Page 1
Philips
Docking Entertainment
System with Dynamic Bass
Boost
Plays MP3/WMA-CD
USB Direct
DCM230
Enjoy iPod music in Hi-Fi
sound quality
Free your iPod music and enjoy it in superb sound on the Philips DCM230. Stylishly
designed with a cool metallic finish, the sleek system features smart functions and boasts
total 30 W RMS power for truly dynamic sound.
Play your iPod content out loud at home
• Play and charge your iPod simultaneously
• USB Direct connection for portable USB MP3 players
• Play MP3/WMA-CD, CD and CD-RW
• Digital tuning for station presets
Rich and clear sound
• Dynamic Bass Boost for deep and dramatic sound
• Digital Sound Control for optimised music style settings
• 2 x 15 W RMS/30 W Total power
Design that blends into your interior
• Stylish desktop design with high-end metallic front panel
• Elegant design with super-slim CD slot
• Single remote control for the system and iPod
Page 2
DCM230/05
Docking Entertainment System
Plays MP3/WMA-CD USB Direct
Highlights
Play and charge your iPod
Enjoy your favourite MP3 music while charging
your iPod!
iPod directly to the Docking entertainment
system so you can listen to your favourite
music in superb quality. It also charges your
iPod while it plays so you can enjoy your music
and not have to worry about your iPod battery
running out. Use the remote control to
navigate, select and playback the music stored
on your iPod. The Docking entertainment
system automatically charges your iPod while it
is docked.
The dock lets you connect your
USB Direct connection
With the USB Direct mode, you can simply
select the music on a USB devi
all your content. All you have to do is plug in
your USB device to play back music or export
content from the device.
Dynamic Bass Boost
Dynamic Bass Boost maximises your music
e
njoyment by emphasising the bass content of
the music throughout the range of volume
settings - from low to high – at the touch of a
button! Bottom-end bass frequencies usually
get lost when the volume is set at a low level.
To counteract this, Dynamic Bass Boost can be
switched on to boost bass levels, so you can
ce and play back
enjoy consistent sound even when you turn
down the volume.
Digital Sound Control
Digital Sound Control offers you a choice of
p
re-set Jazz, Rock, Pop and Classical controls
you can use to optimise the frequency ranges
for different musical styles. Each mode uses
graphic equalizing technology to automatically
adjust the sound balance and enhance the most
important sound frequencies in your chosen
music style. Ultimately, Digital Sound Control
makes it easy for you get the most out of your
music by precisely adjusting the sound balance
to match the type of music you are playing.
Page 3
DCM230/05
Docking Entertainment System
Plays MP3/WMA-CD USB Direct
Specifications
iPod compatibility
• Compatible with: iPod, iPod mini, iPod nano, iPod
with colour display, iPod 5th Generation
Audio Playback
• Cradle playback mode: Charging iPod, Play and
Pause, Next and Previous track, Fast forward and
reverse
• Loader Type: Motorised, Slot
• Playback Media: WMA-CD, MP3-CD, CD, CD-R,
-RW
CD
• Disc Playback Modes: Fast F
Previous Track Search, Repeat Play, Shuffle Play
• Programmable Tracks: 20
orward/Reverse, Next/
Sound
• Output power (RMS): 2 x 15 W
• Sound System: Stereo
• Loudspeaker types: Bass Reflex Speaker System
• Sound Enhancement: Dynamic Bass Boost
• Volume Control: Volume Control up/down
Tuner/Reception/Transmission
• Tuner Bands: FM, MW
• Auto digital tuning
• RDS: Station Name
• Antenna: FM Antenna
Connectivity
• USB: USB host
•Aux in
• Headphones: 3.5 mm
Convenience
• Display Type: LCD
•Backlight
• Remote Control: Multi-functional
• Alarms: Radio Alarm, Sleep timer
•Clock/Version: Digital
Power
• Mains power
Accessories
• Included accessories: AC Power Cord, User
Manual, Warranty certificate, Remote Control,
World Wide Warranty leaflet
Dimensions
• Product dimensions (W x H x D):
390 x 140.5 x 200.5 mm
•
Issue date 2018-03-18
Version: 4.0.6
12 NC: 8670 000 33177
EAN: 87 12581 35814 3
© 2018 Koninklijke Philips N.V.
All Rights reserved.
Specifications are subject to change without notice.
Trademarks are the property of Koninklijke Philips N.V.
or their respective owners.
www.philips.com
