . . .70

warranty . . . . . . . . . . . . . . . . . . . . .79

zoom . . . . . . . . . . . . . . . . . . . . . . . .59

zoom button . . . . . . . . . . . . . . .25, 59

This owner’s manual is made of recyclable materials. Remember to recycle!

IB8481B001 Printed In China

0VMN04158 / H9621CD * * * * *

H9621CD(EN)_2.qx4 04.4.7 0:01 PM Page 80

Page 81

ARRÊTEZ!

DVP620VR/07Lecteur de disque vidéo numérique &

magnétoscope à vidéocassette

Guide d’utilisation

NOUS VOUS REMERCIONS D'AVOIR CHOISI PHILIPS

AIDE RAPIDE?

VEUILLEZ LIRE D'ABORD NOTRE GUIDE D'UTILISATION RAPIDE ET/OU LE

MANUEL DU PROPRIÉTAIRE POUR DES CONSEILS RAPIDES RENDANT PLUS

AGRÉABLE L

'UTILISATION DE VOTRE PRODUIT PHILIPS.

I APRÈS AVOIR LU LES INSTRUCTIONS,VOUS AVEZ TOUJOURS BESOIN D'AS-

SISTANCE,VOUS POUVEZ ACCÉDER À NOTRE AIDE EN LIGNE À

WWW

.P4C.PHILIPS.COM OU BIEN APPELEZ 1-800-531-0039

AVEC VOTRE PRODUIT SOUS LES YEUX.

DVP620_07(FR)_1.qx4 04.4.7 0:01 PM Page 1

Page 82

L’enregistrement de votre modèle auprès de PHILIPS confirme votre éligibilité à tous les bénéfices mentionnés ci-dessous. N’oubliez donc pas de remplir votre carte d’enregistrement de garantie et de nous la retourner le plus tôt possible afin d’assurer :

Retournez rapidement votre carte d’enregistrement de

garantie pour profiter pleinement de votre achat.

À l’usage du client

Entrez ci-dessous le numéro de série qui se trouve à l’arrière du boîtier du dispositif. Conservez ces informations pour référence ultérieure.

No. de modèle : ____________________ No. de série : ______________________

Sachez reconnaître ces symboles de

sécurité

AVIS

RISQUE DE CHOCS ÉLECTRIQUES

NE PAS OUVRIR

Attention: Afin de prévenir le risque de chocs électriques

ne pas retirer les vis.

Toute réparation devrait être confiée à un personnel qualifié.

*Preuve d’achat

*Avis sur la sécurité des produits

*Bénéfices additionnels de l’enregistrement du produit

Nous vous félicitons de votre achat et vous souhaitons la bienvenue dans la « famille »!

Cher propriétaire d’un produit PHILIPS :

Merci de votre confiance en PHILIPS.Vous avez choisi un produit de fabrication et de garantie supérieures parmi les meilleurs disponibles sur le marché. Et nous ferons tout en notre pouvoir pour que vous soyez pleinement satisfait de votre achat pour des années à venir.

En tant que membre de la « famille » PHILIPS, vous avez droit à une protection inégalée par l’une des garanties les plus complètes de l’industrie ainsi qu’à des réseaux de service sans pareil.

De plus, votre achat garantit que vous recevrez toutes les informations et offres spéciales auxquelles vous avez droit, ainsi qu’un accès facile à toute une gamme d’accessoires disponibles via notre réseau de téléachat.

Mais ce qui est encore plus important, vous pouvez compter sur notre engagement total quand il s’agit de votre entière satisfaction. C’est notre façon de vous souhaiter la bienvenue et de vous remercier de votre investissement dans un produit PHILIPS.

P.S. Pour bénéficier au maximum de votre produit PHILIPS, assurez-vous de remplir et de retourner votre carte d’enregistrement de garantie le plus tôt possible.

Visitez notre site sur le Web à http://www.philips.com

L’enregistrement de votre produit garantit que vous bénéficierez de tous les privilèges auxquels vous avez droit y compris des offresrabais spéciales.

Retournez la carte d’enregistrement ci-incluse afin de garantir que la date d’achat de votre produit sera classée dans nos dossiers et éviter ainsi le besoin de remplir d’autres formulaires afin d’obtenir votre service de garantie.

En enregistrant votre produit, vous serez avisé - directement par le fabriquant - de toutes défectuosités compromettant la sécurité ou de tout retrait du produit du marché.

Ce symbole « d’éclair » s’applique aux matériaux non isolés présents dans votre appareil et pouvant causer un choc élec-

trique. Pour assurer la sécurité des membres de votre famille, veuillez ne pas enlever le couvercle de votre produit.

Les « points d’exclamation » ont pour but d’attirer votre attention sur des caractéristiques à propos desquelles vous devez lire soigneusement la documentation

accompagnant l’appareil afin d’éviter tout problème d’exploitation ou d’entretien.

AVERTISSEMENT :Afin de réduire les risques d’incendie ou de choc électrique, ne pas exposer cet appareil à la pluie ou à l’humidité et les objets remplis de liquide, comme les vases, ne doivent pas être placés sur le dessus de l’appareil.

CAUTION :To prevent electric shock, match wide blade of plug to wide slot, fully insert.

ATTENTION : Pour éviter les chocs électriques, introduire la lame la plus large de la fiche dans la borne correspondante de la prise et pousser à fond.

DVP620_07(FR)_1.qx4 04.4.7 0:01 PM Page 2

Page 83

Informations générales et de sécurité 3

Mesures de sécurité

Avertissement: Pour éviter les incendies ou les chocs électriques, ne pas exposer ce matériel

à la pluie ou à l’humidité. Avertissement de la FCC (Federal Communications Commission):Tout changement ou modification non autorisée effectuée sur ce dispositif annule l’autorisation de l’utilisateur d’exploiter ce dispositif. Certification du DHHS (Department of Health and Human Services): Conforme au chapitre

1, sous-chapitre J du 21 Center for Radiation (CFR) 1 applicable au moment de la fab-

rication.

Sécurité du laser: Ce dispositif utilise un laser. Seul un technicien de service qualifié

doit enlever le couvercle et tenter d’effectuer des réparations, afin d’éviter tout risque de blessure aux yeux.

MISE EN GARDE: TOUTE UTILISATION OU RÉGLAGE DES COMMANDES OU TOUTE EXÉCUTION DE PROCÉDURES AUTRES QUE CELLES SPÉCIFIÉES PAR LA PRÉSENTE PEUT ENTRAÎNER L’EXPOSITION À DES RADIATIONS DANGEREUSES. MISE EN GARDE: RAYONNEMENT LASER VISIBLE ET INVISIBLE LORSQUE LE DISPOSITIF EST OUVERT ET QUE LE VERROUILLAGE EST CONTOURNÉ. ÉVITER DE REGARDER LE RAYON LASER FIXEMENT. CE RAYON LASER SE TROUVE À L’INTÉRIEUR PRÈS DU MÉCANISME DE LA PLATINE.

Informations à l’intention des utilisateurs canadiens: Cet appareil

numérique de classe B est conforme à la norme canadienne NMB-003.

Brouillage radio/télévision: Cet appareil a été testé et répond aux limites d’un

appareil numérique de classe B, en accord avec l’article

15 des règles FCC. Ces limites ont été établies pour assurer une protection raisonnable contre toute interférence nuisible lors du fonctionnement dans un environnement commercial. Cet appareil génère, utilise et peut émettre des fréquences radioélectriques et, s’il n’est pas installé et utilisé selon les instructions, peut entraîner des interférences nuisibles aux communications radio.En revanche, il n’existe aucune garantie que des interférences ne se produiront pas dans une installation particulière. Si cet appareil est la cause d’interférences nuisibles à la réception radio ou télévision, ce qui peut être déterminé en mettant l’appareil hors tension puis sous tension, l’utilisateur peut corriger le problème en effectuant l’une ou l’autre des procédures suivantes:

1) Réorientation ou déplacement de l’antenne de réception.

2) Augmentation de la séparation entre le dispositif et le récepteur.

3) Connexion du dispositif dans une prise sur un circuit différent de celui auquel le récepteur

est connecté.

4) Consultation avec le revendeur ou un technicien radio/télévision qualifié pour obtenir de l’aide.

Protection de droit d’auteur: Il est formellement interdit de copier, transmettre,

communiquer au public et de prêter les disques. Ce produit incorpore une technologie de protection de droit d’auteur protégée par demandes de méthode de certains brevets d’invention américains et autres droits de propriété intellectuelle possédés par Macrovision Corporation et autres titulaires de droits. L’utilisation de cette technologie de protection de droit d’auteur doit être autorisée par Macrovision Corporation et est destinée seulement à un usage domestique et autres visionnements limités à moins d’indication contraire de Macrovision Corporation. Il est interdit de désosser ou de désassembler le système.

Remarque concernant l'utilisation de Balayage progressif: Les

consommateurs sont priés de bien vouloir noter que tous les téléviseurs haute définition ne sont pas pleinement compatibles avec ce produit et que cela peut entraîner l’affichage d’objets dans l’image. En cas de problèmes d’image dus au Balayage progressif du 525, il est conseillé à l’utilisateur de commuter la connexion sur la sortie “définition standard”. Si vous avez des questions au sujet de la compatibilité d’une télévision avec ce lecteur DVD modèle 525p, merci de bien vouloir contacter notre centre de service à la clientèle.

Remarque pour l’installateur du système de câble de télévision:

Ce rappel est destiné à attirer l’attention de l’installateur du système de câble à l’Article 820-40 du Code national de l’électricité, fournissant des directives quant à la mise à la terre correcte – en particulier, spécifiant que le câble de mise à la terre doit être raccordé au système de mise à la terre de l’immeuble, aussi près que possible du point d’entrée de câble.

Déclaration de conformité

Numéro de modèle: DVP620VR/07 Nom de commerce: Philips Partie responsable: Philips Consumer Electronics North America

P. O . Box

14810

Knoxville,TN, United States, 379

14-1810

(865) 52

1-4316

DVP620_07(FR)_1.qx4 04.4.7 0:01 PM Page 3

Page 84

4Table des matières

Informations générales

Informations générales et de sécurité . . . . . . . . . . .3

Table des matières . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Disques et vidéocassettes lisibles . . . . . . . . . . . . . . .6

Réglage initial du lecteur DVD/magnétoscope

Connexions . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7-15

Réglage de la télécommande . . . . . . . . . . . . . . . . . .16

Réglage initial du lecteur DVD/magnétoscope . . . .17

Lecture de base

Lecture d’une vidéocassette . . . . . . . . . . . . . . . . . .18

Lecture d’un disque . . . . . . . . . . . . . . . . . . . . . . . . .19

Commandes de base du lecteur DVD/magnétoscope

Panneau d’affichage (DVD) . . . . . . . . . . . . . . . . . . .20

Panneau d’affichage (Magnétoscope) . . . . . . . . . . . .21

Panneau avant . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Panneau arrière . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Télécommande . . . . . . . . . . . . . . . . . . . . . .24-25

Réglage additionnel du magnétoscope

Réglage des canaux . . . . . . . . . . . . . . . . . . . .26-27

Horloge (Magnétoscope) . . . . . . . . . . . . . . . .28-29

Langue (Magnétoscope) . . . . . . . . . . . . . . . . . . .30

Écrans d’état du magnétoscope . . . . . . . . . . . . .3

Options d’enregistrement de magnétoscope

Enregistrement de vidéocassettes . . . . . . . . . . . . . .32

Enregistrement d’un canal/Écoute d’un autre canal .33

Enregistrement immédiat . . . . . . . . . . . . . . . . . . . . .34

Réenregistrement (copie de cassette) . . . . . . . . . . .35

Enregistrement programmé . . . . . . . . . . . . . . . .36-38

Copie d’un disque DVD vers une vidéocassette . . .39

Options de lecture de vidéocassette

Lecture répétitive . . . . . . . . . . . . . . . . . . . . . . . . . .40

Compteur de défilement de cassette . . . . . . . . . . .41

Recherche chronologique, Recherche indexée . . . .42

Lecture d’effets spéciaux . . . . . . . . . . . . . . . . . . . . .43

Fonctions de commande automatique . . . . . . . . . .44

Fonctions additionnelles de magnétoscope

Son de télévision multi-audio . . . . . . . . . . . . . . .45-46

Stéréo haute fidélité . . . . . . . . . . . . . . . . . . . . . . . .47

Fonctions de lecture de disque

Menus de disque DVD . . . . . . . . . . . . . . . . . . . . . .48

Recherche rapide avant/arrière . . . . . . . . . . . . . . . .49

Lecture de titre/chapitre, Lecture à une heure

spécifique . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

Lecture d’une piste . . . . . . . . . . . . . . . . . . . . . . . . .51

Lecture en pause et en pas-à-pas, Reprendre . . . . .52

Répétition, répétition A-B . . . . . . . . . . . . . . . . . . . .53

Marqueurs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54

Sous-titres,Angles de caméra . . . . . . . . . . . . . . . . .55

Mot de passe de contrôle parental . . . . . . . . . . . . .56

Niveaux de contrôle parental . . . . . . . . . . . . . . . . .57

Langue audio, Mode de son stéréo . . . . . . . . . . . . .58

Ralenti, Zoom de lecteur DVD . . . . . . . . . . . . . . . .59

Lecture programmée . . . . . . . . . . . . . . . . . . . . . . . .60

Lecture aléatoire . . . . . . . . . . . . . . . . . . . . . . . . . . .61

Lecture MP3/JPEG . . . . . . . . . . . . . . . . . . . . . . . . . .62

Affichages MP3/JPEG . . . . . . . . . . . . . . . . . . . . . . . .63

Options de réglage du lecteur DVD

Affichage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .64-65

Langue . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66-67

Audio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .68

Écrans d’affichage . . . . . . . . . . . . . . . . . . . . . . . . . . .69

Niveau des noirs,Virtual Surround . . . . . . . . . . . . .70

Initialisation en cours (à l’exception de PARENT) . .71

Informations utiles

Glossaire . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72

Spécifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73

Astuces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74-77

Soins et nettoyage . . . . . . . . . . . . . . . . . . . . . . . . . .78

Garantie limitée . . . . . . . . . . . . . . . . . . . . . . . . . . . .79

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80

DVP620_07(FR)_1.qx4 04.4.7 0:01 PM Page 4

Page 85

Introduction 5

Fonctions du magnétoscope

• Nettoyeur de tête automatique

• Réglage des canaux

• Menus et affichages en anglais, français et espagnol

• Son de télévision multi-audio

• Tête 19 Microns

• Enregistrement : Immédiat et programmé

• Lecture répétitive

•Recherche : Chronologique, Indexée, Marche avant et Marche arrière

• Ralenti

• Image fixe

• Compteur de défilement de cassette

• Réglage d’alignement

Bienvenue !

Ce lecteur DVD/magnétoscope associe un lecteur de disque vidéo numérique (DVD) à un magnétoscope à cassettes vidéo haute fidélité (VCR), vous permettant de faire la lecture des DVD, disques compacts audio (CD audio) et vidéocassettes sur un seul dispositif. Il est recommandé de lire le présent manuel avec soin afin de savoir comment utiliser les fonctions décrites ci-dessous.

Contenu de l’emballage

Les articles suivants accompagnent votre nouveau lecteur DVD/magnétoscope.

• Télécommande et deux piles de type AA

• Un câble coaxial RF noir, 75 ohms

•Un jeu de câbles audio (à bouts rouge et blanc) et vidéo (à bouts jaunes)

• Le présent guide d’utilisation et un guide d’utilisation rapide

Menus de disque DVD...

Le présent guide contient certaines explications décrivant les menus de disque DVD. Le réglage de ces menus est effectué par le fabricant de DVD et peut varier d’un DVD à l’autre. Les DVD ne disposent pas tous de menus. Si le DVD dispose d’un menu, accédez au menu de disque DVD en appuyant sur DVD, puis sur DISC/VCR/MENU de la télécommande.

Des détails supplémentaires se trouvent à la page 48.

Menu de réglage du lecteur DVD...

Certaines instructions expliquent comment utiliser le menu de réglage du lecteur DVD pour effectuer la configuration des fonctions du lecteur DVD ou d’un DVD.Accédez au menu du lecteur DVD en appuyant sur SYSTEM/MENU de la télécommande lorsque la lecture est en arrêt. Même si une fonction est réglée au menu du lecteur DVD, il est possible que celle-ci ne soit pas disponible si le DVD utilisé n’offre pas cette fonction.

Fonctions de disque disponibles...

Les fonctions décrites dans le présent guide ne sont pas toutes disponibles sur chaque disque. Si la fonction n’est pas disponible sur le disque, il est impossible d’utiliser le DVD/magnétoscope pour la rendre accessible. Un « X » est affiché dans le coin supérieur droit de l’écran de télévision si vous essayez d’accéder à une fonction qui n’est pas disponible actuellement.

Fonctions du lecteur DVD

•

Choix de langues audio *

• Afficheur de débit binaire

•Angle de caméra*

• Son Dolby Digital *

• Copie d’un disque DVD vers une vidéocassette

•Commande de gamme dynamique

• Lecture rapide/en pause/lente/pas à pas

• Marqueurs

• Commandes parentales *

• Lecture de programme

•

Balayage progressif

• Lecture aléatoire

•Répétition, Répétition A-B

• Économiseur d’écran

•Recherche (Titre/Chapitre, Chronologique, Piste)

• Sous-titres*

• Virtual Surround

•Zoom

* Si disponible sur le DVD

DVP620_07(FR)_1.qx4 04.4.7 0:01 PM Page 5

Page 86

6 Disques et vidéocassettes lisibles

DVD CD audio CD-RW/CD-R CD vidéo DVD+RW

Codes de région

Le présent lecteur DVD/magnétoscope est doté d’un lecteur DVD de région Un (1).Tout DVD doit être étiqueté pour TOUTES les régions ou pour la région

1 afin de pouvoir être lu par le lecteur DVD . Il est impossible de faire la lecture de DVD portant l’étiquette d’autres régions. Repérez les symboles suivants sur votre DVD. Si ces symboles de région n’apparaissent pas sur le DVD, il est impossible de lire le DVD sur ce lecteur DVD.

Le nombre à l’intérieur du globe correspond à une région du monde. La région

1 représente les États-Unis, le Canada, les régions supérieures de l’Amérique du Nord, les Bermudes, les Îles Vierges américaines et certaines petites régions d’Australie. Un DVD portant l’étiquette d’un format de région spécifique peut être lu seulement par un lecteur DVD disposant du même code de région.

Systèmes de couleur

Les DVD sont enregistrés dans des systèmes de couleur différents à travers le monde. Les systèmes de couleur les plus courants sont NTSC (utilisés surtout aux États-Unis et en Amérique du Nord), PAL et SECAM.

Ce lecteur de DVD peut effectuer la lecture des DVD de format NTSC et PAL. La lecture de DVD enregistrés dans d'autres formats ne peut pas être effectuée. Le système couleur du DVD peut être listé dans le DVD ou sur le boîtier du DVD. Le téléviseur doit également être doté du système couleur NTSC et/ou PAL.

Vidéocassettes lisibles

Le magnétoscope de ce lecteur DVD/magnétoscope est doté d’un système Haute Qualité (HQ) et est compatible avec le matériel VHS actuel. N’utilisez que des vidéocassettes dotées de cette marque . L’utilisation de d’autres types de cassette peut résulter en une qualité réduite de l’image et une accumulation excessive de dépôts sur les têtes vidéo qui, en cas de dommages, ne seront pas couvertes par la garantie. Le magnétoscope dispose également d’une tête de

19 microns offrant une meilleure image lors de la lecture de cassettes enregistrées à vitesse lente (SLP).

Disques lisibles

Le lecteur DVD fait la lecture des disques vidéo numériques (DVD), des disques compacts audio (CD), des disques vidéo numériques réinscriptibles (DVD+RW); des disques compacts réinscriptibles (CD-RW); et Disques Compacts Vidéo (DCV) mis au point. Pour faire la lecture d’un DVD, assurez-vous qu’il répond aux exigences des codes de région et des systèmes de couleur tel que décrit ci-dessous. Les disques affichant les logos suivants peuvent être lus par le lecteur DVD. Il n’est pas garanti que les autres types de disque pourront être lus par le lecteur DVD/magnétoscope. Sur un Super CD Audio, seul le son enregistré sur la couche de CD normal peut êtré délivré. Le son enregistré sur la couche Super CD Audio haute densité ne peut pas être délivré.

DVP620_07(FR)_1.qx4 04.4.7 0:01 PM Page 6

Recordable

ReWritable

Page 87

Connexions 7

Comment effectuer la meilleure connexion possible...

La connexion de votre système repose principalement sur votre matériel actuel, surtout le téléviseur.En revanche, les directives suivantes décrivent les options offrant la meilleure qualité d’image (vidéo) et de son (audio) possible. Les prises sur votre lecteur DVD/magnétoscope ne sont pas toutes utilisées.

Si votre téléviseur ne dispose que d’une prise de style RF, normalement étiquetée Antenna In (Entrée d’antenne), RF In (Entrée RF) ou 75 ohms, utilisez la prise ANT-OUT (Sortie d’antenne) du lecteur DVD/magnétoscope pour raccorder le téléviseur.Cette connexion fournit l’audio et la vidéo via un seul câble. Syntonisez votre téléviseur au canal 3 ou 4 - le canal de sortie du lecteur DVD/magnétoscope. Cette connexion vous permet d’utiliser les fonctions du DVD et du magnétoscope.

Plus de détails en page huit.

★★★★ Si votre téléviseur est doté de jacks Component Video In (qui peuvent être étiquetés Y CR CB,Y PR PB,ou

bien YUV et peuvent être verts, bleus ou rouges), utilisez les jacks Component Video (Y C

B/PB CR/PR) pour la

qualité d’image la meilleure. Si vous n’utilisez que cette connexion vidéo, seule l’image DVD est disponible. Pour voir les caractéristiques DVD sur le téléviseur, réglez le téléviseur sur son canal Component Video In. Component Video offre la qualité d’image la meilleure.

Pour plus de détails, reportez-vous à la page 12.

Balayage progressif fournit une image moins scintillante et de résolution plus élevée que les signaux de télévision traditionnels (525i/480i ou entrelacés). Si votre téléviseur est doté de Balayage progressif (525p/480p ou progressif), connectez le téléviseur aux jacks Component Video Out du DVD/magnétoscope (Y C

B/PB CR/PR).

Réglez PROGRESSIF sur EF dans le menu d’affichage du DVD/magnétoscope.

Pour plus de détails, reportez-vous

aux pages 64-65.

P.SCAN apparaît sur le panneau d’affichage du DVD/magnétoscope. (Lorsque PROGRESSIF est sur EF, les images en provenance des jacks VIDEO OUT ou S-VIDEO OUT sont déformées.) Réglez également votre téléviseur sur Balayage progressif. Si votre téléviseur n’est pas doté de Balayage progressif mais est doté de jacks Component Video, connectezles aux jacks Component Video Out du DVD/magnétoscope (Y C

B/PB CR/PR). Réglez PROGRESSIF sur HF

dans le menu AFFICHAGE ou en appuyant sur et en maintenant la touche PLAY

B (DVD) à l’avant du

DVD/magnétoscope pendant plus de cinq secondes.

Pour plus de détails, reportez-vous aux pages 12 et 64-65.

★★★ Si votre téléviseur dispose d’une prise d’entrée S-Vidéo (étiquetée Y/C ou S-VHS), utilisez la prise S-VIDEO

OUT pour obtenir une excellente qualité d’image. Si vous utilisez cette connexion vidéo seulement, seule l’image DVD est disponible. Pour afficher les fonctions DVD à l’écran du téléviseur, réglez le téléviseur sur son canal d’entrée S-Vidéo.

Plus de détails en page 13.

★★ Si votre téléviseur n’a qu’un seul jack Video In jaune (qui peut également être étiqueté CVBS, Composite ou

baseband), utilisez le jack jaune VIDEO OUT du DVD/magnétoscope pour obtenir une bonne qualité d’image. Cette connexion fournit la vidéo pour le lecteur DVD et le magnétoscope. Pour afficher les fonctions du DVD ou du magnétoscope à l’écran du téléviseur, réglez le téléviseur sur son canal d’entrée vidéo.

Plus de détails en page 11.

★★★★ Si vous utilisez une chaîne stéréophonique dotée d’une prise d’entrée audio numérique coaxiale, celle-ci offre la

meilleure audio pour le lecteur DVD. Raccordez la prise COAXIAL DIGITAL AUDIO OUT du lecteur DVD/ magnétoscope sur votre chaîne stéréophonique pour la meilleure qualité audio. Si vous n’utilisez que cette connexion audio, seule l’audio du lecteur DVD sera disponible (pas celle du magnétoscope).

Plus de détails en page 15.

★★★ Si la connexion audio numérique n’est pas possible, connectez les prises AUDIO OUT rouge et blanc du

lecteur DVD/magnétoscope aux prises Audio In de votre chaîne stéréophonique ou téléviseur. Cette connexion fournit l’audio pour le lecteur DVD ainsi que le magnétoscope.

Plus de détails aux pages 11-14.

Avant de commencer...

● Consultez les guides de votre téléviseur, boîtier du service du câble, chaîne stéréophonique ou autres dispositifs au

besoin. Prenez note du style des prises et des connecteurs de l’autre dispositif. Déterminez comment choisir d’autres canaux d’entrée audio et vidéo sur l’autre dispositif de façon à vous permettre de voir et d’entendre le contenu du lecteur DVD/magnétoscope sur un téléviseur, chaîne stéréophonique, etc.

● Débranchez tout autre appareil des prises d’alimentation. Rebranchez le matériel seulement lorsque la connexion du

système est entièrement terminée. Ne jamais effectuer ou changer des connexions lorsque l’appareil est connecté à une prise d’alimentation.

Souvenez-vous...

● Syntonisez votre téléviseur au canal d’entrée vidéo approprié.Ces canaux portent également le nom de AUX ou

AUXILIARY IN,AUDIO/VIDEO ou A/V IN, EXT

1 ou External In, etc. Ces canaux sont souvent situés près du canal zéro (0). Consultez le guide d’utilisation de votre téléviseur pour de plus amples détails. Si les images du lecteur DVD ou du magnétoscope n’apparaissent pas à l’écran du téléviseur, passez au canal le plus bas (0

1 ou 02) et continuez à faire défiler les canaux de télévision vers le bas jusqu’à ce que l’image du lecteur DVD ou du magnétoscope apparaisse à l’écran du téléviseur. Ou, si votre téléviseur ne dispose que d’une seule prise d’entrée d’antenne et que vous utilisez le câble coaxial RF (tel que décrit à la page huit), réglez le téléviseur au canal 3 ou 4. Pour vous aider à trouver le canal d’entrée audio/vidéo approprié, mettez le lecteur DVD/magnétoscope sous tension.Appuyez sur DVD pour mettre le lecteur DVD/magnétoscope en mode DVD. Sans aucun disque dans le lecteur, un logo DVD Vidéo de grande taille est affiché à l’écran de télévision lorsque le téléviseur est syntonisé au canal d’entrée audio/vidéo approprié ou au canal 3 ou 4.

● Réglez la chaîne stéréophonique au canal ou mode « source » approprié.

● Selon votre connexion, vous devrez peut-être vous procurer des câbles ou adaptateurs supplémentaires. Si votre

téléviseur ou moniteur dispose de connecteurs de type BNC, vous devrez vous procurer un adaptateur.

● Si vous activez ou désactivez Balayage progressif lorsque l'alimentation est sous tension, le DVD/magnétoscope

s'éteint.

● Pour utiliser les fonctions de magnétoscope, vous devez inclure une connexion avec le câble vidéo

jaune et les câbles audio rouge/blanc fournis ou avec le câble coaxial RF fourni.

Une fois la meilleure option déterminée, repérez votre choix aux pages 8-

15. Effectuez la procédure spé-

cifique à la connexion choisie. Ensuite, passez à la page

17 afin de terminer la configuration initiale.

DVP620_07(FR)_1.qx4 04.4.7 0:01 PM Page 7

Page 88

8 Connexions (suite)

DIGITAL

AUDIO OUT

COAXIAL

AUDIO OUT

DVD

LRL

S-VIDEO

OUT

COMPONENT VIDEO OUT

AUDIO OUT

DVD/VCR

VCR

ANT - IN

ANT-OUT

VIDEO OUT

AUDIO IN

VIDEO IN

CR / P

ANT /

CABLE

ANT - IN

ANT-OUT

Câble coaxial

RF noir (fourni)

Signal d’antenne

ou du service du

câble

Débranchez le signal d’antenne ou du service du câble de votre téléviseur puis raccordez-le à la prise ANT-IN (Entrée d’antenne) de votre lecteur DVD/ magnétoscope.

Raccordez le câble coaxial RF noir fourni à la prise ANT-OUT (Sortie d’antenne) à l’arrière du lecteur DVD/magnétoscope et à la prise ANTENNA IN sur le téléviseur.

La prise ANTENNA IN du téléviseur peut porter le nom de TV IN, RF

IN, 75Ω (ohm) ou ANT-IN. Consultez le guide d’utilisation de votre téléviseur.

Branchez les cordons d’alimentation du téléviseur et du lecteur DVD/ magnétoscope.

Réglez votre téléviseur au canal 3 ou 4. Le canal de sortie du lecteur DVD/ magnétoscope est réglé à 3 à l’origine.Vous devez donc régler votre téléviseur au canal 3 lorsque le lecteur DVD/magnétoscope est neuf. Si vous ne pouvez pas utiliser le canal 3 sur votre téléviseur, vous pouvez changer le canal de sortie du lecteur DVD/magnétoscope au canal 4. Pour ce faire, appuyez sur VCR pour mettre le lecteur DVD/magnétoscope en mode VCR. Le voyant de magnétoscope se trouve sur le devant du lecteur DVD/magnétoscope. Insérez une vidéocassette et appuyez sur PLAY

B pour commencer la lecture. Lors de la

lecture, appuyez et maintenez enfoncé PLAY

B(Magnétoscope) sur le devant du

lecteur DVD/magnétoscope entre trois et cinq secondes.

Chaque fois que vous exé-

cutez cette opération, le canal de sortie du

DVD/magnétoscope commute entre 3 et 4 et le

numéro du canal sélectionné apparaît sur le panneau d'affichage. Syntonisez votre téléviseur au canal 3 ou 4, selon le cas. (Il est impossible de changer le canal de sortie du lecteur DVD/magnétoscope pendant que vous effectuez un réglage manuel de l’alignement.Appuyez sur STOP

C pour interrompre la lecture et annuler le réglage de l’alignement puis appuyez

sur PLAY

B pour reprendre la lecture et changer le canal de sortie.) Il n’y a pas de bouton de canal 3/4 sur le lecteur DVD/Magnétoscope (comme c’est le cas avec la majorité des magnétoscopes).

Vous êtes prêt à mettre votre lecteur DVD/magnétoscope sous tension. Passez à la page

17 avant d’allumer le lecteur DVD/magnétoscope.

Prise d’entrée d’an-

tenne

(à l’arrière du

téléviseur) exemple

seulement

Lecteur DVD/magnétoscope au téléviseur seulement

La connexion la plus simple ne nécessitant que le câble coaxial RF noir fourni

Cette connexion vous permet d’utiliser les fonctions du magnétoscope et

du lecteur DVD.

DVP620_07(FR)_1.qx4 04.4.7 0:01 PM Page 8

Page 89

Connexions (suite) 9

DIGITAL

AUDIO OUT

COAXIAL

AUDIO

OUT

DVD

LRL

S-VIDEO

OUT

COMPONENT VIDEO OUT

AUDIO OUT

DVD/VCR

VCR

ANT - IN

ANT-OUT

VIDEO OUT

AUDIO IN

VIDEO IN CR / P

OUT

ANT /

CABLE

Prise

ANTENNA IN

du téléviseur

Boîtier du service du

câble/Système RDS

Lecteur DVD/Magnétoscope

Connexions

Connectez un signal du service du câble/système RDS à la prise d’entrée IN du boîtier du service du câble/système RDS.

Utilisez un câble RF coaxial (comme celui fourni) pour raccorder la prise OUT (Sortie) du boîtier du service du câble/ système RDS à la prise ANT-IN sur le lecteur DVD/magnétoscope.

Utilisez un deuxième câble coaxial RF pour raccorder la prise ANT-OUT sur le lecteur DVD/magnétoscope à la prise Antenna In du téléviseur.

N’oubliez pas ...

Il y a deux façons de connecter votre boîtier du service du câble/système RDS

au lecteur DVD/magnétoscope.Avec la connexion de cette page :

● Sélectionnez les canaux de télévision depuis le boîtier du service du câble/

système RDS et non pas depuis le lecteur DVD/magnétoscope. Pour enregistrer ou regarder des canaux de télévision, effectuez la procédure suivante :

1) Appuyez sur VCR pour mettre le lecteur DVD/magnétoscope en mode VCR. Le voyant de magnétoscope apparaît sur le devant du lecteur DVD/ magnétoscope.

2) Appuyez sur

SKIP ∑/CH o ou SKIP w/CH p pour régler le lecteur

DVD/magnétoscope au canal de sortie du boîtier du service du câble/Système RDS (03 ou 04).

3) Réglez le téléviseur au canal de sortie du lecteur DVD/magnétoscope (03 ou

04). Le canal de sortie du lecteur DVD/magnétoscope est réglé au canal 3 lorsque le lecteur DVD/magnétoscope est neuf. Pour faire passer du canal 3 à 4, appuyez et maintenez enfoncé PLAY

B (magnétoscope) du lecteur DVD/magné-

toscope de 3-5 secondes lors de la lecture de la cassette.

Consultez l’étape 4 à la

page 8 pour de plus amples détails.

4) Sélectionnez le canal que vous voulez regarder/enregistrer à partir du boîtier du service du câble/système RDS.

●

Il est impossible de visionner un canal autre que celui que vous enregistrez.

●

Il n’est possible d’effectuer un enregistrement programmé que pour un canal à la fois. Syntonisez votre boîtier du service du câble/système RDS au canal que vous désirez enregistrer. Lorsque vous entrez le canal que vous voulez enregistrer dans un enregistrement programmé,sélectionnez le canal 03 ou 04 (le canal de sortie du boîtier du service du câble/système RDS). (Il s’agit de l’étape 8 à la page 37.) Laissez le boîtier du service du câble/système RDS sous tension lors d’un enregistrement programmé.

Signal du service du

câble

Câble RF coaxial

Lecteur DVD/magnétoscope à un boîtier du service du câble/système RDS

(diffusion directe par satellite) et téléviseur

avec des câbles coaxiaux RF seulement

Cette connexion vous permet d’ utiliser les fonctions du

magnétoscope et du lecteur DVD.

• Si votre boîtier du service du câble/système RDS est doté de prises de sortie audio et vidéo, utilisez des câbles audio et vidéo pour les raccorder aux prises VCR AUDIO IN et VIDEO IN à l’arrière du lecteur DVD/magnétoscope.Vous n’aurez pas besoin de la connexion de câble coaxial RF entre le boîtier du service du câble/système RDS et le lecteur DVD/magnétoscope tel que décrit à l’étape 2.

Astuce

DVP620_07(FR)_1.qx4 04.4.7 0:01 PM Page 9

Page 90

Connexions (suite)

ANT - IN

ANT-OUT

OUT

T /

ABLE

Prise d’entrée d’antenne du téléviseur

Boîtier du service du

câble/Système RDS

Lecteur DVD/Magnétoscope

Connexions

Connectez un signal du service du câble/système RDS à la prise ANT-IN du lecteur DVD/magnétoscope.

Utilisez un câble coaxial RF (comme celui fourni) pour raccorder la prise ANT-OUT du lecteur DVD/magnétoscope à la prise IN du boîtier du service du câble/système RDS.

Utilisez un deuxième câble coaxial RF pour raccorder la prise OUT du boîtier du service du câble/système RDS à la prise ANTENNA IN sur le téléviseur.

N’oubliez pas ...

Il y a deux façons de connecter votre boîtier du service du câble/système RDS au lecteur DVD/magnétoscope.Avec la connexion de cette page :

● Vous pouvez regarder un canal tout en en enregistrant un deuxième.

Effectuez la procédure suivante :

1) Sélectionnez le même canal pour le boîtier du service du câble/système RDS que le canal de sortie sur le lecteur DVD/magnétoscope (03 ou 04). Le canal de sortie du lecteur DVD/magnétoscope est syntonisé au canal 3 lorsque le lecteur DVD/magnétoscope est neuf. Pour basculer entre le canal 3 et 4, appuyez et maintenez enfoncé PLAY

B (Magnétoscope) sur le devant du lecteur DVD/magnétoscope pendant 3-5 secondes durant la lecture de la cassette.

Consultez l’étape 4 à la page huit pour de plus amples détails. Syntonisez le

téléviseur au canal de sortie du boîtier du service du câble/système RDS (03 ou 04).

2) Appuyez sur VCR pour mettre le lecteur DVD/magnétoscope au mode Magnétoscope. Le voyant du magnétoscope apparaît sur le devant du lecteur DVD/magnétoscope.

3) Appuyez sur VCR/TV de la télécommande pour sélectionner la position VCR.

4) Appuyez sur

SKIP ∑/CH o ou SKIP w/CH p pour sélectionner le canal

que vous voulez enregistrer sur le lecteur DVD/magnétoscope.Appuyez sur RECORD

I pour faire démarrer l’enregistrement.

5) Appuyez une fois sur VCR/TV de la télécommande pour mettre le lecteur DVD/magnétoscope en position de Télévision.

6) Sélectionnez le canal que vous voulez regarder à partir du boîtier du service du câble/système RDS.

● Lorsque vous faites jouer une cassette ou un disque, assurez-vous que le

boîtier du service du câble/système RDS est réglé au même canal de sortie (03 ou 04) du lecteur DVD/magnétoscope. Syntonisez le téléviseur au canal de sortie du boîtier du service du câble/ système RDS (03 ou 04).

Signal du

service du

câble

Câble coaxial RF

Lecteur DVD/Magnétoscope au boîtier du service

du câbleSystème RDS et au téléviseur

avec des câbles coaxiaux RF seulement

Cette connexion vous permet

d’utiliser les fonctions du magnétoscope et du lecteur DVD.

DVP620_07(FR)_1.qx4 04.4.7 0:01 PM Page 10

Page 91

Connexions (suite)

DIGITAL

AUDIO OUT

COAXIAL

AUDIO

OUT

DVD

LRL

S-VIDEO

OUT

COMPONENT

VIDEO OUT

AUDIO OUT

DVD/VCR

VCR

ANT - IN

ANT-OUT

VIDEO OUT

AUDIO IN

VIDEO IN

CR / P

AUDIO IN

VIDEO IN

Signal d’antenne ou du service du

câble à la prise ANT-IN

Câble vidéo

Câbles audio

Prises d’entrée audio et vidéo sur le

téléviseur

Connectez le signal d’antenne ou du service du câble à la prise ANT-IN de votre lecteur DVD/magnétoscope.

Connectez les câbles audio rouge et blanc (fournis) aux prises rouge et blanche DVD/VCR AUDIO OUT du lecteur DVD/magnétoscope et aux prises rouge et blanche AUDIO IN sur le téléviseur.

Faîtes correspondre la couleur des câbles aux couleurs des prises. Si le téléviseur dispose d’une seule prise AUDIO IN, utilisez le câble audio blanc pour connecter la prise blanche DVD/VCR AUDIO OUT du lecteur DVD/ magnétoscope à la prise AUDIO IN du téléviseur. Le câble rouge n’est pas utilisé.Vous pouvez également vous procurer un câble audio répartiteur pour raccorder les prises gauche/droite AUDIO OUT du lecteur DVD/magnétoscope à la prise unique AUDIO IN du téléviseur.

Connectez le câble vidéo jaune (fourni) à la prise DVD/VCR VIDEO OUT du lecteur DVD/magnétoscope et à la prise VIDEO IN du téléviseur.

La prise VIDEO IN du téléviseur est généralement jaune et peut être étiquetée CVBS, Composite ou Bande de base.

Branchez les cordons d’alimentation du téléviseur et du lecteur DVD/ magnétoscope dans une prise d’alimentation.Allumez le téléviseur et réglez-le au canal Audio/Video In approprié.

Passez au canal de télévision le plus bas (01 ou 02), puis changez les canaux vers le bas jusqu’à ce que la lecture en provenance du magnétoscope ou du lecteur DVD soit affichée à l’écran du téléviseur. Pour vous aider à trouver le canal d’entrée audio/vidéo approprié, mettez le lecteur DVD/magnétoscope sous tension.Appuyez sur DVD pour mettre le lecteur DVD/ magnétoscope en mode DVD. Sans aucun disque dans le lecteur, un logo DVD vidéo de grande taille est affiché à l’écran de télévision lorsque le téléviseur est syntonisé au canal d’entrée audio/vidéo approprié. Assurez-vous que PROGRESSIF est réglé sur HF et que P.SCAN n’apparaît pas sur le panneau d’affichage du

DVD/magnétoscope.Désactivez Balayage progressif dans le menu

AFFICHAGE ou en appuyant sur et en maintenant PLAY

B (DVD) à l’avant du DVD/magné-

toscope

pendant plus de cinq secondes. Pour plus de détails, reportez-vous aux pages sept et 64-

65.

Vous êtes prêt à mettre lecteur DVD/magnétoscope sous tension. Passez à la page

17 pour terminer la configuration initiale.

Lecteur DVD/Magnétoscope à un téléviseur

doté de prises d’entrée audio et vidéo

à l’aide des câbles rouge, blanc et jaune fournis

Cette connexion vous permet d’utiliser les fonctions du

magnétoscope et du lecteur DVD.

DVP620_07(FR)_1.qx4 04.4.7 0:01 PM Page 11

Page 92

Connexions (suite)

Lecteur DVD/Magnétoscope à un téléviseur

doté de prises d’entrée vidéo composant

AUDIO IN

Cb/Pb

Cr/Pr

COMPONENT

VIDEO IN

DIGITAL

AUDIO OUT

COAXIAL

AUDIO

OUT

DVD

LRL

S-VIDEO

OUT

COMPONENT VIDEO OUT

AUDIO OUT

DVD/VCR

VCR

ANT - IN

ANT-OUT

VIDEO OUT

AUDIO IN

VIDEO IN CR / P

Connectez le signal d’antenne ou du service du câble à la prise ANT-IN de votre lecteur DVD/magnétoscope.

Connectez les câbles audio rouge et blanc fournis aux prises rouge et blanche DVD/VCR AUDIO OUT du lecteur DVD/magnétoscope et aux prises rouge et blanche AUDIO IN sur le téléviseur.

Faîtes correspondre les couleurs des câbles aux

couleurs des prises.

Connectez le câble vidéo composant (non fourni) aux prises COMPONENT VIDEO OUT du lecteur DVD/magnétoscope et aux prises COMPONENT VIDEO IN du téléviseur.

Les prises d’entrée vidéo composant du téléviseur sont généralement rouge, bleu et verte. La connexion vidéo composant ne fournit que la vidéo (image) pour le lecteur DVD du lecteur DVD/magnétoscope.Afin de pouvoir utiliser les fonctions du magnétoscope ou de regarder des canaux de télévision à partir du lecteur DVD/magnétoscope, il faudra connecter le câble coaxial RF entre la prise ANT-OUT du lecteur DVD/magnétoscope et la prise Antenna In du téléviseur, ou connecter le câble vidéo jaune. Pour la connexion du câble coaxial RF fourni, lire l’étape 2 à la page huit. Pour la connexion du câble vidéo jaune (fourni), voir l’étape 3 à la page

11. Si votre téléviseur est compatible avec Balayage progressif (525p/480p), activez Balayage progressif sur le

DVD/magnétoscope. Réglez PROGRESSIF sur EF dans le menu d’affichage de façon à ce que

P.SCAN apparaisse sur le panneau d’affichage.

Pour plus de détails, reportez-vous aux pages 64-65.

Si votre téléviseur n’est pas compatible avec Balayage progressif, assurez-vous que PROGRESSIF est réglé sur HF et que P.SCAN n’apparaît pas sur le panneau d’affichage du

DVD/magnétoscope.

Désactivez Balayage progressif dans le menu AFFICHAGE ou en appuyant sur et en maintenant PLAY

B (DVD) à l’avant du DVD/magnétoscope pendant plus de cinq secondes. Pour plus de détails,

reportez-vous aux pages sept et 64-65.

Branchez les cordons d’alimentation du lecteur DVD/magnétoscope et du téléviseur dans une prise d’alimentation.Allumez le téléviseur et réglez-le au canal Component Video In pour les fonctionnalités du lecteur DVD .

Si vous utilisez le câble coaxial RF pour la lecture du magnétoscope, choisissez le canal 3 ou 4 à partir du téléviseur. Si vous utilisez le câble vidéo jaune pour la lecture du magnétoscope, choisissez le canal Video In à partir du téléviseur. Passez au canal de télévision le plus bas puis changez les canaux vers le bas jusqu’à ce que la lecture en provenance du magnétoscope ou du lecteur DVD soit affichée à l’écran du téléviseur ou essayez le canal 3 ou 4 à partir du téléviseur. Pour vous aider à trouver le canal d’entrée audio/vidéo approprié,mettez le lecteur DVD/magnétoscope sous tension.Appuyez sur DVD pour mettre le lecteur DVD/ magnétoscope en mode DVD. Sans aucun disque dans le lecteur, un logo DVD vidéo de grande taille est affiché à l’écran de télévision lorsque le téléviseur est syntonisé au canal d’entrée vidéo composant approprié.

Vous êtes prêt à allumer votre lecteur DVD/magnétoscope.Passez à la page 17 avant d’allumer le lecteur DVD/magnétoscope.

Signal d’antenne/du

service du câble

DVP620_07(FR)_1.qx4 04.4.7 0:01 PM Page 12

Page 93

Connexions (suite)

Lecteur DVD/Magnétoscope à un téléviseur doté d’une prise d’entrée S-Vidéo

DIGITAL

AUDIO OUT

COAXIAL

AUDIO

OUT

DVD

LRL

S-VIDEO

OUT

COMPONENT VIDEO OUT

AUDIO OUT

DVD/VCR

VCR

ANT - IN

ANT-OUT

VIDEO OUT

AUDIO IN

VIDEO IN

CR / P

AUDIO IN

LEFT

RIGHT

S-VIDEO IN

Raccordez le signal d’antenne ou du service du câble à la prise ANT-IN de votre lecteur DVD/magnétoscope.

Connectez les câbles audio rouge et blanc fournis aux prises rouge et blanche AUDIO OUT du lecteur DVD/magnétoscope et aux prises rouge et blanche AUDIO IN sur le téléviseur.

Faîtes correspondre les couleurs des câbles aux couleurs

des prises.

Raccordez un câble S-Vidéo (non fourni) à la prise S-VIDEO OUT du lecteur DVD/magnétoscope et à la prise S-VIDEO IN sur le téléviseur.

La connexion S-Vidéo ne fournit que la vidéo (l’image) du lecteur DVD du lecteur DVD/magnétoscope.Afin de pouvoir utiliser les fonctions du magnétoscope ou de regarder des canaux de télévision à partir du lecteur DVD/magnétoscope, il faudra connecter le câble coaxial RF entre la prise ANT-OUT du lecteur DVD/magnétoscope et la prise Antenna In du téléviseur, ou connecter le câble vidéo jaune. Pour la connexion du câble coaxial RF fourni, lire l’étape 2 à la page huit. Pour raccorder le câble vidéo jaune fourni, voir l’étape 3 à la page

11.

Branchez les cordons d’alimentation du téléviseur et du lecteur DVD/magnétoscope dans une prise d’alimentation.Allumez le téléviseur et réglez-le au canal d’entrée S-Vidéo pour les fonctions du lecteur DVD.

Si vous utilisez le câble coaxial RF pour la lecture du magnétoscope, choisissez le canal 3 ou 4 à partir du téléviseur. Si vous utilisez le câble vidéo jaune pour la lecture du magnétoscope, choisissez le canal Video In à partir de votre téléviseur. Pour trouver le canal d’entrée vidéo approprié, passez au canal de télévision le plus bas puis changez les canaux vers le bas jusqu’à ce que la lecture en provenance du magnétoscope soit affichée à l’écran. Pour vous aider à trouver le canal d’entrée S-Vidéo approprié, mettez le lecteur DVD/ magnétoscope sous tension.Appuyez sur DVD pour mettre le lecteur DVD/magnétoscope en mode DVD. Sans aucun disque dans le lecteur, un logo DVD vidéo de grande taille est affiché à l’écran de télévision lorsque le téléviseur est réglé au canal d’entrée S-Vidéo. Assurez-vous que PROGRESSIF est sur HF et que P.SCAN n’apparaît pas sur le panneau d’affichage du

DVD/magnétoscope. Désactivez Balayage progressif dans le menu AFFICHAGE

ou en appuyant sur et en maintenant PLAY

B (DVD) à l’avant du DVD/magnétoscope pen- dant plus de cinq secondes de manière à ce que P.SCAN n’apparaisse pas sur le panneau d’affichage.

Pour plus de détails, reportez-vous aux pages 64-65.

Vous êtes prêt à allumer votre lecteur DVD/magnétoscope. Passez à la page 17 avant de mettre votre lecteur DVD/magnétoscope sous tension.

Signal d’antenne ou du service du câble

DVP620_07(FR)_1.qx4 04.4.7 0:01 PM Page 13

Page 94

14 Connexions (suite)

Lecteur DVD/Magnétoscope à une chaîne stéréophonique et à un téléviseur

DIGITAL

AUDIO OUT

COAXIAL

AUDIO

OUT

DVD

LRL

S-VIDEO

OUT

COMPONENT VIDEO OUT

AUDIO OUT

DVD/VCR

VCR

ANT - IN

ANT-OUT

VIDEO OUT

AUDIO IN

VIDEO IN CR / P

VIDEO IN

AUDIO (LEFT) IN

AUDIO (RIGHT) IN

Connectez le signal d’antenne ou du service du câble à la prise ANT-IN de votre lecteur DVD/magnétoscope.

Connectez les câbles audio rouge et blanc fournis aux prises rouge et blanche DVD/VCR AUDIO OUT du lecteur DVD/magnétoscope et aux prises rouge et blanche AUDIO IN sur la chaîne stéréophonique.

Faîtes correspondre les couleurs

des câbles aux couleurs des prises.

Connectez le câble vidéo jaune (fourni) à la prise DVD/VCR VIDEO OUT sur le lecteur DVD/magnétoscope et à la prise VIDEO IN sur le téléviseur.

Pour utiliser plutôt le câble vidéo composant ou le câble S-Vidéo pour le lecteur DVD, voir les pages

12-13.Vous devrez quand même utiliser le câble vidéo jaune ou le câble coaxial RF

pour les fonctions du magnétoscope.

Branchez les cordons d’alimentation du lecteur DVD/magnétoscope, du téléviseur et de la chaîne stéréophonique dans une prise de courant.Allumez le téléviseur et réglez-le au canal Video In.

Ou, passez au canal de télévision le plus bas (02 ou 03) puis continuez à changer les canaux vers le bas jusqu’à ce que la lecture en provenance du magnétoscope ou du lecteur DVD soit affichée à l’écran du téléviseur. Pour vous aider à trouver le canal d’entrée vidéo approprié au téléviseur, mettez le lecteur DVD/magnétoscope sous tension.Appuyez sur DVD pour mettre le lecteur DVD/ magnétoscope en mode DVD. Sans aucun disque dans le lecteur, un logo DVD vidéo de grande taille est affiché à l’écran de télévision lorsque le téléviseur est syntonisé au canal d’entrée vidéo approprié. Mettez l’appareil stéréo sous tension et réglez-le sur l’auxiliaire ou le mode de source correct. Pour plus de détails, consultez le manuel de votre appareil stéréo.

Vous êtes prêt allumer votre lecteur DVD/magnétoscope. Passez à la page 17 avant d’allumer le lecteur DVD/magnétoscope.

Signal d’antenne ou du service du câble

DVP620_07(FR)_1.qx4 04.4.7 0:01 PM Page 14

Page 95

Connexions (suite) 15

Lecteur DVD/Magnétoscope à un téléviseur et chaîne stéréophonique compat-

ible Dolby Digital à l’aide des connexions audio numériques

DIGITAL

AUDIO OUT

COAXIAL

AUDIO

OUT

DVD

LRL

S-VIDEO

OUT

COMPONENT VIDEO OUT

AUDIO OUT

DVD/VCR

VCR

ANT - IN

ANT-OUT

VIDEO OUT

AUDIO IN

VIDEO IN CR / P

VIDEO IN

COAXIAL DIGITAL AUDIO IN

Connectez le signal d’antenne ou du service du câble à la prise ANT-IN de votre lecteur DVD/magnétoscope.

Connectez un câble audio numérique coaxial (non fourni) à la prise COAXIAL DIGITAL AUDIO OUT du lecteur DVD/magnétoscope et à la prise COAXIAL DIGITAL AUDIO IN sur la chaîne stéréophonique.

Cette connexion audio numérique ne fournit le son que pour le lecteur DVD du lecteur DVD/ magnétoscope. Donc, afin d’utiliser les caractéristiques du VCR ou de pouvoir écouter des chaînes de télévision sur le DVD/magnétoscope, il vous faut soit connecter le câble coaxial RF entre le jack ANT-OUT du DVD/magnétoscope et le jack Antenna In du téléviseur, ou bien connecter les câbles audio rouge/blanc fournis. Pour la connexion du câble coaxial RF fourni, lire l’étape 2 à la page huit. Pour la connexion du câble audio rouge/blanc, voir l’étape 2 à la page 11.

Connectez le câble vidéo jaune (fourni) à la prise DVD/VCR VIDEO OUT jaune sur le lecteur DVD/magnétoscope et à la prise VIDEO IN sur le téléviseur.

Pour utiliser plutôt le câble vidéo composant ou le câble S-Vidéo pour le lecteur DVD, voir les pages 12-13. Vous devrez quand même utiliser le câble vidéo jaune ou le câble coaxial RF pour les fonctions du magnétoscope.

Branchez les cordons d’alimentation de la chaîne stéréophonique, du téléviseur et du lecteur DVD/magnétoscope.Allumez la chaîne stéréophonique et sélectionnez son canal Auxiliary IN.Allumez le téléviseur et réglez-le au canal Video In approprié. Passez

au canal de télévision le plus bas (01 ou 02) puis changez les canaux vers le bas jusqu’à ce que la lecture en provenance du magnétoscope ou du lecteur DVD soit affichée à l’écran du téléviseur. Pour vous aider à trouver le canal d’entrée vidéo approprié sur le téléviseur, mettez le lecteur DVD/magnétoscope sous tension.Appuyez sur DVD pour mettre le lecteur DVD/magnétoscope en mode DVD. Sans aucun disque dans le lecteur, un logo DVD vidéo de grande taille est affiché à l’écran de télévision lorsque le téléviseur est syntonisé au canal d’entrée vidéo composant approprié. Assurez-vous que PROGRESSIF est sur HF et que P.SCAN n’apparaît pas sur le panneau d’affichage du DVD/magnétoscope. Désactivez Balayage progressif dans le menu AFFICHAGE ou en appuyant sur et en maintenant PLAY B (DVD) à l’avant du DVD/magnétoscope pen- dant plus de cinq secondes de manière à ce que P.SCAN n’apparaisse pas sur le panneau d’affichage. Pour plus de détails, reportez-vous aux pages 64-65.

Vous êtes prêt à allumer votre lecteur DVD/magnétoscope. Passez à la page 17 avant d’allumer le lecteur DVD/magnétoscope.

N’oubliez pas ...

Certains DVD sont enregistrés sous le Dolby Digital canal 5.1 Surround. Sélectionnez le Dolby Digital canal 5.

1 Surround Sound à partir du menu de disque DVD.Si Dolby Digital Surround n’est pas enregistré sur le disque, le son d’ambiance n’est pas disponible. Si vous connectez le lecteur DVD/magnétoscope à une chaîne stéréophonique Dolby Digital, réglez DOLBY DIGITAL à EN FONCTION à partir du menu de configuration du lecteur DVD. Plus de détails en page 68. Si le lecteur DVD/magnétoscope n’est pas raccordé à une chaîne stéréophonique compatible Dolby Digital, réglez DOLBY DOLBY DIGITAL à HORS FONCTION. Si les paramètres ne sont pas réglés correctement, vous risquez d’endommager les haut-parleurs ou de déformer l’audio.

Arrière du téléviseur (exemple seulement)

Chaîne stéréophonique

Signal d’antenne ou du service du câble

DVP620_07(FR)_1.qx4 04.4.7 0:01 PM Page 15

Page 96

16 Réglage de la télécommande

Placement des piles dans la télécommande

Enlevez le couvercle du logement des piles dans le bas de

la télécommande en appuyant sur la languette puis en

soulevant le couvercle.

Placez deux piles AA à l’intérieur du logement des

piles

en faisant correspondre les bornes +et –tel qu’indiqué.

Remettez le couvercle du logement des piles en place.

Utilisation de la télécommande

● Dirigez la télécommande vers le capteur infrarouge du lecteur

DVD/magnétoscope (voir la page 22) lors de l’utilisation de la télécommande pour faire fonctionner le lecteur DVD/magnétoscope. Ne pas diriger la télécommande vers le téléviseur.

● Ne pas placer d’objets entre la télécommande et le lecteur

DVD/magnétoscope.

Directives de recyclage/Sécurité des piles

● Votre nouveau dispositif ainsi que son emballage contiennent des

matériaux qui peuvent être recyclés et réutilisés. Des entreprises spécialisées peuvent recycler votre produit en vue de concentrer les matériaux réutilisables et de minimiser la quantité de matériel à mettre au rebut. Les piles utilisées dans votre produit ne doivent pas être simplement jetées lorsqu’elles sont épuisées mais mises au rebut comme déchets chimiques dans un centre de recyclage. Veuillez vous renseigner sur les règlements locaux concernant la mise au rebut de votre produit, de ses piles et de son emballage lorsque vous remplacez votre ancien matériel.

● MISE EN GARDE concernant les piles - Pour prévenir la fuite des

piles pouvant entraîner des blessures ou endommager la

télécommande : Installez TOUTES les piles de façon à ce qu’elles correspondent aux bornes + et –, tel qu’indiqué sur le dispositif. Évitez de mélanger les piles (usagées et neuves ou carbone et alcaline, etc.). Retirez les piles du boîtier lorsque la télécommande n’est pas utilisée pour une période de temps prolongée.

DVP620_07(FR)_1.qx4 04.4.7 0:01 PM Page 16

Page 97

Réglage initial du lecteur DVD/magnétoscope 17

Appuyez sur o ou p pour sélectionner English, Français ou Español

pour la langue utilisée dans les menus

et affichages du magnétoscope.

Appuyez ensuite sur B.

Appuyez sur B pour commencer la programmation des canaux.

RÉGLAGE AUTO clignote à l’écran du téléviseur lors de la recherche des canaux. Le lecteur DVD/magnétoscope mémorise tous les canaux disponibles. Lorsque la programmation des canaux est terminée, le canal le plus bas disponible est affiché à l’écran du téléviseur. Ces canaux seront disponibles lorsque vous voulez regarder la télévision en mode VCR. Pour mettre le lecteur DVD/magnétoscope en mode VCR, appuyez sur VCR pour allumer le voyant de magnétoscope. Utilisez les boutons

SKIP ∑/CH o

ou SKIP w/CH p pour sélectionner les canaux mémorisés.

Pour sélectionner les canaux non mémorisés, utilisez les touches numérotées.

•Pour sauter cette fonction et faire jouer une cassette immédiatement, insérez une cassette après avoir enlevé sa languette de protection.

•Pour sauter l’étape 3, appuyez sur DISC/VCR/MENU. Les menus et affichages du magnétoscope seront affichés en anglais.

•Si vous essayez de programmer des canaux lorsque aucun signal d’antenne ou du service du câble n’est connecté à la prise ANT-IN du lecteur DVD/magnétoscope, la programmation est interrompue. RÉGLAGE AUTO ne clignote plus. Raccordez le signal d’antenne ou de service du câble à la prise ANT-IN du lecteur DVD/magnétoscope et appuyez sur

nouveau.

• Effectuez la procédure de nouveau si le courant est coupé.

•Pour interrompre le réglage des canaux lorsque RÉGLAGE AUTO clignote, appuyez sur DISC/VCR/MENU.

Astuces

Avant d’allumer votre lecteur DVD/magnétoscope, assurez-vous que les piles sont dans la télécommande et que le lecteur DVD/magnétoscope et le téléviseur sont raccordés correctement. Il est impossible de programmer des canaux si vous utilisez un boîtier du service de câble ou un système de radiodiffusion directe par satellite (RDS).

Il est possible que ces menus ne soient pas affichés si vous avez déjà mis le lecteur DVD/magnétoscope sous tension.

Allumez le téléviseur. Réglez-le au canal 3 ou 4 ou à son canal AUDIO/VIDEO IN,

selon la connexion effectuée pour

le lecteur DVD/magnétoscope et le téléviseur.

Appuyez sur VCR, puis appuyez sur STANDBY-ON

(Alimentation). Le voyant du magnétoscope s’allume sur le

devant du lecteur DVD/magnétoscope. L’écran ci-dessous est affiché. Il est possible que ces menus ne soient pas affichés si vous avez déjà mis le lecteur DVD/magnétoscope sous tension.Vous avez peut-être allumé le lecteur DVD/magnétoscope afin de trouver le canal d’entrée audio/vidéo du téléviseur, par exemple. Si c’est le cas, effectuez la procédure à la page 26 pour effectuer le réglage des canaux et à la page 30 pour sélectionner la langue des menus du magnétoscope.

Allumez le téléviseur.

REGLAGE AUTO

APPUYER SUR

3-4

LANGUAGE SELECT

BENGLISH [ON]

FRANCAIS ESPAÑOL

APPUYER SUR

DVP620_07(FR)_1.qx4 04.4.7 0:01 PM Page 17

SEARCH MODE

REPEAT REPEAT

SUBTITLE ZOOM

RETURN TITLE

VCR VCR/TV

DISC/VCR

MENU MENU

SPEED

STANDBY-ON

DISPLAY

AUDIO

A-B

ANGLE

CLEAR/RESET SLOW

SYSTEM

PLAY

MARKER RECORDTIMER SET

1 2 3

SKIP / CH

DVD

PAUSESTOP

+10

Page 98

18 Lecture d’une vidéocassette

•Des options et fonctions supplémentaires de lecture de cassette se trouvent aux pages 40-47.

• Si RÉPÉTITION AUTOMATIQUE est en marche, la lecture commence automatiquement suivant l’insertion de la cassette, même si la languette de protection est intacte. Plus de détails en page 40.

•Vous devez raccorder le lecteur DVD/ magnétoscope au téléviseur avec le câble coaxial RF ou les câbles audio/ vidéo afin de pouvoir utiliser les fonctions du magnétoscope. Ces connexions sont expliquées aux pages huit et

11.

Astuces

Pour faire la lecture d’une cassette, effectuez la procédure suivante.

Allumez le téléviseur. Réglez-le au canal 3 ou 4 ou à son canal AUDIO/VIDEO IN.

Ceci dépend de la connexion

effectuée entre le lecteur DVD/magnétoscope et le téléviseur.

Plus de détails aux pages 7-15.

Avec le lecteur DVD/magnétoscope hors tension, insérez une cassette dans le logement de cassette du lecteur DVD/magnétoscope.

Le voyant du magnétoscope est allumé à l’avant du lecteur DVD/magnétoscope. Si la languette de protection de la cassette a été enlevée, la lecture commence automatiquement. Si le voyant d’alimentation

DVD/magnétoscope est déjà allumé, appuyez sur VCR pour

mettre le lecteur DVD/magnétoscope au mode Magnétoscope, au besoin. Le voyant du magnétoscope s’allume sur le devant du lecteur DVD/magnétoscope.

Si la lecture ne commence pas automatiquement, appuyez sur VCR puis sur PLAY

Appuyez sur STOP C pour interrompre la lecture.

Appuyez sur h pour rembobiner la cassette.

Lorsque la cassette s’arrête, appuyez sur STOP/EJECT (Arrêt/Éjection)

CA sur le devant du lecteur DVD/

magnétoscope pour enlever la cassette.

1 2

Appuyez sur STOP/EJECT

CA sur le lecteur

DVD/magnétoscope.

Allumez le téléviseur.

Insérez une cassette dans le lecteur DVD/magnétoscope.

DVP620_07(FR)_1.qx4 04.4.7 0:01 PM Page 18

SEARCH MODE

REPEAT REPEAT

SUBTITLE ZOOM

RETURN TITLE

DISC/VCR

MENU MENU

SPEED

STANDBY-ON

DISPLAY

AUDIO

A-B

ANGLE

CLEAR/RESET SLOW

SYSTEM

PLAY

PAUSESTOP

MARKER RECORDTIMER SET

1 2 3

SKIP / CH

DVDVCR VCR/TV

+10

Page 99

Lecture de disque 19

• Un « X » apparaît quelquefois dans le

coin supérieur droit de l’écran de télévision lorsque vous essayez une fonction. Cette fonction n’est probablement pas disponible sur le disque ou le lecteur DVD/magnétoscope est dans l’impossibilité d’accéder à la fonction. Ceci n’est pas indicateur d’un problème avec le lecteur DVD/magnétoscope.

• Si un disque est sale ou rayé,les images pourront se déformer ou la lecture pourra être interrompue. Enlevez le disque et mettez le lecteur DVD/magnétoscope hors tension. Débranchez le cordon d’alimentation puis branchez-le de nouveau. Nettoyez le disque, remettez le lecteur DVD/magnétoscope sous tension et insérez le disque de nouveau.

•Lorsque le voyant DVD ou CD s’allume sur le tableau d’affichage, le disque est chargé et prêt à la lecture.

•Lorsque vous appuyez sur OPEN/CLOSE

ou PLAY (DVD) sur le devant du lecteur DVD/magnétoscope lorsque l’alimentation est hors tension, le lecteur DVD/magnétoscope s’allume automatiquement en mode DVD. Sinon, le lecteur DVD/magnétoscope s’allume sous le mode dans lequel il était au moment il a été mis hors tension.

Astuces

Avant de commencer, allumez le téléviseur, la chaîne stéréophonique et tout autre appareil raccordé au lecteur DVD/magnétoscope. Assurez-vous que le téléviseur et la chaîne stéréophonique (s’il y en a une) sont réglés au canal approprié.

Plus de détails aux pages 7-15.

Appuyez sur STANDBY-ON yypour allumer le lecteur DVD/magnétoscope.

Appuyez sur DVD pour allumer le voyant du lecteur DVD sur le devant du lecteur DVD/magnétoscope.

Appuyez sur OPEN/CLOSE A (à la gauche du plateau à disque à l’avant du

DVD/magnétoscope) pour ouvrir le

plateau à disque.

Placez un disque dans le tiroir. Si le DVD est enregistré sur un côté seulement, placez le disque dans le tiroir avec l’étiquette vers le haut et le côté luisant vers le bas. Certains DVD sont enregistrés sur les deux côtés.Assurez-vous que le côté que vous voulez faire jouer est face en dessus.

Appuyez sur PLAY B. Le tiroir se ferme automatiquement et la lecture commence au premier chapitre ou piste du disque. Si un menu DVD est affiché à la place,

consultez la page

48.

Avec certains CD audio, la lecture ne commence pas à

moins que vous n’appuyiez sur PLAY

B.Vous pouvez égale-

ment appuyer sur OPEN/CLOSE

A ou pousser sur le tiroir en direction du lecteur DVD/magnétoscope pour fermer le tiroir. Avec les fichiers MP3 et JPEG, la lecture commence

au début du disque.

Appuyez sur STOP C pour interrompre la lecture.

Insérez un disque.

N’oubliez pas que ce lecteur

DVD/magnétoscope

permet de faire la lecture de certains

disques seulement.

Voir la page six pour plus de détails.

Appuyez sur OPEN/CLOSE

A sur le lecteur DVD/ magnétoscope.

DVP620_07(FR)_1.qx4 04.4.7 0:01 PM Page 19

STANDBY-ON

SEARCH MODE

REPEAT REPEAT

SUBTITLE ZOOM

DISPLAY

AUDIO

A-B

ANGLE

SKIP / CH

RETURN TITLE

DISC/VCR

CLEAR/RESET SLOW

DVDVCR VCR/TV

MENU MENU

SYSTEM

PLAY

PAUSESTOP

MARKER RECORDTIMER SET

Page 100

20 Panneau d’affichage (DVD)

Affichage

Les messages concernant les opérations du disque en cours apparaissent ici. Vo ir les messages d’affichage ci-dessous.

Voy ant DVD

Ce voyant s’allume lorsque le lecteur DVD/ magnétoscope est en mode DVD. Il n’est possible de visionner des DVD que lorsque ce voyant est allumé. Pour allumer le voyant DVD, appuyez sur SOURCE sur le devant du lecteur DVD/magnétoscope ou sur DVD de la télécommande.

Messages d’affichage

STANDBY-ON

SOURCE

POWER ON

VIDEO AUDIO REW F.FWD PLAY

RECORD CHANNEL

VCR

OPEN/CLOSE

DVD

STOP PLAY

ONE TOUCH RECORDING • LONG PLAY

STOP/EJECT

GROUP P.SCAN

DVD

VCD

Tiroir du disque

Insérez un disque ici.

Affiché après la fermeture du tiroir du disque si le tiroir était vide, en présence d'une erreur de lecture ou si un disque non conforme est utilisé.

Le tiroir est en cours d'ouverture ou est ouvert.

Le tiroir est en cours de fermeture.

Le disque est en cours de chargement.

Apparaît lorsque Playback Control (Commande de lecture.) est actif (CD vidéo).

Apparaît lorsqu’une fonction de répétition est active.

Apparaît lorsque répétition A-B est activé.

Apparaît pendant la lecture d’un disque.

Apparaît pendant une lecture au ralenti (DVD, CD vidéo).

Apparaît lorsque Balayage progressif est actif.

Affiche le type du disque en cours.

• DVD: DVD

• CD: CD audio, MP3, JPEG

• DCV: CD vidéo

Affiche la durée de lecture écoulée du Titre ou de la Plage en cours, affiche brièvement un numéro de Plage, de Chapitre ou de Titre lorsque la lecture commence.

Apparaît lorsque répétition TOUT est activé.

Apparaît lorsque la lecture du disque est en pause.

DVP620_07(FR)_1.qx4 04.4.7 0:01 PM Page 20

Philips DVP620VR/07 User Manual [fr]

Specifications and Main Features

Frequently Asked Questions

User Manual
