Philips DCM3060/79 user manual

Register your product and get support at

www.philips.com/welcome

DCM3060

User manual

Contents

1 Important 4

Safety 4
Notice 5

2 Your product 7

Introduction 7
What's in the box 7
Overview of the main unit 8
Overview of the remote control 9

3 Get started 11

Placement 11
Prepare the remote control 11
Connect FM antenna 11
Connect power 11
Auto install radio stations 12
Set clock 12
Turn on 12

4 Play 13

Play disc 13
Play from USB 13
Pause/resume play 13
Skip to a track 13
Search within a track 13
Display play information 13

Repeat and shufe play 13

Program tracks 14

7 Play iPod/iPhone/iPad 16

Compatible iPod/iPhone/iPad 16
Load the iPod/iPhone/iPad 16
Listen to the iPod/iPhone/iPad 16
Charge the iPod/iPhone/iPad 16

8 Other features 17

Set the alarm timer 17
Set the sleep timer 17
Play from an external device 17
Headphone 17

9 Product information 18

Specications 18

USB playability information 18
Supported MP3 disc formats 19
Maintenance 19

10 Troubleshooting 20

5 Adjust sound 14

Adjust volume 14
Select a preset sound effect 14
Enhance bass 14
Mute sound 14

6 Listen to radio 15

Tune to a radio station 15
Program radio stations automatically 15
Program radio stations manually 15
Select a preset radio station 15
FM stations with RDS 15

3EN

1 Important

Safety

This 'bolt of lightning' indicates uninsulated
material within your unit may cause an electrical
shock. For the safety of everyone in your
household, please do not remove product
covering.
The 'exclamation point' calls attention to
features for which you should read the enclosed
literature closely to prevent operating and
maintenance problems.

WARNING: To reduce the risk of re or electric

shock, this apparatus should not be exposed to

rain or moisture and objects lled with liquids,

such as vases, should not be placed on this
apparatus.
CAUTION: To prevent electric shock, match
wide blade of plug to wide slot, fully insert.

Important Safety Instructions

a Read these instructions.
b Keep these instructions.
c Heed all warnings.
d Follow all instructions.
e Do not use this apparatus near water.

f Clean only with dry cloth.
g Do not block any ventilation openings.

Install in accordance with the
manufacturer's instructions.

h Do not install near any heat sources such

as radiators, heat registers, stoves, or

other apparatus (including ampliers) that

produce heat.

i Protect the power cord from being

walked on or pinched, particularly at
plugs, convenience receptacles, and the
point where they exit from the apparatus.

j Only use attachments/accessories

specied by the manufacturer.

k Use only with the cart, stand, tripod,

bracket, or table specied by the

manufacturer or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.

l Unplug this apparatus during lightning

storms or when unused for long periods
of time.

m Refer all servicing to qualied service

personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.

n Battery usage CAUTION – To prevent

battery leakage which may result in bodily
injury, property damage, or damage to
the unit:

4 EN

• Install all batteries correctly, + and - as
marked on the unit.

• Do not mix batteries (old and new or
carbon and alkaline, etc.).

• Remove batteries when the unit is not
used for a long time.

• Batteries (battery pack or batteries
installed) shall not be exposed to

excessive heat such as sunshine, re or

the like.

o Apparatus shall not be exposed to

dripping or splashing.

p Do not place any sources of danger on

the apparatus (e.g. liquid lled objects,
lighted candles).

q Where the MAINS plug or an appliance

coupler is used as the disconnect device,
the disconnect device shall remain readily
operable.

Warning

•

Never remove the casing of this apparatus.

• Never lubricate any part of this apparatus.

• Never place this apparatus on other electrical

equipment.

• Keep this apparatus away from direct sunlight, naked

ames or heat.

• Never look into the laser beam inside this apparatus.

• Ensure that you always have easy access to the power

cord, plug or adaptor to disconnect this apparatus from
the power.

Note

The type plate is located at the rear of the apparatus.

•

higher decibel ranges are offered for those
that may have already experienced some
hearing loss.

• Sound can be deceiving. Over time your
hearing 'comfort level' adapts to higher
volumes of sound. So after prolonged
listening, what sounds 'normal' can actually
be loud and harmful to your hearing. To
guard against this, set your volume to a safe
level before your hearing adapts and leave
it there.

To establish a safe volume level:

• Set your volume control at a low setting.

• Slowly increase the sound until you can

hear it comfortably and clearly, without
distortion.

Listen for reasonable periods of time:

• Prolonged exposure to sound, even
at normally 'safe' levels, can also cause
hearing loss.

• Be sure to use your equipment reasonably

and take appropriate breaks.

Be sure to observe the following guidelines
when using your headphones.

• Listen at reasonable volumes for
reasonable periods of time.

• Be careful not to adjust the volume as your
hearing adapts.

• Do not turn up the volume so high that
you can't hear what's around you.

• You should use caution or temporarily
discontinue use in potentially hazardous
situations. Do not use headphones while
operating a motorized vehicle, cycling,

skateboarding, etc.; it may create a trafc

hazard and is illegal in many areas.

Hearing safety

Listen at a moderate volume.

• Using headphones at a high volume can
impair your hearing. This product can
produce sounds in decibel ranges that may
cause hearing loss for a normal person,
even for exposure less than a minute. The

Notice

Any changes or modications made to this

device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s

authority to operate the equipment.

5EN

Your product is designed and manufactured

with high quality materials and components,

which can be recycled and reused.

When this crossed-out wheeled bin symbol is
attached to a product it means that the product
is covered by the European Directive 2002/96/
EC.
Please inform yourself about the local separate
collection system for electrical and electronic
products.
Please act according to your local rules and
do not dispose of your old products with your
normal household waste. Correct disposal of
your old product helps to prevent potential

negative consequences for the environment and

human health.

Your product contains batteries covered by
the European Directive 2006/66/EC, which
cannot be disposed with normal household
waste.Please inform yourself about the local
rules on separate collection of batteries
because correct disposal helps to prevent

negative consequences for the environmental

and human health.

Environmental information

All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old

equipment.

The making of unauthorized copies of copy­protected material, including computer

programs, les, broadcasts and sound

recordings, may be an infringement of
copyrights and constitute a criminal offence.

This equipment should not be used for such

purposes.

“Made for iPod,” “Made for iPhone,” and “Made
for iPad” mean that an electronic accessory

has been designed to connect specically to

iPod, iPhone, or iPad, respectively, and has

been certied by the developer to meet

Apple performance standards. Apple is not
responsible for the operation of this device
or its compliance with safety and regulatory
standards. Please note that the use of this
accessory with iPod, iPhone, or iPad may affect
wireless performance.
iPad, iPhone, iPod, iPod nano, and iPod touch are
trademarks of Apple Inc., registered in the U.S.
and other countries.

Windows Media and the Windows logo
are trademarks, or registered trademarks of
Microsoft Corporation in the United States
and/or other countries.

This apparatus includes this label:

6 EN

2 Your product

Congratulations on your purchase, and

welcome to Philips! To fully benet from the

support that Philips offers, register your product
at www.philips.com/welcome.

Introduction

With this unit, you can enjoy audio from discs,
iPod/iPhone/iPad, USB devices, and other
external devices, or listen to radio stations.
The unit offers Digital Sound Control (DSC)
and Dynamic Bass Boost (DBB) to enrich
sound.
The unit supports the following media formats:

What's in the box

Check and identify the contents of your
package:

• Main unit

• Remote control and 2 batteries

• FM antenna

• 1 x MP3 link cable

• Quick start guide

• User manual

• Wall mounting instructions

• Mounting kit (2 dowels and 2 screws)

7EN

Overview of the main unit

FM ANT

lmn

-

MP

LINK

3

h

i

j

d

e

f

g

o

a

• Turn on the unit, or switch to standby

mode, or switch to Eco Power standby.

b SOURCE

• Select a source: CD, FM radio, iPod/

iPhone/iPad, USB, or MP3 link.

c

/

• Skip to the previous/next track.

• Search within a track.

• Tune to a radio station.

d

/OK

• Start or pause play.

• Conrm a selection.

e

/MENU

• Stop play.

• Access the iPod/iPhone/iPad menu.

f VOLUME + / -

• Adjust volume.

g

• Open/close the disc compartment.

h Display panel

• Show current status.

i Disc compartment door
j Dock for iPod/iPhone/iPad

k

k Remote sensor

• Detect signal from the remote control.

l

• Connector for a headphone.

m

• Connector for a USB mass storage
device.

n MP3 LINK

• Connector (3.5mm ) for an external
audio device.

o FM ANT

• Connect an FM antenna for reception
improvement.

8 EN

Overview of the remote control

a

b

c

d

e

f
g
h

i

j

k
l

CD

PRESET/ALBUM

OK

3

LINK

MP

USB

DISPLAY

RDS

VOL

1

456

789

PROG/

CLOCK SET

SLEEP/
TIMER

2

0

DSCDBB

DOCK

MENU

3

REPEAT/

SHUFFLE

FM

a

• Turn on the unit, or switch to standby
mode, or switch to Eco Power standby.

b

• Mute or restore volume.

s
r

q

p

o

n

m

c CD

• Select disc source.

d

/

• Skip to the previous/next track.

• Search within a track.

• Tune to a radio station.

e USB/MP3 LINK

• Select USB device source.

• Select external audio device source.

f RDS/DISPLAY

• Select RDS broadcast information.

• Select display information during play.

g

• Start or pause play.

h VOL +/-

• Adjust volume.

i Numeric keypad

• Select a track from a disc directly.

j PROG/CLOCK SET

• Program tracks.

• Program radio stations.

• Set the clock.

k SLEEP/TIMER

• Set the sleep timer.

• Set the alarm timer.

l DSC

• Select a preset sound setting.

m DBB

• Turn on or off dynamic bass
enhancement.

n REPEAT/SHUFFLE

• Play a track or all tracks repeatedly.

• Play tracks randomly.

o

/MENU

• Stop play.

• Access the iPod/iPhone/iPad menu.

p DOCK

• Select iPod/iPhone/iPad source.

q OK

• Conrm a selection.

9EN

r PRESET/ALBUM /

• Skip to the previous/next album.

• Select a preset radio station.

• Navigate the iPod/iPhone/iPad menu.

s FM

• Select FM radio source.

10 EN

3 Get started

Caution

Use of controls or adjustments or performance of

•

procedures other than herein may result in hazardous
radiation exposure or other unsafe operation.

Always follow the instructions in this chapter in

sequence.

If you contact Philips, you will be asked for the
model and serial number of this apparatus. The
model number and serial number are on the
rear of the apparatus. Write the numbers here:
Model No. __________________________
Serial No. ___________________________

Placement

You can place the unit on a at surface or

mount the unit on a wall.

Note

If you are not going to use the remote control for a

•

long time, remove the batteries.

• Do not use old and new or different types of batteries

in combination.

• Batteries contain chemical substances, so they should

be disposed of properly.

Connect FM antenna

1

Connect the supplied FM antenna to the
FM connector on the back of the main
unit.

Mount on a wall

To wall mount the unit, see the included
separate sheet of wall mounting instructions.

Prepare the remote control

Caution

Risk of explosion! Keep batteries away from heat,

•

sunshine, or re. Never discard batteries in re.

To insert the remote control battery:

1 Open the battery compartment.
2 Insert 2 AAA batteries with correct

polarity (+/-) as indicated.

3 Close the battery compartment.

Connect power

Caution

Risk of product damage! Make sure that the power

•

supply voltage corresponds to the voltage printed on
the rear of the main unit.

• Before connecting the AC cord, make sure that you

have completed all other connections.

Note

The type plate is located on the rear of the main unit.

•

1 Connect the AC power cable to the AC

outlet.

11EN

Auto install radio stations

8 Press PROG/CLOCK SET to conrm.

When you connect power and no radio
stations are stored, the unit automatically begins
to store radio stations.

1 Connect the unit to the power supply.

» [AUTO INSTALL - PRESS PLAY

KEY](auto install - press play key) is

displayed.

2 Press on the main unit to star t

installation.

» The unit automatically stores radio

stations with sufcient signal strength.

» When all the available radio stations

are stored, the rst preset radio station

is broadcast automatically.

Set clock

Note

You can set the clock in standby mode only.

•

1 Press to switch the unit to standby.

• Make sure that --:-- (or clock) is
displayed (see "Turn on" > "Switch to
standby").

2 Press and hold PROG/CLOCK SET to

activate the clock setting mode.

» SET CLOCK is displayed.
» The 12 hour or 24 hour format is

displayed.

3 Press / to select 12 hour or 24

hour format.

4 Press PROG/CLOCK SET.

» The hour digits begin to blink.

5 Press / to set the hour.
6 Press PROG/CLOCK SET.

» The minute digits begin to blink.

7 Press / to set the minute.

Turn on

1

Press .

» The unit switches to the last selected

source.

Switch to standby

1 When the unit is turned on, press to

switch the unit to standby.

• In standby, press and hold
from normal standby to Eco power
standby or vice versa.

» In normal standby, the clock (if set)

appears on the display panel.

» In Eco power standby, the backlight on

the display panel turns off.

to switch

12 EN

4 Play

Play disc

1

Press CD to select the disc source.

2 Press on the unit to open the disc

compartment.

3 Insert a disc with the printed side facing

outward, and then press
compartment.

4 If the disc doesn't play, press .

• To stop play, press

Play from USB

Note

Make sure that the USB storage device contains

•

playable audio content.

1 Connect the USB storage device into the

connector on the back panel of this

unit.

2 Press USB to select the USB source.

» Play starts automatically.

• To select a folder, press

• To select an audio le, press

• To star t play, press

• To stop play, press

Pause/resume play

1

During play, press to pause/resume
play.

to close the disc

.

.

/ .

.

.

Skip to a track

For CD:

1 Press / to select another track.

• To select a track directly, you can also
press a key on the numerical keypad.

For MP3 disc and USB:

1 Press to select an album or folder.
2 Press / to select previous/next track

or le.

Search within a track

1

During play, press and hold / .

2 Release to resume normal play.

Display play information

1

During play, press DISPLAY repeatedly to
select different play information.

Repeat and shufe play

1

During play, press REPEAT/SHUFFLE
repeatedly to select a play option.

•

: the current track is played

repeatedly.

•

•

: all the tracks are played

repeatedly.

: all tracks are played in a random

order.

2 To return to normal play, press REPEAT/

SHUFFLE repeatedly until no repeat/

shufe option is displayed.

• You may also press
shufe play.

to cancel repeat/

13EN

Tip

Shufe play is not available when programmed tracks

•

are played.

Program tracks

You can program a maximum of 20 tracks.

1 In CD/USB mode, in the stop position,

press PROG/CLOCK SET to activate the
program mode.

» [PROG] (program) and track number

begin to blink.

2 For MP3 tracks, press to select an

album.

3 Press / to select a track number,

then press PROG/CLOCK SET to conrm.

4 Repeat steps 2 to 3 to program more

tracks.

5 Press to play the programmed tracks.

» During play, [PROG] (program) is

displayed.

• To erase the program, in the stop
position, press

» [PROG] disappears on the display.

.

5 Adjust sound

Adjust volume

1

During play, press VOL +/- to increase/
decrease the volume.

Select a preset sound effect

1

During play, press DSC repeatedly to select
a preset sound setting.

Enhance bass

1

During play, press DBB to turn dynamic
bass enhancement on or off.

» If DBB is activated, DBB is displayed.

Mute sound

1

During play, press to mute/restore the
speakers.

14 EN

6 Listen to radio

Tune to a radio station

1

Press FM.

2 Press and hold / for more than 2

seconds.

» [SEARCH] (search) is displayed.
» The radio tunes to a station with

strong reception automatically.

3 Repeat step 2 to tune to more stations.

• To tune to a weak station, press

repeatedly until you nd optimal

reception.

Program radio stations manually

Note

You can program a maximum of 20 preset radio

•

stations.

1 Tune to a radio station.
2 Press PROG/CLOCK SET to activate

program mode.

» [PROG] (program) begins to blink.

3 Press to allocate a number (1 to 20)

to this radio station, and then press PROG/

/

CLOCK SET to conrm.

4 Repeat the previous steps to program

other stations.

Tip

Position the antenna as far as possible from TV, VCR, or

•

other radiation source.

• For optimal reception, fully extend and adjust the

position of the antenna.

Program radio stations automatically

You can program a maximum of 20 preset
radio stations (FM).

1 In FM mode, press and hold PROG/

CLOCK SET for more than 2 seconds to

activate automatic program mode.

» [AUTO] (auto) is displayed.
» All available stations are programmed.
» The rst programmed radio station is

broadcast automatically.

Note

To overwrite a programmed station, store another

•

station in its place.

Select a preset radio station

1

In FM mode, press to select a preset
number.

FM stations with RDS

Radio Data System (RDS) is a service that
sends additional broadcast information along
with FM stations.
If you listen to a FM station with RDS signal,
"RDS" is displayed.

Display RDS information

1 For a FM station with RDS, press RDS

repeatedly to display various broadcast
information.

15EN

7 Play iPod/

iPhone/iPad

You can enjoy audio from iPod/iPhone/iPad
through this unit.

Compatible iPod/iPhone/iPad

The unit supports the following iPod, iPhone
and iPad models.
Made for:
iPod touch (1st, 2nd, 3rd, and 4th generation)
iPod nano (1st, 2nd, 3rd, 4th, 5th, and 6th
generation)
iPhone 4
iPhone 3GS
iPhone 3G
iPhone
iPad 2
iPad

Load the iPod/iPhone/iPad

Listen to the iPod/iPhone/ iPad

1

Make sure that the iPod/iPhone/iPad is
correctly placed.

2 Press DOCK to select the iPod/iPhone/

iPad source.

3 Play music on the iPod/iPhone/iPad.

• To pause/resume play, press

• To skip to a track, press

• To search during play, press and hold

/ , and then release to resume

normal play.

• To navigate the menu, press MENU,
and press
then press OK to conrm.

to select an option, and

Charge the iPod/iPhone/iPad

.

/ .

1 Push the dock compartment to open it.
2 Place the iPod/iPhone/iPad in the dock.

Install the rubber pad

If necessary, install the supplied rubber pad to
keep the iPad/iPad 2 stable before you place
the iPad/iPad 2.

16 EN

When the unit is connected to power, the
docked iPod/iPhone/iPad begins to charge.

Note

The following iPod models cannot be charged: iPod

•

classic, iPod with video, and iPod with color display.

• In Eco power standby mode, charge is not available.

8 Other features

Set the alarm timer

This unit can be used as an alarm clock. The
disc/radio/USB/docked product is activated to
play at a preset time.

1 Make sure that you have set the clock

correctly.

2 Press to switch the unit to standby.

• Make sure that the clock is displayed
(see "Turn on" > "Switch to standby").

3 Press and hold SLEEP/TIMER.

» A prompt to select the source is

displayed.

4 Press CD, FM, USB or DOCK to select a

source.

5 Press SLEEP/TIMER to conrm.

» The clock digits are displayed and

begin to blink.

6 Press / to set the hour.
7 Press SLEEP/TIMER to conrm.
8 Press / to set the minute.

» The timer is set and activated.

To deactivate or re-activate an alarm timer

1 Press to switch to standby mode.
2 Press SLEEP/TIMER repeatedly to activate

or deactivate timer.

» If timer is activated, the display shows

.

» If timer is deactivated,

the display.

disappears on

Set the sleep timer

This unit can switch to standby automatically
after a set period of time.

1 When the unit is turned on, press SLEEP/

TIMER repeatedly to select a set period of

time (in minutes).

» When sleep timer is activated,

displayed.

To deactivate sleep timer

is

1 Press SLEEP/TIMER repeatedly until [OFF]

(off) is displayed.

» When sleep timer is deactivated,

disappears on the display.

Play from an external device

You can also listen to an external audio device
through this unit.

1 Press MP3 LINK to select the MP3 link

source.

2 Connect the supplied MP3 link cable to:

• the MP3 LINK connector (3.5mm) on
the unit.

• the headphone connector on an
external device.

3 Start to play the device (see the device's

user manual).

Headphone

Plug headphones (not supplied) into the
connector on the unit to listen through the
headphones.

Note

In MP3 link mode, the alarm timer cannot be set.

•

• If disc/USB/dock source is selected and the audio

cannot be played, tuner is activated automatically.

17EN

9 Product

information

Note

Product information is subject to change without prior

•

notice.

Specications

Amplier

Rated Output Power 2 x 20W RMS
Frequency Response 60 Hz - 16 kHz,

±3 dB
Signal to Noise Ratio >65dBA
MP3 link input 500mv, 20kohm

Tuner

Tuning Range FM: 87.5 - 108

MHz
Tuning grid 50 KHz
FM sensitivity

- Mono
Total Harmonic Distortion <2%
Signal to Noise Ratio >55 dB
Number of presets 20 (FM)

Speakers

Speaker Impedance 8 ohm
Speaker Driver 2 X 2.5" full range
Sensitivity >82 dB/m/W

26 dB

General information

AC power AC 100-240V~,

50/60 Hz

Operation Power
Consumption

Eco Standby Power
Consumption

USB Direct Version 2.0/1.1
Dimensions

- Main Unit
(W x H x D)

Weight

- Main Unit 2.614 kg

32 W

<1 W

500 x 217 x 98 mm

USB playability information

Compatible USB storage devices:

• USB ash memory (USB 2.0 or

USB1.1)

• USB ash players (USB 2.0 or USB1.1)

• memory cards (requires an additional

card reader to work with this system)

Supported formats:

• USB or memory le format FAT12,

FAT16, FAT32 (sector size: 512 bytes)

• MP3 bitrate (data rate): 32-320 Kbps
and variable bitrate

• Directory nesting up to a maximum of
8 levels

• Number of albums/ folders: maximum
99

• Number of tracks/titles: maximum 999

• ID3 tag v2.0 or later

• File name in Unicode UTF8 (maximum

length: 128 bytes)

Unsupported formats:

• Empty albums: an empty album is an
album that does not contain MP3 les,

and is not shown in the display.

• Unsupported le formats are skipped.

For example, Word documents (.doc)

18 EN

or MP3 les with extension .dlf are

ignored and not played.

• AAC, WAV, PCM audio les

• DRM protected WMA les (*.wav,
*.m4a, *.m4p, *.mp4, *.aac)

• WMA les in Lossless format

Supported MP3 disc formats

• ISO9660, Joliet

• Maximum title number: 999 (depending on
le name length)

• Maximum album number: 99

• Supported sampling frequencies: 32 kHz,

44.1kHz, 48 kHz

• Supported Bit-rates: 32~256 (kbps),
variable bit rates

Maintenance

Clean the cabinet

• Use a soft cloth slightly moistened with
a mild detergent solution. Do not use a
solution containing alcohol, spirits, ammonia
or abrasives.

Clean discs

• When a disc becomes dirty, clean it with
a cleaning cloth. Wipe the disc from the
centre out.

Clean the disc lens

• After prolonged use, dirt or dust may
accumulate at the disc lens. To ensure good

play quality, clean the disc lens with Philips

CD lens cleaner or any commercially
available cleaner. Follow the instructions
supplied with cleaner.

• Do not use solvents such as benzene,
thinner, commercially available cleaners,
or antistatic spray intended for analogue
records.

19EN

10 Troubleshooting

Warning

•

Never remove the casing of this apparatus.

To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
apparatus, check the following points before

requesting service. If the problem remains

unsolved, go to the Philips web site (www.
philips.com/welcome). When you contact
Philips, ensure that the apparatus is nearby
and the model number and serial number are
available.

No power

• Ensure that the AC power plug of the unit
is connected properly.

• Ensure that there is power at the AC
outlet.

• To save power, the unit switches to
standby automatically 15 minutes after
a play reaches the end and no control is
operated.

No sound

• Adjust the volume.

No response from the unit

• Disconnect and reconnect the AC power
plug, then turn on the unit again.

Remote control does not work

• Before pressing any function button, rst
select the correct source with the remote
control instead of the main unit.

• Reduce the distance between the remote
control and the unit.

• Insert the battery with its polarities (+/–
signs) aligned as indicated.

• Replace the battery.

• Aim the remote control directly at the
sensor on the front of the unit.

No disc detected

• Insert a disc.

• Check if the disc is inserted with the print
side facing inward.

• Wait until the moisture condensation at
the lens has cleared.

• Replace or clean the disc.

• Use a nalized CD or correct format disc.

Cannot display some les in USB device

• The number of folders or les in the USB
device has exceeded a certain limit. This
phenomenon is not a malfunction.

• The formats of these les are not
supported.

USB device not supported

• The USB device is incompatible with the
unit. Try another one.

Poor radio reception

• Increase the distance between the unit and
your TV or VCR.

• Fully extend and adjust the FM antenna.

Timer does not work

• Set the clock correctly.

• Switch on the timer.

Clock/timer setting erased

• Power has been interrupted or the power
cord has been disconnected.

• Reset the clock/timer.

20 EN

August 2011

Philips Electronics Australia Limited and Philips New Zealand Limited

Level 1, 65 Epping Rd, Level 2, 1 Nugent St,
North R yde, SYDNEY NSW 2113 Grafton, AUCKLAND, 1

In this warranty:
We or us means Philips Electronics Australia Limited ACN 008 445 743 or Philips New Zealand Limited (Company

Number 1723), and our contact details are set out at the end of this warranty;

You means the purchaser or the original end-user of the Goo ds;
Supplier means the authorised distributor or retailer of the Goods that sold you the Goods in Australia or New

Zealand; and
Goods means the product or equipment w hich was accompanied by this warranty and purchased in Australia or New

Zealand.
If you require a ssistance with the operation of t he product, its features or specifications please call the Philips

Consumer Care Centre on 1300 363 391 in Australia or 0800 658 224 in New Zealand.

: Our Goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are

Australia

entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss
or damage. You are also entitled to have the Goods repaired or replaced if the goods fail to be of acceptable quality
and the failure does not amount to a major failure. This is not a complete statement of your leg al rights as a consumer.

New Zealand:

This guarantee applies in addition to the conditions and guarantees implied by that legislation.

Additional Warranty:

In addition to the rights and remedies that you have under the Australian Consumer Law, Consumer Guarantees Act
of New Zealand or any other applicable law, we provide the following warranty against defects:

1. If, during the first 12 months from their date of purchase from the Supplier (Warranty Period), the Goods pro ve

2. We do not have to repair or replace the Goods under this Additional Warranty if the Goods have been used for a

3. Even when we do not have to repair or replace the Goods, we ma y decide to do so anyway. In some cases, we

4. All such repaired, replaced or substituted Goods continue to receive the benefit of this Additional Warranty for the

5. This Additional Warranty is limited to repair, replacement or substitution only. As far as the law permits, we will not

6. In order to claim under this Additional W arranty you must telephone us on 1300 363 391 in Australia or 0800 658

∗ All returned Goods must be accompanied by satisfactory proof of purchase which clearly indicates the name and

∗ You must bear any expense for return of the Goods or otherwise associated with making your claim unde r this

7. This warranty is only valid and enforceable in Australia and New Zealand.

Contact us or the place of purchase for further details.

Philips Electronics Australia Limited Philips New Zealand Limited

Consumer Care: 1300 363 391 Consumer Care: 0800 658 224
E-mail: pceinfo.australia @philips.com
Website: www.philips.com/support Website: www.philips.com/support

Our Goods come with guarantees that cannot be ex cluded under the Consumer Guarantees Act 1993.

defective by reason of improper workmanship or materials and none of your statutory rights or remedies apply, we
will repair or replace the Goods without charge.

commercial purpose; misused, improperly or inappro priately installed, operated or repaired; abused; damaged; or
not maintained in accordance with the manuf acturer’s instructions.

may decide to substitut e the Goods with a similar alternative product of our choosing. All such decisions are at
our absolute discretion.

time remaining on the original Warranty Period.

be liable for any loss or damage caused to property or persons arising from any cause whatsoever.

224 in New Zealand within the Warranty Period. You will be ask ed for details of the Goods, a description of the
defect and your personal details. Upon accepting your claim, we shall assist you with either returning the Goods to
the Supplier for replacement or to the most convenient Philips Authorised Service Centre for your Goods to be
repaired. In some case we may require that you return to the Goods to us (at the address below) for repair,
replacement or substitution.

address of the Supplier, the date and place of purchase and identifies product. It is best to provide a legible and
unmodified receipt or sales invoice.

Additional Warr anty.

Warranty against Defects

023

Email: [email protected]

21EN

Specifications are subject to change without notice
© 2012 Koninklijke Philips Electronics N.V.
All rights reserved.

DCM3060_79_UM_V1.1
