Contents

1 Help and support 4

FAQs 4
Contact Philips 4

2 Notice 4

Copyright 4
Compliance 4
Mains fuse (UK only) 5
Open source software 5
Trademarks 5

7 Change settings 22

Picture 22
Sound 23
Language 24
Scan your USB storage device 24
DLNA DMR control 24
Energy saving 24
Apply factory settings 25

8 Update software 25

Check software version 25
Update software through the Internet 25
Update software through USB 26

English

3 Important 6

Safety 6
Care for your product 7
Care of the environment 7

4 Your SoundBar 7

Main unit 7
Remote control 8

5 Connect your SoundBar 9

Subwoofer 9
Connectors 10
Connect to TV 10

Connect audio from TV and other

devices 11
Computers and the Internet 12
Name your SoundBar 14

6 Use your SoundBar 14

Adjust the volume 14
Choose your sound 14
USB storage devices 15
Audio, video, and picture options 16
Use iPhone 17
Share media through SimplyShare 19
EasyLink 21

9 Product specications 26

10 Troubleshooting 29

11 Index 30

EN

3

1 Help and support

2 Notice

Download a software update and nd answers to

many frequently answered questions (FAQs) on
your product at www.philips.com.

FAQs

If you have a problem, refer to the frequently
asked questions (FAQs) for this SoundBar at
www.philips.com/support.

If you still need help, contact Philips Consumer
Care in your country.

Warning

• Do not attempt to repair your SoundBar

yourself. This may cause severe injur y,
irreparable damage to your SoundBar, or void
your warranty.

Contact Philips

If you contact Philips, you will be asked for the
model and serial number of your product. The
model number and serial number are on the
back or bottom of your product. Note the
numbers before you call Philips:

Model No. __________________________
Serial No. ___________________________

This section contains the legal and trademark
notices.

Copyright

This item incorporates copy protection technology
that is protected by U.S. patents and other
intellectual property rights of Rovi Corporation.
Reverse engineering and disassembly are
prohibited.

Copyright in the UK

Recording and playback of material may require
consent. See Copyright Act 1956 and The
Performers Protection Acts 1958 to 1972.

Compliance

This product is in compliance with the essential
requirements and other relevant provisions of
Directives 2006/95/EC (Low Voltage), 2004/108/
EC (EMC).

* Wireless and Ethernet LAN functions are
authorized for indoor use only.

Hereby, Philips Consumer Lifestyle, declares that
this product is in compliance with the essential
requirements and other relevant provisions of
Directive 1999/5/EC.

A copy of the EC declaration of Conformity
is available in the Portable Document Format
(PDF) version of the user manual at
www.philips.com/support.

4

EN

Mains fuse (UK only)

This information applies only to products with a
UK mains plug.

This product is tted with an approved molded

plug. If you replace the fuse, use one with:

• the ratings shown on the plug,

• a BS 1362 approval, and

• the ASTA approval mark.

Contact your dealer if you are not sure about
what type of fuse to use.

Caution: To conform with the EMC directive
(2004/108/EC), do not detach the plug from the
power cord.

Open source software

Philips Electronics Singapore Pte Ltd hereby
offers to deliver, upon request, a copy of the
complete corresponding source code for the
copyrighted open source software packages used
in this product for which such offer is requested
by the respective licenses. This offer is valid up
to three years after product purchase to anyone
in receipt of this information. To obtain source
code, please contact [e-mail].
If you prefer not to use email or if you do not

receive conrmation receipt within a week after

mailing to this email address, please write to
“Open Source Team, Philips Intellectual Proper ty
& Standards, P.O. Box 220, 5600 AE Eindhoven,
The Netherlands”. If you do not receive timely

conrmation of your letter, please email to the

email address above. The texts of the licenses
and acknowledgements for open source
software used in this product are included on a
separate leaet.

Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.

DivX , DivX Cer tied , DivX Plus HD
and associated logos are trademarks of Rovi
Corporation or its subsidiaries and are used
under license.

ABOUT DIVX VIDEO: DivX
format created by DivX, LLC, a subsidiar y of Rovi

Corporation. This is an ofcial DivX Certied

device that plays DivX video. Visit divx.com for
more information and software tools to convert

your les into DivX videos.

ABOUT DIVX VIDEO-ON-DEMAND: This

DivX Cer tied

in order to play purchased DivX Video-on­Demand (VOD) movies. To obtain your
registration code, locate the DivX VOD section
in your device setup menu. Go to vod.divx.com
for more information on how to complete your
registration.

device must be registered

HDMI, the HDMI logo, and High-Denition

Multimedia Interface are trademarks or
registered trademarks of HDMI licensing LLC in
the United States and other countries.

is a digital video

English

Trademarks

Manufactured under license under U.S. Patent
Nos: 5,956,674; 5,974,380; 6,487,535 & other
U.S. and worldwide patents issued & pending.
DTS, the Symbol, & DTS and the Symbol
together are registered trademarks & DTS

2.0+Digital Out is a trademark of DTS, Inc.
Product includes sof tware. © DTS, Inc. All Rights
Reserved.

The Wi-Fi CERTIFIED Logo is a certication

mark of the Wi-Fi Alliance.

Android is a trademark of Google Inc. Use of this
trademark is subject to Google permissions.

DLNA , the DLNA Logo and DLNA CERTIFIED

are trademarks, ser vice marks, or certication

marks of the Digital Living Network Alliance.

EN

5

3 Important

Read and understand all instructions before you
use your SoundBar. If damage is caused by failure
to follow instructions, the warranty does not apply.

Safety

Risk of electric shock or re!

• Never expose the product and accessories

to rain or water. Never place liquid
containers, such as vases, near the product.
If liquids are spilt on or into the product,
disconnect it from the power outlet
immediately. Contact Philips Consumer
Care to have the product checked before
use.

• Never place the product and accessories

near naked ames or other heat sources,

including direct sunlight.

• Never insert objects into the ventilation
slots or other openings on the product.

• Where the mains plug or an appliance
coupler is used as the disconnect device,
the disconnect device shall remain readily
operable.

• Disconnect the product from the power
outlet before lightning storms.

• When you disconnect the power cord,
always pull the plug, never the cable.

Risk of short circuit or re!

• Before you connect the product to the
power outlet, ensure that the power
voltage matches the value printed on the
back or bottom of the product. Never
connect the product to the power outlet if
the voltage is different.

Risk of injury or damage to the SoundBar!

• For wall-mountable products, use only the
supplied wall mount bracket. Secure the
wall mount to a wall that can suppor t the
combined weight of the product and the
wall mount. Koninklijke Philips Electronics
N.V. bears no responsibility for improper
wall mounting that results in accident, injury
or damage.

• Never place the product or any objects
on power cords or on other electrical
equipment.

• If the product is transpor ted in
temperatures below 5°C, unpack the
product and wait until its temperature
matches room temperature before
connecting it to the power outlet.

• Parts of this product can be made of
glass. Handle with care to avoid injur y and
damage.

Risk of overheating!

• Never install this product in a conned
space. Always leave a space of at least four
inches around the product for ventilation.
Ensure curtains or other objects never
cover the ventilation slots on the product.

Risk of contamination!

• Do not mix batteries (old and new or

carbon and alkaline, etc.).

• Remove batteries if they are exhausted or

if the remote control is not to be used for a
long time.

• Batteries contain chemical substances, they

should be disposed of properly.

Risk of swallowing batteries!

• The product/remote control may contain a

coin type battery, which can be swallowed.
Keep the battery out of reach of children at
all times!

6

EN

1

2 3

Care for your product

4 Your SoundBar

Use only microber cloth to clean the product.

Care of the environment

Your product is designed and manufactured with
high quality materials and components, which
can be recycled and reused.

When this crossed-out wheeled bin symbol is
attached to a product it means that the product
is covered by the European Directive 2002/96/
EC. Please inform yourself about the local
separate collection system for electrical and
electronic products.

Please act according to your local rules and
do not dispose of your old products with your
normal household waste.

Correct disposal of your old product helps to
prevent potential negative consequences for the
environment and human health.

Your product contains batteries covered by the
European Directive 2006/66/EC , which cannot
be disposed with normal household waste.

Please inform yourself about the local rules on
separate collection of batteries because correct
disposal helps to prevent negative consequences
for the environmental and human health.

Congratulations on your purchase, and welcome

to Philips! To fully benet from the support that

Philips offers, register your SoundBar at www.
philips.com/welcome.

Main unit

a Standby indicator

When the SoundBar is in standby, the
standby indicator turns red.

b Source indicator/ Volume indicator

Source indicator lights up when a source is
selected.
When you change volume, volume
indicators light up to indicate the volume
level.

• ARC: Lights up when you connect your

SoundBar to a TV through an HDMI
ARC connection.

• OPTICAL: Lights up when you select

Optical as the input source.

• AUX: Lights up when you select AUX

as the input source.

• COA XIAL: Lights up when you select

COAXIAL as the input source.

c Sound mode indicator/ Volume indicator

Sound mode indicator lights up when a you
play an audio source with surround sound.
When you change volume, volume
indicators light up to indicate the volume
level.

• DTS: Lights up when you play DTS

audio.Blinks when you press a remote
control button.

• DOLBY D: Lights up when you play

Dolby audio.

• V.SURR: Lights up when you select

Virtual Surround sound.

English

EN

7

Remote control

a (Standby-On)

• Switch the SoundBar on or to standby.

When the SoundBar is in standby, the
standby indicator turns red.

• When EasyLink is enabled, press

and hold for at least three seconds
to switch all connected HDMI CEC
compliant devices to standby.

b USB

Switch to USB storage device.

c (Home)

Access the home menu.

d AUDIO

Select an audio language when you play a
video.

e Navigation buttons ( / / / )

Navigate menus.

f OK

Conrm an entry or selection.

g OPTIONS

Access more play options while playing a

multimedia le from a USB storage device

or PC (through DLNA).

h +/- (Volume)

Increase or decrease volume.

i (Play)

Star t or resume play.

j (Pause)

Pause play.

k / (Fast Backward/ Fast Forward)

Search backwards or forward.

l ZOOM

Zoom into a video scene or picture.

m TREBLE +/-

Increase or decrease treble.

n BASS +/-

Increase or decrease bass.

o SOUND SETTINGS

Toggle through sound modes.

p SURROUND

Toggle between stereo and vir tual surround
sound.

q SUBTITLE

Select subtitle language for video.

r / (Previous/Next)

Skip to the previous or next track, chapter

or le.

s (Stop)

Stop play.

t (Mute)

Mute or restore volume.

u BACK

Return to a previous menu screen.

8

EN

v INFO

Display information about the current
picture, audio, or video.

w AUDIO SOURCE

• AUX: Switch your audio source to the

AUX connection.

• COA XIAL:Switch your audio source

to the coaxial connection.

• OPTICAL: Switch your audio source

to the optical connection.

EasyLink controls

With Easylink, you can control your SoundBar,
TV and the connected devices with the standby
button on your SoundBar remote control.

• (Standby-On): Press and hold to switch

your SoundBar, TV, and the connected
devices to standby.

5 Connect your

SoundBar

This section helps you connect your SoundBar to a
TV and other devices.
For information about the basic connections of
your SoundBar and accessories, see the quick start
guide. For a comprehensive interactive guide, see
www.connectivityguide.philips.com.

Note

• For identication and supply ratings, refer to the

type plate at the back or bottom of the product.

• Before you make or change any connections,

make sure that all devices are disconnected
from the power outlet .

Subwoofer

Follow the steps below to position and connect
your subwoofer.

Position

Place the subwoofer at least one meter (three
feet) away from your SoundBar, and ten
centimeters away from the wall.
For best results, place your subwoofer as shown
below.

English

Note

• The SoundBar and the subwoofer

automatically pair up when you switch on the
SoundBar and the subwoofer.

EN

9

TV

Connectors

1

AC MAINS~

1 3 4

AUDIO IN

HDMI OUT (ARC) LAN

COAXIALOPTICAL

DIGITAL IN

AUX

LR

5 762

Connect to TV

Connect other devices to your SoundBar.

Side left

USB

Audio, video or picture input from a USB
storage device.

Back connectors

a AC MAINS~

Connect to the power supply.

b (Standby-On)

• Switch the SoundBar on or to standby.

• When the SoundBar is in standby, the

standby indicator turns red.

c DIGITAL IN - OPTICAL

Connect to an optical audio output on the
TV or a digital device.

d DIGITAL IN - COAXIAL

Connect to a coaxial audio output on the
TV or a digital device.

e AUDIO IN - AUX

Connect to an analog audio output on the
TV or an analog device.

f HDMI OUT (ARC)

Connect to the HDMI input on the TV.

g LAN

Connect to the LAN input on a broadband
modem or router.

10

EN

Connect your SoundBar to a TV to watch videos.
You can listen to audio from TV programs through
your SoundBar. Use the best quality connection
available on your SoundBar and TV.

Option 1: Connect to TV through HDMI
(ARC)

Your SoundBar supports HDMI version 1.4

- Audio Return Channel (ARC). If your TV is
HDMI ARC compliant, connect your SoundBar
to the TV through the HDMI ARC connection.

With HDMI ARC, you do not need an additional
audio cable to play audio from TV through your
So und Bar.

(Cable not supplied)

1 Using a High Speed HDMI cable, connect

the HDMI OUT (ARC) connector on your
SoundBar to the HDMI ARC connector on
the TV.

The HDMI ARC connector on the TV
might be labeled HDMI IN or HDMI. For
details on TV connectors, see the TV user
manual.

2 On your TV, turn on HDMI-CEC. For

details, see the TV user manual.

3 If audio from TV does not play

automatically, set up the audio manually
(see ‘Set up audio for connected devices’ on
page 12).

TV

Option 2: Connect to TV through HDMI

TV

Best quality video

If your TV is not HDMI ARC compliant, connect
your SoundBar to the TV through a standard
HDMI connection.
With a standard HDMI connection, you need an
additional audio cable to play the audio from the
TV through your SoundBar (see ‘Connect audio
from T V and other devices’ on page 11).

(Cable not supplied)

1 Using a High Speed HDMI cable, connect

the HDMI OUT (ARC) connector on your
SoundBar to the HDMI connector on the TV.

The HDMI connector on the TV might be
labeled HDMI IN.

2 On your TV, turn on HDMI-CEC. For

details, see the TV user manual.

3 To play audio from TV programs through

your SoundBar, connect an additional audio
cable (see ‘Connect audio from TV and
other devices’ on page 11).

4 If audio from the TV does not play

automatically, set up the audio manually
(see ‘Set up audio for connected devices’ on
page 12).

Connect audio from TV and
other devices

Play audio from TV or other devices through your
SoundBar.

Use the best quality connection available on other
devices.

Note

• The audio connections in this user manual are

only recommendations. You can use other
connections too.

• When your SoundBar and TV are connected

through HDMI ARC , an audio connection is
not required.

Option 1: Connect audio through a digital
optical cable

Best quality audio

Using an optical cable, connect the OPTICAL
connector on your SoundBar to the OPTICAL
OUT connector on the device.

The digital optical connector might be labeled
SPDIF, SPDIF OUT, or OPTICAL.

(Cable not supplied)

English

11

EN
