Registre seu produto e obtenha suporte em

www.philips.com/welcome

HTS5123

User manual

Manual del usuarioManual do Usuário

Responsabilidade Social

A Philips do Brasil LTDA é uma empresa socialmente responsável, preocupada com a valorização dos seus recursos humanos internos, com o relacionamento correto e justo com a comunidade, com o meio ambiente, com o ambiente de trabalho e com o compromisso de cumprimento das leis.

Sendo assim, realiza suas atividades em conformidade com a norma SA-8000, que se baseia nos princípios das convenções da Organização Internacional do Trabalho, da Convenção das Nações Unidas sobre os Direitos da Criança e na Declaração Universal dos Direitos Humanos.

Informação ambiental

Todo o material desnecessário foi retirado da embalagem do produto. Nós tentamos fazer as embalagens de modo que elas sejam fáceis de separar em três materiais: caixa de papelão (caixa), calços de isopor e sacos plásticos.

O seu sistema contém materiais que podem ser reciclados e usados novamente se desmontados por uma empresa especializada. Por favor, observe os regulamentos locais relacionados à disposição de materiais da embalagem, baterias e equipamentos, com relação à destinação no seu ﬁnal de vida.

Prezado Consumidor,

PARABÉNS POR TER ADQUIRIDO ESTE PRODUTO... E BEM VINDO À FAMÍLIA PHILIPS.

Agradecemos pela sua conﬁança na Philips e temos a certeza de que seu Sistema de Home Theater lhe trará muitos momentos agradáveis, pois ele é um produto de tecnologia moderna e com muitos recursos. Para usufruir de todo seu potencial, basta ler atentamente este manual e seguir as orientações dadas. Atenciosamente,

Philips do Brasil LTDA

Baterias e Pilhas

ADVERTÊNCIA: Cuidados com a utilização e descarte de pilhas e baterias.

- Não descarte as pilhas e baterias ao lixo doméstico.

- O descarte inadequado de pilhas e baterias pode representar riscos ao meio ambiente e a saúde humana.

- Para contribuir com a qualidade ambiental e com sua saúde, a Philips receberá pilhas e baterias fornecidas com seus produtos após seu fim de vida. A Philips dispõe de pontos de coleta em Assistências Técnicas que auxiliarão

neste processo.

- Para evitar o vazamento de pilhas ou baterias, o que

recomendamos que: (i) Em caso de aparelhos com pilhas removíveis, retire-as quando não estiver em uso por um longo período, (ii) Não misture pilhas (antigas com novas ou de zinco-carbono com alcalinas, etc.) (iii) Não exponha o produto com pilhas/baterias em seu interior a altas temperaturas.

- Em caso de aparelhos com pilhas não removíveis, promover o encaminhamento à assistência técnica Philips.

- Pilhas e bateiras usadas ou inservíveis recebidas pela Philips serão encaminhadas à destinação ambientalmente correta.

- Em caso de dúvida ou consulta, favor ligar para 0800 701 0203 Brasil ou 2121 0203 Grande São Paulo ou acessar o site http://www.philips.com.br

Programa Ciclo Sustentável Philips – Reciclagem de aparelhos eletro-eletrônicos Philips pós-consumo

O seu produto Philips no final da vida útil pode ser encaminhado a uma de nossas assistências técnicas autorizadas para que tenha um destino ambientalmente adequado já que os equipamentos eletro-eletrônicos não devem ser descartados no lixo comum. O programa também contempla o recolhimento de pilhas e baterias portáteis de qualquer fabricante. Iniciado em 2008, o Ciclo Sustentável Philips é o primeiro programa corporativo que promove a reciclagem de aparelhos eletro-eletrônicos no país, minimizando os impactos ao meio ambiente. De um lado, a Philips entrega produtos inovadores, sempre focando no compromisso com a sustentabilidade. Do outro lado, você retorna o produto para descarte, fechando um ciclo responsável. A Philips sempre foi pioneira em Sustentabilidade dentre as empresas do seu setor. Com essa iniciativa fortalecemos nossa responsabilidade ambiental e o compromisso com a sociedade. Para saber quais assistências técnicas autorizadas participam do Programa Ciclo Sustentável, acesse nossa homepage: http://www.sustentabilidade.philips.com.br.

juntamente

,otudorp oa e siatneibma ,edúas à sonad me ratluser edop

Contents

1 Help and support 2

FAQs 2 Contact Philips 2

2 Notice 2

RMVB end user agreement (Asia Pacic

and China only) 3

Trademarks 4

3 Important 5

Safety 5 Care for your product 5 Care of the environment 6

4 Your SoundBar 6

Main unit 6 Remote control 7

7 Change settings 21

Picture 21 Sound 22 Language 23 Scan your USB storage device 23 DLNA DMR control 23 Energy saving 23 Apply factory settings 24

8 Update software 24

Check software version 24 Update software through the Internet 24 Update software through USB 25

9 Productspecications 25

10 Troubleshooting 28

11 Index 29

English

5 Connect your SoundBar 8

Subwoofer 8 Connectors 9 Connect to TV 9 Connect audio from TV and other devices 10 Computers and the Internet 11 Name your SoundBar 13

6 Use your SoundBar 13

Adjust the volume 13 Choose your sound 14 USB storage devices 14 Audio, video, and picture options 15 Use smartphone 16 Share media through SimplyShare 18 EasyLink 20

1 Help and support

2 Notice

Download a software update and nd answers to

many frequently answered questions (FAQs) on your product at www.philips.com.

FAQs

If you have a problem, refer to the frequently asked questions (FAQs) for this SoundBar at www. philips.com/support. If you still need help, contact Philips Consumer Care in your country.

Warning

• Do not attempt to repair your SoundBar

yourself. This may cause severe injury, irreparable damage to your SoundBar, or void your warranty.

Contact Philips

If you contact Philips, you will be asked for the model and serial number of your product. The model number and serial number are on the back or bottom of your product. Note the numbers before you call Philips: Model No. __________________________ Serial No. ___________________________

This section contains the legal and trademark notices.

This item incorporates copy protection technology that is protected by U.S. patents and other intellectual property rights of Rovi Corporation. Reverse engineering and disassembly are prohibited.

Recording and playback of material may require consent. See Copyright Act 1956 and The Performers Protection Acts 1958 to 1972.

Compliance

This product is in compliance with the essential requirements and other relevant provisions of Directives 2006/95/EC (Low Voltage), 2004/108/ EC (EMC).

2 EN

* Wireless and Ethernet LAN functions are authorized for indoor use only. Hereby, Philips Consumer Lifestyle, declares that this product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A copy of the EC declaration of Conformity is available in the Portable Document Format (PDF) version of the user manual at www.philips.com/ support.

Mains fuse (UK only)

This information applies only to products with a UK mains plug.

This product is tted with an approved molded

plug. If you replace the fuse, use one with:

• the ratings shown on the plug,

• a BS 1362 approval, and

• the ASTA approval mark.

Contact your dealer if you are not sure about what type of fuse to use. Caution: To conform with the EMC directive (2004/108/EC), do not detach the plug from the power cord.

Open source software

Philips Electronics Singapore Pte Ltd hereby offers to deliver, upon request, a copy of the complete corresponding source code for the copyrighted open source software packages used in this product for which such offer is requested by the respective licenses. This offer is valid up to three years after product purchase to anyone in receipt of this information. To obtain source code, please contact open.source@philips.com. If you prefer not

to use email or if you do not receive conrmation

receipt within a week after mailing to this email address, please write to "Open Source Team, Philips Intellectual Property & Standards, P.O. Box 220, 5600 AE Eindhoven, The Netherlands". If you

do not receive timely conrmation of your letter,

please email to the email address above. The texts of the licenses and acknowledgements for open source software used in this product are included

on a separate leaet.

RMVB end user agreement

(AsiaPacicandChinaonly)

Notes to End User: By using this product with RealNetworks software and services, the end user agrees to the following terms of REALNETWORKS, INC:

• End User may only use the software for

private, non-commercial use in accordance with the terms of RealNetworks EULA .

• End User is not allowed to modify, translate,

reverse engineer, decompile, dissemble or use other means to discover the source code or otherwise replicate the functionality of the Real Format Client Code, except to the extent that this restriction is expressly prohibited by applicable law.

• RealNetworks Inc. disclaims all warranties

and conditions other than those set forth in this Agreement which are in lieu of all other warranties, whether express and implied, including but not limited to any implied warranties or conditions of merchantability

and tness for a particular purpose; and

effectively exclude all liability for indirect, special, incidental and consequential damages,

such as but not limited to lost prots.

English

Trademarks

Android is a trademark of Google Inc. Use of this trademark is subject to Google permissions.

The Wi-Fi CERTIFIED Logo is a certication mark

of the Wi-Fi Alliance.

Manufactured under license under U.S. Patent

Nos: 5,956,674; 5,974,380; 6,487,535 & other U.S.

and worldwide patents issued & pending. DTS, the Symbol, & DTS and the Symbol together are registered trademarks & DTS 2.0+Digital Out is a trademark of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved.

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.

DivX , DivX Certied , DivX Plus HD and associated logos are trademarks of Rovi Corporation or its subsidiaries and are used under license. ABOUT DIVX VIDEO: DivX is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is an ofcial DivX Certied device that plays DivX video. Visit divx.com for more information and software tools to convert

your les into DivX videos.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certied device must be registered in order to play purchased DivX Video-on-Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. Go to vod.divx.com for more information on how to complete your registration.

DLNA , the DLNA Logo and DLNA CERTIFIED

are trademarks, service marks, or cer tication

marks of the Digital Living Network Alliance.

HDMI, the HDMI logo, and High-Denition

Multimedia Interface are trademarks or registered trademarks of HDMI licensing LLC in the United States and other countries.

4 EN

3 Important

Read and understand all instructions before you use your SoundBar. If damage is caused by failure to follow instructions, the warranty does not apply.

Safety

Riskofelectricshockorre!

• Never expose the product and accessories to

rain or water. Never place liquid containers, such as vases, near the product. If liquids are spilt on or into the product, disconnect it from the power outlet immediately. Contact Philips Consumer Care to have the product checked before use.

• Never place the product and accessories

near naked ames or other heat sources,

including direct sunlight.

• Never insert objects into the ventilation slots or other openings on the product.

• Where the mains plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.

• Disconnect the product from the power outlet before lightning storms.

• When you disconnect the power cord, always pull the plug, never the cable.

Riskofshortcircuitorre!

• Before you connect the product to the power outlet, ensure that the power voltage matches the value printed on the back or bottom of the product. Never connect the product to the power outlet if the voltage is different.

RiskofinjuryordamagetotheSoundBar!

• For wall-mountable products, use only the supplied wall mount bracket. Secure the wall mount to a wall that can support the combined weight of the product and the wall mount. Koninklijke Philips Electronics N.V. bears no responsibility for improper wall mounting that results in accident, injury or damage.

• Never place the product or any objects on power cords or on other electrical equipment.

• If the product is transported in temperatures below 5°C, unpack the product and wait until its temperature matches room temperature before connecting it to the power outlet.

• Parts of this product can be made of glass. Handle with care to avoid injury and damage.

Riskofoverheating!

• Never install this product in a conned space. Always leave a space of at least four inches around the product for ventilation. Ensure curtains or other objects never cover the ventilation slots on the product.

Riskofcontamination!

• Do not mix batteries (old and new or carbon

and alkaine, etc.).

• Danger of explosion if batteries are

incorrectly replaced. Replace only with the same or equivalent type.

• Remove batteries if they are exhausted or if

the remote control is not to be used for a long time.

• Batteries contain chemical substances, they

should be disposed of properly.

Riskofswallowingbatteries!

• The product/remote control may contain

a coin/button type battery, which can be swallowed. Keep the battery out of reach of children at all times! If swallowed, the battery can cause serious injury or death. Severe internal burns can occur within two hours of ingestion.

• If you suspect that a battery has been

swallowed or placed inside any part of the body, seek immediate medical attention.

• When you change the batteries, always

keep all new and used batteries out of reach of children. Ensure that the battery compartment is completely secure after you replace the battery.

• If the battery compar tment cannot be

completely secured, discontinue use of the product. Keep out of reach of children and contact the manufacturer.

Care for your product

Use only microber cloth to clean the product.

English

Care of the environment

4 Your SoundBar

Your product is designed and manufactured with high quality materials and components, which can be recycled and reused.

When this crossed-out wheeled bin symbol is attached to a product it means that the product is covered by the European Directive 2002/96/ EC. Please inform yourself about the local separate collection system for electrical and electronic products. Please act according to your local rules and do not dispose of your old products with your normal household waste. Correct disposal of your old product helps to prevent potential negative consequences for the environment and human health.

Your product contains batteries covered by the European Directive 2006/66/EC, which cannot be disposed with normal household waste. Please inform yourself about the local rules on separate collection of batteries because correct disposal helps to prevent negative consequences for the environmental and human health.

Congratulations on your purchase, and welcome

to Philips! To fully benet from the support that

Philips offers, register your SoundBar at www. philips.com/welcome.

Main unit

1 2 3

a Standby indicator

When the SoundBar is in standby, the standby indicator turns red.

b Source indicator/ Volume indicator

Source indicator lights up when a source is selected. When you change volume, volume indicators light up to indicate the volume level.

• ARC: Lights up when you select HDMI

ARC as the input source.

• OPTICAL: Lights up when you select

Optical as the input source.

• AUX: Lights up when you select AUX as

the input source.

• COAXIAL: Lights up when you select

COAXIAL as the input source.

c Sound mode indicator/ Volume indicator

Sound mode indicator lights up when a you play an audio source with surround sound. When you change volume, volume indicators light up to indicate the volume level.

• DTS: Lights up when you play DTS audio.

• DOLBY D: Lights up when you play

Dolby audio.

• V.SURR: Lights up when you select Virtual

Surround sound.

6 EN

Remote control

a (Standby-On)

• Switch the SoundBar on or to standby.

When the SoundBar is in standby, the standby indicator turns red.

• When EasyLink is enabled, press and hold

for at least three seconds to switch all connected HDMI CEC compliant devices to standby.

b USB

Switch to USB storage device.

c (Home)

Access the home menu.

d AUDIO

Select an audio language when you play a video.

e Navigation buttons ( / / / )

Navigate menus.

f OK

Conrm an entry or selection.

g OPTIONS

Access more play options while playing a

multimedia le from a USB storage device or

PC (through DLNA).

h +/- (Volume)

Increase or decrease volume.

i (Play)

Start or resume play.

j (Pause)

Pause play.

k / (Fast Backward/ Fast Forward)

Search backwards or forward.

l ZOOM

Zoom into a video scene or picture.

m TREBLE +/-

Increase or decrease treble.

n BASS +/-

Increase or decrease bass.

o SOUND SETTINGS

Toggle through sound modes.

p SURROUND

Toggle between stereo and virtual surround sound.

q SUBTITLE

Select subtitle language for video.

r / (Previous/Next)

Skip to the previous or next track, chapter

or le.

s (Stop)

Stop play.

t (Mute)

Mute or restore volume.

English

u BACK

Return to a previous menu screen.

v INFO

Display information about the current picture, audio, or video.

w AUDIO SOURCE

• AUX: Switch your audio source to the

AUX connection.

• COAXIAL:Switch your audio source to

the coaxial connection.

• OPTICAL: Switch your audio source to

the optical connection. Press twice to switch to HDMI ARC source when your SoundBar is connected to the TV through an HDMI ARC connection.

EasyLink controls

With Easylink, you can control your SoundBar, TV and the connected devices with the standby button on your SoundBar remote control.

• (Standby-On): Press and hold to switch

your SoundBar, TV, and the connected devices to standby.

5 Connect your

SoundBar

This section helps you connect your SoundBar to a TV and other devices. For a comprehensive interactive guide, see www.connectivityguide. philips.com.

Note

• For identication and supply ratings, refer to the

type plate at the back or bottom of the product.

• Before you make or change any connections,

make sure that all devices are disconnected from the power outlet.

Subwoofer

Follow the steps below to position and connect your subwoofer.

Position

Place the subwoofer at least one meter (three feet) away from your SoundBar, and ten centimeters away from the wall. For best results, place your subwoofer as shown below.

8 EN

Note

• The SoundBar and the subwoofer automatically

pair up when you switch on the SoundBar and the subwoofer.

Connectors

e AUDIO IN - AUX

Connect to an analog audio output on the TV or an analog device.

f HDMI OUT (ARC)

Connect to the HDMI input on the TV.

g LAN

Connect to the LAN input on a broadband modem or router.

Connect other devices to your SoundBar.

Side left

USB

Audio, video or picture input from a USB storage device.

Back connectors

HDMI OUT (ARC) LAN

AUX

AC MAINS~

1 3 4

a AC MAINS~

Connect to the power supply.

b (Standby-On)

• Switch the SoundBar on or to standby.

• When the SoundBar is in standby, the

standby indicator turns red.

c DIGITAL IN - OPTICAL

Connect to an optical audio output on the TV or a digital device.

d DIGITAL IN - COAXIAL

Connect to a coaxial audio output on the TV or a digital device.

DIGITAL IN

COAXIALOPTICAL

AUDIO IN

5 762

Connect to TV

Connect your SoundBar to a TV to watch videos. You can listen to audio from TV programs through your SoundBar. Use the best quality connection available on your SoundBar and TV.

Option 1: Connect to TV through HDMI (ARC)

Your SoundBar supports HDMI version 1.4 Audio Return Channel (ARC). If your TV is HDMI ARC compliant, connect your SoundBar to the TV through the HDMI ARC connection. With HDMI ARC, you do not need an additional audio cable to play audio from TV through your SoundBar. (Cable not supplied)

1 Using a High Speed HDMI cable, connect

the HDMI OUT (ARC) connector on your SoundBar to the HDMI ARC connector on the TV. The HDMI ARC connector on the TV might be labeled HDMI IN or HDMI. For details on TV connectors, see the TV user manual.

2 On your TV, turn on HDMI-CEC. For details,

see the TV user manual.

3 If audio from TV does not play automatically,

set up the audio manually (see 'Set up audio for connected devices' on page 11).

English

Option 2: Connect to TV through HDMI

Best quality video

If your TV is not HDMI ARC compliant, connect your SoundBar to the TV through a standard HDMI connection. With a standard HDMI connection, you need an additional audio cable to play the audio from the TV through your SoundBar (see 'Connect audio from TV and other devices' on page 10). (Cable not supplied)

1 Using a High Speed HDMI cable, connect

the HDMI OUT (ARC) connector on your SoundBar to the HDMI connector on the TV. The HDMI connector on the TV might be labeled HDMI IN.

Connect audio from TV and other devices

Play audio from TV or other devices through your SoundBar. Use the best quality connection available on other devices.

Note

• The audio connections in this user manual

are only recommendations. You can use other connections too.

• When your SoundBar and TV are connected

through HDMI ARC, an audio connection is not required.

2 On your TV, turn on HDMI-CEC. For details,

see the TV user manual.

3 To play audio from TV programs through

your SoundBar, connect an additional audio cable (see 'Connect audio from TV and other devices' on page 10).

4 If audio from the TV does not play

automatically, set up the audio manually (see 'Set up audio for connected devices' on page

11).

Option 1: Connect audio through a digital optical cable

Best quality audio

Using an optical cable, connect the OPTICAL connector on your SoundBar to the OPTICAL OUT connector on the device. The digital optical connector might be labeled SPDIF, SPDIF OUT, or OPTICAL. (Cable not supplied)

10 EN

Option 2: Connect audio through a digital coaxial cable

Good quality audio

Using a coaxial cable, connect the COAXIAL connector on your SoundBar to the COAXIAL/ DIGITAL OUT connector on the device. The digital coaxial connector might be labeled DIGITAL AUDIO OUT. (Cable not supplied)

Set up audio for connected devices

When you connect a device to your SoundBar, check the audio settings.

1 On your TV and other devices, turn on

HDMI-CEC. For details, see the user manual of the TV and the other device.

2 Select 'Amplier' from the TV speakers menu

to hear sound from the SoundBar. For details, see the TV user manual.

3 On your SoundBar, turn on System Audio

Control.

If the connected device is not HDMI-CEC compliant, press the correct source button on the remote control to select the audio input.

English

Option 3: Connect audio through analog audio cables

Basic quality audio

Using an analog cable, connect the AUX connectors on your SoundBar to the audio connectors on the device. (Cable not supplied)

VCR

Computers and the Internet

Connect your SoundBar to your computer network and the internet, and enjoy:

• Multimedia content streamed from your

computer: Play music, photo, and video from a computer (see 'Browse PC from SoundBar' on page 18).

• Multimedia content streamed from your

mobile device or tablet:Play music, photo, and video from a mobile device or other media server on your network (see 'Browse a media server from mobile device' on page

19).

• Software update:Update the SoundBar

software through the network (see 'Update software through the Internet' on page 24).

Caution

• Before you try to connect the SoundBar to

a computer network, familiarize yourself with the network router, media server software and networking principles. If necessary, read documentation that accompanies the network components. Philips is not responsible for lost, damaged, or corrupt data.

Wired connection

Connect your SoundBar to your router through a network cable.

What you need

• A network router (with DHCP enabled).

• A network cable (RJ45 straight cable).

• Computer and mobile devices with media

server software installed.

• For software update, make sure that the

network router has access to the Internet,

and is not restricted by rewalls or other

security systems.

Set up the wired network

Connect your SoundBar to your router as shown below, and then switch on the devices.

LAN

Wireless connection

Connect your SoundBar to your router through a wireless connection.

What you need

• A network router (with DHCP enabled). For

best wireless performance, coverage, and compatibility, use 802.11n router.

• Computer and mobile devices with media

server software installed.

• For software update, make sure that the

network router has access to the Internet

and is not restricted by rewalls or other

security systems.

Set up the wireless network

Your SoundBar has a built-in Wi-Fi for easy access to the wireless network. Connect your SoundBar to your router as shown below, and then switch on the devices.

1 Connect the SoundBar to a network router

through a wired connection.

2 Turn on your TV, and switch to the correct

source for the SoundBar.

3 Press (Home). 4 Select [Setup], and then press OK. 5 Select [Network] > [Ethernet], and then

press OK.

6 Follow the instructions on the TV to

complete the setup.

» The SoundBar connects to the internet.

7 If connection fails, a failure message is

displayed on your TV. Press OK to return to the previous menu, and then retry the procedure.

12 EN

1 Connect the SoundBar to a network router

through a wireless connection.

2 Turn on your TV, and switch to the correct

source for the SoundBar.

3 Press (Home). 4 Select [Setup], and then press OK. 5 Select [Network] > [Wireless], and then

press OK.

6 Follow the instructions on the TV to

complete the setup.

» The SoundBar connects to the internet.

7 If connection fails, a failure message is

displayed on your TV. Press OK to return to the previous menu, and then retry the procedure.

Check network settings

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [Network] > [Network Info], and

then press OK.

» The current network settings are

displayed.

Name your SoundBar

To easily identify your SoundBar on a network, name your SoundBar.

1 Turn on your TV, and switch to the correct

source for the SoundBar.

2 Press (Home). 3 Select [Setup], and then press OK. 4 Select [System] > [Device Name], and then

press OK.

» A vir tual keyboard is displayed on your

TV.

5 Press Navigation buttons and OK to enter

the name.

6 Select [OK] on the virtual keyboard to exit.

6 Use your SoundBar

This section helps you use the SoundBar to play media from a wide range of sources.

Before you start

• Make the necessary connections as described

in the user manual.

• Complete the rst-time setup. First-time

setup appears when you turn on the

SoundBar for the rst time. If you do not

complete the setup, you are prompted to complete it each time you turn on the SoundBar.

• Switch the TV to the correct source for the

SoundBar.

English

Adjust the volume

Your SoundBar has incremental volume control. When you change volume or mute your SoundBar, one or multiple Volume indicator light up to indicate the volume level.

• To increase or decrease volume, press +/-

(Volume).

• To mute sound, press MUTE.

• To restore the sound, press MUTE again or

press +/- (Volume).

Choose your sound

This section helps you choose the ideal sound for your video or music.

Sound mode

Select predened sound modes to suit your video

or music.

1 Press SOUND SETTINGS repeatedly to

select a sound setting:

• [Auto]: Automatically select [Movie] or

[Music] based on the sound stream.

• [Movie]: Enjoy a cinematic audio

experience, specially enhanced for movies.

• [Music]: Recreate the original recording

environment of your music, in the studio or at a concert.

• [Original]: Experience the original sound

of your movies and music, without added sound effects.

• [News]: Hear every word with optimized

speech and clear vocals.

• [Gaming]: Enjoy thrilling arcade sounds,

ideal for action-packed video games or loud parties.

2 Press OK to conrm.

Auto volume

Turn the auto volume on to keep the volume constant when you switch to a different source.

1 Press (Home). 2 Select [Setup], and then press OK. 3 Press the Navigation buttons (up/down) to

select [Audio] > [Auto Volume] > [On].

4 Press OK to conrm.

Surround sound mode

Experience an immersive audio experience with surround sound modes.

1 Press SURROUND repeatedly to select a

surround mode.

• [Virtual Surround]: Creates a highly

compelling 5.1 channel listening experience. The sound mode indicator on the main unit lights up.

• [Stereo]: Two-channel stereo sound. Ideal

for listening to music.

Equalizer

Change the high frequency (treble) and low frequency (bass) settings of the SoundBar. Press TREBLE +/- or BASS +/- to change the frequency. The DTS indicator blinks when you press TREBLE

+/- or BASS +/-.

Synchronize picture and sound

If the audio and video are not synchronized, delay the audio to match the video.

1 Press (Home). 2 Select [Setup], and then press OK. 3 Press the Navigation buttons (up/down) to

select [Audio] > [Lip Sync], and then press OK.

4 Select one of the following options, and then

press OK:

• [Auto]: For an HDMI connection,

automatically adjust the audio delay.

• [Manual]: Press the Navigation buttons

(up/down) to manually adjust the audio delay.

• [Off]: Disable automatic adjustment of

audio.

5 Press OK to conrm.

USB storage devices

Enjoy pictures, audio and video on a USB storage device.

What you need

• A USB storage device that is formatted for

FAT or NTFS le systems, and complies with

the Mass Storage Class.

• A USB extension cable, if the USB storage

device does not t into the connector.

Note

• You can use digital cameras connected by USB

if they can play the les without using a special

computer program.

• To play DivX DRM - protected les from a USB

storage device, connect your SoundBar to a TV through an HDMI cable.

14 EN

Playles

1 Connect the USB storage device to the

SoundBar.

2 Press USB.

» The content browser is displayed.

3 Select a le, and then press OK. 4 Press the playback buttons to control play

(see 'Play buttons' on page 15).

Play buttons

Button Action

Navigation buttons

OK Conrm an entry or selection.

(Play)

Navigation buttons (up/

down)

SUBTITLE Select subtitle language for

OPTIONS

For video formats such as DivX and WMV:

• To stop play, press .

• To resume the video from where you

stopped, press (Play).

• To play the video from the start, press OK.

Navigate menus.

Start or resume play. Pause play. Stop play. Skip to the previous or next

track, chapter or le.

Search backwards or forward. Rotate the picture counter-

clockwise or clockwise.

video. Access more play options while

playing a multimedia le.

VOD code for DivX

Before you purchase DivX videos and play them, register the SoundBar on www.divx.com using the DivX VOD code.

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [Miscellaneous] > [DivX(R) VOD

Code], and then press OK.

» The DivX VOD registration code for

your SoundBar is displayed.

Subtitles

If your video has subtitles in multiple languages, select a subtitle language.

1 While playing video, press SUBTITLE to

select a language.

English

Note

• Make sure that the subtitle le has the same

name as the video le. For example, if the video le is named 'movie.avi', save the subtitle le as

'movie.srt' or 'movie.sub'.

• You can play subtitle les in the following

formats: .srt, .sub, .txt, .ssa, .ass, smi, and .sami.

These les do not appear in the le navigation

menu.

Audio, video, and picture options

Use advanced features when you play audio,

video, or media les from a USB storage device or

network media server (through SimplyShare).

DivX

Play DivX videos from a USB storage device.

Note

• To play DivX DRM protected les from a USB

storage device, connect your SoundBar to a TV through an HDMI cable.

Audio options

While playing audio, repeat an audio track or a folder.

1 Press OPTIONS repeatedly to cycle

through the following functions:

• [Repeat One]: Repeat the current track

or le.

• [Repeat All]: Repeat a selected folder.

• [ShufeLoop]: Play audio tracks in

random order.

• [Repeat Off]: Turn off the repeat mode.

Video options

While watching video, select options such as subtitles, audio language, and video settings. Depending on the video source, some options are not available.

1 Press OPTIONS.

» The video options menu is displayed.

2 Press the Navigation buttons and OK to

select and change:

• [Audio]: Select audio language for video.

• [Subtitle]: Select subtitle language for

video.

• [GoTo]: Skip to a specic part of the

video by entering the time of the scene.

• [Repeat Title]: Repeat a title.

• [Repeat All]: Repeat all the tracks.

• [Repeat Off]: Turn off the repeat mode.

• [Video Setting]: Adjust the video output.

Picture options

While viewing a picture, add animation to a slideshow or change the picture settings.

1 Press OPTIONS.

» The picture options menu appears.

2 Press the Navigation buttons and OK to

select and change the following settings:

• [Video Setting]: Adjust the video output.

• [Background Music]: Select the music

track.

• [Slide Timing]: Select the display speed

for each picture in a slide show.

• [Slide Transition]: Select the transition

type for slideshow.

• [ShufeLoop]:Play pictures in random

order.

• [Repeat All]: Repeat a selected folder.

• [Repeat Off]: Turn off the repeat mode.

Slideshows

While playing audio, access fun features such as picture and musical slideshows.

Picture slideshows

View a slideshow of your pictures stored in your USB storage device or network media server.

1 Select a picture from the USB storage device

or network media server, and then press (Play).

2 Press OPTIONS. 3 Press Navigation buttons and OK to select

the following settings:

• [Slide Transition]: Select the transition

type for slideshow.

• [Slide Timing]: Select the display speed

for each picture in a slide show.

4 Press to stop the slideshow.

Musical slideshows

Create a musical slideshow to play music and pictures at the same time.

1 Select a music track, and then press OK. 2 Press BACK, and go to the picture folder. 3 Select a picture, and then press (Play) to

start the slideshow.

4 Press to stop slideshow and music.

Use smartphone

Turn your iPhone or Android smartphone into a virtual remote control, or use it to browse the contents of a USB storage device on your SoundBar.

What you need

• An iPhone (iOS 3.1.3 and above) or Android

(Android 2.1 and above) smartphone.

• A wired or wireless home network.

Before you start

• Connect your SoundBar to your home

network (see 'Computers and the Internet' on page 11).

• Name your SoundBar (see 'Name your

SoundBar' on page 13).

• Connect your smartphone to the same home

network. For details, see your smartphone user manual.

16 EN

Download MyRemote application

Download the Philips application, MyRemote (MyRemote) to your smartphone. This application is free.

Note

• Philips MyRemote is only available for iPhones

and Android smar tphones.

1 Tap the App Store (App Store) icon on the

iPhone or the Market (Market) icon on the Android smartphone.

2 Search for 'Philips MyRemote' application. 3 Follow the instructions on your smar tphone

to download the application.

» The MyRemote (MyRemote) icon is

added to the home screen of your smartphone.

Access MyRemote application

Access the MyRemote application from your smartphone, and then identify your SoundBar on the home network.

1 Tap MyRemote (MyRemote) on your

smartphone.

» Your SoundBar and the other devices

on the network are displayed on your smartphone. A browsing bar with Devices, Remote, and Source tabs is also displayed.

2 If your SoundBar is not found, check the

network connection. Then, tap the Devices (Devices) tab on your smartphone to search again.

3 Tap the SoundBar icon on the smartphone.

» The vir tual remote control is displayed

on the smartphone.

4 To exit the application, press the home

button on your smartphone.

Use your smartphone as a remote control

The virtual remote control is displayed in multiple screens on the smartphone. To access the buttons, swipe the smartphone screen to the left or right. Only the control buttons that are relevant to the play mode are enabled on your smartphone. For example, if you play pictures, only the remote control buttons that are used to control the pictures are enabled. However, if you play a video, additional buttons, such as SUBTITLE are enabled on your smartphone.

1 Launch the application on your smartphone.

» Depending on the play mode, the

relevant remote control buttons are enabled.

2 If the remote control buttons do not appear,

tap the Remote (Remote) tab on your smartphone.

3 Swipe to the left or right screen to access

more buttons.

Note

• Some control functions are not available on

smartphones.

Browse a USB storage device

Browse a USB storage device from your smartphone, and play an audio, video, or

multimedia le.

1 Launch the remote control application on

your smartphone.

2 Connect a USB storage device to your

SoundBar.

3 On your smartphone, tap the Source

(Source) tab, and then select USB (USB).

» The folders in your USB storage device

are displayed.

4 Select a folder to browse, and then select a

le to play.

» The relevant remote control buttons are

enabled on your smartphone.

5 To access the remote control while you

browse the contents, tap the Remote (Remote) tab on your smartphone.

English

Share media through SimplyShare

When you connect your SoundBar to your home network, you can enjoy music, photo, and video stored on a computer or other media server on the network through SimplyShare. With SimplyShare, you can:

• select and play media stored on a computer

through your SoundBar,

• select media stored on a mobile device and

play it on your SoundBar, and

• use your mobile device as a controller to

select content from a media server, and play

it on your SoundBar. The media server can be set up on any DLNA-compatible device such as a computer, smartphone, or tablet.

Note

• You cannot share copyright protected content

through SimplyShare.

What you need

• A wired or wireless home network,

connected to a Universal Plug and Play

(uPnP) router. For best wireless performance,

coverage, and compatibility, use 802.11n

router.

• A LAN cable to connect your SoundBar to

your home network.

• A media server software such as:

• PC running Windows Media Player 11 or

higher, or

• Mac running Twonky Media Server, or

• Mobile devices with media sharing

applications.

Note

• There are numerous media servers in the

market for computers and mobile devices. These media servers support variety of devices, media types, and operating systems. Select a media server based on the device, operating system, and your needs.

Before you start

• Connect your SoundBar to your home

network. For best performance, connect the SoundBar through a wired network (see 'Computers and the Internet' on page 11).

• Connect your computer and other DLNA-

compatible mobile devices to the same home network. For details, see the user manual of the device.

• Make sure that the PC rewall allows you to

run the media server software.

• Make sure that the devices supports DLNA

or media sharing (iOS) features.

• Switch on the devices and the router.

Browse PC from SoundBar

From the SoundBar home menu, access the media

les on your computer and share them through

SimplyShare. To enable media sharing, set up the media server software on your computer.

Set up media server software

Some examples of media servers are as follows. To use other media servers, see the web site of the media server. Microsoft Windows Media Player 11

1 Start Windows Media Player on your PC. 2 Click the Library tab, and then select Media

Sharing.

3 The rst time you select Media Sharing on

your PC,a pop-up screen appears. Check the Share my media box and click OK.

» The Media Sharing screen is displayed.

4 In the Media Sharing screen, make sure that

you see a device marked as Unknown Device.

» If you don't see an unknown device

after a minute or so, check that your PC

rewall is not blocking the connection.

5 Select the unknown device and click Allow.

» A green tick appears next to the device.

6 By default, Windows Media Player shares

from these folders: My Music, My Pictures, and My Videos. If your les are in other folders, select Library > Add to Library.

» The Add to Library screen is displayed.

• If necessary, select Advanced options to

display a list of monitored folders.

7 Select My folders and those of others I can

access, and then click Add.

8 Follow the onscreen instructions to add the

other folders that contain your media les.

18 EN

Microsoft Windows Media Player 12

1 Start Windows Media Player on your PC. 2 In Windows Media Player, click the Stream

tab, and then select Turn on media

streaming.

» The Media streaming options screen is

displayed.

3 Click Turn on media streaming.

» You return to Windows Media Player

screen.

4 Click the Stream tab and select More

streaming options.

» The Media streaming options screen is

displayed.

5 Make sure that you see a media program in

the Local network screen.

» If you don't see a media program, check

that your PC rewall is not blocking the

connection.

6 Select the media program and click Allowed.

» A green arrow appears next to the

media program.

7 By default, Windows Media Player shares

from these folders: My Music, My Pictures,

and My Videos. If your les are in other

folders, click the Organize tab and select

Manage libraries > Music.

» The Music Library Locations screen is

displayed.

8 Follow the onscreen instructions to add the

other folders that contain your media les.

Macintosh OS X Twonky Media (v4.4.2)

1 Visit www.twonkymedia.com to purchase the

software, or download a free 30-day trial to

your Macintosh.

2 Start Twonky Media on the Macintosh. 3 In the Twonky Media Server screen, select

Basic Setup and First Steps.

» The First steps screen is displayed.

4 Type a name for your media server, and then

click Save changes.

5 Back in the Twonky Media screen, select Basic

Setup and Sharing.

» The Sharing screen is displayed.

6 Browse and select folders to share, and then

select Save Changes.

» Your Macintosh rescans the folders

automatically so that they are ready to share.

Play les from your PC

Note

• Before you play multimedia content from the

computer, make sure that the SoundBar is connected to the home network, and the media server software is properly set up.

1 Switch your TV to the correct HDMI source

for your SoundBar.

2 Press (Home).

» The home menu is displayed.

3 Select [Network], and then press OK. 4 Select [Shared Folder] to browse a PC or

[Shared Media Files] to browse a media

server.

5 Select a le, and then press OK. 6 Press the playback buttons to control play

(see 'Play buttons' on page 15).

Browse a media server from mobile device

From your mobile device such as a smartphone or

tablet, access media les on any media server on

the network and share them through SimplyShare.

Note

• Not all devices are capable of sharing media

through SimplyShare. For information about your mobile device, see the user manual of your mobile device.

Download a media sharing application on your mobile device.

• For Android based smartphones and tablets,

search for DLNA media server app in Android Market (Android).

• For iPhones, iPods and iPads, search for media

server app in App Store (Apple). Follow the onscreen instructions to set up the media server software on your mobile device. Make sure that you select the correct settings to use the mobile device as a media server and controller. For details, check the user manual of the mobile application.

English

Control and play les stored on any device

Note

• The exact steps differ from one device to

another. For information about your mobile device, contact the support center of your device.

1 Make sure that the media server application

is set up on your mobile device.

2 Launch the media sharing application on the

mobile device.

» Your SoundBar, mobile device, and

other devices on the home network are automatically detected and displayed on the screen.

3 Select the device that stores your media les.

For example, if you want to play a le from

your mobile device, select the mobile device.

If you want to play a le from your computer,

select your computer.

» The folders in the selected device are

displayed. Depending on the media server, the folder names may vary.

» If you cannot see the folders, make

sure that you enable media sharing on the selected device so that the content is available for sharing.

4 Select a media le to play. 5 From the menu of your mobile device, select

SoundBar to stream the media to your SoundBar.

6 Tap the play buttons on your mobile device

to control the play.

» The media le is shared on the home

network.

» Some media les may not display or

play due to compatibility issues.

EasyLink

The SoundBar supports Philips EasyLink, which uses the HDMI-CEC (Consumer Electronics Control) protocol. EasyLink-compliant devices that are connected through HDMI can be controlled by a single remote control. Philips does not guarantee 100% interoperability with all HDMI-CEC devices.

What you need

• HDMI-CEC compliant devices.

• An HDMI connection between the

connected devices.

Switch on

1 On the TV and other connected devices, turn

on the HDMI-CEC operations. For details,

see the manual of the TV or other devices.

2 Press (Home). 3 Select [Setup], and then press OK. 4 Select [EasyLink] > [EasyLink], and then

press OK.

5 Select [On], and then press OK.

Control devices

Control the SoundBar and the other connected HDMI-CEC compliant devices with a single remote control.

One-touch play

If you enable One-touch play, the TV automatically switches to the correct channel when you play a video in your SoundBar.

One-touch standby

When you press and hold (Standby) on the remote control, the SoundBar and all the connected HDMI-CEC devices (that support one-touch standby) switch to the standby mode. If one-touch standby is enabled on your SoundBar, you can switch to standby with the remote control of the TV or other HDMI-CEC devices.

Auto Power On From TV

If auto power from TV is enabled on your SoundBar, you can turn on your SoundBar when you press and hold the (Standby) on the TV remote control.

20 EN

System Audio Control

When you play a device that has its audio output routed to the SoundBar, turn on System Audio control and select audio source through your connected device. To use one-touch audio, turn on System Audio Control and select audio source through your connected device.

Play audio from SoundBar

Play the audio from a connected device through your SoundBar.

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [EasyLink] > [System Audio Control]

> [On], and then press OK.

4 Press AUDIO SOURCE button on your

remote control to select the audio output for the connected device.

• AUX: Switch your audio source to the

AUX connection.

• COAXIAL: Switch your audio source to

the coaxial connection.

• OPTICAL: Switch your audio source to

the optical connection. Press twice to switch to HDMI ARC source when your SoundBar is connected to the TV through an HDMI ARC connection.

5 Press OK to conrm.

Note

• To play TV audio from your SoundBar through

HDMI ARC connection, select the correct video input on the TV and turn off the TV speakers (see 'Connect to TV' on page 9).

• For details, see the TV user manual.

7 Change settings

This section helps you to change the settings of your SoundBar.

Caution

• Most of the settings are already congured with

the best value for your SoundBar. Unless you have a reason to change a setting, it is best to leave it at the default value.


Change the picture settings to suit your preferences.

Note

• The best setting is automatically selected for the

TV. If you change the setting, make sure that the TV supports the new settings.

Picture settings and format

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [Video] > [Aspect Ratio], and then

press OK.

4 Select one of the following settings, and then

press OK:

• [16:9]: Display picture in 16:9 aspect ratio

if the source is 16:9.

• [Pan Scan 4:3]:Adjust the 16:9 source to

display picture in 4:3 aspect ratio.

• [Letter Box 4:3]: Adjust the 16:9 source

to display picture in 4:3 aspect ratio with black borders on top and bottom.

• [16:10]: Display picture in 16:10 aspect

ratio if the source is 16:10.

English

Picture color

Deep Color recreates the natural world on your TV screen and displays vivid images in over a billion of colors. If your TV supports Deep Color and is connected to your SoundBar through an HDMI cable, you can change the Deep Color.

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [Video] > [Deep Color], and then

press OK.

4 Select one of the following options, and then

press OK:

• [Auto]: Automatically select HDMI Deep

Color.

• [10 bit]: Display 10-bit color.

• [12 bit]: Display 12 bit color.

• [Off]: Display standard 24-bit color.

Picture resolution

Set the picture resolution for your video.

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [Video] > [TV System], and then

press OK.

4 Select a picture resolution, and then press

OK.

Video zoom

Zoom into a picture or video.

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [Video] > [Video Zoom] > [On], and

then press OK.

1080P 24 Hz output

Enable 1080p 24 Hz HDMI output on your TV.

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [Video] > [1080P 24Hz] > [On], and

then press OK.

Video setting

Adjust the video output.

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [Video] > [Video Setting], and then

press OK.

4 Adjust the settings. 5 Press OK to conrm.

Sound

Change the sound settings to suit your preference.

HDMI audio

To hear an HDMI audio output from your TV, connect your SoundBar to the TV through an HDMI cable.

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [Audio] > [HDMI Output], and then

press OK.

4 Select the following options, and then press

OK:

• [PCM]: Switch audio output to stereo.

• [RAW]: Output original DTS or Dolby

audio.

Night mode

For quiet listening, decrease the volume of loud sounds when you play audio. Night mode is only available for Dolby-encoded audio.

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [Audio] > [Night Mode] > [On], and

then press OK.

22 EN

Language

DLNA DMR control

Select a language for the home menu and subtitles.

Home menu

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [System] > [Menu Language], and

then press OK.

4 Select a menu language, and then press OK.

Video subtitle

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [System] > [Subtitle], and then press

OK.

4 Select a subtitle language for your video, and

then press OK.

Scan your USB storage device

Scan the USB storage device connected to your

SoundBar to browse the media les.

Automatic scan

Automatically scan the USB storage device connected to your SoundBar.

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [System] > [Auto Scan] > [Auto scan

on], and then press OK.

Rescan

Rescan the USB storage device connected to your SoundBar or stop scanning.

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [System] > [Scan Storage] > [Rescan

Storage]/ [Stop Scanning Storage] , and then

press OK.

Restrict access to DLNA DMR content.

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [System] > [DLNA DMR] > [On],

and then press OK.

Energy saving

Save energy by changing the following settings.

Auto standby

When playing a le from a USB storage device or

network media server, automatically switch your Soundbar to standby if:

• it is in pause or stop mode, and

• no button is pressed for 15 minutes.

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [System] > [Auto Standby] > [On],

and then press OK.

Sleep timer

Set timers to switch the SoundBar to standby after

a specied time.

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [System] > [Sleep Timer], and then

press OK.

4 Select the duration of the sleep timer.

» The sleep timer can be set up to 60

minutes. If the sleep timer is set to [Off], it switches off.

5 Press OK to activate.

» The SoundBar switches to standby after

the specied time.

English

Screen saver

Automatically switch your SoundBar to screen saver mode if:

• it is in pause or stop mode, and

• no button is pressed for the specied time.

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [System] > [Screen Saver], and then

press OK.

4 Specify the time period by selecting one of

the following options, and then press OK.

• [Off]: Disable the screen saver.

• [2 Minutes]: Switch to screen saver

mode after two minutes.

• [5 Minutes]: Switch to screen saver

mode after ve minutes.

• [10 Minutes]: Switch to screen saver

mode after ten minutes.

8 Update software

To continue to get the best features and support for your SoundBar, update the software regularly. Compare the version of your current software with the latest version on www.philips.com/support.

Check software version

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [Miscellaneous] > [Version Info], and

then press OK.

» The software version is displayed.

Resume play

Resume play from where you stopped.

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [System] > [Resume Play] > [On],

and then press OK.

Apply factory settings

Reset your SoundBar to the default settings.

1 Press (Home). 2 Select [Setup], and then press OK. 3 Select [System] > [Factory Default], and

then press OK.

4 Select [Yes], and then press OK.

Update software through the Internet

1 Connect your SoundBar to the network.

Use a

• wired network connection (see 'Wired

connection' on page 12), or

• a wireless network connection (see

'Wireless connection' on page 12).

2 Press (Home). 3 Select [Setup], and then press OK. 4 Select [Miscellaneous] > [Online Upgrade].

» If an upgrade media is detected, you are

prompted to start or cancel the update.

5 Follow the instruction on the TV to conrm

the update.

» When the software update is complete,

the SoundBar automatically switches off and restarts. If it does not, disconnect the power cord for a few seconds and then reconnect it.

Note

• If the SoundBar cannot connect to the Philips

server, press (Home), and then select [Setup] > [Network] > [Ethernet]/ [Wireless] to set up the network.

24 EN

Update software through USB

What you need

• A USB ash drive, with at least 75MB of

memory. The USB ash drive must be FAT or

NTFS formatted. Do not use a USB hard drive.

• A computer with Internet access.

• An archive utility that supports the ZIP le

format (for example, WinZip® for Microsoft®

Windows® or Stuft® for Macintosh®).

9 Product specifications

Note

• Specications and design are subject to change

without notice.

Step 1: Download the latest software

1 Connect a USB ash drive to your computer. 2 In your web browser, go to www.philips.com/

support.

3 At the Philips Support website, nd your

product and locate the Software and drivers.

» The software update is available as a zip le.

4 Save the zip le in the root directory of your

USB ash drive.

5 Use the archive utility to extract the software

update le in the root directory of the USB ash drive.

» The les are extracted under the root

directory of your USB ash drive.

6 Disconnect the USB ash drive from your

computer.

Step 2: Update the software

1 Connect the USB ash drive to your SoundBar. 2 Switch your TV to the correct source for

your SoundBar.

3 Press (Home), and then select [Setup]. 4 Select [Miscellaneous] > [USB Upgrade]. 5 Follow the instructions on the TV to conrm

the update.

» When the software update is complete,

the SoundBar automatically switches off and restarts. If it does not, disconnect the power cord for a few seconds, and then reconnect it.

Note

• When the software update is in progress, do not

turn off the power or remove the USB ash drive.

Media formats

• Picture les, MP3 media, WMA media, DivX

Plus HD media, USB storage device

File formats

• Audio: .aac, .mka, .mp3, .wma, .wav, .mp4, .m4a

• Video:

• .avi, .divx, .mp4, .mkv, .asf, .wmv, .mpg,

.mpeg, .mov, .m4v

• .rmvb, .rm (Available only in Asia Pacic

• Picture: .bmp, .jpg, .jpeg, .gif, .png

and China)

Audio formats

Your SoundBar supports the following audio les.

Extension Container Audio

codec

.mp3 MP3 MP3 32 kbps ~

.wma ASF WMA 64 kbps ~

.aac AAC AAC, HE-

AAC .wav WAV PCM 1.4 Mbps .m4a MKV AAC 192 kbps .mka MKA PCM 27.648

.mka MKA Dolby

Digital .mka MKA DTS core 1.54 Mbps .mka MKA MPEG 912 kbps .mka MKA MP3 32 kbps ~

Bit rate

320 kbps

160 kbps 192 kbps

Mbps 640 kbps

320 kbps

English

Extension Container Audio

codec

.mka MKA WMA 64 kbps ~

.mka MKA AAC ,

HE-AAC

Bit rate

160 kbps 192 kbps

Video formats

If you have a high denition TV, your SoundBar allows you to play your video les with:

• Resolution: 1920 x 1080 pixels at

• Frame rate: 6 ~ 30 frames per second.

.avilesinAVIcontainer

Audio codec

PCM, Dolby Digital, DTS core, MP3, WMA

.divxlesinAVIcontainer

Audio codec

PCM, Dolby Digital, MP3, WMA

Video codec Bit rate

DivX 3.11, DivX 4.x, DivX 5.x, DivX 6.x

MPEG 1, MPEG 2 20 Mbps (peak

MPEG 4 ASP 10 Mbps max H.264/AVC

HP@4.1/4.0;

MP@3.2/3.1/3.0 WMV9 20 Mbps

Video codec Bit rate

DivX 3.11, DivX 4.x, DivX 5.x, DivX 6.x

MPEG 1, MPEG 2 20 Mbps

MPEG 4 ASP 10 Mbps max

10 Mbps max

40 Mbps)

20 Mbps (peak 40 Mbps)

10 Mbps max

(peak 40 Mbps)

.mp4or.m4vlesinMP4container

Audio codec

Dolby Digital, MPEG, MP3, AAC, HE-AAC

.mkvlesinMKVcontainer

Audio codec Video codec Bit rate PCM, Dolby

Digital, DTS core, MPEG, MP3, WMA, AAC, HEAAC

.asfand.wmvlesinASFcontainer

Audio codec

PCM, Dolby Digital, MP3, WMA

.mpgand.mpeglesinPScontainer

Audio codec

PCM, DTS core, MPEG, MP3

Video codec Bit rate

MPEG 1, MPEG 220 Mbps (peak

MPEG 4 ASP 10 Mbps max H.264/AVC

HP@4.1/4.0;

MP@3.2/3.1/3.0

MPEG 1, MPEG 2

MPEG 4 ASP 10 Mbps max H.264/AVC

HP@4.1/4.0;

MP@3.2/3.1/3.0 WMV9 20 Mbps

Video codec Bit rate

MPEG 4 ASP 10 Mbps max

H.264/AVC

HP@4.1/4.0;

MP@3.2/3.1/3.0 WMV9 20 Mbps

Video codec Bit rate

MPEG 1, MPEG 2

40 Mbps)

20 Mbps (peak 40 Mbps)

26 EN

.rmand.rmvblesinRMcontainer(Available onlyinAsiaPacicandChina)

Audio codec Video

AAC , COOK

codec RV30, RV40 20 Mbps (peak 40

Bit rate

Mbps)

Amplier

• Total output power: 120W RMS (10% THD)

• Frequency response: 20 Hz-20 kHz / ±3 dB

• Signal-to-noise ratio: > 65 dB (CCIR) /

(A-weighted)

• Input sensitivity:

• AUX: 800 mV

Video

• HDMI output: 480i/576i, 480p/576p, 720p,

1080i, 1080p, 1080p24

Audio

• S/PDIF Digital audio input:

• Coaxial: IEC 60958-3

• Optical: TOSLINK

• Sampling frequency:

• MP3: 32 kHz, 44.1 kHz, 48 kHz

• WMA: 44.1 kHz, 48 kHz

• Constant bit rate:

• MP3: 32 kbps - 320 kbps

• WMA: 48 kbps - 192 kbps

Subwoofer

• Output power: 72W RMS (10% THD)

• Power supply: 110-240 V, 50-60 Hz

• Power consumption: 30 W

• Standby power consumption: 0.5 W

• Impedance: 4 ohm

• Speaker drivers: 130 mm (5.25") woofer

• Frequency response: 20 Hz-150 Hz

• Dimensions (WxHxD): 226 x 253 x 280 mm

• Weight: 4 kg

Remote control batteries

• 2 x AAA-R03-1.5 V

English

USB

• Compatibility: Hi-Speed USB (2.0)

• Class support: USB Mass Storage Class (MSC)

• File system: FAT16, FAT32, NTFS

• Maximum memory suppor t: < 2 TB

Main unit

• Power supply: 110-240V, 50-60Hz

• Power consumption: 25 W

• Standby power consumption: ≤ 0.5 W

• Speaker impedance: 8 Ohm

• Speaker drivers: 2 x 64mm (2.5'') woofer + 2

x 25.4 mm (1") tweeter

• Frequency response: 150 Hz - 20 kHz

• Dimensions (WxHxD): 840 x 48 x 110 mm

• Weight: 2.2 kg

10 Troubleshooting

Warning

• Risk of electric shock. Never remove the casing

of the product.

To keep the warranty valid, never try to repair the product yourself. If you have problems using this product, check the following points before you request service. If you still have a problem, get support at www.philips. com/support.


No picture.

• Make sure that the TV is switched to the

correct source for the SoundBar.

No picture on a TV connected through HDMI.

• Make sure that you use a High Speed HDMI

cable to connect the SoundBar and TV. Some Standard HDMI cables do not display properly for some images or Deep Color.

• Make sure that the HDMI cable is not faulty. If

it is faulty, replace it with a new cable.

Sound

No sound from SoundBar speakers.

• Make sure that the SoundBar is not muted.

• Connect the audio cable from your SoundBar

to your TV or other devices. You do not need a separate audio connection when the SoundBar and TV are connected through HDMI ARC connection.

• Set up the audio for the connected device.

• Reset your SoundBar to its factory settings.

Switch it off, and then switch on again.

• On your SoundBar, press the correct source

button to select the correct audio input.

No sound from wireless subwoofer.

1 Switch off the SoundBar and then switch it

on again.

2 Switch the SoundBar to AUX source. 3 Press and hold CONNECT on the

subwoofer until the indicator on the back of the subwoofer blinks.

4 Press and hold Navigation button (right)

for at least three seconds.

» When the wireless connection succeeds,

the indicator on the subwoofer lights up.

» If the wireless pairing fails, repeat steps

1 to 4 to connect your subwoofer to the SoundBar.

Distorted sound or echo.

• If you play audio from the TV through the

SoundBar, make sure that the TV is muted.

Audio and video are not synchronized.

• 1) Press (Home). 2) Select [Setup],

and then press OK. 3) Select [Audio] > [Lip Sync], and then press OK. Press the Navigation buttons ( / ) to select [Auto] or [Manual] and synchronize audio

and video (see 'Synchronize picture and sound' on page 14).

Play

CannotplayaDivXle.

• Make sure that the DivX le is encoded

according to the 'SoundBar' with the DivX encoder.

• Make sure that the DivX le is complete.

DivX or RMVB/RM subtitles do not display correctly.

• Make sure that the subtitle le name is the

same as the movie le name (see 'Subtitles'

on page 15).

Cannot read the contents of a USB storage device.

• Make sure that the format of the USB storage

device is compatible with the SoundBar.

• Make sure that the le system on the USB

storage device is supported by the SoundBar.

EasyLink does not work.

• Make sure that the SoundBar is connected to

a Philips brand EasyLink TV, and the EasyLink option is turned on (see 'Switch on' on page

20).

When you switch on the TV, the SoundBar automatically switches on.

• This behavior is normal when you are using

Philips EasyLink (HDMI-CEC). To make the SoundBar work independently, switch off EasyLink.

28 EN

Network

Wireless network distorted or not found.

• Make sure that the wireless network is not

disturbed by microwave ovens, DECT phones, or other neighboring Wi-Fi devices.

• Place the wireless router and the SoundBar

within ve meters of each other.

• If the wireless network does not work

properly, try a wired network installation (see 'Wired connection' on page 12).

DLNA

My video does not stream smoothly.

• Check that the home network has enough

bandwidth to play the videos. To save the bandwidth on your wireless network, connect your SoundBar to the router through a network cable.

• Use a Wireless N class router (300 mbps)

router for best performance.

• Make sure that the Wi-Fi reception is strong

on your device.

• Check that the video format is supported

by your home theater, the media server application, and the mobile device.

I do not have enough bandwidth on my home network.

• If you are running multiple applications on

your wireless network, stop the applications so that the entire bandwidth is available for content streaming.

• Make sure that you connect your SoundBar to

the network using a wired connection. Whenever possible, connect other devices (such as PC) to the network through a wired connection too.

• Check that the network cables are not damaged.

IcannotseemymedialesonPC.

• Check that you have installed a media server

on your PC, and have enabled le sharing on

your PC.

• Make sure that the SoundBar supports the

PC media les.

• Check the settings on your mobile device to

make sure that media sharing is enabled.

I cannot see my SoundBar when I scan from my mobile device.

• Make sure that the SoundBar is connected to

the same network.

• Check the signal strength to make sure that

your device can receive the signal.

• Make sure that the media server application

that you download on your mobile device is DLNA-compatible.

11 Index

advanced

restore default settings 24 software update 24 software version 24

amplier 27 audio

HDMI audio 22 night mode 22

predened modes 14

settings 22 source 11

specications 27

audio formats 25 audio options 15 auto standby 23

bass 14 browse

USB storage device 14

care

environment 6 product 5

compliance 2 computer

connect to 11 DLNA 18 media server software 18

computer network 11 connect

audio (analog cable) 11 audio (coaxial cable - digital) 11 audio (optical cable - digital) 10 audio from TV and other devices 10 home network 11 TV (HDMI ARC) 9 TV (HDMI) 10

connectors

back connectors 9 side connectors 9

control

Easylink (HDMI-CEC) 8 main unit 6 USB storage device 15

English

disable

HDMI-CEC 20

DivX

subtitles 15

DLNA 18

EasyLink (HDMI-CEC)

control buttons 8

enable

auto standby 23 HDMI-CEC 20 screen saver 24

energy

auto standby 23 screen saver 24 sleep timer 23

factory settings 24 FAQs 2

HDMI

audio 22 TV (HDMI ARC) 9

HDMI-CEC 20

main unit

overview 6

specications 27

media formats 25 media server software 18 multimedia content

from USB storage device 14

network

home network 11 name a device 13 settings 13 troubleshooting 29 update software 24 wired connection 12 wireless connection 12

night mode 22

open source software 3 options

audio 15

overview

HDMI-CEC 20 main unit 6 remote control 7 settings 21

Internet

connect to 11 update software 24

language

onscreen menu 23

legal notices 2

30 EN

connect to 11 DLNA 18 media server software 18

Philips Easylink 20 picture

slideshows 16 troubleshooting 28

play

slideshows 16 troubleshooting 28 USB 14

power options

auto standby 23 screen saver 24 sleep timer 23

preference

audio 22 auto standby 23 menu language 23 screen saver 24 sleep timer 23

productspecications 25

recycling 6 remote control

batteries 27 overview 7

safety

disposal 6 use of the product 5

screen saver 24 settings

audio 22 auto standby 23 HDMI audio 22 HDMI-CEC 20 menu language 23 power 23 screen saver 24 sleep timer 23 video 21

side connectors 9 sleep timer 23 slideshows

animation 16 duration 16 musical 16 picture 16

software

check current version 24 update 24

sound

auto volume 14 bass 14 equalizer 14

predened sound mode 14

surround sound 14 synchronize picture and sound 14 treble 14 troubleshooting 28

specications 25 subwoofer

specications 27

synchronize picture and sound 14

trademarks 4 treble 14 troubleshooting

connection 28 network 29 picture 28 play 28 serial number 2 sound 28

update software

check current version 24 from a USB storage device 25 from network 24

USB

format 27

USB storage device

control buttons 15 play 15

specications 27

update software 25

video

synchronize picture and sound 14

video formats 27

wired network

wired connection 12

wireless network

wireless connection 12

English

32 EN

validade

imprescindível

consumidor

ACRE

CRUZEIRO DO SUL 68-33227216 RIO BRANCO 68-32217642

ALAGOAS

ARAPIRACA 82-35222367 MACEIO 82-32417237 PALMEIRA DOS INDIOS 82-34213452 UNIAO DOS PALMARES 82-32811305

AMAPA

MACAPA 96-32175934

AMAZONAS

MANAUS 92-36633366 MANAUS 92-32324252

BAHIA

BARREIRAS 77-36113854 CAMACARI 71-36219447 CRUZ DAS ALMAS 75-36212839 EUNAPOLIS 73-32815181 FEIRA DE SANTANA 75-32232882 GUANAMBI 77-34512791 ILHEUS 73-32315995 IRECE 74-36410202 ITABUNA 73-36137777 JEQUIE 73-35254141 JUAZEIRO 74-36116456 LAURO DE FREITAS 71-33784021 PAULO AFONSO 75-32811349 RIBEIRA DO POMBAL 75-32761853 SALVADOR 71-32473659 SALVADOR 71-32072070 SALVADOR 71-33356233 SENHOR DO BONFIM 74-35413143 SERRINHA 75-32611794 SANTO ANTONIO DE JESUS 75TEIXEIRA DE FREITAS 73-30111600 VITORIA DA CONQUISTA 77-34221917

CEARÁ

CRATEUS 88-36910019 FORTALEZA 85-40088555 IGUATU 88-35810512 ITAPIPOCA 88-36312030 JUAZEIRO DO NORTE 88-35871973 SOBRAL 88-36110605 TIANGUA 88-36713336 UBAJARA 88-36341233

DISTRITO FEDERAL

BRASILIA 61-33549615 BRASILIA 61-34451991

36314470

ESPIRÍTO SANTO

CACH OEIRA DE IT APEMIRIM 28 -35223 524 COLATINA 27-37222288 GUARAPAR I 27-3 361435 5 LINHARES 27-33715052 SAO MATEUS 27-37635597 VILA VELH A 27-32 891233 VITORIA 27-32233899

GOIÁS

ANAPOLIS 62-33243562 CALDAS NOVAS 64-34532878 CATALAO 64-34412786 FORMOSA 61-36318166 GOIANESIA 62-33534967 GOIANIA 62-32510933 GOIANIA JATAI 64-36363638 LUZIANIA 61-36228519 TRINDADE 62 URUACU 62-33571285

MARANHÃO

ACAILANDIA 99-35381889 BACABAL 99-36212794 CAXIAS 99-35212377 CODO 99-36612942 IMPERATRIZ PEDREIRAS 99-36423142 SANTA INES 98-36537553 SAO JOSE DE RIBAMAR 98-32241581 SAO LUIS 98-33122976

MATO GROSSO

BARRA DO GARCAS 66-34011394 CUIABA 65-33176464 LUCAS DO RIO VERDE 65-35491333 RONDONOPOLIS 66-34233888 VARZEA GRANDE 65-36826502

MATO GROSSO DO SUL

CAMPO GRANDE 67-33831540 DOURADOS 67-34217117

MINAS GERAIS

ARAGUARI 34-32416026 ARAXA 34-36611132 ARCOS 37-33513455 BELO HORIZONTE 31-32254066 BETIM 31-35322088

BOM DESPACHO 37-35222511 CONTAGEM 31-33912994 CORONEL FABRICIANO 31-38411804 DIVINOPOLIS 37-32212353 ELOI MENDES 3 5-32641245

GOVERNADOR VALADARES 33-32716040

GUAXUPE 35-35514124

62-32292908

-35051505

99-35232906

IPATINGA 31-38222332 ITABIRA 31-38316218

ITAJUBA 35-36211315 ITAUNA 37-32412468 JOAO MONLEVADE 31-38512909 JUIZ DE FORA 32-32151514 LAVRAS 35-38210550 MANHUACU 33-33314735 MONTE CARMELO 34-38422082 MONTES CLAROS 38-32218925 MURIAE 32-37224334 PASSOS 35-35214342 PATOS DE MINAS 34-38222588 POCOS DE CALDAS 35-37224618 PONTE NOVA 31-38172486 POUSO ALEGRE 35-34212120 SAO JOAO DEL REI 32-33718306 SAO SEBASTIAO DO PARAISO 35-35313094 SETE LAGOAS 31-37718570 TEOFILO OTONI 33-35225831 UBA 32-35323626 UBERABA 34-33332520 UBERLANDIA 34-32123636 VARGINHA 35-32216827 VICOSA 31-38918000

PARÁ

ALTAMIRA 91-35154349 ANANINDEUA 91-32354831 BELEM 91-32421090 BELEM 91-32542424 CAPANEMA 91-34621100 MARABA PARAGOMINAS 91-30110778 SANTAREM 93-35235322 TUCURUI 94-37871140

PARAÍBA

CAMPINA GRANDE 83-33212128 GUARABIRA 83-32711159 JOAO PESSOA 83-32469689

PARANÁ

ARAPONGAS 43-32521606 CASCAVEL 45-32254005 CIANORTE 44-36292842 CURITIBA 41-32648791 FOZ DO IGUACU 45-35234 115 IRATI 42-34221337 LONDRINA 43-33210077 MARINGA 44-32264620 PARANAGUA 41-34235914 PARANAVAI 44- 342347 11 PATO BRANCO 46-32242786 PONTA GROSSA 42-30275061 RIO NEGRO 47-36450251 SANTO ANTONIO DA PLATINA 43-35341809 UMUARAMA 44-30561485

94-33215574

PERNAMBUCO

CAMARAGIBE 81-34581246 CARUARU 81-37220235 GARANHUNS 87-37610085 PAULISTA 81-34331142 RECIFE 81-34656042 RECIFE 81-32286123 SAO LOURENCO DA MATA 81-35253369 SERRA TALHADA 87-38311401

PIAUÍ

PARNAIBA 86-33222877 TERESINA 86-32230825 TERESINA 86-32214618

RIO DE JANEIRO

BARRA DO PIRAI 24-24437745 BELFORD ROXO 21-27795797 BOM JESUS DO ITABAPOANA 22 -38312216 CABO FRIO 22-26451819 CAMPOS DOS GOYTACAZES 22-27221499 DUQUE DE CAXIAS 21-27711508 ITAGUAI 21-26886491 ITAPERUNA 22-38236825 MAGE 21-26333342 NITEROI 21-26220157 NOVA FRIBURGO 22-25227692 PETROPOLIS 24-22454997 RESENDE 24-33550101 RIO DE JANEIRO 21-24264702 RIO DE JANEIRO 21-25892030 RIO DE JANEIRO 21-25096851 RIO DE JANEIRO 21-24315759 RIO DE JANEIRO 21-33810711 SAO GONCALO 21-27013214 TERESOPOLIS 21-27439467

RIO GRANDE DO NORTE

MOSSORO 84-33164448 NATAL 84-32132345 PAU DOS FERROS 84-33512334

RIO GRANDE DO SUL

BAGE 53-32411295 BENTO GONCALVES 54-34526825 CANELA 54-32821551 CAXIAS DO SUL 54-30211808 ERECHIM 54-33211933 FARROUPILHA 54-32683603 FREDERICO WESTPHALEN 55-37441850 GRAVATAI 5 1-3042 2830 IJUI 55-33327766 LAJEADO 51-37145155 MARAU 54-33424571 MONTENEGRO 51-36324187 NOVO HAMBURGO 51-35823191 OSORIO 51-36632524 PASSO FUNDO 54-33111104 PELOTAS 53-32223633 PORTO ALEGRE 51-32226941 PORTO ALEGRE 51-33256653

RIO GRANDE 53-32323211 SANTA CRUZ DO SUL 51-37153048 SANTA MARIA 55-30282235 SANTA ROSA 55-35128982 TRES DE MAIO 55-35358727 VACARIA 54-32311396 VENANCIO AIRES 51-37411443

RONDÔNIA

CACOAL 69-34431415 PORTO VELHO 69-32273377

RORAIMA

BOA VISTA 95-32249605

SANTA CATARINA

ARARANGUA 48-35220304 BALNEARIO CAMBORIU 47-33630706 BLUMENAU BRUSQUE 47-33557518 CANOINHAS 47-36223615 CHAPECO 49-33221144 CONCORDIA 49-34423704 CRICIUMA 48-21015555 CURITIBANOS 49-32410851 FLORIANOPOLIS 48-32049700 ITAJAI 47-33444777 JARAGUA DO SUL 47-33722050 JOACABA 49-35220418 JOINVILLE 47-34331146 LAGES 49-32244414 LAGUNA 48-36443153 RIO DO SUL 47-35211920 RIO NEGRINHO 47-36440979 SAO MIGUEL DO OESTE 49 -36220026 TUBARAO 48-36261651

SÃO PAULO

AGUAS DE LINDOIA 19-38241524 AMERICANA 19-34062914 AMPARO 19-38072674 ARACATUBA 18-36218775 ARARAQUARA 16-33368710 ASSIS 18-33242649 ATIBAIA 11-44118145 AVARE 14-3 7322142 BARRETOS 17-33222742 BAURU 14-31049551 BIRIGUI 18-36416376 BOTUCATU 14-38134090 CAMPINAS 19-37372500 CATANDUVA 17-35232524 CRUZEIRO 12-31433859 DIADEMA 11-40430669 FERNANDOPOLIS 17-34423752 FRANCA 16-37223898

GUARATINGUETA 12-31335030 GUARULHOS IBITINGA 16-33417665

47-33233907

11-24431153

INDAIATUBA 19-38753831 ITAPETININGA 15-32710936 ITAQUAQUECETUBA 11-46404162 ITU 11-40230188 ITUVERAVA 16-37293365 JALES 17-36324479 JAU 14-36222117 JUNDIAI 11-39644284 LEME 19-35713528 LIMEIRA 19-34413286 LINS 14-35227283 MARILIA 14-34547437 MATAO 16-33821046 MAUA 11-45145233 MOGI DAS CRUZES 11-47941814 MOGI GUAÇU 19-38181171 OSASCO 11-36837343 OURINHOS 14-33225457 PIRACICABA 19-34340454 PORTO FERREIRA 19-35851891

PRESIDENTE PRUDENTE 18-39161028 REGISTRO 13-38212324 RIBEIRAO PRETO SALTO 11-40296563 SANTO ANDRE 11-49905288 SANTOS 13-32272947 SAO BERNARDO CAMPO 11-41257000 SAO CAETANO DO SUL 11-42275339 SAO CARLOS 16-33614913 SAO JOAO DA BOA VISTA 19-36232990 SAO JOSE DO RIO PARDO 19-36085760 SAO JOSE DO RIO PRETO 17-32325680 SAO JOSE DOS CAMPOS 12-39239508 SAO PAULO 11-29791184 SAO PAULO 11-56676090 SAO PAULO 11-22722245 SAO PAULO 11-39757996 SAO PAULO 11-38457575 SAO PAULO 11-22966122 SAO PAULO 11-25770899 SAO PAULO 11-32222311 SAO ROQUE 11-47125635 SOROCABA 15-32241170 TABOAO DA SERRA 11-47871480 TAQUARITINGA 16-32524039 TAUBATE 12-36219080 TUPA 14-34962596 VALINHOS 19-38716629 VOTUPORANGA 17-34214940

SERGIPE

ARACAJU 79-32176080 ITABAIANA 79-34313023 LAGARTO 79-36312656

TOCANTINS

ARAGUAINA 63-34111818 GURUPI 63-33511038 PALMAS 63-32175628

16-36368156

Language Code

Abkhazian 6566 Afar 6565 Afrikaans 6570 Amharic 6577 Arabic 6582 Armenian 7289 Assamese 6583 Avestan 6569 Aymara 6589 Azerhaijani 6590 Bahasa Melayu 7783 Bashkir 6665 Belarusian 6669 Bengali 6678 Bihari 6672 Bislama 6673 Bokmål, Norwegian 7866 Bosanski 6683 Brezhoneg 6682 Bulgarian 6671 Burmese 7789 Castellano, Español 6983 Catalán 6765 Chamorro 6772 Chechen 6769 Chewa; Chichewa; Nyanja 7889 9072

中文

Chuang; Zhuang 9065 Church Slavic; Slavonic 6785 Chuvash 6786 Corsican 6779

esky 6783 Dansk 6865 Deutsch 6869 Dzongkha 6890 English 6978 Esperanto 6979 Estonian 6984 Euskara 6985

6976 Faroese 7079 Français 7082 Frysk 7089 Fijian 7074 Gaelic; Scottish Gaelic 7168 Gallegan 7176 Georgian 7565 Gikuyu; Kikuyu 7573 Guarani 7178 Gujarati 7185 Hausa 7265 Herero 7290 Hindi 7273 Hiri Motu 7279 Hrwatski 6779 Ido 7379 Interlingua (International)7365 Interlingue 7365 Inuktitut 7385

Inupiaq 7375 Irish 7165 Íslenska 7383 Italiano 7384 Ivrit 7269 Japanese 7465 Javanese 7486 Kalaallisut 7576 Kannada 7578 Kashmiri 7583 Kazakh 7575 Kernewek 7587 Khmer 7577 Kinyarwanda 8287 Kirghiz 7589 Komi 7586 Korean 7579 Kuanyama; Kwanyama 7574 Kurdish 7585 Lao 7679 Latina 7665 Latvian 7686 Letzeburgesch; 7666 Limburgan; Limburger 7673 Lingala 7678 Lithuanian 7684 Luxembourgish; 7666 Macedonian 7775 Malagasy 7771 Magyar 7285 Malayalam 7776 Maltese 7784 Manx 7186 Maori 7773 Marathi 7782 Marshallese 7772 Moldavian 7779 Mongolian 7778 Nauru 7865 Navaho; Navajo 7886 Ndebele, North 7868 Ndebele, South 7882 Ndonga 7871 Nederlands 7876 Nepali 7869 Norsk 7879 Northern Sami 8369 North Ndebele 7868 Norwegian Nynorsk; 7878 Occitan; Provencal 7967 Old Bulgarian; Old Slavonic 6785 Oriya 7982 Oromo 7977 Ossetian; Ossetic 7983 Pali 8073 Panjabi 8065 Persian 7065 Polski 8076 Português 8084

Pushto 8083 Russian 8285 Quechua 8185 Raeto-Romance 8277 Romanian 8279 Rundi 8278 Samoan 8377 Sango 8371 Sanskrit 8365 Sardinian 8367 Serbian 8382 Shona 8378 Shqip 8381 Sindhi 8368 Sinhalese 8373 Slovensky 8373 Slovenian 8376 Somali 8379 Sotho; Southern 8384 South Ndebele 7882 Sundanese 8385 Suomi 7073 Swahili 8387 Swati 8383 Svenska 8386 Tagalog 8476 Tahitian 8489 Tajik 8471 Tamil 8465 Tatar 8484 Telugu 8469 Thai 8472 Tibetan 6679 Tigrinya 8473 Tonga (Tonga Islands) 8479 Tsonga 8483 Tswana 8478 Türkçe 8482 Turkmen 8475 Twi 8487 Uighur 8571 Ukrainian 8575 Urdu 8582 Uzbek 8590 Vietnamese 8673 Volapuk 8679 Walloon 8765 Welsh 6789 Wolof 8779 Xhosa 8872 Yiddish 8973 Yoruba 8979 Zulu 9085

Seja Responsável Respeite os direitos autorais

Marcas comerciais são propriedade de Koninklijke Philips Electronics N.V. ou de seus respectivos proprietários.

Especificações sujeitas a alteração sem aviso prévio.

sgpjp_1206/78_v1

back page_78_not in Manaus.indd 6back page_78_not in Manaus.indd 6 2/8/2012 2:32:08 PM2/8/2012 2:32:08 PM

Philips CSS5123/78 user manual

Specifications and Main Features

Frequently Asked Questions

User Manual
