Philips DCB352/10, DCB352 User Manual

www.philips.com/welcome

Register your product and get support at

EN User manual 3

DA Brugervejledning 25

DE Benutzerhandbuch 47

FR Mode d’emploi 71

IT Manuale utente 97

NO Brukerhåndbok 121

DCB352

3

English

EN

8 Other features 21

Set the sleep timer 21
Set the alarm timer 21
Play from an external device 21

9 Product information 22

Specifications 22
Maintenance 23
USB playability information 23
Supported MP3 disc formats 23
RDS program types 24

10 Troubleshooting 24

Contents

1 Important 4

Safety 4
Notice 6

2 Your Docking Entertainment System 7

Introduction 7
What’s in the box 7
Overview of the main unit 8
Overview of the remote control 9

3 Get started 11

Connect power 11
Prepare the remote control 12
Set clock 12
Turn on 12

4 Play 13

Play disc 13
Play from USB 13
Skip to a track 13
Pause/resume play 13
Search within a track 13
Display play information 14
Select repeat/shuffle play options 14
Program tracks 14

5 Adjust sound 15

Adjust volume 15
Select a preset sound effect 15
Enhance bass 15
Mute sound 15

6 Play iPod/iPhone/iPad 15

Compatible iPod/iPhone/iPad 15
Load the iPod/iPhone/iPad 16
Listen to the iPod/iPhone/iPad 16
Charge the iPod/iPhone/iPad 16
Remove the iPod/iPhone/iPad 16

7 Listen to radio 17

Listen to Digital Audio Broadcasts (DAB) 17
Listen to FM radio 19
Reset to factory setting 20

4

g Do not block any ventilation openings.

Install in accordance with the
manufacturer’s instructions.

h Do not install near any heat sources

such as radiators, heat registers, stoves,
or other apparatus (including amplifiers)
that produce heat.

i Protect the power cord from being

walked on or pinched, particularly at
plugs, convenience receptacles, and
the point where they exit from the
apparatus.

j Only use attachments/accessories

specified by the manufacturer.

k Use only with the cart, stand, tripod,

bracket, or table specified by the
manufacturer or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.

l Unplug this apparatus during lightning

storms or when unused for long periods
of time.

m Refer all servicing to qualified service

personnel. Servicing is required when
the apparatus has been damaged in any
way, such as power-supply cord or plug
is damaged, liquid has been spilled or
objects have fallen into the apparatus,
the apparatus has been exposed to rain
or moisture, does not operate normally,
or has been dropped.

1 Important

Safety

This ‘bolt of lightning’ indicates uninsulated
material within your unit may cause an
electrical shock. For the safety of everyone
in your household, please do not remove
product covering.
The ‘exclamation point’ calls attention to
features for which you should read the
enclosed literature closely to prevent
operating and maintenance problems.
WARNING: To reduce the risk of fire or
electric shock, this apparatus should not be
exposed to rain or moisture and objects filled
with liquids, such as vases, should not be
placed on this apparatus.
CAUTION: To prevent electric shock, match
wide blade of plug to wide slot, fully inser t.

Important Safety Instructions

a Read these instructions.
b Keep these instructions.
c Heed all warnings.
d Follow all instructions.
e Do not use this apparatus near water.
f Clean only with dry cloth.

EN

5

English

Hearing safety

Listen at a moderate volume.

Using headphones at a high volume can •
impair your hearing. This product can
produce sounds in decibel ranges that
may cause hearing loss for a normal
person, even for exposure less than a
minute. The higher decibel ranges are
offered for those that may have already
experienced some hearing loss.
Sound can be deceiving. Over time your •
hearing ‘comfor t level’ adapts to higher
volumes of sound. So after prolonged
listening, what sounds ‘normal’ can
actually be loud and harmful to your
hearing. To guard against this, set your
volume to a safe level before your hearing
adapts and leave it there.

To establish a safe volume level:

Set your volume control at a low setting. •
Slowly increase the sound until you can •
hear it comfortably and clearly, without
distortion.

Listen for reasonable periods of time:

Prolonged exposure to sound, even •
at normally ‘safe’ levels, can also cause
hearing loss.
Be sure to use your equipment •
reasonably and take appropriate breaks.

Be sure to observe the following guidelines
when using your headphones.

Listen at reasonable volumes for •
reasonable periods of time.
Be careful not to adjust the volume as •
your hearing adapts.
Do not turn up the volume so high that •
you can’t hear what’s around you.
You should use caution or temporarily •
discontinue use in potentially hazardous
situations. Do not use headphones while
operating a motorized vehicle, cycling,
skateboarding, etc.; it may create a traffic
hazard and is illegal in many areas.

n Battery usage CAUTION – To prevent

battery leakage which may result in
bodily injury, property damage, or
damage to the unit:

Install all batteries correctly, + and - •
as marked on the unit.
Do not mix batteries (old and new •
or carbon and alkaline, etc.).
Remove batteries when the unit is •
not used for a long time.
Batteries (battery pack or batteries •
installed) shall not be exposed to
excessive heat such as sunshine, fire
or the like.

o Apparatus shall not be exposed to

dripping or splashing.

p Do not place any sources of danger on

the apparatus (e.g. liquid filled objects,
lighted candles).

q Where the plug of the Direct Plug-

in Adapter is used as the disconnect
device, the disconnect device shall
remain readily operable.

Warning

Never remove the casing of this apparatus. •
Never lubricate any par t of this apparatus. •
Never place this apparatus on other electr ical •
equipment.
Keep this apparatus away from direct sunlight, naked

•

flames or heat.
Never look into the laser beam inside this apparatus.

•

Ensure that you always have easy access to the •
power cord, plug or adaptor to disconnect this
appar atus from the power.

EN

6

Environmental information

All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please obser ve the
local regulations regarding the disposal of
packaging materials, exhausted batteries and
old equipment.

The making of unauthorized copies of
copy-protected material, including computer
programs, files, broadcasts and sound
recordings, may be an infringement of
copyrights and constitute a criminal offence.
This equipment should not be used for such
purposes.

This apparatus includes this label:

Note

The type plate is located on the bot tom of the •
apparatus.

Notice

Any changes or modifications made to this
device that are not expressly approved by
Philips Consumer Lifestyle may void the user’s
authority to operate the equipment.

This product complies with the radio interference
requirements of the European Community.

Your product is designed and manufactured
with high quality materials and components,
which can be recycled and reused.

When this crossed-out wheeled bin symbol
is attached to a product it means that the
product is covered by the European Directive
2002/96/EC.
Please inform yourself about the local
separate collection system for electrical and
electronic products.
Please act according to your local rules and
do not dispose of your old products with your
normal household waste. Correct disposal of
your old product helps to prevent potential
negative consequences for the environment
and human health.

Your product contains batteries covered by
the European Directive 2006/66/EC, which
cannot be disposed with normal household
waste.Please inform yourself about the local
rules on separate collection of batteries
because correct disposal helps to prevent
negative consequences for the environmental
and human health.

EN

7

English

What’s in the box

Check and identify the contents of your package:

Main unit•
Remote control•
2 AAA batteries•
AC adaptor•
MP3 LINK cable•
User manual•
Quick star t guide•

2 Your Docking

Entertainment
System

Congratulations on your purchase, and
welcome to Philips! To fully benefit from
the support that Philips offers, register your
product at www.philips.com/welcome.

Introduction

With this music system, you can enjoy audio
from audio discs, USB storage devices, iPod,
iPhone, iPad and other external devices, or
listen to radio stations.
The music system offers you multiple sound
effect settings that enrich sound with Digital
Sound Control (DSC) and Dynamic Bass
Boost (DBB).
The system suppor ts the following media
formats:

EN

8

g EJECT

Eject the disc.•

h Display panel

Show current status.•

i SOURCE

Select a source: DISC, USB, DOCK, •
DIGITAL RADIO, FM TUNER , or
MP3-Link.

j PROG

Program tracks.•
Program radio stations.•
Set the clock.•

k DISPLAY

During play, select display •
information.

Overview of the main unit

a MP3-LINK

Jack for an external audio device.•

b

Jack for a USB mass storage device. •

c IR sensor

Detect signals from the remote •
control. Always point the remote
control at the IR sensor.

d Disc compartment
e Dock for iPod/iPhone/iPad

Load an iPod/iPhone/iPad.•

f STANDBY-ON

Turn on the system, switch to •
standby mode, or Eco Power
standby mode.

a

b

c

d

e

f
g

h

ijk

lm

n

q

o

p

r

EN

9

English

Overview of the remote
control

a

Turn on the system, or switch to •
standby mode, or switch to Eco
Power standby.

b OPEN/CLOSE

Eject the disc.•

c CD

Select disc source.•

PRESET/ALBUM

PROG/

CLOCK SET

SLEEP/
TIMER

DISPLAY MENU

RDS

DSC DBB

USB

TUNER

CD

VOL

MODE/

SCAN

3

456

789

1

0

2

DAB

OPEN/CLOSE

MP3 LINK

ENTER

b

a

c

e
f

d

g

h

j

i

k

l
m
n

s

r

q

p
o

l TIMER

Set the alarm timer.•

m MODE/SCAN

Select repeat/shuffle mode.•
Search FM/DAB radio stations. •

n STOP/MENU

Stop play.•
Access iPod/iPhone or DAB menu. •

o ALBUM·PRESET +/-

Select a preset radio station.•
Skip to the previous/next album.•
Adjust time.•

p

/

Skip to the previous/next track.•
Search within a track/disc.•
Tune to a radio station.•

q

Start or pause play.•
Confirm a selection.•

r VOLUME +/-

Adjust volume.•

EN

10

p MODE/SCAN

Select repeat/shuffle play mode. •
Search FM/DAB radio stations. •

q

/MENU

Stop play.•
Access iPod or DAB menu. •

r iPod/iPhone

Select iPod/iPhone source.•

s DAB/TUNER

Select DAB/tuner source. •

d

/

Navigate in the iPod/DAB menu.•
Skip to the previous/next album.•
Skip to the previous/next preset •
station.
Select 12 hour or 24 hour format.•
Adjust hour/minute digits.•

e

/

Skip to the previous/next track.•
Search within a track. •
Tune to a radio station.•

f

/ENTER

Start or pause play.•
Confirm a selection. •

g USB/MP3 LINK

Select USB device source.•
Select external audio device source.•

h RDS/DISPLAY

Display CLOCK. •
Display RDS/DAB information. •
Select display information during play.•

i

Mute or restore volume.•

j VOL +/-

Adjust volume.•

k Numeric keypad

Select a track from a disc directly.•

l PROG/CLOCK SET

Program tracks.•
Program radio stations.•
Set the clock.•

m SLEEP/TIMER

Set the sleep timer.•
Set the alarm timer.•

n DSC

Select a preset sound setting.•

o DBB

Turn on or off dynamic bass •
enhancement.

EN

11

English

1 Select the right adaptor.

2 Connect the power adaptor to the wall

outlet.

3 Get started

Caution

Use of controls or adjustments or per formance •
of procedures other than herein may result in
hazardous radiation exposure or other unsafe
operation.

Always follow the instructions in this chapter
in sequence.
If you contact Philips, you will be asked for the
model and serial number of this apparatus.
The model number and serial number are
on the bottom of the apparatus. Write the
numbers here:
Model No. _______________________
Serial No. ________________________

Connect power

Caution

Risk of product damage! Ensure that the power •
voltage corresponds to the voltage printed on the
back or underside of the apparatus.
Risk of electric shock! When you unplug the AC

•

adaptor, always pull the plug from the socket. Never
pull the cord.
Before you connect the AC adaptor, ensure that you

•

have completed all other connections.

EN

12

Set clock

Note

You can set the clock in the standby mode only. •

1 In standby mode, press and hold PROG/

CLOCK SET to activate the clock setting

mode.

SET CLOCK is displayed. »
The 12 hour or 24 hour format is »

displayed.

2 Press / to select 12 hour or 24 hour

format.

3 Press PROG/CLOCK SET.

The hour digits begin to blink. »

4 Press / to set the hour.
5 Press PROG/CLOCK SET.

The minute digits begin to blink. »

6 Press / to set the minute.
7 Press PROG/CLOCK SET to confirm.

Turn on

1

Press .

The unit switches to the last selected »
source.

Switch to standby

1 Press to switch the system to standby

mode.

The backlight on the display panel is »
reduced.

The clock (if set) is displayed on the »
display panel.

To switch the system to Eco Power standby
mode:

1 In standby mode, press and hold for

more than 2 seconds.

ECO POWER is displayed. »
The backlight on the display panel »

turns off.

Prepare the remote control

Caution

Risk of explosion! Keep batteries away from heat, •
sunshine, or fire. Never discard bat ter ies in fire.

To insert the remote control battery:

1 Open the battery compartment.
2 Insert 2 AAA batteries with correct

polarity (+/-) as indicated.

3 Close the battery compartment.

Note

If you are not going to use the remote control for a •
long time, remove the batteries.
Do not use old and new or different types of

•

batteries in combination.
Batteries contain chemical substances, so they should

•

be disposed of properly.

a

b

c

EN

13

English

Press • to access a folder.
Press •

/ to select a file.

Press •

to start play.

Skip to a track

For CD:

1 Press / to select another track.

To select a track directly, you can •
also press a key on the numerical
keypad.

For MP3 disc and USB:

1 Press to select an album or folder.
2 Press / to select previous/next

track or file.

Pause/resume play

1

During play, press to pause/resume

play.

Search within a track

1

During play, press and hold / .

2 Release to resume normal play.

4 Play

Play disc

1

Press CD to select the disc source.

2 Insert a disc into the disc compartment

with the printed side facing up.

Play starts automatically. »

Play from USB

Note

Ensure that the USB storage device contains playable •
audio content.

1 Connect the USB storage device into the

socket.

2 Press USB to select the USB source.

The total number of playable tracks is »
displayed.

Play starts automatically. »

EN

14

Program tracks

You can program a maximum of 20 tracks.

1 In CD/USB mode, at the stop position,

press PROG to activate the program
mode.

[PROG] (program) and track number »
begin to blink.

2 For MP3 tracks, press to select an

album.

3 Press / to select a track number,

then press PROG to confirm.

4 Repeat steps 2 to 3 to program more

tracks.

5 Press to play the programmed tracks.

During play, [PROG] (program) is »
displayed.

To erase the program:•
Press

once in the stop mode or

twice during playback.

[PROG] disappears on the »
display.

Display play information

1

During play, press DISPLAY repeatedly to

select different play information.

Select repeat/shuffle play
options

To select repeat play mode:

1 During play, press MODE repeatedly to

select a repeat option.

[Rep one]: plays the current track »
continuously.

[Rep all]: repeats the entire disc/ »
programme.

To select shuffle play mode:

1 During play, press MODE repeatedly to

select the shuffle play mode.

[SHUF]: Tracks of the entire disc are »
played in random order.

To resume normal play, press • MODE
repeatedly until no shuffle/repeat option
is displayed.

Tip

During repeat/shuf fle playback, press • to stop
playback and cancel repeat/shuffle playback.
Shuffle function is not available while programmed

•

tracks are played.

EN

15

English

6 Play iPod/

iPhone/iPad

This system is equipped with a dock for
iPod/iPhone/iPad. You can enjoy audio from
the docked system through the powerful
speakers.

Compatible iPod/iPhone/iPad

Made for Apple iPod models with 30-pin dock
connector as follows:

iPod touch (4th generation)•
iPod touch (3rd generation)•
iPod touch (2nd generation)•
iPod touch (1st generation)•
iPod nano (6st generation)•
iPod nano (5th generation)•
iPod nano (4th generation)•
iPod nano (3rd generation)•
iPod nano (2nd generation)•
iPod nano (1st generation)•
iPhone 4•
iPhone 3GS•
iPhone 3G•
iPhone•
iPad•
iPad 2•

5 Adjust sound

Adjust volume

1

During play, press VOL +/- to increase/

decrease the volume.

Select a preset sound effect

1

During play, press DSC repeatedly to

select:

[POP] (pop)•
[JAZZ] (jazz)•
[CLASSIC] (classic)•
[ROCK] (rock)•

Enhance bass

1

During play, press DBB to turn on or off

dynamic bass enhancement.

If DBB is activated, DBB is displayed. »

Mute sound

1

During play, press to mute/restore the

speakers.

EN

16

Charge the iPod/iPhone/iPad

When the system is connected to power, the
docked iPod/iPhone/iPad begins to charge.

Note

IPod with color display, iPod classic, and iPod with •
video are not compatible with dock charging.
In Eco power standby mode, iPod/iPhone/iPad

•

cannot be charged.

Remove the iPod/iPhone/iPad

1

Pull the iPhone/iPod/iPad off the dock.

2 Flip down the lid to hide the dock.

Load the iPod/iPhone/iPad

1

Lift the lid of the dock.

2 Load the iPod/iPhone/iPad onto the dock.

Listen to the iPod/iPhone/iPad

1

Press the button iPod on your RC.

2 Load your iPod/iPhone/iPad.
3 Play the selected track on your iPod/

iPhone/iPad.

To pause/resume the play, press •

.

To search during play: press and hold •

/ , then release to resume
normal play.
To scroll through the menu, press •

/ .

To confirm a selection, press •

to

confirm.

If no key is pressed for more than »
10 seconds after pressing the
button MENU,

acts back as

the play/pause key.

EN

17

English

• ?: Indicates that the station is not
currently available, or not active.

•

: Indicates that the station is
a primary station with secondary
service.

•

: Indicates that the station is a
secondary station.

Program DAB radio stations manually

You can program a maximum of 30 preset
DAB radio stations.

1 Tune to a DAB station.
2 Press PROG on the remote control to

activate programming.

3 Press / on the remote control to

allocate a number (1-30) for the preset.

4 Press PROG to confirm.

Note

If a DAB station is already stored under a preset •
location, new DAB station assigned to this location
will overwrite the old DAB station.
DAB station presets will not overwrite FM presets.

•

Scan for new DAB stations

New stations and services will be regularly
added in the DAB broadcast. To make new
DAB stations and service available on your
DAB radio, a search is needed.

1 In DAB mode, press SCAN.

The unit starts to scan for DAB »
stations.

Listen to a preset DAB radio station

1 Press / to select a preset number on

the main unit.

7 Listen to radio

Listen to Digital Audio
Broadcasts (DAB)

Digital Audio Broadcasting (DAB), is a way
of broadcasting radio digitally through a
network of transmitters. It provides you with
more choice, better sound quality, and more
information.
For the first time when DAB mode is
switched on.

1 Press SOURCEon the main unit

repeatedly to select DAB.

The system performs auto search. »
All the available DAB stations are »

stored.
The radio tunes to the first available »

station

Tip

The display shows a rectangle. The position of the •
rectangle indicates the degree of signal strength.
(The fur ther towards the right, the greater the signal
strength.)
If there is no DAB coverage currently available, or

•

DAB signal is too weak in your area, no DAB station
is found, and message [Ser vice not available] scrolls.

Tune to DAB radio station manually

1 In DAB mode, press / repeatedly

until your desired station name displays.

2 Press ENTER to confirm the selection.

The radio immediately tunes to the »
selected station.

About station display symbols•
You probably see some symbols displayed
before the station names as follows:

H: Indicates that the station is one •
of 10 most-listened stations by you
based on DAB radio’s monitoring.

EN

18

Manual tune

With this feature, you can tune to a specific
channel/frequency manually. In addition to
antenna orientation for better radio reception,
the optimal reception can also be obtained
with this feature.

1 In DAB mode, press MENU to display the

[Manual tune] option.

2 Press ENTER to confirm the selection.

The display shows a channel and its »
frequency.

3 Press / repeatedly until the desired

channel/frequency appears.

4 Press ENTER to confirm the selection.

Tip

You can press • RDS/DISPLAY to change the service
information on the display.
You can adjust the position of the antenna to obtain

•

the optimal signal s trength.

Dynamic Range Control (DRC)

DRC adds or removes a degree of
compensation for the differences in the
dynamic range between radio stations.
There are three levels of compensation:

• [DRC Off]: No compensation
applied. (the default)

• [DRC Low]: Maximum
compensation applied.

• [DRC High]: Medium compensation
applied.

1 In DAB mode, press MENU to enter the

menu options.

2 Press / repeatedly until [DRC]

displays.

3 Press ENTER to enter the sub-menu.

The current DRC level displays on »
the first line.

4 Press / to select a DRC value

» [DRC Off], [DRC Low] and [DRC

High] displays on the second line.

Display DAB information

On the display of DAB broadcasting, the first
line shows station name, and the second line
shows the service information for the current
station. Seven types of service information are
available.

1 Press RDS/DISPLAY repeatedly to

cycle through the display information (if
available).

Dynamic label segment (DLS) »
Program type (PTY) »
Ensemble Name »
Time »
Channel and frequency »
Bit rate and audio status »
Signal error rate »

Use DAB menu

1 In the DAB mode, press MENU to enter

the DAB menu.

The first setup option » [Station list]
displays.

2 Press / to scroll the menu options:

• [Station list]

• [Full scan]

• [Manual tune]

• [DRC]

• [Prune]

• [System]

3 To select an option, press ENTER.
4 Repeat step 2-3 if sub-option is available

under one option.

Full scan

Full scan is used to perform a wide range of
DAB radio search.

1 In the DAB mode, press MENU to enter

the menu options.

2 Press / repeatedly until [Full scan]

displays.

3 Press to confirm the selection.

Full scan starts automatically. »

EN

19

English

Program radio stations automatically

You can program a maximum of 30 preset
radio stations (FM).

1 In the tuner mode, press and hold

MODE/SCAN to activate automatic

program mode.

All available stations are programmed. »
The first programmed radio station is »

broadcast automatically.

Program radio stations manually

Note

You can program a maximum of 30 preset radio •
stations.

1 Tune to a radio station.
2 Press PROG to activate program mode.
3 Press / to allocate a number (1

to 30) to this radio station, then press
PROG to confirm.

The preset number and the frequency »
of the preset station are displayed.

4 Repeat the previous steps to program

other stations.

Note

To overwr ite a progr ammed station, store another •
station in its place.

Select a preset radio station

1 In tuner mode, press / to select a

preset number.

Tip

Position the antenna as far as possible from TV, VCR, •
or other radiation source.
For optimal reception, fully ex tend and adjust the

•

position of the antenna.

5 Press to confirm the selection.

You should be able to hear »
the difference in compression
immediately.

Note

The best way to deter mine which of these DRC •
value settings suits you best is to experiment with
them on various source material.

Prune

This option lists active stations and removes
any stations that are in the list but have no
service in your area from the service list.
Those invalid stations in the service list have
a question mark (?) displayed in front of the
station name.

1 Select Prune stations and press .

All stations that have a question mark »
are deleted from the service list.

System

• [Factory reset]: Reset all the settings
of this unit to factory default. Press

to confirm reset.

• [SW version]: Display software
version of the unit.

Listen to FM radio

Tune to a radio station

1 Press TUNER to select FM.
2 Press / to tune to a specific

frequency.

Play starts automatically. »

Tip

You can press • MODE/SCAN to tune to the next
station with strong reception automatically.

EN

20

Reset to factory setting

1

In DAB/FM mode, press MENU to enter

the menu options.

2 Press / repeatedly until [System]

displays on the display panel.

3 Press to access the system menu.

» [Factory Reset] displays.

4 Press to enter factory reset menu.

The display panel shows options » [Yes]
and [No] under [Factory Reset].

5 Press / to select [Yes].
6 Press to confirm the DAB/FM factory

reset.

FM stations with RDS

Radio Data System (RDS) is a service that
sends additional broadcast information along
with FM stations.
If you listen to a FM station with RDS signal,
“RDS” displays.

Display RDS information

1 Tune to the desired RDS radio station on

the FM waveband.

2 Press RDS/DISPLAY on the remote

control repeatedly to switch through the
following information (if available):

Radio text message•
Program type (for example: News, •
Sport...)
Frequency•
Stereo/Mono Mode•
Time•
Date•

Note

•

[NO Radio Text], [NO PTY], [NO Name], [Mono],
[00:00:00] or [0-0-0000] displays if no RDS signal

is available.

Set RDS clock

You can use time signal broadcast together
with the RDS signal to set the clock of the
unit.

1 Tune to a RDS radio station that

transmits time signals.

2 Press and hold MENU.

[CLK Sync] is displayed. »

Note

The accuracy of the transmit ted time depends on the •
RDS station that transmits the time signal.

EN

21

English

6 Press SLEEP/TIMER to confirm.

The minute digits begin to blink. »

7 Press / to set the minute.

The timer is set and activated. »

»

is displayed.

Activate and deactivate the alarm
timer

1 Switch the system to standby mode.
2 Press TIMER repeatedly to activate or

deactivate the timer.

If the timer is activated, »

is displayed.

If the timer is deactivated, »
disappears on the display.

Note

If DISC/USB/iPod source is selected and the track •
cannot be played, tuner is ac tivated automatically.

Play from an external device

You can also listen to an external audio device
through this unit.

1 Press USB/MP3 LINK to select the MP3

link source.

2 Connect the supplied MP3 link cable to:

the • MP3 LINK jack (3.5mm) on the
unit.
the headphone jack on an external •
device.

3 Start to play the device (see the device

user manual).

8 Other features

Set the sleep timer

This system can switch to standby
automatically after a set period of time.

1 When the system is turned on, press

SLEEP repeatedly to select a set period of

time (in minutes).

When sleep timer is activated, »

is

displayed.

To deactivate sleep timer

1 Press SLEEP repeatedly until “OFF” is

displayed.

When sleep timer is deactivated, »
[SLEEP](sleep)

disappears on the

display.

Set the alarm timer

This unit can be used as an alarm clock. The
disc/radio/USB/iPod is activated to play at a
preset time.

Note

Ensure that you have set the clock correctly. •

1 Press to switch to standby mode.
2 Press and hold SLEEP/TIMER for more

than two seconds.

A prompt to select the source is »
displayed.

3 Press CD, iPod, TUNER, DAB, or USB to

select a source.

4 Press SLEEP/TIMER to confirm.

The clock digits are displayed. »
The hour digits begin to blink. »

5 Press / to set the hour.

EN

22

Tuner

Tuning Range FM: 87.5 - 108 MHz;

DAB: 174.92-239.20 MHz
Tuning grid 50 KHz
DAB sensitivity

- EN50248

<-95 dbm

Total Harmonic
Distortion

<2%

Signal to Noise Ratio >50 dB
Number of presets 30 (FM)

30 (DAB)

Speakers

Speaker Impedance 4 ohm
Speaker Driver 2 X 3” full range
Sensitivity >82 dB/m/W

General information

AC power
(power adaptor)

Model No.: OH­1048E1203500U(Philips);
Input: 100-240 V~,
50/60Hz 1.5A MAX;
Output: 12 V

3.5A;

Operation Power
Consumption

25 W

Eco Standby Power
Consumption

<1 W

USB Direct Version 2.0/1.1
Dimensions

- Main Unit
(W x H x D)

390 x 140.5 x 200.5mm

Weight

- Main Unit

2.54 kg

9 Product

information

Note

Product information is subject to change without •
prior notice.

Specifications

Amplifier

Rated Output
Power

2X15W RMS

Frequency
Response

60 Hz - 16 kHz, ±3 dB

Signal to Noise
Ratio

>65dBA

Aux Input 0.5 V RMS 20kohm

Disc

Laser Type Semiconductor
Disc Diameter 12cm/8cm
Support Disc CD-DA, CD-R,

CD-RW, MP3-CD
Audio DAC 24Bits / 44.1kHz
Total Harmonic

Distortion

<1%

Frequency
Response

60Hz -16kHz (44.1kHz)

S/N Ratio >65dBA

EN

23

English

Supported formats:

USB or memory file format FAT12, •
FAT16, FAT32 (sector size: 512 bytes)
MP3 bitrate (data rate): 32-320 Kbps •
and variable bitrate
Directory nesting up to a maximum •
of 8 levels
Number of albums/ folders: •
maximum 99
Number of tracks/titles: maximum •
999
ID3 tag v2.0 or later•
File name in Unicode UTF8 •
(maximum length: 128 bytes)

Unsupported formats:

Empty albums: an empty album is •
an album that does not contain MP3
files, and is not shown in the display.
Unsupported file formats are •
skipped. For example, Word
documents (.doc) or MP3 files with
extension .dlf are ignored and not
played.
AAC, WAV, PCM audio files•
DRM protected WMA files (*.wav, •
*.m4a, *.m4p, *.mp4, *.aac)
WMA files in Lossless format•

Supported MP3 disc formats

ISO9660, Joliet•
Maximum title number: 512 (depending •
on file name length)
Maximum album number: 255•
Supported sampling frequencies: 32 kHz, •

44.1kHz, 48 kHz
Supported Bit-rates: 32~256 (kbps), •
variable bit rates

Maintenance

Clean the cabinet

Use a soft cloth slightly moistened with •
a mild detergent solution. Do not use
a solution containing alcohol, spirits,
ammonia or abrasives.

Clean discs

When a disc becomes dirty, clean it with •
a cleaning cloth. Wipe the disc from the
centre out.

Do not use solvents such as benzene, •
thinner, commercially available cleaners,
or antistatic spray intended for analogue
records.

Clean the disc lens

After prolonged use, dirt or dust may •
accumulate at the disc lens. To ensure
good play quality, clean the disc lens
with Philips CD lens cleaner or any
commercially available cleaner. Follow the
instructions supplied with cleaner.

USB playability information

Compatible USB storage devices:

USB flash memory (USB 2.0 or •
USB1.1)
USB flash players (USB 2.0 or •
USB1.1)
memory cards (requires an additional •
card reader to work with this
system)

EN

24

10 Troubleshooting

Warning

Never remove the casing of this apparatus. •

To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
apparatus, check the following points before
requesting service. If the problem remains
unsolved, go to the Philips web site
(www.philips.com/welcome). When you
contact Philips, ensure that the apparatus
is nearby and the model number and serial
number are available.

RDS program types

NO TYPE No RDS programme type
NEWS News services
AFFAIRS Politics and current affairs
INFO Special information

programs
SPORT Sports
EDUCATE Education and advanced

training
DRAMA Radio plays and literature
CULTURE Culture, religion and

society
SCIENCE Science
VARIED Entertainment programs
POP M Pop music
ROCK M Rock music
MOR M Light music
LIGHT M Light classical music
CLASSICS Classical music
OTHER M Special music programs
WEATHER Weather
FINANCE Finance
CHILDREN Children’s programs

SOCIAL Social Affairs
RELIGION Religion
PHONE IN Phone In
TRAVEL Travel
LEISURE Leisure
JAZZ Jazz Music
COUNTRY Country Music
NATION M National Music
OLDIES Oldies Music
FOLK M Folk Music
DOCUMENT Documentary
TES Alarm Test
ALARM Alarm

EN

© 2011 Koninklijke Philips Electronics N.V.
All rights reserved.
DCB352_10_UM_V1.1
