Page 1

Philips Digital Satellite Receiver

DSR2011

Premiere geeignet

Access to Free to air and Pay TV digital services

Digital content brought to you by Philips and Premiere

Better

• 2 SCART connectors for connecting your TV and another source

• Fast Zapp, change from channel to channel within 1 second

• High-quality SCART cable is included

• Dolby Digital 5.1 audio output for full surround sound

• Access the Free-to-Air digital TV and radio channels

• Access to Pay-TV channels and free-to-air services

Easier

• Fast and automatic installation of new channels

• Euphoria User Interface simplifies navigation through menus

• 7-day Electronic Program Guide for TV schedule

Page 2

Digital Satellite Receiver

DAYS

EPG

DSR2011/02

Specifications

Convenience

• User convenience: Electronic Programming Guide

• Child Protection: Child Lock+Parental Control

• Ease of Installation: Autoinstall

• Eco Power Standby: 1 watt

• Recording: Record header message

• Signal strength indication

• User Interface: 7 day Electronic program Guide, omatic program list update, Multiple subtitles

Aut supported, Now & Next ESG, On Screen Display on TV, Pre-installed for astra 19.2E, Software upgrade over the air, TV and Radio mode

• Parental control: Lock with PIN code

• Programmable timers: 8

Accessories

• Included accessories: High quality SCART cable,

Mains cord, Quick install guide, Remote Control, Safety & warranty booklet

• Batteries: 2 x AA size

Dimensions

• Carton dimensions (WxDxH) inch: 341 x 245 x

90mm

• Product dimensions (W x H x D):

0 x 60 x 275 mm

• Temperature (storage): -20ºC to +60ºC

• Weight incl. Packaging: 2.5 kg

• Weight: 1.45 kg

• Temperature range (operation): 5°C to 45°C

Power

• Mains power: 230V (+/-10/-15%)/50Hz

• Power consumption: 15 W

• Standby power consumption: < 6 W

System Specifications

• CPU speed: 166 MHz

• Flash memory size: 4 MB

• Video graphics: 16 MB SDRAM

• Video decoding: MPEG-2 DVB up to MP@ML, bit rate up to 15 Mbit/s, Video format 4:3

Video and 16:9, resolution up to 720x576 pix

• Ram size: 16 MB SDRAM

Audio Decoding

• Compression format: MPEG layer I/II

Video Decoding

• Conditional access system: Nagravision (card not

supplied, Subscription needed for pay-TV

• Frequency range: MHz 950-2150, Video bit rate

to 15 Mbit/s

• CA: Nagravision

• Reception-Demodulation: QPSK

• De-scrambling: Smart Card reader, Pay TV ready

Connectivity

• Audio Output - Digital: Coaxial (cinch)

• TV scart out: Controlled audio L/R, CVBS, RGB, S-

ideo (for LCD projector), PAL

• VCR scart in: Audio L/R, CVBS, RGB, Fast blanking,

anking

Slow bl

• Audio Output - Analog: Stereo (Red/White cinch),

olume controlled L/R cinch

• Serial interface: RJ 9

• VCR scart out: Audio L/R, CVBS

Green Specifications

• Lead-free soldered product

• Banned Substance Declaration: Packaging,

facturer

Manu

Sound

• Sound System: Dolby Digital (AC-3)

•

Highlights

2 SCART connectors

2 SCART sockets allow you to connect to 2 devices simultaneously. One connection for the TV and the other, either to a DVD recorder or VCR for recording TV content, or to a video playback device, such as a DVD or Blu-ray player. Simply connect the SCART sockets on the product to the desired device by a SCART cable, to enable transmission of the video signals.

Fast Zapp

Time it takes to go one channel up/down

Free SCART cable

high quality SCART cable

Dolby Digital 5.1 surround

Because Dolby Digital, the world's leading digital multi-channel audio standards, make use of the way the human ear naturally processes sound, you experience superb quality surround sound audio with realistic spatial cues.

Free-to-Air TV channels

You want to continue watching all the traditional publicly broadcasted programs, now in digital quality as well as any new TV channels available following digital switchover. No subscription or fee required.

Access to Pay TV services

There is more and more choice for top quality TV content these days, but the only way to access the premium channels is to subscribe to the services from the local Pay-TV operators. This digital receiver enables you to get the best of both worlds by enabling access to certain pay-TV broadcasts in addition to the standard free-to-air channels. Simply insert the operator's smart card into the receiver's dedicated pay-TV slot, and it will descramble the encrypted signals that are being broadcasted by the Pay-TV operators.

Issue date 2014-02-11

Version: 7.0.8

12 NC: 8622 512 00376 EAN: 87 10895 82949 6

Specifications are subject to change without notice. Trademarks are the property of Koninklijke Philips N.V. or their respective owners.

www.philips.com

Automatic install & update

With the launch of digital terrestrial TV, additional broadcast channels are made available. Also, the channel numbering can often be temorarily reshuffled during digital switchover. To ensure that you always have the access to all available channels, it is important that the product is able to scan and install new channels automatically. A very sensitive tuner in this product scans through the broadcasting network for new channels whenever the product is switched off. Whenever a new service is detected, it will be automatically updated and saved onto the channel list.

Euphoria User Interface

Easy navigation through the menu structure.

7-Day Electronic Program Guide

Woul d you l ike to know w hat the TV sched ule is for today and even for the whole week? This way, you can be sure to not miss any of your favorite shows by planning your evenings or making pre-scheduled recordings. The EPG information is part of the broadcast data and, when available, this receiver compiles the programming details for the upcoming 7 days and lists it in an easy-to-read format for your reference. The EPG can be accessed via the menu, or by simply pressing the EPG button on the remote control.
