Philips CDR-600 User Manual

Audio CD Recorder

CDR-600

Toll Free Help Line

Ligne d’assistance en service libre Linea de ayuda telefónica sin cargo

800-531-0039

xp CDR 600/17 English 20-03-2001 13:27 Pagina 1

Canada

English:

This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the Radio Interference Regulations of the Canadian Department of Communications.

Français:

Cet appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables dans la règlement sur le brouillage radioélectriques édicté par le ministère des communications du Canada.

English

Français

English

___________________________7

Français

_________________________

Español

_________________________

This warning label is located

on the rearside and inside this laser product.

CAUTION: INVISIBLE

LASER RADIATION WHEN OPEN.DO NOT STARE INTO BEAM

DANGER:INVISIBLE LASER RADIATION WHEN OPEN.

AVOID DIRECT EXPOSURE TO BEAM.

VARO! AVATTAESSA JA SUOJALUKITUS OHITEJTAESSA OLET

ALTTIINANAKYMATTOMAALLE LASERSATEILYLLE.ALA KATSO SATEESEEN.

VARNING!OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR

ÖPPNAD OCH SPARREN AR URKOPPLAD.BETRAKTA EJ STRALEN

DANGER - Invisible laser radiation when open.

AVOID DIRECT EXPOSURE TO BEAM

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates,uses and can be used in accordance with the instructions, may cause harmful interference to radio communications.However,there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception,which can be determined by turning this equipment off and on,the user is encouraged to try to correct the interference by one or more of the following measures :

- reorient or relocate the receiving antenna.

- increase the separation between the equipment and receiver.

- connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

- consult the dealer or an experienced radio/TV technician for help.

NOTE

IMPORTANT

THIS PRODUCT WAS FCC VERIFIED UNDER TEST CONDITIONS THAT INCLUDED USE OF SHIELDED CABLES AND CONNECTORS BEWTEEN SYSTEM COMPONENTS.IT IS IMPORTANT THAT YOU USE SHIELDED CABLES TO REDUCE THE POSSIBILITY OF CAUSING INTERFERENCE TO RADIOS,TELEVISION SETS AND OTHER ELECTRONIC DEVICES. IF YOU HAVE ANY PROBLEMS CONTACT YOUR DEALER.

ANY CHANGE OR MODIFICATIONS TO THE EQUIPMENT BY THE USER NOT EXPRESSLY APPROVED BY THE GRANTEE OR MANUFACTURER COULD VOID THE USER’S AUTHORITY TO OPERATE SUCH EQUIPMENT.

xp CDR 600/17 English 20-03-2001 13:27 Pagina 2

Warranty

Veriﬁcation

Registering your product within 10days conﬁrms your right to maximum protection under the terms and conditions of your Philips warranty.

Owner

Conﬁrmation

Your completed Warranty Registration Card serves as veriﬁcation of ownership in the event of product theft or loss.

Model

Registration

Returning your Warranty Registration Card right away guarantees you’ll receive all the information and special offers which you qualify for as the owner of your model.

For Customer Use

Enter below the Serial No.which is located on the bottom of the set.Retain this information for future reference.

Model No. ____________________________________ Serial No._____________________________________

Know these

ssaaffeettyysymbols

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT

REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Return your Warranty Registration card today to

ensure you receive all the beneﬁts you’re entitled to.

This “bolt of lightning” indicates uninsulated material within your unit may cause an electrical shock.For the safety of everyone in your

household,please do not remove product covering.

The “exclamation point” calls attention to features for which you should read the enclosed literatur e closely to prevent operating and maintenance

problems.

WARNING:TO PREVENT FIRE OR SHOCK

HAZARD, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE.

CAUTION:To prevent electric shock,match wide

blade of plug to wide slot,and fully insert.

• Once your Philips purchase is registered,you’re eligible to receive all the privileges of owning a Philips product.

• So complete and return the Warranty Registration Card enclosed with your purchase at once.And take advantage of these important beneﬁts.

CAUTION Use of controls or adjustments or performance of procedures other than herein may result in hazardous radiation exposure or other unsafe operation.

The set complies with the FCC-Rules, Part 15 and with 21 CFR 1040.10. Operation is subject to the following two conditions:

1.This device may not cause harmful interference, and

2.This device must accept any interference received,including interference that may cause undesired operation.

xp CDR 600/17 English 20-03-2001 13:27 Pagina 3

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

7. Do not block any of the ventilation openings.

Install in accordance with the manufacturers instructions.

8. Do not install near any heat sources such as

radiators, heat registers, stoves,or other apparatus (including ampliﬁers) that produce heat.

9. Do not defeat the safety

purpose of the polarized or

grounding-type plug.A polarized plug has two blades with one wider than the other.A grounding type plug has two blades and a third grounding prong.The wide blade or the third prong are provided for your safety.When the provided plug does not ﬁt into your outlet,consult an electrician for replacement of the obsolete outlet.

10.Protect the power cord from being walked on or

pinched,particularly at plugs, convenience receptacles,and the point where they exit from the apparatus.

11.Only use attachments/accessories speciﬁed by the

manufacturer.

12. Use only with a cart, stand, tripod,bracket,

or table speciﬁed by the manufacturer or sold with the apparatus.When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from tip-over.

13.Unplug this apparatus during lightning storms or when

unused for long periods of time.

14.Refer all servicing to qualiﬁed service personnel.

Servicing is required when the apparatus has been damaged in any way, such as if the power-supply cord or plug is damaged,liquid has been spilled or objects have fallen into the apparatus, or when the apparatus has been exposed to rain or moisture, does not operate normally,or has been dropped.

15. Battery usage CAUTION – T o prev ent battery leakage

which may result in bodily injury or damage to the unit:

● Install all batteries correctly, + and - as marked on the unit.

● Do not mix batteries (old and new or carbon and

alkaline,etc.).

● Remove batteries when the unit is not used for a long time.

EL 6475-E002:01/3

IMPORTANT SAFETY INSTRUCTIONS

AC Polarized

Plug

xp CDR 600/17 English 20-03-2001 13:27 Pagina 4

UDIO CD RECORDER

One Year Free Labor

One Year Free Service on Parts

This product must be carried in for repair.

LIMITED WARRANTY

WHO IS COVERED?

You must have proof of purchase to receive warranty service.A sales receipt or other document showing that you purchased the product is considered proof of purchase.

WHAT IS COVERED?

Warranty coverage begins the day you buy your product.For one year thereafter, all parts will be repaired or replaced, and labor is free.After one year from the day of purchase,you pay for the replacement or repair of all parts,and for all labor charges.All parts,including repaired and replaced parts, are covered only for the original warranty period.When the warranty on the product expires, the warranty on all replaced and repaired parts also expires.

WHAT IS EXCLUDED?

Your warranty does not cover:

• labor charges for installation or setup of the product, adjustment of customer controls on the product,and installation or repair of antenna systems outside of the product.

• product repair and/or part replacement because of misuse, accident,unauthorized repair or other cause not within the control of Philips Consumer Electronics Company.

• reception problems caused by signal conditions or cable or antenna systems outside the unit.

• a product that requires modiﬁcation or adaptation to enable it to operate in any country other than the country for which it was designed,manufactured, approved and/or authorized, or repair of products damaged by these modiﬁcations.

• incidental or consequential damages resulting from the product.(Some states do not allow the exclusion of incidental or consequential damages,so the above exclusion may not apply to you.This includes,but is not limited to,prerecorded material, whether copyrighted or not copyrighted.)

• a product that is used for commercial or institutional purposes.

WHERE IS SERVICE AVAILABLE?

Warranty service is available in all countries where the product is ofﬁcially distributed by Philips Consumer Electronics Company. In countries where Philips Consumer Electronics Company does not distribute the product, the local Philips service organization will attempt to provide service (although there may be a delay if the appropriate spare parts and technical manual(s) are not readily available).

MAKE SURE YOU KEEP...

Please keep your sales receipt or other document showing proof of purchase.Attach it to this owner’s manual and keep both nearby.Also keep the original box and packing material in case you need to return your product.

BEFORE REQUESTING SERVICE...

Please check your owner’s manual before requesting service. Adjustments of the controls discussed there may save you a service call.

TO GET WARRANTY SERVICE IN U.S.A., PUERTO RICO OR U.S.VIRGIN ISLANDS...

Take the product to a Philips factory service center (see enclosed list) or authorized service center for repair.When the product has been repaired,you must pick up the unit at the center. Centers may keep defective parts. (In U.S.A.,Puerto Rico and U.S.Virgin Islands,all implied warranties,including implied warranties of merchantability and ﬁtness for a particular purpose, are limited in duration to the duration of this express warranty. But,because some states do not allow limitations on how long an implied warranty may last, this limitation may not apply to you.)

TO GET WARRANTY SERVICE IN CANADA...

Please contact Philips at:

1-800-661-6162 (French Speaking)

1-800-363-7278 (English Speaking) (In Canada,this warranty is given in lieu of all other warranties. No other warranties are expressed or implied, including any implied warranties of merchantability or ﬁtness for a particular purpose. Philips is not liable under any circumstances for any direct,indirect, special, incidental or consequential damages, howsoever incurred,even if notiﬁed of the possibility of such damages.)

REMEMBER...

Please record the model and serial numbers found on the product below.Also, please ﬁll out and mail your warranty registration card promptly. It will be easier for us to notify you if necessary.

MODEL # __________________________________________ SERIAL # ___________________________________________

EL4965F005 / MAC 4110 / 1-97

This warranty gives you speciﬁc legal rights.You may have other rights which vary from state/province to state/province.

Philips Service Solutions Group,P.O.Box 2976, Longview,Texas 75606, USA,(903) 242-4800

xp CDR 600/17 English 20-03-2001 13:27 Pagina 5

General information

Welcome......................................................................................................7

About this manual...................................................................................7

Technical data............................................................................................7

Discs for recording.................................................................................8

Discs for playback....................................................................................8

Maintenance...............................................................................................8

Accessories ................................................................................................8

Operating buttons

Controls........................................................................................................9

Display

DISPLAY indications............................................................................10

DISPLAY messages..............................................................................10

MENU messages...................................................................................12

Connections

Connections at the back..................................................................13

Set up recommandations ...............................................................13

Connections general...........................................................................13

Installation

Analog connections.............................................................................14

Digital connections..............................................................................14

Power supply/Mains.............................................................................15

Remote control

Inserting batteries in the remote control...............................16

Remote control commands...........................................................16

Recording

Insering discs............................................................................................17

Introduction.............................................................................................18

Adjusting the recording level.........................................................19

Recording an entire CD...................................................................19

Recording a single track....................................................................20

Manual recording..................................................................................21

Finalizing CDR & CDRW discs.....................................................22

Unﬁnalizing CDRW discs.................................................................22

Erasing CDRW discs content........................................................23

Playing

Playing a CD............................................................................................23

Selecting a track....................................................................................23

Search..........................................................................................................24

Shufﬂe (random order) play..........................................................24

Repeat CD,track or program.......................................................24

Programming tracks............................................................................24

Menu mode

Remarks about Menu mode..........................................................25

General operation of Menu...........................................................25

A.Text input.............................................................................................26

B. Erasing text.........................................................................................26

C. Reviewing CD text memory...................................................27

D.Auto track increment...................................................................27

E.Balance...................................................................................................28

Fixing problems

Troubleshooting.....................................................................................29

Table of contents

English

xp CDR 600/17 English 20-03-2001 13:27 Pagina 6

Welcome !

Thank you for buying this Philips Compact Disc Recorder.

In the 1980s Philips invented a new audio system - the CD. The CD (compact disc) revealed the new dimensions of digital sound and added to the pleasure of audio.

Compact-disc technology permits a high contrast in both loud and soft passages,with perfect channel separation.

Philips has now further developed compact disc technology and the result is the CD recorder.

With your Philips CD Recordable/ReWritable Recorder, you can record,play and erase your own high-quality audio CDs,subject to legal restrictions on copying. Naturally, you will also be able to play all pre-recorded audio CDs.

Note:In certain countries, including the UK and certain Commonwealth countries, use of the product (or CD Recorder) as shown or suggested in this user manual may require the permission of copyright holders.

Environmental information

All redundant packing material has been omitted.We have done our utmost to make the packaging easily separable into three mono materials: cardboard (box), polystrene foam (buffer) and polyethylene (bags, protective foam sheet).

Your set consists of materials which can be recycled if disassembled by a specialized company. Please observe the local regulations regarding the disposal of packing materials, exhausted batteries and old equipment.

As an ENERGY STAR® partner, Philips has determined that this product meets the ENERGY STAR® guidelines for energy efﬁciency.

About this manual

This manual gives instructions for operating this CD recorder.

Please note:

- the digits (1) throughout the text indicate a sequence of actions necessary to perform a certain operation;

- the arrows (➜) indicate the reaction from the recorder;

- the dots (0) indicate remarks, advice or special options within a sequence of actions.The dot-marked instructions are not necessary for operation.

All instructions in this manual are based on control via the keys on the set.If there are corresponding keys available on the remote control they can be used as well.

Technical data

Subject to modiﬁcation without notice.

General

Power consumption.....................................................................15 W

Power consumption in Standby...............................................6 W

Operating temperature........................................................5-35° C

Weight.....................................................................................................4 kg

Dimensions.......................................................435 x 310 x 88 mm

Audio

Frequency response................................................2Hz-22.050 Hz

Playback S/N (A-weighted)..................................................100 dB

Playback S/N.................................................................................100 dB

Playback dynamic range CDR................................................95 dB

Playback total harmonic

distortion CDR...................................................88 dB = 0.0039 %

Channel separation...................................................................100 dB

Recording S/N (A-weighted).................................................98 dB

Recording S/N digital without SRC...............equal to source

Recording dynamic range.........................................................92 dB

Recording total harmonic

distortion + noise................................................85 dB (0.0056%)

Laser

Type....................................................Semiconductor laser GaAlAs

Wave length ..............................................775-795 nm (at 25° C)

Output power....................2.5 mW (Read,) 35 mW (Write)

Beam divergence..................................................................60 degree

General information

English

CAUTION

INVISIBLE RADIATION WHEN OPEN.

AVOID EXPOSURE TO BEAM.

Note:This warning is located inside the enclosure.

xp CDR 600/17 English 20-03-2001 13:27 Pagina 7

Discs for recording

For recording,make sure to use special audio discs only. These discs are marked with “Digital Audio”and the logos shown below.

There are two different types of audio discs for the use on this CD recorder:

– CD-Audio Recordable (CDR) discs

These discs can be recorded on once and play in all standard CD players and CD recorders, when they are ﬁnalized.

– CD-Audio ReWritable (CDRW) discs

These discs can be recorded on,erased and re-recorded many times and play in CDRW compatible CD players and CD recorders, when they are ﬁnalized.

– All Philips CD players and CD recorders

with the sticker shown here are CDRW compatible.

To ensure proper working of the set we recommend the use of Philips audio CDR and audio CDRW discs only.

Note:Do not use a computer CDR or CDRW as recording will not work!

Recording is permissible insofar as copyright or other rights of third parties are not infringed upon.

In certain countries including the UK and certain Commonwealth countries, use of the product as shown or suggested in this user manual may require the permission of copyright holders.

Discs for playback

Your CD recorder is able to play:

- All pre-recorded audio CDs.

- All Audio CDR and Audio CDRW .

Note:CDR(W) discs containing audio recorded with a computer can only be played when they are correctly treated according the audio standard (IEC958:Consumer part). Single session only!

Maintenance

For recording,it is very important to use discs that are free of dust and scratches.

To clean a CD,wipe it in a straight line from the center towards the edge using a soft,lint-free cloth.A cleaning agent may damage the disc! Write only on the printed side of a CDR or CDRW, and only with a soft felt-tipped pen.

Clean the CD recorder with a soft,slightly dampened lint-free cloth.Do not use any cleaning agents as they may have a corrosive effect.

Do not expose the CD recorder batteries or CDs to humidity,rain, sand or excessive heat (caused by heating equipment or direct sunlight).

Always keep the tray closed to avoid dust on the lens.

The lens may cloud over when the CD recorder is suddenly moved from cold to warm surroundings,making it impossible to play a CD. Leave the CD recorder in the warm environment until the moisture evaporates.

Accessories

- 2 Analog audio cables (with red and white plugs)

- 1 Digital coaxial cable (with black plugs)

- Power cord

- 2 Batteries

- Remote control

- Guarantee

S A M

P L E R

A T E

C O N

V E R T

E R 1 2

5 6 k H z

ReWritable

Recordable

General information

English

xp CDR 600/17 English 20-03-2001 13:27 Pagina 8

Controls

1 ON/OFF

turns the CD recorder ON and OFF

2 Standby indicator 3 Disc tray 4 OPEN/CLOSE /

opens/closes disc tray

5 PLAY/PAUSE 2;

starts play/interrupts play or recording

6 STOP 9

stops/clears a program

7 RECORDING TYPE

selects recording modes

8 RECORD

starts recording,ﬁnalizing, erasing

9 FINALIZE

selects ﬁnalize mode

0 ERASE

selects erasing mode (disc or track)

! SOURCE

selects input source

@ DISPLAY

selects display information,permanent text scrolling and time

# Display

information screen

$ SHUFFLE

plays CD(RW) or program in random order

% PROGRAM

opens/closes program memory

^ SCROLL

activates scrolling of text over the display (once)

& REPEAT

repeats play (all,program or track)

* 5

- searches backward

- cursor control in Menu/Prog. review mode

( 6

- searches forward

- cursor control in Menu/Prog. review mode

) ¡ EASY JOG ™ (rotate)

- previous/next track (Play and Program mode)

- recording level control (recording)

- selects settings (menu on)

ENTER (push)

- plays selected tracks

- selects settings in menu mode

- programs track numbers

¡ STORE/MENU

- enters Menu mode

- stores Menu settings

™ CANCEL/DELETE

- deletes tracks from a program

- deletes text in Menu mode

- returns to a higher level in the menu

£ PHONES

socket for headphones

≤ IR sensor

receives signals from the remote control

Operating buttons

English

CD TEXT RECORDING

OPEN/CLOSE

STORE/M

ENU

CANCEL/DELETE

STANDBY

POWER

TYPE

RECORDING

RECORD

17 18 19 20 21 22 23 244 65 9 10 11 12 13 14 15 167 8

xp CDR 600/17 English 20-03-2001 13:27 Pagina 9

+ 21 hidden pages
