User manual

Charge the handset(s) 24 hours before use.

Quick start guide

The pilot key allows you to browse the menus. Up to go left in the menus and down to go right in the menus & options.

Press to select a menu or an option and validate a setting.It is also used as shortcut to menus Answer/end a call

Make a call Read Call log Redial a number

Call from phonebook

Add a name in the phonebook

Adjust the earpiece volume during a call

Adjust the handset loudspeaker volume

Mute and unmute the microphone

Transfer a call/Intercom (if there are at least 2 handsets)

Predial number & or and dial number

up and browse

up and browse and

down,browse through the list and

Predial number and select scroll to Store

and select ,enter the name and press OK

Scroll up to increase the volume, scroll down

to decrease the volume

During a handsfree call,up to increase,down to

decrease

During a call press Options,press Mute

press End mute

Press + number phone

Read an event

Set the date and time

Set the handset external ring tone

Activate/deactivate the answer machine

Press View

Press to enter the carousel, scroll to Handset and select. ,scroll to Date and time and select Press to select Set date and enter the current date,

press OK. Scroll to Set time and enter the current time,

press OK

Press to enter the carousel, scroll to Sounds and select. ,press to select Handset ring tones.

Press to select External ring tone Browse through the list to hear the ring tones and select

your ring tone

Press on the base station to switch the answer

machine ON or OFF

Quick start guide

http://www.philips.com/faqs/dect

Pilot key

Press to enter the carousel or

DECT 511/DECT 515

Handset

Talk

- Press to take the line,answer a

call or hang up.

select a menu or an option

Scroll to move through the

menus & options

Move the cursor left/right Scroll up to access the Call

Log from idle mode

Scroll down to access the

Phonebook from idle mode

A long press to unlock the ke ypad

Loudspeaker*

- Short press to take the line or to activate the handset loudspeaker during a call

Keypad lock & Editing

- Short press to insert *

- Long press to lock/unlock the keypad in idle mode

- Long press to insert R (in between-digit pause) when dialling

- Long press to enter multitap system or Eatoni®editor when entering text

Earpiece

Microphone

Clear/Recall

- To correct a digit when predialling or a character when editing

- Short press to go back one menu when navigating

- Long press to return to idle mode when navigating

- To insert R for operator services when on line

Do not disturb & case mode

- Short press to insert # when dialling

- Long press to activate/deactivate the “Do Not Disturb” mode

- Long press to insert a pause (P) when dialling

- Press to switch case mode when editing

Alarm clock

- A short press to dial 0

- A long press to activate/deactivate the alarm clock

- A short press to change the letter when editing in Eatoni

SMS key

- Short press to directly access Send new SMS from idle mode

- Short press from the Phonebook or the Call log menu to edit an SMS

®.

*Warning : Handsfree activation could suddenly increase the volume in the earpiece to a very high level.Make sure the handset is not too close to your ear.

http://www.philips.com/faqs/dect

Call transfer/Intercom

- Short press to initiate or cancel internal call

- Short press during internal call to transfer the call or switch between internal call and External call

- Short press to answer an internal call or to release an internal call

DECT 511/DECT 515 handset

Icons on the handset display

The display gives information about the operation of your telephone

On first use, it is sometimes necessar y to wait for a few minutes of charge before seeing icons on the display.

When charging,the batter y bars scroll from empty to full status. When the handset discharges,the batter y shows the status : Full ,2/3 , 1/3

and empty .

The answer machine is activated (DECT 515).When blinking,this symbol indicates that there is a new message on the answer machine or on the operator voice mailbox.When fast blinking it shows that the answer machine is full.

The ring tone is deactivated.

An external call is in progress.When blinking,this symbol indicates that there is an incoming external call in progress or that the line is already busy.

An internal call is in progress.When blinking, this symbol indicates that there is an internal incoming call.

The handset loudspeaker is activated.When blinking,this symbol shows that the base loudspeaker is activated (only for DECT 515).

The SMS function is activated.When blinking, this symbol indicates that a new SMS has been received.When fast blinking, it indicates that the SMS memory is full.

The handset is registered and in range of the base.When blinking,this symbol indicates that the handset is not registered to the base.

Icons on the handset display

http://www.philips.com/faqs/dect

base station

Paging key

The paging key enables you to locate a missing handset. Press the key until the handset starts to ring.Once retrieved,press any key on the handset to end paging.

base station

New message

indicator

When blinking,it indicates

that there is a new message. When fast blinking,it indicates

that the answer machine memory is full.

ON/OFF key

Press to switch the answer machine ON or OFF

Play/Stop key

Short press to play new message

Loudspeaker

Paging key

Press to locate all handsets

Skip/Fast forward key

Short press to go to the next message while listening

Long press to fast forward the current message while listening

Delete key

Short press to delete current

message

Short press to stop a message while listening to it

http://www.philips.com/faqs/dect

Long press to delete all the messages (except unread ones)

DECT 511/DECT515 base stations

Table of contents

Quick start guide 1 DECT 511 / DECT 515 handset 2 Icons on the handset display 3 DECT 511 / DECT 515 base stations 4 Table of Contents 5-6 Menu structure 7-11 Conformity, Environment and Safety 12 Declaration of conformity

Using GAP standard compliance 13

Installing the DECT 511/515

Unpacking your DECT 511 14 Unpacking your DECT 515 14 Installing the base station 15 Installing and replacing the batteries in the handset 15 Battery life and range 15

Introduction

Philips screen saver 16 Idle mode 16

Understanding the menu system 16 How to navigate in the menus 16

Basic principles 17 In-call features 18 Editing systems 19-20

SMS

Send new SMS 21 Read SMS 22 SMS settings 25

Handset

Babysit mode 28 Registration 28 Rename handset 29 Date & time 29 Display contrast 30 Backlight 30 Screen saver 30

Table of contents

http://www.philips.com/faqs/dect

Answer machine

Saved messages 31 Outgoing messages 33 Answerphone settings 33 Record and listen to a memo 37

Intercom

Internal call 38 Call transfer 38 Conference call 39 Babysit mode 39

Phonebook

Add new 40 View 40

Call log

View 43 Delete all 45 Call log settings 45

Operator services 46

Extra

Call duration 47 Alarm clock 47 “Do Not Disturb” mode 48

Sounds

Handset ring tones 49 Base ring tones 50 Group ring tones 50 Handset ring tone volume 50 Base ring tone volume 50 My ring tones 51 Record personal melody 51 Settings 52

Base

Enable registration 54 Line settings 54 Service code settings 56

FAQ 57-58

Troubleshooting 59-60

Index

http://www.philips.com/faqs/dect

Table of contents

Menu structure

By using the “Pilot key” on the side of the handset,you can scroll through the menus.

SMS

Send new SMS

Read SMS

SMS Settings

Choose SMS box*

Mode

SMS boxes*

SMS centre

Send SMS to phone

Read SMS View number

Forward

Send again

Delete SMS Copy to phonebook Call

On or Off

Handset

* only available in the UK

Babysit mode Registration

Rename handset

Date & time

Display contrast

Backlight

Screensaver

Menu structure

On or Off

Base selection

Enter name

Set date Set time

Levels (1 to 5)

Off / 10s / 20s

http://www.philips.com/faqs/dect

Enter RC code

Answer machine

Saved messages

Record a memo

Play Next Previous

Call Delete Store

Send SMS

Outgoing messages

Answerphone settings

Answ.machine mode

Record outgg msg

Mode Rings before answer Voice language

Call screening

Answer and record with personalised OGM

Answer only with personalised OGM

Answer and record with predefined OGM

Answer only with predefined OGM

Standard OGM for answ.& record mode

Standard OGM for answer mode only

Group A Group B Group C

On or Off Toll saver / 3 / 5 / 7

Off/Low/Medium/ High/Boost

Play/Record new Delete

Intercom

Call all

Handset list

http://www.philips.com/faqs/dect

Recording quality Remote control

Menu structure

High / Standard Mode (On or Off)

Change code

Phonebook

View

Call

Call log

Add new

View

Delete all

Change number Change name

Define the group Change SMS box* Delete

Send SMS

Play Call View number

Store Delete Send SMS

A / B / C

Operator services

Call log settings

Call forward

Cancel call forward

Call forward when line busy

Cancel call forward when line busy

Call forward when unanswered

Cancel call forward when unanswered

Incoming calls

Outgoing calls

All calls Unanswered calls only Calls with answer

machine message only

All calls

No call

Voice mail

Cancel call back

Withhold identity

* only available in the UK

Menu structure

http://www.philips.com/faqs/dect

Extra

Call duration

Sounds

Alarm clock

Do not disturb mode

Handset ring tones

Activation On or Off Set day Set time Settings

Activation Set day Start time Stop time

Allowed caller choice A / B / C

External ring tone

Internal ring tone

Ring tones Ring tone volume

On or Off

Low/Medium/High

Base ring tones

Group ring tones

Handset ring tone volume

Base ring tone volume

My ring tones*

Record melody

Settings

Ring tone list

A / B / C

Handset

Base

Play Record new

Delete

Base loudspeaker volume

Earpiece tone

Rename Delete Rename

Delete

* only available in the UK

http://www.philips.com/faqs/dect

Key & feedback tones

Notification beep

Music on hold

Menu structure

Base station

Enable registration Line settings

Service code settings

Dial mode

Recall type

Choose country/oper. First ring

Tone / Pulse

Short flash / Long flash

On or Off

Menu structure

http://www.philips.com/faqs/dect

Conformity,En vir onment and Safety

Safety information

This equipment is not designed to make emergency calls when the power fails.An alternative has to be made available to allow emergency calls.

Conformity

Hereby,Philips declares that the DECT 511xx and DECT 515xx are in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. This product can only be connected to the analogue telephone network of the UK and Ireland.

Power requirements

This product requires an electrical supply of 220-240 volts, alternating monophased power, excluding IT installations defined in standard EN 60-950.In case of power failure,the communication can be lost.

Warning !

The electrical network is classified as hazardous according to criteria in the standard EN 60-

950.The only way to power down this product is to unplug the power supply from the electrical outlet.Ensure the electrical outlet is located close to the apparatus and is always easily accessible.

Telephone connection

The voltage on the network is classified as TNV-3 (Telecommunication Network Voltages), as defined in the standard EN 60-950.

Safety precautions

Do not allow the handset to come into contact with water.Do not open the handset or the base station. You could be exposed to high voltages.Do not allow the charging contacts or the battery to come into contact with conductive materials.

Environmental care

Please remember to observe the local regulations regarding the disposal of your packaging materials,exhausted batteries and old phone and where possible promote their recycling.

http://www.philips.com/faqs/dect

Conformity, Environment and Safety

Declaration of conformity

We Philips Consumer Electronics Route d’Angers 72081 Le Mans Cedex 9 France

Declare that the products DECT 511xx and DECT515xx are in compliance with the Annex III of the R&TTE-Directive 1999/5/EC and then with the following essential requirements:

Article 3.1.a (protection of the health & the safety of the user) :EN 60950-1 (10/2001) Article 3.1.b (protection requirements with respect to electromagnetic compatibility :

ETSI EN 301 489-6 V1.2.1 (08/2002) & ETSI EN 301 489-1 V1.4.1 (08/2002) Article 3.2 (effective use of the radio spectrum) EN 301 406 (2003) The presumption of conformity with essential requirements regarding Council Directive

1999/5/EC is ensured.

Date :10/05/2004 Le Mans Quality Manager, Home Communication

Using GAP standard compliance

The GAP standard guarantees that all DECTTMGAP handsets and base stations comply with a minimum operating standard irrespective of their make.Your DECT 511/515 handset and base station are GAP compliant,which means the minimum guaranteed functions are :register a handset,take the line, receive a call and dial.The advanced features may not be available if you use another handset than a DECT 511/515 with your base station. To register and use your DECT 511/515 handset with a GAP standard base station of a different make, first follow the procedure described in the manufacturer’s instructions, then follow the procedure page 28. To register a handset from another make to the DECT 511/515 base station,place the base station into registration mode (page 28),then follow the procedure in the manufacturer’s instructions.

Philips has marked the battery and packaging with standard symbols designed to promote the recycling and appropriate

disposal of your eventual waste.

A financial contribution has been paid to the associated national recovery & recycling system.

The labelled packaging material is recyclable.

DECTTMis a Trade Mark of ETSI registered for the benefit of the implementers of the DECT technology.

Declaration of conformity

http://www.philips.com/faqs/dect

Installing the DECT 511/515

Unpacking your DECT 511

The DECT 511 package contains:

One DECT 511 base station One DECT 511 handset

NiMh 2HR AAA 600 mAh rechargeable batteries

A user guide A guarantee

A power supply A line cord*

DECT 511

DECT 515

PHILIPS

Unpacking your DECT 515

The DECT 515 package contains:

One DECT 515 base station One DECT 515 handset

NiMh 2HR AAA 600 mAh rechargeable

A user guide A guarantee

batteries

A power supply A line cord*

In DECT 511 and DECT 515 multi-handset packs, you will also find one or more additional handsets,chargers with their power supply and additional rechargeable batteries.

DECT 511

DECT 515

PHILIPS

*Warning : You may find in the box the line adaptor delivered separately from the line cable. In this case, please , first plug this line adaptor to the line cable before connecting it to the line socket.

http://www.philips.com/faqs/dect

Installing the DECT511/515

Installing the base station

Situate your product close enough to the telephone and mains power sockets so that the cables will reach.To properly install the base station,plug the line cord and the power cable into the base station. Plug the cord and the cable into the wall.A beep indicates that the phone is properly installed (only available for DECT515).If you have a broadband DSL Internet Installation,please make sure you have one DSL filter plugged directly on each line socket used in the house and check the modem and the phone are plugged in the correct filter slot (one specific for each).

W arning !The electrical network is classified as dangerous according to criteria in the standard EN 60 -

950. The only way to power down this product is to unplug the power supply from the electrical outlet. Ensure the electrical outlet is located close to the apparatus and is always easily accessible. Please take care that the power supply and telephone line are connected to the correct sockets as incorrect placement could damage your equipment.

W arning !Always use the cables provided with the product.

Do not insert anything in this opening Connect the power supply

Connect the telephone line cord

Installing and replacing the batteries in the handset

To inser t the batteries, open the batter y cover, place the batteries as indicated and put the batter y cover back. When the handset is placed on the base station the 3 batter y bars scroll (if charge is needed).Allow the handset to charge for 24 hours to reach full charge.On first use it may be necessary to wait for a few minutes before seeing symbols on the display. In case you need to change the batteries,the following type is mandatory 2HR AAA NiMh 600 mAh.

Warning: the base station must always be plugged into the mains when charging or when in use .Always use rechargeable batteries.

Batteries should not be disposed of with general household waste.

Battery life and range

Optimal battery life is reached after 3 cycles of complete charge & discharge.When reaching the range limit and the conversation becoming crackly,move closer to the base. To reach optimal range, place the base station away from electrical appliances.

Battery life in standby

mode

up to 200 hours up to15 hours up to 50 metres up to 300 metres

Battery life in

communication

Installing the DECT511/515

Indoor range Outdoor range

http://www.philips.com/faqs/dect

Introduction

Philips screen saver

After 2 minutes of inactivity, the screen saver is displayed: You can deactivate it (see p.30)

Idle mode

In idle mode, the DECT 511/515 display shows various information:

- The date & time , the name of the handset and the instructions to access the menu.

- Missed calls ,new SMS or new messages (answer machine) or network voicemailbox message ,if any.

- “Do Not Disturb” mode , and the alarm clock , if activated.

To activate/deactivate these functions press or

Understanding the menu system

To access the carousel menu from idle mode,press on the side of the handset The carousel represents a loop of icons that gives access to the different first level menus.

Scroll up or down to reach the desired menu and select The sub menus are listed and represented by little squares

at the bottom of the display.To reach one particular sub-menu use the “pilot key” and press to validate your choice. A “tick” shows the selected sub-menu or option. The

shows the option you are browsing. Note:some menus are also directly accessible via a dedicated

key on the keypad like the SMS menu with or the Intercom with .

How to navigate in the menus

Press to access the carousel menu Scroll to Sounds, and select

Scroll to Handset ring tone vol. and select The current level is heard, browse to hear other levels Browse through the levels and select one

http://www.philips.com/faqs/dect

Introduction

Basic principles

To make and to answer a call

Pre dialling

Dial the number Make the call

To call from the phonebook

Scroll down to directly access Phonebook Choose a name in the list

Make the call or press to select Call in the options

To store a name from predial

Dial the number Press to enter the options

Scroll to Store and select

Direct dialling

Press the key

Dial the number

Answer a call

When ringing Take the line

Enter the name and press OK

To store an SMS

Dial the number Press to enter the options Scroll to Send SMS and select

Select your SMS box* (only if you have created several SMS boxes). To create a SMS box please refer to SMS settings page 25

Enter the Destination box* and press OK Enter the text and press Scroll to Store and select

Redial from call log

Scroll up to directly access Call log and select Choose an entry in the list

Make the call or press to select Call in the options

* only available in the UK

Basic principles

http://www.philips.com/faqs/dect

In call features

During an external call,some other options are available.Press to enter Options.

To mute the handset microphone

Press to enter Options Press to select Mute (the caller can no longer hear you)

Press again to resume the conversation (End mute)

Intercom (available only if you have at least two handsets)

During an external call,you can use the intercom in-call option to call another handset and for example transfer the call to this handset.

Press to enter Options Scroll to Intercom (the caller can no longer hear you)

If there is only one additional handset it rings automatically, otherwise select a handset from the list.

Press Transfer when the second handset has taken the line.

Other options are available such as Switch and Conference call (see page 38).

To record a conversation (DECT 515 only)

Press to enter Options Scroll to Record and select

To listen to the conversation,go to the call log menu or the messages list

To switch the handset loudspeaker ON/OFF

Press to activate or deactivate the handset loudspeaker

Warning : Handsfree activation could suddenly increase the volume in the earpiece to a very high level.Make sure the handset is not too close to your ear.

To increase/decrease the handset & earpiece/loudspeaker volume during a call

Scroll up to increase or down to decrease the volume when on line

There are 5 volume levels available .The last setting is stored for the next calls.

To access the phonebook or the call log

Press to enter the options. Scroll to Phonebook or Call log and select

Caller Line identification and Call waiting

If you subscribe to the Call waiting service, a beep in the earpiece informs you of a second incoming call.The name or number of the second caller may be displayed if you also subscribe to Caller Display service.To answer that second call,use + (according to your network,the code may be different).Please contact your network provider for more details.

http://www.philips.com/faqs/dect

In call features

Editing systems

Case mode

By default,the first letter of a sentence is in upper case. Use to change the case mode:

- all letters in upper case (AB)

- all letters in lower case (ab) or

- the first letter in upper case and the rest of the word in lower case (Ab).

Punctuation and mathematical marks are available through and while other special characters are also available on (see table page 20).

Scroll to move the cursor left or right.Press to delete a character ; a long press deletes the whole text.

DECT 511/515 uses two editing systems :Multi-tap and Eatoni®.While editing,a long press on

enables you to switch between the two systems.

The standard multi-tap system

This system allows you to enter the text character by character, pressing the corresponding key as many times as necessar y to reach the desired character.

The Eatoni®system is a predicitive editing system designed to help you to write an SMS. A little E in the header helps you to know the mode you are using.

Eatoni®is a word editor that chooses the most probable letter. The operation of the Eatoni®system is the following:

Press the key that displays the character you want to edit. The character that is most likely to be correct is displayed on the screen.If it does not match the expected letter, press to

display the next most probable character available on the key.

Editing systems

http://www.philips.com/faqs/dect

Let’s compare Multitap and Eatoni® systems to write “Peter”.

To write “Peter” with multi-tap Press once :P

Press twice :Pe Press once :Pet Press twice :Pete Press three times :Peter

To write “Peter” with Eatoni

Keypad Keys

1 2 3 4 5 6 7 8 9 0

Long press to activate Eatoni

Multi-tap Sequence

[space] 1 @ _ # = < > ( ) & ¤ £ $ ¥ [ ] { } ¤ § a b c 2 à ä ç å æ d e f 3 è é ) N g h i 4 ì Γ j k l 5 7 m n o 6 ñ ò ö p q r s 7 ß A 2 E t u v 8 ù ü w x y z 9 f S Ξ Q .0 , / :;" ' ! ¡ ? ¿ * + - % \ ^ ~ |

Press

Press to change character

Press

Press to validate the name

Eatoni®& LetterWise are trademarks of Eatoni Ergonomics,Inc . and used by Philips under license.

http://www.philips.com/faqs/dect

Editing systems

SMS

SMS menu is also accessible via the

Send new SMS Read SMS SMS settings

SMS stands for Short Message Service .To benefit from this service you must subscribe to the Caller Line Identification Service (CLI) together with the SMS service from your network provider. SMS can be exchanged with a phone (mobile or compatible fixed lines) provided the receiver has also subscribed to the CLI & SMS services.

Your DECT 511/515 factory settings correspond to the main national operator. If you wish to send or receive SMS through another service provider you must set the corresponding numbers (see page 27 and the SMS leaflet).

A password can protect your SMS box*, but it is not compulsor y. To send an SMS to the receiver’s own SMS box*,you must know his destination box.

carousel or Important information are also

available on the SMS leaflet in the box

Send new SMS

To send an SMS to a phone

Press to directly reach Send new SMS and select Select your SMS box* (only if you have created several SMS boxes).

To create a SMS box please refer to SMS settings page 25

Enter the password if any and press OK (optional) Enter the phone number directly and press OK or press to

retrieve the number from the Phonebook Enter the Destination box* number (optional),press OK.

Note: the destination box is the SMS box of the receiver. Enter the text and press (see page 19)

Press to select Send now,otherwise if you want to store your SMS,scroll to Store and select .

The SMS stored can be later retrieved from Read SMS

The sent SMS can be up to a maximum of 160 characters long. The special characters ¤,] and [ count for 2. The DECT 511/515 can store 25 SMS for the 3 boxes*.

* only available in the UK

SMS

http://www.philips.com/faqs/dect

Read SMS

The SMS list contains the stored and received SMS. The received SMS are shown by and the stored SMS are shown .

To read an SMS/to view the number

Press to directly reach Send new SMS Scroll to Read SMS and select

Select your SMS box* (only if you have created several SMS boxes). To create a SMS box please refer to SMS settings page 25

Enter the password if any and press OK (optional) Browse the list of SMS and select

Press to select Read SMS or scroll to View number and select

When reading the list of receiv ed SMS,some options are only available for SMS r eceived from a phone. Those options are Reply,Forward,Copy to phonebook, Call and View number.The options Reply and Copy to phonebook use the sender’s own sub-address.

To save a ring tone

only available in the UK

This option enables to save a downloaded ring tone in your handset or in your base station (only available for DECT 515 base station) received through an SMS.This saved ring tone will be then

inserted in the menu Sounds in the list of My ring tones (see p. 50).

Press to directly reach Send new SMS Scroll to Read SMS and select

Select your SMS box* (only if you have created several SMS boxes). To create a SMS box please refer to SMS settings page 25

Enter the password if any and press OK (optional) Browse the list of SMS and select the SMS containing the ring tone

Press to select Read SMS Press to select Save ring tone

Press to select Handset or scroll to Base station and select

http://www.philips.com/faqs/dect

SMS

* only available in the UK

To reply to an SMS

Press to directly reach Send new SMS Scroll to Read SMS and select

Select your SMS box* (only if you have created several SMS boxes). To create a SMS box please refer to SMS Settings page 25

Enter the password if any and press OK (optional) Browse the list of SMS and select the one you want to reply to

Scroll to Reply and press Enter the text and press

Press to select Send now

To forward an SMS

Press to directly reach Send new SMS

Warning:

Scroll to Read SMS and select Select your SMS box* (only if you have created several SMS boxes).

To create a SMS box please refer to SMS Settings page 25 Enter the password if any and press OK (optional) Browse the list of SMS and select the one you want to forward

Scroll to Forward and press

Enter the number and press OK Enter the Destination box* number (if any) and press OK

You can modify the text if necessar y or select Press to select Send now

for copyright reasons,it is strictly forbidden to forward a downloaded ring tone.

* only available in the UK

SMS

http://www.philips.com/faqs/dect

To send again

Press to directly reach Send new SMS Scroll to Read SMS and select

Select your SMS box* (only if you have created several SMS boxes). To create a SMS box please refer to SMS Settings page 25

Enter the password if any and press OK (optional) Browse the list of SMS and select the one you want to send again

Scroll to Send again and press

To delete an SMS

Press to directly reach Send new SMS Scroll to Read SMS and select

Select your SMS box* (only if you have created several SMS boxes). To create a SMS box please refer to SMS Settings page 25

Enter the password if any and press OK (optional) Browse the list of SMS and select the one you want to delete

Scroll to Delete SMS and press Press OK to confirm

To copy a number to the phonebook

Press to directly reach Send new SMS Scroll to Read SMS and select

Select your SMS box* (only if you have created several SMS boxes). To create a SMS box please refer to SMS Settings page 25

Enter the password if any and press OK (optional) Browse the list of SMS and select

Scroll to Copy to phonebook and select Enter the name and press OK

http://www.philips.com/faqs/dect

SMS

* only available in the UK

To call from the SMS list

Press to directly reach Send new SMS Scroll to Read SMS and select

Select your SMS box* (only if you have created several SMS boxes). To create a SMS box please refer to SMS Settings page 25

Enter the password if any and press OK (optional) Browse the list of SMS and select

Scroll to Call and select or make the call

SMS settings

To set the SMS mode

If there are 2 SMS-enabled phones on your telephone line, you will have to deactivate the SMS feature on 1 of the devices.

Press to directly reach Send new SMS Scroll to SMS settings and select

Press to select Mode Press to select On or scroll to OFF and select

To set your personal SMS boxes

only available in the UK

Press to directly reach Send new SMS Scroll to SMS settings and select Scroll to SMS boxes and select Scroll to Add new and select

Enter the SMS box number and press OK Enter the password twice and press OK (optional)

SMS

http://www.philips.com/faqs/dect

To change the password of an SMS box

only available in the UK

Press to directly reach Send new SMS Scroll to SMS settings and select

Scroll to SMS boxes and select the one for which you want to change the password Press to select Change password Enter the old password and press OK Enter the new password twice and press OK

Note:If you forgot your password you can delete the corresponding SMSbox

To delete an SMS box

only available in the UK

Press to directly reach Send new SMS Scroll to SMS settings and select

Scroll to SMS boxes and select the one you want to delete Scroll to Delete and select

Press OK to confirm

Warning:when an SMS box is deleted,all the SMS contained in this box are deleted at the same time.

To choose by default an SMS centre

Press to directly reach Send new SMS Scroll to SMS settings and select

Scroll to SMS centre and select ,choose an SMS centre Press to select Choose by default

http://www.philips.com/faqs/dect

SMS

To set the SMS centre number(s)

The SMS are sent through a centre.To receive an SMS from another operator, you must set the corresponding numbers.

Press to directly reach Send new SMS Scroll to SMS settings and select

Scroll to SMS centre and select Choose an SMS centre and select Scroll to Edit incoming number and select Enter the number and press OK Scroll to Edit outgoing number and select Enter the number and press OK

SMS

http://www.philips.com/faqs/dect

Handset

Babysit mode Registration Rename handset Date & time Display contrast Backlight Screen saver

Babysit mode

This feature allows you to monitor the baby’s room.Place the handset in the room to be monitored and you will hear the noise coming from the room on the additional handset.

if there are at least 2 handsets

To activate/deactivate the babysit mode

Press to enter the carousel menu Scroll to Handset and select

Press to select Babysit mode Select ON or scroll to OFF and select

An intercom is necessary to monitor the room (see page 38).

Note:during an intercom,you can still answer a call or make a call with the handset

Registration

Up to 6 handsets can be registered to the base station.1 handset can be registered to 4 base stations. Warning:If you wish to associate non Philips handsets to the DECT 511 or DECT 515 base station,make sure that this handset is GAP compliant otherwise it will not operate properly (see p 13).

To register a handset

Unplug and plug back in the mains lead to put the base in registration mode

With the additional handset,press to start the registration Enter the 4-digit RC code written on the sticker

placed under the base station and press OK

To unregister a handset

Press to enter the carousel menu Scroll to Handset and select Scroll to Registration and select

Scroll to Un-register handset and select Choose the handset to un-register from the list and press OK Enter the 4-digit RC code and press OK

Note:should you have your handset serviced alone,please make sure it is unregistered from the base station before taking it back to the repair centre.

http://www.philips.com/faqs/dect

Handset

To select a base station

Each DECT 511/515 handset can be used with up to 4 base stations. To use a handset with another base station, the handset must be first registered to that base station.

Press to enter the carousel menu Scroll to Handset and select

Scroll to Registration and select Scroll to Base selection and select

Choose the base from the list and press OK

Warning:the handset will automatically operate with the last base station to which it was registered.If the handset is out of range,it will automatically search for another base station from the list.

Rename handset

To rename a handset

Press to enter the carousel menu Scroll to Handset and select

Scroll to Rename handset and select Long press to delete the current name

Enter the name and press OK

Date & time

To set the date and time

Press to enter the carousel menu Scroll to Handset and select Scroll to Date & time and select

Select Set date Enter the current date and press OK Scroll to Set time and select

Enter the current time and press OK

Warning:If your phone is connected to an ISDN line through an adaptor, the date & time may change after each call.Please check the date & time settings in your ISDN system.Please contact your network provider (see FAQ p.56).

Handset

http://www.philips.com/faqs/dect

Display contrast

To set the display contrast

Press to enter the carousel menu Scroll to Handset and select Scroll to Display contrast and select Browse through the levels and select the appropriate one

Backlight

To set the display backlight duration or deactivate it

Press to enter the carousel menu Scroll to Handset and select

Scroll to Backlight and select Browse through the durations OFF / 10 seconds / 20 seconds

and select

Screen saver

After 2 minutes of inactivity, the screen saver is displayed.You can choose to activate or deactivate it

To activate or deactivate the screen saver

Press to enter the carousel menu Scroll to Handset and select

Scroll to Screen saver and select Press to select ON or scroll to OFF and select

http://www.philips.com/faqs/dect

Handset

Answer machine

Saved messages Record a memo Outgoing messages Answerphone settings

The DECT 515 includes an answer machine that records the calls when it is activated.You can reach the answer machine from the base station or the handset.

By default,the answer machine is activated.It can store up to 25 messages within the maximum recording time of 30 minutes. A message can be up to 3 minutes long.

To switch the DECT 515 Telephone Answer Machine ON/OFF

From the handset

Press to enter the carousel menu Scroll to Answer machine and select

Scroll to Answphone settings and select Press to select Mode

Press to select ON or scroll to OFF and select

From the base station

A press on activates or deactivates the answer machine.Once activated,the red indicator is lit.

Saved messages

You can listen to new or saved messages via the handset or the base station.

To listen to new message(s) via the handset

The display shows that there is 1 or more new messages(s) (1 ). Press to view.

The message is automatically played. Note:the entry shows the number of times the caller tried to reach you.If you have subscribed to

the Caller Identification Service (CLI), the display shows the name of the caller and its group if activated (see page 39).

Answer machine

http://www.philips.com/faqs/dect

To play and browse through saved message(s) via the handset

Press to enter the carousel menu Scroll to Answer machine and select

Select Saved messages, the message which was recorded first is automatically played

Press to access the Options Press to select Play

To go to next or previous messages,scroll to Next message or Previous message and select

Note:you can listen to the message(s) via the Call log.Scroll up to access Call log and scroll to choose the message from the call log list. The entr y is marked (see page 42).

To play and go to next saved message(s) via the base station

Press to play a message and press once again to stop a message while listening Press to go to the next message while listening.Make a long press to fast forward the

messages while listening

To delete a message via the handset

Press to enter the carousel menu Scroll to Answer machine and select

Select Saved messages, the message which was recorded first is automatically played

Press to access the Options

Scroll to Delete and select Press OK to confirm

To delete a message via the base station

Press to delete the current message. Make a long press to delete all the messages (except unread ones)

The other options available from the handset are Call (if number is displayed),Store (if number is displayed) and Send SMS (if number is displayed).

http://www.philips.com/faqs/dect

Answer machine

Settings

To select the answer mode and the outgoing message (OGM) type

You can select among 2 answer modes :Answer only (when no messages can be left) and Answer & record (when messages can be left).For each mode,2 outgoing message types are available: predefined or personal message. By default the answer machine is set to Answer & Record with predefined OGM.

Press to enter the carousel menu Scroll to Answer machine and select Scroll to Outgoing Messages and select

Select Answ. machine mode Choose the appropriate mode among the 4 options above (2 answer

modes and 2 outgoing message types) and select

Note:a predefined message cannot be deleted

To record your personal outgoing message (OGM)

You can record 5 different personal OGM:a specific personal OGM for Answer & record mode for each group (A,B or C),the standard OGM for Answer & record mode for normal callers (not belonging to any group) and the standard OGM for Answer only mode for all callers.It is possible to record specific messages for specific groups only if you subscribe to the Caller Line Identification service (CLI) and if you have set the groups in the phonebook (see page 41).

You can also download outgoing messages through an online service (see Leaflet “Download of ring tones and answerphone messages”)*.

Press to enter the carousel menu Scroll to Answer machine and select Scroll to Outgoing Messages and select

Scroll to Record outgg msg and select Choose between the different type of OGMs and the various

groups and press

Scroll to Record new and select

Press to start recording and once again to stop recording

* only available in the UKand depending on technical availability

Answer machine

http://www.philips.com/faqs/dect

The message is automatically played back.You can delete and/or record it again.The personal message can be up to 1 minute long

Note:Select Standard OGM for answer only mode or Standard OGM for Answ. & Record mode if you have no CLI subscription.

Warning:Please make sure that you have selected the appropriate answering machine mode (refer to page 33 “To select the answer mode and the outgoing message type”)

To set the number of rings before answering

You can set the answer machine to start playing the outgoing message after a given number of rings (3,5, 7 or Toll saver).The toll saver option (activated by default) is useful when using the remote access. The answer machine will start playing the outgoing message after 3 rings if there are new messages.If there is no new message the outgoing message will be played after 5 rings.Hang up after the 4th ring if you want to check if you have any messages at no cost.

Press to enter the carousel menu Scroll to Answer machine and select Scroll to Answphone settings and select

Scroll to Number of rings before answering and select Choose between Toll saver,3 rings,5 rings

or 7 rings and select

To set the voice language

You can change the language of the predefined message (OGM).

Press to enter the carousel menu Scroll to Answer machine and select Scroll to Answphone settings and select

Scroll to Voice language and select Choose the appropriate language among the list and select

http://www.philips.com/faqs/dect

Answer machine

To set the call screening

This feature allows you to activate or deactivate the base station loudspeaker so that you can choose whether to hear or not the callers leaving a message. You can set permanent call screening on the base station.

Press to enter the carousel menu Scroll to Answer machine and select Scroll to Answphone settings and select

Scroll to Call screening and select Press to select Off or scroll to Low, Medium, High or

Boost and select

Note:this feature is activated by default on Medium level. Call screening “call by call” on the handset is also possible.While the caller is leaving a message,

press to listen and press again to stop listening.Adjust the volume with .

To set the recording quality

There are 2 recording qualities:standard and high.In standard quality the total capacity is 30 minutes and in high quality the capacity is up to 15 minutes.

Press to enter the carousel menu Scroll to Answer machine and select Scroll to Answphone settings and select Scroll to Recording quality and select

Choose between High or Standard and select

To activate and deactivate the remote control

Press to enter the carousel menu Scroll to Answer machine and select Scroll to Answphone settings and select Scroll to Remote control and select

Select Mode Press to select ON or scroll to OFF and select

Note:the default setting is OFF.Activate this feature if you want to be able to remotely use the answer machine.

Answer machine

http://www.philips.com/faqs/dect

To remotely control your answer machine

To remotely access your answer machine :

- from another phone dial home

- if your answer machine is on,during or after the message press the star key on the handset ;if your answer machine is off,you will hear a beep after 45 seconds,then press the star key

- dial your remote control code (the default code is the registration code RC)

- if you have new messages they will be automatically played. The following table indicates the features available when remotely accessing the answer machine.

Record memo dial Play previous message dial Play message dial Play next message dial Listen again dial

Delete dial Activate answer machine dial Stop dial Deactivate dial

To change the remote control code

The default code is the registration code. We advise you to personalize it.

Press to enter the carousel menu Scroll to Answer machine and select Scroll to Answphone settings and select

Scroll to Remote control and select Scroll to Change code and select

Delete the default code, enter your new remote control code and press OK

http://www.philips.com/faqs/dect

Answer machine

Record and listen to a memo

This feature allows you to leave local messages for your family on the answer machine . A memo is recorded from the handset,it is represented by in the call log and can last up to 3 minutes.

To record a memo

Press to enter the carousel menu Scroll to Answer machine and select Scroll to Record a memo and select

Press to start recording and once again to stop

To listen to a new memo

The display shows there is 1 new local message (1 ). Press to View. The message is automatically played. Delete is also available in the options (see page 32)

To listen to a saved memo

You can use the Answer machine sub menu Saved messages and select Play or listen to a new or a saved memo through the base station (see page 32).

Answer machine

http://www.philips.com/faqs/dect

Intercom

Call all

Intercom menu is accessible via the carousel or

Handset list

Using the Intercom(if there are at least 2 handsets)

This feature allows you to make free internal calls,transfer external calls from one handset to another, use the conference option and the babysit feature (room monitoring).

Internal call

Press to call the selected handset + handset number (for example ) Hang up

Note:If the handset does not belong to the Philips DECT 511/515 range, this function may not be available.

Fast call transfer when on line

During a call you can transfer the call without waiting for the other handset to pick up.All the handsets will then ring.

Press to call the other handset

Hang up

Note:the person on hold hears music.A press on allows you to switch between the 2 calls.

Call transfer to a specific handset when on line

During a call you can transfer the call to a specific handset.

Press to call the selected handset + handset number (for example ) Hang up

Note:the person on hold hears music.A press on allows you to switch between the 2 calls.

Call transfer via the in-call options

During a call you can transfer the call via the in call options.

Press to enter the options (with handset 1). Scroll to Intercom and select

If there is only one additional handset,it rings automatically. Otherwise:

Browse through the handset list and select the one you want to transfer the call to

Intercom

http://www.philips.com/faqs/dect

The called handset rings. The external call is put on hold. If there is no answer from the called handset you can resume the call on the first handset.

Take the line on the called handset, both internal callers can talk Press to select Transfer (with handset 1) Scroll to Switch and come back to the external caller

Note:to answer the call on the second handset you can press .

Conference call via the in-call options

Conference call allows one external call to be shared with two handsets (in intercom).The 3 people can share the conversation.No operator subscription is needed.

Press to enter the options (with handset 1)

Scroll to Intercom and select If there is only one additional handset,it rings automatically. Otherwise:

Browse through the handset list and select the one you want to call. The called handset rings. The external call is put on hold. If there is no answer

from the called handset you can resume the call on the first handset. Take the line on the called handset, both internal callers can talk

Scroll to the Conference call option and select . The 3 people can share the conversation.

Note:to answer the call on the second handset you can press .

To initiate the babysit (room monitoring) if there are at least two handsets

To use the babysit mode feature you need to activate it (see page 28) & initiate an intercom.Place the handset in the room to be monitored and you will hear the noise coming from the room on the additional handset.

Press to enter the options Scroll to Intercom and select

If there is only one additional handset,it rings automatically. Otherwise: Browse through the handset list and select the one you want

to call. The called handset rings. Take the line on the called handset, the room monitoring can start.

http://www.philips.com/faqs/dect

Intercom

Phonebook

Add new

Phonebook menu is accessible via the carousel or

View

65 names and numbers can be stored in the phonebook. The phonebook contains all the information related to the callers,especially the group settings.The names and numbers are shared with all the handsets registered to your base.

Group settings

There are 3 groups (group A, group B and group C).When ringing, the ring tone helps you identify the caller’s group (see p.49) and the screen shows the caller’s name .A subscription to the Caller Line identification is needed.

Add new

The names are stored in alphabetical order.

To add a name to the phonebook

Press to enter the carousel menu

Scroll to Phonebook and select Scroll to Add new and select Enter the number and press OK

Enter the name and press OK (see page 19 “Editing systems”)

To store a name and number from predial

Once the number is dialled,press to reach the options,scroll to Store and select . Enter the name and press OK

View

To quickly reach a name in the list,enter the first character (browse through the list if several names start with the same letter).

Phonebook

http://www.philips.com/faqs/dect

To call

Scroll down to directly reach the list of names Browse through the list of names and select a name

Make the call

Or press to reach the options And press again to select Call

To change a number

Scroll down to directly reach the list of names Browse through the list of names and select a name

Scroll to Change number and select Press to erase the current number

Enter the new number and press OK

Note:it is possible to erase the current number with .You can simply change any digit by moving the cursor to reach the digit and press

To change a name

Scroll down to directly reach the list of names Browse through the list of names and select

Scroll to Change name and select Press to erase the current name

Enter the new name and press OK

Note:it is possible to erase the current name with . You can simply change any letter by moving the cursor to reach the letter and press

http://www.philips.com/faqs/dect

Phonebook

To define a group for a name and number (see Group settings p.39)

Scroll down to directly reach the list of names Browse through the list of names and select a name Scroll to Select group and select

Browse through the groups and select

To change the SMS box number

only available in the UK

Scroll down to directly reach the list of names Browse through the list of names and select a name Scroll to Change SMS box and select Enter the destination box number and press OK

To delete an entry

Scroll down to directly reach the list of names Browse through the list of names and select

Scroll to Delete and select Press OK to confirm

To send an SMS from the phonebook

Scroll down to directly reach the list of names Browse through the list of names and select Scroll to Send SMS and select

Select your SMS box* (only if you have created several SMS boxes). To create a SMS box please refer to SMS settings page 25

Enter the password and press OK (optional) Enter the Destination box* number (optional),press OK

Enter the text and press OK (see page 19) Press to select Send now

Note: once in the list of names, press to directly edit an SMS

* only available in the UK

Phonebook

http://www.philips.com/faqs/dect

Call log

View

Call log menu is accessible via the carousel or

Delete all Call log settings

The call log can store up to 40 entries

- : unanswered calls - : outgoing calls

- : memo or recorded conversation* - : answered calls

- : messages* - : messages (operator voice mail/if operator sends the information)

* DECT 515 only

The call log shows the list of incoming calls. If you have subscribed to the Caller Line Identification (CLI),you will also have the list of outgoing calls.In this case the name (or number) of the callers will be displayed.The date & time of the call are also shown.

View

To view the call log

Scroll up to directly reach the calls list Browse through the list and read the information

To listen to a message (DECT 515 only)

Scroll up to directly reach the calls list Browse through the list and select

the entry marked with Select Play in the options

To call / redial

Scroll up to directly reach the calls list Browse through the list and select an outgoing call entry**

Press to call Or press to select Call in the options

** Note : to be able to call back a correspondent in the case of an incoming call,you need to subscrible to the Caller Line Identification service.

http://www.philips.com/faqs/dect

Call log

To view the number

Scroll up to directly reach the calls list Browse through the list and select an entry Scroll to View number and select

To store the caller’s number

Scroll up to directly reach the calls list Browse through the list and select an entry

Scroll to Store and select Enter the name and press OK

To delete a name and a number

Scroll up to directly reach the calls list Browse through the list and select an entry Scroll to Delete and select

Press OK to confirm your choice

Warning:if a message is associated to the entry,it is also erased from the answer machine , whether it is read or not (DECT515 only).(see page 45)

To send an SMS from the call log

Scroll up to directly reach the calls list Browse through the list and select an entry

Scroll to Send SMS and select Select your SMS box* (only if you have created several SMS boxes).

To create a SMS box please refer to SMS settings page 25 Enter the password and press OK (optional)

Enter the Destination box* number (optional),press OK

* only available in the UK

Call log

http://www.philips.com/faqs/dect

Enter the text and press OK (see page 19) Press to select Send now

Note: once in the list of names, press to directly edit an SMS

Delete all

To delete all the call log

Press to enter the carousel menu Scroll to Call log and select

Scroll to Delete all and select Press to confirm OK

Note: entries with unread messages will also be deleted (DECT 515 only).

Call log settings

You can set the call log to store information about incoming calls and/or outgoing calls.

Press to enter the carousel menu Scroll to Call log and select

Scroll to Call log settings and select Press to select Incoming calls or scroll to Outgoing calls

and select

Browse through the options and select the one that suits you

http://www.philips.com/faqs/dect

Call log

* only available in the UK

Operator services

This feature allows you to activate or deactivate operator services that are subscription dependent. You need to set up codes (see page 56). Contact your network operator for more details.You can usually subscribe to Call forward, operator voice mailbox etc...

Example of service: Call forward

Calls can be redirected to another phone number. Set the code (see page 56) and activate it when necessary.

To activate call forward

Press to enter the carousel menu Scroll to Operator services and select

Press to select Call forward Enter or retrieve from the phonebook the number to which

the calls are to be forwarded and press OK The number is automatically chained to the call forward prefix

and the system dials the number. Hang up

From now on the calls will be redirected to the assigned phone number.

To deactivate call forward

Press to select View Press to select Cancel

Hang up

Operator services

http://www.philips.com/faqs/dect

Extra

Call duration Alarm clock Do Not Disturb mode

Call duration

Press to enter the carousel menu Scroll to Extra and select

Press to select Call duration The total communication time is displayed

Press to Reset the counter

Alarm clock

To set the alarm clock

Press to enter the carousel menu Scroll to Extra and select Scroll to Alarm clock and select

Scroll to Set day and select . Choose a day. Scroll to Set time and select Enter the time and press OK

When the alarm rings,press any key to stop it. The snooze is then activated (will ring again every 5 minutes). To definitely stop it press

To activate / deactivate the alarm clock

A long press on activates/deactivates the alarm clock with your own settings.

http://www.philips.com/faqs/dect

Extra

To set the alarm ring tone type and ring tone volume

Press to enter the carousel menu Scroll to Extra and select Scroll to Alarm clock and select Scroll to Settings and select

Press to select Ring tones Choose among the available ring tones and select

Scroll to Ring tone volume and select Choose among the available volume levels and select

Do not Disturb mode

This feature allows you to screen calls after a certain time in the evening or when you do not want to be disturbed.Enter the time and select the group(s) allowed to call you.If none of the 4 groups is selected but the feature is activated,then nobody will be able to reach you.If the caller does not belong to an allowed group,the handset and base station will remain silent,while the caller will hear ringing. The answer machine (if activated) or the operator voice mail (network dependent) will answer the call.The feature is deactivated by default. You need to subscribe to the Caller Line Identification service (CLI).

To set the Do not Disturb mode

Press to enter the carousel menu Scroll to Extra and select Scroll to Do not disturb mode and select Scroll to Set day and select the day and press Scroll to Start time,enter the time and press OK Scroll to Stop time,enter the time and press OK

Scroll to Allowed caller choice,activate the callers group(s) allowed to call you and select

Warning! only allowed callers will be able to reach you during the selected day & time

A long press on activates/deactivates this mode with your own settings.

Extra

http://www.philips.com/faqs/dect

Sounds

Handset ring tones Base ring tones Group ring tones Handset ring tone volume Base ring tone volume My ring tones*

Record personal melody Settings

Handset ring tones

To set the external ring tone

Press to enter the carousel Scroll to Sounds and select

Press to select Handset ring tones Press to select External ring tone

Browse through the list of ring tones and select one

To set the internal ring tone (ring tone for internal calls)

Press to enter the carousel Scroll to Sounds and select

Press to select Handset ring tones Scroll to Internal ring tone and select

Browse through the list of ring tones and select one

Base ring tones

Press to enter the carousel

only available for DECT 515

Scroll to Sounds and select Scroll to Base ring tones and select Browse through the list of ring tones and select one

http://www.philips.com/faqs/dect

Sounds

*only available in the UK

Group ring tones

To set the group ring tones

There are 3 groups of callers (see p 40 Group settings).You can associate 1 ring tone to a group.

Press to enter the carousel Scroll to Sounds and select

Scroll to Group ring tones and select Scroll through the 3 different groups and select one Browse through the list of ring tones and select

Handset ring tone volume

Press to enter the carousel Scroll to Sounds and select

Scroll to Handset ring tone vol. and select The current level is heard,browse through the levels to hear them Press to select the appropriate volume

Warning : We strongly advise to put the handset far from your ear when it is ringing.

Base ring tone volume

Press to enter the carousel Scroll to Sounds and select

Scroll to Base ring tone vol. and select

only available for DECT 515

The current level is heard,browse through the levels to hear them Press to select the appropriate volume

Sounds

http://www.philips.com/faqs/dect

My ring tones

This menu gives access to all available downloaded ring tones. These ring tones can be set on your handset or on your base station (only available for DECT 515 base station) (see page 22).You can store up to 3 downloaded ring tones.

only available in the UK

To rename a downloaded ring tone (set on handset or on base station)

Press to enter the carousel Scroll to Sounds and select

Scroll to My ring tones and select Press to select Handset or scroll to Base station and select

Browse through the list of downloaded ring tones and select Press to select Change name

To delete a downloaded ring tone

Press to enter the carousel Scroll to Sounds and select

Scroll to My ring tones and select Press to select Handset or scroll to Base station and select

Browse through the list of downloaded ring tones and select Scroll to Delete and select

Record personal melody

To play a recorded melody

Press to enter the carousel Scroll to Sounds and select

Scroll to Record pers. melody and select Press to select Play

To record a new melody

only available for DECT 515

Press to enter the carousel Scroll to Sounds and select

Scroll to Record pers. melody and select

http://www.philips.com/faqs/dect

Sounds

Scroll to Record new and select Press to start recording

To delete a recorded melody

Press to enter the carousel Scroll to Sounds and select

Scroll to Record pers. melody and select Scroll to Delele and select

Press OK to confirm

Settings

To set the base loudspeaker volume

Press to enter the carousel Scroll to Sounds and select

Scroll to Settings and select Press to select Base loudspeaker vol.

Press to select the appropriate volume

To set the earpiece tone

Press to enter the carousel Scroll to Sounds and select

Scroll to Settings and select Scroll to Earpiece tone and select

only available for DECT 515

Browse through the options and select the appropriate setting

Sounds

http://www.philips.com/faqs/dect

To set the key & feedback tones

Press to enter the carousel Scroll to Sounds and select

Scroll to Settings and select Scroll to Key & feedback tones and select Press to select ON or scroll to OFF and select

To set the notification beep

Press to enter the carousel Scroll to Sounds and select

Scroll to Settings and select Scroll to Notification beep and select

Press to select ON or scroll to OFF and select

To activate/deactivate the music on hold

The feature allows the caller to hear music when the call is put on hold when transferring a call from one handset to the other.

Press to enter the carousel Scroll to Sounds and select

Scroll to Settings and select Scroll to Music on hold and select

Press to select ON or scroll to OFF and select

http://www.philips.com/faqs/dect

Sounds

Base station

Enable registration Line settings Service code settings

Enable registration

This feature allows you to register a DECT peripheral without keypad.Some DECT peripherals, such as repeaters,do not have any keypad.A special menu-operated procedure is used to register such peripherals to the base station.Also use the peripheral instructions to register it to the base

To register a DECT peripheral

Press to enter the carousel menu Scroll to Base station and select

Press to select Enable registration Enter the peripheral code (RC code) and press OK

Follow the instructions in the peripheral manual

Line settings

To change the dial mode

Press to enter the carousel menu Scroll to Base station and select

Scroll to Line settings and select Press to select Dial mode

Press to select Tone or scroll to Pulse and select

Note:this setting allows you to select pulse dialling (also called “Loop disconnect” and used in countries without DTMF tone dialling capability or using old PABX)

Base station

http://www.philips.com/faqs/dect

To change the recall type

Press to enter the carousel menu Scroll to Base station and select Scroll to Line settings and select Scroll to Recall type and select

Press to select Short flash or scroll to Long flash and select

Note:this setting is useful when using operator services.The use of some ser vices accessed with

+1, +2 and +3 (call waiting,call forward...) will depend on the flash setting (short/long)

according to your installation type (ISDN,Public,PABX).

To change the configuration

Press to enter the carousel menu Scroll to Base station and select Scroll to Line settings and select Scroll to Choose country/oper. and select Browse through the countries and select the

appropriate one. Browse through the operator type and select the

appropriate one.

To activate and deactivate the first ring

To prevent the phone from ringing when receiving an SMS,the first ring tone is deactivated.You can activate it.

Press to enter the carousel menu Scroll to Base station and select Scroll to Line settings and select Scroll to First ring and select Choose between ON or OFF and select

http://www.philips.com/faqs/dect

Base station

Service code settings

When you subscribe to extra services with your operator you may need to set some codes in your phone.The default codes are the codes used by the main national operator. If you subscribed to another operator you may need to change the codes. Contact your network operator for more information on the ser vices.

Press to enter the carousel menu Scroll to Base station and select Scroll to Service code settings and select

Browse the list of services and select Enter the code and press OK

Base station

http://www.philips.com/faqs/dect

FAQ

1/ I have no dialling tone after having installed my phone.How do I solve this problem? Check that you have connected your phone using the supplied line cable and not the one from any previous phone (they are often wired differently). Check that you have fully charged the handset according to the instructions given for the phone. Check that the aerial icon (radio link with the base station) is displayed.If the handset is not registered you may need to register it (see p.28).

2/ Can the handset be left on the base all the time? Yes there is no “memory effect”.The handset can be left on the base station for all current models using NiMh batteries.

3/ Will my phone lose all recorded data (phonebooks entries,recorded messages) in the case of a

general power cut?

No it will not. The data recorded in your phone is not deleted in the case of a general power failure or when you unplug your base station or when you replace the batteries.

4/ I have set up the date & time on my phone and the information given after a call is not correct.

Why?

If you have a ISDN phone installation, these parameters (date & time) may be transferred directly through the ISDN to the phone. If you did not set-up the ISDN correctly this can explain why the information transmitted is not correct.Set-up the date & time directly on the ISDN phone installation or, if this is not possible, call the Operator/dealer who provided and installed the ISDN.

5/ I cannot use the answering machine of my Philips phone together with my Fax plugged into the

same line, why is this?

To avoid this,it is recommended to set up the number of rings before the answering machine switches on. Example:if the network mail box or a fax is set to answer the calls after 4 rings,please set up your answering machine on 3 rings. To set up the number of rings, please see p 34.

6/ What is CLI and how do I make it work? CLI stands for Caller Line Identification and it is a special service that you may subscribe to from your network operator. Once you have subscribed to the service,a CLI enabled phone will display the callers number (unless withheld) as the phone rings so that you may decide whether or not to take the call.

7/ The CLI service does not work on my Philips phone, on my digital phone installation (ISDN,

ADSL). How do I solve this problem?

Our products are designed to work on an analogue network.If you plugged your PHILIPS phone into a digital installation,the CLI may not be displayed upon incoming calls. Digital phone installations (ISDN) are not always compatible with analogue phones as far as operator services are concerned. You may find the information regarding compatibility in the user guide of your ISDN.If not,please contact the ISDN manufacturer to check if the device is designed to display CLI on analogue phones. ISDN over 2 or 3 years old are generally not compatible with analogue phones for the CLI Service.

Note that the filters used with some ADSL lines can filter out part of the CLI signal and prevent the phone from displaying CLI correctly. It is possible to purchase better ADSL filters that do not cause this problem.

http://www.philips.com/faqs/dect

FAQ

8/What is CNIP (Caller Name Identification)? As with the CLI service this new feature is dependent on the Network and it has to be activated by your Operator (by subscription).It will allow you to have the name of the caller displayed upon an incoming call. This service may not be available from all Operators yet.We advise you to check with your Operator. NB.If the name of the caller is registered in your phonebook upon an incoming call it will be the name you have registered which will be displayed and not the one provided by the Operator.The data in your phonebook will have priority over the Operator’s data in this particular case . The CNIP uses the same technology as for the CLI.Therefore the limits of this service are identical (please refer to the questions related to CLI if the service is not working properly).Remember that it only works with alphanumeric display.

9/ How many telephones can I have? All items of telephone equipment have Ringtone Equivalence Number* (REN),which is used to calculate the number of items which may be connected to any one telephone line. Your DECT 511/515 has a REN of 1.A total REN of 4 is allowed, if the total REN of 4 is exceeded, the telephones may not ring. With different telephone types there is no guarantee of ringing,even when the REN is less than 4.

10/ My answering machine does not record the messages left by my correspondents.How do I

solve this problem?

Check the operator voice mail box is not activated.If it is activated,set the answering machine so that it starts recording first (set up the number of rings before the answering machine switches on).

11/ Which are the conditions required to be able to send an SMS ? You must first have a subscription to Caller Display (CLI) service from your network operator as well as an SMS service subscription from the appropriate provider.

12/ Is it possible to write, read send or receive an SMS when the other handset is in communica-

tion (DECT 511 and DECT 515 multi-handset packs only)?

No it is not possible. 13/ What happens if I send an SMS to a fixed line with no SMS phone ?

The correspondent could receive a vocal message (SMS provider dependent). 14/ Is it possible to send an SMS to a fixed line in another country ?

This feature depends on your provider.Please contact your provider for more details. 15/ How can I get the SMS centre number ?

One SMS centre number at least is pre-programmed in your DECT 511/DECT 515. However,should you need to store another number,other numbers can be set into the phone from the menu SMS/SMS Settings/SMS centre.Please check the incoming and outgoing centre numbers with the SMS provider or from the enclosed

addendum to your phone user manual. 16/ What is the destination box* useful for ?

This is the number of a personal SMS box.It is a way to send an SMS to someone’s personal box instead of sending it to the default box,which is a kind of common box.If you send an SMS without specifying an SMS box number (destination box),then the SMS will be sent to the default box if the receiver’s phone deals with multiboxes features (provider dependent).

17/ When using my SMS-enabled Philips phone with another SMS-enabled phone on the same

line, can it cause any problems ?

Yes,this will prevent the phones from receiving SMS.You need to deactivate the SMS feature on one of the phones.Your DECT 511/DECT 515 has a feature which enables you to turn the SMS feature off.Go to menu

SMS/SMS Settings/Mode/OFF

* only available in the UK

FAQ

http://www.philips.com/faqs/dect

Troubleshooting

Telephone troubleshooting

www.philips.com/support

PROBLEMS

The icon does not scroll when the handset is

placed on the base No dialling tone

No ring tone

The icon does not appear

CAUSES

- Bad battery contact

- Dirty contact

- Battery is full

- No power

- Batteries are empty

- You are too far from the base station

- Wrong cable

- Line adaptor not plugged to the line cord

- The ring tone is deactivated

- The Do not Disturb mode is ON

- No mains power

- The handset is too far from the base station

SOLUTIONS

- Move the handset slightly

- Clean the contact with a cloth moistened with alcohol

- No need to charge

- Check the connections.Reset the phone :unplug and plug back in the mains

- Charge the batteries at least 24 hours

- Move closer to the base station

- Always use the cable provided

- Plug the line adaptor to the line cord

- Increase the volume (page 50)

- Deactivate it (page 48)

- Check connections

- Move closer to the base station

The icon is blinking

- Crackling on the line

The handset displays ‘not available’

- when attempting to add

another handset to the base station

- when using a handset

Noise interference on your radio or television

- Handset not registered to the base station

- You are too far from the base station

- The base station is too close to electrical appliances,reinforced concrete walls or metal doorframes

- The procedure to add a handset has failed,try again

- Maximum number of handsets (6) has been reached

- Base station is already busy with another handset (ie :phonebook)

The DECT 511/515 base station or mains power pack are too close to electrical appliances

- Register the handset to the base (page 28)

- Move closer to the base station

- Move the base station to find a better place (the higher the better)

- Disconnect and connect the base station power supply.Follow the procedure to register a handset (page 28)

- Un-register a handset

- Wait until it is available

Move the power pack or base station as far as possible

Caller Line Identification (CLI) service does not work

http://www.philips.com/faqs/dect

- The service is not activated

Troubleshooting

- Check your subscription with your network operator

PROBLEMS CAUSES SOLUTIONS

A phonebook entry cannot be memorised

No new SMS are received

No SMS can be sent or received

No caller Id/ poor audio quality/Poor connection quality with broadband DSL internet

The phonebook is full

- SMS memory is full

- The SMS mode is deactivated

- The outgoing or incoming SMSC number is not set or is wrong

- The destination box* is wrong

- SMS mode is OFF

- You have no subscription

- Another SMS-enabled phone is also on your line

- There is a problem of compatibility between operators

- The identity is withheld

- DSL filter(s)/splitter missing or insufficient number of filters

- Modem &/or phone plugged in the wrong DSL filter slot

- Defective DSL filter(s)

Delete an entry to free memory

- Delete old SMS

- Activate it (p 25)

- Refer to the SMS leaflet to get the correct SMSC’s numbers

- See point 16 page 58

- Activate SMS mode (page 25)

- Contact your provider for more information

- Deactivate the SMS mode on one of the device.

- Contact your provider for more information

- Show identity

- Make sure you have one DSL filter plugged directly on each line socket used in the house

- Check the modem and the phone are plugged in the correct filter slot (one specific for each)

- The filter(s) can be defective. Replace it/them and make another test

only available in the UK

Answer machine troubleshooting

PROBLEMS CAUSES

The answer machine does not record messages

- The memory is full

-The answer only mode is activated

- The Answer & record is not activated

The remote control access does not work

It is not possible to record an

The remote control access is not activated

The memory is full

outgoing message The DECT 515 hangs up during

remote access The answer machine stops

automatically

- 3 failed attempts to send a code

- Duration is too long

- The memory is full

- Message exceeds 3 mn

SOLUTIONS

- Delete messages

- Select the Answer & record mode

- Press

Activate the remote control access (page 35)

Delete messages

- Enter the correct code

- Manage the remote control quick er

- Play & delete messages

- Messages must not exceed 3 mn

Troubleshooting

http://www.philips.com/faqs/dect

Index

Add new (phonebook) 40 Alarm clock 47 Answer a call 1,17 Answer machine settings 33

Babysit mode 28,39 Base keys 4 Base installation 15 Batteries & battery life 15

Call duration 47 Call forward 46 Call log settings 45 Call transfer 38 Call screening 35 Change name 40 Change number 41 Choose country/operator 55 Conference call 39 Conformity 12 Copy to phonebook 24

Date and time 29 Declaration of conformity 13 Define groups 42 Delete all (call log) 45 Delete call log entry 44 Delete an entry (phonebook) 42 Delete an SMS 24 Destination box 58 (n°16) Dial mode 54 Display contrast 30 Do Not Disturb mode 48

Earpiece tone 52 Edition mode 19 Enable regisration (DECT peripheral) 54

FAQ 57 First ring 55 Forward SMS 23

GAP 13 Groups 40,50

Make calls 17,25, 41, 43 Music on hold 53 Mute 18

Navigation in menus 16 Notification beeps 53

Outgoing messages 33

PABX/PSTN 54 Phonebook 40 Predial 17 Pulse 54

Range 15 Read SMS 22 Recall type 55 Recording quality 35 Record conversation 18 Record a memo 37 Record personal melody 51 Recording personal outgoing message 33 Redial 17 Register handset 28 Remote access to answer machine 36 Remote control code (answer machine) 36 Rename handset 29 Ring tone type (alarm) 48 Ring tone volume (alarm) 48 Rings before answering (Answer machine) 34

Screening calls 35 Screen saver 16,30 Send new SMS 21 Send SMS (from phonebook) 42 Send SMS (from call log) 44 Service codes settings 56 SMS box 25 SMS centre 26,27 SMS mode 25 SMS settings 25

Handset keys 2 Handset ring tones 49

Idle mode 16 Intercom 18,38

Key & feedback tones 53 Keypad lock/unlock 2

Line settings 54 Listening to messages (Answer machine) 31 Local message (Memo) 37 Loudspeaker 2,18

Toll saver (Answer machine) 34 Tone 54

Unpacking your DECT 511/515 14 Unregister handset 28

View the call log 43 Voice language 34 Volume (earpiece) 18 Volume (ring tone) 50

IRL

3111 285 21872

Printed in Romania 3111 285 22232

Text messaging in the UK see overleaf

INFORMATION ON TEXT MESSAGING (SMS) IN EIRE

SMS and Caller Display disclaimer :The Short Message Service and Caller Display features of your

telephone terminal are network operator dependent.The terminal can provide them only if the network offers such features and if the user has subscribed to these features.Your phone has been carefully developed and tested according to the latest version of the SMS and CLI standards, and is up to date at the time of product release. However, Philips cannot take any responsibility and cannot guarantee the interoperability with the operator’s network in case of standard modification, network modification and/or of incomplete or inaccurate implementation of the standard by the network’s operator.

You must first subscribe to your network provider’s Caller Display service. Example : call EIRCOM free 1901.

Registration to SMS service is done by sending your first SMS.

The network SMS centre numbers are automatically set in your phone on SMS Centre 1: Send SMS service number (Outgoing number) : 1740 9900 Receive SMS service number (Incoming number) : 0818 365 135 Contact your network provider for more information.

WARNING ! Change the operator type in your phone : Go to Base station menu and select Line Settings sub menu.

Select the Choose country/oper. sub menu and choose the appropriate setting among the list (for example: Eircom).

Please refer to your phone user manual.

SMS and Caller Display subscription : The way to subscribe to and to connect to the Short Message Service (SMS) as well as the SMS function may be operator dependent and may vary in time. Please contact your network operator for more information.The following information is believed to be exact at the time of writing. It is provided for guidance only and does not guarantee accuracy over time.

There is a charge for sending SMS text messages (contact your network provider for more information).

REMINDER ! If there are two SMS- enabled phones on your telephone line, you will have to deactivate the SMS feature on

one of the devices.

Feuillet SMS UK_05_07_04_index2.qxd 13/07/04 11:45 Page 1

INFORMATION ON TEXT MESSAGING (SMS) IN THE UK

You must first subscribe to your network provider’s Caller Display service.

Registration to the SMS service is done by sending your first SMS.

There is a charge for sending SMS text messages (Contact your network operator for more information).

SMS and Caller Display disclaimer :The Short Message Service and Caller Display features of the telephone terminal are network operator dependent.The terminal can provide them only if the network offers such features and if the user has subscribed to these features.Your phone has been carefully developed and tested according to the latest version of the SMS and CLI standards, and is up to date at the time of product release. However, Philips cannot take any responsibility and cannot guarantee the interoperability with the operator’s network in case of standard modification, network modification and/or of incomplete or inaccurate implementation of the standard by the network’s operator.

SENDING SMS FROM A FIXED LINE TO A FIXED LINE : follow instructions in the user guide.

SENDING SMS FROM A FIXED LINE TO A MOBILE : follow instructions in the user guide.

Warning : When sending an SMS to a mobile phone, do not enter any destination box as your SMS will not be delivered.

USING DESTINATION BOX ON YOUR PHONE (not available on DECT 311) :

In order to receive an SMS in a specific SMS box, you must have previously sent at least one SMS from this box.

SMS and Caller Display subscription : The way to subscribe to and to connect to the Short Message Service (SMS) as well as the SMS function may be operator dependent, and may vary in time. Please contact British Telecom for more information.The following information is believed to be exact at the time of writing. It is provided for guidance only and does not guarantee accuracy over time.

REMINDER ! If there are two SMS- enabled phones on your telephone line, you will have to deactivate the SMS feature on

one of the devices.

By default, your phone is set with the SMS centre 1 (British Telecom). If you change this setting, the SMS service may not work.

Feuillet SMS UK_05_07_04_index2.qxd 13/07/04 11:45 Page 2

The download of ring tones and outgoing messages (only available in the UK and depending on the network technical availability)

To personalise your cordless telephone, there is nothing better than a melody and a message of your choice! Simply call 0906 666 0788 and that's it!

The download of ring tones

First of all you must subscribe to the SMS function with your network provider (see SMS leaflet).

Just call 0906 666 0788 and follow the instructions!

You have chosen your ring tone? You are about to receive it by SMS.Then you will be able to download it on your telephone (see “SMS” chapter in the user manual, part “Read SMS/To save a ring tone”). Be careful, only three downloaded ring tones can be saved! If you wish to download another ring tone, you will have to delete one of them from "My ring tones" list (see “SOUNDS” chapter in the user manual, part “My ring tones/To delete a ring tone”).

The download of outgoing messages (only available on DECT phones with answer machines).

By default, your answer machine is switched on.You have to change its settings to the "Answer and Record with personalised OGM" mode (refer to “ANSWER MACHINE” chapter in the user manual, part “Settings/To record your personal outgoing message”).These two conditions are necessary to receive your message. Be careful! On the “Answer and Record with personalised OGM” mode, recording a new message will automatically delete the previous one. Before downloading an outgoing message, make sure your answer machine is not full.

Keep in mind your Remote Control code (RC) written under your base station (see the “ANSWER MACHINE” chapter in the user manual, part “Settings/To change the remote control code”).

Just call 0906 666 0788 and follow the instructions!

Remember to free the line. Do not answer the next call and wait for your answer machine to record the message.

You can choose to welcome all the callers with this message or only the group of your choice. In this case, you must previously subscribe to the Caller Display Service offered by your network provider.

Printed in Romania

3111 285 22324

Philips DECT5152S/07, DECT5153S/07, DECT5112S/07, DECT5111S, DECT5112S User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
